Aiwa NSX-SZ300 User manual
SERVICE MANUAL
DATA
NSX-SZ300
HS,HT
SIMPLE
S/M Code No. 09-012-440-5T3
• Replace this Service manual with “Revision Publishing” when it is issued.
COMPACT DISC
STEREO SYSTEM BASIC TAPE MECHANISM : ZZM-3 PR1NM
BASIC CD MECHANISM : BZG-5 ZD3NM
RTV servis Horvat
Tel: ++385-31-856-842
Tel/fax: ++385-31-856-139
Mob: 098-788-319
www.rtv-horvat-d .hr
www.rtv-horvat-dj.hr
2
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O ACCESSORY 87-006-226-010 1B ANT,LOOP AM HTSM CX-NSZ300
O ACCESSORY 87-043-115-010 1A FEEDER-ANT,FM HSSM CX-NSZ300
O ACCESSORY 87-043-115-010 1A FEEDER-ANT,FM HTSM CX-NSZ300
O ACCESSORY 87-A90-119-010 1A ANT, IRE S (5M) HTSM CX-NSZ300
! O ACCESSORY 87-A91-017-010 1A PLUG,CONVERSION JT-0476 HTSM CX-NSZ300
O ACCESSORY 87-A92-150-010 1A ANT,LOOP AM NO-CONT HSSM CX-NSZ300
X ACCESSORY 87-B30-274-010 0E BAT,R6P ATC HSSM CX-NSZ300
O ACCESSORY 8Z-NF9-701-210 1H RC UNIT,ZAS02 HSSM CX-NSZ300
O ACCESSORY 8Z-NF9-701-210 1H RC UNIT,ZAS02 HTSM CX-NSZ300
! O APPEARANCE 87-CE3-023-010 0E BADGE,AI A 30N SILV HSSM CX-NSZ300
! O APPEARANCE 87-CE3-023-010 0E BADGE,AI A 30N SILV HTSM CX-NSZ300
O APPEARANCE 8B-NF9-003-110 1B BOX,CASS 1 HSSM CX-NSZ300
O APPEARANCE 8B-NF9-003-110 1B BOX,CASS 1 HTSM CX-NSZ300
O APPEARANCE 8B-NF9-004-110 1B BOX,CASS 2 HSSM CX-NSZ300
O APPEARANCE 8B-NF9-004-110 1B BOX,CASS 2 HTSM CX-NSZ300
O APPEARANCE 8B-NF9-006-010 1B PANEL,TRAY HSSM CX-NSZ300
O APPEARANCE 8B-NF9-006-010 1B PANEL,TRAY HTSM CX-NSZ300
O APPEARANCE 8B-NF9-007-010 0E PANEL,JOG HSSM CX-NSZ300
O APPEARANCE 8B-NF9-007-010 0E PANEL,JOG HTSM CX-NSZ300
O APPEARANCE 8B-NF9-025-010 1B PANEL,RIGHT HSSM CX-NSZ300
O APPEARANCE 8B-NF9-025-010 1B PANEL,RIGHT HTSM CX-NSZ300
O APPEARANCE 8B-NF9-026-010 1B PANEL,LEFT HSSM CX-NSZ300
O APPEARANCE 8B-NF9-026-010 1B PANEL,LEFT HTSM CX-NSZ300
O APPEARANCE 8B-NF9-027-010 1C PANEL,TOP HSSM CX-NSZ300
O APPEARANCE 8B-NF9-027-010 1C PANEL,TOP HTSM CX-NSZ300
O APPEARANCE 8B-NF9-030-010 -- CABI,FR HR HSSM CX-NSZ300
O APPEARANCE 8B-NF9-030-010 -- CABI,FR HR HTSM CX-NSZ300
O APPEARANCE 8B-NF9-081-010 -- CABI,REAR HTSM HTSM CX-NSZ300
O APPEARANCE 8B-NFY-054-010 -- CABI,REAR HSSM HSSM CX-NSZ300
X CD M8-BZG-590-030 -- BZG-5 ZD3NM HSSM CX-NSZ300
X CD M8-BZG-590-030 -- BZG-5 ZD3NM HTSM CX-NSZ300
! X ELECTRICAL 87-069-033-010 0E CABLE,TIE HSSM CX-NSZ300
! X ELECTRICAL 87-069-033-010 0E CABLE,TIE HTSM CX-NSZ300
! O ELECTRICAL 87-085-185-010 0E BUSHING,AC CORD(E) CM-22B HSSM CX-NSZ300
! O ELECTRICAL 87-085-185-010 0E BUSHING,AC CORD(E) CM-22B HTSM CX-NSZ300
O ELECTRICAL 88-906-251-110 1A FF-CABLE,6P 1.25 HSSM CX-NSZ300
O ELECTRICAL 88-906-251-110 1A FF-CABLE,6P 1.25 HTSM CX-NSZ300
O ELECTRICAL 88-908-301-110 1A FF-CABLE,8P 1.25 HSSM CX-NSZ300
O ELECTRICAL 88-908-301-110 1A FF-CABLE,8P 1.25 HTSM CX-NSZ300
O ELECTRICAL 88-911-101-110 0E FF-CABLE,11P 1.25 HSSM CX-NSZ300
O ELECTRICAL 88-911-101-110 0E FF-CABLE,11P 1.25 HTSM CX-NSZ300
! O ELECTRICAL PT 0001 8B-NF9-613-010 -- PT,BNF-9 HR HSSM CX-NSZ300
! O ELECTRICAL PT 0001 8B-NF9-613-010 -- PT,BNF-9 HR HTSM CX-NSZ300
! O ELECTRICAL 0001 87-A80-155-010 1D AC CORD ASSY,HS TS HSSM CX-NSZ300
! O ELECTRICAL 0001 87-A80-157-010 1B AC CORD ASSY,E BLK CC HTSM CX-NSZ300
O FRCB MECHA * 8B-NF9-207-010 0E GUIDE,FL 90.2-20 HSSM CX-NSZ300
O FRCB MECHA * 8B-NF9-207-010 0E GUIDE,FL 90.2-20 HTSM CX-NSZ300
O FUNC/E.VR C 0605 87-012-280-080 0E C-CAP,U 3300P-50 K B HSSM CX-NSZ300
O FUNC/E.VR C 0605 87-012-280-080 0E C-CAP,U 3300P-50 K B HTSM CX-NSZ300
O FUNC/E.VR C 0606 87-012-280-080 0E C-CAP,U 3300P-50 K B HSSM CX-NSZ300
O FUNC/E.VR C 0606 87-012-280-080 0E C-CAP,U 3300P-50 K B HTSM CX-NSZ300
O FUNC/E.VR C 0609 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM HSSM CX-NSZ300
O FUNC/E.VR C 0609 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM HTSM CX-NSZ300
O FUNC/E.VR C 0610 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM HSSM CX-NSZ300
O FUNC/E.VR C 0610 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM HTSM CX-NSZ300
O FUNC/E.VR C 0611 87-A12-084-080 0E CAP,E 0.22-50 SMG HSSM CX-NSZ300
O FUNC/E.VR C 0611 87-A12-084-080 0E CAP,E 0.22-50 SMG HTSM CX-NSZ300
O FUNC/E.VR C 0612 87-A12-084-080 0E CAP,E 0.22-50 SMG HSSM CX-NSZ300
O FUNC/E.VR C 0612 87-A12-084-080 0E CAP,E 0.22-50 SMG HTSM CX-NSZ300
O FUNC/E.VR C 0613 87-A12-084-080 0E CAP,E 0.22-50 SMG HSSM CX-NSZ300
O FUNC/E.VR C 0613 87-A12-084-080 0E CAP,E 0.22-50 SMG HTSM CX-NSZ300
O FUNC/E.VR C 0614 87-A12-084-080 0E CAP,E 0.22-50 SMG HSSM CX-NSZ300
O FUNC/E.VR C 0614 87-A12-084-080 0E CAP,E 0.22-50 SMG HTSM CX-NSZ300
O FUNC/E.VR C 0615 87-012-172-080 0E C-CAP,U 10P-50 D CH HSSM CX-NSZ300
O FUNC/E.VR C 0615 87-012-172-080 0E C-CAP,U 10P-50 D CH HTSM CX-NSZ300
O FUNC/E.VR C 0616 87-016-459-080 0E CAP,E 470-10 M SMG HSSM CX-NSZ300
O FUNC/E.VR C 0616 87-016-459-080 0E CAP,E 470-10 M SMG HTSM CX-NSZ300
O FUNC/E.VR C 0617 87-016-459-080 0E CAP,E 470-10 M SMG HSSM CX-NSZ300
O FUNC/E.VR C 0617 87-016-459-080 0E CAP,E 470-10 M SMG HTSM CX-NSZ300
O FUNC/E.VR C 0618 87-A12-091-080 0E CAP,E 10-50 SMG HSSM CX-NSZ300
www.rtv-horvat-dj.hr
3
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O FUNC/E.VR C 0618 87-A12-091-080 0E CAP,E 10-50 SMG HTSM CX-NSZ300
O FUNC/E.VR C 0620 87-010-263-080 0E CAP,E 100-10 M 11L SME HSSM CX-NSZ300
O FUNC/E.VR C 0620 87-010-263-080 0E CAP,E 100-10 M 11L SME HTSM CX-NSZ300
O FUNC/E.VR C 0623 87-A12-372-080 0E CAP,M 0.047-100 J CP HSSM CX-NSZ300
O FUNC/E.VR C 0623 87-A12-372-080 0E CAP,M 0.047-100 J CP HTSM CX-NSZ300
O FUNC/E.VR C 0624 87-A12-372-080 0E CAP,M 0.047-100 J CP HSSM CX-NSZ300
O FUNC/E.VR C 0624 87-A12-372-080 0E CAP,M 0.047-100 J CP HTSM CX-NSZ300
O FUNC/E.VR C 0630 87-016-669-080 0E C-CAP,S 0.1-25 K B HSSM CX-NSZ300
O FUNC/E.VR C 0630 87-016-669-080 0E C-CAP,S 0.1-25 K B HTSM CX-NSZ300
O FUNC/E.VR C 0631 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM HSSM CX-NSZ300
O FUNC/E.VR C 0631 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM HTSM CX-NSZ300
O FUNC/E.VR C 0632 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM HSSM CX-NSZ300
O FUNC/E.VR C 0632 87-012-281-080 0E C-CAP,U 3900P-50 K B GRM HTSM CX-NSZ300
O FUNC/E.VR C 0633 87-A11-070-080 0E C-CAP,U 0.033-16 K B HSSM CX-NSZ300
O FUNC/E.VR C 0633 87-A11-070-080 0E C-CAP,U 0.033-16 K B HTSM CX-NSZ300
O FUNC/E.VR C 0634 87-A11-070-080 0E C-CAP,U 0.033-16 K B HSSM CX-NSZ300
O FUNC/E.VR C 0634 87-A11-070-080 0E C-CAP,U 0.033-16 K B HTSM CX-NSZ300
O FUNC/E.VR C 0661 87-012-336-080 0E C-CAP,U 330P-50 J SL HSSM CX-NSZ300
O FUNC/E.VR C 0661 87-012-336-080 0E C-CAP,U 330P-50 J SL HTSM CX-NSZ300
O FUNC/E.VR C 0662 87-012-336-080 0E C-CAP,U 330P-50 J SL HSSM CX-NSZ300
O FUNC/E.VR C 0662 87-012-336-080 0E C-CAP,U 330P-50 J SL HTSM CX-NSZ300
O FUNC/E.VR C 0671 87-010-831-080 0E C-CAP,U 0.1-16 Z F HSSM CX-NSZ300
O FUNC/E.VR C 0671 87-010-831-080 0E C-CAP,U 0.1-16 Z F HTSM CX-NSZ300
O FUNC/E.VR C 0672 87-010-831-080 0E C-CAP,U 0.1-16 Z F HSSM CX-NSZ300
O FUNC/E.VR C 0672 87-010-831-080 0E C-CAP,U 0.1-16 Z F HTSM CX-NSZ300
O FUNC/E.VR C 0673 87-012-278-080 0E C-CAP,U 2200P-50 K B HSSM CX-NSZ300
O FUNC/E.VR C 0673 87-012-278-080 0E C-CAP,U 2200P-50 K B HTSM CX-NSZ300
O FUNC/E.VR C 0677 87-012-286-080 0E C-CAP,U 0.01-25 K B HSSM CX-NSZ300
O FUNC/E.VR C 0677 87-012-286-080 0E C-CAP,U 0.01-25 K B HTSM CX-NSZ300
X FUNC/E.VR C 0678 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X FUNC/E.VR C 0678 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
! O FUNC/E.VR CN 0601 87-099-719-010 1B CONN,30P H BLK TYK-B(X) HSSM CX-NSZ300
! O FUNC/E.VR CN 0601 87-099-719-010 1B CONN,30P H BLK TYK-B(X) HTSM CX-NSZ300
! O FUNC/E.VR CN 0602 87-A60-131-010 0E CONN,6P V FE HSSM CX-NSZ300
! O FUNC/E.VR CN 0602 87-A60-131-010 0E CONN,6P V FE HTSM CX-NSZ300
S FUNC/E.VR D 0601 87-A40-739-080 0E ZENER,UZ2.7BSA HSSM CX-NSZ300
S FUNC/E.VR D 0601 87-A40-739-080 0E ZENER,UZ2.7BSA HTSM CX-NSZ300
S FUNC/E.VR D 0602 87-A40-739-080 0E ZENER,UZ2.7BSA HSSM CX-NSZ300
S FUNC/E.VR D 0602 87-A40-739-080 0E ZENER,UZ2.7BSA HTSM CX-NSZ300
X FUNC/E.VR FB 0602 88-100-000-010 0E PLATING-J , 0.58 SN95 HSSM CX-NSZ300
X FUNC/E.VR FB 0602 88-100-000-010 0E PLATING-J , 0.58 SN95 HTSM CX-NSZ300
S FUNC/E.VR IC 0601 87-A21-401-040 1C C-IC,M61503FP HSSM CX-NSZ300
S FUNC/E.VR IC 0601 87-A21-401-040 1C C-IC,M61503FP HTSM CX-NSZ300
O FUNC/E.VR J 0602 87-A60-881-010 0E JACK,PIN 2P MSP 242V05 PBSN HSSM CX-NSZ300
O FUNC/E.VR J 0602 87-A60-881-010 0E JACK,PIN 2P MSP 242V05 PBSN HTSM CX-NSZ300
X FUNC/E.VR JR 0601 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X FUNC/E.VR JR 0601 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X FUNC/E.VR JR 0602 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X FUNC/E.VR JR 0602 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X FUNC/E.VR JR 0605 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X FUNC/E.VR JR 0605 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X FUNC/E.VR JR 0606 88-129-000-080 0E C-JUMPER,3216 HSSM CX-NSZ300
X FUNC/E.VR JR 0606 88-129-000-080 0E C-JUMPER,3216 HTSM CX-NSZ300
X FUNC/E.VR JR 0607 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X FUNC/E.VR JR 0607 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X FUNC/E.VR JR 0616 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X FUNC/E.VR JR 0616 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
S FUNC/E.VR Q 0601 87-A30-087-080 0E C-FET,2SK2158 HSSM CX-NSZ300
S FUNC/E.VR Q 0601 87-A30-087-080 0E C-FET,2SK2158 HTSM CX-NSZ300
S FUNC/E.VR Q 0602 87-A30-087-080 0E C-FET,2SK2158 HSSM CX-NSZ300
S FUNC/E.VR Q 0602 87-A30-087-080 0E C-FET,2SK2158 HTSM CX-NSZ300
S FUNC/E.VR Q 0605 87-A30-090-080 0E FET,2SK2541 HSSM CX-NSZ300
S FUNC/E.VR Q 0605 87-A30-090-080 0E FET,2SK2541 HTSM CX-NSZ300
S FUNC/E.VR Q 0606 87-A30-090-080 0E FET,2SK2541 HSSM CX-NSZ300
S FUNC/E.VR Q 0606 87-A30-090-080 0E FET,2SK2541 HTSM CX-NSZ300
S FUNC/E.VR Q 0607 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
S FUNC/E.VR Q 0607 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
X FUNC/E.VR R 0077 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0077 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0601 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
www.rtv-horvat-dj.hr
4
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X FUNC/E.VR R 0601 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0602 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0602 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0603 88-108-682-080 0E C-RES,U 6.8K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0603 88-108-682-080 0E C-RES,U 6.8K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0604 88-108-682-080 0E C-RES,U 6.8K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0604 88-108-682-080 0E C-RES,U 6.8K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0605 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0605 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0606 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0606 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0607 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0607 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0608 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0608 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0609 88-108-562-080 0E C-RES,U 5.6K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0609 88-108-562-080 0E C-RES,U 5.6K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0610 88-121-562-080 0E RES,5.6K-1/8 J HSSM CX-NSZ300
X FUNC/E.VR R 0610 88-121-562-080 0E RES,5.6K-1/8 J HTSM CX-NSZ300
X FUNC/E.VR R 0611 88-108-183-080 0E C-RES,U 18K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0611 88-108-183-080 0E C-RES,U 18K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0612 88-108-183-080 0E C-RES,U 18K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0612 88-108-183-080 0E C-RES,U 18K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0613 88-121-472-080 0E RES,4.7K-1/8 J HSSM CX-NSZ300
