S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
CSD-RD370
• TYPE: EZ
S/M Code No. 09–996–403–6T4
COMPACT DISC STEREO
CASSETTE RECORDER
ELECTRICAL MAIN PARTS LIST - 1/7
NOTE: The characters in the suffix column indicate the part usage.
EZ .....................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 218 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 217 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 228 87-010-401-080 CAP, ELECT 1-50V A...................
C 229 87-010-401-080 CAP, ELECT 1-50V A...................
C 231 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 232 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 238 87-010-263-080 CAP, ELECT 100-10V A...................
C 237 87-010-374-080 CAP, ELECT 47-10V A...................
C 235 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 236 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 233 87-010-546-080 CAP, ELECT 0.33-50V A...................
C 234 87-010-546-080 CAP, ELECT 0.33-50V A...................
C 248 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 247 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 246 87-010-405-080 CAP, ELECT 10-50V A...................
C 242 87-010-405-080 CAP, ELECT 10-50V A...................
C 244 87-010-405-080 CAP, ELECT 10-50V A...................
C 245 87-010-405-080 CAP, ELECT 10-50V A...................
C 243 87-010-405-080 CAP, ELECT 10-50V A...................
C 241 87-010-405-080 CAP, ELECT 10-50V A...................
C 261 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 262 87-010-402-080 CAP, ELECT 2.2-50V A...................
D 281 87-A40-466-080 ZENER,MTZJ2.7A A...................
IC 203 87-A21-111-040 C-IC,M62495FP A...................
C 209 87-010-190-080 S CHIP F 0.01 A...................
C 208 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 207 87-010-408-080 CAP, ELECT 47-50V A...................
C 210 87-010-190-080 S CHIP F 0.01 A...................
C 215 87-010-425-080 C-CAP,0.22-25 F A...................
C 216 87-010-425-080 C-CAP,0.22-25 F A...................
C 211 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 212 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 223 87-010-190-080 S CHIP F 0.01 A...................
C 222 87-010-190-080 S CHIP F 0.01 A...................
C 226 87-010-190-080 S CHIP F 0.01 A...................
C 220 87-010-405-080 CAP, ELECT 10-50V A...................
IC 201 87-A20-946-040 C-IC,MM1434XF A...................
C 251 87-010-401-080 CAP, ELECT 1-50V A...................
C 263 87-010-178-080 CHIP CAP 1000P A...................
C 264 87-010-178-080 CHIP CAP 1000P A...................
C 267 87-010-380-080 CAP, ELECT 47-16V A...................
C 268 87-010-380-080 CAP, ELECT 47-16V A...................
C 266 87-010-383-080 CAP, ELECT 33-25V A...................
C 265 87-010-383-080 CAP, ELECT 33-25V A...................
C 279 87-010-112-080 CAP, ELECT 100-16V A...................
C 271 87-010-221-080 CAP, ELECT 470-10V A...................
C 272 87-010-221-080 CAP, ELECT 470-10V A...................
C 277 87-010-260-080 CAP, ELECT 47-25V A...................
C 278 87-010-384-080 CAP, ELECT 100-25V A...................
C 273 87-010-628-080 CAP,E 3.3-16 M 5L BP SRE A...................
C 274 87-010-628-080 CAP,E 3.3-16 M 5L BP SRE A...................
C 280 87-010-401-080 CAP, ELECT 1-50V A...................
C 281 87-010-401-080 CAP, ELECT 1-50V A...................
IC 201 87-A20-591-010 IC,BA5417 A...................
J 251 87-A60-569-010 JACK,HTJ-035-18 A...................
Q 244 89-320-011-010 TR,2SC2001 (0.6W) A...................
Q 243 89-320-011-010 TR,2SC2001 (0.6W) A...................
C 308 87-010-221-080 CAP, ELECT 470-10V A...................
C 309 87-010-263-080 CAP, ELECT 100-10V A...................
C 307 87-010-401-080 CAP, ELECT 1-50V A...................
C 306 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 301 87-010-453-010 CAP, ELECT 4700-25V A...................
C 315 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 314 87-010-248-080 CAP, ELECT 220-10V A...................
C 310 87-010-248-080 CAP, ELECT 220-10V A...................
C 312 87-010-248-080 CAP, ELECT 220-10V A...................
C 311 87-010-263-080 CAP, ELECT 100-10V A...................
C 903 87-A10-577-080 CAP,CER 0.022-50 Z YF A...................
C 904 87-A10-577-080 CAP,CER 0.022-50 Z YF A...................
C 901 87-A10-577-080 CAP,CER 0.022-50 Z YF A...................
C 902 87-A10-577-080 CAP,CER 0.022-50 Z YF A...................
D 307 87-017-148-080 ZENER,HZS6A1L A...................
D 304 87-017-161-080 ZENER,HZS7C2L A...................
D 308 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 303 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 309 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 305 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 306 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 311 87-017-139-010 ZENER,HZS15-2 A...................
D 901 87-A40-465-010 DIODE,FR202 A...................
D 904 87-A40-465-010 DIODE,FR202 A...................
D 903 87-A40-465-010 DIODE,FR202 A...................
D 902 87-A40-465-010 DIODE,FR202 A...................
FC 0 87-033-213-010 CLAMP,FUSE SMK A...................
