Aiwa CDC-X527M User manual
SERVICE MANUAL
DATA
CDC-X527M
YU(S),YH(S)
STEREO CAR CD STEREO
S/M Code No. 09-026-457-2R1
REVISION
BASIC CD MECHANISM : BZG-3 BNF
•This service Manual is the “Revision Publishing” and replaces “Simple
Manual” CDC-X527M <YU(S),YH(S) > (S/M Code No.09-026-457-2T1)
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-2-
SPECIFICATIONS................................................................................................................................................................3
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING .........................................................................4
PROTECTION TOREPLACEOPTICALBLOCK(OPTIMA720JVC) ....................................................................................5
CAUTIONWHEN SERVICING ............................................................................................................................................6
ACCESSORIES PARTS LIST ............................................................................................................................................7
ELECTRICAL PARTS LIST ........................................................................................................................................8 ~ 18
TRANSISTOR ILLUSTRATION .........................................................................................................................................19
SCHEMATIC DIAGRAM – 1 (MAIN) ..................................................................................................................................20
WIRING – 1 (MAIN) ............................................................................................................................................................21
SCHEMATIC DIAGRAM – 2 (FRONT / AUX) .....................................................................................................................22
WIRING– 2(FRONT /AUX) ......................................................................................................................................... 23,24
SCHEMATIC DIAGRAM – 3 (CD / FLEX / SW) .................................................................................................................25
WIRING – 3 (CD) ................................................................................................................................................ 26,27
WIRING – 4 (FLEX / SW) ...................................................................................................................................................28
VOLTAGE CHART ....................................................................................................................................................29 ~ 36
LCD DIAGRAM(CKC-F-G-H) ...................................................................................................................................... 37,38
TEST MODE ...............................................................................................................................................................39,40
IC BLOCK DIAGRAM..................................................................................................................................................41,42
IC DESCRIPTION......................................................................................................................................................43 ~ 48
MECHANICAL EXPLODED VIEW................................................................................................................................... 49
MECHANICAL PARTS LIST .............................................................................................................................................50
COLOR NAME TABLE .......................................................................................................................................................51
CD MECHANISM EXPLODED VIEW (BZG-3 BNF) ......................................................................................................... 52
CD MECHANISM PARTS LIST (BZG-3 BNF) ...................................................................................................................53
OTHERPARTS LIST(CDC-X527M)..................................................................................................................................54
OTHER PARTS LIST (BZG-3 BNF) ..................................................................................................................................55
TABLE OF CONTENTS -1/1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-3-
RADIO SECTION
(FM)
Frequency Range: 87.5 MHz – 108 MHz
Usable Sensitivity: 12.7 dBf
50 dB Quieting Sensitivity: 17.2 dBf
IF Rejection: 100 dB
Frequency Response: 30 Hz – 15,000 Hz
S/N Ratio: 70 dB
Stereo Separation: 35 dB at 1 kHz
Alternate Channel Selectivity: 90 dB
Capture Ratio: 3 dB
(AM)
Frequency Range: 530 kHz – 1,710 kHz (YU Model)
Frequency Range: 531 kHz – 1,602 kHz (YU Model)
Usable Sensitivity: 30 µV (30 dB)
CD SECTION
Frequency Response: 17 Hz – 20 kHz +0/–3 dB
Dynamic Range: More than 85 dB
Channel Separation: More than 60 dB
S/N Ratio: More than 90 dB
Wow/Flutter: Unmeasurable
• Design and specifications are subject to change without notice.
AUDIO SECTION
Max. Power Output: 50 W x 4 channels
AUXinput
Input Sensitivity (load impedance) AUX: 300 mV (10 kohm)
GENERAL
Power-Supply Voltage: 14.4 V (11 to 16 V allowable),
DC, negative ground
Load Impedance: 4 ohm
Tone Control: Bass ± 10 dB at 100 Hz, Treble ± 10 dB at 10 kHz
Preamp Output Voltage (load impedance): 2.2 V (10 kohm)
Installed Size: 182 (W) x 53 (H) x 155 (D) mm
(71/4(W) x 21/8(H) x 61/8(D) inches)
Supplied Accessory:Carrying case(1)
CARD REMOTE CONTROL<CDC-X527M>
Dimensions: approx. 33 (W) x 85 (H) x 7.5 (D) mm
(15/16 (W) x 33/8(H) x 5/16 (D) inches)
Weight: approx. 20g (0.7 oz.) (including battery)
SPECIFICATIONS-1/1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-4-
PROTECTIONOFEYES FROM LASERBEAM DURING SERVICING-1/1
V
AROITUS!
L
aiteen Käyttäminen muulla kuin tässä käyttöohjeessa mainit-
u
lla tavalla saattaa altistaa käyt-täjän turvallisuusluokan 1 ylit-
t
ävälle näkymättömälle lasersäteilylle.
V
ARNING!
O
m apparaten används på annat sätt än vad som specificeras i
d
enna bruksanvising, kan användaren utsättas för osynling
l
aserstrålning, som överskrider gränsen för laserklass 1.
Caution: Invisible laser radiation when
open and interlocks defeated avoid expo-
sure to beam.
Advarsel:Usynling laserståling ved åbning,
når sikkerhedsafbrydere er ude af funktion.
Undgå udsættelse for stråling.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
ATTENTION
L'utilisation de commandes, réglages ou procédures autres qu
e
ceux spécifiés peut entraîner une dangereuse exposition aux
radiations.
ADVARSEL!
Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ud
e
af funktion. Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1 LASER
product.
The CLASS 1 LASER PRODUCT label is located on the rear
exterior.
T
his set employs laser. Therefore, be sure to follow carefully the
i
nstructions below when servicing.
W
ARNING!
W
HEN SERVICING, DO NOT APPROACH THE LASER EXIT
W
ITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO
C
ONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE
F
ROM A DISTANCE OF MORE THAN 30cm FROM THE
S
URFACE OF THE OBJECTIVE LENS ON THE OPTICAL
P
ICK-UP BLOCK.
CLASS 1
KLASSE 1
LUOKAN 1
KLASS 1
LASER PRODUCT
LASER PRODUKT
LASER LAITE
LASER APPARAT
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-5-
PROTECTION TO REPLACE OPTICAL BLOCK (OPTIMA720 JVC) -1/1
1) After the connection, remove solder shown in
the right figure.
Body or clothes electrostatic potential could ruin
laser diode in the optical block. Be sure ground
body and workbench, and use care the clothes
do not touch the diode.
Solder
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-6-
1. Procedure For Disassembly
1) Remove COVER TOP and COVER BOTTOM.
2) Remove the screws (indicated with arrows) from CD
MECHANISM. Refer to Fig. 1
2. Servicing Position
Remove CD MECHANISM and check the movement
while in a stable condition. Refer to Fig-2
Fig-1
Fig-2
CAUTIONWHENSERVICING -1/1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-7-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
ACCESSORIES PARTS LIST -1/1
CDC-X527M CDC-X527M
YHSF YUSF
O AS1001 87-253-033-410 U+2-4 BLK . b
O AS1002 87-B10-141-010 NUT,5 TYPE-2 a b
O AS1003 87-B10-143-010 UT1+5-15 W/O SLOT a b
O AS1004 87-B10-144-010 W,5.2-10-0.5 a b
O AS1005 87-B10-145-010 W-SPR,5.3-8.5-1.5 a b
O AS1006 88-ZG8-435-010 S-SCREW,VIT+2-4 PREC a .
