Aiwa Z-L720 User manual

SERVICE MANUAL
DATA
Z-L720
Z-L820
U
LH
SIMPLE
S/M Code No. 09-011-440-1T1
• Replace this Service manual with “Revision Publishing” when it is issued.
COMPACT DISC STEREO SYSTEM BASIC TAPE MECHANISM: ZZM-3 PR1NM
BASIC CD MECHANISM: 6ZG-1 ZZRNIM

 2 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O ACCESSORY 87-006-268-010 1C ANT,LOOP AM USM CX-ZL720
O ACCESSORY 87-006-268-010 1C ANT,LOOP AM LHSM CX-ZL820
O ACCESSORY 87-043-115-010 1A FEEDER-ANT,FM USM CX-ZL720
O ACCESSORY 87-043-115-010 1A FEEDER-ANT,FM LHSM CX-ZL820
! O ACCESSORY 87-0 -78 -010 1B PLUG,CONVERSION IR44 LHSM CX-ZL820
O ACCESSORY 8Z-NF -702-010 1H RC UNIT,ZAS02 USM CX-ZL720
O ACCESSORY 8Z-NF -702-010 1H RC UNIT,ZAS02 LHSM CX-ZL820
! O APPEARANCE 87-B00-002-010 0E BADGE,AIWA 30 ABS SIL USM CX-ZL720
! O APPEARANCE 87-B00-002-010 0E BADGE,AIWA 30 ABS SIL LHSM CX-ZL820
O APPEARANCE 8B-MA3-025-010 -- BOX,CASS L A3 USM CX-ZL720
O APPEARANCE 8B-MA3-025-010 -- BOX,CASS L A3 LHSM CX-ZL820
O APPEARANCE 8B-MA3-026-010 -- BOX,CASS R A3 USM CX-ZL720
O APPEARANCE 8B-MA3-026-010 -- BOX,CASS R A3 LHSM CX-ZL820
O APPEARANCE 8B-MA3-047-010 -- PANEL,SIDE L (U) USM CX-ZL720
O APPEARANCE 8B-MA3-047-010 -- PANEL,SIDE L (U) LHSM CX-ZL820
O APPEARANCE 8B-MA3-048-010 -- PANEL,SIDE R (U) USM CX-ZL720
O APPEARANCE 8B-MA3-048-010 -- PANEL,SIDE R (U) LHSM CX-ZL820
O APPEARANCE * 8B-MA3-001-010 -- CABI,FR U A3 USM CX-ZL720
O APPEARANCE * 8B-MA3-001-010 -- CABI,FR U A3 LHSM CX-ZL820
O APPEARANCE * 8B-MA3-010-010 -- CABI,REAR U A3 USM CX-ZL720
O APPEARANCE * 8B-MA3-011-010 -- CABI,REAR LH A3 LHSM CX-ZL820
O APPEARANCE * 8B-MA3-021-010 -- CABI,TOP U USM CX-ZL720
O APPEARANCE * 8B-MA3-021-010 -- CABI,TOP U LHSM CX-ZL820
X CD M8-6ZG-18 -030 -- 6ZG-1 ZZRNIM USM CX-ZL720
X CD M8-6ZG-18 -030 -- 6ZG-1 ZZRNIM LHSM CX-ZL820
O CNTL C 0651 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-ZL720
O CNTL C 0651 87-012-274-080 0E C-CAP,U 1000P-50 K B LHSM CX-ZL820
O CNTL C 0652 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-ZL720
O CNTL C 0652 87-012-274-080 0E C-CAP,U 1000P-50 K B LHSM CX-ZL820
O CNTL LED0682 87-A41-056-040 0E LED,HLMF-D405 ORANGE USM CX-ZL720
O CNTL LED0682 87-A41-056-040 0E LED,HLMF-D405 ORANGE LHSM CX-ZL820
O CNTL LED0683 87-A41-056-040 0E LED,HLMF-D405 ORANGE USM CX-ZL720
O CNTL LED0683 87-A41-056-040 0E LED,HLMF-D405 ORANGE LHSM CX-ZL820
O CNTL LED0684 87-A41-056-040 0E LED,HLMF-D405 ORANGE USM CX-ZL720
O CNTL LED0684 87-A41-056-040 0E LED,HLMF-D405 ORANGE LHSM CX-ZL820
O CNTL LED0685 87-A41-056-040 0E LED,HLMF-D405 ORANGE USM CX-ZL720
O CNTL LED0685 87-A41-056-040 0E LED,HLMF-D405 ORANGE LHSM CX-ZL820
O CNTL LED06 8 87-A41-056-040 0E LED,HLMF-D405 ORANGE USM CX-ZL720
O CNTL LED06 8 87-A41-056-040 0E LED,HLMF-D405 ORANGE LHSM CX-ZL820
X CNTL R 0402 88-108-561-080 0E C-RES,U 560-1/16W J USM CX-ZL720
X CNTL R 0402 88-108-561-080 0E C-RES,U 560-1/16W J LHSM CX-ZL820
X CNTL R 0403 88-108-561-080 0E C-RES,U 560-1/16W J USM CX-ZL720
X CNTL R 0403 88-108-561-080 0E C-RES,U 560-1/16W J LHSM CX-ZL820
X CNTL R 0404 88-108-681-080 0E C-RES,U 680-1/16W J USM CX-ZL720
X CNTL R 0404 88-108-681-080 0E C-RES,U 680-1/16W J LHSM CX-ZL820
X CNTL R 0651 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X CNTL R 0651 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X CNTL R 0652 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-ZL720
X CNTL R 0652 88-108-183-080 0E C-RES,U 18K-1/16W J LHSM CX-ZL820
X CNTL R 0653 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X CNTL R 0653 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X CNTL R 0654 88-108-152-080 0E C-RES,U 1.5K-1/16W J USM CX-ZL720
X CNTL R 0654 88-108-152-080 0E C-RES,U 1.5K-1/16W J LHSM CX-ZL820
X CNTL R 0655 88-108-682-080 0E C-RES,U 6.8K-1/16W J USM CX-ZL720
X CNTL R 0655 88-108-682-080 0E C-RES,U 6.8K-1/16W J LHSM CX-ZL820
