Aiwa HT-DV90 User manual

SERVICE MANUAL
DATA
DVD STEREO SYSTEM
HT-DV90
S/M Code No. 09-01C-359-3R1
U (S) K(S) EZ(S)
BASIC DVD/CD MECHANISM: MGD-F6103A
This Service Manual is the ”Revision Publishing” and replace
“Simple Manual” (S/M Code No. 09-01B-359-3T1).
REVISION
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-2-
TABLE OF CONTENTS
SPECIFICATIONS.....................................................................................................................................................................3 ~ 4
PROTECTION OF EYES FROM LASER BEAM DURING SERVING ............................................................................................5
ACCESSORIES LIST ......................................................................................................................................................................6
ELECTRICAL MAIN PARTS LIST ...........................................................................................................................................7 ~ 23
TRANSISTOR ILLUSTRATION.....................................................................................................................................................24
BLOCK DIAGRAM - 1 (OVERALL) ...............................................................................................................................................25
WIRE HARNESS DIAGRAM .........................................................................................................................................................26
SCHEMATIC DIAGRAM - 1 (MAIN SECTION - 1/2) .....................................................................................................................27
SCHEMATIC DIAGRAM - 2 (MAIN SECTION - 2/2) .....................................................................................................................28
SCHEMATIC DIAGRAM - 3 (FRONT/KEY1/KEY2 SECTION) .....................................................................................................31
SCHEMATIC DIAGRAM - 4 (FUNCTION SECTION)....................................................................................................................34
SCHEMATIC DIAGRAM - 5 (POWER SECTION) <EZ, K> ..........................................................................................................36
SCHEMATIC DIAGRAM - 6 (POWER SECTION) <U>.................................................................................................................38
SCHEMATIC DIAGRAM - 7 (DVD MAIN SECTION).....................................................................................................................40
WIRING - 1 (MAIN C.B -1/2) .........................................................................................................................................................29
WIRING - 2 (MAIN C.B -2/2) .........................................................................................................................................................30
WIRING - 3 (FRONT C.B) .............................................................................................................................................................32
WIRING - 4 (KEY1/KEY2 C.B) ......................................................................................................................................................33
WIRING - 5 (FUNCTION C.B).......................................................................................................................................................35
WIRING - 6 (POWER LED C.B) <EZ, K>......................................................................................................................................37
WIRING - 7 (POWER LED C.B) <U> ............................................................................................................................................39
WIRING - 8 (DVD C.B)..................................................................................................................................................................41
DVD SECTION WIRING DIAGRAM 1/1........................................................................................................................................42
LCD DISPLAY ...............................................................................................................................................................................43
IC BLOCK DIAGRAM............................................................................................................................................................44 ~ 47
IC DESCRIPTION .................................................................................................................................................................48 ~ 62
MECHANICAL EXPLODED VIEW 1/1 ..........................................................................................................................................63
