SERVICE MANUAL

DATA

DVD STEREO SYSTEM

HT-DV90

S/M Code No. 09-01B-359-3T1

U (S) K(S) EZ(S)

BASIC DVD/CD MECHANISM: MGD-F6103A

Replace this Service Manual with ”Revision Publishing” when it is issued.

SIMPLE

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-2-

ACCESSORIES PARTS LIST -1/1

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

O 1 SQ-X1A-750-Y00 IB,EZ K a b .

O 1 SQ-X1A-750-Z00 IB,EZ K a b .

O 1 SQ-X1A-755-Z00 IB,U . . c

O 2 SA-RTB-AX2-EZ0 RC UNIT,RC-BAR01 a b .

O 2 SA-RTB-AX2-UC0 RC UNIT,RC-BAR03 . . c

O 3 SS-PBA-X2E-ZF0 FRONT SPEAKER ASSY a b c

O 4 SS-PBA-X2E-ZC0 CENTER SPEAKER ASSY a b c

O 5 SS-PBA-X2E-ZR0 REAR SPEAKER ASSY a b c

O 6 SS-PBA-X2E-ZS0 SUB WOOFER SPEAKER ASSY a b c

O 7 SS-A1A-020-Z00 AM LOOP ANT a b c

O 8 SS-A1A-018-Z00 FM 1 POLE ANT(EZ) a b .

O 8 SS-A1A-019-Z00 FM 1 POL ANT(UL) . . c

O 9 SJ-S4M-023-Z00 CORD,PIN (1P)YELLOW(1.5M) a b c

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-3-

ELECTRICAL PARTS LIST -1/17

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FRONT X BN 73 SW-B1A-008-120 WIRE ASSY a b c

FRONT O C 711 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FRONT O C 712 SC-EA0-JH1-02T CAP,E 1000U-6.3V a b c

FRONT O C 713 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FRONT O C 714 SC-ES0-HD1-040 CAP,GOLD 0.1-5.5 a b c

FRONT O C 715 SC-EA1-CKS-470 CAP,E 47U-16 a b c

FRONT O C 716 SC-EA1-CKS-470 CAP,E 47U-16 a b c

FRONT O C 717 SC-EA1-CKS-470 CAP,E 47U-16 a b c

FRONT O C 718 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FRONT O C 719 SC-EA1-HKS-2R2 CAP,E 2.2U-50 a b c

FRONT O C 720 SC-US1-H22-0JA C-CAP,22P-50 J a b c

FRONT O C 721 SC-US1-H22-0JA C-CAP,22P-50 J a b c

FRONT O C 733 SC-EA1-CKS-470 CAP,E 47U-16 a b c

FRONT O C 734 SC-US1-H10-1JA C-CAP,100P-50 J a b c

FRONT O C 735 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FRONT O C 736 SC-EA1-VKS-100 CAP,E 10U-35 a b c

FRONT O C 737 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FRONT O C 738 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FRONT O C 743 SC-EA1-HKS-1R0 CAP,E 1.0U-50 a b c

FRONT O C 746 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FRONT O C 747 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FRONT O C 751 SC-US1-H82-1JA C-CAP,820P-50 J a b c

FRONT O C 752 SC-US1-H82-1JA C-CAP,820P-50 J a b c

FRONT O C 753 SC-US1-H82-1JA C-CAP,820P-50 J a b c

FRONT O CN 71 SJ-P23-GA1-17Z WAFER,CARD CABLE GF102-23S-TS a b c

FRONT O CN 72 SJ-P17-GA1-17Z WAFER,CARD CABLE GF102-17S-TS a b c

FRONT O CN 74 SJ-P03-GA1-9ZM WAFER a b c

FRONT S D 711 SV-DRB-160-L60 DIODE,RB160L-60TE25 a b c

FRONT S D 712 SV-DRB-160-L60 DIODE,RB160L-60TE25 a b c

FRONT S D 713 SV-D1S-S13-3MT DIODE,1SS133T-77 a b c

FRONT S D 714 SV-D1S-S13-3MT DIODE,1SS133T-77 a b c

FRONT S D 715 SV-D1S-S13-3MT DIODE,1SS133T-77 a b .

FRONT S D 716 SV-D1S-S13-3MT DIODE,1SS133T-77 a b .

FRONT S D 717 SV-D1S-S13-3MT DIODE,1SS133T-77 a b .

FRONT S FIP7 SF-LHN-A10-SM1 F.I.P,HNA-10SM17 a b c

FRONT S IC 71 SV-ITM-P87-PS7 IC,TMP87PS71F a b c

FRONT O L 711 SL-Q02-C10-0KT COIL,10UH K a b c

FRONT S Q 711 SV-TKS-B81-1YT TR,KSB811Y a b c

FRONT S Q 712 SV-TKR-C10-2MT TR,KRC102M a b c

FRONT S Q 713 SV-TKR-C10-2MT TR,KRC102M a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FRONT S Q 714 SV-TKR-A10-2MT TR,KRA102M a b c

FRONT S Q 715 SV-TKR-C10-2MT TR,KRC102M a b c

FRONT S Q 735 SV-TKR-C10-2MT TR,KRC102M a b c

FRONT S Q 736 SV-TKR-C10-2MT TR,KRC102M a b c

FRONT S Q 743 SV-TKR-C10-2MT TR,KRC102M a b c

FRONT X R 711 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FRONT X R 712 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c

