Aiwa CX-NSZ35 User manual
SERVICE MANUAL
DATA
• BASIC TAPE MECHANISM: ZZM-3 YPR1NF
• BASIC TAPE MECHANISM: AZG-1 YZD8RDM
CX-NSZ35
EZ
COMPACT DISC STEREO
CASSETTE RECEIVER
S/M Code No. 09-001-425-8T1
SIMPLE
•Replace this Service Manual with “Revision Publishing” when it is issued.
ELECTRICAL PARTS LIST - 1/6
NOTE: The characters in the suffix column indicate the part usage.
EZSE ...................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 1 87-010-387-080 CAP,E 470-25 SME A...................
C 2 87-A11-148-080 CAP,TC U 0.1-50 Z F A...................
C 184 87-010-403-040 CAP,E 3.3-50 SME A...................
CN 1 87-A61-122-010 CONN,11P V TID-A A...................
D 5 87-A40-736-080 DIODE,1N4148M(SEM) A...................
D 2 87-A40-736-080 DIODE,1N4148M(SEM) A...................
D 3 87-A40-736-080 DIODE,1N4148M(SEM) A...................
D 4 87-A40-736-080 DIODE,1N4148M(SEM) A...................
D 31 87-A40-736-080 DIODE,1N4148M(SEM) A...................
D 32 87-A40-736-080 DIODE,1N4148M(SEM) A...................
PT 2 8A-NF8-662-010 PT,SUB ANF-8 (E) A...................
Q 31 87-026-245-080 TR,DTC114ES A...................
Q 32 87-A30-198-080 TR,KTC3199GR A...................
RY 2 87-A91-418-010 RELAY,AC12V G5PA-1-M A...................
T 2 87-A60-317-010 TERMINAL, 1P MSC A...................
T 1 87-A60-317-010 TERMINAL, 1P MSC A...................
C 102 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................
C 104 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................
C 101 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................
C 107 87-010-493-040 CAP,E 0.47-50 GAS ....................
C 103 87-010-498-040 CAP,E 10-16 GAS ....................
C 108 87-012-393-080 C-CAP,S 0.22-16 R K ....................
C 153 87-010-198-080 CAP, CHIP 0.022 ....................
C 154 87-010-246-040 CAP,E 47-35 SME ....................
C 156 87-010-404-040 CAP,E 4.7-50 SME ....................
C 155 87-010-404-040 CAP,E 4.7-50 SME ....................
C 361 87-010-178-080 CHIP CAP 1000P ....................
C 362 87-010-178-080 CHIP CAP 1000P ....................
C 372 87-010-178-080 CHIP CAP 1000P ....................
C 371 87-010-178-080 CHIP CAP 1000P ....................
C 601 87-010-382-040 CAP,E 22-25 SME ....................
C 802 87-010-195-080 C-CAP,S 0.068-25 F ....................
C 801 87-010-195-080 C-CAP,S 0.068-25 F ....................
C 805 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................
C 806 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................
C 804 87-010-402-040 CAP,E 2.2-50 SME ....................
C 803 87-010-402-040 CAP,E 2.2-50 SME ....................
C 904 87-010-322-080 C-CAP,S 100P-50 CH ....................
C 907 87-010-322-080 C-CAP,S 100P-50 CH ....................
C 908 87-010-322-080 C-CAP,S 100P-50 CH ....................
C 901 87-010-322-080 C-CAP,S 100P-50 CH ....................
C 909 87-010-322-080 C-CAP,S 100P-50 CH ....................
C 903 87-010-322-080 C-CAP,S 100P-50 CH ....................
C 905 87-010-322-080 C-CAP,S 100P-50 CH ....................
C 906 87-010-322-080 C-CAP,S 100P-50 CH ....................
C 902 87-010-322-080 C-CAP,S 100P-50 CH ....................
C 911 87-010-178-080 CHIP CAP 1000P ....................
C 912 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................
C 916 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................
C 915 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................
C 917 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................
C 919 87-010-197-080 CAP, CHIP 0.01 DM ....................
C 913 87-010-248-040 CAP,E 220-10 SME ....................
C 914 87-010-248-040 CAP,E 220-10 SME ....................
C 910 87-010-322-080 C-CAP,S 100P-50 CH ....................
C 921 87-010-186-080 CAP,CHIP 4700P ....................
C 920 87-012-369-080 C-CAP,S 0.047-50F ....................
C 951 87-010-312-080 C-CAP,S 15P-50 CH ....................
C 953 87-012-140-080 CAP 470P ....................
C 952 87-012-155-080 C-CAP 180P-50CH ....................
