Airzone Aidoo Z-Wave Plus Use and care manual

Content
ENVIRONMENTAL POLICY_________________________________________________________________________ 3
BEFORE STARTING__________________________________________________________________________________ 4
AIDOO Z-WAVE PLUSTM BY AIRZONE ___________________________________________________________ 5
>Device elements __________________________________________________________________________ 5
>Technical specs ___________________________________________________________________________ 6
ASSEMBLY AND CONNECTION ___________________________________________________________________ 7
>Assembly __________________________________________________________________________________ 7
>Connection_________________________________________________________________________________ 7
>Self-diagnosis_____________________________________________________________________________ 8
CONFIGURATION ____________________________________________________________________________________ 9
>Add/Remove Aidoo Z-Wave Plus into a Z-Wave network (classic)_____________ 9
>Standard Inclusion _________________________________________________________________ 9
>Standard exclusion_________________________________________________________________ 9
>SmartStart Inclusion_____________________________________________________________________ 9
>S2 Secure inclusion ______________________________________________________________________ 10
Z-WAVE COMMUNICATION________________________________________________________________________ 10
>Supported Command classes__________________________________________________________ 10
>Supporting command class basic _______________________________________________ 11
>Supporting command class indicator___________________________________________ 11
>Notication Command Class _____________________________________________________ 11
>Associations _________________________________________________________________________ 11
>Device control. Z-Wave application command class mapping___________________ 12
>Reset to the factory settings___________________________________________________________ 13
>Firmware Update_________________________________________________________________________ 13
EN

3
EN
Environmental Policy
• Never dispose of this equipment with household waste. Electrical and electronic
products contain substances that can be harmful to the environment if not
properly handled. The crossed-out waste bin symbol indicates separate collection
of electrical devices, which must be separated from other urban waste. For correct
environmental management, at the end of its useful life the equipment should be
taken to the collection centers provided for this purpose.
• The parts that make it up can be recycled. Therefore, please respect the regulations
in force regarding environmental protection.
• If you replace the equipment, the original equipment must be returned to your
dealer or deposited at a specialized collection center.
• Violations are subject to the penalties and measures stipulated in environmental
protection law.

4
EN
• Check the polarity of each device's connectors. A wrong connection can seriously
damage the product.
• To connect to the system, use Airzone cable: four-wire cable (2x0.22 mm2twisted
shielded wires for data communications and 2x0.5mm2wires for power supply).
• For equipment using R32 refrigerant, verify the compliance with the local
refrigerant regulation.
• The system must be installed by a qualified technician.
• This product must not be modified or disassembled under any circumstances.
• Do not handle the system with wet or damp hands.
• In the case of any malfunction of this appliance, do not repair it yourself. Contact the
sales distributor or service dealer for repair or disposal of the product.
• Check that the HVAC installation has been installed according to the manufacturer's
requirements, complies with local regulations in force and is working correctly
before you install the Airzone system.
• Place and connect the elements in your installation in accordance with current
regulations covering electrical installations.
• All connections must be made with the power supply completely turned off.
• Take care not to short circuit any of the system's connections.
• Please refer carefully to the wiring diagram and these instructions when wiring.
• Connect all wiring securely. Loose wiring may cause overheating at the connection
points and is a possible fire hazard.
• Do not locate the Airzone communication bus close to power lines, fluorescent
lights, actuators, etc. as this may cause interference in communications.
• The connection to the external power supply must include a main switch or other
method of disconnection that includes a constant separation for all polarities,
in accordance with appropriate local and national regulations. The system will
automatically restart if the power supply is turned off. Use separate circuits for the
unit that is to be controlled and the power supply to the system.
Before Starting

5
EN
Aidoo Z-Wave PlusTM by Airzone
Device to manage and integrate units remotely. Wireless Z-WaveTM connection. Externally
powered by the indoor unit.
Features:
• Control of the parameters of the unit.
• Communication errors detection.
• Temperature and operating mode time schedules.
• Port for integration via Modbus .
For further information about our products, go to airzonecontrol.com
The Aidoo Z-Wave PlusTM by Airzone operates in any Z-Wave network with other Z-Wave/Z-
Wave Plus certified devices and controllers from any other manufacturer. As a constantly
powered node, Aidoo Z-Wave Plus will act as repeater in order to increase the reliability of the
network.
Nº Description
Cable for connection with indoor unit
Modbus port
Indoor unit port
Device reboot
Association process
Factory reset
DEVICE ELEMENTS