FRONT X R 713 SR-J10-DJ2-23T C-RES,22K-1/10W J a b c

FRONT X R 714 SR-J10-DJ2-23T C-RES,22K-1/10W J a b c

FRONT X R 715 SR-J10-DJ1-22T C-RES,1.2K-1/10W J a b c

FRONT X R 716 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 717 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 718 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 719 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c

FRONT X R 720 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 721 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c

FRONT X R 722 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 723 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 724 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 725 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FRONT X R 726 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 729 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 730 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 731 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 732 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 733 SR-J10-DJ1-01T C-RES,100-1/10W J a b c

FRONT X R 734 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c

FRONT X R 737 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 738 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 739 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 740 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 741 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 742 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 743 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 744 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FRONT X R 745 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FRONT X R 746 SR-J10-DJ2-72T C-RES,2.7K-1/10W J a b c

FRONT X R 747 SR-J10-DJ2-72T C-RES,2.7K-1/10W J a b c

FRONT X R 748 SR-J10-DJ1-22T C-RES,1.2K-1/10W J a b c

FRONT X R 749 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-4-

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FRONT X R 751 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 752 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 753 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FRONT X R 754 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c

FRONT X R 755 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c

FRONT X R 756 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c

FRONT X R 757 SR-J10-DJ1-52T C-RES,1.5K-1/10W J a b c

FRONT X R 758 SR-J10-DJ1-52T C-RES,1.5K-1/10W J a b c

FRONT X R 759 SR-J10-DJ1-52T C-RES,1.5K-1/10W J a b c

FRONT X R 760 SR-J10-DJ1-82T C-RES,1.8K-1/10W J a b c

FRONT X R 761 SR-J10-DJ1-82T C-RES,1.8K-1/10W J a b c

FRONT X R 762 SR-J10-DJ1-82T C-RES,1.8K-1/10W J a b c

FRONT X R 763 SR-J10-DJ2-72T C-RES,2.7K-1/10W J a b c

FRONT X R 764 SR-J10-DJ2-72T C-RES,2.7K-1/10W J a b c

FRONT X R 765 SR-J10-DJ2-72T C-RES,2.7K-1/10W J a b c

FRONT X R 766 SR-J10-DJ3-32T C-RES,3.3K-1/5W J a b c

FRONT X R 767 SR-J10-DJ3-32T C-RES,3.3K-1/5W J a b c

FRONT X R 768 SR-J10-DJ3-32T C-RES,3.3K-1/5W J a b c

FRONT X R 769 SR-J10-DJ5-62T C-RES,5.6K-1/10W J a b c

FRONT X R 770 SR-J10-DJ5-62T C-RES,5.6K-1/10W J a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FRONT X R 771 SR-J10-DJ5-62T C-RES,5.6K-1/10W J a b c

FRONT X R 781 SR-J10-DJ2-71T C-RES,270-1/10W J a b c

FRONT X R 782 SR-J10-DJ3-31T C-RES,330-1/10W J a b c

FRONT X R 783 SR-J10-DJ3-31T C-RES,330-1/10W J a b c

FRONT O RC 73 SR-VKS-M60-3TH REMOCON SENSER,KSM-603TH2 a b c

FRONT O S 751 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 752 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 753 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 754 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 755 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 756 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 757 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 759 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 760 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 762 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 763 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 765 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 766 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 768 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

FRONT O S 769 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FRONT O VR 74 SS-R2A-018-Z00 VR,ENCODER a b c

FRONT O X 721 SO-X08-000-E16 VIB,XTAL 8.0MHz a b c

FUNCTION O C 101 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 102 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 103 SC-EC0-JRV-210 C-CAP,E 100U-6.3 a b c

FUNCTION O C 105 SC-EC0-JRV-210 C-CAP,E 100U-6.3 a b c

FUNCTION O C 107 SC-US1-H15-1JA C-CAP,150P-50 J a b c

FUNCTION O C 108 SC-US1-H15-1JA C-CAP,150P-50 J a b c

FUNCTION O C 109 SC-US1-H15-1JA C-CAP,150P-50 J a b c

FUNCTION O C 110 SC-US1-H15-1JA C-CAP,150P-50 J a b c

FUNCTION O C 111 SC-US1-H15-1JA C-CAP,150P-50 J a b c

FUNCTION O C 111 SC-EC0-JRV-210 C-CAP,E 100U-6.3 a b c

FUNCTION O C 112 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 112 SC-US1-H15-1JA C-CAP,150P-50 J a b c

FUNCTION O C 114 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 115 SC-EA1-CH1-01T CAP,E 100U-16 a b c

FUNCTION O C 116 SC-EA1-CH1-01T CAP,E 100U-16 a b c

FUNCTION O C 116 SC-EC0-JRV-247 C-CAP,E 47U-6.3 a b c

FUNCTION O C 117 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FUNCTION O C 117 SC-US1-H27-0JA C-CAP,27P-50 J a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION O C 118 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FUNCTION O C 118 SC-US1-H27-0JA C-CAP,27P-50 J a b c

FUNCTION O C 119 SC-US1-H22-2KC C-CAP,2200P-50 K a b c

FUNCTION O C 120 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 120 SC-US1-H22-2KC C-CAP,2200P-50 K a b c

FUNCTION O C 121 SC-EA1-CH1-01T CAP,E 100U-16 a b c

FUNCTION O C 121 SC-EC0-JRV-210 C-CAP,E 100U-6.3 a b c

FUNCTION O C 122 SC-EA1-CH1-01T CAP,E 100U-16 a b c

FUNCTION O C 123 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 123 SC-US1-H47-1JA C-CAP,470P-50 J a b c