C 963 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................
C 961 87-010-378-040 CAP,E 10-16 ....................
C 962 87-012-157-080 C-CAP,S 330P-50 CH ....................
CN 104 87-A60-057-010 CONN,11P V 9604S-11C ....................
CN 701 87-099-720-010 CONN,30P TYK-B(P) ....................
CN 731 87-099-015-010 CONN,13P 6216V ....................
D 101 87-A40-736-080 DIODE,1N4148M(SEM) ....................
D 104 87-A40-736-080 DIODE,1N4148M(SEM) ....................
D 103 87-A40-736-080 DIODE,1N4148M(SEM) ....................
D 102 87-A40-752-080 ZENER,UZ6.2BSC ....................
D 601 87-A40-269-080 C-DIODE,MC2836 ....................
D 653 87-A40-269-080 C-DIODE,MC2836 ....................
D 652 87-A40-269-080 C-DIODE,MC2836 ....................
D 651 87-A40-269-080 C-DIODE,MC2836 ....................
D 654 87-A40-269-080 C-DIODE,MC2836 ....................
D 703 87-A40-736-080 DIODE,1N4148M(SEM) ....................
D 702 87-A40-736-080 DIODE,1N4148M(SEM) ....................
D 732 87-A40-736-080 DIODE,1N4148M(SEM) ....................
D 733 87-A40-736-080 DIODE,1N4148M(SEM) ....................
D 983 87-A40-736-080 DIODE,1N4148M(SEM) ....................
D 991 87-A40-736-080 DIODE,1N4148M(SEM) ....................
FL 901 8A-NF9-605-010 FL,HNA-10SS12 ....................
IC 901 8A-NF9-601-110 C-IC,UPD780226GF-012-3BA ....................
IC 961 87-A21-482-010 IC,RPM6938-H4 ....................
L 951 87-A50-434-010 COIL,CLK 4.19M(TOKO) ....................
LED 209 87-A40-317-080 LED,SLR-342VCT31 RED ....................
ELECTRICAL PARTS LIST - 2/6
LED 201 87-A40-619-040 LED,SLR-56PT-T31-W GRN ....................
LED 202 87-A40-619-040 LED,SLR-56PT-T31-W GRN ....................
LED 204 87-A40-619-040 LED,SLR-56PT-T31-W GRN ....................
LED 205 87-A40-619-040 LED,SLR-56PT-T31-W GRN ....................
LED 210 87-A40-619-040 LED,SLR-56PT-T31-W GRN ....................
Q 101 87-026-610-080 TR,KTC3198GR ....................
Q 102 87-A30-076-080 C-TR,2SC3052F ....................
Q 105 87-A30-468-080 C-TR,KRC102S-RTK ....................
Q 103 87-A30-484-080 C-TR,KRA102S ....................
Q 104 87-A30-484-080 C-TR,KRA102S ....................
Q 201 87-A30-087-080 C-FET,2SK2158 ....................
Q 601 87-A30-318-080 TR,CSA952K ....................
Q 602 87-A30-318-080 TR,CSA952K ....................
Q 603 87-A30-329-080 TR,CD1585BC ....................
Q 806 87-A30-075-080 C-TR,2SA1235F ....................
Q 805 87-A30-075-080 C-TR,2SA1235F ....................
Q 804 87-A30-075-080 C-TR,2SA1235F ....................
Q 803 87-A30-075-080 C-TR,2SA1235F ....................
Q 802 87-A30-076-080 C-TR,2SC3052F ....................
Q 801 87-A30-076-080 C-TR,2SC3052F ....................
Q 902 87-A30-468-080 C-TR,KRC102S-RTK ....................
Q 901 87-A30-484-080 C-TR,KRA102S ....................
Q 951 87-A30-087-080 C-FET,2SK2158 ....................
S 306 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 309 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 301 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 304 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 302 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 308 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 307 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 303 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 305 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 323 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 322 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 325 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 324 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 326 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 321 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 345 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 349 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 341 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 346 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 344 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 348 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 347 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 343 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 342 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 350 87-A90-164-080 SW,TACT SKQAB(N) ....................
S 361 87-A91-633-010 SW,RTRY XRE012103PVB25FINA 1-2 ....................
S 371 87-A91-632-010 SW,RTRY XRE012103PVB25FINB 1-2 ....................
C 302 87-010-178-080 CHIP CAP 1000P A...................
C 303 87-010-178-080 CHIP CAP 1000P A...................
C 304 87-010-178-080 CHIP CAP 1000P A...................