O AS1007 8C-KCG-060-110 CASE,DFP C BLK a b
X AS1008 8C-KCG-631-010 CONN ASSY,16P RENEWVERSION a b
O AS1009 8Z-KC1-232-010 KEY,REMOVE -C a b
O AS1010 8Z-KC1-235-010 HLDR,REAR MTG a b
O AS1011 8Z-KC1-244-010 S-SCREW,5*6 TH+ TAPPING ST a b
O AS1012 8Z-KC1-250-010 S-SCREW,HEXAGON a b
X AS1013 8C-KCF-854-010 PAD,A a b
X AS1014 87-B50-055-010 WARR-CARD,USA CUST/CAR AUDIO . b
X AS1015 87-B50-079-010 LIST,FACILITY(B)-0007 a .
X AS1016 87-B50-081-010 WARR-CARD,CHINA CAR-0009 a .
O AS1017 8C-KCF-901-010 IB,YU(ESF)F X527M . b
O AS1018 8C-KCF-902-010 IB,YH(ECC)F X527M a .
O AS1019 8C-KCG-911-010 IB,INST YU/YUC/YL(ESFP)F . b
O AS1020 8C-KCG-912-010 IB,INST YH/Y (ECCA)F a .
CDC-X527M CDC-X527M
YHSF YUSF
O AS1021 8C-KCG-651-010 RC UNIT,CD1B a b
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-8-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
ELECTRICAL PARTS LIST -1/11
CDC-X527M CDC-X527M
YHSF YUSF
AUX O J 0601 85-HRL-623-010 JACK,3.5 BLK ST BLK a b
CD O C 0201 87-010-553-040 CAP,E 47-16 M 5L SRE a b
CD O C 0202 87-010-553-040 CAP,E 47-16 M 5L SRE a b
CD O C 0203 87-012-274-080 C-CAP,U 1000P-50 K B a b
CD O C 0204 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0205 87-A10-353-080 C-CAP,U 0.22-10 K B a b
CD O C 0206 87-010-492-040 CAP,E 0.33-50 M 5L SRE a b
CD O C 0207 87-010-956-080 C-CAP,S 0.068-25 K B GRM a b
CD O C 0208 87-012-272-080 C-CAP,U 680P-50 K B GRM a b
CD O C 0209 87-A10-504-080 C-CAP,U 0.047-16 K B a b
CD O C 0210 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0211 87-010-498-040 CAP,E 10-16 M 5L SRE a b
CD O C 0212 87-012-276-080 C-CAP,U 1500P-50 K B a b
CD O C 0213 87-A10-504-080 C-CAP,U 0.047-16 K B a b
CD O C 0214 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0215 87-012-278-080 C-CAP,U 2200P-50 K B a b
CD O C 0216 87-A10-353-080 C-CAP,U 0.22-10 K B a b
CD O C 0217 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0218 87-010-787-080 C-CAP,U 0.022-25 K B a b
CD O C 0219 87-012-268-080 C-CAP,U 330P-50 K B GRM a b
CDC-X527M CDC-X527M
YHSF YUSF
CD O C 0220 87-012-280-080 C-CAP,U 3300P-50 K B a b
CD O C 0221 87-012-195-080 C-CAP,U 100P-50 J CH a b
CD O C 0222 87-010-492-040 CAP,E 0.33-50 M 5L SRE a b
CD O C 0223 87-010-067-040 CAP,E 0.1-50 M 5L SRE a b
CD O C 0224 87-010-553-040 CAP,E 47-16 M 5L SRE a b
CD O C 0225 87-012-280-080 C-CAP,U 3300P-50 K B a b
CD O C 0226 87-010-497-040 CAP,E 4.7-35 M 5L SRE a b
CD O C 0227 87-010-555-040 CAP,E 100-10 M 5L SRE a b
CD O C 0228 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0229 87-010-498-040 CAP,E 10-16 M 5L SRE a b
CD O C 0230 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0231 87-010-555-040 CAP,E 100-10 M 5L SRE a b
CD O C 0232 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0233 87-010-555-040 CAP,E 100-10 M 5L SRE a b
CD O C 0234 87-010-828-080 C-CAP,U 0.033-16 Z F a b
CD O C 0235 87-A10-504-080 C-CAP,U 0.047-16 K B a b
CD O C 0236 87-010-067-040 CAP,E 0.1-50 M 5L SRE a b
CD O C 0237 87-010-553-040 CAP,E 47-16 M 5L SRE a b
CD O C 0238 87-012-286-080 C-CAP,U 0.01-25 K B a b
CD O C 0240 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CDC-X527M CDC-X527M
YHSF YUSF
CD O C 0250 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0251 87-010-555-040 CAP,E 100-10 M 5L SRE a b
CD O C 0252 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0253 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0254 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0256 87-012-282-080 C-CAP,U 4700P-50 K B a b
CD O C 0258 87-012-168-080 C-CAP,U 6P-50 D CH a b
CD O C 0259 87-012-184-080 C-CAP,U 33P-50 J CH a b
CD O C 0261 87-012-199-080 C-CAP,U 220P-50 J CH a b
CD O C 0262 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0263 87-010-555-040 CAP,E 100-10 M 5L SRE a b
CD O C 0264 87-010-555-040 CAP,E 100-10 M 5L SRE a b
CD O C 0265 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0266 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O C 0267 87-010-498-040 CAP,E 10-16 M 5L SRE a b
CD O C 0268 87-010-498-040 CAP,E 10-16 M 5L SRE a b
CD O C 0269 87-012-276-080 C-CAP,U 1500P-50 K B a b
CD O C 0270 87-012-276-080 C-CAP,U 1500P-50 K B a b
CD O C 0280 87-A10-189-040 CAP,E 220-10 M 5L a b
CD O C 0281 87-010-555-040 CAP,E 100-10 M 5L SRE a b
CDC-X527M CDC-X527M
YHSF YUSF
CD O C 0282 87-A10-260-080 C-CAP,U 0.1-16 K B a b
CD O CON0201 87-A61-220-080 C-CONN,20P H 52271-2090 a b
CD S IC 0201 87-A20-446-010 C-IC,LA9241ML a b
CD S IC 0202 87-A21-319-010 C-IC,LC78622NE a b
CD S IC 0203 87-A22-080-040 C-IC,LA6557H a b
CD X JR 0101 88-108-000-080 C-JUMPER,U a b
CD S Q 0201 87-A30-289-040 C-TR,2SA1037AK(Q) a b
CD S Q 0202 87-A30-435-040 C-TR,DTC144EKA a b
CD S Q 0203 87-A30-435-040 C-TR,DTC144EKA a b
CD S Q 0204 87-A30-435-040 C-TR,DTC144EKA a b
CD S Q 0205 87-A30-435-040 C-TR,DTC144EKA a b
CD S Q 0206 89-324-122-040 C-TR,2SC2412KR a b
CD S Q 0207 87-A30-299-080 TR,2SB1326 a b
CD S Q 0208 87-A30-287-040 C-TR,DTC114TKA a b
CD X R 0201 88-108-100-080 C-RES,U 10-1/16W J a b
CD X R 0202 88-108-103-080 C-RES,U 10K-1/16W J a b
CD X R 0203 88-108-183-080 C-RES,U 18K-1/16W J a b
CD X R 0204 88-108-153-080 C-RES,U 15K-1/16W J a b
CD X R 0205 88-108-153-080 C-RES,U 15K-1/16W J a b
CD X R 0206 88-108-183-080 C-RES,U 18K-1/16W J a b
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-9-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
ELECTRICAL PARTS LIST -2/11
CDC-X527M CDC-X527M
YHSF YUSF
CD X R 0207 88-108-153-080 C-RES,U 15K-1/16W J a b
CD X R 0208 88-108-153-080 C-RES,U 15K-1/16W J a b
CD X R 0209 88-108-392-080 C-RES,U 3.9K-1/16W J a b
