S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with "Revision Publishing" when it is issued.
CT-FX719
CT-FX729M
CT-FX929M
• TYPE: YU
S/M Code No. 09–991–401– 2T1
STEREO CAR
CASSETTE RECEIVER
NOTE: The characters in the suffix column indicate the part usage.
USTC ...................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 634 87-010-198-080 CAP, CHIP 0.022 A...................
C 704 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 703 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 701 87-010-314-080 C-CAP,S 22P-50V A...................
C 702 87-010-315-080 C-CAP,S 27P-50 CH A...................
C 751 87-010-178-080 CHIP CAP 1000P A...................
C 753 87-010-178-080 CHIP CAP 1000P A...................
C 754 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 752 87-010-322-080 C-CAP,S 100P-50 CH A...................
D 702 87-027-262-010 LEDE,TLR-124(RED) A...................
D 757 87-020-331-080 CHIP-DIODE,DAN202K ....................
D 758 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 754 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 755 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 752 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 762 87-020-331-080 CHIP-DIODE,DAN202K A...................
IC 701 87-A21-194-010 C-IC,UPD178016AGC-527-3B9 A...................
L 631 87-003-149-080 COIL,47UH A...................
Q 703 87-A30-287-040 C-TR,DTC114TKA A...................
SW 703 87-036-109-010 PUSH SWITCH A...................
SW 751 87-A91-152-010 SW,SL 1-1-2 SSSS212-11-A A...................
X 701 87-A70-175-010 VIB,XTAL 4.5MHZ AT-49 A...................
C 201 87-010-178-080 CHIP CAP 1000P A...................
C 202 87-010-178-080 CHIP CAP 1000P A...................
C 212 87-010-494-040 CAP,E 1-50 GAS A...................
C 211 87-010-494-040 CAP,E 1-50 GAS A...................
C 228 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 226 87-010-555-040 CAP,E 100-10 GAS A...................
C 237 87-010-198-080 CAP, CHIP 0.022 A...................
C 238 87-010-198-080 CAP, CHIP 0.022 A...................
C 233 87-010-498-040 CAP,E 10-16 GAS A...................
C 234 87-010-498-040 CAP,E 10-16 GAS A...................
C 235 87-010-555-040 CAP,E 100-10 GAS A...................
C 236 87-010-555-040 CAP,E 100-10 GAS A...................
C 251 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 253 87-010-497-040 CAP,E 4.7-35 GAS A...................
C 255 87-010-553-040 CAP,E 47-16 GAS A...................
C 254 87-010-553-040 CAP,E 47-16 GAS A...................
C 252 87-A10-924-040 CAP,E 47-16 BP SME A...................
CNA 251 8Z-KT1-634-010 CONN ASSY,10P DECK-1 A...................
CNA 252 8Z-KT1-635-010 CONN ASSY,5P DECK-2 A...................
D 251 87-017-932-080 ZENER,MTJ6.2B A...................
D 253 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 252 87-020-331-080 CHIP-DIODE,DAN202K A...................
IC 202 87-A21-191-010 IC,KIA6225S A...................
IC 251 88-KT1-604-010 IC,TA7291P A...................
Q 253 87-A30-283-040 C-TR,DTA114YKA A...................
Q 252 87-A30-287-040 C-TR,DTC114TKA A...................
Q 254 87-A30-287-040 C-TR,DTC114TKA A...................
Q 256 87-A30-287-040 C-TR,DTC114TKA A...................
Q 251 87-A30-295-010 TR,KRA226M A...................
Q 255 87-A30-295-010 TR,KRA226M A...................
C 101 87-010-178-080 CHIP CAP 1000P A...................
C 102 87-010-186-080 CAP,CHIP 4700P A...................
C 104 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 106 87-010-198-080 CAP, CHIP 0.022 A...................
C 108 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 103 87-010-490-040 CAP, ELECT 0.1-50 A...................
C 105 87-010-495-040 CAP,E 2.2-50 GAS A...................
C 107 87-010-552-040 CAP,E 22-16 GAS A...................
C 109 87-010-553-040 CAP,E 47-16 GAS A...................
C 114 87-010-178-080 CHIP CAP 1000P A...................
C 115 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 119 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 116 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 111 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 117 87-010-198-080 CAP, CHIP 0.022 A...................
C 110 87-010-553-040 CAP,E 47-16 GAS A...................
C 123 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 121 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 122 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 131 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 132 87-010-198-080 CAP, CHIP 0.022 A...................
C 133 87-010-553-040 CAP,E 47-16 GAS A...................
C 144 87-010-182-080 C-CAP,S 2200P-50 B ....................
C 143 87-010-182-080 C-CAP,S 2200P-50 B ....................
C 146 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 145 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 148 87-010-494-040 CAP,E 1-50 GAS A...................
C 147 87-010-494-040 CAP,E 1-50 GAS A...................
C 141 87-010-498-040 CAP,E 10-16 GAS A...................
C 142 87-010-498-040 CAP,E 10-16 GAS A...................
D 101 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 102 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 131 87-070-334-080 ZENER,MTZJ10B A...................
J 101 8Z-KT1-614-010 ANT,AW-002 A...................
ELECTRICAL MAIN PARTS LIST - 1<CT-FX719>
L 101 87-003-143-080 COIL 4.7 UH A...................
L 102 8Z-KT1-619-010 COIL,68MH K7-D A...................
Q 109 87-A30-287-040 C-TR,DTC114TKA A...................
Q 107 87-A30-288-040 C-TR,DTC114YKA A...................
Q 105 87-A30-289-040 C-TR,2SA1037AK(R) A...................
Q 101 89-324-122-080 TR,2SC2412K A...................
Q 103 89-324-122-080 TR,2SC2412K A...................
Q 102 89-324-122-080 TR,2SC2412K A...................
Q 106 89-324-122-080 TR,2SC2412K A...................
Q 104 89-324-122-080 TR,2SC2412K A...................
Q 131 87-A30-293-010 TR,KTC2804(Y) A...................
TU 101 8Z-KT1-631-010 TU UNIT, FAE347-A02 A...................
C 305 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 306 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 307 87-010-198-080 CAP, CHIP 0.022 A...................
C 308 87-010-198-080 CAP, CHIP 0.022 A...................
C 302 87-010-494-040 CAP,E 1-50 GAS A...................
C 301 87-010-494-040 CAP,E 1-50 GAS A...................
C 304 87-010-498-040 CAP,E 10-16 GAS A...................
C 303 87-010-498-040 CAP,E 10-16 GAS A...................
C 309 87-010-498-040 CAP,E 10-16 GAS A...................
C 310 87-010-498-040 CAP,E 10-16 GAS A...................
C 316 87-010-498-040 CAP,E 10-16 GAS A...................
C 315 87-010-498-040 CAP,E 10-16 GAS A...................
C 311 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 313 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 312 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 314 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 321 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 323 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 324 87-010-552-040 CAP,E 22-16 GAS A...................
C 322 87-010-555-040 CAP,E 100-10 GAS A...................
C 356 87-010-491-040 CAP,E 0.22-50 GAS A...................
C 355 87-010-491-040 CAP,E 0.22-50 GAS A...................
C 353 87-010-498-040 CAP,E 10-16 GAS A...................
C 351 87-010-498-040 CAP,E 10-16 GAS A...................
C 352 87-010-498-040 CAP,E 10-16 GAS A...................
C 354 87-010-498-040 CAP,E 10-16 GAS A...................
C 368 87-010-175-080 CAP 560P A...................
C 365 87-010-175-080 CAP 560P A...................
C 366 87-010-175-080 CAP 560P A...................
C 367 87-010-175-080 CAP 560P A...................
C 362 87-010-494-040 CAP,E 1-50 GAS A...................
C 363 87-010-494-040 CAP,E 1-50 GAS A...................
C 361 87-010-494-040 CAP,E 1-50 GAS A...................
C 364 87-010-494-040 CAP,E 1-50 GAS A...................
C 551 87-010-553-040 CAP,E 47-16 GAS A...................
C 590 87-010-178-080 CHIP CAP 1000P A...................
D 551 87-020-331-080 CHIP-DIODE,DAN202K A...................
IC 301 8Z-KT1-622-010 C-IC,LC75374E A...................
Q 351 87-A30-287-040 C-TR,DTC114TKA A...................
Q 352 87-A30-287-040 C-TR,DTC114TKA A...................
Q 553 87-A30-281-040 C-TR,DTC363TK A...................
Q 554 87-A30-281-040 C-TR,DTC363TK A...................
Q 551 87-A30-281-040 C-TR,DTC363TK A...................
Q 552 87-A30-281-040 C-TR,DTC363TK A...................
Q 559 87-A30-282-040 C-TR,DTA114TKA A...................
Q 560 87-A30-287-040 C-TR,DTC114TKA A...................
C 508 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 502 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 505 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 501 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 507 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 504 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 503 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 506 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 512 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 513 87-010-498-040 CAP,E 10-16 GAS A...................
C 511 8Z-KT1-633-090 CAP,E 3300U-16 PW A...................
IC 501 87-A20-876-010 IC,HA13158 A...................
C 601 87-010-935-040 CAP,E 220-16 M VR A...................
C 611 87-010-198-080 CAP, CHIP 0.022 A...................
C 612 87-016-459-040 CAP,E 470-10 SMG A...................
C 621 87-010-198-080 CAP, CHIP 0.022 A...................