FUNCTION O C 124 SC-US1-H47-1JA C-CAP,470P-50 J a b c

FUNCTION O C 124 SC-EC0-JRV-210 C-CAP,E 100U-6.3 a b c

FUNCTION O C 125 SC-US1-H47-1JA C-CAP,470P-50 J a b c

FUNCTION O C 126 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FUNCTION O C 127 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FUNCTION O C 142 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 144 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 146 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 150 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 151 SC-US1-H10-1JA C-CAP,100P-50 J a b c

ELECTRICAL PARTS LIST -2/17

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-5-

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION O C 152 SC-EA1-VH1-00T CAP,E 10U-35 a b c

FUNCTION O C 152 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 153 SC-EA1-AH4-71T CAP,E 470U-10 a b c

FUNCTION O C 154 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 154 SC-US1-H10-1JA C-CAP,100P-50 J a b c

FUNCTION O C 155 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 155 SC-US1-H10-1JA C-CAP,100P-50 J a b c

FUNCTION O C 156 SC-EA1-VH1-00T CAP,E 10U-35 a b c

FUNCTION O C 156 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 157 SC-EA1-VH1-00T CAP,E 10U-35 a b c

FUNCTION O C 158 SC-EA1-AH4-71T CAP,E 470U-10 a b c

FUNCTION O C 158 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 159 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 159 SC-US1-H22-1JA C-CAP,220P-50 J a b c

FUNCTION O C 160 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 160 SC-US1-H22-1JA C-CAP,220P-50 J a b c

FUNCTION O C 161 SC-US1-H22-1JA C-CAP,220P-50 J a b c

FUNCTION O C 162 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 162 SC-US1-H22-1JA C-CAP,220P-50 J a b c

FUNCTION O C 163 SC-EA1-AH4-71T CAP,E 470U-10 a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION O C 163 SC-US1-H15-1JA C-CAP,150P-50 J a b c

FUNCTION O C 164 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 164 SC-US1-H10-1JA C-CAP,100P-50 J a b c

FUNCTION O C 165 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FUNCTION O C 165 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 166 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b c

FUNCTION O C 166 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 167 SC-EA1-CH1-01T CAP,E 100U-16 a b c

FUNCTION O C 168 SC-EA1-CH1-01T CAP,E 100U-16 a b c

FUNCTION O C 168 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 169 SC-EA1-AH4-71T CAP,E 470U-10 a b c

FUNCTION O C 169 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 170 SC-US1-H82-1JA C-CAP,820P-50 J a b c

FUNCTION O C 171 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 171 SC-US1-H22-1JA C-CAP,220P-50 J a b c

FUNCTION O C 172 SC-EA1-AH4-71T CAP,E 470U-10 a b c

FUNCTION O C 173 SC-EC0-JRV-210 C-CAP,E 100U-6.3 a b c

FUNCTION O C 174 SC-US1-H22-2KC C-CAP,2200P-50 K a b c

FUNCTION O C 178 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 179 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION O C 181 SC-EA1-CH1-01T CAP,E 100U-16 a b .

FUNCTION O C 182 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b .

FUNCTION O C 183 SC-US1-H33-0JA C-CAP,33P-50 J a b .

FUNCTION O C 184 SC-US1-H33-0JA C-CAP,33P-50 J a b .

FUNCTION O C 185 SC-US1-H22-2KC C-CAP,2200P-50 K a b .

FUNCTION O C 186 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 186 SC-US1-H22-2KC C-CAP,2200P-50 K a b .

FUNCTION O C 187 SC-US1-H56-1JA C-CAP,560P-50 J a b .

FUNCTION O C 188 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 188 SC-US1-H10-3ZF C-CAP,0.01U-50 Z a b .

FUNCTION O C 189 SC-EA1-HH2-R2T CAP,E 2.2U-50 a b .

FUNCTION O C 190 SC-EC0-JRV-247 C-CAP,E 47U-6.3 a b c

FUNCTION O C 191 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O C 192 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

FUNCTION O CN 12 SJ-P15-GA1-17Z WAFER,CARD CABLE 15P 1M/M S/T a b c

FUNCTION O CN 13 SJ-P15-GA1-17Z WAFER,CARD CABLE 15P 1M/M S/T a b c

FUNCTION S D 167 SV-DMT-ZJ6-2B0 ZENER,6.2V 1/4W B a b c

FUNCTION S D 168 SV-DMT-ZJ6-2B0 ZENER,6.2V 1/4W B a b c

FUNCTION S D 169 SV-D1S-S13-3MT DIODE,1SS133T-77 a b c

FUNCTION S D 170 SV-D1S-S13-3MT DIODE,1SS133T-77 a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION S IC 11 SV-ITC-916-4AF IC,TC9164AF a b c

FUNCTION S IC 12 SV-INJ-M20-68M IC,NJM2068M-TE1 a b c

FUNCTION S IC 16 SV-INJ-M22-79M IC,NJM2279M-TE1 a b c

FUNCTION S IC 18 SV-ISA-A65-79T IC,SAA6579T/V1 a b .