CD X R 0210 88-108-392-080 C-RES,U 3.9K-1/16W J a b
CD X R 0211 88-108-102-080 C-RES,U 1K-1/16W J a b
CD X R 0212 88-108-102-080 C-RES,U 1K-1/16W J a b
CD X R 0213 88-108-682-080 C-RES,U 6.8K-1/16W J a b
CD X R 0214 88-108-682-080 C-RES,U 6.8K-1/16W J a b
CD X R 0215 88-108-103-080 C-RES,U 10K-1/16W J a b
CD X R 0216 88-108-103-080 C-RES,U 10K-1/16W J a b
CD X R 0217 88-108-104-080 C-RES,U 100K-1/16W J a b
CD X R 0218 88-108-682-080 C-RES,U 6.8K-1/16W J a b
CD X R 0219 88-108-182-080 C-RES,U 1.8K-1/16W J a b
CD X R 0220 88-108-683-080 C-RES,U 68K-1/16W J a b
CD X R 0221 88-108-123-080 C-RES,U 12K-1/16W J a b
CD X R 0222 88-108-103-080 C-RES,U 10K-1/16W J a b
CD X R 0223 88-108-154-080 C-RES,U 150K-1/16W J a b
CD X R 0224 88-108-153-080 C-RES,U 15K-1/16W J a b
CD X R 0225 88-108-392-080 C-RES,U 3.9K-1/16W J a b
CD X R 0226 88-108-153-080 C-RES,U 15K-1/16W J a b
CDC-X527M CDC-X527M
YHSF YUSF
CD X R 0227 88-108-331-080 C-RES,U 330-1/16W J a b
CD X R 0228 88-108-224-080 C-RES,U 220K-1/16W J a b
CD X R 0229 88-108-183-080 C-RES,U 18K-1/16W J a b
CD X R 0230 88-108-562-080 C-RES,U 5.6K-1/16W J a b
CD X R 0231 88-108-183-080 C-RES,U 18K-1/16W J a b
CD X R 0232 88-108-563-080 C-RES,U 56K-1/16W J a b
CD X R 0233 88-108-152-080 C-RES,U 1.5K-1/16W J a b
CD X R 0234 88-108-473-080 C-RES,U 47K-1/16W J a b
CD X R 0235 88-108-124-080 C-RES,U 120K-1/16W J a b
CD X R 0236 88-108-333-080 C-RES,U 33K-1/16W J a b
CD X R 0237 88-108-473-080 C-RES,U 47K-1/16W J a b
CD X R 0238 88-108-473-080 C-RES,U 47K-1/16W J a b
CD X R 0239 88-108-153-080 C-RES,U 15K-1/16W J a b
CD X R 0240 88-108-122-080 C-RES,U 1.2K-1/16W J a b
CD O R 0241 87-022-292-080 C-RES,U 330K-1/16W F a b
CD O R 0242 87-022-292-080 C-RES,U 330K-1/16W F a b
CD X R 0243 88-108-563-080 C-RES,U 56K-1/16W J a b
CD X R 0244 88-108-223-080 C-RES,U 22K-1/16W J a b
CD X R 0245 88-108-473-080 C-RES,U 47K-1/16W J a b
CD X R 0246 88-108-100-080 C-RES,U 10-1/16W J a b
CDC-X527M CDC-X527M
YHSF YUSF
CD X R 0247 88-108-109-080 C-RES,U 1-1/16W J a b
CD X R 0248 88-108-184-080 C-RES,U 180K-1/16W J a b
CD X R 0250 88-108-681-080 C-RES,U 680-1/16W J a b
CD X R 0251 88-108-333-080 C-RES,U 33K-1/16W J a b
CD X R 0252 88-108-122-080 C-RES,U 1.2K-1/16W J a b
CD X R 0253 88-108-333-080 C-RES,U 33K-1/16W J a b
CD X R 0254 88-108-000-080 C-JUMPER,U a b
CD X R 0255 88-108-471-080 C-RES,U 470-1/16W J a b
CD X R 0256 88-108-563-080 C-RES,U 56K-1/16W J a b
CD X R 0257 88-108-103-080 C-RES,U 10K-1/16W J a b
CD X R 0258 88-108-822-080 C-RES,U 8.2K-1/16W J a b
CD X R 0259 88-108-820-080 C-RES,U 82-1/16W J a b
CD X R 0260 88-108-470-080 C-RES,U 47-1/16W J a b
CD X R 0261 88-108-222-080 C-RES,U 2.2K-1/16W J a b
CD X R 0262 88-108-222-080 C-RES,U 2.2K-1/16W J a b
CD X R 0263 88-108-332-080 C-RES,U 3.3K-1/16W J a b
CD X R 0264 88-108-332-080 C-RES,U 3.3K-1/16W J a b
CD X R 0265 88-108-102-080 C-RES,U 1K-1/16W J a b
CD X R 0266 88-108-109-080 C-RES,U 1-1/16W J a b
CD X R 0267 88-108-109-080 C-RES,U 1-1/16W J a b
CDC-X527M CDC-X527M
YHSF YUSF
CD X R 0268 88-108-820-080 C-RES,U 82-1/16W J a b
CD X R 0269 88-108-223-080 C-RES,U 22K-1/16W J a b
CD X R 0270 88-108-333-080 C-RES,U 33K-1/16W J a b
CD X R 0271 88-108-393-080 C-RES,U 39K-1/16W J a b
CD X R 0272 88-108-154-080 C-RES,U 150K-1/16W J a b
CD X R 0273 88-108-000-080 C-JUMPER,U a b
CD X R 0274 88-108-103-080 C-RES,U 10K-1/16W J a b
CD X R 0275 88-108-000-080 C-JUMPER,U a b
CD X R 0276 88-108-000-080 C-JUMPER,U a b
CD X R 0277 88-108-822-080 C-RES,U 8.2K-1/16W J a b
CD X R 0278 88-108-561-080 C-RES,U 560-1/16W J a b
CD X R 0281 88-108-155-080 C-RES,U 1.5M-1/16W J a b
CD X R 0282 88-108-155-080 C-RES,U 1.5M-1/16W J a b
CD X R 0283 88-108-154-080 C-RES,U 150K-1/16W J a b
CD X R 0284 88-108-223-080 C-RES,U 22K-1/16W J a b
CD X R 0285 88-108-123-080 C-RES,U 12K-1/16W J a b
CD X R 0286 88-108-154-080 C-RES,U 150K-1/16W J a b
CD X R 0288 88-108-152-080 C-RES,U 1.5K-1/16W J a b
CD X R 0291 88-108-101-080 C-RES,U 100-1/16W J a b
CD X R 0295 88-108-222-080 C-RES,U 2.2K-1/16W J a b
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-10-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
ELECTRICAL PARTS LIST -3/11
CDC-X527M CDC-X527M
YHSF YUSF
CD X R 0296 88-108-222-080 C-RES,U 2.2K-1/16W J a b
CD X R 0297 88-108-102-080 C-RES,U 1K-1/16W J a b
CD O X 0201 87-A70-371-080 VIB,CER 16.934MHZ CSTLS16M9X54 a b
FRONT O C 0601 87-A10-047-080 C-CAP,U 1-10 Z F a b
FRONT O C 0604 87-012-273-080 C-CAP,U 820P-50 K B GRM a b
FRONT O C 0605 87-A10-260-080 C-CAP,U 0.1-16 K B a b
FRONT O C 0681 87-A10-047-080 C-CAP,U 1-10 Z F a b
FRONT O C 0923 87-A10-260-080 C-CAP,U 0.1-16 K B a b
FRONT O CON0601 88-KTA-602-010 C-CONN,15P CAM-B67 a b
FRONT S D 0601 87-A40-817-040 C-ZENER,STZ6.8N a b
FRONT S D 0602 87-A40-817-040 C-ZENER,STZ6.8N a b
FRONT S D 0681 87-A40-817-040 C-ZENER,STZ6.8N a b
FRONT S IC 0601 87-A21-489-030 C-IC,LC75853NW a b
FRONT O IC 0681 87-A90-951-010 RCR UNIT,SBX1971-52 a b
FRONT O LCD0601 8C-KCG-616-010 LCD,CKC-F-G-H a b
FRONT O LED0641 87-A91-355-040 C-LED,BR1112H-TR-RED a b
FRONT O LED0642 87-A91-355-040 C-LED,BR1112H-TR-RED a b
FRONT O LED0643 87-A91-355-040 C-LED,BR1112H-TR-RED a b
FRONT O LED0651 87-A91-355-040 C-LED,BR1112H-TR-RED a b
FRONT O LED0652 87-A91-355-040 C-LED,BR1112H-TR-RED a b
CDC-X527M CDC-X527M
YHSF YUSF
FRONT O LED0653 87-A91-355-040 C-LED,BR1112H-TR-RED a b
FRONT O LED0661 87-A41-085-010 LED,NSPW315BS WHT a b
FRONT O LED0671 87-A41-118-040 C-LED,SEC1E01C-1 BLU a b
FRONT O LED0672 87-A41-118-040 C-LED,SEC1E01C-1 BLU a b
FRONT O LED0673 87-A41-118-040 C-LED,SEC1E01C-1 BLU a b