C 301 87-010-178-080 CHIP CAP 1000P A...................
C 308 87-010-263-080 CAP, ELECT 100-10V A...................
C 307 87-010-263-080 CAP, ELECT 100-10V A...................
C 309 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 314 87-010-188-080 CAP,CHIP 6800P A...................
C 313 87-010-188-080 CAP,CHIP 6800P A...................
C 315 87-010-263-080 CAP, ELECT 100-10V A...................
C 310 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 318 87-010-546-080 CAP, ELECT 0.33-50V A...................
C 317 87-010-546-080 CAP, ELECT 0.33-50V A...................
C 326 87-010-198-080 CAP, CHIP 0.022 A...................
C 327 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 365 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 360 87-010-401-080 CAP, ELECT 1-50V A...................
C 399 87-012-140-080 CAP 470P A...................
C 409 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 405 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 408 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 407 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 406 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 403 87-010-321-080 CHIP CAPACITOR,82P(J) A...................
C 404 87-010-321-080 CHIP CAPACITOR,82P(J) A...................
C 402 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 401 87-010-544-080 CAP, ELECT 0.1-50V A...................
C 410 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 412 87-010-405-080 CAP, ELECT 10-50V A...................
C 411 87-010-405-080 CAP, ELECT 10-50V A...................
C 459 87-010-175-080 CAP 560P A...................
C 458 87-010-178-080 CHIP CAP 1000P A...................
C 455 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 454 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 453 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 456 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 452 87-010-382-080 CAP, ELECT 22-25V A...................
C 460 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 462 87-012-158-080 C-CAP,S 390P-50 CH A...................
C 461 87-012-158-080 C-CAP,S 390P-50 CH A...................
CN 301 87-A60-620-010 CONN,3P V 2MM JMT A...................
CN 351 87-A60-625-010 CONN,8P V 2MM JMT A...................
D 401 87-A40-736-080 DIODE,1N4148M(SEM) A...................
FB 303 87-008-474-080 F-BEAD,EMI BL02RN1 A...................
IC 301 87-A21-419-040 C-IC,NJM14558MD-TE2 A...................
IC 401 87-A21-419-040 C-IC,NJM14558MD-TE2 A...................
L 451 87-007-342-010 COIL,OSC 85K BIAS A...................
Q 306 87-A30-062-080 C-TR,KRC104S A...................
Q 309 87-A30-075-080 C-TR,2SA1235F A...................
Q 304 87-A30-090-080 FET,2SK2541 A...................
Q 303 87-A30-090-080 FET,2SK2541 A...................
Q 302 87-A30-091-080 FET,2SJ460 A...................
Q 308 87-A30-091-080 FET,2SJ460 A...................
Q 301 87-A30-091-080 FET,2SJ460 A...................
Q 305 87-A30-091-080 FET,2SJ460 A...................
Q 307 87-A30-091-080 FET,2SJ460 A...................
Q 310 87-A30-075-080 C-TR,2SA1235F A...................
Q 443 87-A30-075-080 C-TR,2SA1235F A...................
Q 444 87-A30-075-080 C-TR,2SA1235F A...................
Q 455 87-A30-076-080 C-TR,2SC3052F A...................
Q 451 87-A30-318-080 TR,CSA952K A...................
Q 453 89-333-317-880 TR,2SC3331 (0.5W) A...................
Q 454 89-333-317-880 TR,2SC3331 (0.5W) A...................
SFR 452 87-A90-432-080 SFR,30K H NVZ6TLTA A...................
SFR 451 87-A90-432-080 SFR,30K H NVZ6TLTA A...................
C 508 87-010-178-080 CHIP CAP 1000P A...................
C 507 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 509 87-A10-300-080 CAP,M 0.027-50 J A...................
C 518 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 519 87-010-401-080 CAP, ELECT 1-50V A...................
C 516 87-A10-300-080 CAP,M 0.027-50 J A...................
C 515 87-A10-300-080 CAP,M 0.027-50 J A...................
C 510 87-A10-300-080 CAP,M 0.027-50 J A...................
C 520 87-010-401-080 CAP, ELECT 1-50V A...................
C 525 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 524 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 526 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 523 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 522 87-010-546-080 CAP, ELECT 0.33-50V A...................
C 521 87-010-546-080 CAP, ELECT 0.33-50V A...................
Q 501 87-A30-076-080 C-TR,2SC3052F A...................
Q 502 87-A30-076-080 C-TR,2SC3052F A...................
Q 505 87-A30-076-080 C-TR,2SC3052F A...................
Q 506 87-A30-076-080 C-TR,2SC3052F A...................
