SERVICE MANUAL

DATA

BASIC TAPE MECHANISM : TN-21ZVC-2000

BASIC CD MECHANISM : DTA11T3C

COMPACT DISC RADIO

CASSETTE RECORDER

CSD-A510

CSD-A519

S/M Code No. 09-003-343-2T2

EZ(S),K(S)

LH1J(S)

SIMPLE

• Replace this Service Manual with ”Revision Publishing” when it is issued.

ELECTRICAL MAIN PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

510K<S> ................XX...................................B..................

510EZ<S> ...............XX....................................C.................

519LH1J<S> .............XX.....................................D................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

L 601 87-003-102-080 COIL, 10UH ABCD................

C 605 87-010-264-040 CAP,E 100-10 5L ABCD................

C 614 87-010-312-080 C-CAP,S 15P-50 CH ABCD................

C 601 87-010-313-080 CAP, CHIP 18P ABCD................

C 602 87-010-315-080 C-CAP,S 27P-50 CH ABCD................

C 604 87-010-317-010 CHIP CAP,S 39P CH ABCD................

C 603 87-010-319-080 C-CAP,S 56P-50 CH ABCD................

C 609 87-010-400-080 CAP, ELECT 0.47-50V ABCD................

C 608 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 606 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 613 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 607 87-015-779-010 CHIP CAPACITOR, 0.01 ABCD................

D 601 87-020-465-080 DIODE,1SS133 (110MA) ABCD................

D 602 87-020-465-080 DIODE,1SS133 (110MA) ABCD................

D 607 87-020-465-080 DIODE,1SS133 (110MA) ABCD................

D 608 87-020-465-080 DIODE,1SS133 (110MA) ABCD................

Q 603 87-026-237-080 CHIP-TR,DTC124XK ABCD................

Q 610 87-026-463-080 TR,2SA933S (0.3W) ABCD................

Q 606 87-026-464-010 TR,DTC114TS ABCD................

Q 607 87-026-464-010 TR,DTC114TS ABCD................

Q 608 87-026-464-010 TR,DTC114TS ABCD................

Q 609 87-026-464-010 TR,DTC114TS ABCD................

Q 613 87-026-464-010 TR,DTC114TS ABCD................

X 601 87-030-273-010 VIB,XTAL 32.768K5PPM ABCD................

X 602 87-030-376-080 VIB,CER CSA5.76MG200 ABCD................

D 606 87-070-345-080 DIODE,IN4148 ABCD................

CN 601 87-099-033-010 16P 6216 H ABCD................

CN 602 87-099-201-010 CONN,8P 6216 H ABCD................

C 611 87-A10-189-040 CAP,E 220-10 ABCD................

S 601 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

S 602 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

S 603 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

S 604 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

S 605 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

S 609 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

S 610 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

S 611 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

LED 611 87-CD8-616-010 LED,SA36-11 HWA-11.0 ABCD................

LED 601 88-CD6-630-010 LED,934ID RED ABCD................

LED 602 88-CD6-630-010 LED,934ID RED ABCD................

LED 603 88-CD6-630-010 LED,934ID RED ABCD................

LED 606 88-CD6-630-010 LED,934ID RED ABCD................

LED 607 88-CD6-630-010 LED,934ID RED ABCD................

LED 608 88-CD6-630-010 LED,934ID RED ABCD................

LED 610 88-CD6-631-010 LED,934GD GRN ABCD................

Q 604 89-317-403-080 TR,2SC1740S ABCD................

IC 604 8A-CD9-610-010 C-IC,LC865516A-*** ABCD................

CNA 604 8A-CD9-623-010 CONN ASSY,4P KEY ABCD................

CN 605 87-A60-114-010 CONN,4P H S2M-4WR ABCD................

J 251 87-A60-569-010 JACK,HTJ-035-18 ABCD................

CN 204 87-A60-685-010 CONN,4P H WHT EH ABCD................

S 606 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

S 607 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

S 608 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

S 614 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

S 615 87-A90-696-080 SW,TACT TS2103-03-430 ABCD................