FUNCTION O JK 11 SJ-J4L-002-Z00 JACK,9P a b c

FUNCTION O JK 14 SJ-J9N-004-Z00 JACK,(S-VIDEO+VHS) a b c

FUNCTION O L 101 SL-Z9Z-005-Z00 FERRITE CORE,6*10(A) + COIL a b c

FUNCTION O L 102 SL-Z9Z-005-Z00 FERRITE CORE,6*10(A) + COIL a b c

FUNCTION X L 104 SR-J10-DJ0-R0T C-RES,0-1/10W J a b c

FUNCTION X L 105 SR-J10-DJ0-R0T C-RES,0-1/10W J a b c

FUNCTION O L 159 SL-Q02-C1R-8KT COIL,1.8UH K a b c

FUNCTION O L 160 SL-Q02-C1R-8KT COIL,1.8UH K a b c

FUNCTION O L 171 SL-Q02-C1R-8KT COIL,1.8UH K a b c

FUNCTION O L 172 SL-Q02-C10-0KT COIL,10UH K a b c

FUNCTION X R 101 SR-J10-DJ3-61T C-RES,360-1/10W J a b c

FUNCTION X R 101 SR-J10-DJ4-71T C-RES,470-1/10W J a b c

FUNCTION X R 102 SR-J10-DJ4-71T C-RES,470-1/10W J a b c

FUNCTION X R 103 SR-J10-DJ4-71T C-RES,470-1/10W J a b c

FUNCTION X R 104 SR-J10-DJ4-71T C-RES,470-1/10W J a b c

FUNCTION X R 105 SR-J10-DJ4-71T C-RES,470-1/10W J a b c

ELECTRICAL PARTS LIST -3/17

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-6-

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION X R 106 SR-J10-DJ0-R0T C-RES,0-1/10W J a b c

FUNCTION X R 106 SR-J10-DJ4-71T C-RES,470-1/10W J a b c

FUNCTION X R 107 SR-J10-DJ1-04T C-RES,100K-1/10W J a b c

FUNCTION X R 107 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c

FUNCTION X R 108 SR-J10-DJ1-04T C-RES,100K-1/10W J a b c

FUNCTION X R 108 SR-J10-DJ1-05T C-RES,1M-1/10W J a b c

FUNCTION X R 109 SR-J10-DJ1-04T C-RES,100K-1/10W J a b c

FUNCTION X R 109 SR-J10-DJ1-21T C-RES,120-1/10W J a b c

FUNCTION X R 110 SR-J10-DJ1-04T C-RES,100K-1/10W J a b c

FUNCTION X R 110 SR-J10-DJ1-21T C-RES,120-1/10W J a b c

FUNCTION X R 111 SR-J10-DJ1-04T C-RES,100K-1/10W J a b c

FUNCTION X R 111 SR-J10-DJ1-21T C-RES,120-1/10W J a b c

FUNCTION X R 112 SR-J10-DJ1-04T C-RES,100K-1/10W J a b c

FUNCTION X R 112 SR-J10-DJ1-21T C-RES,120-1/10W J a b c

FUNCTION X R 113 SR-J10-DJ1-04T C-RES,100K-1/10W J a b c

FUNCTION X R 113 SR-J10-DJ2-21T C-RES,220-1/10W J a b c

FUNCTION X R 114 SR-J10-DJ1-04T C-RES,100K-1/10W J a b c

FUNCTION X R 114 SR-J10-DJ4-31T C-RES,430-1/10W J a b c

FUNCTION X R 115 SR-J10-DJ1-04T C-RES,100K-1/10W J a b c

FUNCTION X R 115 SR-J10-DJ2-21T C-RES,220-1/10W J a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION X R 116 SR-J10-DJ1-04T C-RES,100K-1/10W J a b c

FUNCTION X R 116 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c

FUNCTION X R 117 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 118 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 119 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 119 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c

FUNCTION X R 120 SR-J10-DJ1-02T C-RES,1K-1/10W J a b c

FUNCTION X R 120 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c

FUNCTION X R 121 SR-J10-DJ1-01T C-RES,100-1/10W J a b c

FUNCTION X R 121 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 122 SR-J10-DJ1-01T C-RES,100-1/10W J a b c

FUNCTION X R 123 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 123 SR-J10-DJ4-71T C-RES,470-1/10W J a b c

FUNCTION X R 124 SR-J10-DJ4-71T C-RES,470-1/10W J a b c

FUNCTION X R 125 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 125 SR-J10-DJ4-71T C-RES,470-1/10W J a b c

FUNCTION X R 126 SR-J10-DJ1-01T C-RES,100-1/10W J a b c

FUNCTION X R 126 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION X R 127 SR-J10-DJ1-01T C-RES,100-1/10W J a b c

FUNCTION X R 127 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 128 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 129 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 130 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 131 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 132 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 133 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 134 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 135 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 135 SR-J10-DJ4-71T C-RES,470-1/10W J a b c

FUNCTION X R 136 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 136 SR-J10-DJ4-71T C-RES,470-1/10W J a b c

FUNCTION X R 137 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 138 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 139 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 140 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 141 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 142 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 143 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION X R 144 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 145 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 146 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 147 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 148 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 149 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 150 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 151 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 151 SR-J10-DJ7-50T C-RES,75-1/10W J a b c

FUNCTION X R 152 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 153 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 153 SR-J10-DJ6-80T C-RES,68-1/10W J a b c

FUNCTION X R 154 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FUNCTION X R 154 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 155 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 155 SR-J10-DJ7-50T C-RES,75-1/10W J a b c

FUNCTION X R 156 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 157 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 158 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 159 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

ELECTRICAL PARTS LIST -4/17

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-7-

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION X R 159 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 160 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FUNCTION X R 160 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 161 SR-J10-DJ8-20T C-RES,82-1/10W J a b c

FUNCTION X R 162 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 162 SR-J10-DJ8-20T C-RES,82-1/10W J a b c

FUNCTION X R 163 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 163 SR-J10-DJ6-80T C-RES,68-1/10W J a b c

