SERVICE MANUAL
DATA
BASIC TAPE MECHANISM : TN-21ZSC-2003
BASIC CD MECHANISM : DA11T3C
COMPACT DISC STEREO
SYSTEM
LCX-157
S/M Code No. 09-003-340-1N1
HS(S)
MODEL CODE : 86HR8-0117(B)

2
SPECIFICATIONS
•
Design and specifications are subject to change without
notice.

3
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
VAROITUS!
Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa mainit-
ulla tavalla saattaa altistaa käyt-täjän turvallisuusluokan 1 ylit-
tävälle näkymättömälle lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än vad som specificeras i
denna bruksanvising, kan användaren utsättas för osynling
laserstrålning, som överskrider gränsen för laserklass 1.
Caution: Invisible laser radiation when
open and interlocks defeated avoid expo-
sure to beam.
Advarsel:Usynling laserståling ved åbning,
når sikkerhedsafbrydere er ude af funktion.
Undgå udsættelse for stråling.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
ATTENTION
L'utilisation de commandes, réglages ou procédures autres que
ceux spécifiés peut entraîner une dangereuse exposition aux
radiations.
ADVARSEL!
Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude
af funktion. Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1 LASER
product.
The CLASS 1 LASER PRODUCT label is located on the rear
exterior.
This set employs laser. Therefore, be sure to follow carefully the
instructions below when servicing.
WARNING!
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT
WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO
CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE
FROM A DISTANCE OF MORE THAN 30cm FROM THE
SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL
PICK-UP BLOCK.
CLASS 1
KLASSE 1
LUOKAN 1
KLASS 1
LASER PRODUCT
LASER PRODUKT
LASER LAITE
LASER APPARAT
Precaution to replace Optical block
(SF-P101NR)
1) After the connection, remove solder shown in
the right figure.
Body or clothes electrostatic potential could ruin
laser diode in the optical block. Be sure ground
body and workbench, and use care the clothes
do not touch the diode.
Solder
PICK-UP Assy P.C.B