6
EN
TECHNICAL SPECS
Connection to indoor unit
V max. 18 Vdc
I max. 137.5 mA
V in 12-16 Vdc
Consumption 310 mW
Type of cable According to the indoor unit manufacturer
Wire length 2.5 m (8.2 ft)
Z-Wave Communication
Protocol Z-Wave Plus
Model ZGM130S
Communication frequency
E= 864.4 MHz (E.U.)
U= 908.4 MHz, 916 MHz (U.S.)
H= 919.8 MHz, 921.4 MHz (AZN)
Maximum power-Antenna
power 13 dBm
Sensitivity -97 dBm
Protection system S2 Security
Maximum distance Up to 100 m outdoor
Up to 40 m indoor
Modbus Port
Shielded twisted pair
2 x 0.22 + 2 x 0.5 mm2
(AWG 23 – 2 wired +
AWG 20 – 2 wired)
Communication protocol MODBUS RS-485
Par – 19200 bps
Operating temperatures
Storage -20 … 70 ºC (-4 … 158 ºF)
Operation 0 … 45 ºC (32 … 113 ºF)
Operating humidity rango 5 … 90%
(non-condensing)
Mechanical aspects
Protection class IP 41
Weight 130 g (0.29 lb)
Size (WxHxD) 92x80x29 mm (3.62x3.15x1.14”)
Conformity
Europe - 2011/65/EU & 2015/863/EU & 2017/2102/UE – RoHS Directive
- 2014/53/EU – RED (Radio Equipment Directive)
U.S.A / Canada - 47 CFR Part 15B – FCC
- ICES-003 Issue 6 – ISED
Australia / New Zeland - AS/NZS 4268-2017 - SRD Standard
AZAI6ZWxXXX
E= Europe (E.U.)
U= United States (U.S.)
H= Australia / New Zealand (ANZ)

7
EN
General considerations to connect the Aidoo Z-Wave Plus:
1. Important: Some Aidoo Z-Wave Plus requires to be supplied by a limited power source
meeting class PS2 of the standard IEC 62368-1. Refer to the data sheet the for further
information.
2. Important: Use separate circuits for the unit that is to be controlled and the power supply to
the system.
3. Disconnect the indoor unit. Perform all of the connections with a total absence of power.
4. Connect the Aidoo Z-Wave Plus to the indoor unit according to the instructions detailed in
the data sheet of your specific Aidoo Z-Wave Plus reference.
5. Power the indoor unit. Check the LEDs (see Self-diagnosis section).
6. Configure the device.
Perform the assembly by fixing your Aidoo Z-Wave Plus close to the AC unit to be controlled
using the material supplied:
a. Screw attachment.
b. Double-sided adhesive attachment.
ASSEMBLY AND CONNECTION
a. b.
ASSEMBLY
CONNECTION

8
EN
SELF-DIAGNOSIS
Nº Meaning
Connected to Z-Wave network Steady Blue
TX/RX communication with Z-Wave Blinking Red
Linking device Steady Red
Identification mode Fast
Blinking Red
Microprocessor activity Blinking Green
Power supply Steady Red
Data transmission to the indoor unit Blinking Red
Data reception from the indoor unit Blinking Green
The Aidoo Z-Wave Plus have integrated LED that detects the operation of the device.
Depending on the LED operation, it indicates:
Orientative wiring diagram