Q 507 87-A30-269-040 C-FET,2SJ461-T1 A...................
Q 508 87-A30-269-040 C-FET,2SJ461-T1 A...................
Q 511 87-A30-076-080 C-TR,2SC3052F A...................
Q 512 87-A30-076-080 C-TR,2SC3052F A...................
C 973 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 974 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 979 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 971 87-010-381-080 CAP, ELECT 330-16V A...................
C 972 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 982 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 987 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 984 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 983 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 989 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 981 87-010-260-080 CAP, ELECT 47-25V A...................
C 985 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 993 87-010-178-080 CHIP CAP 1000P A...................
C 995 87-010-178-080 CHIP CAP 1000P A...................
C 997 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 998 87-010-260-080 CAP, ELECT 47-25V A...................
C 991 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 992 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 999 87-A11-155-080 CAP,TC U 0.01-16 Z F A...................
D 804 87-A40-736-080 DIODE,1N4148M(SEM) A...................
D 991 87-017-149-080 ZENER,HZS6A2L A...................
D 992 87-A40-736-080 DIODE,1N4148M(SEM) A...................
IC 991 87-070-127-110 IC,LC72131 D A...................
Q 981 87-A30-234-080 TR,CSC4115BC A...................
R 991 87-010-322-080 C-CAP,S 100P-50 CH A...................
R 995 87-010-322-080 C-CAP,S 100P-50 CH A...................
R 993 87-010-322-080 C-CAP,S 100P-50 CH A...................
X 991 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 A...................
C 772 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 771 87-010-263-080 CAP, ELECT 100-10V A...................
C 779 87-010-971-080 C-CAP,S 4700P-50 B J A...................
C 788 87-010-149-080 C-CAP,S 5P-50 CH A...................
C 782 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 784 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 783 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 786 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 785 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 780 87-010-971-080 C-CAP,S 4700P-50 B J A...................
C 789 87-A11-532-080 C-CAP,S 0.022-50 J B A...................
C 791 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 795 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 792 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 796 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 798 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 793 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 797 87-010-405-080 CAP, ELECT 10-50V A...................
ELECTRICAL PARTS LIST - 3/6
C 799 87-010-407-080 CAP, ELECT 33-50V A...................
C 790 87-A11-532-080 C-CAP,S 0.022-50 J B A...................
C 802 87-010-194-080 CAP, CHIP 0.047 A...................
C 803 87-010-198-080 CAP, CHIP 0.022 A...................
C 804 87-010-263-080 CAP, ELECT 100-10V A...................
C 807 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 809 87-010-401-080 CAP, ELECT 1-50V A...................
C 808 87-010-401-080 CAP, ELECT 1-50V A...................
C 801 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 800 87-012-369-080 C-CAP,S 0.047-50F A...................
C 818 87-010-180-080 C-CER 1500P A...................
C 810 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 814 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 815 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 816 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 821 87-010-405-080 CAP, ELECT 10-50V A...................
C 824 87-010-405-080 CAP, ELECT 10-50V A...................
C 825 87-010-596-080 CAP, S 0.047-16 A...................
C 823 87-012-349-080 C-CAP,S 1000P-50 CH A...................
D 801 87-A40-736-080 DIODE,1N4148M(SEM) A...................
D 803 87-A40-736-080 DIODE,1N4148M(SEM) A...................
IC 801 87-A21-560-010 IC,LA1844L-A A...................
L 801 87-A50-608-010 COIL,FM DET-N(TOK) A...................
L 802 87-A91-551-010 FLTR,PCFJZH-450 L(TOK) A...................
L 811 87-005-847-080 COIL,2.2UH(CECS) A...................
R 790 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 831 87-010-406-080 CAP, ELECT 22-50 A...................
C 844 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 842 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 858 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 859 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 852 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 853 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 851 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 850 87-010-260-080 CAP, ELECT 47-25V A...................
C 860 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 942 87-010-149-080 C-CAP,S 5P-50 CH A...................
C 947 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 940 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 948 87-012-140-080 CAP 470P A...................
C 959 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 958 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 952 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 957 87-010-311-080 CAP 12P A...................
C 960 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 962 87-010-401-080 CAP, ELECT 1-50V A...................
C 963 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z A...................
CF 832 82-785-747-010 CF MS2 GHY R A...................
CF 831 87-008-423-010 CERAMIC FILTER, SFE10.7 A...................
D 942 87-A40-270-080 C-DIODE,MC2838 A...................
D 944 87-A40-736-080 DIODE,1N4148M(SEM) A...................
