Nebuliser
AiroMax®
Model: AI-MAX
Instruction Manual
This manual contains important
information for the safe and effective use of
the Airssential AiroMax®Nebuliser System.
Read this manual carefully before use to understand all operational and safety information.
Keep this manual in a safe place for future reference. If you do not understand any part of
these instructions, contact the Airssential Customer Care Centre on [phone].
AIRSSENTIAL

2

3
AiroMax®Nebuliser System
Contents
Introduction ........................................................................................................ 4
Statement Of Intended Use ............................................................................... 4
AiroMax®Components and Accessories ........................................................... 4
General Safety Precautions................................................................................ 6
User Precautions................................................................................................ 7
Operating Instructions........................................................................................ 8
Cleaning, Disinfection, Maintenance and Storage ............................................. 9
Cleaning........................................................................................... 9
Accessory Disinfection .................................................................... 9
Care of the Air Tubing ...................................................................... 9
Filter Replacement......................................................................... 10
Storage ...........................................................................................10
Device Certifications .........................................................................................10
Troubleshooting ................................................................................................11
Disposal ............................................................................................................11
Symbols Used in This Manual...........................................................................12
Warranty and Service ....................................................................................... 12
Technical Specifications................................................................................... 13
Warranty Registration ...................................................................................... 15

4
Introduction
Congratulations on the purchase of your new Airssential AiroMax®Aerosol Therapy
System. This device incorporates the most advanced clinical features for rapid and efficient
medication delivery into the lungs.
The AiroMax®Aerosol Therapy System is suitable for use with all prescribed bronco-therapy
medications including antibiotics. Its speed, durability and nebulising efficiency recommend
this device as an outstanding choice for the administration of nebuliser therapy.
Statement of Intended Use
The AiroMax®Aerosol Therapy System is designed for professional or intensive personal
use in the treatment of either acute or chronic respiratory conditions (including asthma,
chronic obstructive pulmonary disease (COPD), bronchitis, emphysema, cystic fibrosis, etc)
in children or adults. This nebuliser compressor is not for use as either a life-sustaining or
life-supporting device.
Use of this device for any other purpose is inappropriate and may be hazardous.
Use this device to administer only the medication(s) prescribed by your doctor and follow
your doctor’s instructions with regard to dosage, duration of treatment and therapy
frequency.
AiroMax®Nebuliser System
Components & Accessories
Unpacking Your Nebuliser
Remove all contents from the carton. The contents should include the compressor, adult
and child masks, nebuliser bowl, mouthpiece, air tubing, 2 compressor replacement filters,
instruction manual and carrying case.
Ensure all the listed contents are present and undamaged. Report anything missing or
damaged to the point of purchase.
iNote: Retain carton and packing materials for use in shipping or storing the unit.
!Ensure that the polyethylene packing is kept away from the reach of children
and pets to avoid the risk of suffocation!

5
AiroMax®Nebuliser System
The Compressor
Read these instructions before using the AiroMax®compressor. Essential parts of the
compressor are described in Figure 1.
The AiroMax®Aerosol Therapy System is supplied with an Airssential nebuliser bowl.
designed to increase the amount of medication available for inhalation.
!Replacement of original parts with generic components may result in less than
optimal medication delivery or longer treatment times. Nebuliser bowls should
only be replaced by original Airssential branded parts.
1Face Mask
2Nebuliser Bowl
3Filter Cover and Filter
4Compressor Air Outlet
5On/Off Power Switch
6Air Tubing
7Ventilation Slots
8Nebuliser Bowl Holder
1
2
3
5
6
7
8
4