IC 310 87-070-416-010 IC,NJU7201 L55 A...................
Q 303 87-026-291-010 TR,DTC124XS A...................
ELECTRICAL MAIN PARTS LIST - 2/7
Q 307 87-026-462-010 TR,2SC1740S A...................
Q 305 87-026-462-010 TR,2SC1740S A...................
Q 302 87-026-463-010 TR,2SA933S,RS A...................
Q 306 88-NF9-637-010 TR,2SA1318T/U A...................
Q 301 89-112-965-010 TR,2SA1296GR A...................
Q 304 89-213-702-010 TR,2SB1370 (1.8W) A...................
Q 310 87-026-462-010 TR,2SC1740S A...................
C 804 87-010-177-080 C-CAP,S 820P-50 SL A...................
C 803 87-010-177-080 C-CAP,S 820P-50 SL A...................
C 802 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 801 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 809 87-010-406-010 CAP,E 22-50 SM A...................
C 806 87-012-158-080 C-CAP,S 390P-50 CH A...................
C 805 87-012-158-080 C-CAP,S 390P-50 CH A...................
C 815 87-010-374-010 CAP, ELECT 47-10V A...................
C 813 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 814 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 811 87-010-404-010 CONDENSER 4.7-50 A...................
C 812 87-010-404-010 CONDENSER 4.7-50 A...................
C 810 87-010-406-010 CAP,E 22-50 SM A...................
C 823 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 824 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 827 87-010-404-010 CONDENSER 4.7-50 A...................
C 828 87-010-404-010 CONDENSER 4.7-50 A...................
C 825 87-010-405-080 CAP, ELECT 10-50V A...................
C 826 87-010-405-080 CAP, ELECT 10-50V A...................
C 822 87-012-153-080 C-CAP,S 120P-50 CH A...................
C 821 87-012-153-080 C-CAP,S 120P-50 CH A...................
C 833 87-010-179-080 CAP,CHIP S B1200P A...................
C 839 87-010-186-080 CAP,CHIP 4700P A...................
C 831 87-010-198-080 CAP, CHIP 0.022 A...................
C 832 87-010-198-080 CAP, CHIP 0.022 A...................
C 834 87-010-248-080 CAP, ELECT 220-10V A...................
C 830 87-010-260-080 CAP, ELECT 47-25V A...................
C 835 87-010-374-010 CAP, ELECT 47-10V A...................
C 838 87-010-405-080 CAP, ELECT 10-50V A...................
C 845 87-010-178-080 CHIP CAP 1000P A...................
C 844 87-010-178-080 CHIP CAP 1000P A...................
C 849 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 840 87-010-186-080 CAP,CHIP 4700P A...................
C 843 87-010-190-080 S CHIP F 0.01 A...................
C 841 87-010-194-080 CAP, CHIP 0.047 A...................
C 846 87-010-194-080 CAP, CHIP 0.047 A...................
C 842 87-010-194-080 CAP, CHIP 0.047 A...................
C 850 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 851 87-010-186-080 CAP,CHIP 4700P A...................
CN 801 87-049-469-010 CONN,4P V A...................
CN 802 87-049-469-010 CONN,4P V A...................
D 809 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 802 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 807 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 808 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 805 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 801 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 806 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 804 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 803 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 810 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 841 87-070-136-080 ZENER,MTZJ5.1B A...................
IC 801 87-A21-145-040 C-IC,BA4560F-E2 A...................
IC 802 87-A21-145-040 C-IC,BA4560F-E2 A...................
L 801 87-007-342-010 COIL,OSC 85K BIAS A...................
Q 802 87-026-462-010 TR,2SC1740S A...................
Q 803 87-026-463-010 TR,2SA933S,RS A...................
Q 804 87-026-463-010 TR,2SA933S,RS A...................
Q 808 87-026-496-080 FET,2SJ103GR A...................
Q 809 87-026-496-080 FET,2SJ103GR A...................
Q 807 89-110-150-010 TR,2SA1015 A...................
Q 805 89-110-150-010 TR,2SA1015 A...................
Q 810 87-026-464-010 TR,DTC114TS A...................
R 840 87-029-124-010 RES,FUSE 2.2-1/4 A...................
C 299 87-010-190-080 S CHIP F 0.01 A...................
C 321 87-010-190-080 S CHIP F 0.01 A...................
C 322 87-010-263-080 CAP, ELECT 100-10V A...................
C 325 87-010-405-080 CAP, ELECT 10-50V A...................
CN 204 87-049-469-010 CONN,4P V A...................
CN 203 87-049-469-010 CONN,4P V A...................
CN 201 87-099-016-010 CONN,14P 6216V A...................
CN 205 87-A60-109-010 CONN,2P V S2M-2W A...................
D 32 87-027-607-080 ZENER,HZ7B3L A...................
D 322 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 323 87-020-465-080 DIODE,1SS133 (110MA) A...................
Q 323 87-026-291-080 TR,DTC124XS A...................
Q 322 87-026-463-080 TR,2SA933S (0.3W) A...................
Q 321 89-318-154-080 TR,2SC1815 (0.4W) A...................
8Z-CH4-694-010 LCD,AIW4124-32P3S A...................
