Airlink101 AWLL7025 User manual

Quick Installation Guide
Dual Band Wireless N USB Adapter
Model # AWLL7025
Ver. 1A

Thank you for purchasing Airlink101 Dual Band Wireless N USB Adapter.
Please follow the Quick Installation Guide to configure this product. For
detailed installation instructions on advanced features, please refer to the
User’s Manual that can be found on the provided CD.
Before you begin the installation, please check the items of your package:
Install Utility and Driver
Step 1 Insert the USB adapter into an available USB port of your computer.
Step 2 Windows will launch the Found New Hardware Wizard. The Found
New Hardware Wizard appears differently depending on your computer
operating system, click Cancel to quit the wizard and insert the Installation
CD in the CD drive. Continue to Step 3.
Section 1
Package Contents:
•Dual Band Wireless N USB Adapter
•USB Extension Cable
•Driver & Utility CD
•Quick Installation Guide

Step 3 The Autorun screen will pop up. Click Install Utility and Driver from
the menu.

Note: If the Autorun screen doesn’t appear automatically go to Start, Run,
and type D:\Utility\Setup.exe (where D is the letter of your CD drive) and
click OK.
Windows Vista Users:At this point, you may get a warning message like
the one below. Make sure that you click Allow to continue with the
installation.

Step 4 The InstallShield Wizard will pop up. Click Next at the screen.
Step 5 Click Next to begin the installation.

Step 6 Give Permission to Window to install the driver software
For Windows Vista, click the Install this driver software anyway.
For Windows XP click Continue Anyway at the Windows Logo Screen.
For Windows 2000, click Yes at the Digital Signature Not Found prompt.
Step 7 Click Finish to complete the installation.

Configure the Wireless Adapter
Open the Airlink101 Wireless Monitor utility by double clicking on the
Airlink101 Wireless Monitor Utility icon in the system tray at the bottom right-
hand corner of your screen.
Step 1 Click on AP List tab and select a Network Name (SSID) from the list
you want to connect to and click Connect.
Section 2

Step 2 If encryption is not enabled for the selected access point / router,
skip to Step 7. Otherwise, enter a Profile Name for your wireless setting
and click Next.
Step 3 Verify that the Network Name matches the wireless network you
selected to connect and click Next.

Step 4 Verify that the Authentication Mode and Input Method match to your
wireless router’s settings and click Next.
Step 5 Input the encryption key for your wireless network and click Next.

Step 6 Keep the default IP Setting and click Complete.
Step 7 You should see a blue circle around the antenna icon indicating a
valid connection.

Step 8 Go to the Link Information tab and click on the More button.
Step 9 Verify that you are receiving adequate Signal Strength and Link
Quality and that you have been assigned a valid IP address (instead of all
0’s).

If you do not have adequate Signal Strength, try re-orienting the Access
Point and/or the USB Adapter by using the USB Extension Cable included in
the package to get a better reception.
Troubleshooting
If you are experiencing problems with the connection (unable to connect,
low signal strength, slow connection speed, not working, unstable wireless
connection) you may want to tune your router’s signal by changing the
frequency (if your router supports 5 GHz) and/or channels on the router.
You do not need to change the frequency or channel on the Adapter; it will
automatically pick up the new settings after you reboot the router.
For instructions on changing channels, please refer to the documentation
that comes with the router.
Connecting to the Router with WPS
Airlink101 Dual Band Wireless N USB Adapter has an innovated built-in
WPS (WiFi-Protected Setup) push button which can synchronize and build a
connection between any WPS support router safely and easily. If your
wireless router does not support WPS feature, you will need to set up the
wireless security manually and you can skip this section.
In the instructions below, we are going to use the Airlink101 Dual Band
Wireless N Router AR725W and Dual Band Wireless N USB Adapter
AWLL7025 as the example.
Section 3 (Optional)

Step 1 Push and hold the WPS button on the bottom of the Adapter until you
see the WPS window pops up on the computer monitor.
WPS window:
Step 2 Push the WPS button on the Router, and the blue LED will start
blinking.

Step 3 The Router will now start the handshake with the wireless adapter.
When you see the window below, the wireless connection has been
established.
Technical Support
E-mail: [e-mail]
Toll Free: 1-888-746-3238
Website: www.airlink101.com
*Theoretical maximum wireless signal rate derived from IEEE standard 802.11g and draft 802.11n
specifications. Actual data throughput will vary. Network conditions and environmental factors, including
volume of network traffic, building materials and construction, mix of wireless products used, radio frequency
interference (e.g., cordless telephones and microwaves) as well as network overhead lower actual data
throughput rate. This product is based on IEEE draft 802.11n specification and is not guaranteed to be
compatible with future versions of IEEE 802.11n specification. Compatibility with draft 802.11n devices from
other manufactures is not guaranteed. Specifications are subject to change without notice. Photo of product
may not reflect actual content. All products and trademarks are the property of their respective owners.
Copyright ©2009 Airlink101®