6
General Safety Precautions
The Airssential AiroMax®compressor has been tested and certified to meet international
electrical standards. It is however important to observe the following rules to avoid
electrical accidents:
1. Before using this device, check the integrity of the compressor pump and the
accessories. Ensure the casing and power cord is not damaged. If damage is
observed, contact the Airssential Customer Care Centre to arrange service before
further use. Product safety may be compromised if repairs are performed by
unauthorised personnel and will result in voiding your warranty.
2. Before using the compressor the power cord should be fully unwound and the
device placed to operate on a stable surface. Ensure the power cord does not pass
over sharp edges or is pinched. Keep this device and power cord away from heated
surfaces during operation. When not in use, disconnect the compressor from the
mains power.
3. Do not obstruct the compressor’s ventilation slots during operation or cover the
compressor during use. Do not insert any object or body part (e.g. pencil, fingers,
etc.) into the interior of the device when operational.
4. This device is unsuitable for anaesthesia and lung ventilation. Do not operate the
compressor in the presence of any anaesthetic, inflammable solvent or gas.
5. Protect the compressor from weather conditions or high humidity as it is not protected
against the ingress of water or liquids. Do not leave the compressor exposed to high
heat sources or corrosive chemicals as this may damage the device.
6. Before cleaning the compressor disconnect the power supply. Ensure no water enters
or that the compressor is immersed in any liquid. Do not handle the power plug or the
compressor with wet hands. If the device becomes wet, immediately disconnect the
power and contact the Airssential Customer Care Centre to arrange service.
7. Ensure that the electrical rating shown on the bottom of the compressor corresponds
to your mains voltage and frequency before plugging in the device. If the compressor’s
power plug does not fit your wall socket, have the plug changed by an electrician,
provided the compressor’s electrical rating is suitable to operate under local power
conditions.
8. Compressor operation can be affected by appliances emitting excessive
electromagnetic radiation. If such interference occurs, plug the compressor into a
different power socket.
9. If a malfunction occurs during operation, immediately disconnect the power to the
compressor. Refer to the “Troubleshooting” section of this manual. If the problem does
not resolve, do not open the compressor’s motor compartment or attempt to repair the
nebuliser. Contact the Airssential Customer Care Centre to arrange service.

7
AiroMax®Nebuliser System
User Precautions
1. Do not operate the compressor on carpets or in very dusty environments (e.g. under
a bed) as particulate matter from the environment may be aspirated into the lungs or
cause the compressor to malfunction with extended operation.
2. Do not drop the compressor as it is neither shock proof or impact resistant.
3. Never use the compressor while bathing, showering or dozing. Do not use the device
when feeling tired or dizzy.
4. This nebulising system is not intended for use by anyone (including children) with
limited physical, sensory or mental abilities unless under the supervision of a suitably
trained, responsible person.
Do not use this nebulising system on animals.
5. Some of the nebuliser system’s parts are small and could be swallowed by children
or disabled persons. As a safety precaution, keep all nebuliser system components
out of the reach of children and disabled persons.
6. Follow your doctor’s instructions regarding dosage and regimen of medication. Add
fresh medication to the nebuliser bowl for each treatment. Do not use water only in
the nebuliser bowl for nebulising purposes.
7. During therapy, some operational noise or vibration may be caused by the compressor.
This is normal and does not indicate a malfunction.

8
Operating Instructions
iThe AiroMax®nebuliser is supplied with a variety of accessories to allow
treatment to be individualised to specific needs. Consult with your doctor to
recommend the most suitable accessory to administer your therapy.
iDo not share accessories. All accessories are for single patient use only.
iPrior to the initial use of this equipment, clean the accessories as described in
the section “Cleaning and Disinfecting” of this manual.
Thoroughly wash hands before each use. Check that the accessories are clean before each
use and hence begin therapy, as follows:
1. Open the nebuliser bowl and add the medication. Ensure the BLUE conduction cone
is properly fitted inside the nebuliser bowl.
2. Close the nebuliser bowl and lid by twisting or pressing the two halves together.
3. Connect the air-tubing to the bottom of the nebuliser bowl and the compressor’s air
outlet.
4. Connect the mask or mouthpiece (as directed by your doctor) to the nebuliser bowl.
Either place the mouthpiece in the mouth or fit one of the face masks over the mouth
and nose.
5. Turn the compressor’s ON/OFF switch to position “I” to start the therapy. Ensure to
breath naturally during treatment. To stop or interrupt treatment at any time turn the
ON/OFF switch to position “O”.
iDuring therapy:
i. Sit in an upright and relaxed position. Do not lie down or sit slumped (e.g. in
an armchair) as this may restrict the medication’s entry into the lungs and
decrease the efficacy of the treatment.
ii. Ensure that the nebuliser bowl is not tilted at an angle greater than 45° as this
will decrease the medication’s nebulisation rate
iii. Stop therapy and consult your doctor if the medication’s inhalation makes you
feel unwell or causes pain.
6. At the completion of each treatment turn the ON/OFF switch to position “O” and
disconnect the power to the compressor. Discard any remaining medication in the
nebuliser bowl and clean the nebuliser bowl and accessories as described in the
next section of these instructions.
7. At the completion of each day’s use, clean and disinfect the nebuliser bowl as
described in the next section of these instructions.
8. Store the compressor and accessories in their carry case when not in use.