FFE 831 A8-6ZA-191-130 6ZA-1 FEENM ....................
FFE 831 A8-6ZA-19C-170 6ZA-1 YFEENC A...................
J 832 87-A60-403-010 TERMINAL,ANT PAL 2P HSP-312V05 A...................
L 832 87-005-847-080 COIL,2.2UH(CECS) A...................
L 942 87-A50-019-010 COIL,OSC LW(COI) A...................
L 941 87-A50-020-010 COIL,ANT LW(COI) A...................
L 951 8A-NF8-668-010 COIL,AM PACK 2(TOK) A...................
Q 836 87-A30-072-080 C-TR,RT1P 144C A...................
Q 835 89-327-143-080 TR,2SC2714 (0.1W) A...................
Q 948 87-A30-086-070 C-TR,CSD1306E A...................
Q 951 87-A30-074-080 C-TR,RT1P 141C A...................
Q 952 87-A30-086-070 C-TR,CSD1306E A...................
Q 953 89-503-602-080 C-FET,2SK360E A...................
TC 942 87-011-253-080 TRIMER,30P LAR A...................
C 5 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 3 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 6 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 4 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 19 87-010-917-000 CAP,E 3300-50 M SMG A...................
C 18 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 15 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 17 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 16 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 26 87-010-247-080 CAP, ELECT 100-50V A...................
C 25 87-010-408-080 CAP, ELECT 47-50V A...................
C 20 87-010-917-000 CAP,E 3300-50 M SMG A...................
C 23 87-016-495-000 CAP,E 3300-25 M SMG A...................
C 24 87-016-495-000 CAP,E 3300-25 M SMG A...................
C 32 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 38 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 34 87-010-260-080 CAP, ELECT 47-25V A...................
C 31 87-010-263-080 CAP, ELECT 100-10V A...................
C 35 87-010-379-080 CAP, ELECT 22-16V A...................
C 36 87-010-381-080 CAP, ELECT 330-16V A...................
C 30 87-010-430-080 CAP, ELECT 100-63 A...................
C 61 87-010-260-080 CAP, ELECT 47-25V A...................
C 60 87-010-403-080 CAP, ELECT 3.3-50V A...................
CNA 1 8A-NF8-654-010 CONN ASSY,11P TID-A(480) A...................
D 3 87-A40-393-090 DIODE,1N5402GW(F20) A...................
D 2 87-A40-393-090 DIODE,1N5402GW(F20) A...................
D 4 87-A40-393-090 DIODE,1N5402GW(F20) A...................
ELECTRICAL PARTS LIST - 4/6
D 1 87-A40-393-090 DIODE,1N5402GW(F20) A...................
D 10 87-A40-838-090 DIODE,G3SBA60L-6088 A...................
D 26 87-A40-553-080 DIODE,1N4003 LES A...................
D 27 87-A40-553-080 DIODE,1N4003 LES A...................
D 29 87-A40-776-080 ZENER,UZ27BSD A...................
D 33 87-A40-553-080 DIODE,1N4003 LES A...................
D 30 87-A40-736-080 DIODE,1N4148M(SEM) A...................
D 34 87-A40-736-080 DIODE,1N4148M(SEM) A...................
D 35 87-A40-736-080 DIODE,1N4148M(SEM) A...................
D 31 87-A40-764-080 ZENER,UZ10BSC A...................
D 50 87-A40-270-080 C-DIODE,MC2838 A...................
D 56 87-A40-553-080 DIODE,1N4003 LES A...................
D 55 87-A40-553-080 DIODE,1N4003 LES A...................
D 64 87-A40-269-080 C-DIODE,MC2836 A...................
D 63 87-A40-270-080 C-DIODE,MC2838 A...................
D 68 87-A40-313-080 C-DIODE,MC 2840 A...................
D 69 87-A40-313-080 C-DIODE,MC 2840 A...................
D 67 87-A40-313-080 C-DIODE,MC 2840 A...................
D 62 87-A40-313-080 C-DIODE,MC 2840 A...................
D 65 87-A40-736-080 DIODE,1N4148M(SEM) A...................
D 60 87-A40-736-080 DIODE,1N4148M(SEM) A...................
D 66 87-A40-854-080 ZENER,UZ15BSA A...................
D 78 87-A40-313-080 C-DIODE,MC 2840 A...................
D 77 87-A40-313-080 C-DIODE,MC 2840 A...................
D 73 87-A40-313-080 C-DIODE,MC 2840 A...................
Q 9 87-026-609-080 TR,KTA1266GR A...................