FRONT S Q 0651 89-324-122-040 C-TR,2SC2412KR a b
FRONT S Q 0661 89-324-122-040 C-TR,2SC2412KR a b
FRONT S Q 0671 89-324-122-040 C-TR,2SC2412KR a b
FRONT X R 0604 88-108-683-080 C-RES,U 68K-1/16W J a b
FRONT O R 0605 88-108-102-080 C-RES,U 1K-1/16W J a b
FRONT O R 0606 88-108-102-080 C-RES,U 1K-1/16W J a b
FRONT O R 0607 88-108-102-080 C-RES,U 1K-1/16W J a b
FRONT O R 0608 88-108-102-080 C-RES,U 1K-1/16W J a b
FRONT O R 0609 88-108-102-080 C-RES,U 1K-1/16W J a b
FRONT O R 0610 88-108-103-080 C-RES,U 10K-1/16W J a b
FRONT X R 0621 88-108-104-080 C-RES,U 100K-1/16W J a b
FRONT X R 0622 88-108-104-080 C-RES,U 100K-1/16W J a b
FRONT X R 0641 88-108-391-080 C-RES,U 390-1/16W J a b
FRONT X R 0651 88-108-561-080 C-RES,U 560-1/16W J a b
FRONT X R 0652 88-108-561-080 C-RES,U 560-1/16W J a b
CDC-X527M CDC-X527M
YHSF YUSF
FRONT X R 0653 88-108-561-080 C-RES,U 560-1/16W J a b
FRONT X R 0654 88-108-682-080 C-RES,U 6.8K-1/16W J a b
FRONT X R 0661 88-118-331-080 C-RES,S 330-1/10W J a b
FRONT X R 0662 88-108-682-080 C-RES,U 6.8K-1/16W J a b
FRONT O R 0663 88-108-102-080 C-RES,U 1K-1/16W J a b
FRONT X R 0671 88-108-391-080 C-RES,U 390-1/16W J a b
FRONT X R 0672 88-108-391-080 C-RES,U 390-1/16W J a b
FRONT X R 0673 88-108-391-080 C-RES,U 390-1/16W J a b
FRONT X R 0674 88-108-682-080 C-RES,U 6.8K-1/16W J a b
FRONT X R 0681 88-108-180-080 C-RES,U 18-1/16W J a b
FRONT O R 0682 88-108-102-080 C-RES,U 1K-1/16W J a b
FRONT O SW 0601 87-A90-164-080 SW,TACT SKQNAB(N) a b
FRONT O SW 0602 87-A90-164-080 SW,TACT SKQNAB(N) a b
FRONT O SW 0603 87-A90-164-080 SW,TACT SKQNAB(N) a b
FRONT O SW 0605 87-A90-164-080 SW,TACT SKQNAB(N) a b
FRONT O SW 0606 87-A90-164-080 SW,TACT SKQNAB(N) a b
FRONT O SW 0607 87-A90-164-080 SW,TACT SKQNAB(N) a b
FRONT O SW 0608 87-A90-164-080 SW,TACT SKQNAB(N) a b
FRONT O SW 0610 87-A90-164-080 SW,TACT SKQNAB(N) a b
FRONT O SW 0611 87-A90-164-080 SW,TACT SKQNAB(N) a b
CDC-X527M CDC-X527M
YHSF YUSF
FRONT O SW 0612 87-A91-987-080 SW,TACT SKQCAB a b
FRONT O SW 0613 87-A91-987-080 SW,TACT SKQCAB a b
FRONT O SW 0614 87-A91-987-080 SW,TACT SKQCAB a b
FRONT O SW 0615 87-036-339-080 C-SW,TACT SKQM a b
FRONT O SW 0616 87-A91-987-080 SW,TACT SKQCAB a b
FRONT O SW 0617 87-036-339-080 C-SW,TACT SKQM a b
FRONT O SW 0618 87-A91-987-080 SW,TACT SKQCAB a b
FRONT O SW 0621 87-A92-329-010 SW,RTRY SRP-1211VD a b
MAIN O C 0101 87-012-274-080 C-CAP,U 1000P-50 K B GRM a b
MAIN O C 0102 87-012-286-080 C-CAP,U 0.01-25 K B GRM a b
MAIN O C 0103 87-010-402-040 CAP,E 2.2-50 M 11L SME a b
MAIN O C 0106 87-012-282-080 C-CAP,U 4700P-50 K B GRM a b
MAIN O C 0107 87-010-379-040 CAP,E 22-16 M 11L SME a b
MAIN O C 0108 87-012-196-080 C-CAP,U 120P-50 J CH GRM a b
MAIN O C 0109 87-010-380-040 CAP,E 47-16 M 11L SME a b
MAIN O C 0110 87-010-787-080 C-CAP,U 0.022-25 K B GRM a b
MAIN O C 0112 87-012-281-080 C-CAP,U 3900P-50 K B GRM a b
MAIN O C 0113 87-012-286-080 C-CAP,U 0.01-25 K B GRM a b
MAIN O C 0114 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0115 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-11-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
ELECTRICAL PARTS LIST -4/11
CDC-X527M CDC-X527M
YHSF YUSF
MAIN O C 0116 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0131 87-A11-228-080 C-CAP,U 0.027-25 K B a b
MAIN O C 0132 87-A11-228-080 C-CAP,U 0.027-25 K B a b
MAIN O C 0133 87-A10-707-080 C-CAP,U 0.47-10 Z F a b
MAIN O C 0134 87-A10-707-080 C-CAP,U 0.47-10 Z F a b
MAIN O C 0140 87-012-282-080 C-CAP,U 4700P-50 K B GRM a b
MAIN O C 0176 87-012-286-080 C-CAP,U 0.01-25 K B GRM a b
MAIN O C 0401 87-A11-062-080 C-CAP,S 2.2-16 Z F a b
MAIN O C 0402 87-A11-062-080 C-CAP,S 2.2-16 Z F a b
MAIN O C 0403 87-012-276-080 C-CAP,U 1500P-50 K B GRM a b
MAIN O C 0404 87-012-276-080 C-CAP,U 1500P-50 K B GRM a b
MAIN O C 0405 87-A11-062-080 C-CAP,S 2.2-16 Z F a b
MAIN O C 0406 87-A11-062-080 C-CAP,S 2.2-16 Z F a b
MAIN O C 0407 87-010-220-080 C-CAP,S 0.018-25 K B GRM a b
MAIN O C 0408 87-010-220-080 C-CAP,S 0.018-25 K B GRM a b
MAIN O C 0409 87-A10-047-080 C-CAP,U 1-10 Z F a b
MAIN O C 0410 87-A10-047-080 C-CAP,U 1-10 Z F a b
MAIN O C 0411 87-A10-781-080 C-CAP,U 0.15-10 K B a b
MAIN O C 0412 87-A10-781-080 C-CAP,U 0.15-10 K B a b
MAIN O C 0413 87-A10-781-080 C-CAP,U 0.15-10 K B a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN O C 0414 87-A10-781-080 C-CAP,U 0.15-10 K B a b
MAIN O C 0415 87-A10-047-080 C-CAP,U 1-10 Z F a b
MAIN O C 0416 87-A10-047-080 C-CAP,U 1-10 Z F a b
MAIN O C 0417 87-010-498-040 CAP,E 10-16 M 5L SRE a b
MAIN O C 0418 87-010-498-040 CAP,E 10-16 M 5L SRE a b
MAIN O C 0419 87-010-498-040 CAP,E 10-16 M 5L SRE a b
MAIN O C 0420 87-010-498-040 CAP,E 10-16 M 5L SRE a b
MAIN O C 0422 87-010-555-080 CAP,E 100-10 M 5L MA a b
MAIN O C 0424 87-010-552-040 CAP,E 22-16 M 5L SRE a b
MAIN O C 0425 87-010-498-040 CAP,E 10-16 M 5L SRE a b
MAIN O C 0426 87-010-498-040 CAP,E 10-16 M 5L SRE a b
MAIN O C 0427 87-010-498-040 CAP,E 10-16 M 5L SRE a b
MAIN O C 0428 87-010-498-040 CAP,E 10-16 M 5L SRE a b
MAIN O C 0429 87-012-270-080 C-CAP,U 470P-50 K B GRM a b
MAIN O C 0430 87-012-270-080 C-CAP,U 470P-50 K B GRM a b
MAIN O C 0431 87-012-270-080 C-CAP,U 470P-50 K B GRM a b
MAIN O C 0432 87-012-270-080 C-CAP,U 470P-50 K B GRM a b
MAIN O C 0433 87-012-274-080 C-CAP,U 1000P-50 K B GRM a b
MAIN O C 0434 87-010-497-040 CAP,E 4.7-35 M 5L SRE a b
MAIN O C 0435 87-010-555-080 CAP,E 100-10 M 5L MA a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN O C 0438 87-012-280-080 C-CAP,U 3300P-50 K B GRM a b
MAIN O C 0439 87-012-280-080 C-CAP,U 3300P-50 K B GRM a b