C 609 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 608 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 606 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 607 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 601 87-010-313-080 CAP, CHIP 18P A...................
C 604 87-010-314-080 C-CAP,S 22P-50V A...................
ELECTRICAL MAIN PARTS LIST - 3/7
C 602 87-010-315-080 C-CAP,S 27P-50 CH A...................
C 605 87-010-317-080 C-CAP,S 39P-50 CH A...................
C 603 87-010-317-080 C-CAP,S 39P-50 CH ....................
C 603 87-010-319-080 C-CAP,S 56P-50 CH A...................
C 615 87-010-070-080 47UF 50V, ELECTROLYTIC A...................
C 616 87-010-071-080 CAP, ELECT 1-50 M 5L SRE A...................
C 613 87-010-072-080 CAP 2.2-50V A...................
C 611 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 614 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 612 87-010-248-080 CAP, ELECT 220-10V ....................
C 610 87-010-263-080 CAP, ELECT 100-10V ....................
C 610 87-010-264-080 CAP,E 100-10 5L A...................
C 615 87-010-400-080 CAP, ELECT 0.47-50V ....................
C 616 87-010-401-080 CAP, ELECT 1-50V ....................
C 613 87-010-402-080 CAP, ELECT 2.2-50V ....................
C 612 87-A10-189-040 CAP,E 220-10 A...................
CN 601 87-099-031-010 CONN,14P 6216 H A...................
CN 603 87-099-199-010 CONN,6P 6216 H ....................
CN 608 87-099-200-010 CONN,7P 6216H A...................
CN 609 87-099-200-010 CONN,7P 6216H A...................
CN 602 87-099-200-010 CONN,7P 6216H A...................
CN 605 87-099-200-010 CONN,7P 6216H A...................
CN 604 87-099-200-010 CONN,7P 6216H A...................
CN 603 87-099-203-010 CONN,10P 6216 H A...................
CN 606 87-A60-109-010 CONN,2P V S2M-2W A...................
D 602 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 601 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 611 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 614 87-020-465-080 DIODE,1SS133 (110MA) ....................
D 612 87-020-465-080 DIODE,1SS133 (110MA) A...................
IC 601 8Z-CH4-642-010 IC,LC867132V-5L50 ....................
IC 601 8Z-CH4-693-010 IC,LC867248-*** A...................
L 601 87-003-171-010 COIL,15UH TROIDAL A...................
LCD 601 8Z-CH4-635-010 LCD,HLC7365 ZCH-4 ....................
LED 608 88-CD6-630-010 LED,934ID RED A...................
LED 607 88-CD6-630-010 LED,934ID RED A...................
LED 603 88-CD6-630-010 LED,934ID RED A...................
LED 601 88-CD6-630-010 LED,934ID RED A...................
LED 602 88-CD6-630-010 LED,934ID RED A...................
LED 609 88-CD6-630-010 LED,934ID RED ....................
LED 604 88-CD6-630-010 LED,934ID RED A...................
LED 606 88-CD6-630-010 LED,934ID RED A...................
LED 605 88-CD6-630-010 LED,934ID RED ....................
LED 610 88-CD6-631-010 LED,934GD GRN A...................
Q 601 87-026-291-010 TR,DTC124XS A...................
Q 603 87-026-291-010 TR,DTC124XS A...................
Q 602 87-026-463-010 TR,2SA933S,RS A...................
Q 607 87-026-464-010 TR,DTC114TS A...................
Q 606 87-026-464-010 TR,DTC114TS A...................
Q 608 87-026-464-010 TR,DTC114TS A...................
Q 604 87-026-464-010 TR,DTC114TS A...................
Q 609 87-026-464-010 TR,DTC114TS A...................
Q 605 87-026-464-010 TR,DTC114TS A...................
Q 611 87-026-464-010 TR,DTC114TS ....................
Q 610 87-026-464-010 TR,DTC114TS A...................
Q 621 87-026-291-010 TR,DTC124XS ....................
S 601 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 608 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 605 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 609 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 606 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 601 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 603 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 602 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 604 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 607 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 617 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 614 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 616 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 615 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 612 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 611 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 615 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 610 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 616 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 614 87-A90-696-080 SW,TACT TS2103-03-430 ....................
S 613 87-A90-696-080 SW,TACT TS2103-03-430 ....................
X 602 87-030-273-010 VIB,XTAL 32.768K5PPM ....................
X 601 87-030-273-010 VIB,XTAL 32.768K5PPM A...................
X 602 87-A70-070-080 VIB,CER 5.76MHZ CRHF A...................
X 601 87-A70-070-080 VIB,CER 5.76MHZ CRHF ....................
C 407 87-010-178-080 CHIP CAP 1000P A...................
C 400 87-010-178-080 CHIP CAP 1000P A...................
C 402 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 405 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 409 87-010-248-080 CAP, ELECT 220-10V A...................
C 404 87-010-248-080 CAP, ELECT 220-10V A...................
C 403 87-010-263-080 CAP, ELECT 100-10V A...................
C 406 87-010-374-080 CAP, ELECT 47-10V A...................
C 401 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 413 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 410 87-010-263-080 CAP, ELECT 100-10V A...................
ELECTRICAL MAIN PARTS LIST - 4/7
C 412 87-010-401-080 CAP, ELECT 1-50V A...................