C 622 87-010-555-040 CAP,E 100-10 GAS A...................
C 633 87-010-198-080 CAP, CHIP 0.022 A...................
C 631 87-010-198-080 CAP, CHIP 0.022 A...................
C 635 87-010-553-040 CAP,E 47-16 GAS A...................
C 632 87-016-039-090 CAP,DL 0.022F-5.5 Z 70 FM A...................
C 641 87-010-198-080 CAP, CHIP 0.022 A...................
C 653 87-010-555-040 CAP,E 100-10 GAS A...................
C 652 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 651 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 671 87-010-553-040 CAP,E 47-16 GAS A...................
C 882 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 881 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 883 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
CNA 881 8Z-KT1-620-010 CONN ASSY,8P ISO-BLACK ....................
CNA 882 8Z-KT1-621-010 CONN ASSY,8P ISO-WHITE ....................
CON 881 8Z-KT1-611-010 CONN,16P CAM-B51 A...................
D 611 87-070-334-080 ZENER,MTZJ10B A...................
D 621 87-017-931-080 ZENER,MTZJ5.6B A...................
ELECTRICAL MAIN PARTS LIST - 2<CT-FX719>
D 631 87-001-783-080 DIODE,1N4002 A...................
D 632 87-001-783-080 DIODE,1N4002 A...................
D 634 87-017-931-080 ZENER,MTZJ5.6B A...................
D 633 87-A40-002-080 ZENER,MTZJ5.1C A...................
D 635 87-A40-620-080 ZENER,MTZJ6.2A A...................
D 641 87-070-136-080 ZENER,MTZJ5.1B A...................
D 671 87-070-136-080 ZENER,MTZJ5.1B A...................
D 881 87-001-783-080 DIODE,1N4002 A...................
D 882 87-001-783-080 DIODE,1N4002 A...................
F 881 8Z-KT1-617-010 FUSE,10A 32V A...................
IC 641 88-KT1-606-080 IC,PST994D A...................
IC 651 88-KTD-604-010 IC,BA09T A...................
L 881 8Z-KT1-615-010 FLTR,AMORPHOUS -CHOKE A...................
PL 701 8Z-KT1-641-010 LAMP,T-3 A...................
Q 604 87-A30-287-040 C-TR,DTC114TKA A...................
Q 603 87-A30-287-040 C-TR,DTC114TKA A...................
Q 601 87-A30-290-010 TR,KTA1658(Y) A...................
Q 602 87-A30-290-010 TR,KTA1658(Y) A...................
Q 611 87-A30-291-010 TR,KTC4369(Y) A...................
Q 621 87-A30-292-010 TR,KTC3205(Y) A...................
Q 633 87-A30-287-040 C-TR,DTC114TKA A...................
Q 632 87-A30-287-040 C-TR,DTC114TKA A...................
Q 631 87-A30-292-010 TR,KTC3205(Y) A...................
Q 702 87-A30-287-040 C-TR,DTC114TKA A...................
Q 701 87-A30-294-040 C-TR,DTB123YK A...................
R 605 88-148-102-080 C-RES, 1K-1/2W J A...................
C 861 87-010-494-040 CAP,E 1-50 GAS A...................
C 862 87-010-494-040 CAP,E 1-50 GAS A...................
CON 851 8Z-KT1-613-010 CONN,16P CAM-C74 A...................
D 856 87-017-932-080 ZENER,MTJ6.2B A...................
D 852 87-017-932-080 ZENER,MTJ6.2B A...................
D 853 87-017-932-080 ZENER,MTJ6.2B A...................
D 855 87-017-932-080 ZENER,MTJ6.2B A...................
D 851 87-017-932-080 ZENER,MTJ6.2B A...................
D 857 87-017-932-080 ZENER,MTJ6.2B A...................
D 860 87-017-932-080 ZENER,MTJ6.2B A...................
SW 702 87-036-220-080 C-SW,T A...................
C 381 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 453 87-010-498-040 CAP,E 10-16 GAS A...................
C 454 87-010-498-040 CAP,E 10-16 GAS A...................
C 451 87-010-498-040 CAP,E 10-16 GAS A...................
C 452 87-010-498-040 CAP,E 10-16 GAS A...................
C 458 87-012-140-080 CAP 470P A...................
C 456 87-012-140-080 CAP 470P A...................
C 455 87-012-140-080 CAP 470P A...................
C 457 87-012-140-080 CAP 470P A...................
J 451 88-KTA-604-010 JACK,PIN 4P V-TYPE A...................
Q 381 89-324-122-080 TR,2SC2412K A...................
C 901 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 902 87-010-194-080 CAP, CHIP 0.047 A...................
C 903 87-010-194-080 CAP, CHIP 0.047 A...................
C 901 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 921 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
CON 901 8Z-KT1-612-010 CONN,16P CAM-C73 A...................
D 908 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 909 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 907 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 906 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 921 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
IC 902 87-A90-951-010 RCR UNIT,SBX1971-52 A...................
IC 901 88-KT1-608-010 C-IC,LC75854W A...................
J 901 87-A60-249-010 JACK,MOJ-B32 A...................
LCD 901 8Z-KT1-608-010 LCD,ZKT-3 A...................
LED 901 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 902 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 904 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 905 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 903 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 908 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 907 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 909 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 906 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 917 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 911 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 916 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 919 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 918 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 910 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 913 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 912 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 914 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 915 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 920 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 921 87-017-828-070 C-LED,SEL 1401C GRN A...................
PL 902 8Z-KT1-641-010 LAMP,T-3 A...................
PL 901 8Z-KT1-641-010 LAMP,T-3 A...................
SW 907 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 905 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 903 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 901 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 906 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 908 87-A91-159-010 SW,TACT SKHLAD A...................
ELECTRICAL MAIN PARTS LIST - 3<CT-FX719>
SW 904 87-A91-159-010 SW,TACT SKHLAD A...................
SW 902 87-A91-159-010 SW,TACT SKHLAD A...................
SW 909 87-A91-159-010 SW,TACT SKHLAD A...................
SW 916 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 918 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 911 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 917 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 912 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 919 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 915 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 914 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 913 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 910 87-A91-159-010 SW,TACT SKHLAD A...................
SW 921 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 920 87-A90-001-080 C-SW,TACT SKQMAL A...................
ELECTRICAL MAIN PARTS LIST - 4<CT-FX719>
NOTE: The characters in the suffix column indicate the part usage.
YUSTC ..................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 634 87-010-198-080 CAP, CHIP 0.022 A...................
C 703 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 704 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 701 87-010-314-080 C-CAP,S 22P-50V A...................
C 702 87-010-315-080 C-CAP,S 27P-50 CH A...................
C 705 87-010-490-040 CAP, ELECT 0.1-50 A...................
C 753 87-010-178-080 CHIP CAP 1000P A...................
C 751 87-010-178-080 CHIP CAP 1000P A...................
C 754 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 752 87-010-322-080 C-CAP,S 100P-50 CH A...................
D 701 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 702 87-027-262-010 LEDE,TLR-124(RED) A...................
D 758 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 752 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 755 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 754 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 762 87-020-331-080 CHIP-DIODE,DAN202K A...................
IC 701 87-A21-194-010 C-IC,UPD178016AGC-527-3B9 A...................
L 631 87-003-149-080 COIL,47UH A...................
Q 703 87-A30-287-040 C-TR,DTC114TKA A...................
SW 703 87-036-109-010 PUSH SWITCH A...................
SW 701 87-A91-155-010 SW,TACT SKHHLQ A...................
SW 751 87-A91-152-010 SW,SL 1-1-2 SSSS212-11-A A...................
X 701 87-A70-175-010 VIB,XTAL 4.5MHZ AT-49 A...................
C 201 87-010-178-080 CHIP CAP 1000P A...................
C 202 87-010-178-080 CHIP CAP 1000P A...................
C 211 87-010-494-040 CAP,E 1-50 GAS A...................
C 212 87-010-494-040 CAP,E 1-50 GAS A...................
C 228 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 226 87-010-555-040 CAP,E 100-10 GAS A...................
C 238 87-010-198-080 CAP, CHIP 0.022 A...................
C 237 87-010-198-080 CAP, CHIP 0.022 A...................
C 234 87-010-498-040 CAP,E 10-16 GAS A...................
C 233 87-010-498-040 CAP,E 10-16 GAS A...................
C 236 87-010-555-040 CAP,E 100-10 GAS A...................
C 235 87-010-555-040 CAP,E 100-10 GAS A...................
C 251 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 253 87-010-497-040 CAP,E 4.7-35 GAS A...................
C 254 87-010-553-040 CAP,E 47-16 GAS A...................
C 255 87-010-553-040 CAP,E 47-16 GAS A...................
C 252 87-A10-924-040 CAP,E 47-16 BP SME A...................
CNA 251 8Z-KT1-634-010 CONN ASSY,10P DECK-1 A...................
CNA 252 8Z-KT1-635-010 CONN ASSY,5P DECK-2 A...................
D 251 87-017-932-080 ZENER,MTJ6.2B A...................
D 252 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 253 87-020-331-080 CHIP-DIODE,DAN202K A...................
IC 202 87-A21-191-010 IC,KIA6225S A...................
IC 251 88-KT1-604-010 IC,TA7291P A...................
Q 253 87-A30-283-040 C-TR,DTA114YKA A...................