X CNTL R 0670 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X CNTL R 0670 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X CNTL R 0680 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X CNTL R 0680 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X CNTL R 0682 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X CNTL R 0682 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X CNTL R 0683 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X CNTL R 0683 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X CNTL R 0684 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X CNTL R 0684 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X CNTL R 0685 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X CNTL R 0685 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X CNTL R 0686 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X CNTL R 0686 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X CNTL R 0687 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720

 3 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X CNTL R 0687 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X CNTL R 0688 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X CNTL R 0688 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X CNTL R 068 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X CNTL R 068 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X CNTL R 0805 88-121-681-080 0E RES,680-1/8W J USM CX-ZL720
X CNTL R 0805 88-121-681-080 0E RES,680-1/8W J LHSM CX-ZL820
X CNTL R 0806 88-108-821-080 0E C-RES,U 820-1/16W J USM CX-ZL720
X CNTL R 0806 88-108-821-080 0E C-RES,U 820-1/16W J LHSM CX-ZL820
X CNTL R 0807 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X CNTL R 0807 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X CNTL R 0808 88-108-122-080 0E C-RES,U 1.2K-1/16W J USM CX-ZL720
X CNTL R 0808 88-108-122-080 0E C-RES,U 1.2K-1/16W J LHSM CX-ZL820
X CNTL R 080 88-108-152-080 0E C-RES,U 1.5K-1/16W J USM CX-ZL720
X CNTL R 080 88-108-152-080 0E C-RES,U 1.5K-1/16W J LHSM CX-ZL820
X CNTL R 0821 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-ZL720
X CNTL R 0821 88-108-103-080 0E C-RES,U 10K-1/16W J LHSM CX-ZL820
X CNTL R 0822 88-108-561-080 0E C-RES,U 560-1/16W J USM CX-ZL720
X CNTL R 0822 88-108-561-080 0E C-RES,U 560-1/16W J LHSM CX-ZL820
X CNTL R 0823 88-108-561-080 0E C-RES,U 560-1/16W J USM CX-ZL720
X CNTL R 0823 88-108-561-080 0E C-RES,U 560-1/16W J LHSM CX-ZL820
X CNTL R 0824 88-108-681-080 0E C-RES,U 680-1/16W J USM CX-ZL720
X CNTL R 0824 88-108-681-080 0E C-RES,U 680-1/16W J LHSM CX-ZL820
X CNTL R 0825 88-108-681-080 0E C-RES,U 680-1/16W J USM CX-ZL720
X CNTL R 0825 88-108-681-080 0E C-RES,U 680-1/16W J LHSM CX-ZL820
X CNTL R 0826 88-108-821-080 0E C-RES,U 820-1/16W J USM CX-ZL720
X CNTL R 0826 88-108-821-080 0E C-RES,U 820-1/16W J LHSM CX-ZL820
X CNTL R 0827 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X CNTL R 0827 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X CNTL R 0828 88-121-122-080 0E RES,1.2K-1/8W J USM CX-ZL720
X CNTL R 0828 88-121-122-080 0E RES,1.2K-1/8W J LHSM CX-ZL820
X CNTL R 082 88-121-152-080 0E RES,1.5K-1/8W J USM CX-ZL720
X CNTL R 082 88-121-152-080 0E RES,1.5K-1/8W J LHSM CX-ZL820
X CNTL R 0830 88-108-182-080 0E C-RES,U 1.8K-1/16W J USM CX-ZL720
X CNTL R 0830 88-108-182-080 0E C-RES,U 1.8K-1/16W J LHSM CX-ZL820
X CNTL R 0831 88-121-222-080 0E RES,2.2K-1/8W J USM CX-ZL720
X CNTL R 0831 88-121-222-080 0E RES,2.2K-1/8W J LHSM CX-ZL820
X CNTL R 0842 88-108-561-080 0E C-RES,U 560-1/16W J USM CX-ZL720
X CNTL R 0842 88-108-561-080 0E C-RES,U 560-1/16W J LHSM CX-ZL820
X CNTL R 0843 88-108-561-080 0E C-RES,U 560-1/16W J USM CX-ZL720
X CNTL R 0843 88-108-561-080 0E C-RES,U 560-1/16W J LHSM CX-ZL820
X CNTL R 0844 88-121-681-080 0E RES,680-1/8W J USM CX-ZL720
X CNTL R 0844 88-121-681-080 0E RES,680-1/8W J LHSM CX-ZL820
X CNTL R 0845 88-108-681-080 0E C-RES,U 680-1/16W J USM CX-ZL720
X CNTL R 0845 88-108-681-080 0E C-RES,U 680-1/16W J LHSM CX-ZL820
X CNTL R 0846 88-108-821-080 0E C-RES,U 820-1/16W J USM CX-ZL720
X CNTL R 0846 88-108-821-080 0E C-RES,U 820-1/16W J LHSM CX-ZL820
X CNTL R 0847 88-121-102-080 0E RES,1K-1/8W J USM CX-ZL720
X CNTL R 0847 88-121-102-080 0E RES,1K-1/8W J LHSM CX-ZL820
X CNTL R 0848 88-108-122-080 0E C-RES,U 1.2K-1/16W J USM CX-ZL720
X CNTL R 0848 88-108-122-080 0E C-RES,U 1.2K-1/16W J LHSM CX-ZL820
X CNTL R 084 88-121-152-080 0E RES,1.5K-1/8W J USM CX-ZL720
X CNTL R 084 88-121-152-080 0E RES,1.5K-1/8W J LHSM CX-ZL820