MAIN O C 0440 87-A11-070-080 C-CAP,U 0.033-16 K B a b
MAIN O C 0441 87-010-380-040 CAP,E 47-16 M 11L SME a b
MAIN O C 0442 87-012-188-080 C-CAP,U 47P-50 J CH GRM a b
MAIN O C 0443 87-012-188-080 C-CAP,U 47P-50 J CH GRM a b
MAIN O C 0444 87-A11-070-080 C-CAP,U 0.033-16 K B a b
MAIN O C 0449 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0451 87-A10-707-080 C-CAP,U 0.47-10 Z F a b
MAIN O C 0452 87-A10-707-080 C-CAP,U 0.47-10 Z F a b
MAIN O C 0453 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0454 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0501 87-012-199-080 C-CAP,U 220P-50 J CH GRM a b
MAIN O C 0502 87-012-199-080 C-CAP,U 220P-50 J CH GRM a b
MAIN O C 0503 87-012-199-080 C-CAP,U 220P-50 J CH GRM a b
MAIN O C 0504 87-012-199-080 C-CAP,U 220P-50 J CH GRM a b
MAIN O C 0505 87-010-805-080 C-CAP,S 1-16 Z F GRM a b
MAIN O C 0506 87-010-805-080 C-CAP,S 1-16 Z F GRM a b
MAIN O C 0507 87-010-805-080 C-CAP,S 1-16 Z F GRM a b
MAIN O C 0508 87-010-805-080 C-CAP,S 1-16 Z F GRM a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN O C 0509 87-010-380-040 CAP,E 47-16 M 11L SME a b
MAIN O C 0510 87-010-805-080 C-CAP,S 1-16 Z F GRM a b
MAIN O C 0511 8A-KC7-623-000 CAP,E 2200-16 125 BT a b
MAIN O C 0512 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0513 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0514 87-A12-317-080 C-CAP,U 0.1-50 Z F a b
MAIN O C 0515 87-010-498-040 CAP,E 10-16 M 5L SRE a b
MAIN O C 0516 87-012-274-080 C-CAP,U 1000P-50 K B GRM a b
MAIN O C 0701 87-012-195-080 C-CAP,U 100P-50 J CH GRM a b
MAIN O C 0711 87-A10-047-080 C-CAP,U 1-10 Z F a b
MAIN O C 0712 87-A10-047-080 C-CAP,U 1-10 Z F a b
MAIN O C 0731 87-A10-707-080 C-CAP,U 0.47-10 Z F a b
MAIN O C 0732 87-A10-707-080 C-CAP,U 0.47-10 Z F a b
MAIN O C 0735 87-012-278-080 C-CAP,U 2200P-50 K B GRM a b
MAIN O C 0736 87-012-278-080 C-CAP,U 2200P-50 K B GRM a b
MAIN O C 0751 87-010-787-080 C-CAP,U 0.022-25 K B GRM a b
MAIN O C 0761 87-A10-707-080 C-CAP,U 0.47-10 Z F a b
MAIN O C 0762 87-A10-707-080 C-CAP,U 0.47-10 Z F a b
MAIN O C 0801 87-012-278-080 C-CAP,U 2200P-50 K B GRM a b
MAIN O C 0804 87-012-278-080 C-CAP,U 2200P-50 K B GRM a b
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-12-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
ELECTRICAL PARTS LIST -5/11
CDC-X527M CDC-X527M
YHSF YUSF
MAIN O C 0811 87-010-787-080 C-CAP,U 0.022-25 K B GRM a b
MAIN O C 0812 87-010-498-040 CAP,E 10-16 M 5L SRE a b
MAIN O C 0813 87-010-555-040 CAP,E 100-10 M 5L SRE a b
MAIN O C 0814 87-010-787-080 C-CAP,U 0.022-25 K B GRM a b
MAIN O C 0821 87-010-787-080 C-CAP,U 0.022-25 K B GRM a b
MAIN O C 0822 87-010-380-040 CAP,E 47-16 M 11L SME a b
MAIN O C 0831 87-010-380-040 CAP,E 47-16 M 11L SME a b
MAIN O C 0833 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0901 87-012-182-080 C-CAP,U 27P-50 J CH GRM a b
MAIN O C 0902 87-012-179-080 C-CAP,U 20P-50 J CH GRM a b
MAIN O C 0903 87-010-555-080 CAP,E 100-10 M 5L MA a b
MAIN O C 0904 87-016-039-090 CAP,DL 0.022F-5.5 Z 70 FM a b
MAIN O C 0906 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0907 87-010-404-040 CAP,E 4.7-50 M 11L SME a b
MAIN O C 0911 87-012-195-080 C-CAP,U 100P-50 J CH GRM a b
MAIN O C 0912 87-012-195-080 C-CAP,U 100P-50 J CH GRM a b
MAIN O C 0913 87-012-199-080 C-CAP,U 220P-50 J CH GRM a b
MAIN O C 0941 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O C 0942 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a b
MAIN O CON0701 87-A61-219-010 CONN,20P H 52089-2020 a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN O CON0702 88-KTA-603-010 CONN,15P CAM-B68 a b
MAIN O CON0801 8Z-KT1-624-010 CONN,16P SOC017 a b
MAIN S D 0101 87-A40-250-040 C-DIODE,DAN217 a b
MAIN S D 0440 87-020-331-040 C-DIODE,DAN202K a b
MAIN S D 0451 87-A40-250-040 C-DIODE,DAN217 a b
MAIN S D 0501 87-001-783-080 DIODE,1N4002 a b
MAIN S D 0502 87-001-783-080 DIODE,1N4002 a b
MAIN S D 0503 87-001-783-080 DIODE,1N4002 a b
MAIN S D 0504 87-001-783-080 DIODE,1N4002 a b
MAIN S D 0505 87-001-783-080 DIODE,1N4002 a b
MAIN S D 0506 87-001-783-080 DIODE,1N4002 a b
MAIN S D 0507 87-001-783-080 DIODE,1N4002 a b
MAIN S D 0508 87-001-783-080 DIODE,1N4002 a b
MAIN S D 0591 87-A40-337-080 ZENER,MTZJ6.8B a b
MAIN S D 0701 87-017-932-080 ZENER,MTZJ6.2B a b
MAIN S D 0702 87-017-932-080 ZENER,MTZJ6.2B a b
MAIN S D 0703 87-017-932-080 ZENER,MTZJ6.2B a b
MAIN S D 0704 87-017-932-080 ZENER,MTZJ6.2B a b
MAIN S D 0705 87-017-932-080 ZENER,MTZJ6.2B a b
MAIN S D 0706 87-017-932-080 ZENER,MTZJ6.2B a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN S D 0707 87-017-932-080 ZENER,MTZJ6.2B a b
MAIN S D 0708 87-017-932-080 ZENER,MTZJ6.2B a b
MAIN S D 0751 87-A40-817-040 C-ZENER,STZ6.8N a b
MAIN S D 0752 87-A40-817-040 C-ZENER,STZ6.8N a b
MAIN S D 0753 87-A40-817-040 C-ZENER,STZ6.8N a b
MAIN S D 0811 87-001-783-080 DIODE,1N4002 a b
MAIN S D 0812 87-001-783-080 DIODE,1N4002 a b
MAIN S D 0813 87-017-932-080 ZENER,MTZJ6.2B a b
MAIN S D 0821 87-070-334-080 ZENER,MTZJ10B a b
MAIN S D 0831 87-070-335-080 ZENER,MTZJ8.2B a b
MAIN S D 0881 87-A40-798-010 DIODE,1N5402 (3A/200V) a b
MAIN S D 0883 87-020-465-080 DIODE,1SS133 a b
MAIN S D 0901 87-020-331-040 C-DIODE,DAN202K a b
MAIN S D 0902 87-020-331-040 C-DIODE,DAN202K a b
MAIN S D 0903 87-020-331-040 C-DIODE,DAN202K a b
MAIN S D 0904 87-070-136-080 ZENER,MTZJ5.1B a b
MAIN S D 0905 87-017-366-040 C-DIODE,DAN202U a b
MAIN S D 0906 87-020-331-040 C-DIODE,DAN202K a b
MAIN S D 0907 87-020-331-040 C-DIODE,DAN202K a b
MAIN S D 0912 87-020-465-080 DIODE,1SS133 a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN S D 0914 87-020-465-080 DIODE,1SS133 a b