Q 252 87-A30-287-040 C-TR,DTC114TKA A...................
Q 256 87-A30-287-040 C-TR,DTC114TKA A...................
Q 254 87-A30-287-040 C-TR,DTC114TKA A...................
Q 255 87-A30-295-010 TR,KRA226M A...................
Q 251 87-A30-295-010 TR,KRA226M A...................
C 401 87-010-494-040 CAP,E 1-50 GAS A...................
C 402 87-010-494-040 CAP,E 1-50 GAS A...................
D 415 87-017-932-080 ZENER,MTJ6.2B A...................
D 416 87-017-932-080 ZENER,MTJ6.2B A...................
D 413 87-017-932-080 ZENER,MTJ6.2B A...................
D 412 87-017-932-080 ZENER,MTJ6.2B A...................
D 414 87-017-932-080 ZENER,MTJ6.2B A...................
D 417 87-017-932-080 ZENER,MTJ6.2B A...................
J 401 8Z-KT1-618-010 JACK,DIN 13 P TCS5116 A...................
Q 411 87-A30-283-040 C-TR,DTA114YKA A...................
Q 412 87-A30-287-040 C-TR,DTC114TKA A...................
C 101 87-010-178-080 CHIP CAP 1000P A...................
C 102 87-010-186-080 CAP,CHIP 4700P A...................
C 104 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 106 87-010-198-080 CAP, CHIP 0.022 A...................
C 108 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 103 87-010-490-040 CAP, ELECT 0.1-50 A...................
C 105 87-010-495-040 CAP,E 2.2-50 GAS A...................
C 107 87-010-552-040 CAP,E 22-16 GAS A...................
C 109 87-010-553-040 CAP,E 47-16 GAS A...................
C 114 87-010-178-080 CHIP CAP 1000P A...................
C 115 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 119 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 111 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 116 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 117 87-010-198-080 CAP, CHIP 0.022 A...................
C 110 87-010-553-040 CAP,E 47-16 GAS A...................
C 123 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 121 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 122 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 131 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 132 87-010-198-080 CAP, CHIP 0.022 A...................
ELECTRICAL MAIN PARTS LIST - 1<CT-FX729M>
C 133 87-010-553-040 CAP,E 47-16 GAS A...................
C 143 87-010-182-080 C-CAP,S 2200P-50 B ....................
C 144 87-010-182-080 C-CAP,S 2200P-50 B ....................
C 145 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 146 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 148 87-010-494-040 CAP,E 1-50 GAS A...................
C 147 87-010-494-040 CAP,E 1-50 GAS A...................
C 142 87-010-498-040 CAP,E 10-16 GAS A...................
C 141 87-010-498-040 CAP,E 10-16 GAS A...................
D 101 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 102 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 131 87-070-334-080 ZENER,MTZJ10B A...................
J 101 8Z-KT1-614-010 ANT,AW-002 A...................
L 101 87-003-143-080 COIL 4.7 UH A...................
L 102 8Z-KT1-619-010 COIL,68MH K7-D A...................
Q 109 87-A30-287-040 C-TR,DTC114TKA A...................
Q 107 87-A30-288-040 C-TR,DTC114YKA A...................
Q 105 87-A30-289-040 C-TR,2SA1037AK(R) A...................
Q 104 89-324-122-080 TR,2SC2412K A...................
Q 101 89-324-122-080 TR,2SC2412K A...................
Q 106 89-324-122-080 TR,2SC2412K A...................
Q 102 89-324-122-080 TR,2SC2412K A...................
Q 103 89-324-122-080 TR,2SC2412K A...................
Q 131 87-A30-293-010 TR,KTC2804(Y) A...................
TU 101 8Z-KT1-631-010 TU UNIT, FAE347-A02 A...................
C 305 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 306 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 308 87-010-198-080 CAP, CHIP 0.022 A...................
C 307 87-010-198-080 CAP, CHIP 0.022 A...................
C 301 87-010-494-040 CAP,E 1-50 GAS A...................
C 302 87-010-494-040 CAP,E 1-50 GAS A...................
C 309 87-010-498-040 CAP,E 10-16 GAS A...................
C 303 87-010-498-040 CAP,E 10-16 GAS A...................
C 304 87-010-498-040 CAP,E 10-16 GAS A...................
C 315 87-010-498-040 CAP,E 10-16 GAS A...................
C 310 87-010-498-040 CAP,E 10-16 GAS A...................
C 316 87-010-498-040 CAP,E 10-16 GAS A...................
C 314 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 311 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 313 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 312 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 323 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 321 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 324 87-010-552-040 CAP,E 22-16 GAS A...................
C 322 87-010-555-040 CAP,E 100-10 GAS A...................
C 355 87-010-491-040 CAP,E 0.22-50 GAS A...................
C 356 87-010-491-040 CAP,E 0.22-50 GAS A...................
C 353 87-010-498-040 CAP,E 10-16 GAS A...................
C 354 87-010-498-040 CAP,E 10-16 GAS A...................
C 351 87-010-498-040 CAP,E 10-16 GAS A...................
C 352 87-010-498-040 CAP,E 10-16 GAS A...................
C 367 87-010-175-080 CAP 560P A...................
C 368 87-010-175-080 CAP 560P A...................
C 365 87-010-175-080 CAP 560P A...................
C 366 87-010-175-080 CAP 560P A...................
C 363 87-010-494-040 CAP,E 1-50 GAS A...................
C 361 87-010-494-040 CAP,E 1-50 GAS A...................
C 362 87-010-494-040 CAP,E 1-50 GAS A...................
C 364 87-010-494-040 CAP,E 1-50 GAS A...................
C 551 87-010-553-040 CAP,E 47-16 GAS A...................
C 590 87-010-178-080 CHIP CAP 1000P A...................
D 551 87-020-331-080 CHIP-DIODE,DAN202K A...................
IC 301 8Z-KT1-622-010 C-IC,LC75374E A...................
Q 351 87-A30-287-040 C-TR,DTC114TKA A...................
Q 352 87-A30-287-040 C-TR,DTC114TKA A...................
Q 553 87-A30-281-040 C-TR,DTC363TK A...................
Q 554 87-A30-281-040 C-TR,DTC363TK A...................
Q 551 87-A30-281-040 C-TR,DTC363TK A...................
Q 552 87-A30-281-040 C-TR,DTC363TK A...................
Q 559 87-A30-282-040 C-TR,DTA114TKA A...................
Q 560 87-A30-287-040 C-TR,DTC114TKA A...................
C 508 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 506 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 507 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 503 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 501 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 505 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 504 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 502 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 512 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 513 87-010-498-040 CAP,E 10-16 GAS A...................
C 511 8Z-KT1-633-090 CAP,E 3300U-16 PW A...................
IC 501 87-A20-876-010 IC,HA13158 A...................
C 601 87-010-935-040 CAP,E 220-16 M VR A...................
C 611 87-010-198-080 CAP, CHIP 0.022 A...................
C 612 87-016-459-040 CAP,E 470-10 SMG A...................
C 621 87-010-198-080 CAP, CHIP 0.022 A...................
C 622 87-010-555-040 CAP,E 100-10 GAS A...................
C 631 87-010-198-080 CAP, CHIP 0.022 A...................
C 633 87-010-198-080 CAP, CHIP 0.022 A...................
C 635 87-010-553-040 CAP,E 47-16 GAS A...................
C 632 87-016-039-090 CAP,DL 0.022F-5.5 Z 70 FM A...................
ELECTRICAL MAIN PARTS LIST - 2<CT-FX729M>
C 641 87-010-198-080 CAP, CHIP 0.022 A...................
C 653 87-010-555-040 CAP,E 100-10 GAS A...................
C 652 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 651 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 671 87-010-553-040 CAP,E 47-16 GAS A...................
C 883 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 882 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 881 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
CON 881 8Z-KT1-611-010 CONN,16P CAM-B51 A...................
D 611 87-070-334-080 ZENER,MTZJ10B A...................
D 621 87-017-931-080 ZENER,MTZJ5.6B A...................
D 631 87-001-783-080 DIODE,1N4002 A...................
D 632 87-001-783-080 DIODE,1N4002 A...................
D 634 87-017-931-080 ZENER,MTZJ5.6B A...................
D 633 87-A40-002-080 ZENER,MTZJ5.1C A...................
D 635 87-A40-620-080 ZENER,MTZJ6.2A A...................
D 641 87-070-136-080 ZENER,MTZJ5.1B A...................
D 671 87-070-136-080 ZENER,MTZJ5.1B A...................
D 881 87-001-783-080 DIODE,1N4002 A...................
D 882 87-001-783-080 DIODE,1N4002 A...................
F 881 8Z-KT1-617-010 FUSE,10A 32V A...................
IC 641 88-KT1-606-080 IC,PST994D A...................
IC 651 88-KTD-604-010 IC,BA09T A...................
L 881 8Z-KT1-615-010 FLTR,AMORPHOUS -CHOKE A...................
PL 701 8Z-KT1-641-010 LAMP,T-3 A...................
Q 603 87-A30-287-040 C-TR,DTC114TKA A...................
Q 604 87-A30-287-040 C-TR,DTC114TKA A...................
Q 601 87-A30-290-010 TR,KTA1658(Y) A...................
Q 602 87-A30-290-010 TR,KTA1658(Y) A...................
