SERVICE MANUAL
DATA
COMPACT DISC STEREO
SYSTEM
Z-A65
S/M Code No. 09-023-453-5R1
REVISION
LH(S)
BASIC TAPE MECHANISM : ZZM-3 YPR1NC
BASIC CD MECHANISM : BZG-5 ZD4GN1C
• This Service Manual is the “Revision Publishing” and replaces “Simple Manual”
Z-A65 (LH), (S/M Code No. 09-021-453-5T1).
• If requiring information about the CD mechanism, see Service Manual of BZG-5,
(S/M Code No. 09-023-353-3NA).
CX-ZA65
Z-A65 RC–ZAS02
SYSTEM CD
CASSEIVER
REMOTE
CONTROLLER
SPEAKER
SX-WZA65

– 2 –
SPECIFICATIONS ..............................................................................................................................................................3
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING ......................................................................4
NOTE ON BEFORE STARTING REPAIR ....................................................................................................................5 ~ 6
ELECTRICAL PARTS LIST (CX – ZA65) .................................................................................................................7 ~ 21
ELECTRICAL PARTS LIST (ZZM – 3) ........................................................................................................................... 22
CHIP RESISTOR PART CODE ......................................................................................................................................23
TRANSISTOR ILLUSTRATION ........................................................................................................................................ 23
WIRING – 1 (MAIN) .......................................................................................................................................................... 24
SCHEMATIC DIAGRAM – 1 (MAIN 1 / 2 : AMP SECTION) ........................................................................................... 25
SCHEMATIC DIAGRAM – 2 (MAIN 2 / 2 : TUNER SECTION) ..................................................................................... 26
WIRING – 2 (FRONT) ...................................................................................................................................................... 27
SCHEMATIC DIAGRAM – 3 (FRONT / KEY CD / DECK) .............................................................................................. 28
WIRING – 3 (KEY CD / FAN) ........................................................................................................................................... 29
SCHEMATIC DIAGRAM – 4 (FAN) ................................................................................................................................. 30
WIRING – 4 (PT) ..............................................................................................................................................................31
SCHEMATIC DIAGRAM – 5 (PT) .................................................................................................................................... 32
WIRING – 5 (DECK) ......................................................................................................................................................... 33
IC BLOCK DIAGRAM ..................................................................................................................................................... 34
IC DESCRIPTION .................................................................................................................................................... 35 ~ 36
FL (BJ823GNK) GRID ASSIGNMENT / PIN CONNECTION / ANODE CONNECTION ................................................37
ADJUSTMENT <TUNER / DECK / FRONT>............................................................................................................ 38 ~ 44
CD TEST MODE ............................................................................................................................................................. 45
MECHANICAL EXPLODED VIEW ................................................................................................................................. 46
MECHANICAL PARTS LIST ...................................................................................................................................47 ~ 48
COLOR NAME TABLE ................................................................................................................................................... 49
TAPE MECHANISM EXPLODED VIEW ....................................................................................................................... 50
TAPE MECHANISM PARTS LIST ..........................................................................................................................51 ~ 52
GENERAL SPEAKER DISASSEMBLY INSTRUCTIONS (FOR REFERENCE) ..........................................................53
SPEAKER PARTS LIST (SX – WZA65) ......................................................................................................................... 54
ACCESSORIES PARTS LIST ......................................................................................................................................... 55
OTHERS PARTS LIST (CX – ZA65) .............................................................................................................................. 56
OTHERS PARTS LIST (ZZM – 3) .................................................................................................................................. 57
TABLE OF CONTENTS

– 3 –
SPECIFICATIONS
<FM tuner section>
Tuning range 87.5 MHz to 108 MHz
Usable sensitivity (IHF) 13.2 dBf
Antenna terminals 75 ohms (unbalanced)
<AM tuner section>
Tuning range 530 kHz to 1710 kHz (10 kHz step)
531 kHz to 1602 kHz (9 kHz step)
Usable sensitivity 350 µV/m
Antenna Loop antenna
<Amplifier section>
Power output Rated: 100 W + 100 W (6 ohms,
T.H.D. 1 %, 1 kHz)
Reference: 120 W + 120 W (6 ohms,
T.H.D. 10 %, 1 kHz)
Total harmonic distortion 0.1% (50 W, 1 kHz, 6 ohms, DIN
AUDIO)
Inputs VIDEO/AUX/PHONO : 500 mV
Outputs SPEAKERS:
accept speakers of 6 ohms or more
PHONES (stereo jack):
accepts headphones of 32 ohms or
more
<Cassette deck section>
Track format 4 tracks, 2 channels stereo
Frequency response 50 Hz – 12500 Hz
Recording system AC bias
Heads Deck 1 : Playback head x 1
Deck 2 : Recording/playback head
x 1, erase head x 1
<Compact disc player section>
Laser Semiconductor laser (l =780 nm)
D-A converter 1 bit dual
Signal-to-noise ratio 85 dB (1 kHz, 0 dB)
Harmonic distortion 0.05 % (1 kHz, 0 dB)
Wow and flutter Unmeasurable
<Speaker system SX–WZA65>
Cabinet type 3 way, built-in subwoofer
Speakers Subwoofer:
220 mm cone type
Full range:
140 mm cone type
Super tweeter:
20 mm ceramic type
Impedance 6 ohms
Output sound pressure level
89 dB/W/m
Dimensions (W xH xD) 275 x 495 x 297 mm
Weight 8.2 kg
<General>
Power requirements 120 V/220 - 230 V/240 V AC,
switchable: 50/60 Hz
Power consumption 130 W
Dimensions of main unit 360 x 395.3 x 360.6 mm
(W xH xD)
Weight of main unit 10 kg
• Design and specifications are subject to change without notice.

– 4 –
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
This set employs laser. Therefore, be sure to follow carefully
the instructions below when servicing.
WARNING!!
WHEN SERVICING, DO NOT APPROACH THE LASER
EXIT WITH THE EYE TOO CLOSELY. IN CASE IT IS
NECESSARY TO CONFIRM LASER BEAM EMISSION.
BESURETO OBSERVEFROMA DISTANCEOFMORE
THAN 30cm FROM THE SURFACE OF THE OBJEC-
TIVE LENS ON THE OPTICAL PICK-UP BLOCK.
sCaution: Invisible laser radiation when
open and interlocks defeated avoid
exposure to beam.
sAdvarsel: Usynliglaserstålingvedåbning,
nårsikkerhedsafbrydereerudeaffunktion.
Undgå udsættelse for stråling.
VAROITUS!
Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa
mainitulla tavalla saataa altistaa käyt-täjän
turvallisuusluokan 1 ylittävälle näkymättömälle
lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än vad som
specificeras i denna bruksanvising, kan användaren
utsättas för osynling laserstrålning, som överskrider
gränsen för laserklass 1.
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
CAUTION
Use of controls or adjustments or performance of proce-
dures other than those specified herin may result in
hazardous radiation exposure.
ATTENTION
L’utillisation de commandes, réglages ou procédures
autresqueceuxspécifiéspeutentraînerunedangereuse
exposition aux radiations.
ADVARSEL
Usynliglaserstålingvedåbning,nårsikkerhedsafbrydereer
ude af funktion. Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1
LASER product.
The CLASS 1 LASER PRODUCT label is located on the
rear exterior.
Precaution to replace Optical block
(KSS-213F)
Body or clothes electrostatic potential could
ruin laser diode in the optical block. Be sure
ground body and workbench, and use care the
clothes do not touch the diode.
1) After the connection, remove solder shown in
right figure.
PICK-UP Assy PWB
Solder

– 5 –
NOTE ON BEFORE STARTING REPAIR
Charging voltage (V) Discharging Rated power (W) Parts number
(C101, 102) resistor (Ω)
25-48 100 3 87-A00-247-090
49-140 220 5 87-A00-232-090
Note: The reference numbers (C101, C102) of the electrolytic capacitors can change depending on the models. Be sure to check the
reference numbers of the charging capacitors on schematic diagram before starting the discharging work.
2. Check items before exchanging the MICROCOMPUTER
Be sure to check the following items before exchanging the MICROCOMPUTER. Exchange the MICROCOMPUTER after confirming
that the MICROCOMPUTER is surely defective.
2-1. Regarding the HOLD terminal of the MICROCOMPUTER
Whenthe HOLD terminal(INPUT)of the MICROCOMPUTERis“H”, the MICROCOMPUTER isjudged to be operatingcorrectly.
When this terminal is “L”, the main power cannot be turned on. Therefore, be sure to check the terminal voltage of the HOLD
terminal before exchange.
When the MICROCOMPUTER is not defective, the HOLD terminal can also go “L” when the POWER AMPLIFIER has any
abnormalities that triggers the abnormality detection circuit on the MAIN C. B. that sets the HOLD terminal to “L”.
• Good or no good judgement of the MICROCOMPUTER
11
11
1Turn on the AC main power.
22
22
2Confirm that the main power is turned on and the HOLD terminal of the MICROCOMPUTER keeps the “H” level or not.
33
33
3When the HOLD terminal is “L” level, the abnormality detection circuit is judged to be working correctly and the
MICROCOMPUTER is judged to be good.
1. Forced discharge of electrolytic capacitor of power supply block
When repair is going to be attempted in the set that uses relay circuit in the power supply block, electric potential is kept charged across
the electrolytic capacitors (C101, 102) even though AC power cord is removed. If repair is attempted in this condition, secondary defect
can occur.
In order to prevent the secondary trouble, perform the following measures before starting repair work.
Discharge procedure
11
11
1Remove the AC power cord.
22
22
2Connect a discharging resistor at an end of lead wire that
has clips at both ends. Connect the other end of the lead
wire to metal chassis.
33
33
3Contact the other end of the discharging resistor to the
positive (+) side (+VH) of C101. (For two seconds)
44
44
4Contact the same end of the discharging resistor as step
33
33
3to the negative (-) side (-VH) of C102 in the same way.
(For two seconds)
55
55
5Check that voltage across C101 and C102 has decreased
to 1 V or less using a multimeter or an oscilloscope.
Select a discharging resistor referring to the following table.
Fig-1
MAIN C.B
D101
C101 C102
22
34

– 6 –
In such a case, check also if the POWER AMPLIFIER circuit or power supply circuit has any abnormalities or not.