9
AiroMax®Nebuliser System
Cleaning, Disinfection, Maintenance and Storage
Cleaning
Follow the procedure below to clean the accessories and compressor’s housing.
1. Switch the compressor off and disconnect the power from the device.
2. Disconnect the air-tubing from the nebuliser bowl. Discard any residual medication
remaining in the nebuliser bowl. Rinse all parts of the nebuliser bowl and hence soak in
soapy, warm water for 5 minutes. After soaking, rinse all parts again with warm water.
Arrange the accessories on clean, absorbment towelling to dry before next usage.
Failure to clean nebulising accessories after use may decrease the effectiveness of
the treatment or lead to infection.
3. The compressor housing may be cleaned with a soft damp cloth. Do not use harsh or
abrasive cleaners, to avoid scratching the compressor’s surface. DO NOT immerse
the compressor in any liquid. DO NOT rinse the compressor under running water.
Accessory Disinfection
Disinfect the nebuliser bowl before its initial use, and at the completion of each day’s treatment,
or if the device has been unused for longer than 4 weeks. Follow the cleaning procedure
described above before disinfecting the nebuliser parts by using one of the methods below:
1. Disinfection is recommended using a medical disinfectant solution. Carefully follow
the disinfectant manufacturer’s directions for use.
Alternatively, the accessories may be disinfected by soaking in a mixture of one-part
white vinegar with 3 parts of hot water, for 30 minutes.
2. After disinfecting, arrange the accessories on clean, absorbent towelling to thoroughly
dry before next usage.
Care of the Air-Tubing
1. After each use, check the air-tubing for condensation. If condensation is present, connect
only the air-tubing to the compressor and run the compressor to force air through the
tubing for up to 20 minutes, until the moisture has been removed by the airstream. Forcing
the moisture from the air-tubing in this manner alters the environmental conditions that
promote bacterial accumulation.
2. Do not soak or clean the air-tubing with water or any disinfecting solution. If the outside
of the air-tubing is dirty, wipe it clean with a soft, damp cloth and mild detergent. If the
inside of the air-tubing appears soiled or discoloured, it should be replaced.

10
Filter Replacement
Replace the air filter immediately if the filter is discoloured, damp or after a maximum of
3 months of regular usage. Do not operate the compressor without a filter installed. To
change the air filter:
1. Remove the air filter cover.
2. Remove the old filter and insert the new filter.
3. Replace the air filter cover into position
!
Use only original air filter replacements
from Airssential, in this device. Filters are
single use only. Do not wash and re-use
air filters.
Storage
Store the compressor and accessories in their carry case, when not in use, in an area away
from children and pets. Protect from extreme temperatures, dust, high humidity or direct
sunlight. Always transport the compressor and accessories in its carrying bag.
Device Certifications
The Airssential AiroMax®Nebuliser System is a Class IIa Medical Device. In
compliance with the European standard 93/42/EWG, this device bears the
CE conformity mark of the Medical Devices Directive.
This device conforms to:
- Medical Devices Directive 93/42/EEC
- EN 60601-1 Medical Electrical Equipment -
General Requirements for Safety
- EN 60601-1-2 Electromagnetic compatibility of
medical electrical equipment
- EN13544-1 Respiratory Therapy Equipment (Part 1)
This device complies with the RoHS (Restriction of the use of certain
Hazardous Substances) Directives 2011/65/EU and 2012/19/UE-WEEE.
These directives restrict the marketing of electronic equipment containing
heavy metals or compounds and set standards for the disposal of Waste
Electrical and Electronic Equipment (WEEE) to lessen the impact on our
health and the environment
0197