CNA 203 8A-CD9-628-010 CONN ASSY,3P MA-HP ABCD................

C 901 87-010-192-080 C-CAP,S 0.022-50 F ABCD................

C 902 87-010-192-080 C-CAP,S 0.022-50 F ABCD................

C 903 87-010-192-080 C-CAP,S 0.022-50 F ABCD................

C 904 87-010-192-080 C-CAP,S 0.022-50 F ABCD................

D 901 87-A40-465-010 DIODE,FR202 ABCD................

D 902 87-A40-465-010 DIODE,FR202 ABCD................

D 903 87-A40-465-010 DIODE,FR202 ABCD................

D 904 87-A40-465-010 DIODE,FR202 ABCD................

PR 901 87-A90-092-080 PROTECTOR,2.5A 491 ABCD................

SP 901 87-CD6-213-010 SPR-C,BATT (-) ABCD................

SP 902 87-CD6-213-010 SPR-C,BATT (-) ABCD................

SP 903 87-CD6-213-010 SPR-C,BATT (-) ABCD................

SP 904 87-CD6-213-010 SPR-C,BATT (-) ABCD................

CNA 901 8A-CD9-627-010 CONN ASSY,3P PWR ABCD................

C 239 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 240 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 231 87-010-213-080 C-CAP,S 0.015-50 B ABCD................

C 232 87-010-213-080 C-CAP,S 0.015-50 B ABCD................

C 310 87-010-248-080 CAP, ELECT 220-10V ABCD................

C 247 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 248 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 237 87-010-408-080 CAP, ELECT 47-50V ABCD................

C 819 87-010-426-080 C-CAP,S 0.012-25 B ABCD................

C 820 87-010-426-080 C-CAP,S 0.012-25 B ABCD................

C 211 87-010-805-080 CAP, S 1-16 ABCD................

C 212 87-010-805-080 CAP, S 1-16 ABCD................

C 483 87-012-156-080 C-CAP,S 220P-50 CH ABCD................

C 484 87-012-156-080 C-CAP,S 220P-50 CH ABCD................

ELECTRICAL MAIN PARTS LIST - 2

C 215 87-016-460-080 C-CAP,S 0.22-16 B ABCD................

C 216 87-016-460-080 C-CAP,S 0.22-16 B ABCD................

C 235 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 236 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

D 310 87-020-465-080 DIODE,1SS133 (110MA) ABCD................

C 233 87-A10-201-080 C-CAP,S0.33-16 KB ABCD................

C 234 87-A10-201-080 C-CAP,S0.33-16 KB ABCD................

IC 203 87-A21-520-040 C-IC,M61509FP ABCD................

C 267 87-010-112-080 CAP, ELECT 100-16V ABCD................

C 268 87-010-112-080 CAP, ELECT 100-16V ABCD................

C 263 87-010-178-080 CHIP CAP 1000P ABCD................

C 264 87-010-178-080 CHIP CAP 1000P ABCD................

C 271 87-010-237-080 CAP, ELECT 1000-16V ABCD................

C 272 87-010-237-080 CAP, ELECT 1000-16V ABCD................

C 265 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 266 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 279 87-010-385-080 CAP, ELECT 220-25V ABCD................

C 261 87-010-402-080 CAP, ELECT 2.2-50V ABCD................

C 262 87-010-402-080 CAP, ELECT 2.2-50V ABCD................

C 278 87-010-405-080 CAP, ELECT 10-50V ABCD................

IC 202 87-A21-064-010 IC,LA4227 ABCD................

CN 202 8A-CH4-689-010 CONN,3P V 2.5 ABCD................

C 308 87-010-221-080 CAP, ELECT 470-10V ABCD................

C 311 87-010-374-080 CAP, ELECT 47-10V ABCD................

C 312 87-010-385-080 CAP, ELECT 220-25V ABCD................

C 307 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 306 87-010-404-080 CAP, ELECT 4.7-50V ABCD................