C 414 87-010-405-080 CAP, ELECT 10-50V A...................
C 416 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 417 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 425 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 429 87-010-186-080 CAP,CHIP 4700P A...................
C 439 87-010-178-080 CHIP CAP 1000P A...................
C 438 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 435 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 436 87-010-374-080 CAP, ELECT 47-10V A...................
C 432 87-010-374-080 CAP, ELECT 47-10V A...................
C 433 87-010-401-080 CAP, ELECT 1-50V A...................
C 437 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 431 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 430 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 440 87-010-147-080 C-CAP,S 3P-50 CH A...................
C 445 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 447 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 446 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 442 87-010-313-080 CAP, CHIP 18P A...................
C 448 87-010-315-080 C-CAP,S 27P-50 CH A...................
C 459 87-010-263-080 CAP, ELECT 100-10V A...................
C 458 87-010-316-080 C-CAP,S 33P-50 CH A...................
C 457 87-010-316-080 C-CAP,S 33P-50 CH A...................
C 450 87-012-140-080 CAP 470P A...................
C 463 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 460 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 468 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 461 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 466 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 463 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 467 87-010-263-080 CAP, ELECT 100-10V A...................
C 462 87-010-370-080 CAP,E 330-6.3 SME A...................
C 465 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 469 87-012-154-080 C-CAP,S 150P-50 CH A...................
C 472 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 473 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 471 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 474 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 475 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 479 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 477 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 476 87-010-236-080 CAP,E 1000-10 SME A...................
C 478 87-010-263-080 CAP, ELECT 100-10V A...................
C 489 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 480 87-010-221-080 CAP, ELECT 470-10V A...................
C 482 87-010-405-080 CAP, ELECT 10-50V A...................
C 481 87-010-405-080 CAP, ELECT 10-50V A...................
C 483 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 484 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 490 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 498 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 496 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 499 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 493 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 495 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 497 87-010-322-080 C-CAP,S 100P-50 CH A...................
CN 403 87-099-195-010 CONN,7P 6216 V A...................
CN 401 87-A60-424-010 CONN,16P V TOC-B A...................
D 401 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 402 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 403 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 494 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 491 87-020-465-080 DIODE,1SS133 (110MA) A...................
IC 401 87-A20-446-010 C-IC,LA9241ML A...................
IC 402 87-A20-459-010 C-IC,LC78622ED A...................
IC 404 87-A21-093-010 IC,LA6541D A...................
L 401 87-003-102-080 COIL, 10UH A...................
L 406 87-005-847-080 COIL,2.2UH(CECS) A...................
L 402 87-005-847-080 COIL,2.2UH(CECS) A...................
L 405 87-008-372-010 FILTER, EMI BL OIRNI A...................
L 404 87-008-372-010 FILTER, EMI BL OIRNI A...................
L 403 87-008-372-010 FILTER, EMI BL OIRNI A...................
Q 403 87-026-502-080 DTC144TS A...................
Q 402 89-113-184-080 TR,2SA1318T A...................
SFR 401 87-024-175-080 SEMI-FIXED RESISTOR, 47K ....................
SFR 401 87-024-176-080 SEMI-FIXED RESISTOR, 100K A...................
X 401 81-592-641-010 VIB,CER 16.93MHZ A...................
X 401 87-A70-046-010 VIB,XTAL 16.934MHZ A...................
C 491 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 492 87-010-221-080 CAP, ELECT 470-10V A...................
D 491 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 494 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 492 87-020-465-080 DIODE,1SS133 (110MA) A...................
Q 401 87-026-463-080 TR,2SA933S (0.3W) A...................
Q 492 87-026-291-080 TR,DTC124XS A...................
Q 491 89-112-965-080 TR,2SA1296 (0.75W) A...................
C 5 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................
C 6 87-010-311-080 CAP 12P ....................
C 6 87-010-313-080 CAP, CHIP 18P ....................
C 1 87-010-314-080 C-CAP,S 22P-50V ....................
C 3 87-010-314-080 C-CAP,S 22P-50V ....................
ELECTRICAL MAIN PARTS LIST - 5/7
C 2 87-010-316-080 C-CAP,S 33P-50 CH ....................
C 7 87-012-158-080 C-CAP,S 390P-50 CH ....................
C 8 87-012-349-080 C-CAP,S 1000P-50 CH ....................
C 7 87-014-051-080 CAPACITOR (PP), 560P ....................
C 19 87-010-112-080 CAP, ELECT 100-16V ....................
C 13 87-010-145-080 C-CAP,S 1P-50 CH ....................
C 17 87-010-194-080 CAP, CHIP 0.047 ....................
C 12 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 11 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 10 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 14 87-010-305-080 C-CAP 470P-50CH ....................
C 16 87-010-380-080 CAP, ELECT 47-16V ....................
C 15 87-012-349-080 C-CAP,S 1000P-50 CH ....................
C 18 87-015-819-080 CAPACITOR,0.01 ....................
C 23 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 26 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 22 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 21 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 20 87-010-404-080 CAP, ELECT 4.7-50V ....................
C 24 87-015-629-080 CHIP CAPACITOR, 0.0022 ....................
C 25 87-016-460-080 C-CAP,S 0.22-16 B ....................