MECHANICAL MAIN PARTS LIST 1/1.........................................................................................................................................64
COLOR NAME TABLE ..................................................................................................................................................................65
MECHANISM EXPLODED VIEW 1/1............................................................................................................................................66
MECHANISM MAIN PARTS LIST 1/1 ...........................................................................................................................................67
OTHER PARTS LIST 1/1...............................................................................................................................................................68
SPEAKER EXPLODED VIEW 1/1.................................................................................................................................................69
SPEAKER PARTS LIST 1/1 ..........................................................................................................................................................70
SPEAKER OTHER PARTS LIST 1/1.............................................................................................................................................71
SPEAKER DISASSEMBLY INSTRUCTION ..........................................................................................................................72 ~ 73
AMPLIFIER ADJUSTMENT ..........................................................................................................................................................74
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-3-
SPECIFICATIONS -1/2
[EZ, K Models]
Main unit HT-DV90
FM tuner section
Tuning range 87.5 MHz to 108 MHz
Usable sensitivity (IHF) 16.2 dBf
Antenna jack 75 ohms (unbalanced)
AM tuner section
Tuning range 531 kHz to 1629 kHz (9 kHz step)
530 kHz to 1710 kHz (10 kHz step)
Usable sensitivity 700 µV/m
Antenna Loop antenna
Amplifier section
Power output Front
Rated: 38 W + 38 W
(6 ohms, T.H.D 1%, 1 kHz/DIN 45500)
Reference: 50 W + 50 W
(6 ohms, T.H.D. 10%, 1 kHz/DIN 45324)
DIN MUSIC POWER: 50 W + 50 W
Rear (Surrond)
Rated: 38 W + 38 W
(6 ohms, T.H.D 1%, 1 kHz/DIN 45500)
Reference: 50 W + 50 W
(6 ohms, T.H.D. 10%, 1 kHz/DIN 45324)
DIN MUSIC POWER: 50 W + 50 W
Center
Rated: 38 W
(6 ohms, T.H.D 1%, 1 kHz/DIN 45500)
Reference: 50 W
(6 ohms, T.H.D. 10%, 1 kHz/DIN 45324)
DIN MUSIC POWER: 50 W
Subwoofer
Rated: 38 W
(6 ohms, T.H.D 1%, 100 Hz/DIN 45500)
Reference: 50 W
(6 ohms, T.H.D. 10%, 100 Hz/DIN 45324)
DIN MUSIC POWER: 50 W
Total harmonic distortion 0.2% (10 W, 1 kHz, 6 ohms, DIN AUDIO,
Front)
Input/output
Input AUDIO VIDEO 1 IN, AUDIO VIDEO 2 IN:
370 mV (47 kohms)
OPTICAL IN VIDEO 1, OPTICAL IN VIDEO 2:
accept linear PCM signals and Dolby Digital
and DTS surround bitstream (32 kHz,
44.1 kHz, 48 kHz, and 96 kHz)
VIDEO VIDEO 1 IN, VIDEO VIDEO 2 IN:
1 Vp-p (75 ohms, unbalanced)
Output AUDIO VIDEO 1 OUT: 350 mV (47 kohms)
OPTICAL OUT
VIDEO VIDEO 1 OUT, VIDEO OUT:
1 Vp-p (75 ohms, unbalanced)
S-VIDEO OUT
Y output: 1 Vp-p (75 ohms, sync negative)
C output: 0.286 Vp-p
FRONT SPEAKERS: accept speakers of
6 ohms
SURROUND SPEAKERS: accept speakers
of 6 ohms
CENTER SPEAKER: accept speakers of
6 ohms
SUB WOOFER terminal: 6 ohms
SUB WOOFER jack: 1 V
PHONES (mini jack): accepts headphones of
32 phms or more
General
Power requirements 230 V AC, 50 Hz
Power consumption 85 W
Power consumption 4W in standby mode
Dimensions 430 (W) x 70 (H) x 311 (D) mm
Weight 4.3 kg
Disc player section
Colour system PAL/MULTI/NTSC (Switchable)
Supported discs DVD video discs
12 cm (single-sided sigle-layer, single-sided
double-layer, double-sided-doubel layer)
8 cm (single-sided sigle-layer, single-sided
double-layer, double-sided-doubel layer)
Compact discs (CD-DA, CD-R/RW, video
CD)
12 cm and 8 cm discs
Audio output characteristics
Frequency range: 20 Hz to 20 kHz
Operating conditions 5 °C to 35 °C (41 °F to 95 °F)
Spekaer system
Speakers Front, Surround, Center: full range, 100 mm
bass reflex type
Subwoofer: 200 mm, bass reflex type
Impedance 6 ohms
Maximum input power 55 W (peak)
Dimensions (W x H x D) SX-F90 (Front): 115 x 153 x 138 mm
SX-R90 (Surround): 115 x 153 x 138 mm
SX-C90 (Center): 153 x 115 x 138 mm
TS-W90 (Subwoofer): 180 x 335 x 390 mm
Weight SX-F90 (Front): 1 kg
SX-R90 (Surround): 0.8 kg
SX-C90 (Center): 1 kg
TS-W90 (Subwoofer): 4.9 kg
• Design and specifications are subject to change without notice.
• Manufactured under license from Dolby Laboratories. ”Dolby”, “Pro Logic”
and the double-D symbol are trademarks of Dolby Laboratories. Confi-
dential unpublished works. ©1992-1997 Dolby Laboratories. All right re-
served.
• Manufactured under license from Digital Theatre Systems, Inc. US Pat.