2-2. Regarding reset
There are cases that the machine does not work correctly because the MICROCOMPUTER is not reset even though the AC power
cord is re-inserted, or the software reset (pressing the STOP key + POWER key) is performed.
When the above described phenomenon occurs, it can lead to wrong judgement as if the MICROCOMPUTER is defective and to
exchange the MICROCOMPUTER. In such a case, perform the forced-reset by the following procedure and check good or no
good of the MICROCOMPUTER.
11
11
1Remove the AC power cord.
22
22
2Short both ends of the electrolytic capacitor C113 that is connected to VDD of the MICROCOMPUTER with tweezers.
33
33
3Connect the AC power cord again. If the MICROCOMPUTER returns to the normal operation, the MICROCOMPUTER is
good.
Note: Thereference number orMICROCOMPUTER pin number oftransistor (Q110) andelectrolyticcapacitor (C113) canchange depending
on the models. Be sure to check the reference numbers on schematic diagram before starting the discharging work.
2-3. Confirmation of soldering state of MICROCOMPUTER
Check the soldering state of the MICROCOMPUTER in addition to the above described procedures. Be sure to exchange the
MICROCOMPUTER after surely confirming that the trouble is not caused by poor soldering but the MICROCOMPUTER itself.
Fig-2-2
MICRO-
COMPUTER
MICROCOMPUTER
FRONT C.B
FRONT C.B
VSS
VDD
C113 *
%
C113
18
15
Short with tweezers.

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 7 –
ELECTRICAL PARTS LIST (CX – ZA65)
CX-ZA65
LHSC
FAN O C 0501 87-010-401-080 CAP,E 1-50 M 11L SME a
FAN O C 0502 87-010-374-080 CAP,E 47-10 M 11L SME a
FAN O C 0503 87-010-380-080 CAP,E 47-16 M 11L SME a
FAN O CN 0502 87-A60-688-010 CONN,4P H GRY TUC-P04X-C1 a
FAN O CN 0503 87-A60-619-010 CONN,2P V 2MM JMT a
FAN S Q 0501 87-A30-076-080 C-TR,2SC3052F a
FAN S Q 0503 87-A30-218-080 TR,2SB1237Q a
FAN X R 0501 88-108-473-080 C-RES,U 47K-1/16W J a
FAN X R 0502 88-108-474-080 C-RES,U 470K-1/16W J a
FAN X R 0503 88-108-122-080 C-RES,U 1.2K-1/16W J a
FAN X R 0504 88-108-102-080 C-RES,U 1K-1/16W J a
FAN X R 0505 88-108-102-080 C-RES,U 1K-1/16W J a
FAN X R 0506 88-108-103-080 C-RES,U 10K-1/16W J a
FAN X R 0507 88-108-000-080 C-JUMPER,U a
FRONT O C 0100 87-A10-047-080 C-CAP,U 1-10 Z F a
FRONT O C 0102 87-010-498-040 CAP,E 10-16 M 5L SRE a
FRONT O C 0106 87-010-248-040 CAP,E 220-10 M 11L SME a
FRONT O C 0107 87-010-759-080 C-CAP,U 0.1-25 Z F a
FRONT O C 0108 87-012-278-080 C-CAP,U 2200P-50 K B a
FRONT O C 0110 87-010-248-040 CAP,E 220-10 M 11L SME a
CX-ZA65
LHSC
FRONT O C 0111 87-A10-260-080 C-CAP,U 0.1-16 K B a
FRONT O C 0112 87-010-493-040 CAP,E 0.47-50 M 5L SRE a
FRONT O C 0113 87-012-274-080 C-CAP,U 1000P-50 K B a
FRONT O C 0114 87-010-831-080 C-CAP,U 0.1-16 Z F a
FRONT O C 0116 87-010-759-080 C-CAP,U 0.1-25 Z F a
FRONT O C 0117 87-010-872-080 C-CAP,U 470P-50 SL a
FRONT O C 0122 87-012-369-080 C-CAP,S 0.047-50 Z F a
FRONT O C 0123 87-010-408-040 CAP,E 47-50 M 11L SME a
FRONT O C 0124 87-010-421-040 CAP,E 4.7-50 M 5L SRE a
FRONT O C 0125 87-010-421-040 CAP,E 4.7-50 M 5L SRE a
FRONT O C 0132 87-012-199-080 C-CAP,U 220P-50 J CH a
FRONT O C 0133 87-012-184-080 C-CAP,U 33P-50 J CH a
FRONT O C 0135 87-A11-148-080 CAP,TC U 0.1-50 Z F a
FRONT O C 0137 87-012-178-080 C-CAP,U 18P-50 J CH a
FRONT O C 0138 87-010-759-080 C-CAP,U 0.1-25 Z F a
FRONT O C 0251 87-010-759-080 C-CAP,U 0.1-25 Z F a
FRONT O C 0252 87-012-199-080 C-CAP,U 220P-50 J CH a
FRONT O C 0253 87-012-195-080 C-CAP,U 100P-50 J CH a
FRONT O C 0301 87-012-358-080 C-CAP,S 0.47-10 Z F CM/CB a
FRONT O C 0302 87-012-335-080 C-CAP,U 270P-50 J SL a
CX-ZA65
LHSC
FRONT O C 0303 87-012-358-080 C-CAP,S 0.47-10 Z F CM/CB a
FRONT O C 0304 87-012-358-080 C-CAP,S 0.47-10 Z F CM/CB a
FRONT O C 0305 87-010-759-080 C-CAP,U 0.1-25 Z F a
FRONT O C 0306 87-010-759-080 C-CAP,U 0.1-25 Z F a
FRONT O C 0310 87-010-759-080 C-CAP,U 0.1-25 Z F a
FRONT O C 0311 87-010-405-040 CAP,E 10-50 M 11L SME a
FRONT O C 0411 87-012-157-080 C-CAP,S 330P-50 J CH GRM a
FRONT O C 0412 87-010-405-040 CAP,E 10-50 M 11L SME a
FRONT O C 0421 87-012-274-080 C-CAP,U 1000P-50 K B a
FRONT O C 0422 87-012-274-080 C-CAP,U 1000P-50 K B a
FRONT O C 0651 87-012-274-080 C-CAP,U 1000P-50 K B a
FRONT O C 0652 87-012-274-080 C-CAP,U 1000P-50 K B a
FRONT O C 0940 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
FRONT O C 0941 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
FRONT O C 0942 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
FRONT O C 0943 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
FRONT O C 0944 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
FRONT O C 0945 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
FRONT O C 0946 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
FRONT O C 0947 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
CX-ZA65
LHSC
FRONT O C 0948 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
FRONT O C 0949 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
FRONT O C 0950 87-012-158-080 C-CAP,S 390P-50 J CH GRM a
FRONT O C 0951 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
FRONT O C 0952 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
FRONT O CN 0101 87-099-720-010 CONN,30P BLK TYK-B(P) a
FRONT O CN 0104 87-A60-136-010 CONN,11P V FE a
FRONT O CN 1000 87-099-196-010 CONN,8P V BLK 6216 a
FRONT O CNA0302 8B-MA5-652-010 CONN ASSY,2P V (100MM) a
FRONT S D 0101 87-A40-234-080 ZENER,MTZJ5.6A a
FRONT S D 0102 87-A40-270-080 C-DIODE,MC2838 a
FRONT S D 0103 87-020-465-080 DIODE,1SS133 a
FRONT S D 0104 87-020-465-080 DIODE,1SS133 a
FRONT S D 0132 87-020-465-080 DIODE,1SS133 a
FRONT S D 0134 87-020-465-080 DIODE,1SS133 a
FRONT X D 0135 88-100-000-010 PLATING-JW, 0.58 SN95 a
FRONT S D 0137 87-020-465-080 DIODE,1SS133 a
FRONT S D 0138 87-020-465-080 DIODE,1SS133 a
FRONT S D 0301 87-020-465-080 DIODE,1SS133 a
FRONT S D 0302 87-020-465-080 DIODE,1SS133 a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 8 –
CX-ZA65
LHSC
FRONT S D 0303 87-020-465-080 DIODE,1SS133 a
FRONT S D 0304 87-020-465-080 DIODE,1SS133 a
FRONT S D 0311 87-A40-234-080 ZENER,MTZJ5.6A a
FRONT S D 0351 87-A40-269-080 C-DIODE,MC2836 a
FRONT S D 0371 87-020-465-080 DIODE,1SS133 a
FRONT S D 0372 87-020-465-080 DIODE,1SS133 a
FRONT S D 0375 87-020-465-080 DIODE,1SS133 a
FRONT S D 0376 87-020-465-080 DIODE,1SS133 a
FRONT S D 0377 87-020-465-080 DIODE,1SS133 a
FRONT S D 0378 87-020-465-080 DIODE,1SS133 a
FRONT S D 0379 87-020-465-080 DIODE,1SS133 a
FRONT S D 0380 87-020-465-080 DIODE,1SS133 a
FRONT S D 0381 87-020-465-080 DIODE,1SS133 a
FRONT S D 0382 87-020-465-080 DIODE,1SS133 a
FRONT S D 0383 87-020-465-080 DIODE,1SS133 a
FRONT S D 0384 87-020-465-080 DIODE,1SS133 a
FRONT S D 0385 87-020-465-080 DIODE,1SS133 a
FRONT S D 0386 87-020-465-080 DIODE,1SS133 a
FRONT S D 0447 87-020-465-080 DIODE,1SS133 a
FRONT S D 0450 87-020-465-080 DIODE,1SS133 a
CX-ZA65
LHSC
FRONT S D 0451 87-020-465-080 DIODE,1SS133 a
FRONT O FFC0104 88-911-151-110 FF-CABLE,11P 1.25 150MM a
FRONT O FFC1000 88-908-271-110 FF-CABLE,8P 1.25 270MM a
FRONT O FL 0101 8B-MA5-671-010 FL,BJ823GNK a
FRONT S IC 0101 8B-MA5-651-010 C-IC,LC876564V-5T64 a
FRONT S IC 0380 87-A21-577-040 C-IC,M61506FP a
FRONT S IC 0412 87-A21-831-010 IC,SPS-442-1-F1 a
FRONT S IC 0662 87-070-289-040 C-IC,BU2092F a
FRONT X JW 0144 88-121-333-080 RES,33K-1/8W J a
FRONT X JW 0153 88-121-471-080 RES,470-1/8W J a
FRONT S JW 0217 87-020-465-080 DIODE,1SS133 a
FRONT O L 0101 87-A50-657-010 COIL,CLK 9.43MHZ (TOKO)7KLY a
FRONT O LED0131 87-A40-317-080 LED,SLR-342VCT31 RED a
FRONT O LED0202 87-A41-056-040 LED,HLMF-D405 ORANGE a
FRONT O LED0205 87-A41-056-040 LED,HLMF-D405 ORANGE a
FRONT O LED0210 87-A41-056-040 LED,HLMF-D405 ORANGE a
FRONT O LED0212 87-A41-056-040 LED,HLMF-D405 ORANGE a
FRONT O LED0682 87-A41-056-040 LED,HLMF-D405 ORANGE a
FRONT O LED0683 87-A41-056-040 LED,HLMF-D405 ORANGE a
FRONT O LED0684 87-A41-056-040 LED,HLMF-D405 ORANGE a
CX-ZA65
LHSC
FRONT O LED0685 87-A41-056-040 LED,HLMF-D405 ORANGE a
FRONT O LED0698 87-A41-056-040 LED,HLMF-D405 ORANGE a
FRONT S Q 0101 87-A30-492-080 TR,2SC5343G a
FRONT S Q 0102 87-A30-538-040 C-TR,SRA2202S a
FRONT S Q 0104 87-A30-492-080 TR,2SC5343G a
FRONT S Q 0105 87-A30-494-080 TR,2SA1980G a
FRONT S Q 0111 87-A30-076-080 C-TR,2SC3052F a
FRONT S Q 0130 87-A30-598-040 C-TR,SRC1202S a
FRONT S Q 0131 87-A30-087-080 C-FET,2SK2158 a
FRONT S Q 0132 87-A30-087-080 C-FET,2SK2158 a
FRONT S Q 0133 87-A30-598-040 C-TR,SRC1202S a
FRONT S Q 0134 87-A30-076-080 C-TR,2SC3052F a
FRONT S Q 0351 89-112-965-080 TR,2SA1296GR a
FRONT S Q 0352 87-A30-495-080 TR,2SA1981Y a
FRONT S Q 0353 87-A30-495-080 TR,2SA1981Y a
FRONT S Q 0441 87-A30-142-040 C-TR,DTA123EKA a
FRONT X R 0074 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0075 88-121-102-080 RES,1K-1/8W J a
FRONT X R 0076 88-121-101-080 RES,100-1/8W J a
FRONT X R 0077 88-121-102-080 RES,1K-1/8W J a
CX-ZA65
LHSC