C 28 87-016-669-080 C-CAP,S 0.1-25 K B ....................
C 29 87-016-669-080 C-CAP,S 0.1-25 K B ....................
C 27 87-A11-067-080 C-CAP,S 1-10 K B ....................
C 36 87-010-112-080 CAP, ELECT 100-16V ....................
C 37 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 31 87-010-198-080 CAP, CHIP 0.022 ....................
C 30 87-010-198-080 CAP, CHIP 0.022 ....................
C 30 87-010-213-080 C-CAP,S 0.015-50 B ....................
C 31 87-010-213-080 C-CAP,S 0.015-50 B ....................
C 38 87-010-380-080 CAP, ELECT 47-16V ....................
C 34 87-010-401-080 CAP, ELECT 1-50V ....................
C 33 87-010-401-080 CAP, ELECT 1-50V ....................
C 39 87-010-404-080 CAP, ELECT 4.7-50V ....................
C 35 87-015-819-080 CAPACITOR,0.01 ....................
C 46 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 40 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 47 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 48 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 44 87-010-311-080 CAP 12P ....................
C 45 87-010-312-080 C-CAP,S 15P-50 CH ....................
C 43 87-012-349-080 C-CAP,S 1000P-50 CH ....................
C 41 87-012-349-080 C-CAP,S 1000P-50 CH ....................
C 42 87-012-349-080 C-CAP,S 1000P-50 CH ....................
C 53 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 55 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 50 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 52 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 51 87-010-316-080 C-CAP,S 33P-50 CH ....................
C 54 87-014-055-080 CAP,PP 820P-100 J ....................
CF 2 82-785-747-080 CF,MS2 GHY,R ....................
CF 3 82-785-747-080 CF,MS2 GHY,R ....................
CF 1 87-A91-094-010 FLTR,CDA10.7 MG80A ....................
D 6 87-017-072-080 ZENER,HZS3B1 ....................
D 2 87-070-345-080 DIODE,IN4148 ....................
D 1 87-070-345-080 DIODE,IN4148 ....................
HD 2 88-CD6-661-010 HLDR,BAR ANT. ....................
HD 1 88-CD6-661-010 HLDR,BAR ANT. ....................
IC 1 87-A21-184-010 IC,TA2104AN ....................
IC 2 87-A21-185-040 C-IC,LC72121M ....................
L 8 87-005-849-080 COIL,10UH(CECS) ....................
L 9 87-005-849-080 COIL,10UH(CECS) ....................
L 2 87-A50-347-010 COIL,FM BPF EX ....................
L 4 87-A50-420-010 COIL,MW OSC(SYN) ....................
L 5 87-A50-424-010 COIL,FM RF EX(SYN) ....................
L 6 87-A50-427-010 COIL,FM OSC EX(SYN) ....................
L 6 87-A50-454-010 COIL,FM OSC U(SYN) ....................
L 3 87-A91-095-010 BAR-ANT,MW FOR 2B(SYN) ....................
L 3 87-A91-096-010 BAR-ANT,MW/LW FOR 3B(SYN) ....................
L 7 87-A91-308-010 FLTR,PCFAZH- 450T (TOK) ....................
L 2 88-CD6-655-010 COIL,FM5MM*3.5T ....................
L 51 87-A50-421-010 COIL,LW OSC(SYN) ....................
Q 1 89-319-233-080 TR,2SC1923 (0.1W) ....................
Q 54 87-026-214-080 TR,DTA114YS (0.3W) ....................
Q 52 87-026-447-080 TR,2SC1740S R ....................
Q 51 87-A30-092-080 FET,2SK439E/F ....................
Q 53 89-320-011-080 TR,2SC2001 (15W) ....................
SCR 5 87-A40-615-070 VARI-CAP,KV1311NT ....................
SCR 4 87-A40-615-070 VARI-CAP,KV1311NT ....................
SCR 3 87-A40-616-070 VARI-CAP,SVC384(S/T) ....................
TC 1 87-011-220-080 TRIMMER CAP 20P VTC ....................
TC 51 87-011-233-080 TRIMER,50P VCT54 ....................
X 1 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 ....................
C 7 87-012-140-080 CAP 470P A...................
C 8 87-018-059-080 CAP TC-S 22P-50CH A...................
C 4 87-018-131-080 CAP, CER 1000P-50V A...................
C 2 87-018-134-080 CAPACITOR,TC-U 0.01-16 A...................
C 5 87-018-144-080 CAP,TC-U 5.6P-50 CH A...................
C 1 87-018-145-080 CAP,TC-U 6.8P-50 CH A...................
C 6 87-018-145-080 CAP,TC-U 6.8P-50 CH A...................
C 9 87-018-148-080 CAP,TC-U 12P-50 CH A...................
C 3 87-018-149-080 CAP,TC-U 15P-50 CH A...................
C 18 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 15 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 17 87-010-311-080 CAP 12P A...................
C 11 87-018-059-080 CAP TC-S 22P-50CH A...................
C 13 87-018-119-080 CAP, CER 100P-50V A...................
C 14 87-018-134-080 CAPACITOR,TC-U 0.01-16 A...................
C 12 87-018-141-080 CAP, CERA-SOL SS 3.3P CH A...................
C 10 87-A10-142-010 CAP,CER 33P-50 K CH A...................