MAIN S D 0915 87-020-465-080 DIODE,1SS133 a b
MAIN S D 0916 87-020-465-080 DIODE,1SS133 a b
MAIN S D 0941 87-070-136-080 ZENER,MTZJ5.1B a b
MAIN ! S F 0881 8B-KC1-621-010 FUSE,15A 32V a b
MAIN S IC 0401 87-A22-225-030 C-IC,LA2657M a b
MAIN S IC 0402 87-017-917-040 C-IC,BU4066BCF a b
MAIN S IC 0501 8B-KCF-616-010 IC,TA8273H a b
MAIN S IC 0901 8C-KCF-611-030 C-IC,LC72366-9A69 a b
MAIN S IC 0941 88-KT1-606-080 IC,PST994D a b
MAIN O J 0101 8Z-KT1-614-010 ANT,AW-002 a b
MAIN O J 0401 87-A61-224-110 JACK,PIN 4P XR-401 a b
MAIN O J 0751 8A-KC7-620-010 JACK,DIN 13P SKDS1302 a b
MAIN X JR 0101 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0102 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0103 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0104 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0105 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0106 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0108 88-118-000-080 C-JUMPER,S a b
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-13-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
ELECTRICAL PARTS LIST -6/11
CDC-X527M CDC-X527M
YHSF YUSF
MAIN X JR 0109 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0110 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0111 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0113 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0116 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0117 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0118 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0119 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0120 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0122 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0123 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0125 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0127 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0128 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0129 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0130 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0131 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0132 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0133 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0134 88-118-000-080 C-JUMPER,S a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN X JR 0135 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0136 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0137 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0138 88-118-000-080 C-JUMPER,S a b
MAIN X JR 0501 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0502 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0503 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0504 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0505 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0506 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0507 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0508 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0509 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0510 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0511 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0513 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0514 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0515 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0516 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0517 88-129-000-080 C-JUMPER, 3216 a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN X JR 0518 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0519 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0520 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0521 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0523 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0524 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0525 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0526 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0530 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0531 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0532 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0533 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0534 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0535 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0536 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0537 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0538 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0539 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0540 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0541 88-129-000-080 C-JUMPER, 3216 a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN X JR 0542 88-129-000-080 C-JUMPER, 3216 a b
MAIN X JR 0543 88-129-000-080 C-JUMPER, 3216 a b
MAIN O L 0101 87-003-143-080 COIL,4.7UH K LAL02 a b
MAIN O L 0102 8Z-KT1-619-010 COIL,68MH K7-D a b
MAIN O L 0401 87-003-143-080 COIL,4.7UH K LAL02 a b
MAIN O L 0731 87-005-906-080 C-COIL,S 10UH K LK2125 a b
MAIN O L 0801 8B-KCF-615-010 FLTR,AMORPHOUS -CHOKE a b
MAIN O L 0901 87-003-149-080 COIL,47UH J LAL02 a b
MAIN S Q 0101 89-324-122-040 C-TR,2SC2412KR a b
MAIN S Q 0102 89-324-122-040 C-TR,2SC2412KR a b
MAIN S Q 0105 87-A30-289-040 C-TR,2SA1037AK(Q) a b
MAIN S Q 0106 89-324-122-040 C-TR,2SC2412KR a b
MAIN S Q 0107 87-A30-288-040 C-TR,DTC114YKA a b
MAIN S Q 0109 87-A30-287-040 C-TR,DTC114TKA a b
MAIN S Q 0401 87-A30-287-040 C-TR,DTC114TKA a b