FUNCTION X R 164 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FUNCTION X R 164 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 165 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 165 SR-J10-DJ8-20T C-RES,82-1/10W J a b c

FUNCTION X R 166 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 166 SR-J10-DJ8-20T C-RES,82-1/10W J a b c

FUNCTION X R 167 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 167 SR-J10-DJ8-20T C-RES,82-1/10W J a b c

FUNCTION X R 168 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

FUNCTION X R 168 SR-J10-DJ8-20T C-RES,82-1/10W J a b c

FUNCTION X R 169 SR-J10-DJ1-03T C-RES,10K-1/10W J a b c

FUNCTION X R 169 SR-J10-DJ4-73T C-RES,47K-1/10W J a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION X R 170 SR-J10-DJ1-R0T C-RES,1.0-1/10W J a b c

FUNCTION X R 170 SR-J10-DJ4-70T C-RES,47-1/10W J a b c

FUNCTION X R 171 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 171 SR-J10-DJ7-50T C-RES,75-1/10W J a b c

FUNCTION X R 172 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 172 SR-D25-TJ4-R7T C-RES,4.7-1/4W J a b c

FUNCTION X R 173 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 173 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 174 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 174 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 175 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 175 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 176 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 176 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 177 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 177 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 178 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 178 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 179 SR-J10-DJ1-00T C-RES,10-1/10W J a b c

FUNCTION X R 179 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION X R 180 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 181 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 181 SR-J10-DJ1-22T C-RES,1.2K-1/10W J a b .

FUNCTION X R 182 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 182 SR-J10-DJ5-62T C-RES,5.6K-1/10W J a b .

FUNCTION X R 183 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 184 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 184 SR-J10-DJ4-71T C-RES,470-1/10W J a b .

FUNCTION X R 185 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 185 SR-J10-DJ1-03T C-RES,10K-1/10W J a b .

FUNCTION X R 186 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 186 SR-J10-DJ1-03T C-RES,10K-1/10W J a b .

FUNCTION X R 187 SR-J10-DJ4-70T C-RES,47-1/10W J a b c

FUNCTION X R 188 SR-J10-DJ4-70T C-RES,47-1/10W J a b c

FUNCTION X R 188 SR-J10-DJ1-01T C-RES,100-1/10W J a b .

FUNCTION X R 189 SR-J10-DJ4-70T C-RES,47-1/10W J a b c

FUNCTION X R 190 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 191 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 192 SR-J10-DJ3-30T C-RES,33-1/10W J a b c

FUNCTION X R 193 SR-J10-DJ4-70T C-RES,47-1/10W J a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

FUNCTION X R 194 SR-J10-DJ4-70T C-RES,47-1/10W J a b c

FUNCTION X R 195 SR-J10-DJ4-70T C-RES,47-1/10W J a b c

FUNCTION X R 196 SR-J10-DJ4-70T C-RES,47-1/10W J a b c

FUNCTION X R 197 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c

FUNCTION X R 198 SR-J10-DJ4-72T C-RES,4.7K-1/10W J a b c

FUNCTION O TUN001 SN-VMB-001-MA0 MODULE,TUNER(UL) 3 GANGKSTMB0 . . c

FUNCTION O X 181 SO-X04-332-A20 VIB,XTAL 4.332KHz a b .

KEY0 O C 782 SC-EA1-HKS-1R0 CAP,E 1.0U-50 a b c

KEY1 O C 783 SC-US1-H82-1JA C-CAP,820P-50 J a b c

KEY1 O C 784 SC-US1-H82-1JA C-CAP,820P-50 J a b c

KEY1 O D 781 SV-DSP-R39-MVW LED,2COLORSPR-39MVW3 a b c

KEY1 O JK 78 SJ-J2D-003-Z00 JACK,HEADPHONE a b c

KEY1 X JW 71 SW-EH2-021-20P WIRE,IP a b c

KEY1 O S 781 SS-T1A-012-ZT0 SW,TACT SKHV10910G a b c

KEY2 X BN 74 SW-B1A-003-080 WIRE ASSY a b c

KEY2 O SW 75 SS-T6F-017-Z00 SW,JOG TACT SKQUCAA010 a b c

MAIN X BN 91 SW-B1E-006-240 WIRE ASSY a b c

MAIN X BN 92 SW-B1C-009-150 WIRE ASSY a b c

MAIN X BN 93 SW-B1C-006-150 WIRE ASSY a b c

MAIN O C 001 SC-EA0-JH1-02T CAP,E 1000U-6.3V a b c

ELECTRICAL PARTS LIST -5/17

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-8-

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

MAIN O C 201 SC-US1-H33-0JA C-CAP,33P-50 J a b c

MAIN O C 202 SC-US1-H33-0JA C-CAP,33P-50 J a b c

MAIN O C 203 SC-EA1-CH1-01T CAP,E 100U-16 a b c

MAIN O C 204 SC-EA1-CH1-01T CAP,E 100U-16 a b c

MAIN O C 205 SC-EA1-CH1-01T CAP,E 100U-16 a b c

MAIN O C 206 SC-US1-H33-0JA C-CAP,33P-50 J a b c

MAIN O C 207 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 208 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 209 SC-EA1-CH1-01T CAP,E 100U-16 a b c

MAIN O C 210 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 211 SC-US1-H33-0JA C-CAP,33P-50 J a b c