C 325 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 301 87-016-495-000 CAP,E 3300-25 M SMG ABCD................

Q 303 87-026-291-080 TR,DTC124XS ABCD................

Q 305 87-026-462-080 TR,2SC1740 S(RS 0.3W) ABCD................

Q 302 87-026-463-080 TR,2SA933S (0.3W) ABCD................

D 311 87-027-702-080 DIODE,ZENER HZ6C2L (200MA) ABCD................

D 303 87-070-345-080 DIODE,IN4148 ABCD................

D 305 87-070-345-080 DIODE,IN4148 ABCD................

D 306 87-070-345-080 DIODE,IN4148 ABCD................

D 304 87-A40-648-080 ZENER,MTZJ8.2A ABCD................

Q 301 89-112-965-080 TR,2SA1296 (0.75W) ABCD................

Q 304 89-213-702-080 TR,2SB1370E ABCD................

Q 310 89-318-154-080 TR,2SC1815 (0.4W) ABCD................

CN 301 8A-CH4-689-010 CONN,3P V 2.5 ABCD................

L 801 87-007-342-010 COIL,OSC 85K BIAS ABCD................

C 811 87-010-178-080 CHIP CAP 1000P ABCD................

C 812 87-010-178-080 CHIP CAP 1000P ABCD................

C 823 87-010-178-080 CHIP CAP 1000P ABCD................

C 824 87-010-178-080 CHIP CAP 1000P ABCD................

C 829 87-010-178-080 CHIP CAP 1000P ABCD................

C 830 87-010-178-080 CHIP CAP 1000P ABCD................

C 845 87-010-178-080 CHIP CAP 1000P ABCD................

C 852 87-010-178-080 CHIP CAP 1000P ABCD................

C 816 87-010-180-080 C-CER 1500P ABCD................

C 817 87-010-180-080 C-CER 1500P ABCD................

C 851 87-010-186-080 CAP,CHIP 4700P ABCD................

C 843 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 831 87-010-198-080 CAP, CHIP 0.022 ABCD................

C 801 87-010-248-080 CAP, ELECT 220-10V ABCD................

C 834 87-010-248-080 CAP, ELECT 220-10V ABCD................

C 30 87-010-260-080 CAP, ELECT 47-25V ABCD................

C 846 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 835 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 836 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 821 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 822 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 807 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 808 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 809 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 810 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 805 87-012-365-080 C-CAP,S 0.027-25VBK ABCD................

C 806 87-012-365-080 C-CAP,S 0.027-25VBK ABCD................

D 308 87-017-978-080 DIODE,1N4003 ABCD................

C 844 87-018-124-080 CAP, CER 270P-50V ABCD................

C 833 87-018-195-080 CAP, CER 1200P-16V ABCD................

C 853 87-018-211-080 CAP, CER 0.01-50 A...................

D 809 87-020-465-080 DIODE,1SS133 (110MA) ABCD................

D 810 87-020-465-080 DIODE,1SS133 (110MA) ABCD................

Q 810 87-026-464-080 TR,DTC114TS (0.3W) ABCD................

R 840 87-029-124-010 RES,FUSE 2.2-1/4 ABCD................

D 309 87-070-345-080 DIODE,IN4148 ABCD................

D 807 87-070-345-080 DIODE,IN4148 ABCD................

D 808 87-070-345-080 DIODE,IN4148 ABCD................

C 853 87-A11-145-080 CAP,TC U 0.01-50 Z F .BCD................

IC 801 87-A21-431-010 IC,BA4560N ABCD................

CN 801 87-A60-110-010 CONN,4P V S2M-4W ABCD................

Q 801 89-318-154-080 TR,2SC1815 (0.4W) ABCD................

CN 802 8A-CH4-687-010 CONN,4P V 2.5 ABCD................

SW 801 8Z-CD9-609-010 SW,SL 1-6-2 PS62D01 ABCD................

C 321 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 322 87-010-263-080 CAP, ELECT 100-10V ABCD................