C 20 87-018-134-080 CAPACITOR,TC-U 0.01-16 A...................
C 87 87-010-317-080 C-CAP,S 39P-50 CH A...................
C 82 87-010-401-080 CAP, ELECT 1-50V A...................
C 85 87-018-130-080 CAP,TC-U 820P-50 B A...................
CF 1 82-785-747-080 CF,MS2 GHY,R A...................
D 4 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 3 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 1 87-A40-226-080 VARI-CAP,SVC251SPA A...................
D 2 87-A40-226-080 VARI-CAP,SVC251SPA A...................
D 5 87-A40-456-080 VARI-CAP,KV1590NT A...................
IFT 6 86-ZA1-604-010 IFT,FM IFT 7-6.2 A...................
L 5 87-005-847-080 COIL,2.2UH(CECS) A...................
L 2 87-006-244-010 COIL,RF FM 3-1/2T,L4 A...................
L 3 87-006-246-010 COIL,RF FM 3-1/2T,L4 A...................
L 1 87-A50-110-010 COIL,FM BPF EX A...................
L 8 87-CHH-602-010 COIL,BAR-ANT,EZ A...................
L 4 8Z-CH4-699-010 COIL,FM OSC(EZ) A...................
L 11 87-A50-198-010 COIL,OSC LW(CEC) 856KHZ A...................
L 10 87-CHH-608-010 COIL,OSC MW U(COI) A...................
Q 4 87-026-214-080 TR,DTA114YS (0.3W) A...................
Q 6 87-026-462-080 TR,2SC1740 S(RS 0.3W) A...................
Q 1 87-A30-092-080 FET,2SK439E/F A...................
Q 7 87-A30-092-080 FET,2SK439E/F A...................
Q 2 89-305-352-380 TR,2SC535(B/C) A...................
Q 3 89-319-233-080 TR,2SC1923 (0.1W) A...................
Q 9 89-320-011-080 TR,2SC2001 (15W) A...................
Q 12 87-026-269-080 TR,DTA114ES A...................
TC 2 87-011-220-080 TRIMMER CAP 20P VTC A...................
TC 1 87-011-233-080 TRIMER,50P VCT54 A...................
C 26 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 22 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 21 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 29 87-010-263-080 CAP, ELECT 100-10V A...................
C 27 87-010-405-080 CAP, ELECT 10-50V A...................
C 28 87-015-835-080 C-CAP,0.047 D A...................
C 36 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 37 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 30 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 33 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 34 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 36 87-010-401-080 CAP, ELECT 1-50V A...................
C 35 87-010-401-080 CAP, ELECT 1-50V A...................
C 32 87-010-405-080 CAP, ELECT 10-50V A...................
C 38 87-010-405-080 CAP, ELECT 10-50V A...................
C 31 87-015-835-080 C-CAP,0.047 D A...................
C 44 87-010-308-080 C-CAP,820P-50 J CH A...................
C 46 87-010-384-080 CAP, ELECT 100-25V A...................
C 48 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 42 87-010-546-080 CAP, ELECT 0.33-50V A...................
C 43 87-010-546-080 CAP, ELECT 0.33-50V A...................
C 40 87-015-835-080 C-CAP,0.047 D A...................
C 41 87-015-835-080 C-CAP,0.047 D A...................
C 45 87-016-248-080 C-CAP,8200P-50 B A...................
C 47 87-018-208-080 CAP 0.047-50F A...................
C 80 87-010-401-080 CAP, ELECT 1-50V A...................
C 96 87-010-322-080 C-CAP,S 100P-50 CH A...................
CN 1 87-099-198-010 CONN,10P 6216 V A...................
D 7 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 6 87-020-465-080 DIODE,1SS133 (110MA) A...................
IC 1 86-NFZ-654-010 IC,LA1836(Z) A...................
L 15 87-A50-015-010 COIL,FM DET(TOK) A...................
L 14 87-A90-245-010 FLTR,CFAZH-450 (TOK) A...................
L 21 87-A50-063-080 COIL,0.47UH (CECS) A...................
L 20 87-A50-079-080 COIL,22UH (CECS) A...................
Q 22 89-318-155-080 TR,2SC1815 (0.4W) A...................
SFR 2 87-024-432-080 SFR,4.7K RH063EC A...................
X 1 87-A70-044-010 VIB, CER CMU2-456A15 A...................
C 49 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 58 87-010-112-080 CAP, ELECT 100-16V A...................
C 55 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 54 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 56 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 50 87-010-311-080 CAP 12P A...................
C 57 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 52 87-012-349-080 C-CAP,S 1000P-50 CH A...................
C 51 87-012-349-080 C-CAP,S 1000P-50 CH A...................
C 53 87-018-131-080 CAP, CER 1000P-50V A...................
C 61 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 62 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 60 87-010-248-080 CAP, ELECT 220-10V A...................
C 97 87-010-197-080 CAP, CHIP 0.01 DM A...................
D 9 87-A40-234-080 ZENER,MTZJ5.6A A...................
IC 2 87-070-127-110 IC,LC72131 D A...................
X 2 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 A...................
ELECTRICAL MAIN PARTS LIST - 6/7
S 607 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 604 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 605 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 608 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 609 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 606 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 612 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 610 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 613 87-A90-164-080 SW,TACT SKQAB(N) A...................