4
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ELECTRICAL MAIN PARTS LIST
IC
87-A20-734-010 IC,TDA2007A
87-A21-443-040 C-IC,M62495AFP
8A-CLB-602-010 IC,LC867240A-5P15
87-A21-245-010 IC,RPM6938-V4
87-A21-145-040 C-IC,BA4560F-E2
87-A20-446-010 C-IC,LA9241ML
87-A20-459-010 C-IC,LC78622ED
87-A21-093-010 IC,LA6541D
87-070-127-110 IC,LC72131 D
87-A20-913-010 IC,LA1837NL
87-A20-440-040 C-IC,BU1920FS
TRANSISTOR
87-026-610-080 TR,KTC3198GR
89-213-702-010 TR,2SB1370 (1.8W)
87-A30-185-010 TR,2SD1381FQR
87-026-313-080 TR,DTC343TS
87-026-609-080 TR,KTA1266GR
87-026-218-080 TR,DTC144ES (0.2W)
87-026-237-080 CHIP-TR,DTC124XK
87-026-223-080 TR,DTC143TK
89-320-011-080 TR,2SC2001 (15W)
87-CD7-603-080 TR,SS8050
89-318-154-080 TR,2SC1815 (0.4W)
87-026-291-080 TR,DTC124XS
89-112-965-080 TR,2SA1296 (0.75W)
87-026-463-080 TR,2SA933S (0.3W)
87-026-239-080 TR,DTC114TK (0.2W)
87-A30-227-080 TR,2SB1010Q
87-026-210-080 CHIP-TR,DTC144EK
87-A30-196-080 TR,2SC4115SRS
89-327-143-080 TR,2SC2714 (0.1W)
87-A30-072-080 C-TR,RT1P 144C
87-A30-076-080 C-TR,2SC3052F
89-505-434-540 C-FET,2SK543(4/5)
87-A30-257-080 C-TR,2SD1306E
87-A30-074-080 C-TR,RT1P 141C
DIODE
87-020-465-080 DIODE,1SS133 (110MA)
87-A40-393-090 DIODE,1N5402GW(F20)
87-070-334-080 ZENER,MTZJ10B
87-017-932-080 ZENER,MTJ6.2B
87-A40-347-080 ZENER,MTZJ2.2B
87-070-136-080 ZENER,MTZJ5.1B
87-020-027-080 CHIP-DIODE 1SS184
87-027-825-080 ZENER,HZ9A3L
87-A40-291-080 DIODE,1N4148 (CPT)
87-017-978-080 DIODE,1N4003
87-A40-234-080 ZENER,MTZJ5.6A
87-A40-270-080 C-DIODE,MC2838
MAIN C.B
C30 87-010-544-080 CAP, ELECT 0.1-50V
C101 87-010-190-080 S CHIP F 0.01
C102 87-010-190-080 S CHIP F 0.01
C103 87-010-190-080 S CHIP F 0.01
C104 87-010-404-080 CAP, ELECT 4.7-50V
C105 87-010-403-080 CAP, ELECT 3.3-50V
C106 87-010-192-080 C-CAP,S 0.022-50 F
C107 87-010-192-080 C-CAP,S 0.022-50 F
C108 87-010-192-080 C-CAP,S 0.022-50 F
C109 87-010-192-080 C-CAP,S 0.022-50 F
C110 87-010-190-080 S CHIP F 0.01
C111 87-016-658-090 CAP,E 4700-35 SMG
C112 87-012-140-080 CAP 470P
C113 87-010-190-080 S CHIP F 0.01
C114 87-010-190-080 S CHIP F 0.01
C115 87-010-112-080 CAP, ELECT 100-16V
C116 87-010-101-080 CAP, ELECT 220-16
C118 87-010-263-080 CAP, ELECT 100-10V
C119 87-010-190-080 S CHIP F 0.01
C120 87-010-401-080 CAP, ELECT 1-50V
C121 87-010-396-080 CAP,E 470-35 SME