11
AiroMax®Nebuliser System
Troubleshooting
Check the following if the device should fail during operation.
Problem Possible Cause Solution
Compressor does
not work after
being turned on.
The power plug is
incorrectly inserted into the
power socket.
Switch off the device (“O”) and insert
the power plug properly into the
power socket. Do not use extension
cords etc.
The medication
does not nebulise.
The blue conduction cone
is missing from the
nebuliser bowl.
Re-assemble the nebuliser bowl to
include the conduction cone.
Add more medication (2mL
minimum) into the nebuliser bowl.
No nebulisation or
low nebulisation
rate.
The nebuliser bowl is
incorrectly assembled or
is tilted at an angle greater
than 45°.
Follow the Instructions for Use.
Ensure that the nebuliser bowl is not
tilted at an angle greater than 45°.
The air-tubing is incorrectly
attached to the compressor,
is bent or damaged.
Check the connection of the air-
tubing to the compressor and the
nebuliser bowl. The air-tubing must
not be kinked or bent. Replace the
air tubing if it is damaged.
Too much or too little
medication in the nebuliser
bowl.
Check to ensure the correct amount
of medication is in the nebuliser
bowl.
Note: Medication bowl capacity is
between 2 - 8mL.
The compressor
becomes very
hot.
The compressor’s ventilation
slots are covered or
obstructed.
Do not obstruct or cover the
compressor’s vents during use
Disposal
Waste electrical products should not be disposed of with household waste.
If this compressor is no longer required or it is no longer serviceable, dispose
of the device and its accessories in compliance with local regulations.
Please recycle where facilities exist. Check with your local Council for
recycling information.

12
Symbols Used in this Manual
Warranty and Service
The Airssential AiroMax®Nebuliser System is covered by a limited warranty offered by
Airssential Home Health Care Solutions (“Airssential”), a division of Boian Surgical Pty Ltd., to
the original purchaser of this product. Proof of purchase is required to substantiate warranty
claims. Airssential warrants that for a period of 5 years from the date of purchase, this product
will be free from defects in material and workmanship.
Airssential will replace the compressor if it is defective during the warranty period, provided
the product’s use has been in accordance with the instructions provided. If the product is no
longer available, replacement may be made with a similar product. Airssential shall not be
liable for any incidental or consequential damages caused by the breach of any express or
implied warranty.
This warranty excludes replacement of the accessories due to normal wear, damage to the
compressor due to improper usage or accidental user damage. Freight costs associated with
all warranty claims will be borne by the consumer.
Do not disassemble the compressor, as it cannot be serviced at home. Unauthorised
disassembly of this device will void the warranty. If service is required, contact the Airssential
Customer Care Service Centre to arrange service. Send this device, together with proof of
purchase and a cheque or money order for $9.90 to cover return shipping and insurance to
the Airssential Customer Care Service Centre, 122 Gow St., Padstow, NSW, 2211.Please
include your name, address and a contact telephone number with your service request.
The CE conformity verifies this
device fulfills the provisions of
the European Medical Device
Directive 93/42/EEC
This marking shown on the
product or its literature, indicates
that it should not be disposed of,
with other household wastes at
the end of its working life.
This device complies with the
RoHS (Restriction of the use of
certain Hazardous Substances)
Directives 2011/65/EU and
2012/19/UE-WEEE to lessen the
impact of heavy metals on our
health and the environment
Please note important information
Warning
These warning notes must be
observed to prevent any injury to
the user
BF type applied part
Manufacturer
Protection Class II
0197
i
!

