Airwell MAY 90RCE User manual

Owner’s Manual
High Quality Window Type Room Air Conditioner
MAY 90RCE
Standby
Operate
Timer
Filter
RCA INST MANUAL

INTRODUCTION
PRODUCT DESCRIPTION
USE OF WIRELESS REMOTE CONTROL
REMOTE CONTROL
ON UNIT CONTROLS
MODES OF OPERATION, FUNCTIONS AND FEATURES
OPERATION PROCEDURE
Turning on the air conditioner
Ventilating operation
Cooling operation
Cooling operation with auto fan mode
Heating operation
Heating operation with auto fan mode
Auto cooling / heating operation
Dry operation
Selecting the temperature
Sleep function
Timer operation
Timer operating modes
Turning off the air conditioner
Current clock time set
PROTECTION MODES
CARE AND MAINTENANCE
OPERATING TIPS
PRECAUTIONS
BEFORE CALLING FOR SERVICE
CONTENTS
1
2
3
4
6
7
8
8
8
8
8
8
8
9
9
9
9
10
11
11
11
12
13
14
15
16
IF YOUR AIR
CONDITIONER IS FOR
COOLING ONLY, PLEASE
DISREGARD THE
HEATING INSTRUCTIONS
PLEASE READ THESE
INSTRUCTIONS BEFORE
OPERATING THE AIR
CONDITIONER
RCA INST MANUAL

This air conditioner is a domestic electrical product of the class 1 anti-
shock protection category. The user should have grounding
equipment to ensure that the grounding terminal of the air
conditioner’s plug can be secured grounded, the method of power
connection in the air conditioner is M type connection.
This air conditioner fully utilizes water condensation. This improves
condensation effects and increases air cooling efficiency. Moreover,
we have adopted special noise reduction devices to reduce the noise
of water pumping.
The maximum input power and electric current marked on the label
are values under the most condition before the air conditioner left the
O
factory. The outdoor temperature was 43 C. But the input power and
electric current rating marked on the label were obtained from testes
conducted under conditions in which the outdoor temperature was
O
35 C and voltage was 220V.
The noise value marked on the label was obtained from tests
conducted in the Noise Measurement Room at the factory.
The water proof level marked on the label is outdoor IXP4. That is
where the air conditioner is in stated of actual installation, the front
cover and the wall is sealed. Under these conditions, the IXP4 test is
carried out on the outside unit of the air conditioner.
Note: If your air conditioner is the type that for cooling only, ignore the
instructions related to heating.
INTRODUCTION - GENERAL INFORMATION
IMPORTANTNOTICE:
This air conditioner must be
grounded to protect against
electrical shock.
Electrical connections and
power cord replacement
should be made by
authorized electricians and in
accordance with electrical
regulations and local codes.
Cooling
Heating.
Dehumidifying
Air Filtration
Ventilation
To ensure correct and safe use of the air conditioner, be sure to install
in accordance with the installation instructions. Before using
the air conditioner, read these instructions carefully and keep them in a
safe place.
This window-type air conditioner can be used for commercial, residential
or other purposes.
properly
1
RCA INST MANUAL

Horizontal Air Louvre
Air Exhaust Control
Power Cord
Air Intake Grille Air FilterFront Panel
Reset key (H) (manual control button)
Protective Cover of
the Control Panel
Vertical Air Louvre
adjustment Knob.
ON UNIT INDICATORS AND CONTROLS
PRODUCT DESCRIPTION
AIR CONDITIONER CONTROL PANEL
Cool / heat / on / off air conditioner operation
keys (manual control buttons)
Power Indicator Light (A)
Operation Indicator Light (B)
Timer Indicator Light (C)
Filter Indicator Light (D)
Air Conditioner
Control Unit
2
RCA INST MANUAL