X CNTL R 0850 88-108-182-080 0E C-RES,U 1.8K-1/16W J USM CX-ZL720
X CNTL R 0850 88-108-182-080 0E C-RES,U 1.8K-1/16W J LHSM CX-ZL820
X CNTL R 0851 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-ZL720
X CNTL R 0851 88-108-222-080 0E C-RES,U 2.2K-1/16W J LHSM CX-ZL820
O CNTL S 0401 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0401 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0402 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0402 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0405 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0405 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0651 87-A 1-542-010 1A SW,RTRY EC12E12504 USM CX-ZL720
O CNTL S 0651 87-A 1-542-010 1A SW,RTRY EC12E12504 LHSM CX-ZL820
O CNTL S 0805 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0805 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0806 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0806 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0807 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720

 4 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O CNTL S 0807 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0808 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0808 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 080 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 080 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0821 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0821 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0822 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0822 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0823 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0823 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0825 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0825 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0826 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0826 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0827 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0827 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0828 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0828 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 082 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 082 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0830 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0830 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0831 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0831 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0842 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0842 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0843 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0843 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0844 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0844 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0845 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0845 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0846 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0846 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 084 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 084 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O CNTL S 0851 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O CNTL S 0851 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
! S ELECTRICAL 87-035-1 4-010 1A FUSE,6.3A 250V T 218 LHSM CX-ZL820
! S ELECTRICAL 87-035-4 3-010 0E FUSE,8A 125V T 237 USM CX-ZL720
! X ELECTRICAL 87-06 -033-010 0E CABLE,TIE USM CX-ZL720
! X ELECTRICAL 87-06 -033-010 0E CABLE,TIE LHSM CX-ZL820
! O ELECTRICAL 87-085-185-010 0E BUSHING,AC CORD(E) CM-22B LHSM CX-ZL820
! O ELECTRICAL 87-A80-148-010 1B AC CORD ASSY,E BLK LHSM CX-ZL820
! O ELECTRICAL 87-A80-14 -010 1B AC CORD ASSY,U BLK USM CX-ZL720
! O ELECTRICAL 87-A 1-422-010 1D BUSHING,AC CORD(U) USM CX-ZL720
O ELECTRICAL 87-A 1-736-010 1F FAN,DSB0812M-S382 -300MM USM CX-ZL720
O ELECTRICAL 87-A 1-736-010 1F FAN,DSB0812M-S382 -300MM LHSM CX-ZL820
X ELECTRICAL 88-100-000-010 0E PLATING-JW, 0.58 SN 5 USM CX-ZL720
X ELECTRICAL 88-100-000-010 0E PLATING-JW, 0.58 SN 5 LHSM CX-ZL820