C122 87-010-213-080 C-CAP,S 0.015-50 B
C123 87-010-196-080 CHIP CAPACITOR,0.1-25
C124 87-010-402-080 CAP, ELECT 2.2-50V
C126 87-010-408-080 CAP, ELECT 47-50V
C127 87-010-248-080 CAP, ELECT 220-10V
C128 87-010-393-080 CAP, ELECT 100-35V
C129 87-010-248-080 CAP, ELECT 220-10V
C130 87-010-393-080 CAP, ELECT 100-35V
C131 87-010-393-080 CAP, ELECT 100-35V
C132 87-010-237-080 CAP, ELECT 1000-16V
C136 87-010-197-080 CAP, CHIP 0.01 DM
C137 87-010-197-080 CAP, CHIP 0.01 DM
C138 87-010-197-080 CAP, CHIP 0.01 DM
C139 87-010-197-080 CAP, CHIP 0.01 DM
C143 87-010-401-080 CAP, ELECT 1-50V
C144 87-010-401-080 CAP, ELECT 1-50V
C147 87-010-190-080 S CHIP F 0.01
C150 87-010-263-080 CAP, ELECT 100-10V
C151 87-010-263-080 CAP, ELECT 100-10V
C152 87-010-182-080 C-CAP,S 2200P-50 B
C153 87-010-166-080 C-CAP,S 100P-50 SL
C154 87-010-545-080 CAP, ELECT 0.22-50V
C155 87-010-545-080 CAP, ELECT 0.22-50V
C157 87-010-404-080 CAP, ELECT 4.7-50V
C158 87-010-545-080 CAP, ELECT 0.22-50V
C159 87-010-545-080 CAP, ELECT 0.22-50V
C161 87-010-404-080 CAP, ELECT 4.7-50V
C162 87-010-405-080 CAP, ELECT 10-50V
C163 87-010-405-080 CAP, ELECT 10-50V
C164 87-010-405-080 CAP, ELECT 10-50V
C165 87-010-405-080 CAP, ELECT 10-50V
C166 87-010-404-080 CAP, ELECT 4.7-50V
C167 87-010-404-080 CAP, ELECT 4.7-50V
C169 87-010-197-080 CAP, CHIP 0.01 DM
C170 87-010-197-080 CAP, CHIP 0.01 DM
C171 87-010-404-080 CAP, ELECT 4.7-50V
C175 87-010-237-080 CAP, ELECT 1000-16V
C181 87-010-197-080 CAP, CHIP 0.01 DM
C182 87-010-197-080 CAP, CHIP 0.01 DM
C301 87-010-322-080 C-CAP,S 100P-50 CH
C302 87-015-951-080 CAP,E 1-50 LL
C304 87-010-406-080 CAP, ELECT 22-50
C306 87-010-405-080 CAP, ELECT 10-50V
C307 87-010-248-080 CAP, ELECT 220-10V
C308 87-010-405-080 CAP, ELECT 10-50V
C309 87-010-322-080 C-CAP,S 100P-50 CH
C311 87-010-406-080 CAP, ELECT 22-50
C312 87-015-951-080 CAP,E 1-50 LL
C314 87-010-426-080 C-CAP,S 0.012-25 B
C315 87-010-404-080 CAP, ELECT 4.7-50V
C316 87-010-404-080 CAP, ELECT 4.7-50V
C319 87-010-426-080 C-CAP,S 0.012-25 B
C320 87-010-197-080 CAP, CHIP 0.01 DM
C322 87-010-112-080 CAP, ELECT 100-16V
C325 87-010-178-080 CHIP CAP 1000P
C326 87-010-178-080 CHIP CAP 1000P
C327 87-010-178-080 CHIP CAP 1000P
C329 87-015-695-080 CAP,E 1-50 7L
C330 87-012-140-080 CAP 470P
C701 87-010-381-080 CAP, ELECT 330-16V
C702 87-010-404-080 CAP, ELECT 4.7-50V