9
EN
Standard Inclusion
The Aidoo Z-Wave Plus is compatible with all Z-Wave/Z-Wave Plus certified controllers. The
device supports both the Network SmartStart inclusion mechanism (which offers the ability
to be included in a network, even if the device is not directly connected to the controller) and
Standard Inclusion.
By default, the inclusion procedure starts in Normal Inclusion mode and after a short timeout
the procedure continues in Network Wide Inclusion mode that lasts for about 20 Seconds.
If the Aidoo Z-Wave Plus has not been included yet into the Z-Wave network, the LED will
remain off. The procedure of inclusion is activated by pressing the Association Button . As
soon as the inclusion procedure initiates, the LED remains steady red until the device is
included in the network.
Standard exclusion
Only a controller can remove the device from the network. After activating the exclusion
function by the controller, the device can be removed by setting it in Learning Mode.
If the Aidoo Z-Wave Plus is already included into the Z-Wave network, the LED will remain
steady blue. The procedure of exclusion is activated by pressing the Association Button . As
soon as the exclusion procedure initiates, the LED remains steady red until the device is
excluded of the network.
SMARTSTART INCLUSION
Z-Wave SmartStart aims to shift the tasks related to inclusion of an Aidoo Z-Wave Plus into
a Z-Wave network away from the Aidoo device itself, and towards the more user-friendly
interface of the gateway.
Z-Wave SmartStart removes the need for initiating the Aidoo device to start inclusion. Inclusion
is initiated automatically on power-ON, and repeated at dynamic intervals for as long as the
device is not included into a Z-Wave network. As the new device announces itself on power-ON,
the protocol will provide notifications, and the gateway can initiate the inclusion process in the
background, without the need for user interaction or any interruption of normal operation. The
Smart Start inclusion process only includes authenticated devices.
CONFIGURATION
The Aidoo Z-Wave Plus is compatible with all Z-Wave/Z-Wave Plus certified controllers. The
device supports both the Network Wide Inclusion mechanism (which offers the ability to be
included in a network, even if the device is not directly connected to the controller) and Normal
Inclusion.
By default, the inclusion procedure starts in Normal Inclusion mode and after a short timeout
the procedure continues in Network Wide Inclusion mode that lasts for about 20 Seconds.
ADD/REMOVE AIDOO Z-WAVE PLUS INTO A Z-WAVE NETWORK
(CLASSIC)

10
EN
The Aidoo Z-Wave Plus can be added
into a Z-Wave network by scanning the
Z-Wave QR Code present on the product
with a controller providing SmartStart
inclusion. No further action is required
and the SmartStart product will be added
automatically within 10 minutes of being
switched on in the network vicinity.
The SmartStart QR and the full DSK string
code can be found on the front side of
the Aidoo Z-Wave Plus. The PIN is the
first group of 5 underlined digits of the
DSK identified as DSK in the left side of
the sticker. If you plan to use the DSK, it is
important that you take a picture of the
label and keep it in a safe place.
S2 SECURE INCLUSION
When adding the Aidoo Z-Wave Plus to a Z-Wave network with a controller supporting Security
2 Authenticated (S2), the PIN code of the Z-Wave Device Specific Key (DSK) is required. The first
five digits of the unique DSK code are the key PIN code and is printed on the product label.
Z-WAVE COMMUNICATION
SUPPORTED COMMAND CLASSES
Command class Version Non-Secure CC Secure CC
BASIC 2 x
ZWAVEPLUS_INFO 2 x
ASSOCIATION 2 x
MULTI_CHANNEL_ASSOCIATION_V2 3 x
ASSOCIATION_GRP_INFO 3 x
TRANSPORT_SERVICE 2 x
VERSION 3 x
MANUFACTURER_SPECIFIC 2 x
DEVICE_RESET_LOCALLY 1 x
INDICATOR 3 x
POWERLEVEL 1 x
SECURITY 0 1 x
DSK Z-Wave

11
EN
Command class Version Non-Secure CC Secure CC
SECURITY_2 1 x
SUPERVISION 1 x
FIRMWARE_UPDATE_MD 5 x
THERMOSTAT_FAN_MODE 2 x
THERMOSTAT_MODE 3 x
THERMOSTAT_SETPOINT 1 x
SENSOR_MULTILEVEL 1 x
NOTIFICATION 8 x
Supporting command class basic
The basic command classes are mapped into the Thermostat Mode Command Class as
required by the protocol specification.
Supporting command class indicator
The Aidoo Z-Wave Plus supports Indicator V3 with Indicator ID 0x50 (identity). When the device
receives an indicator set, the backlight start to blink accordingly the received command.
Implemented Mapping:
Associations
Lifeline group: Nodes belonging to this group will receive: notifications about device reset and
all other changes.
Notification Command Class
The system implement notification command class with Type: System (0x09) and event:
System hardware failure (manufacturer proprietary failure code provided).
Manufacturer proprietary failure code provided are 2 bytes length (error and warning). The
meaning of these bytes are described into the Air conditioning manufacturer's installation
manual.
Basic Command Received Mapped Command (Thermostat Mode)
Basic set (0xxFF) If the last non Off mode was 1 or 2 -> Thermostat Mode(last non
Off mode). Otherwise -> Thermostat Mode (0x01)
Basic set (0xx00) Thermostat Mode (0x00)
Basic GET Replay with a basic Report with these meaning:
Basic Report 0x00 if mode is equal to 0x00
If mode different than 0 reply with Basic Report 0xFF