MAIN O C 212 SC-US1-H33-0JA C-CAP,33P-50 J a b c

MAIN O C 213 SC-US1-H10-1JA C-CAP,100P-50 J a b c

MAIN O C 214 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 215 SC-EA1-CH1-01T CAP,E 100U-16 a b c

MAIN O C 216 SC-EA1-AH4-71T CAP,E 470U-10 a b c

MAIN O C 221 SC-US1-H10-1JA C-CAP,100P-50 J a b c

MAIN O C 222 SC-US1-H10-1JA C-CAP,100P-50 J a b c

MAIN O C 223 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 224 SC-EA1-AH4-71T CAP,E 470U-10 a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

MAIN O C 225 SC-US1-H10-1JA C-CAP,100P-50 J a b c

MAIN O C 226 SC-US1-H10-1JA C-CAP,100P-50 J a b c

MAIN O C 235 SC-US1-H10-1JA C-CAP,100P-50 J a b c

MAIN O C 236 SC-US1-H10-1JA C-CAP,100P-50 J a b c

MAIN O C 239 SC-US1-H47-0JA C-CAP,47P-50 J a b c

MAIN O C 241 SC-EA1-HH2-R2T CAP,E 2.2U-50 a b c

MAIN O C 242 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 243 SC-EA1-AH2-21T CAP,E 220U-10 a b c

MAIN O C 244 SC-QI1-H10-3JZ CAP,M 0.01U-50 J a b c

MAIN O C 245 SC-US1-H47-1JA C-CAP,470P-50 J a b c

MAIN O C 246 SC-US1-H47-1JA C-CAP,470P-50 J a b c

MAIN O C 255 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 257 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 261 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 262 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 263 SC-EA1-CH1-01T CAP,E 100U-16 a b c

MAIN O C 264 SC-EA1-AH4-71T CAP,E 470U-10 a b c

MAIN O C 265 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 266 SC-EA1-CH1-01T CAP,E 100U-16 a b c

MAIN O C 267 SC-EA1-AH4-71T CAP,E 470U-10 a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

MAIN O C 268 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 269 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 270 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 271 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 272 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 273 SC-US1-H10-1JA C-CAP,100P-50 J a b c

MAIN O C 274 SC-US1-H10-1JA C-CAP,100P-50 J a b c

MAIN O C 275 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 276 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 277 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 278 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 279 SC-QI1-H22-2JZ CAP,M 2.2U-50 J a b c

MAIN O C 280 SC-QI1-H22-2JZ CAP,M 2.2U-50 J a b c

MAIN O C 281 SC-EA1-AH2-21T CAP,E 220U-10 a b c

MAIN O C 282 SC-EA1-CH1-01T CAP,E 100U-16 a b c

MAIN O C 283 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 284 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 285 SC-EC0-JSE-331 C-CAP,E 330U-6.3 a b c

MAIN O C 286 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 287 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

MAIN O C 287 SC-US1-H33-0JA C-CAP,33P-50 J a b c

MAIN O C 288 SC-US1-H33-0JA C-CAP,33P-50 J a b c

MAIN O C 289 SC-US1-H10-1JA C-CAP,100P-50 J a b c

MAIN O C 295 SC-EA1-AH2-21T CAP,E 220U-10 a b c

MAIN O C 296 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 301 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 302 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 303 SC-US1-H47-0JA C-CAP,47P-50 J a b c

MAIN O C 304 SC-US1-H47-0JA C-CAP,47P-50 J a b c

MAIN O C 307 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 308 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 309 SC-US1-H47-1JA C-CAP,470P-50 J a b c

MAIN O C 310 SC-US1-H47-1JA C-CAP,470P-50 J a b c

MAIN O C 311 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 312 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 313 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 315 SE-A1V-H10-0TS CAP,E 10U-35 a b c

MAIN O C 316 SE-A1V-H10-0TS CAP,E 10U-35 a b c

MAIN O C 317 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 318 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

ELECTRICAL PARTS LIST -6/17

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-9-

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

MAIN O C 319 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 320 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 321 SC-US1-H47-3ZF C-CAP,0.047U-50 Z a b c

MAIN O C 322 SC-US1-H47-3ZF C-CAP,0.047U-50 Z a b c

MAIN O C 323 SC-EA1-VH4-71E CAP,E 470U-35 a b c

MAIN O C 324 SC-EA1-VH4-71E CAP,E 470U-35 a b c

MAIN O C 325 SC-EA1-VH1-01T CAP,E 100U-35 a b c

MAIN O C 326 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 327 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 329 SC-QI1-H10-4JZ CAP,M 0.1U-50 J a b c

MAIN O C 330 SC-QI1-H10-4JZ CAP,M 0.1U-50 J a b c

MAIN O C 331 SC-EA1-EH4-70T CAP,E 47U-25 a b c

MAIN O C 332 SC-EA1-EH4-70T CAP,E 47U-25 a b c

MAIN O C 333 SC-US1-H56-1JA C-CAP,560P-50 J a b c

MAIN O C 334 SC-US1-H56-1JA C-CAP,560P-50 J a b c

MAIN O C 335 SC-FE1-J22-4JB CAP,FILM(POLYESTER) 0.22U-63 a b c

MAIN O C 336 SC-FE1-J22-4JB CAP,FILM(POLYESTER) 0.22U-63 a b c

MAIN O C 337 SC-FE1-J10-4JB CAP,FILM(POLYESTER) 0.1U-63 a b c

MAIN O C 338 SC-FE1-J10-4JB CAP,FILM(POLYESTER) 0.1U-63 a b c

MAIN O C 339 SC-US1-H10-2KC C-CAP,1000P-50 K a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