X FUNC/E.VR R 0613 88-121-472-080 0E RES,4.7K-1/8 J HTSM CX-NSZ300
X FUNC/E.VR R 0614 88-121-472-080 0E RES,4.7K-1/8 J HSSM CX-NSZ300
X FUNC/E.VR R 0614 88-121-472-080 0E RES,4.7K-1/8 J HTSM CX-NSZ300
X FUNC/E.VR R 0615 88-108-183-080 0E C-RES,U 18K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0615 88-108-183-080 0E C-RES,U 18K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0616 88-108-183-080 0E C-RES,U 18K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0616 88-108-183-080 0E C-RES,U 18K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0618 88-108-332-080 0E C-RES,U 3.3K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0618 88-108-332-080 0E C-RES,U 3.3K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0621 88-108-824-080 0E C-RES,U 820K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0621 88-108-824-080 0E C-RES,U 820K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0622 88-108-824-080 0E C-RES,U 820K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0622 88-108-824-080 0E C-RES,U 820K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0625 88-121-472-080 0E RES,4.7K-1/8 J HSSM CX-NSZ300
X FUNC/E.VR R 0625 88-121-472-080 0E RES,4.7K-1/8 J HTSM CX-NSZ300
X FUNC/E.VR R 0626 88-121-103-080 0E RES,10K-1/8 J HSSM CX-NSZ300
X FUNC/E.VR R 0626 88-121-103-080 0E RES,10K-1/8 J HTSM CX-NSZ300
X FUNC/E.VR R 0627 88-108-123-080 0E C-RES,U 12K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0627 88-108-123-080 0E C-RES,U 12K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0628 88-121-332-080 0E RES,3.3K-1/8 J HSSM CX-NSZ300
X FUNC/E.VR R 0628 88-121-332-080 0E RES,3.3K-1/8 J HTSM CX-NSZ300
X FUNC/E.VR R 0631 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0631 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0632 88-108-123-080 0E C-RES,U 12K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0632 88-108-123-080 0E C-RES,U 12K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0634 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0634 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0635 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0635 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0637 88-108-222-080 0E C-RES,U 2.2K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0637 88-108-222-080 0E C-RES,U 2.2K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0638 88-108-222-080 0E C-RES,U 2.2K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0638 88-108-222-080 0E C-RES,U 2.2K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0639 88-108-273-080 0E C-RES,U 27K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0639 88-108-273-080 0E C-RES,U 27K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0640 88-108-273-080 0E C-RES,U 27K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0640 88-108-273-080 0E C-RES,U 27K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0653 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X FUNC/E.VR R 0653 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X FUNC/E.VR R 0654 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X FUNC/E.VR R 0654 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X FUNC/E.VR R 0661 88-108-153-080 0E C-RES,U 15K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0661 88-108-153-080 0E C-RES,U 15K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0662 88-108-153-080 0E C-RES,U 15K-1/16 J HSSM CX-NSZ300
X FUNC/E.VR R 0662 88-108-153-080 0E C-RES,U 15K-1/16 J HTSM CX-NSZ300
X FUNC/E.VR R 0671 88-121-273-080 0E RES,27K-1/8 J HSSM CX-NSZ300
www.rtv-horvat-dj.hr
5
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X FUNC/E.VR R 0671 88-121-273-080 0E RES,27K-1/8 J HTSM CX-NSZ300
X FUNC/E.VR R 0672 88-121-273-080 0E RES,27K-1/8 J HSSM CX-NSZ300
X FUNC/E.VR R 0672 88-121-273-080 0E RES,27K-1/8 J HTSM CX-NSZ300
O KNOB 8B-NF9-011-110 0E KEY,PO ER HSSM CX-NSZ300
O KNOB 8B-NF9-011-110 0E KEY,PO ER HTSM CX-NSZ300
O KNOB 8B-NF9-012-010 0E KEY,T-BASS HSSM CX-NSZ300
O KNOB 8B-NF9-012-010 0E KEY,T-BASS HTSM CX-NSZ300
O KNOB 8B-NF9-013-010 1A KEY,FUN HSSM CX-NSZ300
O KNOB 8B-NF9-013-010 1A KEY,FUN HTSM CX-NSZ300
O KNOB 8B-NF9-014-010 0E KEY,CD HSSM CX-NSZ300
O KNOB 8B-NF9-014-010 0E KEY,CD HTSM CX-NSZ300
O KNOB 8B-NF9-016-010 1A KEY,OPE P HSSM CX-NSZ300
O KNOB 8B-NF9-016-010 1A KEY,OPE P HTSM CX-NSZ300
O KNOB 8B-NF9-018-010 0E KEY,GEQ HSSM CX-NSZ300
O KNOB 8B-NF9-018-010 0E KEY,GEQ HTSM CX-NSZ300
O KNOB 8B-NF9-019-010 0E KNOB,RTRY VOL HSSM CX-NSZ300
O KNOB 8B-NF9-019-010 0E KNOB,RTRY VOL HTSM CX-NSZ300
O KNOB 8B-NF9-020-010 0E KNOB,RTRY JOG HSSM CX-NSZ300
O KNOB 8B-NF9-020-010 0E KNOB,RTRY JOG HTSM CX-NSZ300
O KNOB 8B-NF9-024-010 -- KNOB,RTRY MIC HSSM CX-NSZ300
O KNOB 8B-NF9-024-010 -- KNOB,RTRY MIC HTSM CX-NSZ300
X LBL,POP 8B-NF9-980-010 -- LBL,POP HTL HSSM CX-NSZ300
X LBL,POP 8B-NF9-980-010 -- LBL,POP HTL HTSM CX-NSZ300
X LBL,POP 8B-NF9-981-010 -- LBL,POP HTR HTSM CX-NSZ300
X LBL,POP 8B-NF9-982-010 -- LBL,POP HSR HSSM CX-NSZ300
X MECHANICAL 8B-NF9-237-010 1D CHAS,MAIN BS 66-60 HSSM CX-NSZ300
X MECHANICAL 8B-NF9-237-010 1D CHAS,MAIN BS 66-60 HTSM CX-NSZ300
O MIC C 0401 87-012-282-080 0E C-CAP,U 4700P-50 K B HSSM CX-NSZ300
O MIC C 0401 87-012-282-080 0E C-CAP,U 4700P-50 K B HTSM CX-NSZ300
O MIC C 0402 87-010-112-040 0E CAP,E 100-16 M 11L SME HSSM CX-NSZ300
O MIC C 0402 87-010-112-040 0E CAP,E 100-16 M 11L SME HTSM CX-NSZ300
O MIC C 0403 87-010-545-040 0E CAP,E 0.22-50 M 11L SME HSSM CX-NSZ300
O MIC C 0403 87-010-545-040 0E CAP,E 0.22-50 M 11L SME HTSM CX-NSZ300
O MIC C 0404 87-012-191-080 0E C-CAP,U 68P-50 J CH HSSM CX-NSZ300
O MIC C 0404 87-012-191-080 0E C-CAP,U 68P-50 J CH HTSM CX-NSZ300
O MIC C 0405 87-010-545-040 0E CAP,E 0.22-50 M 11L SME HSSM CX-NSZ300
O MIC C 0405 87-010-545-040 0E CAP,E 0.22-50 M 11L SME HTSM CX-NSZ300
O MIC C 0406 87-010-545-040 0E CAP,E 0.22-50 M 11L SME HSSM CX-NSZ300
O MIC C 0406 87-010-545-040 0E CAP,E 0.22-50 M 11L SME HTSM CX-NSZ300
O MIC C 0407 87-010-405-040 0E CAP,E 10-50 M 11L SME HSSM CX-NSZ300
O MIC C 0407 87-010-405-040 0E CAP,E 10-50 M 11L SME HTSM CX-NSZ300
O MIC C 0408 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O MIC C 0408 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O MIC C 0409 87-010-265-040 0E CAP,E 33-16 M 11L SME HSSM CX-NSZ300
O MIC C 0409 87-010-265-040 0E CAP,E 33-16 M 11L SME HTSM CX-NSZ300
O MIC C 0410 87-010-829-080 0E C-CAP,U 0.047-16 Z F HSSM CX-NSZ300
O MIC C 0410 87-010-829-080 0E C-CAP,U 0.047-16 Z F HTSM CX-NSZ300
O MIC C 0413 87-A10-978-080 0E C-CAP,U 820P-25 J CH HSSM CX-NSZ300
O MIC C 0413 87-A10-978-080 0E C-CAP,U 820P-25 J CH HTSM CX-NSZ300
O MIC EMI0401 87-008-372-080 0E FLTR,EMI BL01 RN1 HSSM CX-NSZ300
O MIC EMI0401 87-008-372-080 0E FLTR,EMI BL01 RN1 HTSM CX-NSZ300
O MIC J 0401 87-A61-243-010 1A JACK,6.3 BLK MONO /S V MSC HSSM CX-NSZ300
O MIC J 0401 87-A61-243-010 1A JACK,6.3 BLK MONO /S V MSC HTSM CX-NSZ300
X MIC JR 0405 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MIC JR 0405 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
S MIC Q 0401 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
S MIC Q 0401 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
S MIC Q 0402 87-A30-075-080 0E C-TR,2SA1235F HSSM CX-NSZ300
S MIC Q 0402 87-A30-075-080 0E C-TR,2SA1235F HTSM CX-NSZ300
S MIC Q 0403 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
S MIC Q 0403 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
S MIC Q 0404 87-A30-075-080 0E C-TR,2SA1235F HSSM CX-NSZ300
S MIC Q 0404 87-A30-075-080 0E C-TR,2SA1235F HTSM CX-NSZ300
S MIC Q 0405 87-A30-087-080 0E C-FET,2SK2158 HSSM CX-NSZ300
S MIC Q 0405 87-A30-087-080 0E C-FET,2SK2158 HTSM CX-NSZ300
S MIC Q 0406 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
S MIC Q 0406 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
X MIC R 0401 88-108-472-080 0E C-RES,U 4.7K-1/16 J HSSM CX-NSZ300
X MIC R 0401 88-108-472-080 0E C-RES,U 4.7K-1/16 J HTSM CX-NSZ300
X MIC R 0402 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
www.rtv-horvat-dj.hr
6
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MIC R 0402 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MIC R 0403 88-121-101-080 0E RES,100-1/8 J HSSM CX-NSZ300
X MIC R 0403 88-121-101-080 0E RES,100-1/8 J HTSM CX-NSZ300
X MIC R 0404 88-108-222-080 0E C-RES,U 2.2K-1/16 J HSSM CX-NSZ300
X MIC R 0404 88-108-222-080 0E C-RES,U 2.2K-1/16 J HTSM CX-NSZ300
X MIC R 0405 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MIC R 0405 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MIC R 0406 88-108-334-080 0E C-RES,U 330K-1/16 J HSSM CX-NSZ300
X MIC R 0406 88-108-334-080 0E C-RES,U 330K-1/16 J HTSM CX-NSZ300
X MIC R 0407 88-108-333-080 0E C-RES,U 33K-1/16 J HSSM CX-NSZ300
X MIC R 0407 88-108-333-080 0E C-RES,U 33K-1/16 J HTSM CX-NSZ300
X MIC R 0408 88-108-562-080 0E C-RES,U 5.6K-1/16 J HSSM CX-NSZ300
X MIC R 0408 88-108-562-080 0E C-RES,U 5.6K-1/16 J HTSM CX-NSZ300
X MIC R 0409 88-108-101-080 0E C-RES,U 100-1/16 J HSSM CX-NSZ300
X MIC R 0409 88-108-101-080 0E C-RES,U 100-1/16 J HTSM CX-NSZ300
X MIC R 0410 88-108-153-080 0E C-RES,U 15K-1/16 J HSSM CX-NSZ300
X MIC R 0410 88-108-153-080 0E C-RES,U 15K-1/16 J HTSM CX-NSZ300
X MIC R 0411 88-108-561-080 0E C-RES,U 560-1/16 J HSSM CX-NSZ300
X MIC R 0411 88-108-561-080 0E C-RES,U 560-1/16 J HTSM CX-NSZ300
X MIC R 0412 88-108-274-080 0E C-RES,U 270K-1/16 J HSSM CX-NSZ300
X MIC R 0412 88-108-274-080 0E C-RES,U 270K-1/16 J HTSM CX-NSZ300
X MIC R 0413 88-108-223-080 0E C-RES,U 22K-1/16 J HSSM CX-NSZ300
X MIC R 0413 88-108-223-080 0E C-RES,U 22K-1/16 J HTSM CX-NSZ300
X MIC R 0414 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MIC R 0414 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MIC R 0415 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MIC R 0415 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MIC R 0416 88-108-224-080 0E C-RES,U 220K-1/16 J HSSM CX-NSZ300
X MIC R 0416 88-108-224-080 0E C-RES,U 220K-1/16 J HTSM CX-NSZ300
X MIC R 0417 88-108-334-080 0E C-RES,U 330K-1/16 J HSSM CX-NSZ300
X MIC R 0417 88-108-334-080 0E C-RES,U 330K-1/16 J HTSM CX-NSZ300
X MIC R 0418 88-108-154-080 0E C-RES,U 150K-1/16 J HSSM CX-NSZ300
X MIC R 0418 88-108-154-080 0E C-RES,U 150K-1/16 J HTSM CX-NSZ300
O MIC VR 0401 86-NFA-607-010 1A VR,RTRY 10K15AX1 1 V XV0121PVN HSSM CX-NSZ300
O MIC VR 0401 86-NFA-607-010 1A VR,RTRY 10K15AX1 1 V XV0121PVN HTSM CX-NSZ300
X MICON * 8B-NF9-621-010 1C P B,FRONT BNF-9 (MSIA) HSSM CX-NSZ300
X MICON * 8B-NF9-621-010 1C P B,FRONT BNF-9 (MSIA) HTSM CX-NSZ300
O MICON C 0108 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM HSSM CX-NSZ300
O MICON C 0108 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM HTSM CX-NSZ300
O MICON C 0153 87-010-787-080 0E C-CAP,U 0.022-25 K B HSSM CX-NSZ300
O MICON C 0153 87-010-787-080 0E C-CAP,U 0.022-25 K B HTSM CX-NSZ300
O MICON C 0154 87-A12-078-040 0E CAP,E 47-35 SMG HSSM CX-NSZ300
O MICON C 0154 87-A12-078-040 0E CAP,E 47-35 SMG HTSM CX-NSZ300
O MICON C 0155 87-010-404-040 0E CAP,E 4.7-50 M 11L SME HSSM CX-NSZ300
O MICON C 0155 87-010-404-040 0E CAP,E 4.7-50 M 11L SME HTSM CX-NSZ300
O MICON C 0156 87-010-404-040 0E CAP,E 4.7-50 M 11L SME HSSM CX-NSZ300
O MICON C 0156 87-010-404-040 0E CAP,E 4.7-50 M 11L SME HTSM CX-NSZ300
O MICON C 0301 87-012-278-080 0E C-CAP,U 2200P-50 K B HSSM CX-NSZ300
O MICON C 0301 87-012-278-080 0E C-CAP,U 2200P-50 K B HTSM CX-NSZ300
O MICON C 0351 87-A10-353-080 0E C-CAP,U 0.22-10 K B HSSM CX-NSZ300
O MICON C 0351 87-A10-353-080 0E C-CAP,U 0.22-10 K B HTSM CX-NSZ300
O MICON C 0361 87-012-274-080 0E C-CAP,U 1000P-50 K B HSSM CX-NSZ300
O MICON C 0361 87-012-274-080 0E C-CAP,U 1000P-50 K B HTSM CX-NSZ300
O MICON C 0362 87-012-274-080 0E C-CAP,U 1000P-50 K B HSSM CX-NSZ300
O MICON C 0362 87-012-274-080 0E C-CAP,U 1000P-50 K B HTSM CX-NSZ300
O MICON C 0371 87-012-274-080 0E C-CAP,U 1000P-50 K B HSSM CX-NSZ300
O MICON C 0371 87-012-274-080 0E C-CAP,U 1000P-50 K B HTSM CX-NSZ300