No. 5,451,942 and other worldwide patents issued and pending. “DTS”
and “DTS Digital Surround” are trademarks of Digital Theatre Systems,
Inc. ©1996 Digital Theatre Systems, Inc. All right reserved.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-4-
[U Model]
Main unit HT-DV90
FM tuner section
Tuning range 87.5 MHz to 108 MHz
Usable sensitivity (IHF) 16.2 dBf
Antenna jack 75 ohms (unbalanced)
AM tuner section
Tuning range 531 kHz to 1629 kHz (9 kHz step)
530 kHz to 1710 kHz (10 kHz step)
Usable sensitivity 700 µV/m
Antenna Loop antenna
Amplifier section
Power output Front
Rated: 38 W + 38 W
(40 Hz - 20 kHz, T.H.D less than 1%, 6 ohms)
Reference: 50 W + 50 W
(40 Hz - 20 kHz,T.H.D less than 10%, 6 ohms)
Setting range: 1 FT to 30 FT (feet)
Rear (Surrond)
Rated: 38 W + 38 W
(40 Hz - 20 kHz, T.H.D less than 1%, 6 ohms)
Reference: 50 W + 50 W
(40 Hz - 20 kHz,T.H.D less than 10%, 6 ohms)
Setting range: 1 FT to 30 FT (feet)
Center
Rated: 38 W
(40 Hz - 20 kHz, T.H.D less than 1%, 6 ohms)
Reference: 50 W
(40 Hz - 20 kHz,T.H.D less than 10%, 6 ohms)
Setting range: 1 FT to 30 FT (feet)
Subwoofer
Rated: 38 W
(40 Hz - 20 kHz, T.H.D less than 1%, 6 ohms)
Reference: 50 W
(40 Hz - 20 kHz,T.H.D less than 10%, 6 ohms)
Setting range: 1 FT to 30 FT (feet)
Total harmonic distortion 0.2% (10 W, 1 kHz, 6 ohms, DIN AUDIO,
Front)
Input/output
Input AUDIO VIDEO 1 IN, AUDIO VIDEO 2 IN:
370 mV (47 kohms)
OPTICAL IN VIDEO 1, OPTICAL IN VIDEO 2:
accept linear PCM signals and Dolby Digital
and DTS surround bitstream (32 kHz,
44.1 kHz, 48 kHz, and 96 kHz)
VIDEO VIDEO 1 IN, VIDEO VIDEO 2 IN:
1 Vp-p (75 ohms, unbalanced)
Output AUDIO VIDEO 1 OUT: 350 mV (47 kohms)
OPTICAL OUT
VIDEO VIDEO 1 OUT, VIDEO OUT:
1 Vp-p (75 ohms, unbalanced)
S-VIDEO OUT
Y output: 1 Vp-p (75 ohms, sync negative)
C output: 0.286 Vp-p
FRONT SPEAKERS: accept speakers of
6 ohms
SURROUND SPEAKERS: accept speakers
of 6 ohms
CENTER SPEAKER: accept speakers of
6 ohms
SUB WOOFER terminal: 6 ohms
SUB WOOFER jack: 1 V
PHONES (mini jack): accepts headphones of
32 phms or more
General
Power requirements 120 VAC, 60 Hz
Power consumption 85 W
Power consumption 4W in standby mode
Dimensions 430 (W) x 70 (H) x 311 (D) mm
(17 x 2 7/8x 12 1/4in.)
Weight 4.3 kg (9 lbs 8 oz)
Disc player section
Colour system NTSC/MULTI/PAL (Switchable)
Supported discs DVD video discs
12 cm (single-sided sigle-layer, single-sided
double-layer, double-sided-doubel layer)
8 cm (single-sided sigle-layer, single-sided
double-layer, double-sided-doubel layer)
Compact discs (CD-DA, CD-R/RW)
12 cm and 8 cm discs
Audio output characteristics
Frequency range: 20 Hz to 20 kHz
Operating conditions 5 °C to 35 °C (41 °F to 95 °F)
Spekaer system
Speakers Front, Surround, Center: full range, 100 mm
(4 in.), bass reflex type
Subwoofer: 200 mm (77/8in.), bass reflex type
Impedance 6 ohms
Maximum input power 55 W (peak)
Dimensions (W x H x D) SX-F90 (Front): 115 x 153 x 138 mm
(4 5/8x 6 1/8x 5 1/2in.)
SX-R90 (Surround): 115 x 153 x 138 mm
(4 5/8x 6 1/8x 5 1/2in.)
SX-C90 (Center): 153 x 115 x 138 mm
(6 1/8x 4 5/8x 5 1/2in.)
TS-W90 (Subwoofer): 180 x 335 x 390 mm
(7 1/8x 13 1/4x 15 3/8in.)