Q 841 87-026-291-080 TR,DTC124XS ABCD................

D 32 87-027-399-080 ZENER,HZ7A3L (200MA) ....................

D 32 87-027-607-080 ZENER,HZ7B3L ABCD................

D 323 87-070-345-080 DIODE,IN4148 ABCD................

CN 201 87-099-018-010 CONN,16P ABCD................

ELECTRICAL MAIN PARTS LIST - 3

Q 321 89-318-154-080 TR,2SC1815 (0.4W) ABCD................

CN 302 8A-CD9-629-010 CONN ASSY,6P MA-TU ABCD................

L 401 87-003-102-080 COIL, 10UH ABCD................

L 404 87-003-152-080 COIL, 100UH ABCD................

C 425 87-010-176-080 C-CAP,S 680P-50 SL ABCD................

C 407 87-010-178-080 CHIP CAP 1000P ABCD................

C 439 87-010-178-080 CHIP CAP 1000P ABCD................

C 422 87-010-183-080 C-CAP,S 2700P-50 B ABCD................

C 434 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCD................

C 429 87-010-186-080 CAP,CHIP 4700P ABCD................

C 494 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 408 87-010-198-080 CAP, CHIP 0.022 ABCD................

C 418 87-010-213-080 C-CAP,S 0.015-50 B ABCD................

C 480 87-010-221-080 CAP, ELECT 470-10V ABCD................

C 476 87-010-236-080 CAP,E 1000-10 SME ABCD................

C 455 87-010-247-080 CAP, ELECT 100-50V ABCD................

C 404 87-010-248-080 CAP, ELECT 220-10V ABCD................

C 409 87-010-248-080 CAP, ELECT 220-10V ABCD................

C 462 87-010-248-080 CAP, ELECT 220-10V ABCD................

C 403 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 410 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 459 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 467 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 478 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 442 87-010-312-080 C-CAP,S 15P-50 CH ABCD................

C 457 87-010-312-080 C-CAP,S 15P-50 CH ABCD................

C 458 87-010-312-080 C-CAP,S 15P-50 CH ABCD................

C 448 87-010-315-080 C-CAP,S 27P-50 CH ABCD................

C 502 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 503 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 504 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 505 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 506 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 406 87-010-374-080 CAP, ELECT 47-10V ABCD................

C 432 87-010-374-080 CAP, ELECT 47-10V ABCD................

C 436 87-010-374-080 CAP, ELECT 47-10V ABCD................

C 412 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 433 87-010-401-080 CAP, ELECT 1-50V ABCD................

C 401 87-010-403-080 CAP, ELECT 3.3-50V ABCD................

C 437 87-010-404-080 CAP, ELECT 4.7-50V ABCD................

C 465 87-010-404-080 CAP, ELECT 4.7-50V ABCD................

C 414 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 481 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 482 87-010-405-080 CAP, ELECT 10-50V ABCD................

C 470 87-010-544-080 CAP, ELECT 0.1-50V ABCD................

C 416 87-010-545-080 CAP, ELECT 0.22-50V ABCD................

C 431 87-010-545-080 CAP, ELECT 0.22-50V ABCD................

C 423 87-010-956-080 CHIP-CAP,S 0.068-25B ABCD................

C 424 87-010-993-080 C-CAP,S 0.056-25 B ABCD................

C 450 87-012-140-080 CAP 470P ABCD................

C 469 87-012-154-080 C-CAP,S 150P-50 CH ABCD................

C 430 87-012-156-080 C-CAP,S 220P-50 CH ABCD................

C 451 87-012-156-080 C-CAP,S 220P-50 CH ABCD................

C 417 87-012-157-080 C-CAP,S 330P-50 CH ABCD................

C 445 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 446 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 447 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 466 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 489 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 490 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 501 87-012-368-080 C-CAP,S 0.1-50 F ABCD................

C 471 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z ABCD................

C 472 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z ABCD................

C 473 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z ABCD................

C 474 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z ABCD................