O MICON C 0372 87-012-274-080 0E C-CAP,U 1000P-50 K B HSSM CX-NSZ300
O MICON C 0372 87-012-274-080 0E C-CAP,U 1000P-50 K B HTSM CX-NSZ300
O MICON C 0601 87-010-382-040 0E CAP,E 22-25 M 11L SME HSSM CX-NSZ300
O MICON C 0601 87-010-382-040 0E CAP,E 22-25 M 11L SME HTSM CX-NSZ300
O MICON C 0801 87-A10-804-080 0E C-CAP,S 0.1-25 J B HSSM CX-NSZ300
O MICON C 0801 87-A10-804-080 0E C-CAP,S 0.1-25 J B HTSM CX-NSZ300
O MICON C 0802 87-010-316-080 0E C-CAP,S 33P-50 J CH GRM HSSM CX-NSZ300
O MICON C 0802 87-010-316-080 0E C-CAP,S 33P-50 J CH GRM HTSM CX-NSZ300
O MICON C 0803 87-012-280-080 0E C-CAP,U 3300P-50 K B HSSM CX-NSZ300
O MICON C 0803 87-012-280-080 0E C-CAP,U 3300P-50 K B HTSM CX-NSZ300
O MICON C 0804 87-A10-592-080 0E C-CAP,S 0.015-50 J B HSSM CX-NSZ300
O MICON C 0804 87-A10-592-080 0E C-CAP,S 0.015-50 J B HTSM CX-NSZ300
O MICON C 0805 87-012-184-080 0E C-CAP,U 33P-50 J CH HSSM CX-NSZ300
www.rtv-horvat-dj.hr
7
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O MICON C 0805 87-012-184-080 0E C-CAP,U 33P-50 J CH HTSM CX-NSZ300
O MICON C 0806 87-012-274-080 0E C-CAP,U 1000P-50 K B HSSM CX-NSZ300
O MICON C 0806 87-012-274-080 0E C-CAP,U 1000P-50 K B HTSM CX-NSZ300
O MICON C 0807 87-012-274-080 0E C-CAP,U 1000P-50 K B HSSM CX-NSZ300
O MICON C 0807 87-012-274-080 0E C-CAP,U 1000P-50 K B HTSM CX-NSZ300
O MICON C 0808 87-010-544-040 0E CAP,E 0.1-50 M 11L SME HSSM CX-NSZ300
O MICON C 0808 87-010-544-040 0E CAP,E 0.1-50 M 11L SME HTSM CX-NSZ300
O MICON C 0809 87-010-404-040 0E CAP,E 4.7-50 M 11L SME HSSM CX-NSZ300
O MICON C 0809 87-010-404-040 0E CAP,E 4.7-50 M 11L SME HTSM CX-NSZ300
O MICON C 0810 87-012-286-080 0E C-CAP,U 0.01-25 K B HSSM CX-NSZ300
O MICON C 0810 87-012-286-080 0E C-CAP,U 0.01-25 K B HTSM CX-NSZ300
O MICON C 0811 87-A12-052-080 0E C-CAP,S 0.033-25 J B HSSM CX-NSZ300
O MICON C 0811 87-A12-052-080 0E C-CAP,S 0.033-25 J B HTSM CX-NSZ300
O MICON C 0901 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O MICON C 0901 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O MICON C 0902 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O MICON C 0902 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O MICON C 0903 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O MICON C 0903 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O MICON C 0904 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O MICON C 0904 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O MICON C 0905 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O MICON C 0905 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O MICON C 0906 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O MICON C 0906 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O MICON C 0907 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O MICON C 0907 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O MICON C 0908 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O MICON C 0908 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O MICON C 0909 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O MICON C 0909 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O MICON C 0910 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O MICON C 0910 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O MICON C 0911 87-012-274-080 0E C-CAP,U 1000P-50 K B HSSM CX-NSZ300
O MICON C 0911 87-012-274-080 0E C-CAP,U 1000P-50 K B HTSM CX-NSZ300
O MICON C 0912 87-010-831-080 0E C-CAP,U 0.1-16 Z F HSSM CX-NSZ300
O MICON C 0912 87-010-831-080 0E C-CAP,U 0.1-16 Z F HTSM CX-NSZ300
O MICON C 0913 87-A10-189-040 0E CAP,E 220-10 M 5L HSSM CX-NSZ300
O MICON C 0913 87-A10-189-040 0E CAP,E 220-10 M 5L HTSM CX-NSZ300
O MICON C 0914 87-A10-189-040 0E CAP,E 220-10 M 5L HSSM CX-NSZ300
O MICON C 0914 87-A10-189-040 0E CAP,E 220-10 M 5L HTSM CX-NSZ300
O MICON C 0915 87-010-831-080 0E C-CAP,U 0.1-16 Z F HSSM CX-NSZ300
O MICON C 0915 87-010-831-080 0E C-CAP,U 0.1-16 Z F HTSM CX-NSZ300
O MICON C 0916 87-010-831-080 0E C-CAP,U 0.1-16 Z F HSSM CX-NSZ300
O MICON C 0916 87-010-831-080 0E C-CAP,U 0.1-16 Z F HTSM CX-NSZ300
O MICON C 0917 87-010-831-080 0E C-CAP,U 0.1-16 Z F HSSM CX-NSZ300
O MICON C 0917 87-010-831-080 0E C-CAP,U 0.1-16 Z F HTSM CX-NSZ300
O MICON C 0919 87-012-286-080 0E C-CAP,U 0.01-25 K B HSSM CX-NSZ300
O MICON C 0919 87-012-286-080 0E C-CAP,U 0.01-25 K B HTSM CX-NSZ300
O MICON C 0920 87-010-829-080 0E C-CAP,U 0.047-16 Z F HSSM CX-NSZ300
O MICON C 0920 87-010-829-080 0E C-CAP,U 0.047-16 Z F HTSM CX-NSZ300
O MICON C 0921 87-012-282-080 0E C-CAP,U 4700P-50 K B HSSM CX-NSZ300
O MICON C 0921 87-012-282-080 0E C-CAP,U 4700P-50 K B HTSM CX-NSZ300
O MICON C 0951 87-012-172-080 0E C-CAP,U 10P-50 D CH HSSM CX-NSZ300
O MICON C 0951 87-012-172-080 0E C-CAP,U 10P-50 D CH HTSM CX-NSZ300
O MICON C 0952 87-010-854-080 0E C-CAP,S 560P-50 J CH HSSM CX-NSZ300
O MICON C 0952 87-010-854-080 0E C-CAP,S 560P-50 J CH HTSM CX-NSZ300
O MICON C 0953 87-012-349-080 0E C-CAP,S 1000P-50 J CH GRM HSSM CX-NSZ300
O MICON C 0953 87-012-349-080 0E C-CAP,S 1000P-50 J CH GRM HTSM CX-NSZ300
O MICON C 0961 87-010-378-040 0E CAP,E 10-16 M 11L SME HSSM CX-NSZ300
O MICON C 0961 87-010-378-040 0E CAP,E 10-16 M 11L SME HTSM CX-NSZ300
O MICON C 0962 87-012-336-080 0E C-CAP,U 330P-50 J SL HSSM CX-NSZ300
O MICON C 0962 87-012-336-080 0E C-CAP,U 330P-50 J SL HTSM CX-NSZ300
O MICON C 0963 87-010-831-080 0E C-CAP,U 0.1-16 Z F HSSM CX-NSZ300
O MICON C 0963 87-010-831-080 0E C-CAP,U 0.1-16 Z F HTSM CX-NSZ300
! O MICON CN 0104 87-A60-057-010 0E CONN,11P V 9604S-11C HSSM CX-NSZ300
! O MICON CN 0104 87-A60-057-010 0E CONN,11P V 9604S-11C HTSM CX-NSZ300
! O MICON CN 0701 87-099-720-010 1B CONN,30P BLK TYK-B(P) HSSM CX-NSZ300
! O MICON CN 0701 87-099-720-010 1B CONN,30P BLK TYK-B(P) HTSM CX-NSZ300
! O MICON CN 0731 87-099-196-010 0E CONN,8P V BLK 6216 HSSM CX-NSZ300
www.rtv-horvat-dj.hr
8
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
! O MICON CN 0731 87-099-196-010 0E CONN,8P V BLK 6216 HTSM CX-NSZ300
S MICON D 0104 87-A40-291-080 0E DIODE,1N4148M (CPT) HSSM CX-NSZ300
S MICON D 0104 87-A40-291-080 0E DIODE,1N4148M (CPT) HTSM CX-NSZ300
S MICON D 0301 87-A40-748-080 0E ZENER,UZ5.6BSA HSSM CX-NSZ300
S MICON D 0301 87-A40-748-080 0E ZENER,UZ5.6BSA HTSM CX-NSZ300
S MICON D 0302 87-A40-291-080 0E DIODE,1N4148M (CPT) HSSM CX-NSZ300
S MICON D 0302 87-A40-291-080 0E DIODE,1N4148M (CPT) HTSM CX-NSZ300
S MICON D 0601 87-A40-269-080 0E C-DIODE,MC2836 HSSM CX-NSZ300
S MICON D 0601 87-A40-269-080 0E C-DIODE,MC2836 HTSM CX-NSZ300
S MICON D 0651 87-A40-269-080 0E C-DIODE,MC2836 HSSM CX-NSZ300
S MICON D 0651 87-A40-269-080 0E C-DIODE,MC2836 HTSM CX-NSZ300
S MICON D 0652 87-A40-269-080 0E C-DIODE,MC2836 HSSM CX-NSZ300
S MICON D 0652 87-A40-269-080 0E C-DIODE,MC2836 HTSM CX-NSZ300
S MICON D 0653 87-A40-269-080 0E C-DIODE,MC2836 HSSM CX-NSZ300
S MICON D 0653 87-A40-269-080 0E C-DIODE,MC2836 HTSM CX-NSZ300
S MICON D 0654 87-A40-269-080 0E C-DIODE,MC2836 HSSM CX-NSZ300
S MICON D 0654 87-A40-269-080 0E C-DIODE,MC2836 HTSM CX-NSZ300
S MICON D 0655 87-A40-269-080 0E C-DIODE,MC2836 HSSM CX-NSZ300
S MICON D 0655 87-A40-269-080 0E C-DIODE,MC2836 HTSM CX-NSZ300
S MICON D 0656 87-A40-269-080 0E C-DIODE,MC2836 HSSM CX-NSZ300
S MICON D 0656 87-A40-269-080 0E C-DIODE,MC2836 HTSM CX-NSZ300
X MICON D 0702 88-100-000-010 0E PLATING-J , 0.58 SN95 HSSM CX-NSZ300
X MICON D 0702 88-100-000-010 0E PLATING-J , 0.58 SN95 HTSM CX-NSZ300
X MICON D 0703 88-100-000-010 0E PLATING-J , 0.58 SN95 HSSM CX-NSZ300
X MICON D 0703 88-100-000-010 0E PLATING-J , 0.58 SN95 HTSM CX-NSZ300
S MICON D 0801 87-A40-291-080 0E DIODE,1N4148M (CPT) HSSM CX-NSZ300
S MICON D 0801 87-A40-291-080 0E DIODE,1N4148M (CPT) HTSM CX-NSZ300
S MICON D 0984 87-A40-291-080 0E DIODE,1N4148M (CPT) HTSM CX-NSZ300
S MICON D 0989 87-A40-291-080 0E DIODE,1N4148M (CPT) HSSM CX-NSZ300
S MICON D 0989 87-A40-291-080 0E DIODE,1N4148M (CPT) HTSM CX-NSZ300
O MICON EMI0402 87-008-372-080 0E FLTR,EMI BL01 RN1 HSSM CX-NSZ300
O MICON EMI0402 87-008-372-080 0E FLTR,EMI BL01 RN1 HTSM CX-NSZ300
O MICON FL 0901 8B-NF9-605-010 2M FL,BJ814GNK HSSM CX-NSZ300
O MICON FL 0901 8B-NF9-605-010 2M FL,BJ814GNK HTSM CX-NSZ300
S MICON IC 0901 8B-NF9-601-030 2A C-IC,UPD780226GF-021-3BA HSSM CX-NSZ300
S MICON IC 0901 8B-NF9-601-030 2A C-IC,UPD780226GF-021-3BA HTSM CX-NSZ300
S MICON IC 0961 87-A21-218-110 1B IC,NJL64H380A HSSM CX-NSZ300
S MICON IC 0961 87-A21-218-110 1B IC,NJL64H380A HTSM CX-NSZ300
X MICON JR 0101 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0101 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0151 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0151 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0152 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0152 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0361 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0361 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0402 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0402 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0601 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0601 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0603 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0603 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0605 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0605 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0607 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0607 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0609 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0609 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0612 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0612 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0616 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0616 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0617 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0617 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0618 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0618 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0619 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0619 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0621 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0621 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
www.rtv-horvat-dj.hr
9
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON JR 0901 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0901 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0902 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0902 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0903 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0903 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0904 88-129-000-080 0E C-JUMPER,3216 HSSM CX-NSZ300
X MICON JR 0904 88-129-000-080 0E C-JUMPER,3216 HTSM CX-NSZ300
X MICON JR 0905 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0905 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0906 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0906 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON JR 0964 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON JR 0964 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
O MICON L 0951 87-A50-655-010 0E COIL,CLK 4.19MHZ (TOKO)7KLY HSSM CX-NSZ300
O MICON L 0951 87-A50-655-010 0E COIL,CLK 4.19MHZ (TOKO)7KLY HTSM CX-NSZ300
O MICON LED0209 87-A41-062-040 0E LED,LTL-1CHEE-012A RED HSSM CX-NSZ300
O MICON LED0209 87-A41-062-040 0E LED,LTL-1CHEE-012A RED HTSM CX-NSZ300
S MICON Q 0102 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
S MICON Q 0102 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
S MICON Q 0103 87-A30-074-080 0E C-TR,RT1P 141C HSSM CX-NSZ300
S MICON Q 0103 87-A30-074-080 0E C-TR,RT1P 141C HTSM CX-NSZ300
S MICON Q 0104 87-A30-074-080 0E C-TR,RT1P 141C HSSM CX-NSZ300
S MICON Q 0104 87-A30-074-080 0E C-TR,RT1P 141C HTSM CX-NSZ300
S MICON Q 0105 87-A30-468-080 0E C-TR,KRC102S-RTK HSSM CX-NSZ300