When the room is full of fouled air, you can put the air exhaust lever
to open position to discharge the fouled air out of the room.
Four positional adjustments can be made to the direction of this
machine’s upper air outlet. Select the air direction that best
meets your requirements.
VENTILATION
AIR FLOW DIRECTION ADJUSTMENT
Note:
If the lever for air outlet
adjustment is kept in
the open position, the
effectiveness of the air
cooling operation and
the drying function will
be reduced.
Ventilation (air exhaust control)
Vertical
adjustment of air
exhaust louvre
Horizontal
adjustment of air
exhaust louvre
3
RCA INST MANUAL

4
COOL Cools, dehumidifies and filters the room air. Maintains the desired room
temperature.
OPERATION MODES, FUNCTIONS
AND FEATURES
SLEEP Designed to create comfortable sleeping conditions. When in COOLING mode,
the temperature rises one degree centigrade every hour, for to three hours, from
the start of the mode. The temperature rise prevents the feeling of over-cooling
while sleeping (when your body is at rest). In HEATING mode the reverse occurs;
the air conditioner lowers its temperature one-degree every hour. When in SLEEP
mode, the air conditioner will be automatically turned off after have operated for
seven hours. The result is a more comfortable and invigorating sleep, which leaves
you feeling fresh and energetic on the next morning.
TIMER Real time control and display, automatically turns the air conditioner ON and
OFF according to the time of day setting, ensuring comfort conditions before
returning home, without wasting electricity. It turns the air conditioner off
automatically when sleeping.
HOT KEEP In HEATING and in AUTO FAN, the fan will be turned off when the compressor
is not in operation and will not be restarted, unless the indoor coil reaches
adequate temperature. The fan speed will vary automatically according to the
room temperature.
AUTO FAN The air conditioner automatically selects the FAN speed in accordance to with the
room temperature. At the start, the unit operates at high fan speed. As the room
air approaches to the desired temperature, the fan switches to a lower speed for
quieter operation.
FAN Recirculates and filters the room air. Maintains constant air movement in
the room.
DRY Dehumidifies and softly cools the room In DRY Mode, the air conditioner
operates at an inceased dehumidifying power. This function is recommended
to be used when temperature is rather low but the humidity is high.
AUTO Automatically switches from COOLING to HEATING or from HEATING to
COOLING, maintaining the desired temperature according to the room conditions.
HEAT Heats and filters the room air. Maintains the desired room temperature.
RCA INST MANUAL

BUZZER A soft buzzer will sound from the indoor unit display to indicate that a command
sent by the remote control has been accepted and stored in the unit s memory.
This feature may be easily cancelled by the user from the display panel.
3-MIN
DELAYED RUN
This compressor is protected by a three-minute delayed restart.
ON UNIT
OPERATION
The air conditoner can be aturned ON for COOLING or HEATING or be turned
OFF directly form the indoor unit display panel without the use of the remote
control.
SETTING
STORED
The air conditioner will store all the settings of the MODE button in COOL, HEAT,
AUTO, DRY and FAN
FILTER
INDICATION Filter indicator on the indoor unit display is turned on when the filter requires
cleaning. After cleaning and reistalling the filter, the system should be reset.
MEMORY The microprocessor retains the last data entry whether or not the unit is plugged
in. Therefore, when the unit restarts after a power distruption or failure, it will
resume operating in the same mode as before the power was disrupted.
5
RCA INST MANUAL