MAIN S Q 0402 87-A30-287-040 C-TR,DTC114TKA a b
MAIN S Q 0403 87-A30-287-040 C-TR,DTC114TKA a b
MAIN S Q 0404 87-A30-287-040 C-TR,DTC114TKA a b
MAIN S Q 0409 87-A30-405-040 C-TR,DTC114TUA a b
MAIN S Q 0410 87-A30-405-040 C-TR,DTC114TUA a b
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-14-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
ELECTRICAL PARTS LIST -7/11
CDC-X527M CDC-X527M
YHSF YUSF
MAIN S Q 0441 87-A30-287-040 C-TR,DTC114TKA a b
MAIN S Q 0442 87-A30-282-040 C-TR,DTA114TKA a b
MAIN S Q 0451 89-324-122-040 C-TR,2SC2412KR a b
MAIN S Q 0591 87-A30-282-040 C-TR,DTA114TKA a b
MAIN S Q 0592 87-A30-282-040 C-TR,DTA114TKA a b
MAIN S Q 0751 87-A30-142-040 C-TR,DTA123EKA a b
MAIN S Q 0752 87-A30-427-040 C-TR,DTC114EKA a b
MAIN S Q 0801 89-213-750-010 TR,2SB1375 a b
MAIN S Q 0802 87-A30-287-040 C-TR,DTC114TKA a b
MAIN S Q 0811 87-A30-301-080 TR,2SD1862 a b
MAIN S Q 0821 89-420-120-010 TR,2SD2012 a b
MAIN S Q 0831 89-420-120-010 TR,2SD2012 a b
MAIN S Q 0832 87-A30-289-040 C-TR,2SA1037AK(Q) a b
MAIN S Q 0833 87-A30-427-040 C-TR,DTC114EKA a b
MAIN X R 0101 88-108-105-080 C-RES,U 1M-1/16W J a b
MAIN X R 0102 88-108-821-080 C-RES,U 820-1/16W J a b
MAIN O R 0103 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0104 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0105 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN O R 0106 88-108-223-080 C-RES,U 22K-1/16W J a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN O R 0110 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN X R 0111 88-108-222-080 C-RES,U 2.2K-1/16W J a b
MAIN X R 0112 88-108-330-080 C-RES,U 33-1/16W J a b
MAIN X R 0113 88-108-221-080 C-RES,U 220-1/16W J a b
MAIN X R 0114 88-108-000-080 C-JUMPER,U a b
MAIN X R 0115 88-118-100-080 C-RES,S 10-1/10W J a b
MAIN O R 0116 88-108-473-080 C-RES,U 47K-1/16W J a b
MAIN X R 0117 88-108-334-080 C-RES,U 330K-1/16W J a b
MAIN X R 0118 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN O R 0119 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN X R 0120 88-108-122-080 C-RES,U 1.2K-1/16W J a b
MAIN O R 0121 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN X R 0131 88-121-393-080 RES,39K-1/8W J a b
MAIN X R 0132 88-121-393-080 RES,39K-1/8W J a b
MAIN X R 0133 88-108-000-080 C-JUMPER,U a b
MAIN O R 0140 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0401 88-108-153-080 C-RES,U 15K-1/16W J a b
MAIN O R 0402 88-108-153-080 C-RES,U 15K-1/16W J a b
MAIN X R 0403 88-108-392-080 C-RES,U 3.9K-1/16W J a b
MAIN X R 0404 88-108-392-080 C-RES,U 3.9K-1/16W J a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN O R 0405 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0406 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0407 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0408 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN X R 0410 88-108-682-080 C-RES,U 6.8K-1/16W J a b
MAIN X R 0411 88-108-682-080 C-RES,U 6.8K-1/16W J a b
MAIN O R 0415 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0416 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0417 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0418 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN X R 0419 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0420 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0421 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0422 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0423 88-108-222-080 C-RES,U 2.2K-1/16W J a b
MAIN O R 0424 88-108-272-080 C-RES,U 2.7K-1/16W J a b
MAIN X R 0425 88-108-333-080 C-RES,U 33K-1/16W J a b
MAIN X R 0426 88-108-333-080 C-RES,U 33K-1/16W J a b
MAIN O R 0427 88-108-473-080 C-RES,U 47K-1/16W J a b
MAIN O R 0428 88-108-473-080 C-RES,U 47K-1/16W J a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN X R 0429 88-121-470-080 RES,47-1/8W J a b
MAIN X R 0430 88-108-683-080 C-RES,U 68K-1/16W J a b
MAIN X R 0431 88-108-683-080 C-RES,U 68K-1/16W J a b
MAIN X R 0432 88-108-683-080 C-RES,U 68K-1/16W J a b
MAIN X R 0433 88-108-683-080 C-RES,U 68K-1/16W J a b
MAIN X R 0434 88-108-393-080 C-RES,U 39K-1/16W J a b
MAIN O R 0435 88-108-563-080 C-RES,U 56K-1/16W J a b
MAIN O R 0436 88-108-563-080 C-RES,U 56K-1/16W J a b
MAIN X R 0437 88-108-393-080 C-RES,U 39K-1/16W J a b
MAIN X R 0438 88-108-274-080 C-RES,U 270K-1/16W J a b
MAIN O R 0439 88-108-473-080 C-RES,U 47K-1/16W J a b
MAIN X R 0441 88-121-222-080 RES,2.2K-1/8W J a b
MAIN O R 0442 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN X R 0451 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0452 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0453 88-108-105-080 C-RES,U 1M-1/16W J a b
MAIN O R 0454 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN O R 0456 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN X R 0457 88-108-333-080 C-RES,U 33K-1/16W J a b
MAIN O R 0458 88-108-224-080 C-RES,U 220K-1/16W J a b
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-15-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
ELECTRICAL PARTS LIST -8/11
CDC-X527M CDC-X527M
YHSF YUSF
MAIN O R 0501 88-108-123-080 C-RES,U 12K-1/16W J a b
MAIN O R 0502 88-108-123-080 C-RES,U 12K-1/16W J a b
MAIN O R 0503 88-108-123-080 C-RES,U 12K-1/16W J a b
MAIN O R 0504 88-108-123-080 C-RES,U 12K-1/16W J a b
MAIN X R 0505 88-108-183-080 C-RES,U 18K-1/16W J a b
MAIN X R 0506 88-108-183-080 C-RES,U 18K-1/16W J a b
MAIN X R 0507 88-108-183-080 C-RES,U 18K-1/16W J a b
MAIN X R 0508 88-108-183-080 C-RES,U 18K-1/16W J a b
MAIN X R 0509 88-121-103-080 RES,10K-1/8W J a b
MAIN O R 0592 88-108-473-080 C-RES,U 47K-1/16W J a b