5
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
C703 87-012-286-080 CAP, U 0.01-25
C704 87-012-286-080 CAP, U 0.01-25
C709 87-012-195-080 C-CAP,U 100P-50CH
C711 87-010-263-080 CAP, ELECT 100-10V
C712 87-010-196-080 CHIP CAPACITOR,0.1-25
C713 87-012-286-080 CAP, U 0.01-25
C714 87-012-286-080 CAP, U 0.01-25
C715 87-012-195-080 C-CAP,U 100P-50CH
C717 87-012-286-080 CAP, U 0.01-25
C719 87-012-286-080 CAP, U 0.01-25
C720 87-012-195-080 C-CAP,U 100P-50CH
C721 87-012-176-080 CAP 15P
C722 87-012-176-080 CAP 15P
C723 87-012-274-080 CHIP CAP,U 1000P-50B
C725 87-018-131-080 CAP, CER 1000P-50V
C727 87-010-196-080 CHIP CAPACITOR,0.1-25
C728 87-010-248-080 CAP, ELECT 220-10V
C729 87-012-274-080 CHIP CAP,U 1000P-50B
C731 87-012-286-080 CAP, U 0.01-25
C752 87-012-284-080 CAP, U 6800P-50
C753 87-012-195-080 C-CAP,U 100P-50CH
C755 87-012-286-080 CAP, U 0.01-25
C756 87-012-286-080 CAP, U 0.01-25
C757 87-012-188-080 C-CAP,U 47P-50 CH
C758 87-012-167-080 C-CAP,U 5P-50 CH
C761 87-010-196-080 CHIP CAPACITOR,0.1-25
C762 87-012-286-080 CAP, U 0.01-25
C763 87-010-829-080 CAP, U 0.047-16
C765 87-012-286-080 CAP, U 0.01-25
C766 87-010-197-080 CAP, CHIP 0.01 DM
C768 87-012-286-080 CAP, U 0.01-25
C769 87-010-260-080 CAP, ELECT 47-25V
C769 87-010-260-080 CAP, ELECT 47-25V
C770 87-010-829-080 CAP, U 0.047-16
C771 87-010-383-080 CAP, ELECT 33-25V
C772 87-010-829-080 CAP, U 0.047-16
C773 87-010-196-080 CHIP CAPACITOR,0.1-25
C774 87-010-263-080 CAP, ELECT 100-10V
C775 87-010-404-080 CAP, ELECT 4.7-50V
C776 87-012-286-080 CAP, U 0.01-25
C777 87-010-400-080 CAP, ELECT 0.47-50V
C778 87-010-401-080 CAP, ELECT 1-50V
C779 87-010-401-080 CAP, ELECT 1-50V
C780 87-010-196-080 CHIP CAPACITOR,0.1-25
C781 87-010-405-080 CAP, ELECT 10-50V
C782 87-010-405-080 CAP, ELECT 10-50V
C783 87-012-286-080 CAP, U 0.01-25
C784 87-012-286-080 CAP, U 0.01-25
C785 87-010-405-080 CAP, ELECT 10-50V
C786 87-010-405-080 CAP, ELECT 10-50V
C787 87-012-287-080 C-CAP,U 0.015-25 F
C788 87-012-287-080 C-CAP,U 0.015-25 F
C789 87-012-275-080 C-CAP,U 1200P-50 B
C790 87-012-275-080 C-CAP,U 1200P-50 B
C791 87-010-405-080 CAP, ELECT 10-50V
C793 87-012-275-080 C-CAP,U 1200P-50 B
C794 87-010-406-080 CAP, ELECT 22-50
C795 87-010-596-080 CAP, S 0.047-16
C796 87-010-403-080 CAP, ELECT 3.3-50V
C797 87-012-276-080 CAP, CHIP SS 1500 PBK
C798 87-012-276-080 CAP, CHIP SS 1500 PBK
C799 87-010-829-080 CAP, U 0.047-16
C803 87-018-047-080 CAP, CER 0.01-16V
C812 87-012-286-080 CAP, U 0.01-25
C814 87-012-286-080 CAP, U 0.01-25
C820 87-010-260-080 CAP, ELECT 47-25V
C821 87-012-286-080 CAP, U 0.01-25
C822 87-012-286-080 CAP, U 0.01-25
C823 87-012-286-080 CAP, U 0.01-25