Weight SX-F90 (Front): 1 kg (2 lbs 30 z)
SX-R90 (Surround): 0.8 kg (1 lbs 120 z)
SX-C90 (Center): 1 kg (2 lbs 30 z)
TS-W90 (Subwoofer): 4.9 kg (10 lbs 130 z)
•Design and specifications are subject to change without notice.
•Manufactured under license from Dolby Laboratories. ”Dolby”, “Pro Logic”
and the double-D symbol are trademarks of Dolby Laboratories. Confi-
dential unpublished works. ©1992-1997 Dolby Laboratories. All right re-
served.
•Manufactured under license from Digital Theatre Systems, Inc. US Pat.
No. 5,451,942 and other worldwide patents issued and pending. “DTS”
and “DTS Digital Surround”are trademarks of Digital Theatre Systems,
Inc. ©1996 Digital Theatre Systems, Inc. All right reserved.
SPECIFICATIONS -2/2
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

-5-
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING -1/1
This set employs laser. Therefore, be sure to follow carefully the instructions below
when servicing.
WARNING!
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT
WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY
TO CONFIRM LASER BEAM EMISSION.
BE SURE TO OBSERVE FROM A DISTANCE OF MORE THAN
30cm FROM THE SURFACE OF THE OBJECTIVE LENS ON
THE OPTICAL PICK-UP BLOCK.
Caution: Invisible laser radiation when open
and interlocks defeated avoid exposure to
beam.
Advarsel: Usynlig laerståling ved åbning, når
sikkerhedsafbrydere er ude af funktion.
Undgå udsættelse for stråling.
VAROITUS!
Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa
mainitulla tavalla saataa altistaa käyt-täjän turvallisuusluokan
1 ylittävälle näkymättömälle lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än vad som specificeras i
denna bruksanvising, kan användaren utsättas för osynling
laserstrålning, som överskrider gränsen för laserklass 1.
CAUTION
Use of controls or adjustments or performance of procedures other
than those specified herin may result in hazardous radiation
exposure.
ATTENTION
L’utillisation de commandes, réglages ou procédures autres que
ceux spécifiés peut entraîner une dangereuse exposition aux
radiations.
ADVARSEL!
Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude
af funktion. Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1 LASER
product.
The CLASS 1 LASER PRODUCT label is located on the rear
exterior.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-6-
ACCESSORIES PARTS LIST -1/1
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
O AS1001 SQ-X1A-755-Z00 MANUAL,INSTRUCTION a . .
O AS1001 SQ-X1A-750-Y00 MANUAL,INSTRUCTION . b .
O AS1001 SQ-X1A-750-Z00 MANUAL,INSTRUCTION . b .
O AS1001 SQ-X1A-765-Z00 MANUAL,INSTRUCTION . . c
O AS1002 SA-RTB-AX2-UC0 RC UNIT,RC-BAR03 a . .
O AS1002 SA-RTB-AX2-EZ0 RC UNIT,RC-BAR01 . b c
O AS1003 SS-A1A-020-Z00 AM LOOP ANT a b c
O AS1004 SS-A1A-019-Z00 FM 1 POL ANT(UL) a . .