FRONT X R 0078 88-108-000-080 C-JUMPER,U a
FRONT X R 0079 88-121-101-080 RES,100-1/8W J a
FRONT X R 0080 88-121-101-080 RES,100-1/8W J a
FRONT X R 0081 88-121-102-080 RES,1K-1/8W J a
FRONT X R 0082 88-100-000-010 PLATING-JW, 0.58 SN95 a
FRONT X R 0083 88-121-101-080 RES,100-1/8W J a
FRONT X R 0084 88-108-101-080 C-RES,U 100-1/16W J a
FRONT X R 0085 88-108-101-080 C-RES,U 100-1/16W J a
FRONT X R 0087 88-108-222-080 C-RES,U 2.2K-1/16W J a
FRONT X R 0088 88-108-222-080 C-RES,U 2.2K-1/16W J a
FRONT X R 0090 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0101 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0104 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0105 88-108-222-080 C-RES,U 2.2K-1/16W J a
FRONT X R 0106 88-108-471-080 C-RES,U 470-1/16W J a
FRONT X R 0111 88-108-124-080 C-RES,U 120K-1/16W J a
FRONT X R 0112 88-108-333-080 C-RES,U 33K-1/16W J a
FRONT X R 0113 88-108-153-080 C-RES,U 15K-1/16W J a
FRONT X R 0114 88-121-472-080 RES,4.7K-1/8W J a
FRONT X R 0115 88-108-224-080 C-RES,U 220K-1/16W J a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 9 –
CX-ZA65
LHSC
FRONT X R 0116 88-121-224-080 RES,220K-1/8W J a
FRONT X R 0121 88-108-100-080 C-RES,U 10-1/16W J a
FRONT X R 0122 88-108-681-080 C-RES,U 680-1/16W J a
FRONT X R 0123 88-121-472-080 RES,4.7K-1/8W J a
FRONT X R 0124 88-108-681-080 C-RES,U 680-1/16W J a
FRONT X R 0125 88-121-472-080 RES,4.7K-1/8W J a
FRONT X R 0126 88-108-100-080 C-RES,U 10-1/16W J a
FRONT X R 0131 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0133 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0135 88-121-102-080 RES,1K-1/8W J a
FRONT X R 0136 88-121-102-080 RES,1K-1/8W J a
FRONT X R 0137 88-108-101-080 C-RES,U 100-1/16W J a
FRONT X R 0138 88-108-333-080 C-RES,U 33K-1/16W J a
FRONT X R 0139 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0140 88-108-122-080 C-RES,U 1.2K-1/16W J a
FRONT X R 0141 88-108-224-080 C-RES,U 220K-1/16W J a
FRONT X R 0156 88-108-124-080 C-RES,U 120K-1/16W J a
FRONT X R 0157 88-108-223-080 C-RES,U 22K-1/16W J a
FRONT X R 0158 88-108-333-080 C-RES,U 33K-1/16W J a
FRONT X R 0176 88-108-103-080 C-RES,U 10K-1/16W J a
CX-ZA65
LHSC
FRONT X R 0197 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0201 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0202 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0205 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0206 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0213 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0214 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0217 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0218 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0251 88-108-222-080 C-RES,U 2.2K-1/16W J a
FRONT X R 0252 88-108-222-080 C-RES,U 2.2K-1/16W J a
FRONT X R 0253 88-108-222-080 C-RES,U 2.2K-1/16W J a
FRONT X R 0254 88-121-472-080 RES,4.7K-1/8W J a
FRONT X R 0255 88-121-103-080 RES,10K-1/8W J a
FRONT X R 0256 88-108-101-080 C-RES,U 100-1/16W J a
FRONT X R 0302 88-108-224-080 C-RES,U 220K-1/16W J a
FRONT X R 0303 88-121-273-080 RES,27K-1/8W J a
FRONT X R 0304 88-108-273-080 C-RES,U 27K-1/16W J a
FRONT X R 0305 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0306 88-108-104-080 C-RES,U 100K-1/16W J a
CX-ZA65
LHSC
FRONT X R 0307 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0311 88-118-471-080 C-RES,S 470-1/10W J a
FRONT X R 0321 88-108-101-080 C-RES,U 100-1/16W J a
FRONT X R 0322 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0323 88-108-273-080 C-RES,U 27K-1/16W J a
FRONT X R 0324 88-121-472-080 RES,4.7K-1/8W J a
FRONT X R 0330 88-108-472-080 C-RES,U 4.7K-1/16W J a
FRONT X R 0331 88-108-273-080 C-RES,U 27K-1/16W J a
FRONT X R 0332 88-108-472-080 C-RES,U 4.7K-1/16W J a
FRONT X R 0333 88-108-273-080 C-RES,U 27K-1/16W J a
FRONT X R 0334 88-108-472-080 C-RES,U 4.7K-1/16W J a
FRONT X R 0335 88-108-273-080 C-RES,U 27K-1/16W J a
FRONT X R 0351 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0352 88-121-561-080 RES,560-1/8W J a
FRONT X R 0353 88-108-109-080 C-RES,U 1-1/16W J a
FRONT X R 0354 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0355 88-121-222-080 RES,2.2K-1/8W J a
FRONT X R 0356 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0357 88-121-222-080 RES,2.2K-1/8W J a
FRONT X R 0361 88-108-473-080 C-RES,U 47K-1/16W J a
CX-ZA65
LHSC
FRONT X R 0363 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0366 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0367 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0368 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0371 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0373 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0374 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0375 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0376 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0377 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0378 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0379 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0401 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0402 88-108-561-080 C-RES,U 560-1/16W J a
FRONT X R 0403 88-108-561-080 C-RES,U 560-1/16W J a
FRONT X R 0404 88-108-681-080 C-RES,U 680-1/16W J a
FRONT X R 0405 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0411 88-108-101-080 C-RES,U 100-1/16W J a
FRONT X R 0412 88-108-563-080 C-RES,U 56K-1/16W J a
FRONT X R 0421 88-108-682-080 C-RES,U 6.8K-1/16W J a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 10 –
CX-ZA65
LHSC
FRONT X R 0422 88-108-152-080 C-RES,U 1.5K-1/16W J a
FRONT X R 0423 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0424 88-108-183-080 C-RES,U 18K-1/16W J a
FRONT X R 0425 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0441 88-121-223-080 RES,22K-1/8W J a
FRONT X R 0442 88-121-101-080 RES,100-1/8W J a
FRONT X R 0651 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0652 88-108-183-080 C-RES,U 18K-1/16W J a
FRONT X R 0653 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0654 88-108-152-080 C-RES,U 1.5K-1/16W J a
FRONT X R 0655 88-108-682-080 C-RES,U 6.8K-1/16W J a
FRONT X R 0670 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0680 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0682 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0683 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0684 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0685 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0686 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0687 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0688 88-118-122-080 C-RES,S 1.2K-1/10W J a
CX-ZA65
LHSC
FRONT X R 0689 88-118-122-080 C-RES,S 1.2K-1/10W J a
FRONT X R 0805 88-121-681-080 RES,680-1/8W J a
FRONT X R 0806 88-108-821-080 C-RES,U 820-1/16W J a
FRONT X R 0807 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0808 88-108-122-080 C-RES,U 1.2K-1/16W J a
FRONT X R 0809 88-108-152-080 C-RES,U 1.5K-1/16W J a
FRONT X R 0821 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0822 88-108-561-080 C-RES,U 560-1/16W J a
FRONT X R 0823 88-108-561-080 C-RES,U 560-1/16W J a
FRONT X R 0824 88-108-681-080 C-RES,U 680-1/16W J a
FRONT X R 0825 88-108-681-080 C-RES,U 680-1/16W J a
FRONT X R 0826 88-108-821-080 C-RES,U 820-1/16W J a
FRONT X R 0827 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0828 88-121-122-080 RES,1.2K-1/8W J a
FRONT X R 0829 88-121-152-080 RES,1.5K-1/8W J a
FRONT X R 0830 88-108-182-080 C-RES,U 1.8K-1/16W J a
FRONT X R 0831 88-121-222-080 RES,2.2K-1/8W J a
FRONT X R 0842 88-108-561-080 C-RES,U 560-1/16W J a
FRONT X R 0843 88-108-561-080 C-RES,U 560-1/16W J a
FRONT X R 0844 88-121-681-080 RES,680-1/8W J a
CX-ZA65
LHSC
FRONT X R 0845 88-108-681-080 C-RES,U 680-1/16W J a
FRONT X R 0846 88-108-821-080 C-RES,U 820-1/16W J a
FRONT X R 0847 88-121-102-080 RES,1K-1/8W J a
FRONT X R 0848 88-108-122-080 C-RES,U 1.2K-1/16W J a
FRONT X R 0849 88-121-152-080 RES,1.5K-1/8W J a
FRONT X R 0850 88-108-182-080 C-RES,U 1.8K-1/16W J a
FRONT X R 0851 88-108-222-080 C-RES,U 2.2K-1/16W J a
FRONT X R 0901 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0902 88-118-103-080 C-RES,S 10K-1/10W J a
FRONT X R 0903 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0904 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0905 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0906 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0907 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0908 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0909 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0910 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0911 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0912 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0913 88-108-473-080 C-RES,U 47K-1/16W J a
CX-ZA65
LHSC