Q 2 87-026-609-080 TR,KTA1266GR A...................
Q 1 87-026-609-080 TR,KTA1266GR A...................
Q 5 87-026-610-080 TR,KTC3198GR A...................
Q 8 87-A30-075-080 C-TR,2SA1235F A...................
Q 6 87-A30-076-080 C-TR,2SC3052F A...................
Q 4 89-213-702-010 TR,2SB1370 (1.8W) A...................
Q 10 87-A30-076-080 C-TR,2SC3052F A...................
Q 51 87-A30-075-080 C-TR,2SA1235F A...................
Q 50 87-A30-075-080 C-TR,2SA1235F A...................
Q 66 87-A30-075-080 C-TR,2SA1235F A...................
Q 63 87-A30-075-080 C-TR,2SA1235F A...................
Q 61 87-A30-075-080 C-TR,2SA1235F A...................
Q 65 87-A30-075-080 C-TR,2SA1235F A...................
Q 60 87-A30-076-080 C-TR,2SC3052F A...................
Q 64 87-A30-076-080 C-TR,2SC3052F A...................
Q 62 87-A30-076-080 C-TR,2SC3052F A...................
WH 1 87-A91-179-010 HLDR,WIRE 2.5-11P A...................
C 605 87-010-179-080 CAP,CHIP S B1200P A...................
C 606 87-010-179-080 CAP,CHIP S B1200P A...................
C 609 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 615 87-010-154-080 CAP CHIP 10P A...................
C 610 87-010-213-080 C-CAP,S 0.015-50 B A...................
C 617 87-010-221-080 CAP, ELECT 470-10V A...................
C 616 87-010-221-080 CAP, ELECT 470-10V A...................
C 618 87-010-405-080 CAP, ELECT 10-50V A...................
C 613 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 612 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 611 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 614 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 620 87-010-263-080 CAP, ELECT 100-10V A...................
C 631 87-010-185-080 C-CAP,S 3900P-50 B A...................
C 632 87-010-185-080 C-CAP,S 3900P-50 B A...................
C 634 87-016-369-080 C-CAP,S 0.033-25 B K A...................
C 633 87-016-369-080 C-CAP,S 0.033-25 B K A...................
C 630 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 669 87-010-180-080 C-CER 1500P A...................
C 661 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 662 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 670 87-010-180-080 C-CER 1500P A...................
C 677 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 678 87-010-197-080 CAP, CHIP 0.01 DM A...................
CN 601 87-099-719-010 CONN,30P TYK-B(X) A...................
CN 602 87-A60-131-010 CONN,6P V FE A...................
D 601 87-A40-739-080 ZENER,UZ2.7BSA A...................
D 602 87-A40-739-080 ZENER,UZ2.7BSA A...................
IC 601 87-A21-401-040 C-IC,M61503FP A...................
J 602 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN A...................
Q 607 87-A30-076-080 C-TR,2SC3052F A...................
Q 601 87-A30-087-080 C-FET,2SK2158 A...................
Q 602 87-A30-087-080 C-FET,2SK2158 A...................
Q 605 87-A30-090-080 FET,2SK2541 A...................
Q 606 87-A30-090-080 FET,2SK2541 A...................
C 102 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 101 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 107 87-010-406-080 CAP, ELECT 22-50 A...................
C 108 87-010-406-080 CAP, ELECT 22-50 A...................
C 104 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 103 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 109 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 119 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 113 87-010-405-080 CAP, ELECT 10-50V A...................
C 112 87-010-405-080 CAP, ELECT 10-50V A...................
C 111 87-010-405-080 CAP, ELECT 10-50V A...................
C 114 87-010-405-080 CAP, ELECT 10-50V A...................
C 110 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 124 87-010-176-080 C-CAP,S 680P-50 SL A...................
ELECTRICAL PARTS LIST - 5/6
C 123 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 129 87-010-191-080 C-CAP,S 0.015-50 F A...................
C 120 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 126 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 127 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 128 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 125 87-012-368-080 C-CAP,S 0.1-50 F A...................
C 133 87-010-186-080 CAP,CHIP 4700P A...................
C 130 87-010-191-080 C-CAP,S 0.015-50 F A...................
C 132 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 131 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 140 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 141 87-012-368-080 C-CAP,S 0.1-50 F A...................
D 101 87-A40-269-080 C-DIODE,MC2836 A...................
D 116 87-A40-270-080 C-DIODE,MC2838 A...................
IC 101 87-A21-396-010 IC,STK490-040 A...................
J 203 87-A60-238-010 TERMINAL,SP 4P (MSC) A...................