O AS1004 SS-A1A-018-Z00 FM 1 POLE ANT(EZ) . b c
O AS1005 SJ-S4M-023-Z00 CORD,PIN (1P)YELLOW(1.5M) a b c
O AS1006 SJ-S3L-004-Z00 ADAPTOR,UK (240V) . . c
O AS1007 SW-X1A-030-000 CABLE SPEAKER,5M (SUB) a b c
O AS1008 SW-X1A-029-000 CABLE SPEAKER,3M (CENTER) a b c
O AS1009 SW-X1A-027-000 CABLE SPEAKER,4M (FRONT) a b c
O AS1010 SW-X1A-028-000 CABLE SPEAKER,8M (REAR) a b c
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-7-
ELECTRICAL PARTS LIST - 1/17
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
DVD MAIN O C 101 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 102 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 103 SC-EC0-JRV-210 C-CAP,E 100U-6.3 a b c
DVD MAIN O C 105 SC-EC0-JRV-210 C-CAP,E 100U-6.3 a b c
DVD MAIN O C 111 SC-EC0-JRV-210 C-CAP,E 100U-6.3 a b c
DVD MAIN O C 112 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 114 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 116 SC-EC0-JRV-247 C-CAP,E 47U-6.3 a b c
DVD MAIN O C 117 SC-US1-H27-0JA C-CAP,27P-50 J a b c
DVD MAIN O C 118 SC-US1-H27-0JA C-CAP,27P-50 J a b c
DVD MAIN O C 120 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 121 SC-EC0-JSE-331 C-CAP,E 330U-6.3 a b c
DVD MAIN O C 123 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 124 SC-EC0-JRV-210 C-CAP,E 100U-6.3 a b c
DVD MAIN O C 142 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 144 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 146 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 150 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 152 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 154 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
DVD MAIN O C 155 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 156 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 158 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 159 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 160 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 162 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 163 SC-US1-H15-1JA C-CAP,150P-50 J a b c
DVD MAIN O C 164 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 165 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 166 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 168 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 169 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 171 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 173 SC-EC0-JRV-210 C-CAP,E 100U-6.3 a b c
DVD MAIN O C 178 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 179 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 186 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 188 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 190 SC-EC0-JRV-247 C-CAP,E 47U-6.3 a b c
DVD MAIN O C 191 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
DVD MAIN O C 192 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 285 SC-EC0-JSE-331 C-CAP,E 330U-6.3 a b c
DVD MAIN O C 286 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O C 287 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c
DVD MAIN O CN 010 SJ-P17-GA1-17Z WAFER,CARD CABLE GF102-17S-TS a b c
DVD MAIN O CN 012 SJ-P40-GB8-0ZP 40P HEADER (ANGLE TYPE)2110DR a b c
DVD MAIN O FFC001 SW-ZHT-S50-00B CABLE,ATAPI(FLATE,40P) a b c
DVD MAIN S IC 001 SV-IES-431-8F0 IC,ES4318F a b c
DVD MAIN S IC 003 SV-IHY-29F-400 IC,HY29F400BT90 a b c
DVD MAIN S IC 007 SV-I74-VHC-04M IC,74VHC04M a b c
DVD MAIN S IC 008 SV-IRC-111-7ST IC,RC1117ST a b c
DVD MAIN S IC 009 SV-IRC-111-7ST IC,RC1117ST a b c
DVD MAIN S IC 010 SV-IHY-57V-161 IC,HY57V161610DTC8 a b c
DVD MAIN S IC 011 SV-IHY-57V-161 IC,HY57V161610DTC8 a b c
DVD MAIN S IC 013 SV-IBR-24C-16F IC,2K*8 SOP8 a b c
DVD MAIN S IC 014 SV-ICS-495-500 IC,CS4955 a b c
DVD MAIN O L 101 SL-Z9Z-005-Z00 FERRITE CORE,6*10(A) + COIL a b c
DVD MAIN O L 102 SL-Z9Z-005-Z00 FERRITE CORE,6*10(A) + COIL a b c
DVD MAIN X L 104 SR-J10-DJ0-R0T C-RES,0-1/10W J a b c
DVD MAIN X L 105 SR-J10-DJ0-R0T C-RES,0-1/10W J a b c
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
DVD MAIN X R 101 SR-J10-DJ3-61T C-RES,360-1/10W J a b c
DVD MAIN X R 106 SR-J10-DJ0-R0T C-RES,0-1/10W J a b c
DVD MAIN X R 107 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c
DVD MAIN X R 108 SR-J10-DJ1-05T C-RES,1M-1/10W J a b c
DVD MAIN X R 109 SR-J10-DJ1-21T C-RES,120-1/10W J a b c
DVD MAIN X R 110 SR-J10-DJ1-21T C-RES,120-1/10W J a b c
DVD MAIN X R 111 SR-J10-DJ1-21T C-RES,120-1/10W J a b c
DVD MAIN X R 112 SR-J10-DJ1-21T C-RES,120-1/10W J a b c
DVD MAIN X R 113 SR-J10-DJ2-21T C-RES,220-1/10W J a b c
DVD MAIN X R 114 SR-J10-DJ4-31T C-RES,430-1/10W J a b c
DVD MAIN X R 115 SR-J10-DJ2-21T C-RES,220-1/10W J a b c
DVD MAIN X R 116 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c
DVD MAIN X R 117 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 118 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 119 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 120 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c