S MICON Q 0105 87-A30-468-080 0E C-TR,KRC102S-RTK HTSM CX-NSZ300
S MICON Q 0301 87-A30-494-080 0E TR,2SA1980G HSSM CX-NSZ300
S MICON Q 0301 87-A30-494-080 0E TR,2SA1980G HTSM CX-NSZ300
S MICON Q 0302 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
S MICON Q 0302 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
S MICON Q 0303 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
S MICON Q 0303 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
S MICON Q 0601 87-A30-495-080 0E TR,2SA1981Y HSSM CX-NSZ300
S MICON Q 0601 87-A30-495-080 0E TR,2SA1981Y HTSM CX-NSZ300
S MICON Q 0602 87-A30-495-080 0E TR,2SA1981Y HSSM CX-NSZ300
S MICON Q 0602 87-A30-495-080 0E TR,2SA1981Y HTSM CX-NSZ300
S MICON Q 0603 87-A30-582-080 0E TR,CDA1585BC HSSM CX-NSZ300
S MICON Q 0603 87-A30-582-080 0E TR,CDA1585BC HTSM CX-NSZ300
S MICON Q 0801 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
S MICON Q 0801 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
S MICON Q 0802 87-A30-075-080 0E C-TR,2SA1235F HSSM CX-NSZ300
S MICON Q 0802 87-A30-075-080 0E C-TR,2SA1235F HTSM CX-NSZ300
S MICON Q 0803 87-A30-288-040 0E C-TR,DTC114YKA HTSM CX-NSZ300
S MICON Q 0803 87-A30-490-080 0E C-TR,KRC107S HSSM CX-NSZ300
S MICON Q 0804 87-A30-288-040 0E C-TR,DTC114YKA HTSM CX-NSZ300
S MICON Q 0804 87-A30-490-080 0E C-TR,KRC107S HSSM CX-NSZ300
S MICON Q 0805 87-A30-288-040 0E C-TR,DTC114YKA HTSM CX-NSZ300
S MICON Q 0805 87-A30-490-080 0E C-TR,KRC107S HSSM CX-NSZ300
S MICON Q 0901 87-A30-074-080 0E C-TR,RT1P 141C HSSM CX-NSZ300
S MICON Q 0901 87-A30-074-080 0E C-TR,RT1P 141C HTSM CX-NSZ300
X MICON R 0109 88-108-224-080 0E C-RES,U 220K-1/16 J HSSM CX-NSZ300
X MICON R 0109 88-108-224-080 0E C-RES,U 220K-1/16 J HTSM CX-NSZ300
X MICON R 0110 88-108-153-080 0E C-RES,U 15K-1/16 J HSSM CX-NSZ300
X MICON R 0110 88-108-153-080 0E C-RES,U 15K-1/16 J HTSM CX-NSZ300
X MICON R 0111 88-108-333-080 0E C-RES,U 33K-1/16 J HSSM CX-NSZ300
X MICON R 0111 88-108-333-080 0E C-RES,U 33K-1/16 J HTSM CX-NSZ300
X MICON R 0112 88-108-224-080 0E C-RES,U 220K-1/16 J HSSM CX-NSZ300
X MICON R 0112 88-108-224-080 0E C-RES,U 220K-1/16 J HTSM CX-NSZ300
X MICON R 0114 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0114 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0115 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0115 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0116 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0116 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0151 88-100-000-010 0E PLATING-J , 0.58 SN95 HSSM CX-NSZ300
X MICON R 0151 88-100-000-010 0E PLATING-J , 0.58 SN95 HTSM CX-NSZ300
X MICON R 0152 88-100-000-010 0E PLATING-J , 0.58 SN95 HSSM CX-NSZ300
X MICON R 0152 88-100-000-010 0E PLATING-J , 0.58 SN95 HTSM CX-NSZ300
X MICON R 0153 88-128-821-080 0E C-RES, 820-1/8 J HSSM CX-NSZ300
X MICON R 0153 88-128-821-080 0E C-RES, 820-1/8 J HTSM CX-NSZ300
www.rtv-horvat-dj.hr
10
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0154 88-128-821-080 0E C-RES, 820-1/8 J HSSM CX-NSZ300
X MICON R 0154 88-128-821-080 0E C-RES, 820-1/8 J HTSM CX-NSZ300
X MICON R 0155 88-108-332-080 0E C-RES,U 3.3K-1/16 J HSSM CX-NSZ300
X MICON R 0155 88-108-332-080 0E C-RES,U 3.3K-1/16 J HTSM CX-NSZ300
X MICON R 0156 88-108-332-080 0E C-RES,U 3.3K-1/16 J HSSM CX-NSZ300
X MICON R 0156 88-108-332-080 0E C-RES,U 3.3K-1/16 J HTSM CX-NSZ300
X MICON R 0208 88-121-332-080 0E RES,3.3K-1/8 J HSSM CX-NSZ300
X MICON R 0208 88-121-332-080 0E RES,3.3K-1/8 J HTSM CX-NSZ300
X MICON R 0301 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0301 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0302 88-108-472-080 0E C-RES,U 4.7K-1/16 J HSSM CX-NSZ300
X MICON R 0302 88-108-472-080 0E C-RES,U 4.7K-1/16 J HTSM CX-NSZ300
X MICON R 0303 88-108-153-080 0E C-RES,U 15K-1/16 J HSSM CX-NSZ300
X MICON R 0303 88-108-153-080 0E C-RES,U 15K-1/16 J HTSM CX-NSZ300
X MICON R 0304 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0304 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0306 88-108-471-080 0E C-RES,U 470-1/16 J HSSM CX-NSZ300
X MICON R 0306 88-108-471-080 0E C-RES,U 470-1/16 J HTSM CX-NSZ300
X MICON R 0321 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0321 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0322 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0322 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0323 88-108-821-080 0E C-RES,U 820-1/16 J HSSM CX-NSZ300
X MICON R 0323 88-108-821-080 0E C-RES,U 820-1/16 J HTSM CX-NSZ300
X MICON R 0324 88-108-122-080 0E C-RES,U 1.2K-1/16 J HSSM CX-NSZ300
X MICON R 0324 88-108-122-080 0E C-RES,U 1.2K-1/16 J HTSM CX-NSZ300
X MICON R 0325 88-108-122-080 0E C-RES,U 1.2K-1/16 J HSSM CX-NSZ300
X MICON R 0325 88-108-122-080 0E C-RES,U 1.2K-1/16 J HTSM CX-NSZ300
X MICON R 0326 88-108-122-080 0E C-RES,U 1.2K-1/16 J HSSM CX-NSZ300
X MICON R 0326 88-108-122-080 0E C-RES,U 1.2K-1/16 J HTSM CX-NSZ300
X MICON R 0327 88-108-182-080 0E C-RES,U 1.8K-1/16 J HSSM CX-NSZ300
X MICON R 0327 88-108-182-080 0E C-RES,U 1.8K-1/16 J HTSM CX-NSZ300
X MICON R 0328 88-108-182-080 0E C-RES,U 1.8K-1/16 J HSSM CX-NSZ300
X MICON R 0328 88-108-182-080 0E C-RES,U 1.8K-1/16 J HTSM CX-NSZ300
X MICON R 0329 88-121-272-080 0E RES,2.7K-1/8 J HSSM CX-NSZ300
X MICON R 0329 88-121-272-080 0E RES,2.7K-1/8 J HTSM CX-NSZ300
X MICON R 0330 88-108-332-080 0E C-RES,U 3.3K-1/16 J HSSM CX-NSZ300
X MICON R 0330 88-108-332-080 0E C-RES,U 3.3K-1/16 J HTSM CX-NSZ300
X MICON R 0331 88-121-472-080 0E RES,4.7K-1/8 J HSSM CX-NSZ300
X MICON R 0331 88-121-472-080 0E RES,4.7K-1/8 J HTSM CX-NSZ300
X MICON R 0332 88-108-682-080 0E C-RES,U 6.8K-1/16 J HSSM CX-NSZ300
X MICON R 0332 88-108-682-080 0E C-RES,U 6.8K-1/16 J HTSM CX-NSZ300
X MICON R 0333 88-121-103-080 0E RES,10K-1/8 J HSSM CX-NSZ300
X MICON R 0333 88-121-103-080 0E RES,10K-1/8 J HTSM CX-NSZ300
X MICON R 0334 88-108-183-080 0E C-RES,U 18K-1/16 J HSSM CX-NSZ300
X MICON R 0334 88-108-183-080 0E C-RES,U 18K-1/16 J HTSM CX-NSZ300
X MICON R 0341 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0341 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0342 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0342 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0343 88-108-821-080 0E C-RES,U 820-1/16 J HSSM CX-NSZ300
X MICON R 0343 88-108-821-080 0E C-RES,U 820-1/16 J HTSM CX-NSZ300
X MICON R 0344 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0344 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0345 88-108-122-080 0E C-RES,U 1.2K-1/16 J HSSM CX-NSZ300
X MICON R 0345 88-108-122-080 0E C-RES,U 1.2K-1/16 J HTSM CX-NSZ300
X MICON R 0346 88-121-122-080 0E RES,1.2K-1/8 J HSSM CX-NSZ300
X MICON R 0346 88-121-122-080 0E RES,1.2K-1/8 J HTSM CX-NSZ300
X MICON R 0347 88-108-182-080 0E C-RES,U 1.8K-1/16 J HSSM CX-NSZ300
X MICON R 0347 88-108-182-080 0E C-RES,U 1.8K-1/16 J HTSM CX-NSZ300
X MICON R 0348 88-108-182-080 0E C-RES,U 1.8K-1/16 J HSSM CX-NSZ300
X MICON R 0348 88-108-182-080 0E C-RES,U 1.8K-1/16 J HTSM CX-NSZ300
X MICON R 0349 88-108-272-080 0E C-RES,U 2.7K-1/16 J HSSM CX-NSZ300
X MICON R 0349 88-108-272-080 0E C-RES,U 2.7K-1/16 J HTSM CX-NSZ300
X MICON R 0361 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0361 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0362 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0362 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0363 88-108-100-080 0E C-RES,U 10-1/16 J HSSM CX-NSZ300
X MICON R 0363 88-108-100-080 0E C-RES,U 10-1/16 J HTSM CX-NSZ300
www.rtv-horvat-dj.hr
11
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0364 88-108-100-080 0E C-RES,U 10-1/16 J HSSM CX-NSZ300
X MICON R 0364 88-108-100-080 0E C-RES,U 10-1/16 J HTSM CX-NSZ300
X MICON R 0371 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0371 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0372 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0372 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0373 88-108-100-080 0E C-RES,U 10-1/16 J HSSM CX-NSZ300
X MICON R 0373 88-108-100-080 0E C-RES,U 10-1/16 J HTSM CX-NSZ300
X MICON R 0374 88-108-100-080 0E C-RES,U 10-1/16 J HSSM CX-NSZ300
X MICON R 0374 88-108-100-080 0E C-RES,U 10-1/16 J HTSM CX-NSZ300
X MICON R 0601 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0601 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0602 88-108-222-080 0E C-RES,U 2.2K-1/16 J HSSM CX-NSZ300
X MICON R 0602 88-108-222-080 0E C-RES,U 2.2K-1/16 J HTSM CX-NSZ300
X MICON R 0603 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0603 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0604 88-108-222-080 0E C-RES,U 2.2K-1/16 J HSSM CX-NSZ300
X MICON R 0604 88-108-222-080 0E C-RES,U 2.2K-1/16 J HTSM CX-NSZ300
X MICON R 0605 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0605 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0606 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0606 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0607 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON R 0607 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON R 0611 88-108-473-080 0E C-RES,U 47K-1/16 J HSSM CX-NSZ300
X MICON R 0611 88-108-473-080 0E C-RES,U 47K-1/16 J HTSM CX-NSZ300
X MICON R 0613 88-108-473-080 0E C-RES,U 47K-1/16 J HSSM CX-NSZ300
X MICON R 0613 88-108-473-080 0E C-RES,U 47K-1/16 J HTSM CX-NSZ300
X MICON R 0614 88-108-473-080 0E C-RES,U 47K-1/16 J HSSM CX-NSZ300
X MICON R 0614 88-108-473-080 0E C-RES,U 47K-1/16 J HTSM CX-NSZ300
X MICON R 0615 88-108-473-080 0E C-RES,U 47K-1/16 J HSSM CX-NSZ300
X MICON R 0615 88-108-473-080 0E C-RES,U 47K-1/16 J HTSM CX-NSZ300
X MICON R 0616 88-108-473-080 0E C-RES,U 47K-1/16 J HSSM CX-NSZ300
X MICON R 0616 88-108-473-080 0E C-RES,U 47K-1/16 J HTSM CX-NSZ300
X MICON R 0651 88-128-152-080 0E C-RES, 1.5K-1/8 J HSSM CX-NSZ300
X MICON R 0651 88-128-152-080 0E C-RES, 1.5K-1/8 J HTSM CX-NSZ300
X MICON R 0652 88-108-152-080 0E C-RES,U 1.5K-1/16 J HSSM CX-NSZ300
X MICON R 0652 88-108-152-080 0E C-RES,U 1.5K-1/16 J HTSM CX-NSZ300
X MICON R 0653 88-108-152-080 0E C-RES,U 1.5K-1/16 J HSSM CX-NSZ300
X MICON R 0653 88-108-152-080 0E C-RES,U 1.5K-1/16 J HTSM CX-NSZ300
X MICON R 0654 88-108-152-080 0E C-RES,U 1.5K-1/16 J HSSM CX-NSZ300
X MICON R 0654 88-108-152-080 0E C-RES,U 1.5K-1/16 J HTSM CX-NSZ300
X MICON R 0655 88-128-152-080 0E C-RES, 1.5K-1/8 J HSSM CX-NSZ300
X MICON R 0655 88-128-152-080 0E C-RES, 1.5K-1/8 J HTSM CX-NSZ300
X MICON R 0656 88-108-152-080 0E C-RES,U 1.5K-1/16 J HSSM CX-NSZ300
X MICON R 0656 88-108-152-080 0E C-RES,U 1.5K-1/16 J HTSM CX-NSZ300
X MICON R 0704 88-121-102-080 0E RES,1K-1/8 J HSSM CX-NSZ300
X MICON R 0704 88-121-102-080 0E RES,1K-1/8 J HTSM CX-NSZ300
X MICON R 0705 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0705 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0706 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0706 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0707 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0707 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0708 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0708 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0709 88-108-101-080 0E C-RES,U 100-1/16 J HSSM CX-NSZ300
X MICON R 0709 88-108-101-080 0E C-RES,U 100-1/16 J HTSM CX-NSZ300
X MICON R 0710 88-121-101-080 0E RES,100-1/8 J HSSM CX-NSZ300
X MICON R 0710 88-121-101-080 0E RES,100-1/8 J HTSM CX-NSZ300
X MICON R 0711 88-108-101-080 0E C-RES,U 100-1/16 J HSSM CX-NSZ300
X MICON R 0711 88-108-101-080 0E C-RES,U 100-1/16 J HTSM CX-NSZ300
X MICON R 0712 88-128-101-080 0E C-RES, 100-1/8 J HSSM CX-NSZ300
X MICON R 0712 88-128-101-080 0E C-RES, 100-1/8 J HTSM CX-NSZ300
X MICON R 0715 88-128-101-080 0E C-RES, 100-1/8 J HSSM CX-NSZ300
X MICON R 0715 88-128-101-080 0E C-RES, 100-1/8 J HTSM CX-NSZ300
X MICON R 0716 88-108-472-080 0E C-RES,U 4.7K-1/16 J HSSM CX-NSZ300
X MICON R 0716 88-108-472-080 0E C-RES,U 4.7K-1/16 J HTSM CX-NSZ300