J 202 87-A60-483-010 JACK,DIA6.3 BLK ST W/S KM A...................
L 101 87-A50-610-010 COIL,1UH K(MDEC) A...................
L 102 87-A50-610-010 COIL,1UH K(MDEC) A...................
Q 126 87-A30-107-070 C-TR,CMBT5401 A...................
Q 123 87-A30-107-070 C-TR,CMBT5401 A...................
Q 124 87-A30-107-070 C-TR,CMBT5401 A...................
Q 130 87-A30-106-040 C-TR,CMBT5551 A...................
R 129 87-A00-258-080 RES,M/F 0.22-1W J A...................
R 130 87-A00-258-080 RES,M/F 0.22-1W J A...................
R 146 87-A00-439-050 RES,180-1/2W J RP A...................
R 143 87-A00-439-050 RES,180-1/2W J RP A...................
R 144 87-A00-439-050 RES,180-1/2W J RP A...................
R 145 87-A00-439-050 RES,180-1/2W J RP A...................
C 203 87-010-185-080 C-CAP,S 3900P-50 B A...................
C 204 87-010-185-080 C-CAP,S 3900P-50 B A...................
C 209 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 211 87-010-186-080 CAP,CHIP 4700P A...................
C 212 87-010-186-080 CAP,CHIP 4700P A...................
C 214 87-010-401-080 CAP, ELECT 1-50V A...................
C 213 87-010-401-080 CAP, ELECT 1-50V A...................
C 210 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 217 87-010-405-080 CAP, ELECT 10-50V A...................
C 218 87-010-405-080 CAP, ELECT 10-50V A...................
C 223 87-010-190-080 S CHIP F 0.01 A...................
C 224 87-010-190-080 S CHIP F 0.01 A...................
C 229 87-010-993-080 C-CAP,S 0.056-25 B A...................
C 233 87-010-190-080 S CHIP F 0.01 A...................
C 234 87-010-190-080 S CHIP F 0.01 A...................
C 239 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 232 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 231 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 238 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 237 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 230 87-010-993-080 C-CAP,S 0.056-25 B A...................
C 270 87-010-190-080 S CHIP F 0.01 A...................
D 202 87-A40-269-080 C-DIODE,MC2836 A...................
IC 201 87-A21-396-010 IC,STK490-040 A...................
J 205 87-A61-157-010 JACK,PIN 2P R/W/BL V(SEPA) KM A...................
L 202 87-A50-610-010 COIL,1UH K(MDEC) A...................
L 201 87-A50-610-010 COIL,1UH K(MDEC) A...................
Q 202 87-A30-076-080 C-TR,2SC3052F A...................
Q 201 87-A30-076-080 C-TR,2SC3052F A...................
Q 219 87-A30-107-070 C-TR,CMBT5401 A...................
Q 220 87-A30-107-070 C-TR,CMBT5401 A...................
R 234 87-A00-258-080 RES,M/F 0.22-1W J A...................
R 233 87-A00-258-080 RES,M/F 0.22-1W J A...................
ELECTRICAL PARTS LIST - 6/6
MECHANICAL PARTS LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage.
EZSE ...................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
87-CE3-023-010 BADGE,AIWA 30N SILV ....................
8A-NF8-005-010 PANEL,TOP A...................
8A-NF8-007-010 PANEL,LEFT V-2 A...................
8A-NF8-008-010 PANEL,RIGHT V-2 A...................
8A-NF9-003-010 BOX,CASS 1 ....................
8A-NF9-004-010 BOX,CASS 2 ....................
8A-NF9-014-010 PANEL,TRAY A...................
8A-NF9-017-010 PANEL,JOG ....................
8A-NFK-001-010 CABI,FR EZ ....................
8A-NFK-002-010 CABI,REAR EZSE A...................
8A-NFK-004-010 CABI,REAR EZSM ....................
8A-NF9-008-010 KEY,POWER ....................
8A-NF9-009-010 KEY,FUN ....................
8A-NF9-010-110 KEY,ASSY OPE 1 WAY ....................
8A-NF9-016-010 KNOB,RTRY VOL ....................
8A-NF9-018-010 KNOB,RTRY JOG ....................
8A-NF9-019-010 KEY,SYNC ....................
8A-NF9-020-010 KEY,CD ....................
8A-NF9-022-010 REFLECTOR,ECO ....................
8A-NF9-026-110 KEY,ENTER ....................
81-532-080-010 LABEL, CASS. COMPT ....................
8A-NF8-006-010 WINDOW,TOP A...................