O ELECTRICAL 88- 06-321-110 0E FF-CABLE, 6P 1.25 320MM USM CX-ZL720
O ELECTRICAL 88- 06-321-110 0E FF-CABLE, 6P 1.25 320MM LHSM CX-ZL820
O ELECTRICAL 88- 08-151-110 0E FF-CABLE,8P 1.25-150MM USM CX-ZL720
O ELECTRICAL 88- 08-151-110 0E FF-CABLE,8P 1.25-150MM LHSM CX-ZL820
O ELECTRICAL 88- 10-231-210 0E FF-CABLE,10P 1.25 230MM USM CX-ZL720
O ELECTRICAL 88- 10-231-210 0E FF-CABLE,10P 1.25 230MM LHSM CX-ZL820
O ELECTRICAL 88- 11-151-110 1A FF-CABLE,11P 1.25 150MM USM CX-ZL720
O ELECTRICAL 88- 11-151-110 1A FF-CABLE,11P 1.25 150MM LHSM CX-ZL820
X ELECTRICAL 8 -750-124-410 0E WIRE ASSY,120 LUG USM CX-ZL720
X ELECTRICAL 8 -750-124-410 0E WIRE ASSY,120 LUG LHSM CX-ZL820
X ELECTRICAL 8A-MA3-215-010 0E HT-SINK,IC USM CX-ZL720
X ELECTRICAL 8A-MA3-215-010 0E HT-SINK,IC LHSM CX-ZL820
O ELECTRICAL PT 0001 8B-MA3-661-010 -- PT,BMA-3 U USM CX-ZL720
O ELECTRICAL PT 0001 8B-MA3-663-010 -- PT,BMA-3 LH LHSM CX-ZL820
X FRONT JUMPER JR 00 8 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 00 8 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 00 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 00 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0100 88-108-000-080 0E C-JUMPER,U USM CX-ZL720

 5 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X FRONT JUMPER JR 0100 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0101 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 0101 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0102 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 0102 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0105 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 0105 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0107 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 0107 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0108 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 0108 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0112 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 0112 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0113 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 0113 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0121 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 0121 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0131 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 0131 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0132 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 0132 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0802 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 0802 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FRONT JUMPER JR 0803 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FRONT JUMPER JR 0803 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
O FUNC/E.VR C 0605 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM USM CX-ZL720
O FUNC/E.VR C 0605 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM LHSM CX-ZL820
O FUNC/E.VR C 0606 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM USM CX-ZL720
O FUNC/E.VR C 0606 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM LHSM CX-ZL820
O FUNC/E.VR C 060 87-012-287-080 0E C-CAP,U 0.015-25 Z F USM CX-ZL720
O FUNC/E.VR C 060 87-012-287-080 0E C-CAP,U 0.015-25 Z F LHSM CX-ZL820
O FUNC/E.VR C 0610 87-012-287-080 0E C-CAP,U 0.015-25 Z F USM CX-ZL720
O FUNC/E.VR C 0610 87-012-287-080 0E C-CAP,U 0.015-25 Z F LHSM CX-ZL820
O FUNC/E.VR C 0611 87-A12-084-080 0E CAP,E 0.22-50 SMG USM CX-ZL720
O FUNC/E.VR C 0611 87-A12-084-080 0E CAP,E 0.22-50 SMG LHSM CX-ZL820
O FUNC/E.VR C 0612 87-A12-084-080 0E CAP,E 0.22-50 SMG USM CX-ZL720
O FUNC/E.VR C 0612 87-A12-084-080 0E CAP,E 0.22-50 SMG LHSM CX-ZL820
O FUNC/E.VR C 0613 87-A12-084-080 0E CAP,E 0.22-50 SMG USM CX-ZL720
O FUNC/E.VR C 0613 87-A12-084-080 0E CAP,E 0.22-50 SMG LHSM CX-ZL820
O FUNC/E.VR C 0614 87-A12-084-080 0E CAP,E 0.22-50 SMG USM CX-ZL720
O FUNC/E.VR C 0614 87-A12-084-080 0E CAP,E 0.22-50 SMG LHSM CX-ZL820
O FUNC/E.VR C 0615 87-012-172-080 0E C-CAP,U 10P-50 D CH USM CX-ZL720
O FUNC/E.VR C 0615 87-012-172-080 0E C-CAP,U 10P-50 D CH LHSM CX-ZL820
O FUNC/E.VR C 0616 87-010-221-080 0E CAP,E 470-10 M SME USM CX-ZL720