S 611 87-A90-164-080 SW,TACT SKQAB(N) A...................
C 69 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 68 87-010-405-080 CAP, ELECT 10-50V A...................
C 67 87-012-140-080 CAP 470P A...................
C 65 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 66 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 70 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 72 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 74 87-010-314-080 C-CAP,S 22P-50V A...................
C 73 87-010-316-080 C-CAP,S 33P-50 CH A...................
C 75 87-010-405-080 CAP, ELECT 10-50V A...................
C 71 87-010-405-080 CAP, ELECT 10-50V A...................
C 76 87-012-349-080 C-CAP,S 1000P-50 CH A...................
D 10 87-020-465-080 DIODE,1SS133 (110MA) A...................
IC 3 87-A20-440-080 C-IC,BU1920FS A...................
L 22 87-005-847-080 COIL,2.2UH(CECS) A...................
Q 21 87-026-215-080 TR,DTC114YS A...................
Q 23 87-026-610-080 TR,KTC3198GR A...................
X 3 87-A70-184-080 VIB,XTAL 4.332MHZ HC-49/U A...................
ELECTRICAL MAIN PARTS LIST - 7/7
MECHANICAL PARTS LIST - 1/2
NOTE: The characters in the suffix column indicate the part usage.
EZ .....................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
87-B00-020-010 BADGE,AIWA 30 GOLD A...................
88-CH6-019-010 PANEL,CD A...................
8Z-CH4-002-110 CABI,REAR ....................
8Z-CH4-003-010 CHAS,CD ....................
8Z-CH4-004-110 BOX,CD ....................
8Z-CH4-005-010 WINDOW,CD A...................
8Z-CH4-007-010 WINDOW,CASS A...................
8Z-CH4-008-010 LID,BATT ....................
8Z-CH4-009-010 HANDL,ARM ....................
8Z-CH4-010-010 HANDL,GRIP ....................
8Z-CH4-011-010 GRILLE,FR L ....................
8Z-CH4-012-010 GRILLE,FR R ....................
8Z-CH4-013-010 PANEL,LCD21 ....................
8Z-CH4-015-010 WINDOW,LCD ....................
8Z-CH4-016-010 WINDOW,LED ....................
8Z-CH4-030-110 COVER, PH ....................
8Z-CH4-064-010 WINDOW,LCD EZ ....................
8Z-CH6-001-010 CABI,TOP 3L ....................
8Z-CH6-002-010 CABI,TOP 3R ....................
8Z-CH6-003-010 PANEL,RDS21 A...................
8Z-CH6-005-010 WINDOW,RDS A...................
8Z-CH6-010-010 BOX,CASS 6 ....................
8Z-CH6-012-010 CABI,FR X ....................
8Z-CH6-017-010 GRILLE,FR L 6 ....................
8Z-CH6-018-010 GRILLE,FR R 6 ....................
8Z-CH6-019-010 WINDOW,LED 6A ....................
8Z-CH6-020-010 CABI,FR XA A...................
8Z-CH6-021-010 CABI,REAR A A...................
8Z-CH6-022-010 BOX,CASS 6A A...................
8Z-CH6-025-010 WINDOW,LED 6B A...................
8Z-CH6-026-010 CABI,TOP 3L C A...................
8Z-CH6-027-010 CABI,TOP 3R C A...................
8Z-CH6-028-010 HANDL,ARM B A...................
8Z-CH6-029-010 HANDL,GRIP B A...................
8Z-CH6-030-010 CHAS,CD A A...................
8Z-CHE-026-010 COVER, PH A A...................
8Z-CHE-027-010 LID,BATT A A...................
8Z-CHG-005-010 BOX,CD 16 A...................
8Z-CHR-013-010 GRILLE,FR L 24 A...................
8Z-CHR-014-010 GRILLE,FR R 24 A...................
8Z-CHT-015-010 BOX CASS ....................
8Z-CH4-023-110 BTN,VOL ....................
8Z-CH4-024-010 BTN,CD ....................
8Z-CH4-025-010 BTN,REPEAT ....................
8Z-CH4-026-010 BTN,FUNC A...................
8Z-CH4-027-010 BTN,EQ A...................
8Z-CH4-028-010 KEY,CASS 21 A...................
8Z-CH6-006-010 BTN,VOL RDS A...................
8Z-CH6-007-010 BTN,CD RDS A...................
87-CD6-041-010 PLATE,AC A...................
84-CD5-215-010 GEAR A...................
84-CD5-216-010 BRACKET A...................
84-CD5-217-010 PLATE,MAGNET A...................
85-CD7-217-010 HLDR,CHUCK A A...................
86-CT4-218-010 CUSHION,FOOT/PORON A...................
87-036-368-010 MAGNET A...................
87-A91-151-010 SW,LEAF 1P2T/TC48-021 A...................
87-CD6-213-010 SPR-C,BATT (-) A...................
87-CD6-214-010 SPR-C,BATT LINK A...................
87-CD6-222-010 SPR-C,BATT (-) L A...................
87-CD6-223-010 SPR-C,BATT LINK L A...................
88-CH6-207-010 HLDR,ANT A...................