DVD MAIN X R 121 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 123 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 125 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 126 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-8-
ELECTRICAL PARTS LIST - 2/17
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
DVD MAIN X R 127 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 128 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 129 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 130 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 131 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 132 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 133 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 134 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 135 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 136 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 137 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 138 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 139 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 140 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 141 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 142 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 143 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 144 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 145 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 146 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
DVD MAIN X R 147 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 148 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 149 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 150 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 151 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 152 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 153 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 154 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 155 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 156 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 157 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 158 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 159 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 160 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 162 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 163 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 164 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 165 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 166 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 167 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
DVD MAIN X R 168 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 169 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 170 SR-J10-DJ4-70T C-RES,47-1/10W J a b c
DVD MAIN X R 171 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 172 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 173 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 174 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 175 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 176 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 177 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 178 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 179 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 180 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 181 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 182 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 183 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 184 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 185 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 186 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 187 SR-J10-DJ4-70T C-RES,47-1/10W J a b c
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
DVD MAIN X R 188 SR-J10-DJ4-70T C-RES,47-1/10W J a b c
DVD MAIN X R 189 SR-J10-DJ4-70T C-RES,47-1/10W J a b c
DVD MAIN X R 190 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 191 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 192 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 193 SR-J10-DJ4-70T C-RES,47-1/10W J a b c
DVD MAIN X R 194 SR-J10-DJ4-70T C-RES,47-1/10W J a b c
DVD MAIN X R 195 SR-J10-DJ4-70T C-RES,47-1/10W J a b c
DVD MAIN X R 196 SR-J10-DJ4-70T C-RES,47-1/10W J a b c
DVD MAIN X R 197 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c
DVD MAIN X R 198 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c
DVD MAIN X R 200 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c
DVD MAIN X R 201 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 203 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
DVD MAIN X R 208 SR-J10-DJ0-R0T C-RES,0-1/10W J a b c