O FUNC/E.VR C 0616 87-010-221-080 0E CAP,E 470-10 M SME LHSM CX-ZL820
O FUNC/E.VR C 0617 87-010-221-080 0E CAP,E 470-10 M SME USM CX-ZL720
O FUNC/E.VR C 0617 87-010-221-080 0E CAP,E 470-10 M SME LHSM CX-ZL820
O FUNC/E.VR C 0618 87-A12-0 1-080 0E CAP,E 10-50 SMG USM CX-ZL720
O FUNC/E.VR C 0618 87-A12-0 1-080 0E CAP,E 10-50 SMG LHSM CX-ZL820
O FUNC/E.VR C 0620 87-010-263-080 0E CAP,E 100-10 M 11L SME USM CX-ZL720
O FUNC/E.VR C 0620 87-010-263-080 0E CAP,E 100-10 M 11L SME LHSM CX-ZL820
O FUNC/E.VR C 0623 87-010-402-080 0E CAP,E 2.2-50 M 11L SME USM CX-ZL720
O FUNC/E.VR C 0623 87-010-402-080 0E CAP,E 2.2-50 M 11L SME LHSM CX-ZL820
O FUNC/E.VR C 0624 87-010-402-080 0E CAP,E 2.2-50 M 11L SME USM CX-ZL720
O FUNC/E.VR C 0624 87-010-402-080 0E CAP,E 2.2-50 M 11L SME LHSM CX-ZL820
O FUNC/E.VR C 0630 87-010-75 -080 0E C-CAP,U 0.1-25 Z F USM CX-ZL720
O FUNC/E.VR C 0630 87-010-75 -080 0E C-CAP,U 0.1-25 Z F LHSM CX-ZL820
X FUNC/E.VR C 0633 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-ZL720
X FUNC/E.VR C 0633 88-108-183-080 0E C-RES,U 18K-1/16W J LHSM CX-ZL820
X FUNC/E.VR C 0634 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-ZL720
X FUNC/E.VR C 0634 88-108-183-080 0E C-RES,U 18K-1/16W J LHSM CX-ZL820
O FUNC/E.VR C 066 87-012-1 5-080 0E C-CAP,U 100P-50 J CH USM CX-ZL720
O FUNC/E.VR C 066 87-012-1 5-080 0E C-CAP,U 100P-50 J CH LHSM CX-ZL820
O FUNC/E.VR C 0670 87-012-1 5-080 0E C-CAP,U 100P-50 J CH USM CX-ZL720
O FUNC/E.VR C 0670 87-012-1 5-080 0E C-CAP,U 100P-50 J CH LHSM CX-ZL820
O FUNC/E.VR C 0671 87-010-805-080 0E C-CAP,S 1-16 Z F USM CX-ZL720
O FUNC/E.VR C 0671 87-010-805-080 0E C-CAP,S 1-16 Z F LHSM CX-ZL820
O FUNC/E.VR C 0672 87-010-805-080 0E C-CAP,S 1-16 Z F USM CX-ZL720
O FUNC/E.VR C 0672 87-010-805-080 0E C-CAP,S 1-16 Z F LHSM CX-ZL820
O FUNC/E.VR C 0673 87-012-1 5-080 0E C-CAP,U 100P-50 J CH USM CX-ZL720

 6 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O FUNC/E.VR C 0673 87-012-1 5-080 0E C-CAP,U 100P-50 J CH LHSM CX-ZL820
O FUNC/E.VR C 0677 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-ZL720
O FUNC/E.VR C 0677 87-012-286-080 0E C-CAP,U 0.01-25 K B LHSM CX-ZL820
X FUNC/E.VR C 0678 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FUNC/E.VR C 0678 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
O FUNC/E.VR C 0681 87-012-1 5-080 0E C-CAP,U 100P-50 J CH USM CX-ZL720
O FUNC/E.VR C 0681 87-012-1 5-080 0E C-CAP,U 100P-50 J CH LHSM CX-ZL820
O FUNC/E.VR C 0682 87-012-1 5-080 0E C-CAP,U 100P-50 J CH USM CX-ZL720
O FUNC/E.VR C 0682 87-012-1 5-080 0E C-CAP,U 100P-50 J CH LHSM CX-ZL820
! O FUNC/E.VR CN 0601 87-0 -71 -010 1B CONN,30P H BLK TYK-B(X) USM CX-ZL720
! O FUNC/E.VR CN 0601 87-0 -71 -010 1B CONN,30P H BLK TYK-B(X) LHSM CX-ZL820
! O FUNC/E.VR CN 0602 87-A60-131-010 0E CONN,6P V FE USM CX-ZL720
! O FUNC/E.VR CN 0602 87-A60-131-010 0E CONN,6P V FE LHSM CX-ZL820
S FUNC/E.VR D 0601 87-A40-53 -080 0E ZENER,MTZJ2.4A USM CX-ZL720
S FUNC/E.VR D 0601 87-A40-53 -080 0E ZENER,MTZJ2.4A LHSM CX-ZL820
S FUNC/E.VR D 0602 87-A40-53 -080 0E ZENER,MTZJ2.4A USM CX-ZL720
S FUNC/E.VR D 0602 87-A40-53 -080 0E ZENER,MTZJ2.4A LHSM CX-ZL820
X FUNC/E.VR FB 0602 88-100-000-010 0E PLATING-JW, 0.58 SN 5 USM CX-ZL720
X FUNC/E.VR FB 0602 88-100-000-010 0E PLATING-JW, 0.58 SN 5 LHSM CX-ZL820
S FUNC/E.VR IC 0601 87-A21-443-040 1C C-IC,M624 5AFP USM CX-ZL720
S FUNC/E.VR IC 0601 87-A21-443-040 1C C-IC,M624 5AFP LHSM CX-ZL820
O FUNC/E.VR J 0603 87-A60- 26-010 1A JACK,PIN 4P R/W TC58-118 USM CX-ZL720
O FUNC/E.VR J 0603 87-A60- 26-010 1A JACK,PIN 4P R/W TC58-118 LHSM CX-ZL820
X FUNC/E.VR JR 0601 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FUNC/E.VR JR 0601 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FUNC/E.VR JR 0602 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FUNC/E.VR JR 0602 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FUNC/E.VR JR 0606 88-12 -000-080 0E C-JUMPER,3216 USM CX-ZL720
X FUNC/E.VR JR 0606 88-12 -000-080 0E C-JUMPER,3216 LHSM CX-ZL820
X FUNC/E.VR JR 0607 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FUNC/E.VR JR 0607 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FUNC/E.VR JR 0612 88-12 -000-080 0E C-JUMPER,3216 USM CX-ZL720
X FUNC/E.VR JR 0612 88-12 -000-080 0E C-JUMPER,3216 LHSM CX-ZL820