FRONT X R 0914 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0915 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0916 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0917 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0918 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0919 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0920 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0921 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0922 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0923 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0924 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0925 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0926 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0927 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0928 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0929 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0930 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0931 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0932 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0933 88-108-473-080 C-RES,U 47K-1/16W J a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 11 –
CX-ZA65
LHSC
FRONT X R 0934 88-121-473-080 RES,47K-1/8W J a
FRONT X R 0935 88-121-473-080 RES,47K-1/8W J a
FRONT X R 0936 88-121-473-080 RES,47K-1/8W J a
FRONT X R 0937 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0938 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0939 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0940 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0941 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0942 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0943 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0944 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0945 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0946 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0947 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0948 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0949 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0950 88-118-123-080 C-RES,S 12K-1/10W J a
FRONT X R 0951 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0952 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT X R 0953 88-108-104-080 C-RES,U 100K-1/16W J a
CX-ZA65
LHSC
FRONT X R 1000 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 1001 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 1002 88-108-101-080 C-RES,U 100-1/16W J a
FRONT X R 1003 88-108-272-080 C-RES,U 2.7K-1/16W J a
FRONT X R 1004 88-108-101-080 C-RES,U 100-1/16W J a
FRONT X R 1005 88-108-272-080 C-RES,U 2.7K-1/16W J a
FRONT X R 1006 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 1007 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 1010 88-108-823-080 C-RES,U 82K-1/16W J a
FRONT O S 0401 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0402 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0405 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0421 87-A92-071-110 SW,RTRY EC12E24508-30MM a
FRONT O S 0651 87-A91-542-110 SW,RTRY EC12E12504 a
FRONT O S 0805 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0806 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0807 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0808 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0809 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0821 87-A90-095-080 SW,TACT EVQ11G04M a
CX-ZA65
LHSC
FRONT O S 0822 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0823 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0825 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0826 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0827 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0828 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0829 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0830 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0831 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0842 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0843 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0845 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0846 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0849 87-A90-095-080 SW,TACT EVQ11G04M a
FRONT O S 0851 87-A90-095-080 SW,TACT EVQ11G04M a
KEY CD O CNA0702 87-A60-666-010 CONN,2P H 2MM JMT a
KEY CD X R 0751 88-108-272-080 C-RES,U 2.7K-1/16W J a
KEY CD X R 0752 88-108-392-080 C-RES,U 3.9K-1/16W J a
KEY CD X R 0753 88-108-472-080 C-RES,U 4.7K-1/16W J a
KEY CD X R 0754 88-108-682-080 C-RES,U 6.8K-1/16W J a
CX-ZA65
LHSC
KEY CD X R 0755 88-108-103-080 C-RES,U 10K-1/16W J a
KEY CD O S 0751 87-A90-095-080 SW,TACT EVQ11G04M a
KEY CD O S 0752 87-A90-095-080 SW,TACT EVQ11G04M a
KEY CD O S 0753 87-A90-095-080 SW,TACT EVQ11G04M a
KEY CD O S 0754 87-A90-095-080 SW,TACT EVQ11G04M a
KEY CD O S 0755 87-A90-095-080 SW,TACT EVQ11G04M a
MAIN O C 0003 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0004 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0005 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0006 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0009 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0010 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0011 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0012 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0019 87-A12-875-000 CAP,E 3300-65 M 85 IV a
MAIN O C 0020 87-A12-875-000 CAP,E 3300-65 M 85 IV a
MAIN O C 0021 87-A12-440-000 CAP,E 3300-35 M 85 IV LELON a
MAIN O C 0022 87-A12-440-000 CAP,E 3300-35 M 85 IV LELON a
MAIN O C 0025 87-010-247-080 CAP,E 100-50 M SME a
MAIN O C 0026 87-010-247-080 CAP,E 100-50 M SME a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 12 –
CX-ZA65
LHSC
MAIN O C 0027 87-010-247-080 CAP,E 100-50 M SME a
MAIN O C 0028 87-010-247-080 CAP,E 100-50 M SME a
MAIN O C 0030 87-010-430-080 CAP,E 100-63 a
MAIN O C 0031 87-010-263-080 CAP,E 100-10 M 11L SME a
MAIN O C 0032 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0033 87-010-263-080 CAP,E 100-10 M 11L SME a
MAIN O C 0034 87-010-247-080 CAP,E 100-50 M SME a
MAIN O C 0035 87-010-380-080 CAP,E 47-16 M 11L SME a
MAIN O C 0036 87-010-381-080 CAP,E 330-16 M SME a
MAIN O C 0038 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0060 87-010-403-080 CAP,E 3.3-50 M 11L SME a
MAIN O C 0061 87-010-260-080 CAP,E 47-25 M 11L SME a
MAIN O C 0083 87-010-387-080 CAP,E 470-25 M SME a
MAIN O C 0097 87-010-759-080 C-CAP,U 0.1-25 Z F a
MAIN O C 0099 87-010-759-080 C-CAP,U 0.1-25 Z F a
MAIN O C 0101 87-012-279-080 C-CAP,U 2700P-50 K B GRM a
MAIN O C 0102 87-012-279-080 C-CAP,U 2700P-50 K B GRM a
MAIN O C 0103 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0104 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0107 87-010-405-080 CAP,E 10-50 M 11L SME a
CX-ZA65
LHSC
MAIN O C 0108 87-010-405-080 CAP,E 10-50 M 11L SME a
MAIN O C 0109 87-012-199-080 C-CAP,U 220P-50 J CH a
MAIN O C 0110 87-012-199-080 C-CAP,U 220P-50 J CH a
MAIN O C 0111 87-010-392-080 CAP,E 33-35 M 11L SME a
MAIN O C 0112 87-010-392-080 CAP,E 33-35 M 11L SME a
MAIN O C 0113 87-A10-596-080 C-CAP,S 100P-100 J CH a
MAIN O C 0114 87-A10-596-080 C-CAP,S 100P-100 J CH a
MAIN O C 0115 87-012-167-080 C-CAP,U 5P-50 C CH a
MAIN O C 0116 87-012-167-080 C-CAP,U 5P-50 C CH a
MAIN O C 0117 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0118 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0119 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0120 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0121 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0122 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0123 87-010-177-080 C-CAP,S 820P-50 J SL C2012 a
MAIN O C 0124 87-010-177-080 C-CAP,S 820P-50 J SL C2012 a
MAIN O C 0133 87-012-282-080 C-CAP,U 4700P-50 K B a
MAIN O C 0140 87-012-278-080 C-CAP,U 2200P-50 K B a
MAIN O C 0186 87-010-759-080 C-CAP,U 0.1-25 Z F a
CX-ZA65
LHSC
MAIN O C 0187 87-A10-119-080 CAP,E 10-100 REA a
MAIN O C 0188 87-A10-119-080 CAP,E 10-100 REA a
MAIN O C 0191 87-A10-812-080 C-CAP,S 220P-200 J CH a
MAIN O C 0192 87-A10-812-080 C-CAP,S 220P-200 J CH a
MAIN O C 0225 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0226 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0227 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0228 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0229 87-012-287-080 C-CAP,U 0.015-25 Z F a
MAIN O C 0230 87-012-287-080 C-CAP,U 0.015-25 Z F a
MAIN O C 0231 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0232 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0241 87-010-759-080 C-CAP,U 0.1-25 Z F a
MAIN O C 0301 87-012-274-080 C-CAP,U 1000P-50 K B a
MAIN O C 0302 87-012-274-080 C-CAP,U 1000P-50 K B a
MAIN O C 0303 87-012-275-080 C-CAP,U 1200P-50 K B GRM a
MAIN O C 0304 87-012-275-080 C-CAP,U 1200P-50 K B GRM a
MAIN O C 0307 87-010-263-080 CAP,E 100-10 M 11L SME a