X MICON R 0719 88-121-100-080 0E RES,10-1/8 J HSSM CX-NSZ300
X MICON R 0719 88-121-100-080 0E RES,10-1/8 J HTSM CX-NSZ300
www.rtv-horvat-dj.hr
12
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0720 88-108-101-080 0E C-RES,U 100-1/16 J HSSM CX-NSZ300
X MICON R 0720 88-108-101-080 0E C-RES,U 100-1/16 J HTSM CX-NSZ300
X MICON R 0721 88-128-101-080 0E C-RES, 100-1/8 J HSSM CX-NSZ300
X MICON R 0721 88-128-101-080 0E C-RES, 100-1/8 J HTSM CX-NSZ300
X MICON R 0730 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0730 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0732 88-108-101-080 0E C-RES,U 100-1/16 J HSSM CX-NSZ300
X MICON R 0732 88-108-101-080 0E C-RES,U 100-1/16 J HTSM CX-NSZ300
X MICON R 0733 88-108-101-080 0E C-RES,U 100-1/16 J HSSM CX-NSZ300
X MICON R 0733 88-108-101-080 0E C-RES,U 100-1/16 J HTSM CX-NSZ300
X MICON R 0734 88-121-102-080 0E RES,1K-1/8 J HSSM CX-NSZ300
X MICON R 0734 88-121-102-080 0E RES,1K-1/8 J HTSM CX-NSZ300
X MICON R 0735 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0735 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0740 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0740 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0741 88-121-101-080 0E RES,100-1/8 J HSSM CX-NSZ300
X MICON R 0741 88-121-101-080 0E RES,100-1/8 J HTSM CX-NSZ300
X MICON R 0742 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0742 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0743 88-108-474-080 0E C-RES,U 470K-1/16 J HSSM CX-NSZ300
X MICON R 0743 88-108-474-080 0E C-RES,U 470K-1/16 J HTSM CX-NSZ300
X MICON R 0744 88-108-823-080 0E C-RES,U 82K-1/16 J HSSM CX-NSZ300
X MICON R 0744 88-108-823-080 0E C-RES,U 82K-1/16 J HTSM CX-NSZ300
X MICON R 0745 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0745 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0749 88-108-474-080 0E C-RES,U 470K-1/16 J HSSM CX-NSZ300
X MICON R 0749 88-108-474-080 0E C-RES,U 470K-1/16 J HTSM CX-NSZ300
X MICON R 0803 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0803 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0804 88-108-224-080 0E C-RES,U 220K-1/16 J HSSM CX-NSZ300
X MICON R 0804 88-108-224-080 0E C-RES,U 220K-1/16 J HTSM CX-NSZ300
X MICON R 0805 88-108-273-080 0E C-RES,U 27K-1/16 J HSSM CX-NSZ300
X MICON R 0805 88-108-273-080 0E C-RES,U 27K-1/16 J HTSM CX-NSZ300
X MICON R 0806 88-108-562-080 0E C-RES,U 5.6K-1/16 J HSSM CX-NSZ300
X MICON R 0806 88-108-562-080 0E C-RES,U 5.6K-1/16 J HTSM CX-NSZ300
X MICON R 0807 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON R 0807 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON R 0808 88-128-101-080 0E C-RES, 100-1/8 J HSSM CX-NSZ300
X MICON R 0808 88-128-101-080 0E C-RES, 100-1/8 J HTSM CX-NSZ300
X MICON R 0809 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0809 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0810 88-108-272-080 0E C-RES,U 2.7K-1/16 J HSSM CX-NSZ300
X MICON R 0810 88-108-272-080 0E C-RES,U 2.7K-1/16 J HTSM CX-NSZ300
X MICON R 0811 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0811 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0813 88-108-223-080 0E C-RES,U 22K-1/16 J HSSM CX-NSZ300
X MICON R 0813 88-108-223-080 0E C-RES,U 22K-1/16 J HTSM CX-NSZ300
X MICON R 0815 88-108-272-080 0E C-RES,U 2.7K-1/16 J HSSM CX-NSZ300
X MICON R 0815 88-108-272-080 0E C-RES,U 2.7K-1/16 J HTSM CX-NSZ300
X MICON R 0816 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0816 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0818 88-108-223-080 0E C-RES,U 22K-1/16 J HSSM CX-NSZ300
X MICON R 0818 88-108-223-080 0E C-RES,U 22K-1/16 J HTSM CX-NSZ300
X MICON R 0819 88-108-272-080 0E C-RES,U 2.7K-1/16 J HSSM CX-NSZ300
X MICON R 0819 88-108-272-080 0E C-RES,U 2.7K-1/16 J HTSM CX-NSZ300
X MICON R 0821 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0821 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0822 88-108-223-080 0E C-RES,U 22K-1/16 J HSSM CX-NSZ300
X MICON R 0822 88-108-223-080 0E C-RES,U 22K-1/16 J HTSM CX-NSZ300
X MICON R 0823 88-108-101-080 0E C-RES,U 100-1/16 J HSSM CX-NSZ300
X MICON R 0823 88-108-101-080 0E C-RES,U 100-1/16 J HTSM CX-NSZ300
X MICON R 0824 88-108-101-080 0E C-RES,U 100-1/16 J HSSM CX-NSZ300
X MICON R 0824 88-108-101-080 0E C-RES,U 100-1/16 J HTSM CX-NSZ300
X MICON R 0825 88-108-101-080 0E C-RES,U 100-1/16 J HSSM CX-NSZ300
X MICON R 0825 88-108-101-080 0E C-RES,U 100-1/16 J HTSM CX-NSZ300
X MICON R 0826 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON R 0826 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON R 0827 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0827 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
www.rtv-horvat-dj.hr
13
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0901 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0901 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0902 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0902 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0903 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0903 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0904 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0904 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0905 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0905 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0906 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0906 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0907 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0907 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0908 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0908 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0909 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0909 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0910 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0910 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0911 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0911 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0912 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0912 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0913 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0913 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0914 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0914 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0915 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0915 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0916 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0916 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0917 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0917 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0918 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0918 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0919 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0919 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0920 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0920 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0921 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0921 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0922 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0922 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0923 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0923 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0924 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0924 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0925 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0925 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0926 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0926 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0927 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0927 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0928 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0928 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0929 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0929 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0930 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0930 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0931 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0931 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0932 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0932 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0933 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0933 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0934 88-108-683-080 0E C-RES,U 68K-1/16 J HSSM CX-NSZ300
X MICON R 0934 88-108-683-080 0E C-RES,U 68K-1/16 J HTSM CX-NSZ300
X MICON R 0935 88-108-683-080 0E C-RES,U 68K-1/16 J HSSM CX-NSZ300
X MICON R 0935 88-108-683-080 0E C-RES,U 68K-1/16 J HTSM CX-NSZ300
www.rtv-horvat-dj.hr
14
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0936 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0936 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0937 88-128-472-080 0E C-RES, 4.7K-1/8 J HSSM CX-NSZ300
X MICON R 0937 88-128-472-080 0E C-RES, 4.7K-1/8 J HTSM CX-NSZ300
X MICON R 0938 88-108-472-080 0E C-RES,U 4.7K-1/16 J HSSM CX-NSZ300
X MICON R 0938 88-108-472-080 0E C-RES,U 4.7K-1/16 J HTSM CX-NSZ300
X MICON R 0939 88-108-472-080 0E C-RES,U 4.7K-1/16 J HSSM CX-NSZ300
X MICON R 0939 88-108-472-080 0E C-RES,U 4.7K-1/16 J HTSM CX-NSZ300
X MICON R 0940 88-121-104-080 0E RES,100K-1/8 J HSSM CX-NSZ300
X MICON R 0940 88-121-104-080 0E RES,100K-1/8 J HTSM CX-NSZ300
X MICON R 0941 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0941 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0942 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0942 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0943 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X MICON R 0943 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X MICON R 0946 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X MICON R 0946 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X MICON R 0947 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0947 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0948 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0948 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0951 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X MICON R 0951 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X MICON R 0955 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0955 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0956 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0956 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0957 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0957 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0958 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X MICON R 0958 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X MICON R 0961 88-128-181-080 0E C-RES, 180-1/8 J HSSM CX-NSZ300
X MICON R 0961 88-128-181-080 0E C-RES, 180-1/8 J HTSM CX-NSZ300
X MICON R 0962 88-108-563-080 0E C-RES,U 56K-1/16 J HSSM CX-NSZ300
X MICON R 0962 88-108-563-080 0E C-RES,U 56K-1/16 J HTSM CX-NSZ300
O MICON S 0321 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0321 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0322 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0322 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0323 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0323 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0324 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0324 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0325 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0325 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0326 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0326 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0327 87-A90-095-080 0E S ,TACT EVQ11G04M HSSM CX-NSZ300