88-CH6-220-010 CUSHION,CD A A...................
8Z-CH4-201-010 HLDR,LCD ....................
8Z-CH4-205-010 SPR-T,CASS A...................
8Z-CH4-206-010 SPR-T,CD A...................
8Z-CH4-208-010 HLDR,PWB A...................
8Z-CH4-209-010 HLDR,PT A...................
8Z-CH4-210-010 HLDR,LED A...................
8Z-CH4-211-010 BASE,CHUCK A...................
8Z-CH4-212-010 RING,CHUCK A...................
8Z-CH4-214-010 HLDR,REC-SW 21 A...................
8Z-CH4-216-010 HLDR,FUNC-PWB ....................
8Z-CH4-223-010 HLDR,SPEAKER T1.0 A...................
8Z-CH4-224-010 HLDR,OIL-DMPR SECC A...................
8Z-CH6-201-010 HLDR,LCD RDS A...................
8Z-CH6-202-010 HLDR,FUNC-PWB RDS A...................
87-067-566-010 TAPPING SCREW, VFTT+3-6 A...................
87-254-097-410 U+3-12 CR A...................
87-261-037-410 V+2-10 GLD A...................
87-342-074-010 UT2+2.6-8 A...................
87-571-032-410 VIT+2-3 A...................
87-644-096-410 UT1+3-10 CR A...................
87-661-100-410 VFT1+3-16 A...................
87-741-095-410 UT2+3-8 GLD A...................
87-751-094-410 VT2+3-6 W10SL0T A...................
* 87-751-075-410 VT2+2.6-10 A...................
* 87-B10-239-010 QT2+3-8 W/O CR A...................
* 87-B10-242-010 UT2+3-30 W/O CR A...................
87-036-389-010 SW,PUSH LOCK A...................
87-A60-177-010 JACK,AC U W/SW ....................
87-A60-178-010 JACK,AC E W/SW A...................
87-A90-092-080 PROTECTOR,2.5A 491 A...................
88-CH6-626-010 PT,U ....................
88-CH6-627-010 PT,E A...................
8Z-CH4-610-010 CONN ASSY,4P RPH A...................
8Z-CH4-611-010 CONN ASSY,4P TA-ME1WAY A...................
8Z-CH4-614-010 CONN ASSY,6P CD-ME A...................
8Z-CH4-615-010 CONN ASSY,4P M-SP A...................
8Z-CH4-617-010 CONN ASSY,2P DOOR A...................
8Z-CH4-618-010 FF-CABLE, 16P CD-RF A...................
8Z-CH4-620-010 FF-CABLE, 7P FR-LED A...................
8Z-CH4-621-010 FF-CABLE, 7P CD-FR ....................
8Z-CH4-640-010 ANT,ROD A...................
8Z-CH4-695-010 FF-CABLE, 10P TU-FR A...................
8Z-CH4-696-010 FF-CABLE, 7P CD-FR A...................
CN 606 8Z-CH4-624-010 CONN ASSY,2P KEY A...................
CN 901 8Z-CH4-613-010 CONN ASSY,3P PWR A...................
CNA 0 8Z-CH4-623-010 CONN ASSY,2P R/P SW A...................
SP 0 88-CD5-603-010 SPKR,10 7OHM A...................
W 0 8Z-CH4-619-010 FF-CABLE, 14P AF-FR A...................
W 0 8Z-CH4-622-010 FF-CABLE, 6P TU-FR ....................
8Z-CH4-694-010 LCD,AIW4124-32P3S A...................
MECHANICAL PARTS LIST - 2/2
ACCESSORIES / PACKAGE LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage.
EZ .....................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-CH6-905-010 IB,U(ESF)B ....................
8Z-CH6-908-010 IB,EZ(9L)B ....................
8Z-CH6-909-010 IB,K(E)B ....................
8Z-CH6-915-010 IB,U(ESF)FM ....................
8Z-CH6-918-010 IB,EZ(9L)FM ....................
8Z-CH6-919-010 IB,K(E)FM ....................
8Z-CH6-928-010 IB,EZ(9L)B -RDS A...................
87-A80-034-010 AC CORD SET ASSY,K W/F MAY-BG ....................
87-A80-036-010 AC CORD SET ASSY,E W/FLTR VOL A...................
87-A80-109-010 AC CORD,HK7281 BLK U ....................
SCHEMATIC DIAGRAM _1 (MAIN)
SCHEMATIC DIAGRAM _2 (CD)
SCHEMATIC DIAGRAM _3 (FRONT)
SCHEMATIC DIAGRAM _4 (TUNER)
PrintedinSingapore
Tokyo Japan
4
9420208
Table of contents
Other Aiwa CD Player manuals
Aiwa
Aiwa XP-V50 User manual
Aiwa
Aiwa XP-SR320 User manual
Aiwa
Aiwa XP-770 User manual
Aiwa
Aiwa CSD-TD21 User manual
Aiwa
Aiwa CSD-EX111U CSD-EX110U, CSD-EX1 User manual
Aiwa
Aiwa NSX-SZ500 User manual
Aiwa
Aiwa ADC-EX108 User manual
Aiwa
Aiwa XP-V713 User manual
Aiwa
Aiwa Z-A65 User manual
Aiwa
Aiwa XP-V311 User manual