MAIN O C 0308 87-010-263-080 CAP,E 100-10 M 11L SME a
MAIN O C 0309 87-012-195-080 C-CAP,U 100P-50 J CH a
CX-ZA65
LHSC
MAIN O C 0310 87-012-195-080 C-CAP,U 100P-50 J CH a
MAIN O C 0313 87-012-284-080 C-CAP,U 6800P-50 K B GRM a
MAIN O C 0314 87-012-284-080 C-CAP,U 6800P-50 K B GRM a
MAIN O C 0315 87-010-263-080 CAP,E 100-10 M 11L SME a
MAIN O C 0317 87-010-546-080 CAP,E 0.33-50 M 11L SME a
MAIN O C 0318 87-010-546-080 CAP,E 0.33-50 M 11L SME a
MAIN O C 0326 87-016-118-080 C-CAP,U 0.022-25 J B GRM a
MAIN O C 0327 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0360 87-010-401-080 CAP,E 1-50 M 11L SME a
MAIN O C 0365 87-010-759-080 C-CAP,U 0.1-25 Z F a
MAIN O C 0399 87-012-270-080 C-CAP,U 470P-50 K B a
MAIN O C 0401 87-010-544-080 CAP,E 0.1-50 M 11L SME a
MAIN O C 0402 87-010-544-080 CAP,E 0.1-50 M 11L SME a
MAIN O C 0403 87-012-193-080 C-CAP,U 82P-50 J CH a
MAIN O C 0404 87-012-193-080 C-CAP,U 82P-50 J CH a
MAIN O C 0405 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0406 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0407 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0408 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0409 87-012-278-080 C-CAP,U 2200P-50 K B a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 13 –
CX-ZA65
LHSC
MAIN O C 0410 87-012-278-080 C-CAP,U 2200P-50 K B a
MAIN O C 0411 87-010-405-080 CAP,E 10-50 M 11L SME a
MAIN O C 0412 87-010-405-080 CAP,E 10-50 M 11L SME a
MAIN O C 0452 87-010-406-080 CAP,E 22-50 M 11L SME a
MAIN O C 0453 87-012-279-080 C-CAP,U 2700P-50 K B GRM a
MAIN O C 0454 87-012-279-080 C-CAP,U 2700P-50 K B GRM a
MAIN O C 0455 87-012-279-080 C-CAP,U 2700P-50 K B GRM a
MAIN O C 0456 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0457 87-A12-361-080 CAP,M 5600P-100 J CP a
MAIN O C 0458 87-012-274-080 C-CAP,U 1000P-50 K B a
MAIN O C 0459 87-012-271-080 C-CAP,U 560P-50 K B a
MAIN O C 0460 87-010-759-080 C-CAP,U 0.1-25 Z F a
MAIN O C 0461 87-012-269-080 C-CAP,U 390P-50 K B a
MAIN O C 0462 87-012-269-080 C-CAP,U 390P-50 K B a
MAIN O C 0470 87-A11-104-080 CAP,TC U 470P-50 J CH a
MAIN O C 0605 87-012-275-080 C-CAP,U 1200P-50 K B GRM a
MAIN O C 0606 87-012-275-080 C-CAP,U 1200P-50 K B GRM a
MAIN O C 0609 87-012-287-080 C-CAP,U 0.015-25 Z F a
MAIN O C 0610 87-012-287-080 C-CAP,U 0.015-25 Z F a
MAIN O C 0611 87-010-545-080 CAP,E 0.22-50 M 11L SME a
CX-ZA65
LHSC
MAIN O C 0612 87-010-545-080 CAP,E 0.22-50 M 11L SME a
MAIN O C 0613 87-010-545-080 CAP,E 0.22-50 M 11L SME a
MAIN O C 0614 87-010-545-080 CAP,E 0.22-50 M 11L SME a
MAIN O C 0615 87-012-172-080 C-CAP,U 10P-50 D CH a
MAIN O C 0616 87-010-221-080 CAP,E 470-10 M SME a
MAIN O C 0617 87-010-221-080 CAP,E 470-10 M SME a
MAIN O C 0618 87-010-405-080 CAP,E 10-50 M 11L SME a
MAIN O C 0620 87-010-263-080 CAP,E 100-10 M 11L SME a
MAIN O C 0623 87-010-402-080 CAP,E 2.2-50 M 11L SME a
MAIN O C 0624 87-010-402-080 CAP,E 2.2-50 M 11L SME a
MAIN O C 0630 87-010-759-080 C-CAP,U 0.1-25 Z F a
MAIN X C 0633 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X C 0634 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN O C 0669 87-012-195-080 C-CAP,U 100P-50 J CH a
MAIN O C 0670 87-012-195-080 C-CAP,U 100P-50 J CH a
MAIN O C 0677 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0771 87-010-263-080 CAP,E 100-10 M 11L SME a
MAIN O C 0772 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN X C 0781 88-108-000-080 C-JUMPER,U a
MAIN O C 0782 87-012-286-080 C-CAP,U 0.01-25 K B a
CX-ZA65
LHSC
MAIN O C 0783 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0784 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0785 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0786 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0788 87-012-167-080 C-CAP,U 5P-50 C CH a
MAIN O C 0789 87-A12-052-080 C-CAP,S 0.033-25 J B a
MAIN O C 0790 87-A12-052-080 C-CAP,S 0.033-25 J B a
MAIN O C 0791 87-010-831-080 C-CAP,U 0.1-16 Z F a
MAIN O C 0792 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0793 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0795 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0796 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0797 87-010-405-080 CAP,E 10-50 M 11L SME a
MAIN O C 0798 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0799 87-010-265-080 CAP,E 33-16 M 11L SME a
MAIN O C 0800 87-010-829-080 C-CAP,U 0.047-16 Z F a
MAIN O C 0801 87-010-403-080 CAP,E 3.3-50 M 11L SME a
MAIN O C 0802 87-010-829-080 C-CAP,U 0.047-16 Z F a
MAIN O C 0803 87-010-787-080 C-CAP,U 0.022-25 K B a
MAIN O C 0804 87-010-263-080 CAP,E 100-10 M 11L SME a
CX-ZA65
LHSC
MAIN O C 0807 87-010-400-080 CAP,E 0.47-50 M 11L SME a
MAIN O C 0808 87-010-401-080 CAP,E 1-50 M 11L SME a
MAIN O C 0809 87-010-401-080 CAP,E 1-50 M 11L SME a
MAIN O C 0810 87-010-831-080 C-CAP,U 0.1-16 Z F a
MAIN O C 0814 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0815 87-010-400-080 CAP,E 0.47-50 M 11L SME a
MAIN O C 0816 87-010-400-080 CAP,E 0.47-50 M 11L SME a
MAIN O C 0821 87-010-405-080 CAP,E 10-50 M 11L SME a
MAIN X C 0822 88-108-000-080 C-JUMPER,U a
MAIN O C 0823 87-010-177-080 C-CAP,S 820P-50 J SL C2012 a
MAIN O C 0824 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0825 87-010-829-080 C-CAP,U 0.047-16 Z F a
MAIN O C 0842 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN X C 0843 88-108-000-080 C-JUMPER,U a
MAIN O C 0844 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN X C 0845 88-108-000-080 C-JUMPER,U a
MAIN X C 0846 88-108-000-080 C-JUMPER,U a
MAIN X C 0847 88-108-000-080 C-JUMPER,U a
MAIN X C 0848 88-108-000-080 C-JUMPER,U a
MAIN X C 0849 88-108-000-080 C-JUMPER,U a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 14 –
CX-ZA65
LHSC
MAIN O C 0850 87-010-260-080 CAP,E 47-25 M 11L SME a
MAIN O C 0851 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0852 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0853 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0858 87-010-831-080 C-CAP,U 0.1-16 Z F a
MAIN O C 0901 87-018-145-080 CAP,TC U 6.8P-50 K CH UP050 a
MAIN O C 0904 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0905 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0907 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0908 87-A10-915-080 C-CAP,U 1000P-25 J CH a
MAIN O C 0909 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0910 87-012-174-080 C-CAP,U 12P-50 J CH a
MAIN O C 0911 87-012-170-080 C-CAP,U 8P-50 D CH a
MAIN O C 0912 87-012-195-080 C-CAP,U 100P-50 J CH a
MAIN O C 0913 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0914 87-012-166-080 C-CAP,U 4P-50 C CH a
MAIN O C 0915 87-012-174-080 C-CAP,U 12P-50 J CH a
MAIN O C 0916 87-012-180-080 C-CAP,U 22P-50 J CH a
MAIN O C 0917 87-012-186-080 C-CAP,U 39P-50 J CH a
MAIN O C 0918 87-A10-039-080 C-CAP,U 470P-50 J CH a
CX-ZA65
LHSC
MAIN O C 0921 87-012-195-080 C-CAP,U 100P-50 J CH a
MAIN O C 0922 87-012-174-080 C-CAP,U 12P-50 J CH a
MAIN X C 0940 88-108-000-080 C-JUMPER,U a
MAIN O C 0959 87-010-831-080 C-CAP,U 0.1-16 Z F a
MAIN O C 0960 87-010-831-080 C-CAP,U 0.1-16 Z F a
MAIN O C 0961 87-012-167-080 C-CAP,U 5P-50 C CH a
MAIN O C 0963 87-015-785-080 C-CAP, 0.1-25 Z F C3216 a
MAIN O C 0971 87-010-381-080 CAP,E 330-16 M SME a
MAIN O C 0972 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0973 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0974 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0979 87-012-195-080 C-CAP,U 100P-50 J CH a
MAIN O C 0981 87-010-260-080 CAP,E 47-25 M 11L SME a
MAIN O C 0982 87-010-831-080 C-CAP,U 0.1-16 Z F a
MAIN O C 0983 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0984 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0987 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN O C 0991 87-012-176-080 C-CAP,U 15P-50 J CH a
MAIN O C 0992 87-012-176-080 C-CAP,U 15P-50 J CH a
MAIN O C 0993 87-012-274-080 C-CAP,U 1000P-50 K B a
CX-ZA65
LHSC
MAIN O C 0995 87-012-274-080 C-CAP,U 1000P-50 K B a
MAIN O C 0997 87-010-831-080 C-CAP,U 0.1-16 Z F a
MAIN O C 0998 87-010-260-080 CAP,E 47-25 M 11L SME a
MAIN O C 0999 87-A11-155-080 CAP,TC U 0.01-16 Z F a
MAIN O CF 0831 87-008-261-010 FLTR,CF SFE10.7MA5 a
MAIN O CF 0832 87-008-261-010 FLTR,CF SFE10.7MA5 a
MAIN X CLP0302 87-A60-884-010 PIN,DIA1 COATING-SHS a
MAIN X CLP0601 8B-MA6-646-010 WIRE ASSY,LUG a
MAIN O CN 0301 87-A60-620-010 CONN,3P V 2MM JMT a
MAIN O CN 0351 87-A60-625-010 CONN,8P V 2MM JMT a
MAIN O CN 0501 87-099-564-010 CONN,4P V TUC-P4P-B1 a
MAIN O CN 0601 87-099-719-010 CONN,30P H BLK TYK-B(X) a
MAIN O CN 0602 87-A60-131-010 CONN,6P V FE a
MAIN O CNA0001 8A-NF8-653-010 CONN ASSY,9P TID-A(480) a
MAIN S D 0009 87-017-447-010 DIODE,GBU4DL-6419 a
MAIN S D 0010 87-017-447-010 DIODE,GBU4DL-6419 a
MAIN S D 0025 87-A40-553-080 DIODE,1N4003 LES a
MAIN S D 0026 87-A40-553-080 DIODE,1N4003 LES a
MAIN S D 0027 87-A40-553-080 DIODE,1N4003 LES a
MAIN S D 0028 87-A40-553-080 DIODE,1N4003 LES a