DVD MAIN X R 213 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c
DVD MAIN X R 214 SR-J10-DJ0-R0T C-RES,0-1/10W J a b c
DVD MAIN X R 217 SR-J10-DJ1-01T C-RES,100-1/10W J a b c
DVD MAIN X R 218 SR-J10-DJ1-01T C-RES,100-1/10W J a b c
DVD MAIN X R 219 SR-J10-DJ1-52T C-RES,1.5K-1/10W J a b c
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-9-
ELECTRICAL PARTS LIST - 3/17
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
DVD MAIN X R 220 SR-J10-DJ1-52T C-RES,1.5K-1/10W J a b c
DVD MAIN X R 222 SR-J10-DJ1-01T C-RES,100-1/10W J a b c
DVD MAIN X R 223 SR-J10-DJ1-01T C-RES,100-1/10W J a b c
DVD MAIN X R 225 SR-J10-DJ1-01T C-RES,100-1/10W J a b c
DVD MAIN X R 226 SR-J10-DJ1-01T C-RES,100-1/10W J a b c
DVD MAIN X R 228 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c
DVD MAIN X R 229 SR-J10-DF4-02T C-RES,4.0K-1/10W F a b c
DVD MAIN X R 230 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 231 SR-J10-DJ3-30T C-RES,33-1/10W J a b c
DVD MAIN X R 248 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c
DVD MAIN X R 249 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c
DVD MAIN X R 250 SR-J10-DJ3-31T C-RES,330-1/10W J a b c
DVD MAIN X R 251 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c
DVD MAIN X R 252 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c
DVD MAIN X R 260 SR-J10-DJ0-R0T C-RES,0-1/10W J a b c
DVD MAIN X R 261 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 262 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 263 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 264 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
DVD MAIN X R 267 SR-J10-DJ7-50T C-RES,75-1/10W J a b c
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
DVD MAIN X R 268 SR-J10-DJ8-20T C-RES,82-1/10W J a b c
DVD MAIN X R 269 SR-J10-DJ7-50T C-RES,75-1/10W J a b c
DVD MAIN X R 270 SR-J10-DJ7-50T C-RES,75-1/10W J a b c
DVD MAIN X R 271 SR-J10-DJ7-50T C-RES,75-1/10W J a b c
DVD MAIN X R 272 SR-J10-DJ7-50T C-RES,75-1/10W J a b c
DVD MAIN X R 273 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c
DVD MAIN O X 101 SO-X27-000-E18 C-VIB,XTAL 27MHZ a b c
FRONT X BN 073 SW-B1A-008-120 WIRE ASSY a b c
FRONT O C 711 SC-US1-H10-3KC CAP,CHIP a b c
FRONT O C 712 SC-EA0-JH1-02T CAP,E 1000U-6.3V a b c
FRONT O C 713 SC-US1-H10-3KC CAP,CHIP a b c
FRONT O C 714 SC-ES0-HD1-040 CAP,GOLD 0.1-5.5 a b c
FRONT O C 715 SC-EA1-CKS-470 CAP,E 47U-16 a b c
FRONT O C 716 SC-EA1-CKS-470 CAP,E 47U-16 a b c
FRONT O C 717 SC-EA1-CKS-470 CAP,E 47U-16 a b c
FRONT O C 718 SC-US1-H10-3KC CAP,CHIP a b c
FRONT O C 719 SC-EA1-HKS-2R2 CAP,E 2.2U-50 a b c
FRONT O C 720 SC-US1-H22-0JA C-CAP,22P-50 J a b c
FRONT O C 721 SC-US1-H22-0JA C-CAP,22P-50 J a b c
FRONT O C 733 SC-EA1-CKS-470 CAP,E 47U-16 a b c
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
FRONT O C 734 SC-US1-H10-1JA C-CAP,100P-50 J a b c
FRONT O C 735 SC-US1-H10-3KC CAP,CHIP a b c
FRONT O C 736 SC-EA1-VKS-100 CAP,E 10U-35 a b c
FRONT O C 737 SC-US1-H10-3KC CAP,CHIP a b c
FRONT O C 738 SC-US1-H10-3KC CAP,CHIP a b c
FRONT O C 743 SC-EA1-HKS-1R0 CAP,E 1.0U-50 a b c
FRONT O C 746 SC-US1-H10-3KC CAP,CHIP a b c
FRONT O C 747 SC-US1-H10-3KC CAP,CHIP a b c
FRONT O C 751 SC-US1-H82-1JA C-CAP,820P-50 J a b c
FRONT O C 752 SC-US1-H82-1JA C-CAP,820P-50 J a b c
FRONT O C 753 SC-US1-H82-1JA C-CAP,820P-50 J a b c
FRONT O CN 071 SJ-P23-GA1-17Z WAFER,CARD CABLE GF102-23S-TS a b c
FRONT O CN 072 SJ-P17-GA1-17Z WAFER,CARD CABLE GF102-17S-TS a b c
FRONT O CN 074 SJ-P03-GA1-9ZM WAFER a b c
FRONT S D 711 SV-DRB-160-L60 DIODE,RB160L-60TE25 a b c
FRONT S D 712 SV-DRB-160-L60 DIODE,RB160L-60TE25 a b c
FRONT S D 713 SV-D1S-S13-3MT DIODE,1SS133T-77 a b c
FRONT S D 714 SV-D1S-S13-3MT DIODE,1SS133T-77 a b c
FRONT S D 715 SV-D1S-S13-3MT DIODE,1SS133T-77 . b c
FRONT S D 716 SV-D1S-S13-3MT DIODE,1SS133T-77 . b c
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
FRONT S D 717 SV-D1S-S13-3MT DIODE,1SS133T-77 . b c
FRONT S FIP007 SF-LHN-A10-SM1 F.I.P,HNA-10SM17 a b c
FRONT S IC 071 SV-ITM-P87-PS7 IC,TMP87PS71F a b c
FRONT O L 711 SL-Q02-C10-0KT COIL,10UH K a b c
FRONT S Q 711 SV-TKS-B81-1YT TR,KSB811Y a b c
FRONT S Q 712 SV-TKR-C10-2MT TR,KRC102M a b c
FRONT S Q 713 SV-TKR-C10-2MT TR,KRC102M a b c
FRONT S Q 714 SV-TKR-A10-2MT TR,KRA102M a b c
FRONT S Q 715 SV-TKR-C10-2MT TR,KRC102M a b c
FRONT S Q 735 SV-TKR-C10-2MT TR,KRC102M a b c
FRONT S Q 736 SV-TKR-C10-2MT TR,KRC102M a b c
FRONT S Q 743 SV-TKR-C10-2MT TR,KRC102M a b c
FRONT X R 711 SR-J10-DJ1-00T C-RES,10-1/10W J a b c
FRONT X R 712 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c
FRONT X R 713 SR-J10-DJ2-23T C-RES,22K-1/10W J a b c
FRONT X R 714 SR-J10-DJ2-23T C-RES,22K-1/10W J a b c
FRONT X R 715 SR-J10-DJ1-22T C-RES,1.2K-1/10W J a b c
FRONT X R 716 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 717 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 718 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-10-