C 460 87-015-819-080 CAPACITOR,0.01 ABCD................

C 413 87-016-369-080 C-CAP,S 0.033-25 B K ABCD................

C 420 87-016-369-080 C-CAP,S 0.033-25 B K ABCD................

C 438 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 495 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 510 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

Q 403 87-026-295-080 TR,DTC144TK ABCD................

Q 404 87-026-295-080 TR,DTC144TK ABCD................

Q 405 87-026-295-080 TR,DTC144TK ABCD................

D 401 87-070-345-080 DIODE,IN4148 ABCD................

D 402 87-070-345-080 DIODE,IN4148 ABCD................

D 403 87-070-345-080 DIODE,IN4148 ABCD................

CN 403 87-099-201-010 CONN,8P 6216 H ABCD................

C 411 87-A11-177-080 C-CAP,S 0.15-16 K B ABCD................

C 421 87-A11-177-080 C-CAP,S 0.15-16 K B ABCD................

C 419 87-A11-608-080 C-CAP,S 0.33-25 K B ABCD................

C 426 87-A11-608-080 C-CAP,S 0.33-25 K B ABCD................

IC 401 87-A20-446-010 C-IC,LA9241ML ABCD................

IC 402 87-A20-459-010 C-IC,LC78622ED ABCD................

IC 404 87-A21-093-010 IC,LA6541D ABCD................

CN 205 87-A60-109-010 CONN,2P V S2M-2W ABCD................

CN 401 87-A60-424-010 CONN,16P V TOC-B ABCD................

Q 401 89-109-332-380 TR,2SA933RS ABCD................

Q 402 89-113-187-080 TR,2SA1318TU ABCD................

CNA 402 8A-CD9-625-010 CONN ASSY,6P CD-ME ABCD................

X 401 8Z-CD5-633-010 VIB, CER16.93MHZ FCR16.93M2 ABCD................

C 491 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 492 87-010-221-080 CAP, ELECT 470-10V ABCD................

ELECTRICAL MAIN PARTS LIST - 4

Q 492 87-026-291-080 TR,DTC124XS ABCD................

D 491 87-070-345-080 DIODE,IN4148 ABCD................

D 494 87-070-345-080 DIODE,IN4148 ABCD................

Q 491 89-112-965-080 TR,2SA1296 (0.75W) ABCD................

CF 2 82-785-747-010 CF MS2 GHY R ....................

CF 3 82-785-747-010 CF MS2 GHY R ....................

L 10 87-005-849-080 COIL,10UH(CECS) ABCD................

CF 2 87-008-261-010 FILTER, SFE10.7MA5-A ABCD................

CF 3 87-008-261-010 FILTER, SFE10.7MA5-A ABCD................

C 4 87-010-148-080 CAP, CHIP S 75P SL ABCD................

C 42 87-010-150-080 C-CAP,S 6P-50 CH .BC.................

C 9 87-010-151-080 C-CAP,S 7P-50 CH ....................

C 56 87-010-152-080 C-CAP,S 8P-50 CH ABCD................

C 16 87-010-178-080 CHIP CAP 1000P ABCD................

C 24 87-010-188-080 CAP,CHIP 6800P .BC.................

C 25 87-010-188-080 CAP,CHIP 6800P .BC.................

C 8 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 10 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 22 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 32 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 33 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 34 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 35 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 37 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 38 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 51 87-010-197-080 CAP, CHIP 0.01 DM ABCD................

C 18 87-010-198-080 CAP, CHIP 0.022 ABCD................

C 30 87-010-248-080 CAP, ELECT 220-10V ABCD................

C 36 87-010-263-080 CAP, ELECT 100-10V ABCD................

C 9 87-010-311-080 CAP 12P ABCD................

C 1 87-010-314-080 C-CAP,S 22P-50V ABCD................

C 3 87-010-314-080 C-CAP,S 22P-50V ABCD................

C 12 87-010-314-080 C-CAP,S 22P-50V ABCD................

C 2 87-010-316-080 C-CAP,S 33P-50 CH ABCD................