CX-ZA65
LHSC
MAIN S D 0029 87-A40-780-080 ZENER,UZ33BSD a
MAIN S D 0030 87-020-465-080 DIODE,1SS133 a
MAIN S D 0031 87-A40-764-080 ZENER,UZ10BSC a
MAIN S D 0033 87-A40-553-080 DIODE,1N4003 LES a
MAIN S D 0034 87-020-465-080 DIODE,1SS133 a
MAIN S D 0035 87-020-465-080 DIODE,1SS133 a
MAIN S D 0041 87-A40-270-080 C-DIODE,MC2838 a
MAIN S D 0042 87-A40-269-080 C-DIODE,MC2836 a
MAIN S D 0060 87-020-465-080 DIODE,1SS133 a
MAIN S D 0062 87-A40-270-080 C-DIODE,MC2838 a
MAIN S D 0063 87-A40-270-080 C-DIODE,MC2838 a
MAIN S D 0064 87-A40-269-080 C-DIODE,MC2836 a
MAIN S D 0065 87-A40-269-080 C-DIODE,MC2836 a
MAIN S D 0071 87-A40-269-080 C-DIODE,MC2836 a
MAIN S D 0072 87-A40-270-080 C-DIODE,MC2838 a
MAIN S D 0076 87-A40-269-080 C-DIODE,MC2836 a
MAIN S D 0077 87-A40-270-080 C-DIODE,MC2838 a
MAIN S D 0101 87-A40-269-080 C-DIODE,MC2836 a
MAIN S D 0103 87-020-465-080 DIODE,1SS133 a
MAIN S D 0104 87-020-465-080 DIODE,1SS133 a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 15 –
CX-ZA65
LHSC
MAIN S D 0105 87-020-465-080 DIODE,1SS133 a
MAIN S D 0106 87-020-465-080 DIODE,1SS133 a
MAIN S D 0107 87-020-465-080 DIODE,1SS133 a
MAIN S D 0108 87-020-465-080 DIODE,1SS133 a
MAIN S D 0115 87-A40-270-080 C-DIODE,MC2838 a
MAIN S D 0117 87-020-465-080 DIODE,1SS133 a
MAIN S D 0118 87-020-465-080 DIODE,1SS133 a
MAIN S D 0150 87-A40-270-080 C-DIODE,MC2838 a
MAIN S D 0160 87-A40-270-080 C-DIODE,MC2838 a
MAIN S D 0185 87-A40-646-010 DIODE,FMB-G16L a
MAIN S D 0186 87-A40-646-010 DIODE,FMB-G16L a
MAIN S D 0187 87-A40-002-080 ZENER,MTZJ5.1C a
MAIN S D 0188 87-A40-749-080 ZENER,UZ5.6BSB a
MAIN S D 0189 87-A40-270-080 C-DIODE,MC2838 a
MAIN S D 0190 87-A40-269-080 C-DIODE,MC2836 a
MAIN S D 0191 87-A40-764-080 ZENER,UZ10BSC a
MAIN S D 0192 87-020-465-080 DIODE,1SS133 a
MAIN S D 0193 87-020-465-080 DIODE,1SS133 a
MAIN S D 0401 87-020-465-080 DIODE,1SS133 a
MAIN S D 0501 87-A40-270-080 C-DIODE,MC2838 a
CX-ZA65
LHSC
MAIN S D 0601 87-A40-539-080 ZENER,MTZJ2.4A a
MAIN S D 0602 87-A40-539-080 ZENER,MTZJ2.4A a
MAIN X D 0801 88-100-000-010 PLATING-JW, 0.58 SN95 a
MAIN S D 0803 87-A40-291-080 DIODE,1N4148M (CPT) a
MAIN O D 0902 87-A40-128-080 C-VARI-CAP,HVU202A a
MAIN O D 0903 87-A40-128-080 C-VARI-CAP,HVU202A a
MAIN X D 0944 88-100-000-010 PLATING-JW, 0.58 SN95 a
MAIN S D 0991 87-017-149-080 ZENER,HZS6A2L a
MAIN S D 0994 87-020-465-080 DIODE,1SS133 a
MAIN X FB 0301 88-100-000-010 PLATING-JW, 0.58 SN95 a
MAIN X FB 0302 88-108-000-080 C-JUMPER,U a
MAIN X FB 0602 88-100-000-010 PLATING-JW, 0.58 SN95 a
MAIN O FFC0602 88-906-321-110 FF-CABLE, 6P 1.25 320MM a
MAIN S IC 0301 87-A21-419-040 C-IC,NJM14558MD-TE2 a
MAIN S IC 0401 87-A21-893-040 C-IC,NJM14558V-TE2 a
MAIN S IC 0601 87-A21-443-040 C-IC,M62495AFP a
MAIN S IC 0801 87-A21-695-010 IC,LA1845L a
MAIN S IC 0991 87-A21-928-010 IC,LC72131D-N a
MAIN O J 0201 87-A60-488-010 JACK,DIA6.3 BLK ST W/SW KM16AT a
MAIN O J 0203 87-A60-238-010 TERMINAL,SP 4P (MSC) a
CX-ZA65
LHSC
MAIN O J 0602 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN a
MAIN O J 0831 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 a
MAIN X JR 0105 88-128-273-080 C-RES, 27K-1/8W J a
MAIN O JR 0123 87-A10-596-080 C-CAP,S 100P-100 J CH a
MAIN O JR 0124 87-A10-596-080 C-CAP,S 100P-100 J CH a
MAIN X JR 0404 88-128-150-080 C-RES, 15-1/8W J a
MAIN X JR 0835 88-108-561-080 C-RES,U 560-1/16W J a
MAIN O L 0201 87-A50-610-010 COIL,1UH K(MDEC) a
MAIN O L 0202 87-A50-610-010 COIL,1UH K(MDEC) a
MAIN O L 0451 87-007-342-010 COIL,OSC 85KHZ BIAS a
MAIN O L 0801 87-A50-608-010 COIL,FM DET-N(TOK) a
MAIN O L 0802 87-A91-551-010 FLTR,PCFJZH-450 L(TOK) a
MAIN O L 0811 87-005-847-080 COIL,2.2UH K CECS a
MAIN O L 0832 87-005-847-080 COIL,2.2UH K CECS a
MAIN O L 0902 88-ZA1-602-110 COIL,FM-RF-U2 2G a
MAIN O L 0903 88-ZA1-601-010 COIL,FM-RF-U1 2G a
MAIN O L 0904 87-005-847-080 COIL,2.2UH K CECS a
MAIN O L 0905 88-ZA1-624-010 COIL,FM IFT 7-6.2 (COILS) a
MAIN O L 0906 88-ZA1-603-010 COIL,FM-OSC-U 2G a
MAIN O L 0951 8A-NF8-667-010 COIL,AM PACK 4(TOK) a
CX-ZA65
LHSC
MAIN S Q 0001 87-A30-494-080 TR,2SA1980G a
MAIN S Q 0002 87-A30-494-080 TR,2SA1980G a
MAIN S Q 0003 87-A30-559-010 TR,CSB1370EF a
MAIN S Q 0005 87-A30-492-080 TR,2SC5343G a
MAIN S Q 0006 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0008 87-A30-075-080 C-TR,2SA1235F a
MAIN S Q 0009 87-A30-494-080 TR,2SA1980G a
MAIN S Q 0010 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0059 87-A30-635-040 C-TR,SBT5401F a
MAIN S Q 0060 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0061 87-A30-075-080 C-TR,2SA1235F a
MAIN S Q 0062 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0063 87-A30-075-080 C-TR,2SA1235F a
MAIN S Q 0064 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0065 87-A30-538-040 C-TR,SRA2202S a
MAIN S Q 0101 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0102 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0103 87-A30-635-040 C-TR,SBT5401F a
MAIN S Q 0104 87-A30-635-040 C-TR,SBT5401F a
MAIN S Q 0105 87-A30-635-040 C-TR,SBT5401F a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 16 –
CX-ZA65
LHSC
MAIN S Q 0106 87-A30-635-040 C-TR,SBT5401F a
MAIN S Q 0107 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0108 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0109 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0110 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0111 87-A30-672-080 TR,2N5551C a
MAIN S Q 0112 87-A30-672-080 TR,2N5551C a
MAIN S Q 0113 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0114 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0115 87-A30-636-040 C-TR,SBT5551F a
MAIN S Q 0116 87-A30-636-040 C-TR,SBT5551F a
MAIN S Q 0121 87-A30-672-080 TR,2N5551C a
MAIN S Q 0122 87-A30-672-080 TR,2N5551C a
MAIN S Q 0123 87-A30-635-040 C-TR,SBT5401F a
MAIN S Q 0124 87-A30-635-040 C-TR,SBT5401F a
MAIN S Q 0126 87-A30-635-040 C-TR,SBT5401F a
MAIN S Q 0127 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0128 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0130 87-A30-636-040 C-TR,SBT5551F a
MAIN S Q 0131 87-A30-098-010 TR,FP1016 a
CX-ZA65
LHSC
MAIN S Q 0132 87-A30-098-010 TR,FP1016 a
MAIN S Q 0133 87-A30-097-010 TR,FN1016 a
MAIN S Q 0134 87-A30-097-010 TR,FN1016 a
MAIN S Q 0183 87-A30-162-010 FET,2SK2937 a
MAIN S Q 0184 87-A30-162-010 FET,2SK2937 a
MAIN S Q 0185 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0186 87-A30-075-080 C-TR,2SA1235F a
MAIN S Q 0187 87-A30-075-080 C-TR,2SA1235F a
MAIN S Q 0235 87-A30-075-080 C-TR,2SA1235F a
MAIN S Q 0301 87-A30-091-080 FET,2SJ460 a
MAIN S Q 0302 87-A30-091-080 FET,2SJ460 a
MAIN S Q 0303 87-A30-090-080 FET,2SK2541 a
MAIN S Q 0304 87-A30-090-080 FET,2SK2541 a
MAIN S Q 0305 87-A30-091-080 FET,2SJ460 a
MAIN S Q 0306 87-A30-586-040 C-TR,SRC1204S a
MAIN S Q 0307 87-A30-091-080 FET,2SJ460 a
MAIN S Q 0308 87-A30-091-080 FET,2SJ460 a
MAIN S Q 0309 87-A30-075-080 C-TR,2SA1235F a
MAIN S Q 0310 87-A30-075-080 C-TR,2SA1235F a
MAIN S Q 0443 87-A30-075-080 C-TR,2SA1235F a
CX-ZA65
LHSC
MAIN S Q 0444 87-A30-075-080 C-TR,2SA1235F a
MAIN S Q 0451 87-A30-495-080 TR,2SA1981Y a
MAIN S Q 0453 87-A30-492-080 TR,2SC5343G a
MAIN S Q 0454 87-A30-492-080 TR,2SC5343G a
MAIN S Q 0601 87-A30-087-080 C-FET,2SK2158 a
MAIN S Q 0602 87-A30-087-080 C-FET,2SK2158 a
MAIN S Q 0605 87-A30-090-080 FET,2SK2541 a
MAIN S Q 0606 87-A30-090-080 FET,2SK2541 a
MAIN S Q 0607 87-A30-076-080 C-TR,2SC3052F a
MAIN S Q 0835 89-327-143-080 C-TR,2SC2714O a
MAIN S Q 0836 87-A30-677-040 C-TR,SRA2207S a
MAIN S Q 0901 89-503-602-080 C-FET,2SK360E a
MAIN S Q 0902 89-327-143-080 C-TR,2SC2714O a
MAIN S Q 0903 89-327-143-080 C-TR,2SC2714O a
MAIN S Q 0981 87-A30-196-080 TR,2SC4115SRS a
MAIN X R 0001 88-100-000-010 PLATING-JW, 0.58 SN95 a
MAIN X R 0005 88-100-000-010 PLATING-JW, 0.58 SN95 a
MAIN X R 0009 88-108-273-080 C-RES,U 27K-1/16W J a
MAIN X R 0010 88-108-273-080 C-RES,U 27K-1/16W J a
MAIN X R 0011 88-108-472-080 C-RES,U 4.7K-1/16W J a
CX-ZA65
LHSC
MAIN X R 0012 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0013 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0014 88-108-100-080 C-RES,U 10-1/16W J a
MAIN X R 0015 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0016 88-108-333-080 C-RES,U 33K-1/16W J a
MAIN X R 0017 88-130-151-080 RES,150-1/4W J a
MAIN X R 0018 88-108-221-080 C-RES,U 220-1/16W J a
MAIN X R 0019 88-108-000-080 C-JUMPER,U a
MAIN X R 0020 88-121-680-080 RES,68-1/8W J a
MAIN X R 0021 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0022 88-108-221-080 C-RES,U 220-1/16W J a
MAIN X R 0023 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0027 88-108-471-080 C-RES,U 470-1/16W J a
MAIN X R 0028 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0029 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0030 88-108-333-080 C-RES,U 33K-1/16W J a
MAIN X R 0031 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0032 88-121-102-080 RES,1K-1/8W J a