12
EN
DEVICE CONTROL. Z-WAVE APPLICATION COMMAND CLASS MAP-
PING
Description Values Z-Wave Command
On/Off Off Thermostat_Mode
On Thermostat_Mode
SetPoint
- SetpointType: (Heating,
Cooling, Dry Air)
- SetPointValue: (tenths of °C)
Thermostat_Setpoint
LocalTemp Room temperature x10 Sensor_Multilevel
Modes
OFF
Auto chageover
Cooling
Heating
Fan
Dry
Thermostat_Mode
Speed
Auto - Medium
Low
Medium
High
Off
Thermostat_Fan_Mode
Warning Max 2 Byte Notification(*)
Error Max 2 Byte
The Aidoo Z-Wave Plus controller acts as a gateway between the air conditioner controller
interface and the Z-Wave network. The Aidoo Z-Wave Plus interacts with the proprietary
protocol of the different A/C manufacturers converting the orders into Modbus commands to
trigger the Z-Wave network commands.
The monitoring/control items supported by the Aidoo Z-Wave Plus are mapped to the standard
Thermostat Command class object types defined by the Z-Wave protocol. The user can interact
with the air conditioning system through the Z-Wave network with the following supported
monitoring/control items.
(*) For the Notification Z-Wave command class, the Aidoo Z-Wave Plus reserves 2
alphanumeric bytes to represent the Air conditioning unit warnings and error codes. The
warnings and error codes are represented in a different way according to each manufacturer.
Please refer to the manufacturer's installation manual to check the meaning of the different
codes.
Group
ID
Group
Name
N° of max nodes
supported in the
group
Description Command sent
1 Lifeline 1 Life Line
Group
DEVICE_RESET_LOCALLY_NOTIFICATION
THERMOSTAT_FAN_MODE_REPORT
INDICATOR_REPORT
THERMOSTAT_MODE_REPORT
THERMOSTAT_SETPOINT_REPORT
SENSOR_MULTILEVEL_REPORT
NOTIFICATION_REPORT

13
EN
RESET TO THE FACTORY SETTINGS
The Aidoo Z-Wave Plus can be reset to the original factory settings by long pressing over the
Factoy Reset button until all of the front side LEDs light up for a second.
Please use this procedure only when the network primary controller is missing or ortherwise
inoperable.
Note: If the reset is performed while the device is still part of a network, it notifies the other
devices in the Lifeline group that it has been removed.
FIRMWARE UPDATE
The Aidoo Z-Wave Plus supports over-the-air firmware updates that do not require the device
to be removed from its location. The firmware update can be activated from all certified
controllers supporting version 5 of the Firmware Update function.
Important: The Aidoo Z-Wave Plus will be rebooted at the end of the firmware update
procedure. It is advisable to carry out the firmware update procedure only when necessary
and following careful planning of the intervention.
It is possible to check the compatible Air conditioning indoor units in the Airzone compatibility
checker:
https://www.airzonecontrol.com/control_solutions/aidoo/wi-fi
The following interactions with the air conditioning unit will imply a combination of Z-Wave.
commands:
Description Values Z-Wave Command
Fan Off Off Thermostat_Fan_Mode
Thermostat_Mode
Change Mode
Thermostat_Mode:
Auto chageover
Cooling
Heating
Fan
Dry
Thermostat_Setpoint
- SetpointType: (Heating,
Cooling, Dry Air)
- SetPointValue: (tenths of °C)
Thermostat_Mode
Thermostat_Setpoint

Contenido
POLÍTICA MEDIOAMBIENTAL _____________________________________________________________________ 3
ANTES DE EMPEZAR _______________________________________________________________________________ 4
AIDOO Z-WAVE PLUS BY AIRZONE______________________________________________________________ 5
>Elementos del dispositivo ______________________________________________________________ 5
>Características técnicas _________________________________________________________________ 6
MONTAJE Y CONEXIÓN_____________________________________________________________________________ 7
>Montaje ____________________________________________________________________________________ 7
>Conexión ___________________________________________________________________________________ 7
>Autodiagnóstico __________________________________________________________________________ 8
CONFIGURACIÓN ____________________________________________________________________________________ 9
>Añadir Aidoo Z-Wave Plus a una red Z-Wave o eliminarlo (Classic)____________ 9
>Inclusión estándar__________________________________________________________________ 9
>Exclusión estándar _________________________________________________________________ 9
>Inclusión SmartStart_____________________________________________________________________ 9
>Inclusión segura S2 Security___________________________________________________________ 10
COMUNICACIÓN Z-WAVE __________________________________________________________________________ 10
>Clases de comandos compatibles_____________________________________________________ 10
>Compatibilidad con la clase de comando “BASIC”____________________________ 11
>Compatibilidad con la clase de comando “INDICATOR” _____________________ 11
>Clase de comando Notication___________________________________________________ 11
>Asociaciones_________________________________________________________________________ 11
>Control del dispositivo. Asignación de clases de comandos de aplicación
Z-Wave _____________________________________________________________________________________ 12
>Reset del dispositivo a los valores de fábrica_______________________________________ 13
>Actualización de rmware______________________________________________________________ 13
ES