C824 87-012-172-080 CAPACITOR CHIP U 10P CH
C828 87-010-196-080 CHIP CAPACITOR,0.1-25
C828 87-010-196-080 CHIP CAPACITOR,0.1-25
C829 87-010-196-080 CHIP CAPACITOR,0.1-25
C859 87-012-286-080 CAP, U 0.01-25
C861 87-012-199-080 CAP 220P
C862 87-012-199-080 CAP 220P
C864 87-010-405-080 CAP, ELECT 10-50V
C865 87-010-196-080 CHIP CAPACITOR,0.1-25
C866 87-010-405-080 CAP, ELECT 10-50V
C867 87-012-286-080 CAP, U 0.01-25
C868 87-012-184-080 C-CAP,U 33P-50 CH
C869 87-012-180-080 C-CAP,U 22P-50 CH
C909 87-012-286-080 CAP, U 0.01-25
C910 87-012-286-080 CAP, U 0.01-25
C940 87-012-286-080 CAP, U 0.01-25
C942 87-012-172-080 CAPACITOR CHIP U 10P CH
C947 87-012-286-080 CAP, U 0.01-25
C949 87-A10-039-080 C-CAP,U 470P-50 J CH
C952 87-012-286-080 CAP, U 0.01-25
C958 87-010-197-080 CAP, CHIP 0.01 DM
C959 87-010-831-080 C-CAP,U,0.1-16F
C960 87-010-196-080 CHIP CAPACITOR,0.1-25
C962 87-010-401-080 CAP, ELECT 1-50V
CF801 87-008-423-010 CERAMIC FILTER, SFE10.7
CF802 82-785-747-010 CF MS2 GHY R
CN301 87-009-036-010 CONNECTOR, 8P PH V WHT
! F101 87-035-457-010 FUSE,3.15A 250V TW/C
FC101 87-033-213-080 CLAMP, FUSE
FC102 87-033-213-080 CLAMP, FUSE
FFE801 A8-6ZA-19C-170 6ZA-1 YFEENC
J101 87-A60-354-010 JACK,PIN 2P MSP -242V-05
J102 87-A60-754-010 TERMINAL,SPK 4P MSP-154V-05
J103 87-A60-420-010 JACK,3.5 ST (MSC)
J104 87-099-608-010 JACK, DC HEC3800
J801 87-A60-880-010 TERMINAL,ANT-PAL 2P MSP-313V-0
L101 87-005-366-010 COIL, 1UH
L102 87-005-366-010 COIL, 1UH
L104 87-005-676-080 COIL,2.2UH K LF5.0S
L301 88-CL6-609-010 COIL,BIAS 8CL6
L771 87-A50-266-010 COIL,FM DET-2N(TOK)
L772 87-A90-733-010 FLTR,PCFAZH-450 (TOK)
L781 87-005-847-080 COIL,2.2UH(CECS)
L832 87-005-847-080 COIL,2.2UH(CECS)
L851 87-005-847-080 COIL,2.2UH(CECS)
L941 87-A50-020-010 COIL,ANT LW(COI)
L942 87-A50-019-010 COIL,OSC LW(COI)
L981 87-NF4-651-110 COIL,AM PACK2N(TOM)
! PR100 87-A90-091-080 PROTECTOR,2A 491
R118 87-029-118-090 RES,FUSE 220-1/2W J
SW301 8Z-CL8-668-010 SW,RP ZCL8
TC942 87-011-164-010 CAPACITOR,TRIMMER 30P
WH101 87-099-043-010 CONN 2P EH
X721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309
X851 87-A70-184-010 VIB,XTAL 4.332MHZ HC-49/U
FRONT C.B
C201 87-010-375-080 CAP,E 330-10 SME
C202 87-012-350-080 C-CAP,1-25 F
C203 87-010-197-080 CAP, CHIP 0.01 DM
C205 87-010-178-080 CHIP CAP 1000P
C208 87-010-197-080 CAP, CHIP 0.01 DM
C209 87-010-196-080 CHIP CAPACITOR,0.1-25
C210 87-010-196-080 CHIP CAPACITOR,0.1-25
C211 87-010-314-080 C-CAP,S 22P-50V
C212 87-010-318-080 C-CAP,S 47P-50 CH
C213 87-010-154-080 CAP CHIP 10P
C214 87-012-149-080 C-CAP,S 30P-50 CH
C215 87-010-312-080 C-CAP,S 15P-50 CH
C216 87-010-400-080 CAP, ELECT 0.47-50V