8A-NF9-006-010 WINDOW,CASS 1 ....................
8A-NF9-007-010 WINDOW,CASS 2 ....................
8A-NF9-039-010 WINDOW,CD ....................
8A-NFK-003-010 WINDOW,DISP EZ ....................
84-ZG1-245-210 CAP,OPTICAL A...................
82-NF5-229-010 PLATE,LOCK ....................
86-NF9-224-010 SPR-C,LOCK ....................
87-064-080-010 WIRE, BINDER A...................
87-NF4-216-010 HLDR,LOCK 1 ....................
87-NF4-217-110 HLDR,LOCK 2 ....................
87-NF4-221-010 HLDR,CABLE A...................
8A-DB8-209-010 HLDR,PWB PT ....................
8A-NF8-205-010 HLDR,IC A...................
8A-NF8-206-010 HLDR,PWB M A...................
8A-NF8-207-010 SPR-T,EJECT 1 A...................
8A-NF8-208-010 SPR-T,EJECT 2 A...................
8A-NF8-209-010 OIL-DMPR,120 ....................
8Z-NB8-240-010 COVER, PL A...................
87-067-581-010 TAPPING SCREW, BVT2+3-15 A...................
87-067-641-010 UTT2+3-8(W/O SLOT)BL A...................
87-067-688-010 BVTT+3-6 A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
87-078-191-010 S-SCREW,IT+4-10 A...................
87-721-096-410 QT2+3-10 GLD A...................
87-721-097-410 QT2+3-12 GLD A...................
87-723-096-410 QT2+3-10W/O SLOT BL A...................
87-NF4-224-010 S-SCREW,IT3B+3-8 CU A...................
82-NF7-210-110 GUIDE,FL (*) ....................
8A-NF9-201-010 GUIDE,OPE 1 WAY ....................
87-085-185-010 BUSHING, AC CORD (E) A...................
88-906-251-110 FF-CABLE,6P 1.25 A...................
88-911-101-110 FF-CABLE,11P 1.25 ....................
88-913-301-110 FF-CABLE,13P-1.25 ....................
C 205 87-018-130-080 CAP,TC-U 820P-50 B A...................
C 206 87-018-130-080 CAP,TC-U 820P-50 B A...................
PT 1 8A-NFK-617-010 PT,ANF-19 EZ A...................
W 1 87-A80-092-010 AC CORD ASSY,E BLK SUN FAI A...................
WH 1 87-A91-179-010 HLDR,WIRE 2.5-11P A...................
ACCESSORIES / PACKAGE LIST-1/1
NOTE: The characters in the suffix column indicate the part usage.
EZSE ...................XX..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8A-NFK-906-010 IB,EZ(9L)E -SZ35 A...................
8A-NFK-916-010 IB,EZ(9L)M -SZ35 ....................
87-006-225-010 AM LOOP ANT NC2 A...................
87-A90-118-010 ANT,WIRE FM (Z) A...................
8Z-NF9-701-210 RC UNIT,ZAS02 A...................
SCHEMATIC DIAGRAM - 1 <MAIN 1/2>
SCHEMATIC DIAGRAM - 2 <MAIN: TUNER 2/2>
SCHEMATIC DIAGRAM - 3 (FRONT)
SCHEMATIC DIAGRAM - 4 (PT)
2–11, IKENOHATA 1–CHOME, TAITO-KU,TOKYO 110, JAPAN TEL:03 (3827) 3111
Printed in Singapore9920594
Table of contents
Other Aiwa Stereo Receiver manuals
Aiwa
Aiwa AV-D35 Specification sheet
Aiwa
Aiwa NSX-F9 User manual
Aiwa
Aiwa AD-1800 User manual
Aiwa
Aiwa NSX-T77 User manual
Aiwa
Aiwa CX-ZL800 User manual
Aiwa
Aiwa CR-LA15 YZ User manual
Aiwa
Aiwa CX-NHMT75 u User manual
Aiwa
Aiwa NSX-SZ10 LH User manual
Aiwa
Aiwa CR-IC90 User manual
Aiwa
Aiwa CT-FR720M Specification sheet
Popular Stereo Receiver manuals by other brands
Marantz
Marantz SR7400 Service manual
Krell Industries
Krell Industries Evolution 707 Quick setup guide
Harman Kardon
Harman Kardon 900 instruction manual
Sony
Sony STR-DB830 - Fm Stereo/fm-am Receiver Service manual
Kenwood
Kenwood VRS-N8100 - AV / Digital Multimedia Receiver Service manual
Sherwood
Sherwood RX-772 operating instructions