C 2 87-010-318-080 C-CAP,S 47P-50 CH ....................

C 41 87-010-321-080 CHIP CAPACITOR,82P(J) .BC.................

C 13 87-010-322-080 C-CAP,S 100P-50 CH ABCD................

C 5 87-010-378-080 CAP, ELECT 10-16V ABCD................

C 31 87-010-379-080 CAP, ELECT 22-16V ABCD................

C 20 87-010-400-080 CAP, ELECT 0.47-50V ABCD................

C 21 87-010-403-080 CAP, ELECT 3.3-50V ABCD................

C 28 87-010-992-080 C-CAP,S 0.047-25 B ABCD................

C 29 87-010-992-080 C-CAP,S 0.047-25 B ABCD................

TC 5 87-011-253-080 TRIMER,30P LAR .BC.................

TC 6 87-011-253-080 TRIMER,30P LAR .BC.................

C 44 87-012-140-080 CAP 470P .BC.................

C 7 87-012-154-080 C-CAP,S 150P-50 CH ....................

C 7 87-012-156-080 C-CAP,S 220P-50 CH ABCD................

C 26 87-012-358-080 C-CAP,S 0.47-10 F Z ABCD................

C 27 87-012-358-080 C-CAP,S 0.47-10 F Z ABCD................

C 15 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 17 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

C 19 87-016-669-080 C-CAP,S 0.1-25 K B ABCD................

D 1 87-020-465-080 DIODE,1SS133 (110MA) ABCD................

D 2 87-020-465-080 DIODE,1SS133 (110MA) ABCD................

Q 4 87-026-213-080 CHIP-TR,DTC114YK ABCD................

Q 2 87-026-447-080 TR,2SC1740S R ABCD................

Q 3 87-026-463-080 TR,2SA933S (0.3W) ABCD................

IC 1 87-A20-955-010 IC,LA1828 ABCD................

D 13 87-A40-128-080 C-VARI-CAP,HVU202A ABCD................

L 8 87-A50-335-010 COIL,FM IFT (TOKO) ABCD................

L 17 87-A50-337-010 COIL,AM OSC (TOKO) ABCD................

L 2 87-A50-560-010 COIL,FM BPF(ACD) ABCD................

L 4 87-A50-561-010 COIL,FM RF D(ACD) ....................

L 4 87-A50-562-010 COIL,FM RF EX(ACD) ABCD................

L 5 87-A50-563-010 COIL,FM OSC D(ACD) ....................

L 5 87-A50-564-010 COIL,FM OSC EX(ACD) ABCD................

L 16 87-A50-569-010 COIL,LW OSC-ACD(COI) .BC.................

L 9 87-A50-577-010 COIL,FM DET(ACD) ABCD................

L 7 87-A50-579-010 COIL,AM IFT(ACD) ABCD................

CN 2 87-A60-116-010 CONN,6P H S2M-6WR ABCD................

CF 1 87-A90-128-010 FLTR,AM IF CFAL-455 ABCD................

VC 1 87-A91-167-010 TUN-CAP,20P-160P FA-22125 N000 A..D................

VC 1 87-A91-169-010 TUN-CAP,40P-140P FA-22124 AN00 ....................

S 1 87-A91-548-010 SW,SL-2-3 SK23E01G06 A..D................

S 1 87-A91-549-010 SW,SL-6-4 SK64D01G06 .BC.................

VC 1 87-A91-635-010 TUN-CAP,20P-140P E-ACD(MITSUMI .BC.................

Q 1 89-327-143-080 TR,2SC2714 (0.1W) ABCD................

L 3 8A-CD9-660-010 BAR-ANT,MW 2B-ACD(COI) A..D................

L 3 8A-CD9-661-010 BAR-ANT,MW/LW 3B-ACD(COI) .BC.................

MECHANICAL PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

510K<S> ................XX...................................B..................

510EZ<S> ...............XX....................................C.................