6
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
C217 87-010-196-080 CHIP CAPACITOR,0.1-25
CN201 87-099-720-010 CONN,30P TYK-B(P)
CN202 87-A60-404-010 CONN,3P TKX-P03P-F1
L206 87-003-098-080 COIL,2.2UH
LCD201 8Z-CL8-665-110 LCD,ZCL-8
S200 87-A90-095-080 SW,TACT EVQ11G04M
S201 87-A90-095-080 SW,TACT EVQ11G04M
S202 87-A90-095-080 SW,TACT EVQ11G04M
S203 87-A90-095-080 SW,TACT EVQ11G04M
S205 87-A90-095-080 SW,TACT EVQ11G04M
S207 87-A90-095-080 SW,TACT EVQ11G04M
S208 87-A90-095-080 SW,TACT EVQ11G04M
S213 87-A90-095-080 SW,TACT EVQ11G04M
S214 87-A90-095-080 SW,TACT EVQ11G04M
S216 87-A90-095-080 SW,TACT EVQ11G04M
S217 87-A90-095-080 SW,TACT EVQ11G04M
S218 87-A90-095-080 SW,TACT EVQ11G04M
S220 87-A90-095-080 SW,TACT EVQ11G04M
SW221 87-A90-095-080 SW,TACT EVQ11G04M
X201 87-030-364-010 VIB,XTAL 32.768K CT
X202 87-A70-185-080 VIB,CER 5.76MHZ TF21
CD C.B
C500 87-016-459-040 CAP,E 470-10 SMG
C502 87-016-459-040 CAP,E 470-10 SMG
C503 87-016-459-040 CAP,E 470-10 SMG
C505 87-010-196-080 CHIP CAPACITOR,0.1-25
C507 87-010-196-080 CHIP CAPACITOR,0.1-25
C513 87-010-196-080 CHIP CAPACITOR,0.1-25
C514 87-010-196-080 CHIP CAPACITOR,0.1-25
C515 87-012-157-080 C-CAP,S 330P-50 CH
C516 87-010-545-080 CAP, ELECT 0.22-50V
C521 87-010-186-080 CAP,CHIP 4700P
C525 87-010-176-080 C-CAP,S 680P-50 SL
C528 87-012-156-080 C-CAP,S 220P-50 CH
C529 87-010-545-080 CAP, ELECT 0.22-50V
C530 87-012-140-080 CAP 470P
C531 87-010-374-080 CAP, ELECT 47-10V
C532 87-010-401-080 CAP, ELECT 1-50V
C533 87-010-184-080 CHIP CAPACITOR 3300P(K)
C534 87-010-197-080 CAP, CHIP 0.01 DM
C535 87-010-145-080 C-CAP,S 1P-50 CH
C536 87-010-312-080 C-CAP,S 15P-50 CH
C537 87-010-309-080 C-CAP,1000P-50 CH
C538 87-010-196-080 CHIP CAPACITOR,0.1-25
C539 87-010-404-080 CAP, ELECT 4.7-50V
C540 87-010-196-080 CHIP CAPACITOR,0.1-25
C541 87-010-405-080 CAP, ELECT 10-50V
C542 87-010-369-080 C-CAP,S 0.033-25 K B
C543 87-010-401-080 CAP, ELECT 1-50V
C545 87-010-197-080 CAP, CHIP 0.01 DM
C546 87-010-374-080 CAP, ELECT 47-10V
C547 87-010-263-080 CAP, ELECT 100-10V
C548 87-010-248-080 CAP, ELECT 220-10V
C549 87-010-198-080 CAP, CHIP 0.022
C550 87-010-248-080 CAP, ELECT 220-10V
C551 87-010-178-080 CHIP CAP 1000P
C552 87-010-197-080 CAP, CHIP 0.01 DM
C553 87-010-374-080 CAP, ELECT 47-10V
C555 87-010-403-080 CAP, ELECT 3.3-50V
C556 87-010-197-080 CAP, CHIP 0.01 DM
C559 87-010-315-080 C-CAP,S 27P-50 CH
C560 87-010-263-080 CAP, ELECT 100-10V
C561 87-010-196-080 CHIP CAPACITOR,0.1-25
C562 87-010-196-080 CHIP CAPACITOR,0.1-25
C563 87-012-156-080 C-CAP,S 220P-50 CH
C564 87-010-197-080 CAP, CHIP 0.01 DM
C565 87-010-263-080 CAP, ELECT 100-10V
C566 87-010-196-080 CHIP CAPACITOR,0.1-25
C568 87-010-197-080 CAP, CHIP 0.01 DM
C571 87-010-248-080 CAP, ELECT 220-10V
C572 87-010-196-080 CHIP CAPACITOR,0.1-25
C573 87-010-197-080 CAP, CHIP 0.01 DM
C578 87-010-197-080 CAP, CHIP 0.01 DM
C579 87-010-263-080 CAP, ELECT 100-10V
C582 87-010-197-080 CAP, CHIP 0.01 DM
C583 87-010-405-080 CAP, ELECT 10-50V
C587 87-010-166-080 C-CAP,S 100P-50 SL
C589 87-010-166-080 C-CAP,S 100P-50 SL
C590 87-010-166-080 C-CAP,S 100P-50 SL
C591 87-010-166-080 C-CAP,S 100P-50 SL
C592 87-010-166-080 C-CAP,S 100P-50 SL
C593 87-010-197-080 CAP, CHIP 0.01 DM
C594 87-010-263-080 CAP, ELECT 100-10V
C596 87-010-404-080 CAP, ELECT 4.7-50V
C598 87-010-197-080 CAP, CHIP 0.01 DM
CN501 87-009-345-010 CONN,2P PH H
CN510 87-009-034-010 CONN,6P PH V
CN520 87-A60-248-010 CONN,16P H CFF1416
L501 87-005-647-080 COIL,10UH K LF5S
L502 87-005-659-080 COIL,100UH K LF5.0S
R503 87-029-019-010 RES, FUSEIBLE 1/2W-2.2
SFR501 87-A90-787-080 SFR,100K H HOKU
X501 87-A70-046-010 VIB,XTAL 16.934MHZ
LED C.B
D941 87-A40-365-080 LED,L-1154 SGD
D942 87-A40-365-080 LED,L-1154 SGD
D943 87-A40-365-080 LED,L-1154 SGD
D944 87-A40-365-080 LED,L-1154 SGD
D945 87-A40-365-080 LED,L-1154 SGD
D946 87-A40-365-080 LED,L-1154 SGD
D947 87-A40-365-080 LED,L-1154 SGD
D948 87-A40-365-080 LED,L-1154 SGD
D949 87-A40-365-080 LED,L-1154 SGD
AC C.B
C181 87-010-197-080 CAP, CHIP 0.01 DM
C182 87-010-197-080 CAP, CHIP 0.01 DM
CNA101 8A-CLA-630-010 CONN ASSY,2P PT
! T1 87-A60-317-010 TERMINAL, 1P MSC
! T2 87-A60-317-010 TERMINAL, 1P MSC
MOTOR C.B
M2 9X-262-576-910 MOTOR GEAR ASSY
PIN3 91-564-722-110 CONNECTOR 6P
SW1 91-572-085-120 LEAF SW