O MICON S 0327 87-A90-095-080 0E S ,TACT EVQ11G04M HTSM CX-NSZ300
O MICON S 0328 87-A90-095-080 0E S ,TACT EVQ11G04M HSSM CX-NSZ300
O MICON S 0328 87-A90-095-080 0E S ,TACT EVQ11G04M HTSM CX-NSZ300
O MICON S 0329 87-A90-095-080 0E S ,TACT EVQ11G04M HSSM CX-NSZ300
O MICON S 0329 87-A90-095-080 0E S ,TACT EVQ11G04M HTSM CX-NSZ300
O MICON S 0330 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0330 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0331 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0331 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0332 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0332 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0333 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0333 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0334 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0334 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0341 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0341 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0342 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0342 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0343 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0343 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
www.rtv-horvat-dj.hr
15
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O MICON S 0344 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0344 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0345 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0345 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0346 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0346 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0347 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0347 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0348 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0348 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0349 87-A90-164-080 0E S ,TACT SKQNAB(N) HSSM CX-NSZ300
O MICON S 0349 87-A90-164-080 0E S ,TACT SKQNAB(N) HTSM CX-NSZ300
O MICON S 0361 87-A92-041-010 1A S ,RTRY XRE012103PVB30F-24 HSSM CX-NSZ300
O MICON S 0361 87-A92-041-010 1A S ,RTRY XRE012103PVB30F-24 HTSM CX-NSZ300
O MICON S 0371 87-A92-040-010 1A S ,RTRY XRE012103PVB30F-12 HSSM CX-NSZ300
O MICON S 0371 87-A92-040-010 1A S ,RTRY XRE012103PVB30F-12 HTSM CX-NSZ300
! O OTHERS 82-NF5-229-010 0E PLATE,LOCK(*) HSSM CX-NSZ300
! O OTHERS 82-NF5-229-010 0E PLATE,LOCK(*) HTSM CX-NSZ300
O OTHERS 86-NF9-224-010 0E SPR-C,LOCK HSSM CX-NSZ300
O OTHERS 86-NF9-224-010 0E SPR-C,LOCK HTSM CX-NSZ300
X OTHERS 87-064-080-010 0E BINDER, IRE HSSM CX-NSZ300
X OTHERS 87-064-080-010 0E BINDER, IRE HTSM CX-NSZ300
! O OTHERS 87-NF4-216-010 0E HLDR,LOCK 1 HSSM CX-NSZ300
! O OTHERS 87-NF4-216-010 0E HLDR,LOCK 1 HTSM CX-NSZ300
! O OTHERS 87-NF4-217-110 0E HLDR,LOCK 2 HSSM CX-NSZ300
! O OTHERS 87-NF4-217-110 0E HLDR,LOCK 2 HTSM CX-NSZ300
! O OTHERS 87-NF4-221-010 0E HLDR,CABLE HSSM CX-NSZ300
! O OTHERS 87-NF4-221-010 0E HLDR,CABLE HTSM CX-NSZ300
! O OTHERS 8A-NF8-206-010 0E HLDR,P B M HSSM CX-NSZ300
! O OTHERS 8A-NF8-206-010 0E HLDR,P B M HTSM CX-NSZ300
O OTHERS 8A-NF8-281-010 0E SPR-T,EJECT 1 HSSM CX-NSZ300
O OTHERS 8A-NF8-281-010 0E SPR-T,EJECT 1 HTSM CX-NSZ300
O OTHERS 8A-NF8-282-010 0E SPR-T,EJECT 2 HSSM CX-NSZ300
O OTHERS 8A-NF8-282-010 0E SPR-T,EJECT 2 HTSM CX-NSZ300
! O OTHERS 8A-NF9-211-010 0E HLDR,P B PT HI HSSM CX-NSZ300
! O OTHERS 8A-NF9-211-010 0E HLDR,P B PT HI HTSM CX-NSZ300
X OTHERS 8A-NF9-225-010 0E SH,PT 20-16-1 /ADH HTSM CX-NSZ300
X OTHERS 8B-NF9-204-010 0E CUSH, 11-8.5-2 HSSM CX-NSZ300
X OTHERS 8B-NF9-204-010 0E CUSH, 11-8.5-2 HTSM CX-NSZ300
X OTHERS 8B-NF9-210-010 0E PLATE,EARTH MIC HSSM CX-NSZ300
X OTHERS 8B-NF9-210-010 0E PLATE,EARTH MIC HTSM CX-NSZ300
O OTHERS 8B-NF9-211-010 1B HLDR,TR S HSSM CX-NSZ300
O OTHERS 8B-NF9-211-010 1B HLDR,TR S HTSM CX-NSZ300
X OTHERS 8B-NF9-214-010 1C HT-SINK,MAIN60 S HSSM CX-NSZ300
X OTHERS 8B-NF9-214-010 1C HT-SINK,MAIN60 S HTSM CX-NSZ300
X OTHERS 8B-NFK-210-010 0E SH,TR VM HSSM CX-NSZ300
X OTHERS 8B-NFK-210-010 0E SH,TR VM HTSM CX-NSZ300
X OTHERS 8Z-NB8-212-010 0E PLATE,EARTH MECH HSSM CX-NSZ300
X OTHERS 8Z-NB8-212-010 0E PLATE,EARTH MECH HTSM CX-NSZ300
! O OTHERS 8Z-NF6-210-010 0E DMPR,150 N HSSM CX-NSZ300
! O OTHERS 8Z-NF6-210-010 0E DMPR,150 N HTSM CX-NSZ300
X P-SUPPLY/P B/FAN * 8B-NF9-670-110 1E P B,COMB MAIN -M'SIA HSSM CX-NSZ300
X P-SUPPLY/P B/FAN * 8B-NF9-670-110 1E P B,COMB MAIN -M'SIA HTSM CX-NSZ300
X P-SUPPLY/P B/FAN * 8B-NF9-671-110 -- P B,MAIN-M'SIA HSSM CX-NSZ300
X P-SUPPLY/P B/FAN * 8B-NF9-671-110 -- P B,MAIN-M'SIA HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0003 87-012-368-080 0E C-CAP,S 0.1-50 Z F HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0003 87-012-368-080 0E C-CAP,S 0.1-50 Z F HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0004 87-012-368-080 0E C-CAP,S 0.1-50 Z F HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0004 87-012-368-080 0E C-CAP,S 0.1-50 Z F HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0005 87-012-368-080 0E C-CAP,S 0.1-50 Z F HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0005 87-012-368-080 0E C-CAP,S 0.1-50 Z F HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0006 87-012-368-080 0E C-CAP,S 0.1-50 Z F HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0006 87-012-368-080 0E C-CAP,S 0.1-50 Z F HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0009 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0009 87-010-759-080 0E C-CAP,U 0.1-25 Z F HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0010 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0010 87-010-759-080 0E C-CAP,U 0.1-25 Z F HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0011 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0011 87-010-759-080 0E C-CAP,U 0.1-25 Z F HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0012 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSSM CX-NSZ300
www.rtv-horvat-dj.hr
16
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O P-SUPPLY/P B/FAN C 0012 87-010-759-080 0E C-CAP,U 0.1-25 Z F HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0019 87-A12-776-090 1B CAP,E 2200-50 M 85 SKR HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0019 87-A12-776-090 1B CAP,E 2200-50 M 85 SKR HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0020 87-A12-776-090 1B CAP,E 2200-50 M 85 SKR HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0020 87-A12-776-090 1B CAP,E 2200-50 M 85 SKR HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0021 87-A12-777-090 1A CAP,E 3300-25 M 85 SKR HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0021 87-A12-777-090 1A CAP,E 3300-25 M 85 SKR HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0022 87-A12-777-090 1A CAP,E 3300-25 M 85 SKR HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0022 87-A12-777-090 1A CAP,E 3300-25 M 85 SKR HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0025 87-A12-072-080 0E CAP,E 100-25 SMG HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0025 87-A12-072-080 0E CAP,E 100-25 SMG HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0026 87-A12-072-080 0E CAP,E 100-25 SMG HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0026 87-A12-072-080 0E CAP,E 100-25 SMG HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0027 87-A12-072-080 0E CAP,E 100-25 SMG HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0027 87-A12-072-080 0E CAP,E 100-25 SMG HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0028 87-A12-072-080 0E CAP,E 100-25 SMG HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0028 87-A12-072-080 0E CAP,E 100-25 SMG HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0030 87-A12-095-080 0E CAP,E 100-50 SMG HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0030 87-A12-095-080 0E CAP,E 100-50 SMG HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0031 87-A12-062-080 0E CAP,E 100-10 SMG HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0031 87-A12-062-080 0E CAP,E 100-10 SMG HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0032 87-012-286-080 0E C-CAP,U 0.01-25 K B HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0032 87-012-286-080 0E C-CAP,U 0.01-25 K B HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0034 87-A12-072-080 0E CAP,E 100-25 SMG HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0034 87-A12-072-080 0E CAP,E 100-25 SMG HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0035 87-A12-071-080 0E CAP,E 47-25 SMG HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0035 87-A12-071-080 0E CAP,E 47-25 SMG HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0036 87-A12-067-080 0E CAP,E 330-16 SMG HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0036 87-A12-067-080 0E CAP,E 330-16 SMG HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0038 87-012-286-080 0E C-CAP,U 0.01-25 K B HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0038 87-012-286-080 0E C-CAP,U 0.01-25 K B HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0060 87-A12-089-080 0E CAP,E 3.3-50 SMG HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0060 87-A12-089-080 0E CAP,E 3.3-50 SMG HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0061 87-A12-071-080 0E CAP,E 47-25 SMG HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0061 87-A12-071-080 0E CAP,E 47-25 SMG HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0083 87-A12-068-080 0E CAP,E 470-16 SMG HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0083 87-A12-074-080 0E CAP,E 470-25 SMG HTSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0097 87-010-831-080 0E C-CAP,U 0.1-16 Z F HSSM CX-NSZ300
O P-SUPPLY/P B/FAN C 0097 87-010-831-080 0E C-CAP,U 0.1-16 Z F HTSM CX-NSZ300
! O P-SUPPLY/P B/FAN CNA0001 8A-NF8-653-010 1B CONN ASSY,9P TID-A(480) HSSM CX-NSZ300
! O P-SUPPLY/P B/FAN CNA0001 8A-NF8-653-010 1B CONN ASSY,9P TID-A(480) HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0013 87-A40-454-090 0E DIODE,1N5393 G 12.5 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0013 87-A40-454-090 0E DIODE,1N5393 G 12.5 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0014 87-A40-454-090 0E DIODE,1N5393 G 12.5 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0014 87-A40-454-090 0E DIODE,1N5393 G 12.5 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0015 87-A40-454-090 0E DIODE,1N5393 G 12.5 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0015 87-A40-454-090 0E DIODE,1N5393 G 12.5 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0016 87-A40-454-090 0E DIODE,1N5393 G 12.5 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0016 87-A40-454-090 0E DIODE,1N5393 G 12.5 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0017 87-A40-454-090 0E DIODE,1N5393 G 12.5 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0017 87-A40-454-090 0E DIODE,1N5393 G 12.5 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0018 87-A40-454-090 0E DIODE,1N5393 G 12.5 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0018 87-A40-454-090 0E DIODE,1N5393 G 12.5 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0019 87-A40-454-090 0E DIODE,1N5393 G 12.5 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0019 87-A40-454-090 0E DIODE,1N5393 G 12.5 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0020 87-A40-454-090 0E DIODE,1N5393 G 12.5 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0020 87-A40-454-090 0E DIODE,1N5393 G 12.5 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0025 87-A40-553-080 0E DIODE,1N4003 LES HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0025 87-A40-553-080 0E DIODE,1N4003 LES HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0026 87-A40-553-080 0E DIODE,1N4003 LES HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0026 87-A40-553-080 0E DIODE,1N4003 LES HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0027 87-A40-553-080 0E DIODE,1N4003 LES HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0027 87-A40-553-080 0E DIODE,1N4003 LES HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0028 87-A40-553-080 0E DIODE,1N4003 LES HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0028 87-A40-553-080 0E DIODE,1N4003 LES HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0029 87-A40-776-080 0E ZENER,UZ27BSD HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0029 87-A40-776-080 0E ZENER,UZ27BSD HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0030 87-A40-291-080 0E DIODE,1N4148M (CPT) HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0030 87-A40-291-080 0E DIODE,1N4148M (CPT) HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0031 87-A40-764-080 0E ZENER,UZ10BSC HSSM CX-NSZ300