ELECTRICAL PARTS LIST - 4/17
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
FRONT X R 719 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c
FRONT X R 720 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 721 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c
FRONT X R 722 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 723 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 724 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 725 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 726 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 729 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 730 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 731 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 732 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 733 SR-J10-DJ1-01T C-RES,100-1/10W J a b c
FRONT X R 734 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c
FRONT X R 737 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 738 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 739 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 740 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 741 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 742 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
FRONT X R 743 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 744 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
FRONT X R 745 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c
FRONT X R 746 SR-J10-DJ2-72T C-RES,2.7K-1/10W J a b c
FRONT X R 747 SR-J10-DJ2-72T C-RES,2.7K-1/10W J a b c
FRONT X R 748 SR-J10-DJ1-22T C-RES,1.2K-1/10W J a b c
FRONT X R 749 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c
FRONT X R 751 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 752 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 753 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c
FRONT X R 754 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c
FRONT X R 755 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c
FRONT X R 756 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c
FRONT X R 757 SR-J10-DJ1-52T C-RES,1.5K-1/10W J a b c
FRONT X R 758 SR-J10-DJ1-52T C-RES,1.5K-1/10W J a b c
FRONT X R 759 SR-J10-DJ1-52T C-RES,1.5K-1/10W J a b c
FRONT X R 760 SR-J10-DJ1-82T C-RES,1.8K-1/10W J a b c
FRONT X R 762 SR-J10-DJ1-82T C-RES,1.8K-1/10W J a b c
FRONT X R 763 SR-J10-DJ2-72T C-RES,2.7K-1/10W J a b c
FRONT X R 765 SR-J10-DJ2-72T C-RES,2.7K-1/10W J a b c
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
FRONT X R 766 SR-J10-DJ3-32T C-RES,3.3K-1/5W J a b c
FRONT X R 768 SR-J10-DJ3-32T C-RES,3.3K-1/5W J a b c
FRONT X R 769 SR-J10-DJ5-62T C-RES,5.6K-1/10W J a b c
FRONT X R 771 SR-J10-DJ5-62T C-RES,5.6K-1/10W J a b c
FRONT O RC 073 SR-VKS-M60-3TH REMOCON SENSER,KSM-603TH2 a b c
FRONT O S 751 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 752 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 753 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 754 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 755 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 756 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 757 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 759 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 760 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 762 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 763 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 765 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 766 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 768 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
FRONT O S 769 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c
HT-DV90 HT-DV90 HT-DV90
USC EZSC KSC
FRONT O VR 074 SS-R2A-018-Z00 VR,ENCODER a b c
FRONT O X 721 SO-X08-000-E16 VIB,XTAL 8.0MHz a b c
FUNCTION O C 107 SC-US1-H15-1JA C-CAP,150P-50 J a b c
FUNCTION O C 108 SC-US1-H15-1JA C-CAP,150P-50 J a b c
FUNCTION O C 109 SC-US1-H15-1JA C-CAP,150P-50 J a b c
FUNCTION O C 110 SC-US1-H15-1JA C-CAP,150P-50 J a b c
FUNCTION O C 111 SC-US1-H15-1JA C-CAP,150P-50 J a b c
FUNCTION O C 112 SC-US1-H15-1JA C-CAP,150P-50 J a b c
FUNCTION O C 115 SC-EA1-CH1-01T CAP,E 100U-16 a b c
FUNCTION O C 116 SC-EA1-CH1-01T CAP,E 100U-16 a b c
FUNCTION O C 117 SC-US1-H10-3KC CAP,CHIP a b c
FUNCTION O C 118 SC-US1-H10-3KC CAP,CHIP a b c
FUNCTION O C 119 SC-US1-H22-2KC C-CAP,2200P-50 K a b c
FUNCTION O C 120 SC-US1-H22-2KC C-CAP,2200P-50 K a b c
FUNCTION O C 121 SC-EA1-CH1-01T CAP,E 100U-16 a b c
FUNCTION O C 122 SC-EA1-CH1-01T CAP,E 100U-16 a b c
FUNCTION O C 123 SC-US1-H47-1JA C-CAP,470P-50 J a b c
FUNCTION O C 124 SC-US1-H47-1JA C-CAP,470P-50 J a b c
FUNCTION O C 125 SC-US1-H47-1JA C-CAP,470P-50 J a b c
FUNCTION O C 126 SC-US1-H10-3KC CAP,CHIP a b c
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