Q 611 87-A30-291-010 TR,KTC4369(Y) A...................
Q 621 87-A30-292-010 TR,KTC3205(Y) A...................
Q 633 87-A30-287-040 C-TR,DTC114TKA A...................
Q 632 87-A30-287-040 C-TR,DTC114TKA A...................
Q 631 87-A30-292-010 TR,KTC3205(Y) A...................
Q 702 87-A30-287-040 C-TR,DTC114TKA A...................
Q 701 87-A30-294-040 C-TR,DTB123YK A...................
R 605 88-148-102-080 C-RES, 1K-1/2W J A...................
C 861 87-010-494-040 CAP,E 1-50 GAS A...................
C 862 87-010-494-040 CAP,E 1-50 GAS A...................
CON 851 8Z-KT1-613-010 CONN,16P CAM-C74 A...................
D 855 87-017-932-080 ZENER,MTJ6.2B A...................
D 857 87-017-932-080 ZENER,MTJ6.2B A...................
D 852 87-017-932-080 ZENER,MTJ6.2B A...................
D 851 87-017-932-080 ZENER,MTJ6.2B A...................
D 856 87-017-932-080 ZENER,MTJ6.2B A...................
D 853 87-017-932-080 ZENER,MTJ6.2B A...................
D 860 87-017-932-080 ZENER,MTJ6.2B A...................
SW 702 87-036-220-080 C-SW,T A...................
C 381 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 452 87-010-498-040 CAP,E 10-16 GAS A...................
C 451 87-010-498-040 CAP,E 10-16 GAS A...................
C 453 87-010-498-040 CAP,E 10-16 GAS A...................
C 454 87-010-498-040 CAP,E 10-16 GAS A...................
C 455 87-012-140-080 CAP 470P A...................
C 458 87-012-140-080 CAP 470P A...................
C 457 87-012-140-080 CAP 470P A...................
C 456 87-012-140-080 CAP 470P A...................
J 451 88-KTA-604-010 JACK,PIN 4P V-TYPE A...................
Q 381 89-324-122-080 TR,2SC2412K A...................
C 901 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 903 87-010-194-080 CAP, CHIP 0.047 A...................
C 902 87-010-194-080 CAP, CHIP 0.047 A...................
C 901 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 921 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
CON 901 8Z-KT1-612-010 CONN,16P CAM-C73 A...................
D 906 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 907 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 908 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 909 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 921 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
IC 902 87-A90-951-010 RCR UNIT,SBX1971-52 A...................
IC 901 88-KT1-608-010 C-IC,LC75854W A...................
J 901 87-A60-249-010 JACK,MOJ-B32 A...................
LCD 901 8Z-KT1-608-010 LCD,ZKT-3 A...................
LED 904 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 906 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 907 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 903 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 908 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 905 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 901 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 902 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 909 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 911 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 918 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 910 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 919 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 913 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 912 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 915 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 917 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 916 87-017-828-070 C-LED,SEL 1401C GRN A...................
ELECTRICAL MAIN PARTS LIST - 3<CT-FX729M>
LED 914 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 920 87-017-828-070 C-LED,SEL 1401C GRN A...................
LED 921 87-017-828-070 C-LED,SEL 1401C GRN A...................
PL 901 8Z-KT1-641-010 LAMP,T-3 A...................
PL 902 8Z-KT1-641-010 LAMP,T-3 A...................
SW 903 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 906 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 907 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 901 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 905 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 908 87-A91-159-010 SW,TACT SKHLAD A...................
SW 904 87-A91-159-010 SW,TACT SKHLAD A...................
SW 902 87-A91-159-010 SW,TACT SKHLAD A...................
SW 909 87-A91-159-010 SW,TACT SKHLAD A...................
SW 919 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 917 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 911 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 918 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 913 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 912 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 916 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 915 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 914 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 910 87-A91-159-010 SW,TACT SKHLAD A...................
SW 920 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 921 87-A90-001-080 C-SW,TACT SKQMAL A...................
88-KC4-052-010 CABI,UNIT HRC A...................
88-KC4-054-010 WINDOW,DIODE HRC A...................
88-KC4-055-010 BTN,ARRAY HRC A...................
88-KC4-056-010 HLDR,BAT. HRC A...................
88-KC4-058-010 CAP, FUNC. HRC A...................
8Z-KY1-011-010 CABI,TOP SW1 AL A...................
88-KC4-252-010 TERMINAL,(+) A...................
88-KC4-256-010 S-SCREW,VT2+2-4 BLK A...................
88-KC4-260-010 RING,DIODE -C A...................
88-KC4-261-010 TERMINAL,(-) SPR -C A...................
C 1 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 2 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 3 87-016-459-010 CAP,E 470-10 M SMG A...................
IC 1 88-KC4-621-040 C-IC,LC7461-8100 A...................
LED 1 87-A40-629-010 LED,SIR-34ST3F IR A...................
Q 1 89-328-734-080 C-TRANSISTOR,2SC2873Y A...................
SW 4 87-A91-233-080 C-SW,TACT SKQYAC A...................
SW 1 87-A91-233-080 C-SW,TACT SKQYAC A...................
SW 3 87-A91-233-080 C-SW,TACT SKQYAC A...................
SW 2 87-A91-233-080 C-SW,TACT SKQYAC A...................
SW 5 87-A91-233-080 C-SW,TACT SKQYAC A...................
W 1 8Z-KY1-604-010 F-CABLE,2P (LED) A...................
X 1 87-030-142-010 CERAMIC CSB 455E A...................
ELECTRICAL MAIN PARTS LIST - 4<CT-FX729M>
ELECTRICAL MAIN PARTS LIST - 1<CT-FX929M>
NOTE: The characters in the suffix column indicate the part usage.
YUSTC ..................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 634 87-010-198-080 CAP, CHIP 0.022 A...................
C 704 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 703 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 701 87-010-314-080 C-CAP,S 22P-50V A...................
C 702 87-010-315-080 C-CAP,S 27P-50 CH A...................
C 705 87-010-490-040 CAP, ELECT 0.1-50 A...................
C 751 87-010-178-080 CHIP CAP 1000P A...................
C 753 87-010-178-080 CHIP CAP 1000P A...................
C 754 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 752 87-010-322-080 C-CAP,S 100P-50 CH A...................
D 701 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 702 87-027-262-010 LEDE,TLR-124(RED) A...................
D 759 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 756 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 753 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 752 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 755 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 758 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 754 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 762 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 761 87-020-331-080 CHIP-DIODE,DAN202K A...................
IC 701 87-A21-194-010 C-IC,UPD178016AGC-527-3B9 A...................
L 631 87-003-149-080 COIL,47UH A...................
Q 703 87-A30-287-040 C-TR,DTC114TKA A...................
SW 703 87-036-109-010 PUSH SWITCH A...................
SW 701 87-A91-155-010 SW,TACT SKHHLQ A...................
SW 751 87-A91-152-010 SW,SL 1-1-2 SSSS212-11-A A...................
X 701 87-A70-175-010 VIB,XTAL 4.5MHZ AT-49 A...................
C 201 87-010-178-080 CHIP CAP 1000P A...................
C 202 87-010-178-080 CHIP CAP 1000P A...................
C 205 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 206 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 209 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 204 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 203 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 208 87-010-495-040 CAP,E 2.2-50 GAS A...................
C 207 87-010-495-040 CAP,E 2.2-50 GAS A...................
C 210 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 211 87-010-494-040 CAP,E 1-50 GAS A...................
C 212 87-010-494-040 CAP,E 1-50 GAS A...................
C 227 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 222 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 223 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 221 87-010-492-040 CAP,E 0.33-50 GAS A...................
C 225 87-010-494-040 CAP,E 1-50 GAS A...................
C 224 87-010-494-040 CAP,E 1-50 GAS A...................
C 226 87-010-555-040 CAP,E 100-10 GAS A...................
C 251 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 253 87-010-497-040 CAP,E 4.7-35 GAS A...................
C 255 87-010-553-040 CAP,E 47-16 GAS A...................
C 254 87-010-553-040 CAP,E 47-16 GAS A...................
C 252 87-A10-924-040 CAP,E 47-16 BP SME A...................
CNA 251 8Z-KT1-634-010 CONN ASSY,10P DECK-1 A...................
CNA 252 8Z-KT1-635-010 CONN ASSY,5P DECK-2 A...................
D 251 87-017-932-080 ZENER,MTJ6.2B A...................
D 252 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 253 87-020-331-080 CHIP-DIODE,DAN202K A...................
IC 201 87-A20-233-010 C-IC,HA12192F A...................
IC 251 88-KT1-604-010 IC,TA7291P A...................
Q 201 87-A30-287-040 C-TR,DTC114TKA A...................
Q 253 87-A30-283-040 C-TR,DTA114YKA A...................
Q 254 87-A30-287-040 C-TR,DTC114TKA A...................
Q 252 87-A30-287-040 C-TR,DTC114TKA A...................
Q 256 87-A30-287-040 C-TR,DTC114TKA A...................
Q 255 87-A30-295-010 TR,KRA226M A...................
Q 251 87-A30-295-010 TR,KRA226M A...................
SFR 202 87-024-433-080 SFR,10K RH063EC A...................
SFR 201 87-024-433-080 SFR,10K RH063EC A...................
C 402 87-010-494-040 CAP,E 1-50 GAS A...................
C 401 87-010-494-040 CAP,E 1-50 GAS A...................