MAIN O C 340 SC-US1-H10-2KC C-CAP,1000P-50 K a b c

MAIN O C 341 SC-EA1-EH4-70T CAP,E 47U-25 a b c

MAIN O C 342 SC-EA1-EH4-70T CAP,E 47U-25 a b c

MAIN O C 343 SC-US1-H47-3ZF C-CAP,0.047U-50 Z a b c

MAIN O C 344 SC-US1-H47-3ZF C-CAP,0.047U-50 Z a b c

MAIN O C 361 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 362 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 363 SC-QI1-H18-2JZ CAP,M 1800P-50 J a b c

MAIN O C 364 SC-QI1-H18-2JZ CAP,M 1800P-50 J a b c

MAIN O C 365 SC-US1-H22-1JA C-CAP,220P-50 J a b c

MAIN O C 366 SC-US1-H22-1JA C-CAP,220P-50 J a b c

MAIN O C 367 SC-US1-H22-2KC C-CAP,2200P-50 K a b c

MAIN O C 368 SC-US1-H22-2KC C-CAP,2200P-50 K a b c

MAIN O C 371 SC-QI1-H18-2JZ CAP,M 1800P-50 J a b c

MAIN O C 372 SC-QI1-H18-2JZ CAP,M 1800P-50 J a b c

MAIN O C 375 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 376 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 377 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 378 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 381 SC-US1-H15-1JA C-CAP,150P-50 J a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

MAIN O C 384 SC-US1-H15-1JA C-CAP,150P-50 J a b c

MAIN O C 387 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 388 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 390 SC-EA1-CH1-01T CAP,E 100U-16 a b c

MAIN O C 391 SC-EA1-CH1-01T CAP,E 100U-16 a b c

MAIN O C 392 SC-EA1-CH1-01T CAP,E 100U-16 a b c

MAIN O C 393 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 394 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 395 SC-QI1-H82-2JZ CAP,M 8200P-50 J a b c

MAIN O C 396 SC-QI1-H82-2JZ CAP,M 8200P-50 J a b c

MAIN O C 397 SC-QI1-H15-3JZ CAP,M 0.015U-50 J a b c

MAIN O C 398 SC-QI1-H15-3JZ CAP,M 0.015U-50 J a b c

MAIN O C 399 SC-FE1-J33-4JB CAP,FILM 0.33U-63 J a b c

MAIN O C 400 SC-FE1-J33-4JB CAP,FILM 0.33U-63 J a b c

MAIN O C 401 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 402 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 405 SC-US1-H47-0JA C-CAP,47P-50 J a b c

MAIN O C 406 SC-US1-H10-2KC C-CAP,1000P-50 K a b c

MAIN O C 407 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 408 SC-EA1-HH2-R2T CAP,E 2.2U-50 a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

MAIN O C 409 SC-US1-H47-1JA C-CAP,470P-50 J a b c

MAIN O C 410 SC-US1-H10-2KC C-CAP,1000P-50 K a b c

MAIN O C 411 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 412 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 415 SE-A1V-H10-0TS CAP,E 10U-35 a b c

MAIN O C 416 SE-A1V-H10-0TS CAP,E 10U-35 a b c

MAIN O C 417 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 418 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 419 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 420 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 421 SC-US1-H47-3ZF C-CAP,0.047U-50 Z a b c

MAIN O C 422 SC-US1-H47-3ZF C-CAP,0.047U-50 Z a b c

MAIN O C 423 SC-EA1-VH4-71E CAP,E 470U-35 a b c

MAIN O C 424 SC-EA1-VH4-71E CAP,E 470U-35 a b c

MAIN O C 425 SC-EA1-VH1-01T CAP,E 100U-35 a b c

MAIN O C 426 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 427 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 428 SC-EA1-EH4-70T CAP,E 47U-25 a b c

MAIN O C 429 SC-QI1-H10-4JZ CAP,M 0.1U-50 J a b c

MAIN O C 430 SC-QI1-H10-4JZ CAP,M 0.1U-50 J a b c

ELECTRICAL PARTS LIST -7/17

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-10-

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

MAIN O C 431 SC-EA1-EH4-70T CAP,E 47U-25 a b c

MAIN O C 432 SC-EA1-EH4-70T CAP,E 47U-25 a b c

MAIN O C 433 SC-US1-H56-1JA C-CAP,560P-50 J a b c

MAIN O C 434 SC-US1-H56-1JA C-CAP,560P-50 J a b c

MAIN O C 435 SC-FE1-J22-4JB CAP,FILM(POLYESTER) 0.22U-63 a b c

MAIN O C 436 SC-FE1-J22-4JB CAP,FILM(POLYESTER) 0.22U-63 a b c

MAIN O C 437 SC-FE1-J10-4JB CAP,FILM(POLYESTER) 0.1U-63 a b c

MAIN O C 438 SC-FE1-J10-4JB CAP,FILM(POLYESTER) 0.1U-63 a b c

MAIN O C 439 SC-US1-H10-2KC C-CAP,1000P-50 K a b c

MAIN O C 440 SC-US1-H10-2KC C-CAP,1000P-50 K a b c

MAIN O C 443 SC-US1-H47-3ZF C-CAP,0.047U-50 Z a b c

MAIN O C 444 SC-US1-H47-3ZF C-CAP,0.047U-50 Z a b c

MAIN O C 461 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 462 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 463 SC-QI1-H18-2JZ CAP,M 1800P-50 J a b c