MAIN X R 0033 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0034 88-108-394-080 C-RES,U 390K-1/16W J a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 17 –
CX-ZA65
LHSC
MAIN X R 0037 88-128-680-080 C-RES, 68-1/8W J a
MAIN X R 0038 88-130-151-080 RES,150-1/4W J a
MAIN X R 0039 88-128-680-080 C-RES, 68-1/8W J a
MAIN X R 0040 88-108-333-080 C-RES,U 33K-1/16W J a
MAIN X R 0042 88-130-151-080 RES,150-1/4W J a
MAIN X R 0043 88-130-151-080 RES,150-1/4W J a
MAIN X R 0044 88-128-680-080 C-RES, 68-1/8W J a
MAIN X R 0045 88-128-680-080 C-RES, 68-1/8W J a
MAIN X R 0046 88-130-151-080 RES,150-1/4W J a
MAIN X R 0047 88-130-151-080 RES,150-1/4W J a
MAIN X R 0048 88-121-153-080 RES,15K-1/8W J a
MAIN X R 0050 88-128-680-080 C-RES, 68-1/8W J a
MAIN X R 0051 88-128-680-080 C-RES, 68-1/8W J a
MAIN X R 0052 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0054 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0055 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0056 88-108-822-080 C-RES,U 8.2K-1/16W J a
MAIN X R 0057 88-108-272-080 C-RES,U 2.7K-1/16W J a
MAIN X R 0058 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0059 88-108-103-080 C-RES,U 10K-1/16W J a
CX-ZA65
LHSC
MAIN X R 0060 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0061 88-108-333-080 C-RES,U 33K-1/16W J a
MAIN X R 0062 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0063 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0064 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0065 88-108-123-080 C-RES,U 12K-1/16W J a
MAIN X R 0066 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0067 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0068 88-108-224-080 C-RES,U 220K-1/16W J a
MAIN X R 0069 88-108-224-080 C-RES,U 220K-1/16W J a
MAIN X R 0070 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0071 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0072 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0073 88-128-680-080 C-RES, 68-1/8W J a
MAIN X R 0074 88-128-680-080 C-RES, 68-1/8W J a
MAIN X R 0076 88-108-562-080 C-RES,U 5.6K-1/16W J a
MAIN X R 0077 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0078 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN X R 0079 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN X R 0080 88-121-153-080 RES,15K-1/8W J a
CX-ZA65
LHSC
MAIN X R 0081 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0085 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0087 88-121-153-080 RES,15K-1/8W J a
MAIN X R 0093 88-108-823-080 C-RES,U 82K-1/16W J a
MAIN X R 0094 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN X R 0095 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN X R 0096 88-108-823-080 C-RES,U 82K-1/16W J a
MAIN X R 0101 88-108-392-080 C-RES,U 3.9K-1/16W J a
MAIN X R 0102 88-108-392-080 C-RES,U 3.9K-1/16W J a
MAIN X R 0103 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN X R 0104 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN X R 0105 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN X R 0106 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN X R 0107 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0108 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0111 88-108-821-080 C-RES,U 820-1/16W J a
MAIN X R 0112 88-108-821-080 C-RES,U 820-1/16W J a
MAIN X R 0113 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN X R 0114 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN X R 0117 88-108-103-080 C-RES,U 10K-1/16W J a
CX-ZA65
LHSC
MAIN X R 0118 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0119 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0120 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0121 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0122 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0123 88-128-332-080 C-RES, 3.3K-1/8W J a
MAIN X R 0124 88-128-332-080 C-RES, 3.3K-1/8W J a
MAIN X R 0125 88-128-332-080 C-RES, 3.3K-1/8W J a
MAIN X R 0126 88-128-332-080 C-RES, 3.3K-1/8W J a
MAIN X R 0127 88-108-390-080 C-RES,U 39-1/16W J a
MAIN X R 0128 88-108-390-080 C-RES,U 39-1/16W J a
MAIN O R 0129 87-A00-262-080 RES,M/F 0.15-2W J a
MAIN O R 0130 87-A00-262-080 RES,M/F 0.15-2W J a
MAIN O R 0131 87-A00-262-080 RES,M/F 0.15-2W J a
MAIN O R 0132 87-A00-262-080 RES,M/F 0.15-2W J a
MAIN X R 0133 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0134 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0135 88-108-122-080 C-RES,U 1.2K-1/16W J a
MAIN X R 0136 88-108-122-080 C-RES,U 1.2K-1/16W J a
MAIN X R 0137 88-108-101-080 C-RES,U 100-1/16W J a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 18 –
CX-ZA65
LHSC
MAIN X R 0138 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0141 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0142 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0151 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0152 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0153 88-108-390-080 C-RES,U 39-1/16W J a
MAIN X R 0154 88-108-390-080 C-RES,U 39-1/16W J a
MAIN X R 0155 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0156 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0157 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0158 88-128-272-080 C-RES, 2.7K-1/8W J a
MAIN X R 0159 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0160 88-121-103-080 RES,10K-1/8W J a
MAIN X R 0161 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0162 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0163 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0164 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0165 88-108-152-080 C-RES,U 1.5K-1/16W J a
MAIN X R 0166 88-108-152-080 C-RES,U 1.5K-1/16W J a
MAIN X R 0167 88-108-103-080 C-RES,U 10K-1/16W J a
CX-ZA65
LHSC
MAIN X R 0168 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0169 88-108-271-080 C-RES,U 270-1/16W J a
MAIN X R 0170 88-108-271-080 C-RES,U 270-1/16W J a
MAIN X R 0171 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0172 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0173 88-108-152-080 C-RES,U 1.5K-1/16W J a
MAIN X R 0174 88-108-152-080 C-RES,U 1.5K-1/16W J a
MAIN X R 0175 88-108-331-080 C-RES,U 330-1/16W J a
MAIN X R 0176 88-108-331-080 C-RES,U 330-1/16W J a
MAIN X R 0177 88-128-272-080 C-RES, 2.7K-1/8W J a
MAIN X R 0178 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0179 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0180 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0181 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0182 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0184 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0185 88-108-332-080 C-RES,U 3.3K-1/16W J a
MAIN X R 0186 88-118-681-080 C-RES,S 680-1/10W J a
MAIN X R 0187 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0188 88-118-152-080 C-RES,S 1.5K-1/10W J a
CX-ZA65
LHSC
MAIN X R 0189 88-128-272-080 C-RES, 2.7K-1/8W J a
MAIN X R 0190 88-128-272-080 C-RES, 2.7K-1/8W J a
MAIN X R 0192 88-128-272-080 C-RES, 2.7K-1/8W J a
MAIN X R 0193 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0194 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0195 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0196 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0197 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0198 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0199 88-108-225-080 C-RES,U 2.2M-1/16W J a
MAIN X R 0213 88-108-273-080 C-RES,U 27K-1/16W J a
MAIN X R 0217 88-108-683-080 C-RES,U 68K-1/16W J a
MAIN X R 0218 88-108-105-080 C-RES,U 1M-1/16W J a
MAIN X R 0219 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0243 87-A01-002-050 RES,270-1/2W J BLT2J a
MAIN O R 0244 87-A01-002-050 RES,270-1/2W J BLT2J a
MAIN O R 0245 87-A00-442-050 RES,330-1/2W J RP a
MAIN O R 0246 87-A00-442-050 RES,330-1/2W J RP a
MAIN X R 0247 88-130-100-080 RES,10-1/4W J a
MAIN X R 0248 88-130-100-080 RES,10-1/4W J a
CX-ZA65
LHSC
MAIN X R 0249 88-128-100-080 C-RES, 10-1/8W J a
MAIN X R 0250 88-121-100-080 RES,10-1/8W J a
MAIN X R 0265 88-128-222-080 C-RES, 2.2K-1/8W J a
MAIN X R 0266 88-128-222-080 C-RES, 2.2K-1/8W J a
MAIN X R 0301 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN X R 0302 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN X R 0303 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0304 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0305 88-108-224-080 C-RES,U 220K-1/16W J a
MAIN X R 0306 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0307 88-108-471-080 C-RES,U 470-1/16W J a
MAIN X R 0308 88-108-471-080 C-RES,U 470-1/16W J a
MAIN X R 0309 88-108-680-080 C-RES,U 68-1/16W J a
MAIN X R 0310 88-108-680-080 C-RES,U 68-1/16W J a
MAIN X R 0313 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0314 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0315 88-108-394-080 C-RES,U 390K-1/16W J a
MAIN X R 0316 88-108-394-080 C-RES,U 390K-1/16W J a
MAIN X R 0317 88-108-122-080 C-RES,U 1.2K-1/16W J a