87
TRANSISTOR ILLUSTRATION
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ 1.0 0.5 0.35 104
Lt
W
2SA1296
2SC1815
KTC3198
2SC2714
2SD1306
DTC114TK
DTC143TK
DTC144EK
RT1P141C
PT1P144C
2SC4115
DTC124XS
DTC343TS
2SA933
2SB1010
2SC2001
SS8050
2SD1381
BE
C
ECB ECB ECB ECB D
S
G
2SK543
• Regarding connectors, they are not stocked as they are not the initial order items.
The connectors are available after they are supplied from connector manufacturers upon the order is received.
ANODE CONNECTION
FL (13-ST-36GNAK) GRID ASSIGNMENT/ANODE CONNECTION
GRID ASSIGNMENT

12345678910 11 12 13 14
A
B
C
D
E
F
G
H
I
J
K
109
WIRING-1 (MAIN)

1211
IC BLOCK DIAGRAM
IC, M62495AFP
IC, LA1837NL
IC, LA6541D
IC, LC72131D
IC, BU1920FS

1413
SCHEMATIC DIAGRAM-1 (MAIN 1/2)
TO FRONT C.B CN201
TO MAIN C.B 2/2
MAIN C.B
(1/2)
AC C.B
(1/2)
AC C.B(2/2)
R
SIGNAL
: PB/FM
: REC/AM
J105
INV.
IC301
CASSETTE
PER AMP
BIAS OSC
BEAT CUT
REG
REG
REG
REG
REG
SW
C121
137 MODEL:330/25V
157 MODEL:470/35V
HOLD DET HOLD DET
POWER AMP
IC102
FUNCTION
SWITCH
POWER
CONT
POWER
ON/OFF
J101
JACK. PIN 3P MSP
J101
JACK. 3.5 ST
PHONES
SPEAKERS
F101
3.15A 250V
230V
50Hz
1.8k
1.8k

1615
SCHEMATIC DIAGRAM-2 (MAIN 2/2)
TO MAIN C.B (1/2)
MAIN C.B (2/2)
R
R
FM IF
LW ANT SW
MW/LW SW
AM RF AMP
LW OSC SW
AM IF ADJ
DC BALANCE
ADJ
IC771
FM/AM IF/STEREO
TUNER SYSTEM
SIGNAL
: PB/FM
: REC/AM
BAND
SW
D942
D944
L773
2.2µH
TUNER
ON//OFF
SWITCH
0.015
0.015
BEAT
VM
+5V
ROCL
RODA
SIG
FM 75Ω
MW/LW
LOOP
J801
ANTENNA
1SS133
D5
R822 10K