D 412 87-017-932-080 ZENER,MTJ6.2B A...................
D 416 87-017-932-080 ZENER,MTJ6.2B A...................
D 414 87-017-932-080 ZENER,MTJ6.2B A...................
D 417 87-017-932-080 ZENER,MTJ6.2B A...................
D 413 87-017-932-080 ZENER,MTJ6.2B A...................
D 415 87-017-932-080 ZENER,MTJ6.2B A...................
J 401 8Z-KT1-618-010 JACK,DIN 13 P TCS5116 A...................
Q 411 87-A30-283-040 C-TR,DTA114YKA A...................
Q 412 87-A30-287-040 C-TR,DTC114TKA A...................
C 101 87-010-178-080 CHIP CAP 1000P A...................
C 102 87-010-186-080 CAP,CHIP 4700P A...................
C 104 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 106 87-010-198-080 CAP, CHIP 0.022 A...................
C 108 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 103 87-010-490-040 CAP, ELECT 0.1-50 A...................
C 105 87-010-495-040 CAP,E 2.2-50 GAS A...................
ELECTRICAL MAIN PARTS LIST - 2<CT-FX929M>
C 107 87-010-552-040 CAP,E 22-16 GAS A...................
C 109 87-010-553-040 CAP,E 47-16 GAS A...................
C 114 87-010-178-080 CHIP CAP 1000P A...................
C 115 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 119 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 116 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 111 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 117 87-010-198-080 CAP, CHIP 0.022 A...................
C 110 87-010-553-040 CAP,E 47-16 GAS A...................
C 123 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 122 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 121 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 131 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 132 87-010-198-080 CAP, CHIP 0.022 A...................
C 133 87-010-553-040 CAP,E 47-16 GAS A...................
C 143 87-010-182-080 C-CAP,S 2200P-50 B ....................
C 144 87-010-182-080 C-CAP,S 2200P-50 B ....................
C 145 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 146 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 148 87-010-494-040 CAP,E 1-50 GAS A...................
C 147 87-010-494-040 CAP,E 1-50 GAS A...................
C 141 87-010-498-040 CAP,E 10-16 GAS A...................
C 142 87-010-498-040 CAP,E 10-16 GAS A...................
D 102 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 101 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 131 87-070-334-080 ZENER,MTZJ10B A...................
J 101 8Z-KT1-614-010 ANT,AW-002 A...................
L 101 87-003-143-080 COIL 4.7 UH A...................
L 102 8Z-KT1-619-010 COIL,68MH K7-D A...................
Q 109 87-A30-287-040 C-TR,DTC114TKA A...................
Q 107 87-A30-288-040 C-TR,DTC114YKA A...................
Q 105 87-A30-289-040 C-TR,2SA1037AK(R) A...................
Q 101 89-324-122-080 TR,2SC2412K A...................
Q 104 89-324-122-080 TR,2SC2412K A...................
Q 102 89-324-122-080 TR,2SC2412K A...................
Q 106 89-324-122-080 TR,2SC2412K A...................
Q 103 89-324-122-080 TR,2SC2412K A...................
Q 131 87-A30-293-010 TR,KTC2804(Y) A...................
TU 101 8Z-KT1-631-010 TU UNIT, FAE347-A02 A...................
C 306 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 305 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 308 87-010-198-080 CAP, CHIP 0.022 A...................
C 307 87-010-198-080 CAP, CHIP 0.022 A...................
C 301 87-010-494-040 CAP,E 1-50 GAS A...................
C 302 87-010-494-040 CAP,E 1-50 GAS A...................
C 304 87-010-498-040 CAP,E 10-16 GAS A...................
C 303 87-010-498-040 CAP,E 10-16 GAS A...................
C 309 87-010-498-040 CAP,E 10-16 GAS A...................
C 316 87-010-498-040 CAP,E 10-16 GAS A...................
C 310 87-010-498-040 CAP,E 10-16 GAS A...................
C 315 87-010-498-040 CAP,E 10-16 GAS A...................
C 311 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 313 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 312 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 314 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 323 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 321 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 324 87-010-552-080 CAP,E 22-16 GAS A...................
C 322 87-010-555-040 CAP,E 100-10 GAS A...................
C 355 87-010-491-040 CAP,E 0.22-50 GAS A...................
C 356 87-010-491-040 CAP,E 0.22-50 GAS A...................
C 353 87-010-498-040 CAP,E 10-16 GAS A...................
C 351 87-010-498-040 CAP,E 10-16 GAS A...................
C 352 87-010-498-040 CAP,E 10-16 GAS A...................
C 354 87-010-498-040 CAP,E 10-16 GAS A...................
C 366 87-010-175-080 CAP 560P A...................
C 367 87-010-175-080 CAP 560P A...................
C 368 87-010-175-080 CAP 560P A...................
C 365 87-010-175-080 CAP 560P A...................
C 364 87-010-494-040 CAP,E 1-50 GAS A...................
C 361 87-010-494-040 CAP,E 1-50 GAS A...................
C 362 87-010-494-040 CAP,E 1-50 GAS A...................
C 363 87-010-494-040 CAP,E 1-50 GAS A...................
C 551 87-010-553-040 CAP,E 47-16 GAS A...................
C 590 87-012-349-080 C-CAP,S 1000P-50 CH A...................
D 551 87-020-331-080 CHIP-DIODE,DAN202K A...................
IC 301 8Z-KT1-622-010 C-IC,LC75374E A...................
Q 352 87-A30-287-040 C-TR,DTC114TKA A...................
Q 351 87-A30-287-040 C-TR,DTC114TKA A...................
Q 553 87-A30-281-040 C-TR,DTC363TK A...................
Q 554 87-A30-281-040 C-TR,DTC363TK A...................
Q 552 87-A30-281-040 C-TR,DTC363TK A...................
Q 551 87-A30-281-040 C-TR,DTC363TK A...................
Q 559 87-A30-282-040 C-TR,DTA114TKA A...................
Q 560 87-A30-287-040 C-TR,DTC114TKA A...................
C 504 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 508 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 507 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 501 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 503 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 502 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 506 87-010-322-080 C-CAP,S 100P-50 CH A...................
ELECTRICAL MAIN PARTS LIST - 3<CT-FX929M>
C 505 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 512 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 513 87-010-498-040 CAP,E 10-16 GAS A...................
C 511 8Z-KT1-633-090 CAP,E 3300U-16 PW A...................
IC 501 87-A20-876-010 IC,HA13158 A...................
C 601 87-010-935-040 CAP,E 220-16 M VR A...................
C 611 87-010-198-080 CAP, CHIP 0.022 A...................
C 612 87-016-459-040 CAP,E 470-10 SMG A...................
C 621 87-010-198-080 CAP, CHIP 0.022 A...................
C 622 87-010-555-040 CAP,E 100-10 GAS A...................
C 631 87-010-198-080 CAP, CHIP 0.022 A...................
C 633 87-010-198-080 CAP, CHIP 0.022 A...................
C 635 87-010-553-040 CAP,E 47-16 GAS A...................
C 632 87-016-039-090 CAP,DL 0.022F-5.5 Z 70 FM A...................
C 641 87-010-198-080 CAP, CHIP 0.022 A...................
C 653 87-010-555-040 CAP,E 100-10 GAS A...................
C 652 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 651 87-A11-177-080 C-CAP,S 0.15-16 K B A...................
C 661 87-010-198-080 CAP, CHIP 0.022 A...................
C 662 87-010-555-040 CAP,E 100-10 GAS A...................
C 671 87-010-553-040 CAP,E 47-16 GAS A...................
C 883 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 882 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 881 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
CON 881 8Z-KT1-611-010 CONN,16P CAM-B51 A...................
D 611 87-070-334-080 ZENER,MTZJ10B A...................
D 621 87-017-931-080 ZENER,MTZJ5.6B A...................
D 632 87-001-783-080 DIODE,1N4002 A...................
D 631 87-001-783-080 DIODE,1N4002 A...................
D 634 87-017-931-080 ZENER,MTZJ5.6B A...................
D 641 87-070-136-080 ZENER,MTZJ5.1B A...................
D 663 87-017-931-080 ZENER,MTZJ5.6B A...................
D 661 87-070-335-080 ZENER,MTZJ8.2B A...................
D 662 87-A40-337-080 ZENER,MTZJ 6.8B A...................
D 671 87-070-136-080 ZENER,MTZJ5.1B A...................
D 881 87-001-783-080 DIODE,1N4002 A...................
D 882 87-001-783-080 DIODE,1N4002 A...................
F 881 8Z-KT1-617-010 FUSE,10A 32V A...................
IC 641 88-KT1-606-080 IC,PST994D A...................
IC 651 88-KTD-604-010 IC,BA09T A...................
L 881 8Z-KT1-615-010 FLTR,AMORPHOUS -CHOKE A...................
PL 701 8Z-KT1-641-010 LAMP,T-3 A...................
Q 604 87-A30-287-040 C-TR,DTC114TKA A...................
Q 603 87-A30-287-040 C-TR,DTC114TKA A...................
Q 602 87-A30-290-010 TR,KTA1658(Y) A...................
Q 601 87-A30-290-010 TR,KTA1658(Y) A...................
Q 611 87-A30-291-010 TR,KTC4369(Y) A...................
Q 621 87-A30-292-010 TR,KTC3205(Y) A...................