519LH1J<S> .............XX.....................................D................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

* 0001 8A-CD8-001-010 CABI,FR D ....................

* 8A-CD8-002-010 CABI,REAR D ....................

8A-CD8-003-010 LID,BATT ABCD................

8A-CD8-004-010 BOX,CD D ....................

8A-CD8-005-010 CHAS,CD D ....................

8A-CD8-006-010 BOX,CASS ABCD................

8A-CD8-007-010 WINDOW,CASS ABCD................

8A-CD8-008-010 HANDL,FR ABCD................

8A-CD8-009-010 HANDL,REAR ABCD................

8A-CD8-010-010 POINTER,TU ABCD................

8A-CD8-018-010 PANEL,FR L ABCD................

8A-CD8-019-010 WINDOW,DISPLAY D ....................

8A-CD8-020-010 WINDOW,DIAL D ....................

8A-CD8-021-010 CHAS,CASS ABCD................

8A-CD8-022-010 PANEL,FR R ABCD................

8A-CD8-023-010 CABI,FR EX ABCD................

8A-CD8-024-010 CABI,REAR U A..D................

8A-CD8-026-010 CABI,REAR EZ .BC.................

8A-CD8-027-010 BOX,CD EX ABCD................

8A-CD8-028-010 CHAS,CD EX ABCD................

8A-CD8-029-010 WINDOW,DIAL U A..D................

8A-CD8-030-010 WINDOW,DIAL EZ .BC.................

8A-CD8-031-010 WINDOW,DIAL HR ....................

8A-CD8-033-010 GRILLE,SPKR L ABCD................

8A-CD8-034-010 GRILLE,SPKR R ABCD................

8A-CD8-043-010 WINDOW,DISPLAY EX ABCD................

8Z-CDB-169-010 PANEL,CD SANYO ABCD................

8Z-CL7-107-010 BADGE,AIWA SILVER ABCD................

8A-CD8-011-010 KEY,CASS SET ABCD................

8A-CD8-012-010 KNOB,RTRY TU ABCD................

8A-CD8-013-010 KNOB,SL BAND ABCD................

8A-CD8-014-010 KEY,VOL ABCD................

8A-CD8-015-010 KEY,FUNC ABCD................

8A-CD8-016-010 KEY,CONTROL CD ABCD................

8A-CD8-017-010 KEY,QSOUND ABCD................

M8-ZZK-E90-070 DA11T3C ABCD................

84-CD5-215-010 GEAR ABCD................

84-CD5-216-010 BRACKET ABCD................

84-CT5-209-010 PLATE,MAGNET ABCD................

87-036-368-010 MAGNET ABCD................

88-CD8-209-010 SPR-C,BATT ABCD................

88-CD9-211-210 RING,CHUCK ABCD................

8A-CD8-201-010 GEAR,IDLER ABCD................

8A-CD8-202-010 LEVER,BAND ABCD................

8A-CD8-203-010 DRUM,DIAL ABCD................

* 8A-CD8-206-010 HLDR,LED ABCD................

8A-CD8-207-010 SPR-T,CASS ABCD................

8A-CD8-208-010 SPR-T,CD ABCD................

* 8A-CD8-209-010 HLDR,TRANS ABCD................

* 8A-CD8-210-010 HLDR,SPKR A ABCD................

* 8A-CD8-211-010 HLDR,SPKR B ABCD................

* 8A-CD8-212-010 HLDR,ANT ABCD................

8A-CD8-213-010 SPR-P,REC ABCD................

8Z-CDB-170-010 BASE,CHUCK ABCD................

87-067-566-010 TAPPING SCREW, VFTT+3-6 ABCD................

87-254-097-410 U+3-12 CR ABCD................

87-342-074-010 UT2+2.6-8 ABCD................

87-353-076-210 VT2+2.6-12 ABCD................

87-571-032-410 VIT+2-3 ABCD................

87-641-096-410 UT1+3-10 GLD ABCD................

87-661-097-410 TAPPING SCREW, VFT1+3-12 ABCD................