3
Política medioambiental
• No tire nunca este equipo con los desechos domésticos. Los productos eléctricos y
electrónicos contienen sustancias que pueden ser dañinas para el medioambiente
si no se les da el tratamiento adecuado. El símbolo del contenedor de basura
tachado indica la recogida selectiva de aparatos eléctricos, que se diferencia del
resto de basuras urbanas. Para una correcta gestión ambiental, se deberá llevar el
equipo a los centros de recogida previstos al final de su vida útil.
• Las piezas que forman parte del mismo se pueden reciclar. Respete, por tanto, la
reglamentación en vigor sobre protección medioambiental.
• Debe entregarlo a su distribuidor si lo reemplaza por otro, o depositarlo en un centro
de recogida especializado.
• Los infractores están sujetos a las sanciones y a las medidas que establece la ley
sobre protección del medio ambiente.
EN
ES

4
ES
desconexión que tenga una separación constante en todos los polos. El sistema se
reiniciará automáticamente si se apaga la alimentación principal. Utilice un circuito
independiente del equipo a controlar para la alimentación del sistema.
• Respete la polaridad de conexión de cada dispositivo. Una conexión errónea puede
dañar seriamente el producto.
• Para la conexión de comunicación con el sistema, utilice el cable Airzone:
cable formado por 4 hilos (2 x 0,22 mm2hilos trenzados y apantallados para la
comunicación de datos y 2x0,5mm2hilos para la alimentación).
• Si el equipo utiliza gas refrigerante R32, compruebe que cumple la normativa local
sobre refrigerantes.
• El sistema debe ser instalado por un técnico cualificado.
• Este producto no debe modificarse ni desmontarse bajo ninguna circunstancia.
• No manipule el sistema con las manos mojadas ni húmedas.
• En caso de mal funcionamiento de este aparato, no lo repare usted mismo. Póngase
en contacto con el distribuidor de ventas o el distribuidor de servicio para la
reparación o eliminación del producto.
• Compruebe que la instalación de climatización ha sido instalada según los
requisitos del fabricante, cumple con la normativa local vigente y funciona
correctamente antes de instalar el sistema Airzone.
• Ubique y conecte todos los elementos de su instalación conforme a la
reglamentación electrónica local vigente.
• Realice todas las conexiones con ausencia total de alimentación.
• Tenga precaución de no realizar ningún cortocircuito en ninguna conexión del
sistema.
• Consulte cuidadosamente el diagrama de cableado y estas instrucciones al realizar
el cableado.
• Conecte todo el cableado firmemente. Un cableado suelto puede provocar un
sobrecalentamiento en los puntos de conexión y un posible riesgo de incendio.
• No sitúe el bus de comunicaciones Airzone junto a líneas de fuerza, fluorescentes,
motores, etc., que puedan generar interferencias en las comunicaciones.
• En el cableado de alimentación externo del sistema deberá incorporarse, según la
reglamentación local y nacional pertinente, un interruptor principal u otro medio de
Antes de empezar

5
ES
Aidoo Z-Wave PlusTM by Airzone
Dispositivo para la gestión e integración de equipos de forma remota. Conexión inalámbrica
Z-WaveTM. Alimentación externa mediante la unidad interior.
Funciones:
• Control de los parámetros de la unidad.
• Detección de errores de comunicación.
• Programaciones horarias de temperatura y de modo de funcionamiento.
• Puerto para la integración mediante Modbus.
Para obtener más información sobre nuestros productos, diríjase a airzonecontrol.com.
El Aidoo Z-Wave PlusTM by Airzone funciona en cualquier red Z-Wave con otros controladores y
dispositivos con certificación Z-Wave/Z-Wave Plus de cualquier otro fabricante. Como nodo que
recibe alimentación de manera constante, el Aidoo Z-Wave Plus actúa como un repetidor de
red independiente para aumentar la fiabilidad de la red.
Nº Descripción
Cable para la conexión con la unidad interior
Puerto Modbus
Puerto de la unidad interior
Reinicio del dispositivo
Proceso de asociación
Reset de fábrica
ELEMENTOS DEL DISPOSITIVO