X FUNC/E.VR JR 0613 88-12 -000-080 0E C-JUMPER,3216 USM CX-ZL720
X FUNC/E.VR JR 0613 88-12 -000-080 0E C-JUMPER,3216 LHSM CX-ZL820
X FUNC/E.VR JR 0614 88-12 -000-080 0E C-JUMPER,3216 USM CX-ZL720
X FUNC/E.VR JR 0614 88-12 -000-080 0E C-JUMPER,3216 LHSM CX-ZL820
X FUNC/E.VR JR 0615 88-12 -000-080 0E C-JUMPER,3216 USM CX-ZL720
X FUNC/E.VR JR 0615 88-12 -000-080 0E C-JUMPER,3216 LHSM CX-ZL820
X FUNC/E.VR JR 0616 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FUNC/E.VR JR 0616 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
S FUNC/E.VR Q 0601 87-A30-087-080 0E C-FET,2SK2158 USM CX-ZL720
S FUNC/E.VR Q 0601 87-A30-087-080 0E C-FET,2SK2158 LHSM CX-ZL820
S FUNC/E.VR Q 0602 87-A30-087-080 0E C-FET,2SK2158 USM CX-ZL720
S FUNC/E.VR Q 0602 87-A30-087-080 0E C-FET,2SK2158 LHSM CX-ZL820
S FUNC/E.VR Q 0605 87-A30-0 0-080 0E FET,2SK2541 USM CX-ZL720
S FUNC/E.VR Q 0605 87-A30-0 0-080 0E FET,2SK2541 LHSM CX-ZL820
S FUNC/E.VR Q 0606 87-A30-0 0-080 0E FET,2SK2541 USM CX-ZL720
S FUNC/E.VR Q 0606 87-A30-0 0-080 0E FET,2SK2541 LHSM CX-ZL820
S FUNC/E.VR Q 0607 87-A30-076-080 0E C-TR,2SC3052F USM CX-ZL720
S FUNC/E.VR Q 0607 87-A30-076-080 0E C-TR,2SC3052F LHSM CX-ZL820
X FUNC/E.VR R 0077 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0077 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0601 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0601 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0602 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0602 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0603 88-108-682-080 0E C-RES,U 6.8K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0603 88-108-682-080 0E C-RES,U 6.8K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0604 88-108-682-080 0E C-RES,U 6.8K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0604 88-108-682-080 0E C-RES,U 6.8K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0607 88-108-682-080 0E C-RES,U 6.8K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0607 88-108-682-080 0E C-RES,U 6.8K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0608 88-108-682-080 0E C-RES,U 6.8K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0608 88-108-682-080 0E C-RES,U 6.8K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 060 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-ZL720
X FUNC/E.VR R 060 88-108-332-080 0E C-RES,U 3.3K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0610 88-121-332-080 0E RES,3.3K-1/8W J USM CX-ZL720
X FUNC/E.VR R 0610 88-121-332-080 0E RES,3.3K-1/8W J LHSM CX-ZL820
X FUNC/E.VR R 0611 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720

 7 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X FUNC/E.VR R 0611 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0612 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0612 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0613 88-121-102-080 0E RES,1K-1/8W J USM CX-ZL720
X FUNC/E.VR R 0613 88-121-102-080 0E RES,1K-1/8W J LHSM CX-ZL820
X FUNC/E.VR R 0614 88-121-102-080 0E RES,1K-1/8W J USM CX-ZL720
X FUNC/E.VR R 0614 88-121-102-080 0E RES,1K-1/8W J LHSM CX-ZL820
X FUNC/E.VR R 0615 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0615 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0616 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0616 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0618 88-108-332-080 0E C-RES,U 3.3K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0618 88-108-332-080 0E C-RES,U 3.3K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 061 88-108-273-080 0E C-RES,U 27K-1/16W J USM CX-ZL720
X FUNC/E.VR R 061 88-108-273-080 0E C-RES,U 27K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0620 88-108-273-080 0E C-RES,U 27K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0620 88-108-273-080 0E C-RES,U 27K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0621 88-108-105-080 0E C-RES,U 1M-1/16W J USM CX-ZL720
X FUNC/E.VR R 0621 88-108-105-080 0E C-RES,U 1M-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0622 88-108-105-080 0E C-RES,U 1M-1/16W J USM CX-ZL720
X FUNC/E.VR R 0622 88-108-105-080 0E C-RES,U 1M-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0625 88-121-472-080 0E RES,4.7K-1/8W J USM CX-ZL720