www.rtv-horvat-dj.hr
17
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
S P-SUPPLY/P B/FAN D 0031 87-A40-764-080 0E ZENER,UZ10BSC HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0033 87-A40-553-080 0E DIODE,1N4003 LES HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0033 87-A40-553-080 0E DIODE,1N4003 LES HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0034 87-A40-291-080 0E DIODE,1N4148M (CPT) HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0034 87-A40-291-080 0E DIODE,1N4148M (CPT) HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0035 87-A40-291-080 0E DIODE,1N4148M (CPT) HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0035 87-A40-291-080 0E DIODE,1N4148M (CPT) HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0041 87-A40-270-080 0E C-DIODE,MC2838 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0041 87-A40-270-080 0E C-DIODE,MC2838 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0042 87-A40-269-080 0E C-DIODE,MC2836 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0042 87-A40-269-080 0E C-DIODE,MC2836 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0060 87-A40-291-080 0E DIODE,1N4148M (CPT) HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0060 87-A40-291-080 0E DIODE,1N4148M (CPT) HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0062 87-A40-270-080 0E C-DIODE,MC2838 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0062 87-A40-270-080 0E C-DIODE,MC2838 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0063 87-A40-270-080 0E C-DIODE,MC2838 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0063 87-A40-270-080 0E C-DIODE,MC2838 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0064 87-A40-269-080 0E C-DIODE,MC2836 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0064 87-A40-269-080 0E C-DIODE,MC2836 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0065 87-A40-269-080 0E C-DIODE,MC2836 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0065 87-A40-269-080 0E C-DIODE,MC2836 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0071 87-A40-269-080 0E C-DIODE,MC2836 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0071 87-A40-269-080 0E C-DIODE,MC2836 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0072 87-A40-270-080 0E C-DIODE,MC2838 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0072 87-A40-270-080 0E C-DIODE,MC2838 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0076 87-A40-269-080 0E C-DIODE,MC2836 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0076 87-A40-269-080 0E C-DIODE,MC2836 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0077 87-A40-270-080 0E C-DIODE,MC2838 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN D 0077 87-A40-270-080 0E C-DIODE,MC2838 HTSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0001 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0001 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0003 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0003 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0004 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0004 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0005 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0005 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0006 88-129-000-080 0E C-JUMPER,3216 HSSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0006 88-129-000-080 0E C-JUMPER,3216 HTSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0023 88-128-820-080 0E C-RES, 82-1/8 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0023 88-128-820-080 0E C-RES, 82-1/8 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0024 88-128-820-080 0E C-RES, 82-1/8 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN JR 0024 88-128-820-080 0E C-RES, 82-1/8 J HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0001 87-A30-494-080 0E TR,2SA1980G HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0001 87-A30-494-080 0E TR,2SA1980G HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0002 87-A30-494-080 0E TR,2SA1980G HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0002 87-A30-494-080 0E TR,2SA1980G HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0003 87-A30-559-010 1A TR,CSB1370EF HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0003 87-A30-559-010 1A TR,CSB1370EF HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0005 87-026-610-080 0E TR,KTC3198GR HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0005 87-026-610-080 0E TR,KTC3198GR HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0006 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0006 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0008 87-A30-075-080 0E C-TR,2SA1235F HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0008 87-A30-075-080 0E C-TR,2SA1235F HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0009 87-A30-494-080 0E TR,2SA1980G HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0009 87-A30-494-080 0E TR,2SA1980G HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0010 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0010 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0059 87-A30-107-070 0E C-TR,CMBT5401 HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0059 87-A30-107-070 0E C-TR,CMBT5401 HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0060 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0060 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0061 87-A30-075-080 0E C-TR,2SA1235F HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0061 87-A30-075-080 0E C-TR,2SA1235F HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0062 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0062 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0063 87-A30-075-080 0E C-TR,2SA1235F HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0063 87-A30-075-080 0E C-TR,2SA1235F HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0064 87-A30-076-080 0E C-TR,2SC3052F HSSM CX-NSZ300
www.rtv-horvat-dj.hr
18
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
S P-SUPPLY/P B/FAN Q 0064 87-A30-076-080 0E C-TR,2SC3052F HTSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0065 87-A30-484-080 0E C-TR,KRA102S HSSM CX-NSZ300
S P-SUPPLY/P B/FAN Q 0065 87-A30-484-080 0E C-TR,KRA102S HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0001 88-100-000-010 0E PLATING-J , 0.58 SN95 HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0001 88-100-000-010 0E PLATING-J , 0.58 SN95 HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0005 88-100-000-010 0E PLATING-J , 0.58 SN95 HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0005 88-100-000-010 0E PLATING-J , 0.58 SN95 HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0009 88-108-273-080 0E C-RES,U 27K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0009 88-108-273-080 0E C-RES,U 27K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0010 88-108-273-080 0E C-RES,U 27K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0010 88-108-273-080 0E C-RES,U 27K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0011 88-108-472-080 0E C-RES,U 4.7K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0011 88-108-472-080 0E C-RES,U 4.7K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0012 88-108-472-080 0E C-RES,U 4.7K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0012 88-108-472-080 0E C-RES,U 4.7K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0013 88-108-472-080 0E C-RES,U 4.7K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0013 88-108-472-080 0E C-RES,U 4.7K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0014 88-118-100-080 0E C-RES,S 10-1/10 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0014 88-118-100-080 0E C-RES,S 10-1/10 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0015 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0015 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0016 88-108-333-080 0E C-RES,U 33K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0016 88-108-333-080 0E C-RES,U 33K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0017 88-100-000-010 0E PLATING-J , 0.58 SN95 HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0017 88-100-000-010 0E PLATING-J , 0.58 SN95 HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0018 88-118-221-080 0E C-RES,S 220-1/10 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0018 88-118-221-080 0E C-RES,S 220-1/10 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0019 88-108-000-080 0E C-JUMPER,U HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0019 88-108-000-080 0E C-JUMPER,U HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0020 88-121-680-080 0E RES,68-1/8 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0020 88-121-680-080 0E RES,68-1/8 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0021 88-108-472-080 0E C-RES,U 4.7K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0021 88-108-472-080 0E C-RES,U 4.7K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0022 88-108-221-080 0E C-RES,U 220-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0022 88-108-221-080 0E C-RES,U 220-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0023 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0023 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0027 88-118-471-080 0E C-RES,S 470-1/10 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0027 88-118-471-080 0E C-RES,S 470-1/10 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0028 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0028 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0029 88-108-222-080 0E C-RES,U 2.2K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0029 88-108-222-080 0E C-RES,U 2.2K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0030 88-108-333-080 0E C-RES,U 33K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0030 88-108-333-080 0E C-RES,U 33K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0031 88-108-473-080 0E C-RES,U 47K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0031 88-108-473-080 0E C-RES,U 47K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0032 88-121-102-080 0E RES,1K-1/8 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0032 88-121-102-080 0E RES,1K-1/8 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0033 88-108-101-080 0E C-RES,U 100-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0033 88-108-101-080 0E C-RES,U 100-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0034 88-108-394-080 0E C-RES,U 390K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0034 88-108-394-080 0E C-RES,U 390K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0037 88-128-680-080 0E C-RES, 68-1/8 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0037 88-128-680-080 0E C-RES, 68-1/8 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0038 88-130-151-080 0E RES,150-1/4 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0038 88-130-151-080 0E RES,150-1/4 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0039 88-128-680-080 0E C-RES, 68-1/8 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0039 88-128-680-080 0E C-RES, 68-1/8 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0042 88-130-151-080 0E RES,150-1/4 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0042 88-130-151-080 0E RES,150-1/4 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0043 88-130-151-080 0E RES,150-1/4 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0043 88-130-151-080 0E RES,150-1/4 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0044 88-128-680-080 0E C-RES, 68-1/8 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0044 88-128-680-080 0E C-RES, 68-1/8 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0045 88-128-680-080 0E C-RES, 68-1/8 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0045 88-128-680-080 0E C-RES, 68-1/8 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0046 88-130-151-080 0E RES,150-1/4 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0046 88-130-151-080 0E RES,150-1/4 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0047 88-100-000-010 0E PLATING-J , 0.58 SN95 HSSM CX-NSZ300