6
ES
CARACTERÍSTICAS TÉCNICAS
Conexión con la unidad interior
V máx. 18Vdc
I máx. 137,5mA
V entrada 12-16Vdc
Consumo 310mW
Tipo de cable En función del fabricante de la unidad interior
Longitud del cable 2,5m (8,2ft)
Comunicación Z-Wave
Protocolo Z-Wave Plus
Modelo ZGM130S
Frecuencia de comunica-
ción E=864,4MHz (UE)
U=908,4MHz, 916MHz (EE.UU.)
H=919,8MHz, 921,4MHz (ANZ)
Potencia máxima-Potencia
de antena 13dBm
Sensibilidad -97dBm
Sistema de protección S2 Security
Distancia máxima Hasta 100m en exterior
Hasta 40m en interior
Puerto Modbus
Par apantallado y trenzado
2x0,22mm2+2x0,5mm2
(AWG 23–2hilos+
AWG 20–2hilos)
Protocolo de comunica-
ciones
MODBUS RS-485
Par–19.200bps
Temperaturas operativas
Almacenaje Entre -20 y 70°C (entre -4 y 158°F)
Funcionamiento Entre 0 y 45°C (entre 32 y 113°F)
Rango de humedad de
funcionamiento
Entre 5% y 90%
(sin condensación)
Aspectos mecánicos
Clase de protección IP 41
Peso 130g (0,29lb)
Dimensiones (AnxAlxPr) 92x80x29mm (3,62x3,15x1,14”)
Conformidad
Europa - 2011/65/UE, 2015/863/UE y 2017/2102/UE – Directiva RoHS
- 2014/53/UE – DER (directiva sobre equipos radioeléctricos)
EE.UU./Canadá - 47 CFR Parte 15B – FCC
- ICES-003 Número 6 – ISED
Australia/Nueva
Zelanda
- AS/NZS 4268-2017 – Norma sobre dispositivos de corto
alcance (SRD)
AZAI6ZWxXXX E=Europa (UE)
U=Estados Unidos (EE.UU.)
H=Australia/Nueva Zelanda (ANZ)

7
ES
Consideraciones generales para conectar el Aidoo Z-Wave Plus:
1. Importante: Algunos Aidoo Z-Wave Plus deben recibir energía de una fuente de
alimentación limitada de clase PS2 según la norma IEC 62368-1. Consulte la ficha técnica
para obtener más información.
2. Importante: Utilice un circuito independiente del equipo a controlar para la alimentación
del sistema.
3. Desconecte la unidad interior. Realice todas las conexiones con ausencia total de
alimentación.
4. Conecte el Aidoo Z-Wave Plus a la unidad interior conforme a las instrucciones detalladas en
la ficha técnica de su referencia de Aidoo Z-Wave Plus específica.
5. Conecte la unidad interior. Compruebe los LED (véase el apartado Autodiagnóstico).
6. Configure el dispositivo.
Realice el montaje fijando el Aidoo Z-Wave Plus cerca de la unidad de climatización que desee
controlar utilizando los materiales suministrados:
a. Fijación mediante tornillos.
b. Fijación mediante adhesivo de doble cara.
MONTAJE Y CONEXIÓN
a. b.
MONTAJE
CONEXIÓN

8
ES
AUTODIAGNÓSTICO
Nº Significado
Conexión a la red Z-Wave Fijo Azul
Comunicación TX/RX con Z-Wave Parpadeo Rojo
Modo de identificación Parpadeo
rápido Rojo
Vinculación del dispositivo Fijo Rojo
Actividad del microprocesador Parpadeo Verde
Alimentación Fijo Rojo
Transmisión de datos a la unidad
interior Parpadeo Rojo
Recepción de datos de la unidad
interior Parpadeo Verde
El Aidoo Z-Wave Plus tiene LED integrados que detectan el funcionamiento del dispositivo.
Según el comportamiento de los LED, se indica lo siguiente:
Esquema de conexión orientativo
This manual suits for next models
15
Table of contents
Languages:
Other Airzone Controllers manuals