MAIN O R 0701 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0702 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0703 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0704 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0705 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0706 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0707 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0708 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN X R 0709 88-121-100-080 RES,10-1/8W J a b
MAIN X R 0731 88-108-472-080 C-RES,U 4.7K-1/16W J a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN X R 0732 88-108-472-080 C-RES,U 4.7K-1/16W J a b
MAIN O R 0733 88-108-562-080 C-RES,U 5.6K-1/16W J a b
MAIN O R 0734 88-108-562-080 C-RES,U 5.6K-1/16W J a b
MAIN X R 0751 88-108-222-080 C-RES,U 2.2K-1/16W J a b
MAIN O R 0752 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0753 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0754 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0755 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0756 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN O R 0757 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN X R 0761 88-108-472-080 C-RES,U 4.7K-1/16W J a b
MAIN X R 0762 88-108-472-080 C-RES,U 4.7K-1/16W J a b
MAIN X R 0763 88-108-392-080 C-RES,U 3.9K-1/16W J a b
MAIN X R 0764 88-108-392-080 C-RES,U 3.9K-1/16W J a b
MAIN O R 0801 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN O R 0802 88-148-102-080 C-RES, 1K-1/2W J a b
MAIN X R 0803 88-148-229-080 C-RES, 2.2-1/2W J a b
MAIN X R 0811 88-118-101-080 C-RES,S 100-1/10W J a b
MAIN X R 0812 88-108-472-080 C-RES,U 4.7K-1/16W J a b
MAIN X R 0813 88-118-101-080 C-RES,S 100-1/10W J a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN X R 0821 88-118-391-080 C-RES,S 390-1/10W J a b
MAIN X R 0822 88-118-391-080 C-RES,S 390-1/10W J a b
MAIN X R 0831 88-148-151-080 C-RES, 150-1/2W J a b
MAIN O R 0833 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN X R 0834 88-118-102-080 C-RES,S 1K-1/10W J a b
MAIN O R 0902 88-108-823-080 C-RES,U 82K-1/16W J a b
MAIN O R 0903 88-108-473-080 C-RES,U 47K-1/16W J a b
MAIN X R 0904 88-108-474-080 C-RES,U 470K-1/16W J a b
MAIN X R 0905 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0906 88-108-222-080 C-RES,U 2.2K-1/16W J a b
MAIN O R 0908 88-108-224-080 C-RES,U 220K-1/16W J a b
MAIN X R 0909 88-121-104-080 RES,100K-1/8W J a b
MAIN X R 0910 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN O R 0911 88-108-223-080 C-RES,U 22K-1/16W J a b
MAIN X R 0912 88-108-222-080 C-RES,U 2.2K-1/16W J a b
MAIN O R 0913 88-108-223-080 C-RES,U 22K-1/16W J a b
MAIN X R 0914 88-121-104-080 RES,100K-1/8W J a b
MAIN X R 0915 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0916 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0918 88-108-104-080 C-RES,U 100K-1/16W J a b
CDC-X527M CDC-X527M
YHSF YUSF
MAIN O R 0921 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN X R 0922 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0923 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0924 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0925 88-108-104-080 C-RES,U 100K-1/16W J a b
MAIN X R 0926 88-121-102-080 RES,1K-1/8W J a b
MAIN O R 0927 88-108-332-080 C-RES,U 3.3K-1/16W J a b
MAIN X R 0928 88-121-332-080 RES,3.3K-1/8W J a b
MAIN O R 0929 88-108-102-080 C-RES,U 1K-1/16W J a b
MAIN X R 0933 88-121-102-080 RES,1K-1/8W J a b
MAIN X R 0934 88-121-102-080 RES,1K-1/8W J a b
MAIN X R 0935 88-121-102-080 RES,1K-1/8W J a b
MAIN X R 0936 88-121-102-080 RES,1K-1/8W J a b
MAIN X R 0941 88-108-392-080 C-RES,U 3.9K-1/16W J a b
MAIN O R 0942 88-108-103-080 C-RES,U 10K-1/16W J a b
MAIN X R 0943 88-108-472-080 C-RES,U 4.7K-1/16W J a b
MAIN X R 0952 88-108-000-080 C-JUMPER,U a b
MAIN O SW 0901 87-A91-070-010 SW,TACT SKHHLV a b
MAIN O TU 0101 8C-KCG-621-010 TU UNIT, FAE347-A30 a b
MAIN X W 0001 8Z-KC1-614-010 WIRE,ANT a b
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-16-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
ELECTRICAL PARTS LIST -9/11
CDC-X527M CDC-X527M
YHSF YUSF
MAIN O X 0901 87-A70-362-080 VIB,XTAL 4.5MHZ HC-49/U-S a b
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
-17-
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
ELECTRICAL PARTS LIST -10/11 (BZG-3 BNF) -1/1
BZG-3
BNF
FLEX O 8B-ZG3-607-010 PWB,FLEX PIC 2 a
SW O S 0001 87-A92-279-080 C-SW,PUSH 2-1 ESE22MH22XQ a
SW O S 0002 87-A92-279-080 C-SW,PUSH 2-1 ESE22MH22XQ a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-18-
ELECTRICAL PARTS LIST -11/11
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form
LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ 1.0 0.5 0.35 104
Lt
W
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-19-
TRANSISTORILLUSTRATION-1/1
C
C
C
B
B
B
E
E
E
2SA1037AK(Q)
2SC2412KR
DTA114TKA
DTC114YKA
DTC114EKA
DTA123EKA
2SD2012
2SB1375 2SD1862
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-20-
SCHEMATIC DIAGRAM -1/3 (MAIN)
Q
JP
JP
JP
/5.5
SW
SW
SW
SW
Q101,102
FILTER
LEVEL AMP
E-VOL
CPU
TUNER PACK
Q401~404
MUTE SW
Q441,442
SWITCHING
Q592
Q409,410
BU0666BCF
VDD DETECT
REGULATOR
Q591
ADD DETECT
SW
RESET
IC941
RESET IC
Q821,831,832
REGULATOR
Q811
REGULATOR
SW
TO CD C.B CON201
TO POWER SUPPLY/SPEAKER
CONNECTOR
TO FRONT C.B CON601
:FM
:AM
SIGNAL:
MAIN C.B
Q751,752
ACC CONT
BBE SW
ANALOG SW
12 3
64
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
Other manuals for CDC-X527M
1
This manual suits for next models
4
Table of contents
Other Aiwa Car Receiver manuals