www.rtv-horvat-dj.hr
19
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X P-SUPPLY/P B/FAN R 0047 88-100-000-010 0E PLATING-J , 0.58 SN95 HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0050 88-128-680-080 0E C-RES, 68-1/8 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0050 88-128-680-080 0E C-RES, 68-1/8 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0051 88-128-680-080 0E C-RES, 68-1/8 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0051 88-128-680-080 0E C-RES, 68-1/8 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0052 88-108-333-080 0E C-RES,U 33K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0052 88-108-333-080 0E C-RES,U 33K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0054 88-118-473-080 0E C-RES,S 47K-1/10 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0054 88-118-473-080 0E C-RES,S 47K-1/10 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0055 88-118-473-080 0E C-RES,S 47K-1/10 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0055 88-118-473-080 0E C-RES,S 47K-1/10 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0056 88-108-822-080 0E C-RES,U 8.2K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0056 88-108-822-080 0E C-RES,U 8.2K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0057 88-108-222-080 0E C-RES,U 2.2K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0057 88-108-222-080 0E C-RES,U 2.2K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0058 88-108-682-080 0E C-RES,U 6.8K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0058 88-108-682-080 0E C-RES,U 6.8K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0059 88-118-103-080 0E C-RES,S 10K-1/10 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0059 88-118-103-080 0E C-RES,S 10K-1/10 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0060 88-118-473-080 0E C-RES,S 47K-1/10 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0060 88-118-473-080 0E C-RES,S 47K-1/10 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0061 88-108-333-080 0E C-RES,U 33K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0061 88-108-333-080 0E C-RES,U 33K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0062 88-108-273-080 0E C-RES,U 27K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0062 88-108-273-080 0E C-RES,U 27K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0063 88-108-273-080 0E C-RES,U 27K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0063 88-108-273-080 0E C-RES,U 27K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0064 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0064 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0065 88-108-123-080 0E C-RES,U 12K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0065 88-108-123-080 0E C-RES,U 12K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0066 88-108-104-080 0E C-RES,U 100K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0066 88-108-104-080 0E C-RES,U 100K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0067 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0067 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0068 88-108-224-080 0E C-RES,U 220K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0068 88-108-224-080 0E C-RES,U 220K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0069 88-108-224-080 0E C-RES,U 220K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0069 88-108-224-080 0E C-RES,U 220K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0070 88-108-102-080 0E C-RES,U 1K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0070 88-108-102-080 0E C-RES,U 1K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0071 88-108-473-080 0E C-RES,U 47K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0071 88-108-473-080 0E C-RES,U 47K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0072 88-108-473-080 0E C-RES,U 47K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0072 88-108-473-080 0E C-RES,U 47K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0073 88-128-560-080 0E C-RES, 56-1/8 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0073 88-128-560-080 0E C-RES, 56-1/8 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0074 88-128-680-080 0E C-RES, 68-1/8 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0074 88-128-680-080 0E C-RES, 68-1/8 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0076 88-108-562-080 0E C-RES,U 5.6K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0076 88-108-562-080 0E C-RES,U 5.6K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0078 88-108-393-080 0E C-RES,U 39K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0078 88-108-393-080 0E C-RES,U 39K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0079 88-108-393-080 0E C-RES,U 39K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0079 88-108-393-080 0E C-RES,U 39K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0081 88-108-101-080 0E C-RES,U 100-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0081 88-108-101-080 0E C-RES,U 100-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0085 88-108-103-080 0E C-RES,U 10K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0085 88-108-103-080 0E C-RES,U 10K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0086 88-108-474-080 0E C-RES,U 470K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0086 88-108-474-080 0E C-RES,U 470K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0093 88-108-683-080 0E C-RES,U 68K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0093 88-108-683-080 0E C-RES,U 68K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0094 88-108-393-080 0E C-RES,U 39K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0094 88-108-393-080 0E C-RES,U 39K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0095 88-108-393-080 0E C-RES,U 39K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0095 88-108-393-080 0E C-RES,U 39K-1/16 J HTSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0096 88-108-683-080 0E C-RES,U 68K-1/16 J HSSM CX-NSZ300
X P-SUPPLY/P B/FAN R 0096 88-108-683-080 0E C-RES,U 68K-1/16 J HTSM CX-NSZ300
! O P-SUPPLY/P B/FAN H 0001 87-A90-510-010 0E HLDR, IRE 2.5-9P HSSM CX-NSZ300
www.rtv-horvat-dj.hr
20
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
! O P-SUPPLY/P B/FAN H 0001 87-A90-510-010 0E HLDR, IRE 2.5-9P HTSM CX-NSZ300
X PACKING 86-NFA-860-010 0E PAD,BOX HSSM CX-NSZ300
X PACKING 86-NFA-860-010 0E PAD,BOX HTSM CX-NSZ300
X PACKING 87-B40-098-010 0E BAG,PV 0.025-650-750 PL HSSM CX-NSZ300
X PACKING 87-B40-098-010 0E BAG,PV 0.025-650-750 PL HTSM CX-NSZ300
X PACKING 8B-NF9-859-010 1A CUSHION,FRONT USM HSSM CX-NSZ300
X PACKING 8B-NF9-859-010 1A CUSHION,FRONT USM HTSM CX-NSZ300
X PACKING 8B-NF9-860-010 1A CUSHION,REAR USM HSSM CX-NSZ300
X PACKING 8B-NF9-860-010 1A CUSHION,REAR USM HTSM CX-NSZ300
X PACKING 8B-NF9-881-010 -- CTN,PRINTED HTSM HTSM CX-NSZ300
X PACKING 8B-NF9-882-010 -- CTN,PRINTED HSSM HSSM CX-NSZ300
X PACKING 93-704-337-010 1A SH,FOAMED-MAT 0.31-800-500 HSSM CX-NSZ300
X PACKING 93-704-337-010 1A SH,FOAMED-MAT 0.31-800-500 HTSM CX-NSZ300
X PLATE 84-426-949-010 0E LBL,SERIAL NO HSSM CX-NSZ300
! X PLATE 87-057-961-010 0E LBL,CAUTION TRIANGLE HSSM CX-NSZ300
! X PLATE 87-057-961-010 0E LBL,CAUTION TRIANGLE HTSM CX-NSZ300
! X PLATE 87-057-995-010 0E LBL,CAUTION EFSD HSSM CX-NSZ300
! X PLATE 87-057-995-010 0E LBL,CAUTION EFSD HTSM CX-NSZ300
X PLATE 87-B40-281-010 0E LBL,BAR-CODE A 35X8 HSSM CX-NSZ300
X PLATE 87-B40-281-010 0E LBL,BAR-CODE A 35X8 HTSM CX-NSZ300
O PLATE 8B-NF9-008-010 0E INDO ,CASS 1 HSSM CX-NSZ300
O PLATE 8B-NF9-008-010 0E INDO ,CASS 1 HTSM CX-NSZ300
O PLATE 8B-NF9-009-010 0E INDO ,CASS 2 HSSM CX-NSZ300
O PLATE 8B-NF9-009-010 0E INDO ,CASS 2 HTSM CX-NSZ300
O PLATE 8B-NF9-021-010 0E REFLECTOR,ECO HSSM CX-NSZ300
O PLATE 8B-NF9-021-010 0E REFLECTOR,ECO HTSM CX-NSZ300
X PLATE 8B-NF9-023-010 -- PLATE,MIC HSSM CX-NSZ300
X PLATE 8B-NF9-023-010 -- PLATE,MIC HTSM CX-NSZ300
X PLATE 8B-NF9-028-010 -- LBL,SAFETY HT HTSM CX-NSZ300
O PLATE 8B-NF9-035-010 1A INDO ,DISP H HSSM CX-NSZ300
O PLATE 8B-NF9-035-010 1A INDO ,DISP H HTSM CX-NSZ300
X PLATE 8B-NF9-040-010 -- LBL,SPEC HSSM HSSM CX-NSZ300
O PO ER AMP C 0101 87-012-278-080 0E C-CAP,U 2200P-50 K B HSSM CX-NSZ300
O PO ER AMP C 0101 87-012-278-080 0E C-CAP,U 2200P-50 K B HTSM CX-NSZ300
O PO ER AMP C 0102 87-012-278-080 0E C-CAP,U 2200P-50 K B HSSM CX-NSZ300
O PO ER AMP C 0102 87-012-278-080 0E C-CAP,U 2200P-50 K B HTSM CX-NSZ300
O PO ER AMP C 0103 87-A12-084-080 0E CAP,E 0.22-50 SMG HSSM CX-NSZ300
O PO ER AMP C 0103 87-A12-084-080 0E CAP,E 0.22-50 SMG HTSM CX-NSZ300
O PO ER AMP C 0104 87-A12-084-080 0E CAP,E 0.22-50 SMG HSSM CX-NSZ300
O PO ER AMP C 0104 87-A12-084-080 0E CAP,E 0.22-50 SMG HTSM CX-NSZ300
O PO ER AMP C 0105 87-012-277-080 0E C-CAP,U 1800P-50 K B GRM HSSM CX-NSZ300
O PO ER AMP C 0105 87-012-277-080 0E C-CAP,U 1800P-50 K B GRM HTSM CX-NSZ300
O PO ER AMP C 0106 87-012-277-080 0E C-CAP,U 1800P-50 K B GRM HSSM CX-NSZ300
O PO ER AMP C 0106 87-012-277-080 0E C-CAP,U 1800P-50 K B GRM HTSM CX-NSZ300
O PO ER AMP C 0107 87-A12-089-080 0E CAP,E 3.3-50 SMG HSSM CX-NSZ300
O PO ER AMP C 0107 87-A12-089-080 0E CAP,E 3.3-50 SMG HTSM CX-NSZ300
O PO ER AMP C 0108 87-A12-089-080 0E CAP,E 3.3-50 SMG HSSM CX-NSZ300
O PO ER AMP C 0108 87-A12-089-080 0E CAP,E 3.3-50 SMG HTSM CX-NSZ300
O PO ER AMP C 0111 87-A12-077-080 0E CAP,E 33-35 SMG HSSM CX-NSZ300
O PO ER AMP C 0111 87-A12-077-080 0E CAP,E 33-35 SMG HTSM CX-NSZ300
O PO ER AMP C 0112 87-A12-077-080 0E CAP,E 33-35 SMG HSSM CX-NSZ300
O PO ER AMP C 0112 87-A12-077-080 0E CAP,E 33-35 SMG HTSM CX-NSZ300
O PO ER AMP C 0113 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O PO ER AMP C 0113 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O PO ER AMP C 0114 87-012-195-080 0E C-CAP,U 100P-50 J CH HSSM CX-NSZ300
O PO ER AMP C 0114 87-012-195-080 0E C-CAP,U 100P-50 J CH HTSM CX-NSZ300
O PO ER AMP C 0117 87-012-368-080 0E C-CAP,S 0.1-50 Z F HSSM CX-NSZ300
O PO ER AMP C 0117 87-012-368-080 0E C-CAP,S 0.1-50 Z F HTSM CX-NSZ300
O PO ER AMP C 0118 87-012-368-080 0E C-CAP,S 0.1-50 Z F HSSM CX-NSZ300
O PO ER AMP C 0118 87-012-368-080 0E C-CAP,S 0.1-50 Z F HTSM CX-NSZ300
O PO ER AMP C 0119 87-012-286-080 0E C-CAP,U 0.01-25 K B HSSM CX-NSZ300
O PO ER AMP C 0119 87-012-286-080 0E C-CAP,U 0.01-25 K B HTSM CX-NSZ300
O PO ER AMP C 0120 87-012-286-080 0E C-CAP,U 0.01-25 K B HSSM CX-NSZ300
O PO ER AMP C 0120 87-012-286-080 0E C-CAP,U 0.01-25 K B HTSM CX-NSZ300
O PO ER AMP C 0123 87-010-177-080 0E C-CAP,S 820P-50 J SL C2012 HSSM CX-NSZ300
O PO ER AMP C 0123 87-010-177-080 0E C-CAP,S 820P-50 J SL C2012 HTSM CX-NSZ300
O PO ER AMP C 0124 87-010-177-080 0E C-CAP,S 820P-50 J SL C2012 HSSM CX-NSZ300
O PO ER AMP C 0124 87-010-177-080 0E C-CAP,S 820P-50 J SL C2012 HTSM CX-NSZ300
O PO ER AMP C 0133 87-012-282-080 0E C-CAP,U 4700P-50 K B HSSM CX-NSZ300
O PO ER AMP C 0133 87-012-282-080 0E C-CAP,U 4700P-50 K B HTSM CX-NSZ300
www.rtv-horvat-dj.hr
Other Aiwa Stereo System manuals