13
AiroMax®Nebuliser System
Technical Specifications
Compressor
Name: Airssential AiroMax®Nebuliser System
Model: AI-MAX
Power supply: 220V ± 22V / 50Hz
Power Consumption: ≤70W
Dimensions: 180 x 205 x 100 mm L*W*H
Weight: 1.8 Kg
Operation mode: Suitable for continuous use
Pressure range: 300-330 kPa; 44-51 psi
Operational flow: 12-16 L/min
Sound level: < 53 dBA
Nebulisation rate: 0.50 mL/min (NaCI 0.9% Solution)
Operating pressure: 120 kPa (1.2 bar)
Operating conditions: +10°C - +40°C, rel. humidity ≤95 %
Storage conditions: -20°C - +70°C, rel. humidity ≤95 %
Classification: Class II equipment Type B applied part
Electrical equipment class: Type II
Water ingress protection: IPXO
Nebuliser Bowl
Particle size: 0.5-5 µm (80%)
Output Rate: ~ 400 µl/min
Capacity: 2 - 8 mL
In accordance with our policy of continual product improvement, technical specifications
are subject to change without notice. Specifications may vary with medication type used
iAll nebuliser accessories should be replaced after 3 months of use.

14

15
AiroMax®Nebuliser System
If service is required, contact the Airssential Customer Care Service Centre
to arrange service on [phone]. Retain this section of the Warranty Card for your records.
Airssential®products are covered by a limited warranty offered by Boian Surgical Pty Ltd. (“Boian Surgical”).
No distributor of Airssential®products may alter the terms of this warranty. Proof of purchase may be required
to substantiate warranty claims.
Boian Surgical warrants that for a period of five years from the date of purchase, this product will be
free from defects in material and workmanship provided it is used as intended by the manufacturer and
according to the instruction manual.
Boian Surgical, at its option, will repair or replace the product or any component of the product found
to be defective during the warranty period. If the product is no longer available, replacement may be
made with a similar product of equal or greater value. Boian Surgical shall not be liable for any incidental
or consequential damages caused by the breach of any express or implied warranty. This warranty
excludes:
• Freight costs
• Damage caused by improper or accidental use
• Damage caused by the use of non-genuine parts
• Replacement of parts due to normal wear
• Damage caused by unauthorised repair or modifications to the product
Do not disassemble the product as this will void the warranty.
To obtain warranty service ship this device, together with proof of purchase and a cheque or money order
made out to “Boian Surgical” for $9.90 to cover return shipping and insurance, to Airssential Customer
Care Service Centre, 122 Gow Street, Padstow NSW 2211. Please include your name, address and a
contact telephone number with your request.
Date of Purchase:................................
Product Purchased:.................................................................................................................
Serial No. (if applicable):......................................... Date of Purchase: ...................................
Buyer Registration
Name: ......................................................................................................................................
Address: ..................................................................................................................................
.............................................................................................Postcode: ...................................
Email or Phone: .......................................................................................................................
This unit was purchased from:
Name: ......................................................................................................................................
Coupon to be returned at time of purchase
Warranty Registration
AIRSSENTIAL
Airssential Customer Care Service Centre
122 Gow Street, Padstow NSW 2211. Phone: [phone].
Airssential®Home Health Care Solutions is a division of Boian Surgical Pty Ltd. Airssential®and AiroMax®are the registered trademarks of
Boian Surgical Pty Ltd. These products are distributed under a quality management system certified as complying with ISO9001:2008.

16
Vitalic®Commando BMI Digital Scales
Airssential Home Health Care Solutions
122 Gow Street, Padstow NSW 2211
Phone [phone]
Airssential®Home Health Care Solutions is a division of Boian Surgical Pty Ltd.
Airssential®and AiroMax®are the registered trademarks of Boian Surgical Pty Ltd.
These products are distributed under a quality management system certified as complying with ISO9001:2008.
www.airssential.com.au
MADE IN CHINA
Ningbo Jiangbei Ruijing Medical Equipment Co. Ltd.
Jiangbei District, Ningbo, Zhejiang, China 315033
V1.18.09
AIRSSENTIAL
0197