12345678910 11 12 13 14
A
B
C
D
E
F
G
H
I
J
K
1817
WIRING-2 (CD/FRONT: INSERTED PARTS)

12345678910 11 12 13 14
A
B
C
D
E
F
G
H
I
J
K
2019
WIRING-3 (CD/FRONT: CHIP PARTS)

2221
SCHEMATIC DIAGRAM-3 (FRONT)
IRDDT
IR200

2423
SCHEMATIC DIAGRAM-4 (CD)

2625
VOLTAGE CHART

2827

3029
ELECTRICAL ADJUSTMENT

31
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16, 17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36-38
39-55
56
57
58-79
80
81
IC, LC867240A-5P15
IC DESCRIPTION
O-SCONTM
O-SCONTL
O-DATA
___________
I-TUNE/IFC
O-TUCL
O-COIN
I-SQOUT
___________
O-CQCK
O-RWC
_______________
O-CLKSFT
I-TMBASE
____________
I-RESET
XT1
XT2
VSS1
CF1, CF2
VDD1
I-KEY0
I-KEY1
I-RDSIG
I-WRQ
I-DRF
I-DOOR
I-PUIN
I-SWTAPE
________________
I-STEREO
I-RDCL
________
I-REM
___________
I-HOLD
I-RDDT
I-TPREC
I-TPPLAY
O-MOTOR
O-PL
O-NC
S9-S25
VDD2
VSS2
S26-S47
I-CLKDSP
I-AS
O
O
O
I
O
O
I
O
O
O
I
I
I
O
—
I/O
—
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
O
O
O
O
—
—
O
I
I
M62439SP control. open drain output.
Tuner control. CMOS output.
Tuner control.
Tuner control. CMOS output.
CD control. open drain output.
CD control.
CD control. open drain output.
Clock shift output. “L” during shift. open drain output.
8 Hz time base input.
Reset input.
Input pin.
Output pin for 32.768kHz crystal oscillation.
GND.
Main clock input/output 5.76 MHz.
+5V.
KEY0 A/D input.
KEY1 A/D input.
RDS signal level input. (A/D input)
CD control.
CD door SW detection SW input. “L” at CLOSE.
CD pick-up detection SW input. “L” at ON.
Tape detection SW input. (A/D input)
Monaural/stereo indication selector input. “L” at stereo.
RDS clock input.
Remote control input. (fall-down edge interrupt input)
Hold mode detection. “L” at hold mode.
RDS data input.
Tape REC detection input. “H” at REC.
Tape PLAY detection input. “H” at PLAY.
Mechanism deck motor ON/OFF output. “H” at ON. CMOS output.
Mechanism deck plunger solenoid ON/OFF output. “H” at ON. CMOS output .
Not used.
LCD SEG terminal Initial setting output. (S10 to S16)
+5V.
GND.
LCD SEG terminal .
Watch indication select input “L”: 12H. “H”: 24H.
Auto stop. counter input .
Pin No. Pin Name I/O Description

32
__________
I-STOP
COM0-COM3
I-INIT
______
I-AC/DC
VSS3
VDD3
O-NC
O-TUCE
O-CD-ON
_____________
O-TU-ON
__________
O-RMT
________ _____
O-REC/PB
O-MUTE
O-PCONT
__________
O-BIAS
O-NC
Pin No. Pin Name I/O Description
82
83-86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
I
O
I
O
—
—
O
O
O
O
O
O
O
O
O
O
Tape stop input.
LCD common output.
Initial setting input.
Beat selector output. “H” during selection. CMOS output .
GND.
5V.
Not used.
Tuner chip enable output. CMOS output .
“H” output during CD function. CMOS output.
“H” output during TU function. Open drain output.
REC mute output. “H” during mute. Open drain output.
REC/PB select output. “H” during PB. Open drain output.
Mute output. “H” during mute. Open drain output.
Power control output. “H” at ON. CMOS output.
REC bias ON/OFF output. “H” at ON. Open drain output.
Not used.