MAIN X R 0318 88-108-122-080 C-RES,U 1.2K-1/16W J a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 19 –
CX-ZA65
LHSC
MAIN X R 0319 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0321 88-108-000-080 C-JUMPER,U a
MAIN X R 0322 88-108-000-080 C-JUMPER,U a
MAIN X R 0375 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0376 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0377 88-121-101-080 RES,100-1/8W J a
MAIN X R 0399 88-108-105-080 C-RES,U 1M-1/16W J a
MAIN X R 0401 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0402 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0403 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0404 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0405 88-108-823-080 C-RES,U 82K-1/16W J a
MAIN X R 0406 88-108-823-080 C-RES,U 82K-1/16W J a
MAIN X R 0407 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0408 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0409 88-108-122-080 C-RES,U 1.2K-1/16W J a
MAIN X R 0410 88-108-122-080 C-RES,U 1.2K-1/16W J a
MAIN X R 0411 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN X R 0412 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN X R 0413 88-108-222-080 C-RES,U 2.2K-1/16W J a
CX-ZA65
LHSC
MAIN X R 0414 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0415 88-108-681-080 C-RES,U 680-1/16W J a
MAIN X R 0416 88-108-681-080 C-RES,U 680-1/16W J a
MAIN X R 0417 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0418 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0419 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0420 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0421 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN X R 0422 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN X R 0423 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0424 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0453 88-108-152-080 C-RES,U 1.5K-1/16W J a
MAIN X R 0454 88-128-829-080 C-RES, 8.2-1/8W J a
MAIN X R 0455 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0456 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0457 88-130-100-080 RES,10-1/4W J a
MAIN X R 0458 88-121-104-080 RES,100K-1/8W J a
MAIN X R 0459 88-128-150-080 C-RES, 15-1/8W J a
MAIN X R 0460 88-140-100-080 RES,10-1/2W J a
MAIN X R 0511 88-121-472-080 RES,4.7K-1/8W J a
CX-ZA65
LHSC
MAIN X R 0512 88-121-472-080 RES,4.7K-1/8W J a
MAIN X R 0601 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0602 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0603 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0604 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0605 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0606 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0607 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0608 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0609 88-108-152-080 C-RES,U 1.5K-1/16W J a
MAIN X R 0610 88-121-152-080 RES,1.5K-1/8W J a
MAIN X R 0611 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0612 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0613 88-100-000-010 PLATING-JW, 0.58 SN95 a
MAIN X R 0614 88-100-000-010 PLATING-JW, 0.58 SN95 a
MAIN X R 0615 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0616 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0618 88-108-332-080 C-RES,U 3.3K-1/16W J a
MAIN X R 0619 88-108-273-080 C-RES,U 27K-1/16W J a
MAIN X R 0620 88-108-273-080 C-RES,U 27K-1/16W J a
CX-ZA65
LHSC
MAIN X R 0621 88-108-824-080 C-RES,U 820K-1/16W J a
MAIN X R 0622 88-108-824-080 C-RES,U 820K-1/16W J a
MAIN X R 0625 88-121-472-080 RES,4.7K-1/8W J a
MAIN X R 0626 88-121-103-080 RES,10K-1/8W J a
MAIN X R 0627 88-108-123-080 C-RES,U 12K-1/16W J a
MAIN X R 0628 88-121-332-080 RES,3.3K-1/8W J a
MAIN X R 0631 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0632 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0633 88-108-563-080 C-RES,U 56K-1/16W J a
MAIN X R 0634 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN X R 0635 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN X R 0637 88-108-182-080 C-RES,U 1.8K-1/16W J a
MAIN X R 0638 88-108-182-080 C-RES,U 1.8K-1/16W J a
MAIN X R 0639 88-108-273-080 C-RES,U 27K-1/16W J a
MAIN X R 0640 88-108-273-080 C-RES,U 27K-1/16W J a
MAIN X R 0649 88-108-562-080 C-RES,U 5.6K-1/16W J a
MAIN X R 0650 88-108-562-080 C-RES,U 5.6K-1/16W J a
MAIN X R 0653 88-108-000-080 C-JUMPER,U a
MAIN X R 0654 88-108-000-080 C-JUMPER,U a
MAIN X R 0661 88-108-123-080 C-RES,U 12K-1/16W J a

! = ! SAFETY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
– 20 –
CX-ZA65
LHSC
MAIN X R 0662 88-108-123-080 C-RES,U 12K-1/16W J a
MAIN O R 0790 87-012-286-080 C-CAP,U 0.01-25 K B a
MAIN X R 0791 88-108-000-080 C-JUMPER,U a
MAIN X R 0793 88-108-000-080 C-JUMPER,U a
MAIN X R 0795 88-108-000-080 C-JUMPER,U a
MAIN X R 0801 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0802 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN X R 0803 88-128-183-080 C-RES, 18K-1/8W J a
MAIN X R 0804 88-108-000-080 C-JUMPER,U a
MAIN X R 0805 88-108-332-080 C-RES,U 3.3K-1/16W J a
MAIN X R 0806 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0809 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0810 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0811 88-108-000-080 C-JUMPER,U a
MAIN X R 0812 88-108-000-080 C-JUMPER,U a
MAIN X R 0813 88-108-224-080 C-RES,U 220K-1/16W J a
MAIN X R 0814 88-108-105-080 C-RES,U 1M-1/16W J a
MAIN X R 0815 88-121-682-080 RES,6.8K-1/8W J a
MAIN X R 0818 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0821 88-108-000-080 C-JUMPER,U a
CX-ZA65
LHSC
MAIN X R 0823 88-108-333-080 C-RES,U 33K-1/16W J a
MAIN X R 0824 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0825 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0826 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN X R 0832 88-108-391-080 C-RES,U 390-1/16W J a
MAIN X R 0836 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0840 88-108-221-080 C-RES,U 220-1/16W J a
MAIN X R 0850 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0851 88-108-000-080 C-JUMPER,U a
MAIN X R 0852 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0853 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0854 88-108-331-080 C-RES,U 330-1/16W J a
MAIN X R 0855 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0856 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0857 88-108-181-080 C-RES,U 180-1/16W J a
MAIN X R 0858 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0860 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0903 88-108-471-080 C-RES,U 470-1/16W J a
MAIN X R 0904 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0905 88-108-564-080 C-RES,U 560K-1/16W J a
CX-ZA65
LHSC
MAIN X R 0907 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0908 88-108-121-080 C-RES,U 120-1/16W J a
MAIN X R 0909 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0910 88-108-822-080 C-RES,U 8.2K-1/16W J a
MAIN X R 0911 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0921 88-108-000-080 C-JUMPER,U a
MAIN X R 0945 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN X R 0962 88-121-221-080 RES,220-1/8W J a
MAIN X R 0963 88-108-330-080 C-RES,U 33-1/16W J a
MAIN X R 0975 88-108-562-080 C-RES,U 5.6K-1/16W J a
MAIN X R 0976 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0977 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0978 88-108-681-080 C-RES,U 680-1/16W J a
MAIN X R 0980 88-108-684-080 C-RES,U 680K-1/16W J a
MAIN X R 0981 88-121-471-080 RES,470-1/8W J a
MAIN X R 0982 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN X R 0983 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0984 88-121-181-080 RES,180-1/8W J a
MAIN X R 0985 88-121-471-080 RES,470-1/8W J a
MAIN X R 0986 88-108-222-080 C-RES,U 2.2K-1/16W J a
CX-ZA65
LHSC
MAIN X R 0987 88-121-472-080 RES,4.7K-1/8W J a
MAIN X R 0988 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0989 88-121-102-080 RES,1K-1/8W J a
MAIN X R 0990 88-108-563-080 C-RES,U 56K-1/16W J a
MAIN O R 0991 87-012-195-080 C-CAP,U 100P-50 J CH a
MAIN X R 0992 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0993 87-012-195-080 C-CAP,U 100P-50 J CH a
MAIN X R 0994 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0995 87-012-195-080 C-CAP,U 100P-50 J CH a
MAIN X R 0996 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0997 88-108-154-080 C-RES,U 150K-1/16W J a
MAIN X R 0998 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0999 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O SFR0451 87-024-435-080 SFR,33K H RH063MC a
MAIN O SFR0452 87-024-435-080 SFR,33K H RH063MC a
MAIN X SH 0901 88-ZA1-605-010 SHLD-CASE,IFT CAP-CASE a
MAIN O TH 0101 87-A91-042-080 C-THMS,100K 55001 a
MAIN O TH 0102 87-A91-042-080 C-THMS,100K 55001 a
MAIN O WH 0001 87-A90-510-010 HLDR,WIRE 2.5-9P a
MAIN O X 0992 87-A70-306-010 VIB,XTAL 4.500MHZ CSA-309ST a