USE OF WIRELESS REMOTE CONTROL
WIRELESS REMOTE
CONTROL PUTS ALL
FUNCTIONS AT YOUR
FINGERTIPS
● Aim at the infrared signal receiver on the room air conditioner when operating.
● The remote control signal can be received at a distance of up to about 8 m.
● Be sure that there is nothing between the remote control and the signal receptor.
● Do not drop or throw the remote control.
● Do not place the remote control in a location exposed to direct sunlight, or next to a
heating unit, and/or other heat source.
● Do not expose the air conditioner signal receiver to a strong light such as fluorescent
lamp or sunlight
REMOTE CONTROL BATTERY CHANGE
● Remove the batteries from the remote control as shown.
● Use two 1.5 volt size AAA batteries
● Perform reset operation by pressing buttons (9), (10), (13), (14)
6
Prior to operating your air
conditioner, make sure that:
PRIOR TO
OPERATION
● The unit is properly
plugged into the electrical
socket.
● Stand bu Indicator (A) on the
unit's display is lit, meaning
that the air conditioner is ready
to accept your remote control
command.
● The red tap protecting the
remeote control batteries has
been removed.
● For clock setting, see page 11.
Use the remote control holder
when unit is not in use.
REMOTE CONTROL
HOLDER (DESK TYPE)
Remote control can be slipped
in or out its holder.
RCA INST MANUAL

1
2
3
4
5
6
7
REMOTE CONTROL
7
AUTO
ON
OFF
MODE
+
-
TIMER
SET
CLEAR
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
START/STOP button
Operation mode
selection button
COOLING
HEATING
AUTO COOL/HEAT
DRY
FAN
FAN SPEED and
AUTO FAN button
Room temperature
UP button
Room temperature
DOWN Button
SLEEP button
Airflow direction
AUTO-CONTROL
button
TIMER button
TIMER UP button
TIMER DOWN button
LCD operation display
Infrared signal
transmitter
TIMER SET button
TIMER CLEAR button
Transmission sign
8
9
10
11
12
13
14
15
AUTO
ON
OFF
MODE
+
-
TIMER
SET
CLEAR
RCA INST MANUAL

OPERATION PROCEDURE
MODE
+
-
TIMER
SET
CLEAR
MODE
+
-
TIMER
SET
CLEAR
MODE
+
-
TIMER
SET
CLEAR
MODE
+
-
TIMER
SET
CLEAR
AUTO
ON
OFF
AUTO
ON
OFF
AUTO
ON
OFF
AUTO
ON
OFF
AUTO
ON
OFF
MODE
+
-
TIMER
SET
CLEAR
Press START/STOP button (1) to turn the air conditioner. After connecting to the
power supply,Theindicator (B)on the air conditioner light up, indicating that the air
conditioner is in the standby status. Please note that LCD operation display (11) will
always show the last mode of operation and the function used. If you
want to change the control settings, proceed according to the following instructions.
Otherwise, the air conditioner will start and operate in the same mode and functions prior to
being turned off.
Select the ventilating mode by pressing MODE button (2). Switch to the desired
fan speed by pressing FAN speed button (3).
Select the COOLING mode by pressing MODE button (2). Switch to the desired
FAN SPEED or to AUTO FAN by pressing button (3). Select suitable temperature
setting. By selecting the COOLING mode, the air flap will move automatically to air
delivery position, optimal for cooling.
This operation starts with the highest air flow in order to quickly lower the room
temperature. It will then automatically switch to the low air flow to quietly maintain
the selected temperature.
Select the HEATING mode by pressing MODE button (2). Switch to the
desired FAN SPEED or to AUTO FAN by pressing FAN button (3). Select
suitable temperature setting. By selecting the HEATING mode, the air flap will
move automatically to air delivery position, optimal for heating.
TURNING ON THE AIR CONDITIONER
VENTILATING OPERATION
COOLING OPERATION
COOLING OPERATION WITH AUTO FAN MODE
HEATING OPERATION
previous
HEATING OPERATION WITH AUTO FAN MODE
This operation starts with the highest air flow in order to quickly raise the room
temperature. It will then automatically switch to a lower air flow to quietly maintain
the selected temperature. HEATING with AUTO FAN will automatically provide
the user with the HOT KEEP function. The fan will be turned off when the indoor
coil temperature is not sufficiently hot to prevent uncomfortable cold air drafts.
AUTO
ON
OFF
MODE
+
-
TIMER
SET
CLEAR
8
RCA INST MANUAL
