nologo COPY-CONTROL User manual

GB COPY-CONTROL
P1
FUNCTION BUTTON
This button can activate one of the three functions, besides,
in the FUNCTION 3, it conrm right memorisation of the
code.
P2
ENTER BUTTON/ ESC/ MEMORISATION
This button can conrm or not conrm one of the functions,
previously selected, with the button P1, besides, in the
FUNCTION 3, it needs to memorize the code inside the
machine and it can be choosen to transmit the memorized
code.
COPY-CONTROL
GB_COPY-CONTROL_160909_VX8503
FUNCTION 1:• frequency reader in Mhz
FUNCTION 2:• frequency adjuster of the
oscillator (maximum value
is 1024)
FUNCTION 3:• memorisation of the remote
control’s code and check of the
right memorization of
the original remote control
indicating the right percentage
of the good learning.
FUNCTION 3bis:• Transmission of the code
between the
COPY-CONTROL and
the copied remote control.
(between 250 and 869 Mhz).
The right position of the remote control is indicated in the picture
1 area 1, we recommend to nd the position of the antenna of
the remote control, normally it is in the lower part of the remote
control but it is not always the technical structure and the design of
the remote control , and vice versa, so we can nd the antenna in
another position. When you press the button of the remote control
the two RED L.E.D. of the COPY-CONTROL start ashing fast,
indicating the begining of the reading.
In particular the reading of the frequency is precise from 250 Mhz
to 869 Mhz
FUNCTION 1
Functions
1 - 2 - 3
Pressing repeatedly the P1 you will see numbers which
indicate the three functions available:
When you give power supply to the COPY-CONTROL (12VAC/DC), it turns on automatically and you can see a number on
the display for a while, this indicate the number of the software. (For example after the FUNCTION NO.1).
Select the FUNCTION no.1 with the button and keep pressed till you see in the display the number 1.
P1 Press the button P2 to conrm the operation and go in the program.
When you are in this function you can read an adjust the frequencies without going out or enter in the same functions.
To go out press the button esc P2.

When you get near the remote control like in the shown position
of the picture (the oscillator should be already plugged in) press
the button with a pencil and turn slowly the potentiometer with a
ceramic screw-driver.
The COPY-CONTROL show a rst adjustment level and the better
one is 1023.
We suggest you to put the remote control as near as you can in
the COPY-CONTROL and then remove it 3-5 cm to reach the
value 1024. We recommend not turn strong the potentiometer but
do it slowly.
To go out press the button esc P2.
FUNCTION 2
Put the antenna on the remote X to check like in the photo. Then press the button of the copy remote control to check if it has
well copied the code. When the COPY-CONTROL take the radio signal, the two REDLIGHTSashfaster. The right learning
of the remote control will be conrmed from the turning on of the YELLOW LIGHTS and the simultaneously showing on in the
display of the 100%. (The YELLOW L.E.D. will turn on only when the code is 100% copied)
Release the button P2.
FUNCTION 3
Pay attention that this function reachable only if you are already in the FUNCTION no.3 and after learning a code in the
memory of the COPY-CONTROL. In this situation if you press the button P2 , keep it pressed, conrm it pressing and re
leasing the P1, (P2+P1 and then release). After this operation you have a constantly transmission of the memory code,
this is conrmed when a ashing “t“will be displayed as shown in the picture.
Now, putting a remote control as shown in the picture, we can clone that code directly from the COPY-CONTROL, to make
easy the copy of the remote control which have the same code and besides this is useful in case of difcult copy because
you can hang on the better sensitivity of the COPY-CONTROL.
FUNCTION 3/Bis
Nologo srl declares that COPY-CONTROL is conformed to the essential requirements of the following norms:
ETSI EN 301 489-3 EN 300 220-1 EN 300 220-3 EN 60950: 1997
Me Ernestino Bandera the administrator, declares that the remote control has been tested in a typical installation and satises all
essential requirements of the directives: 99/5/CE
Ernestino Bandera
Busto Arsizio, 01.10.2008
ConformityDeclaration
2002/95/EC
RoHS
C O M P L I A N T
To select the function 2 with the button P1 , keep it pressed until you’ll see in the display the code in the picture.
Press the button P2 to enter in the program.
Now the COPY-CONTROL is ready to receive a signal of a remote control (low frequencies) to display the adjustment level.
Choose the function no.3 with the button P1 and keep it pressed till in the display you see the same number as in the picture.
Press and keep pressed the button P2 to memorize in the COPY-CONTROL the original code X.
Now the COPY-CONTROL that has already memorize the remote
control , now it can compare the code with the next one Y.
Put the remote control Y and press the button and check it.
If the transmitted code is the same of the previous learned remote
control, the YELLOW L.E.D. and the percentage of the right
memorization the l.e.d. will turn on in the same time..
If the copy of the remote control hasn’t copied 100% well the code
the blue lights will turn on and a low percentage (less then 100%) the
code is different of the previously memorized.
If we test with a rolling code remote control we can check that the learning and the comparison with the same button will give a
negative result (BLUE L.E.D. and low percentage) to conrm that it is a rolling code and it cannot be copied.
This is not valid for the xed part of the code which can be indicated in the percentage of the code (rolling code)