Q 631 87-A30-292-010 TR,KTC3205(Y) A...................
Q 662 87-A30-287-040 C-TR,DTC114TKA A...................
Q 663 87-A30-287-040 C-TR,DTC114TKA A...................
Q 661 87-A30-292-010 TR,KTC3205(Y) A...................
Q 702 87-A30-287-040 C-TR,DTC114TKA A...................
Q 701 87-A30-294-040 C-TR,DTB123YK A...................
R 605 88-148-102-080 C-RES, 1K-1/2W J A...................
C 862 87-010-494-040 CAP,E 1-50 GAS A...................
C 861 87-010-494-040 CAP,E 1-50 GAS A...................
CON 851 8Z-KT1-613-010 CONN,16P CAM-C74 A...................
D 856 87-017-932-080 ZENER,MTJ6.2B A...................
D 853 87-017-932-080 ZENER,MTJ6.2B A...................
D 854 87-017-932-080 ZENER,MTJ6.2B A...................
D 851 87-017-932-080 ZENER,MTJ6.2B A...................
D 857 87-017-932-080 ZENER,MTJ6.2B A...................
D 855 87-017-932-080 ZENER,MTJ6.2B A...................
D 852 87-017-932-080 ZENER,MTJ6.2B A...................
SW 702 87-036-220-080 C-SW,T A...................
C 459 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 452 87-010-498-040 CAP,E 10-16 GAS A...................
C 453 87-010-498-040 CAP,E 10-16 GAS A...................
C 454 87-010-498-040 CAP,E 10-16 GAS A...................
C 451 87-010-498-040 CAP,E 10-16 GAS A...................
C 457 87-012-140-080 CAP 470P A...................
C 458 87-012-140-080 CAP 470P A...................
C 456 87-012-140-080 CAP 470P A...................
C 455 87-012-140-080 CAP 470P A...................
C 461 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 462 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 460 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 468 87-010-552-040 CAP,E 22-16 GAS A...................
C 467 87-010-553-040 CAP,E 47-16 GAS A...................
C 466 87-010-805-080 CAP, S 1-16 A...................
C 465 87-010-805-080 CAP, S 1-16 A...................
C 464 87-010-805-080 CAP, S 1-16 A...................
C 463 87-010-805-080 CAP, S 1-16 A...................
C 805 87-010-194-080 CAP, CHIP 0.047 A...................
C 804 87-010-495-040 CAP,E 2.2-50 GAS A...................
C 803 87-010-497-040 CAP,E 4.7-35 GAS A...................
C 806 87-010-497-040 CAP,E 4.7-35 GAS A...................
C 801 87-010-553-040 CAP,E 47-16 GAS A...................
C 807 87-010-553-040 CAP,E 47-16 GAS A...................
C 802 87-010-935-040 CAP,E 220-16 M VR A...................
IC 451 87-001-611-080 IC,NJM3403M A...................
ELECTRICAL MAIN PARTS LIST - 4<CT-FX929M>
IC 801 87-002-689-080 IC,NJM2072M A...................
J 451 88-KTA-604-010 JACK,PIN 4P V-TYPE A...................
MIC 801 8Z-KT1-643-090 MIC,EMC KUC2123-040245DB A...................
C 902 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 901 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 904 87-010-805-080 CAP, S 1-16 A...................
C 903 87-010-805-080 CAP, S 1-16 A...................
CON 901 8Z-KT1-612-010 CONN,16P CAM-C73 A...................
D 901 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 903 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 904 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 905 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 902 87-020-585-080 CHIP-ZENER,02CZ6.2Y A...................
D 922 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 921 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 929 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 925 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 924 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 927 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 928 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 923 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 926 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 933 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 934 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 937 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 939 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 932 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 935 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 931 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 938 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 936 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 930 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 940 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
D 941 87-A40-621-040 C-LED,SEC2484C GR/AMB A...................
IC 902 87-A90-951-010 RCR UNIT,SBX1971-52 A...................
IC 901 8Z-KT1-623-010 C-IC,UPD16432B A...................
J 901 87-A60-249-010 JACK,MOJ-B32 A...................
LCD 901 8Z-KT1-607-010 LCD,ZKT-1 A...................
PL 901 8Z-KT1-651-010 LAMP,9V-85MA A...................
PL 902 8Z-KT1-651-010 LAMP,9V-85MA A...................
SW 905 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 908 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 909 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 902 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 907 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 901 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 904 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 903 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 906 87-A91-159-010 SW,TACT SKHLAD A...................
SW 911 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 918 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 916 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 912 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 914 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 917 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 915 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 913 87-A91-159-010 SW,TACT SKHLAD A...................
SW 919 87-A91-159-010 SW,TACT SKHLAD A...................
SW 910 87-A91-159-010 SW,TACT SKHLAD A...................
SW 920 87-A90-001-080 C-SW,TACT SKQMAL A...................
SW 921 87-A91-159-010 SW,TACT SKHLAD A...................
SW 931 87-036-127-010 SLIDE SWITCH A...................
88-KC4-052-010 CABI,UNIT HRC A...................
88-KC4-054-010 WINDOW,DIODE HRC A...................
88-KC4-055-010 BTN,ARRAY HRC A...................
88-KC4-056-010 HLDR,BAT. HRC A...................
88-KC4-058-010 CAP, FUNC. HRC A...................
8Z-KY1-011-010 CABI,TOP SW1 AL A...................
88-KC4-252-010 TERMINAL,(+) A...................
88-KC4-256-010 S-SCREW,VT2+2-4 BLK A...................
88-KC4-260-010 RING,DIODE -C A...................
88-KC4-261-010 TERMINAL,(-) SPR -C A...................
C 1 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 2 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 3 87-016-459-010 CAP,E 470-10 M SMG A...................
D 1 87-A40-629-010 LED,SIR-34ST3F IR A...................
IC 1 88-KC4-621-040 C-IC,LC7461-8100 A...................
Q 1 89-328-734-080 C-TRANSISTOR,2SC2873Y A...................
S 1 87-A91-233-080 C-SW,TACT SKQYAC A...................
S 4 87-A91-233-080 C-SW,TACT SKQYAC A...................
S 3 87-A91-233-080 C-SW,TACT SKQYAC A...................
S 2 87-A91-233-080 C-SW,TACT SKQYAC A...................
S 5 87-A91-233-080 C-SW,TACT SKQYAC A...................
W 1 8Z-KY1-604-010 F-CABLE,2P (LED) A...................
X 1 87-030-142-010 CERAMIC CSB 455E A...................
NOTE: The characters in the suffix column indicate the part usage.
USTC ...................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-KT1-002-010 CABI,REAR F-T A...................
8Z-KT1-021-010 CABI,BASE F-T A...................
8Z-KT1-022-010 CABI,TRIM F-T A...................
8Z-KT1-023-010 DOOR,CASS A...................
8Z-KT5-004-010 CABI,FRONT F -T5 A...................
8Z-KT8-001-010 WINDOW,LCD FX719 A...................
8Z-KT8-002-010 WINDOW,LCD FX7019 ....................
8Z-KT8-003-010 RING,OVAL RTF -T A...................
8Z-KT1-007-010 BTN,+/- -T A...................
8Z-KT1-008-010 BTN,SEL -T A...................
8Z-KT1-009-010 BTN,MUTE -T A...................
8Z-KT1-010-010 BTN,H-BASS -T A...................
8Z-KT1-011-010 BTN,U/D -T A...................
8Z-KT1-012-010 BTN,DRV -T A...................
8Z-KT1-016-010 BTN,OPEN F -T A...................
8Z-KT1-018-010 BTN,EJ F-T A...................
8Z-KT3-002-010 BTN,P.SET -T3 A...................
8Z-KT4-003-010 BTN,TWIN BAND -T A...................
8Z-KT5-003-010 BTN,TETRA DALD -T A...................
8Z-KT5-019-010 BTN,M.INF -T A...................
8Z-KT1-201-010 ARM,F-LOCK -T A...................
8Z-KT1-202-010 LEVER,F-OPEN -T A...................
8Z-KT1-203-010 GEAR,FLAP -T A...................
8Z-KT1-204-010 HLDR,F-HOOK L -T A...................
8Z-KT1-205-010 HLDR,F-HOOK R -T A...................
8Z-KT1-206-010 CASE,LCD LENS F -T A...................
8Z-KT1-207-010 LENS,LCD F -T A...................
8Z-KT1-208-010 LENS,BASE -T A...................
8Z-KT1-209-010 LENS,IR -T A...................
8Z-KT1-211-010 COVER, TOP -T A...................
8Z-KT1-212-010 COVER, BOTTOM -T A...................
8Z-KT1-215-010 HLDR,P-IC -T A...................
8Z-KT1-216-010 HLDR,DECK CDS522 A...................
8Z-KT1-219-010 HLDR,TR -T A...................
8Z-KT1-220-010 HLDR,JACK F -T A...................
8Z-KT1-222-010 ARM,SENSOR F -T A...................
8Z-KT1-225-010 HLDR,LCD F -T A...................
8Z-KT1-229-010 HLDR,DAMPER F ASS’Y-T A...................
8Z-KT1-230-010 HLDR,DFP ASS’Y-T A...................
8Z-KT1-235-010 COVER, CONN.BLIND -T ....................
8Z-KT1-236-010 CAP,LAMP BLU A...................