MAIN O C 464 SC-QI1-H18-2JZ CAP,M 1800P-50 J a b c

MAIN O C 465 SC-US1-H22-1JA C-CAP,220P-50 J a b c

MAIN O C 466 SC-US1-H10-2KC C-CAP,1000P-50 K a b c

MAIN O C 467 SC-US1-H22-2KC C-CAP,2200P-50 K a b c

MAIN O C 468 SC-US1-H22-2KC C-CAP,2200P-50 K a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

MAIN O C 471 SC-QI1-H18-2JZ CAP,M 1800P-50 J a b c

MAIN O C 472 SC-QI1-H18-2JZ CAP,M 1800P-50 J a b c

MAIN O C 473 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 474 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 475 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 476 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 483 SC-US1-H47-1JA C-CAP,470P-50 J a b c

MAIN O C 487 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 488 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 493 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 494 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 495 SC-EA1-EH4-70T CAP,E 47U-25 a b c

MAIN O C 496 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 497 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 498 SC-EA1-AH2-21T CAP,E 220U-10 a b c

MAIN O C 499 SC-EA1-EH4-70T CAP,E 47U-25 a b c

MAIN O C 500 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 501 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 502 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 505 SC-US1-H47-0JA C-CAP,47P-50 J a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

MAIN O C 506 SC-US1-H47-0JA C-CAP,47P-50 J a b c

MAIN O C 507 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 508 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 509 SC-US1-H47-1JA C-CAP,470P-50 J a b c

MAIN O C 510 SC-US1-H47-1JA C-CAP,470P-50 J a b c

MAIN O C 511 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 512 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 515 SE-A1V-H10-0TS CAP,E 10U-35 a b c

MAIN O C 516 SE-A1V-H10-0TS CAP,E 10U-35 a b c

MAIN O C 517 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 518 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 519 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 520 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 521 SC-US1-H47-3ZF C-CAP,0.047U-50 Z a b c

MAIN O C 522 SC-US1-H47-3ZF C-CAP,0.047U-50 Z a b c

MAIN O C 523 SC-EA1-VH4-71E CAP,E 470U-35 a b c

MAIN O C 524 SC-EA1-VH4-71E CAP,E 470U-35 a b c

MAIN O C 525 SC-EA1-VH1-01T CAP,E 100U-35 a b c

MAIN O C 526 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

MAIN O C 527 SC-US1-E10-4ZF C-CAP,0.1U-25 Z a b c

HT-DV90 HT-DV90 HT-DV90

KSC EZSC USC

MAIN O C 529 SC-QI1-H10-4JZ CAP,M 0.1U-50 J a b c

MAIN O C 530 SC-QI1-H10-4JZ CAP,M 0.1U-50 J a b c

MAIN O C 531 SC-EA1-EH4-70T CAP,E 47U-25 a b c

MAIN O C 532 SC-EA1-EH4-70T CAP,E 47U-25 a b c

MAIN O C 533 SC-US1-H56-1JA C-CAP,560P-50 J a b c

MAIN O C 534 SC-US1-H56-1JA C-CAP,560P-50 J a b c

MAIN O C 535 SC-FE1-J22-4JB CAP,FILM(POLYESTER) 0.22U-63 a b c

MAIN O C 536 SC-FE1-J22-4JB CAP,FILM(POLYESTER) 0.22U-63 a b c

MAIN O C 537 SC-FE1-J10-4JB CAP,FILM(POLYESTER) 0.1U-63 a b c

MAIN O C 538 SC-FE1-J10-4JB CAP,FILM(POLYESTER) 0.1U-63 a b c

MAIN O C 539 SC-US1-H10-2KC C-CAP,1000P-50 K a b c

MAIN O C 540 SC-US1-H10-2KC C-CAP,1000P-50 K a b c

MAIN O C 543 SC-US1-H47-3ZF C-CAP,0.047U-50 Z a b c

MAIN O C 544 SC-US1-H47-3ZF C-CAP,0.047U-50 Z a b c

MAIN O C 561 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 562 SC-EA1-VH1-00T CAP,E 10U-35 a b c

MAIN O C 563 SC-QI1-H18-2JZ CAP,M 1800P-50 J a b c

MAIN O C 564 SC-QI1-H18-2JZ CAP,M 1800P-50 J a b c

MAIN O C 565 SC-US1-H22-1JA C-CAP,220P-50 J a b c

MAIN O C 566 SC-US1-H22-1JA C-CAP,220P-50 J a b c

ELECTRICAL PARTS LIST -8/17

Other manuals for HT-DV90

Popular Stereo System manuals by other brands

Sony

Sony HCD-VX88 Service manual

Philips

Philips MCM398D/12 user manual

Sony

Sony CMT-SPZ90DB operating instructions

LG OM4560 owner's manual

JVC

JVC UX-G3 instructions

Odys

Odys ODYS - LOOP instruction manual

Panasonic

Panasonic SC-AK100 operating instructions

Sharp

Sharp CD-G10000V Operation manual

Bogen

Bogen NEARSCAPES 4.1 manual

Panasonic

Panasonic SCPM29 - MINI HES W/CD PLAYER operating instructions

Meyer

Meyer LD-3 operating instructions

THOMSON

THOMSON MIC302U manual

Philips

Philips MCM530 Service manual

Sony

Sony SS-CEP50 Service manual

Cetacea Sound

Cetacea Sound CVS-II user guide

Sony

Sony MHC-V21D Service manual

Denon

Denon UCD-250 Service manual

Exibel

Exibel BDX600-UK user manual

Aiwa HT-DV90 User manual

Popular Stereo System manuals by other brands