X FUNC/E.VR R 0625 88-121-472-080 0E RES,4.7K-1/8W J LHSM CX-ZL820
X FUNC/E.VR R 0626 88-121-103-080 0E RES,10K-1/8W J USM CX-ZL720
X FUNC/E.VR R 0626 88-121-103-080 0E RES,10K-1/8W J LHSM CX-ZL820
X FUNC/E.VR R 0627 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0627 88-108-123-080 0E C-RES,U 12K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0628 88-121-332-080 0E RES,3.3K-1/8W J USM CX-ZL720
X FUNC/E.VR R 0628 88-121-332-080 0E RES,3.3K-1/8W J LHSM CX-ZL820
X FUNC/E.VR R 0631 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0631 88-108-104-080 0E C-RES,U 100K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0632 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0632 88-108-103-080 0E C-RES,U 10K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0633 88-108-563-080 0E C-RES,U 56K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0633 88-108-563-080 0E C-RES,U 56K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0634 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0634 88-108-223-080 0E C-RES,U 22K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0635 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0635 88-108-223-080 0E C-RES,U 22K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0637 88-108-182-080 0E C-RES,U 1.8K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0637 88-108-182-080 0E C-RES,U 1.8K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0638 88-108-182-080 0E C-RES,U 1.8K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0638 88-108-182-080 0E C-RES,U 1.8K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 063 88-108-273-080 0E C-RES,U 27K-1/16W J USM CX-ZL720
X FUNC/E.VR R 063 88-108-273-080 0E C-RES,U 27K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0640 88-108-273-080 0E C-RES,U 27K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0640 88-108-273-080 0E C-RES,U 27K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0641 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0641 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0642 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0642 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0643 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0643 88-108-472-080 0E C-RES,U 4.7K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0644 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0644 88-108-472-080 0E C-RES,U 4.7K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 064 88-108-562-080 0E C-RES,U 5.6K-1/16W J USM CX-ZL720
X FUNC/E.VR R 064 88-108-562-080 0E C-RES,U 5.6K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0650 88-108-562-080 0E C-RES,U 5.6K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0650 88-108-562-080 0E C-RES,U 5.6K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0653 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FUNC/E.VR R 0653 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FUNC/E.VR R 0654 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X FUNC/E.VR R 0654 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X FUNC/E.VR R 0661 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0661 88-108-123-080 0E C-RES,U 12K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0662 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0662 88-108-123-080 0E C-RES,U 12K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0663 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-ZL720
X FUNC/E.VR R 0663 88-108-123-080 0E C-RES,U 12K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0664 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-ZL720

 8 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X FUNC/E.VR R 0664 88-108-123-080 0E C-RES,U 12K-1/16W J LHSM CX-ZL820
X FUNC/E.VR R 0671 88-121-183-080 0E RES,18K-1/8W J USM CX-ZL720
X FUNC/E.VR R 0671 88-121-183-080 0E RES,18K-1/8W J LHSM CX-ZL820
X FUNC/E.VR R 0672 88-121-183-080 0E RES,18K-1/8W J USM CX-ZL720
X FUNC/E.VR R 0672 88-121-183-080 0E RES,18K-1/8W J LHSM CX-ZL820
! O KEY-CD CN 0701 87-A60-156-010 0E CONN,8P H FE USM CX-ZL720
! O KEY-CD CN 0701 87-A60-156-010 0E CONN,8P H FE LHSM CX-ZL820