8Z-KT1-237-010 CAP,LAMP GRN A...................
8Z-KT1-241-010 SPR-C,DFP HOOK F -T A...................
8Z-KT1-242-010 SPR-C,OPEN BTN F -T A...................
8Z-KT1-243-010 SPR-T,FLAP -T A...................
8Z-KT1-244-010 SPR-T,DOOR Z A...................
8Z-KT1-248-010 SPR-T,SENSOR F -T A...................
8Z-KT1-250-010 OIL-DMPR,100 A...................
8Z-KT1-257-010 HLDR,ISO-WIRE -T ....................
8Z-KT1-260-010 SPR-T,F.LOCK-T A...................
8Z-KT4-201-010 COVER, CD BLIND -T A...................
8Z-KT5-020-010 HLDR,M.INF -T A...................
8Z-KT5-201-010 COVER, ISO BLIND -T A...................
87-251-073-410 SCREW,U+2.6-6 A...................
87-251-075-410 U+2.6-10 A...................
87-251-096-410 U+3-10 A...................
87-253-034-410 U+2-5 BLK A...................
87-B10-210-010 UT2+3.0-6.0 W/0 SLOT (BH TAP) A...................
88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK A...................
8Z-KT1-246-010 S-SCREW,2.0-2.5 -10 A...................
8Z-KT1-247-010 S-SCREW,GEAR2.0-1.8 -4.2 A...................
8Z-KT1-253-010 S-SCREW,PT 2*8 BH+ BLK A...................
8Z-KT1-254-010 S-SCREW,PT 2*5 BH+ BLK A...................
MECHANICAL PARTS LIST - 1<CT-FX719>
MECHANICAL PARTS LIST - 1<CT-FX729M>
NOTE: The characters in the suffix column indicate the part usage.
YUSTC ..................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-KT1-002-010 CABI,REAR F-T A...................
8Z-KT1-017-010 RING,OVAL -T A...................
8Z-KT1-021-010 CABI,BASE F-T A...................
8Z-KT1-022-010 CABI,TRIM F-T A...................
8Z-KT1-023-010 DOOR,CASS A...................
8Z-KT5-004-010 CABI,FRONT F -T5 A...................
8Z-KT7-001-010 WINDOW,LCD FX729M A...................
8Z-KT7-002-010 WINDOW,LCD FX7029M ....................
8Z-KT7-006-010 WINDOW,LCD FX729M YH ....................
8Z-KT1-007-010 BTN,+/- -T A...................
8Z-KT1-008-010 BTN,SEL -T A...................
8Z-KT1-009-010 BTN,MUTE -T A...................
8Z-KT1-010-010 BTN,H-BASS -T A...................
8Z-KT1-011-010 BTN,U/D -T A...................
8Z-KT1-012-010 BTN,DRV -T A...................
8Z-KT1-013-010 BTN,TWIN -T A...................
8Z-KT1-016-010 BTN,OPEN F -T A...................
8Z-KT1-018-010 BTN,EJ F-T A...................
8Z-KT3-002-010 BTN,P.SET -T3 A...................
8Z-KT5-003-010 BTN,TETRA DALD -T A...................
8Z-KT5-019-010 BTN,M.INF -T A...................
8Z-KT1-201-010 ARM,F-LOCK -T A...................
8Z-KT1-202-010 LEVER,F-OPEN -T A...................
8Z-KT1-203-010 GEAR,FLAP -T A...................
8Z-KT1-204-010 HLDR,F-HOOK L -T A...................
8Z-KT1-205-010 HLDR,F-HOOK R -T A...................
8Z-KT1-206-010 CASE,LCD LENS F -T A...................
8Z-KT1-207-010 LENS,LCD F -T A...................
8Z-KT1-208-010 LENS,BASE -T A...................
8Z-KT1-209-010 LENS,IR -T A...................
8Z-KT1-211-010 COVER, TOP -T A...................
8Z-KT1-212-010 COVER, BOTTOM -T A...................
8Z-KT1-215-010 HLDR,P-IC -T A...................
8Z-KT1-216-010 HLDR,DECK CDS522 A...................
8Z-KT1-218-010 HLDR,CD -T A...................
8Z-KT1-219-010 HLDR,TR -T A...................
8Z-KT1-220-010 HLDR,JACK F -T A...................
8Z-KT1-222-010 ARM,SENSOR F -T A...................
8Z-KT1-225-010 HLDR,LCD F -T A...................
8Z-KT1-229-010 HLDR,DAMPER F ASS’Y-T A...................
8Z-KT1-230-010 HLDR,DFP ASS’Y-T A...................
8Z-KT1-236-010 CAP,LAMP BLU A...................
8Z-KT1-237-010 CAP,LAMP GRN A...................
8Z-KT1-241-010 SPR-C,DFP HOOK F -T A...................
8Z-KT1-242-010 SPR-C,OPEN BTN F -T A...................
8Z-KT1-243-010 SPR-T,FLAP -T A...................
8Z-KT1-244-010 SPR-T,DOOR Z A...................
8Z-KT1-248-010 SPR-T,SENSOR F -T A...................
8Z-KT1-250-010 OIL-DMPR,100 A...................
8Z-KT1-260-010 SPR-T,F.LOCK-T A...................
8Z-KT5-020-010 HLDR,M.INF -T A...................
8Z-KT5-201-010 COVER, ISO BLIND -T A...................
87-251-073-410 SCREW,U+2.6-6 A...................
87-251-075-410 U+2.6-10 A...................
87-251-096-410 U+3-10 A...................
87-253-034-410 U+2-5 BLK A...................
87-B10-210-010 UT2+3.0-6.0 W/0 SLOT (BH TAP) A...................
88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK A...................
8Z-KT1-246-010 S-SCREW,2.0-2.5 -10 A...................
8Z-KT1-247-010 S-SCREW,GEAR2.0-1.8 -4.2 A...................
8Z-KT1-253-010 S-SCREW,PT 2*8 BH+ BLK A...................
8Z-KT1-254-010 S-SCREW,PT 2*5 BH+ BLK A...................
88-KC4-052-010 CABI,UNIT HRC A...................
88-KC4-054-010 WINDOW,DIODE HRC A...................
88-KC4-055-010 BTN,ARRAY HRC A...................
88-KC4-056-010 HLDR,BAT. HRC A...................
88-KC4-058-010 CAP, FUNC. HRC A...................
8Z-KY1-011-010 CABI,TOP SW1 AL A...................
88-KC4-252-010 TERMINAL,(+) A...................
88-KC4-256-010 S-SCREW,VT2+2-4 BLK A...................
88-KC4-260-010 RING,DIODE -C A...................
88-KC4-261-010 TERMINAL,(-) SPR -C A...................
W 1 8Z-KY1-604-010 F-CABLE,2P (LED) A...................
MECHANICAL PARTS LIST - 1<CT-FX929M>
NOTE: The characters in the suffix column indicate the part usage.
YUSTC ..................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-KT1-002-010 CABI,REAR F-T A...................
8Z-KT1-017-010 RING,OVAL -T A...................
8Z-KT1-021-010 CABI,BASE F-T A...................
8Z-KT1-022-010 CABI,TRIM F-T A...................
8Z-KT1-023-010 DOOR,CASS A...................
8Z-KT5-001-010 WINDOW,LCD FX929M A...................
8Z-KT5-002-010 WINDOW,LCD FX929M YH ....................
8Z-KT5-004-010 CABI,FRONT F -T5 A...................
8Z-KT1-006-010 BTN,P.SET -T A...................
8Z-KT1-007-010 BTN,+/- -T A...................
8Z-KT1-008-010 BTN,SEL -T A...................
8Z-KT1-009-010 BTN,MUTE -T A...................
8Z-KT1-010-010 BTN,H-BASS -T A...................
8Z-KT1-011-010 BTN,U/D -T A...................
8Z-KT1-012-010 BTN,DRV -T A...................
8Z-KT1-013-010 BTN,TWIN -T A...................
8Z-KT1-016-010 BTN,OPEN F -T A...................
8Z-KT1-018-010 BTN,EJ F-T A...................
8Z-KT5-003-010 BTN,TETRA DALD -T A...................
8Z-KT5-019-010 BTN,M.INF -T A...................
8Z-KT1-201-010 ARM,F-LOCK -T A...................
8Z-KT1-202-010 LEVER,F-OPEN -T A...................
8Z-KT1-203-010 GEAR,FLAP -T A...................
8Z-KT1-204-010 HLDR,F-HOOK L -T A...................
8Z-KT1-205-010 HLDR,F-HOOK R -T A...................
8Z-KT1-206-010 CASE,LCD LENS F -T A...................
8Z-KT1-207-010 LENS,LCD F -T A...................
8Z-KT1-208-010 LENS,BASE -T A...................
8Z-KT1-209-010 LENS,IR -T A...................
8Z-KT1-211-010 COVER, TOP -T A...................
8Z-KT1-212-010 COVER, BOTTOM -T A...................
8Z-KT1-215-010 HLDR,P-IC -T A...................
8Z-KT1-216-010 HLDR,DECK CDS522 A...................
8Z-KT1-218-010 HLDR,CD -T A...................
8Z-KT1-219-010 HLDR,TR -T A...................
8Z-KT1-220-010 HLDR,JACK F -T A...................
8Z-KT1-222-010 ARM,SENSOR F -T A...................