87-741-095-410 UT2+3-8 GLD ABCD................

87-741-097-410 UT2+3-12 ABCD................

87-B10-242-010 UT2+3-30 W/O CR ABCD................

87-WA5-253-010 W,3.3-10-0.8 ABCD................

* 87-036-389-010 SW,PUSH LOCK ABCD................

87-751-094-410 VT2+3-6 W10SL0T ABCD................

* 87-A60-178-010 JACK,AC E W/SW ABCD................

* 87-A60-179-010 JACK,AC D W/SW ....................

* 87-A90-086-010 COVER,AC-SOCKET ABCD................

* 87-A91-369-010 SW,AC SL 2 2 2 SDKGA41700 A..D................

SP 0 88-CD8-622-010 SPKR,F 77 7OHM 3W ABCD................

PT 901 8A-CD8-601-010 PT,D 2.5W ....................

PT 901 8A-CD8-603-010 PT,E 2.5W .BC.................

PT 901 8A-CD8-604-010 PT,H 2.5W A..D................

W 0 8A-CD9-620-010 FF-CABLE, 16P FR-MAIN ABCD................

W 0 8A-CD9-621-010 FF-CABLE, 16P CD-RF ABCD................

W 0 8A-CD9-622-010 FF-CABLE, 8P CD-FR ABCD................

CNA 0 8A-CD9-626-010 CONN ASSY,2P DOOR ABCD................

CNA 0 8A-CD9-630-010 CONN ASSY,4P RPH ABCD................

CNA 0 8A-CD9-631-010 CONN ASSY,4P TP-ME ABCD................

CNA 0 8A-CD9-633-010 CONN ASSY,4P SP ABCD................

* 8Z-CH4-640-010 ANT,ROD ABCD................

ACCESSORIES LIST

NOTE: The characters in the suffix column indicate the part usage.

510K<S> ................XX...................................B..................

510EZ<S> ...............XX....................................C.................

519LH1J<S> .............XX.....................................D................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8A-CD8-901-010 IB,H(ECA)B ....................

8A-CD8-902-010 IB,LH(ESP)B ....................

8A-CD8-905-010 IB,K(E)B .B..................

8A-CD8-906-010 IB,EZ(9L)B ..C.................

8A-CD8-908-010 IB,D(J)B ....................

8A-CD9-902-010 IB,LH(ESP)B A...................

8A-CD8-940-010 IB,LH1(P)KIT ...D................

87-A80-033-010 AC CORD SET,D BLK ....................

87-A80-034-010 AC CORD SET ASSY,K W/F MAY-BG .B..................

87-A80-036-010 AC CORD SET ASSY,E W/FLTR VOL A.CD................

87-A90-312-010 PLUG,CONVERSION WTN-1157R1 A..D................

2-11, IKENOHATA 1-CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111

931196 Printed in Singapore

Other manuals for CSD-A510

This manual suits for next models

Table of contents

Popular Stereo System manuals by other brands

Sony

Sony HCD-VX88 Service manual

Philips

Philips MCM398D/12 user manual

Sony

Sony CMT-SPZ90DB operating instructions

LG OM4560 owner's manual

JVC

JVC UX-G3 instructions

Odys

Odys ODYS - LOOP instruction manual

Panasonic

Panasonic SC-AK100 operating instructions

Sharp

Sharp CD-G10000V Operation manual

Bogen

Bogen NEARSCAPES 4.1 manual

Panasonic

Panasonic SCPM29 - MINI HES W/CD PLAYER operating instructions

Meyer

Meyer LD-3 operating instructions

THOMSON

THOMSON MIC302U manual

Philips

Philips MCM530 Service manual

Sony

Sony SS-CEP50 Service manual

Cetacea Sound

Cetacea Sound CVS-II user guide

Sony

Sony MHC-V21D Service manual

Denon

Denon UCD-250 Service manual

Exibel

Exibel BDX600-UK user manual

Aiwa CSD-A510 User manual

Popular Stereo System manuals by other brands