8Z-KT1-225-010 HLDR,LCD F -T A...................
8Z-KT1-229-010 HLDR,DAMPER F ASS’Y-T A...................
8Z-KT1-230-010 HLDR,DFP ASS’Y-T A...................
8Z-KT1-237-010 CAP,LAMP GRN A...................
8Z-KT1-239-010 CAP,LAMP BLU B A...................
8Z-KT1-241-010 SPR-C,DFP HOOK F -T A...................
8Z-KT1-242-010 SPR-C,OPEN BTN F -T A...................
8Z-KT1-243-010 SPR-T,FLAP -T A...................
8Z-KT1-244-010 SPR-T,DOOR Z A...................
8Z-KT1-248-010 SPR-T,SENSOR F -T A...................
8Z-KT1-250-010 OIL-DMPR,100 A...................
8Z-KT1-260-010 SPR-T,F.LOCK-T A...................
8Z-KT5-020-010 HLDR,M.INF -T A...................
8Z-KT5-201-010 COVER, ISO BLIND -T A...................
87-251-073-410 SCREW,U+2.6-6 A...................
87-251-075-410 U+2.6-10 A...................
87-251-096-410 U+3-10 A...................
87-253-034-410 U+2-5 BLK A...................
87-B10-210-010 UT2+3.0-6.0 W/0 SLOT (BH TAP) A...................
88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK A...................
8Z-KT1-246-010 S-SCREW,2.0-2.5 -10 A...................
8Z-KT1-247-010 S-SCREW,GEAR2.0-1.8 -4.2 A...................
8Z-KT1-253-010 S-SCREW,PT 2*8 BH+ BLK A...................
8Z-KT1-254-010 S-SCREW,PT 2*5 BH+ BLK A...................
88-KC4-052-010 CABI,UNIT HRC A...................
88-KC4-054-010 WINDOW,DIODE HRC A...................
88-KC4-055-010 BTN,ARRAY HRC A...................
88-KC4-056-010 HLDR,BAT. HRC A...................
88-KC4-058-010 CAP, FUNC. HRC A...................
8Z-KY1-011-010 CABI,TOP SW1 AL A...................
88-KC4-252-010 TERMINAL,(+) A...................
88-KC4-256-010 S-SCREW,VT2+2-4 BLK A...................
88-KC4-260-010 RING,DIODE -C A...................
88-KC4-261-010 TERMINAL,(-) SPR -C A...................
W 1 8Z-KY1-604-010 F-CABLE,2P (LED) A...................
NOTE: The characters in the suffix column indicate the part usage.
USTC ...................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-KT7-901-010 IB,YU(3L) 729M/719 A...................
8Z-KT7-902-010 IB,INST,YU (3L)729M/719 A...................
8Z-KT7-903-010 IB,YL(3L) 7029M/7019 ....................
8Z-KT7-904-010 IB,INST,YL (3L)7029M/7019 ....................
8Z-KT7-905-010 IB,YH,Y(EA CK CH)729M/719 ....................
8Z-KT7-906-010 IB,INST,YH,Y (EA CK CH)729M/71 ....................
8Z-KT8-901-010 IB,YZ(9L) 719 ....................
8Z-KT8-902-010 IB,INST,YZ (6L)719 ....................
8Z-KT8-903-010 IB,INST,YZ (CZ-PO-H)719 ....................
86-KT1-237-010 HLDR,REAR MTG A...................
87-B10-141-010 NUT,5 TYPE-2 A...................
87-B10-144-010 W,5.2-10-0.5 A...................
87-B10-145-010 W-SPR,5.3-8.5-1.5 A...................
88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK A...................
8Z-KT1-030-010 CASE,DFP -T A...................
8Z-KT1-231-010 HLDR,HALF -T A...................
8Z-KT1-232-010 KEY,REMOVE -T A...................
* 87-B10-143-010 UT1+5-15 W/O SLOT A...................
* 88-KT1-247-010 S-SCREW,HEXAGON A...................
* 8Z-KT1-251-010 S-SCREW,5*6 TH+ TAPPING ST A...................
* 8Z-KT1-616-010 CONN ASSY,16P B52 A...................
ACCESSORIES/PACKAGE LIST - 1<CT-FX719>
ACCESSORIES/PACKAGE LIST - 1<CT-FX729M>
NOTE: The characters in the suffix column indicate the part usage.
YUSTC ..................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-KT7-901-010 IB,YU(3L) 729M/719 A...................
8Z-KT7-902-010 IB,INST,YU (3L)729M/719 A...................
8Z-KT7-903-010 IB,YL(3L) 7029M/7019 ....................
8Z-KT7-904-010 IB,INST,YL (3L)7029M/7019 ....................
8Z-KT7-905-010 IB,YH,Y(EA CK CH)729M/719 ....................
8Z-KT7-906-010 IB,INST,YH,Y (EA CK CH)729M/71 ....................
8Z-KY2-901-010 IB,YU(3L) CD1 A...................
8Z-KY2-902-010 IB,Y(3L,GIP CK) CD1 ....................
8Z-KY2-906-010 IB,Y(3L,GIP CK) CD1 -A ....................
86-KT1-237-010 HLDR,REAR MTG A...................
87-B10-141-010 NUT,5 TYPE-2 A...................
87-B10-144-010 W,5.2-10-0.5 A...................
87-B10-145-010 W-SPR,5.3-8.5-1.5 A...................
88-KC4-053-010 HLDR,BELT HRC A...................
88-KC4-057-010 BELT, HRC A...................
88-KC4-254-010 PLATE,NUT M3 A...................
88-KC4-255-010 S-SCREW,HEX-SOC+3-3.5 BLK A...................
88-KC4-257-010 KEY,HEXAGON WRENCH A...................
88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK A...................
8Z-KC7-691-010 RC UNIT,CD1 ....................
8Z-KT1-030-010 CASE,DFP -T A...................
8Z-KT1-231-010 HLDR,HALF -T A...................
8Z-KT1-232-010 KEY,REMOVE -T A...................
* 87-B10-143-010 UT1+5-15 W/O SLOT A...................
* 88-KT1-247-010 S-SCREW,HEXAGON A...................
* 8Z-KT1-251-010 S-SCREW,5*6 TH+ TAPPING ST A...................
* 8Z-KT1-616-010 CONN ASSY,16P B52 A...................
ACCESSORIES/PACKAGE LIST - 1<CT-FX929M>
NOTE: The characters in the suffix column indicate the part usage.
YUSTC ..................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-KT5-901-010 IB,YU(3L) 929M A...................
8Z-KT5-902-010 IB,INST,YU (3L)929M A...................
8Z-KT5-905-010 IB,YH(E CK A) 929M ....................
8Z-KT5-906-010 IB,INST,YH (E CK A)929M ....................
8Z-KY1-902-010 IB,YU(3L) SW1 -A A...................
8Z-KY1-904-010 IB,Y(3L,GIP CK) SW1-A ....................
86-KT1-237-010 HLDR,REAR MTG A...................
87-B10-141-010 NUT,5 TYPE-2 A...................
87-B10-144-010 W,5.2-10-0.5 A...................
87-B10-145-010 W-SPR,5.3-8.5-1.5 A...................
88-KC4-053-010 HLDR,BELT HRC A...................
88-KC4-057-010 BELT, HRC A...................
88-KC4-254-010 PLATE,NUT M3 A...................
88-KC4-255-010 S-SCREW,HEX-SOC+3-3.5 BLK A...................
88-KC4-257-010 KEY,HEXAGON WRENCH A...................
88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK A...................
8Z-KT1-030-010 CASE,DFP -T A...................
8Z-KT1-231-010 HLDR,HALF -T A...................
8Z-KT1-232-010 KEY,REMOVE -T A...................
* 87-B10-143-010 UT1+5-15 W/O SLOT A...................
* 88-KT1-247-010 S-SCREW,HEXAGON A...................
* 8Z-KT1-251-010 S-SCREW,5*6 TH+ TAPPING ST A...................
* 8Z-KT1-616-010 CONN ASSY,16P B52 A...................
SCHEMATIC DIAGRAM _1<CT-FX719>
Other manuals for CT-FX719
1
This manual suits for next models
3
Table of contents
Other Aiwa Stereo Receiver manuals
Aiwa
Aiwa Compact disc stereo cassette receiver User manual
Aiwa
Aiwa Z-L90 User manual
Aiwa
Aiwa NSX-BL14 User manual
Aiwa
Aiwa CT-FR720M Specification sheet
Aiwa
Aiwa AV-D58 User manual
Aiwa
Aiwa NSX-T99 LH User manual
Aiwa
Aiwa CR-DS800 Building instructions
Aiwa
Aiwa NSX-S222 User manual
Aiwa
Aiwa NSX-MT320 User manual
Aiwa
Aiwa AV-X100 User manual
Aiwa
Aiwa AV-D25 User manual
Aiwa
Aiwa SIMPLE-2 NSX-WVT99 HR User manual
Aiwa
Aiwa NSX-AV240 Specification sheet
Aiwa
Aiwa AV-D78 User manual
Aiwa
Aiwa NSX-SZ70 User manual
Aiwa
Aiwa AV-D78 User manual
Aiwa
Aiwa CR-IC90 User manual
Aiwa
Aiwa NSX-VC18 User manual
Aiwa
Aiwa CR-LA30 User manual
Aiwa
Aiwa XR-M200 User manual