O KEY-CD LED0771 87-A41-055-040 0E LED,HLMF-K405 ORANGE USM CX-ZL720
O KEY-CD LED0771 87-A41-055-040 0E LED,HLMF-K405 ORANGE LHSM CX-ZL820
O KEY-CD LED0772 87-A41-055-040 0E LED,HLMF-K405 ORANGE USM CX-ZL720
O KEY-CD LED0772 87-A41-055-040 0E LED,HLMF-K405 ORANGE LHSM CX-ZL820
O KEY-CD LED0773 87-A41-055-040 0E LED,HLMF-K405 ORANGE USM CX-ZL720
O KEY-CD LED0773 87-A41-055-040 0E LED,HLMF-K405 ORANGE LHSM CX-ZL820
O KEY-CD LED0774 87-A41-055-040 0E LED,HLMF-K405 ORANGE USM CX-ZL720
O KEY-CD LED0774 87-A41-055-040 0E LED,HLMF-K405 ORANGE LHSM CX-ZL820
O KEY-CD LED0775 87-A41-055-040 0E LED,HLMF-K405 ORANGE USM CX-ZL720
O KEY-CD LED0775 87-A41-055-040 0E LED,HLMF-K405 ORANGE LHSM CX-ZL820
X KEY-CD R 0751 88-108-272-080 0E C-RES,U 2.7K-1/16W J USM CX-ZL720
X KEY-CD R 0751 88-108-272-080 0E C-RES,U 2.7K-1/16W J LHSM CX-ZL820
X KEY-CD R 0752 88-108-3 2-080 0E C-RES,U 3. K-1/16W J USM CX-ZL720
X KEY-CD R 0752 88-108-3 2-080 0E C-RES,U 3. K-1/16W J LHSM CX-ZL820
X KEY-CD R 0753 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-ZL720
X KEY-CD R 0753 88-108-472-080 0E C-RES,U 4.7K-1/16W J LHSM CX-ZL820
X KEY-CD R 0754 88-108-682-080 0E C-RES,U 6.8K-1/16W J USM CX-ZL720
X KEY-CD R 0754 88-108-682-080 0E C-RES,U 6.8K-1/16W J LHSM CX-ZL820
X KEY-CD R 0755 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-ZL720
X KEY-CD R 0755 88-108-103-080 0E C-RES,U 10K-1/16W J LHSM CX-ZL820
X KEY-CD R 0756 88-108-153-080 0E C-RES,U 15K-1/16W J USM CX-ZL720
X KEY-CD R 0756 88-108-153-080 0E C-RES,U 15K-1/16W J LHSM CX-ZL820
X KEY-CD R 0757 88-108-273-080 0E C-RES,U 27K-1/16W J USM CX-ZL720
X KEY-CD R 0757 88-108-273-080 0E C-RES,U 27K-1/16W J LHSM CX-ZL820
X KEY-CD R 0771 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X KEY-CD R 0771 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X KEY-CD R 0772 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X KEY-CD R 0772 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X KEY-CD R 0773 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X KEY-CD R 0773 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X KEY-CD R 0774 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X KEY-CD R 0774 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X KEY-CD R 0775 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X KEY-CD R 0775 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X KEY-CD R 0776 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X KEY-CD R 0776 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X KEY-CD R 0777 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X KEY-CD R 0777 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X KEY-CD R 0778 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X KEY-CD R 0778 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X KEY-CD R 077 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X KEY-CD R 077 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X KEY-CD R 0780 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X KEY-CD R 0780 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
O KEY-CD S 0751 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O KEY-CD S 0751 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O KEY-CD S 0752 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O KEY-CD S 0752 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O KEY-CD S 0753 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O KEY-CD S 0753 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O KEY-CD S 0754 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O KEY-CD S 0754 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O KEY-CD S 0755 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O KEY-CD S 0755 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O KEY-CD S 0756 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O KEY-CD S 0756 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O KEY-CD S 0757 87-A 0-0 5-080 0E SW,TACT EVQ11G04M USM CX-ZL720
O KEY-CD S 0757 87-A 0-0 5-080 0E SW,TACT EVQ11G04M LHSM CX-ZL820
O KNOB 8B-MA3-061-010 -- KEY,OPEN USM CX-ZL720
O KNOB 8B-MA3-061-010 -- KEY,OPEN LHSM CX-ZL820
X KNOB 8B-MA3-063-010 -- KEY,DIRECT A3 USM CX-ZL720
X KNOB 8B-MA3-063-010 -- KEY,DIRECT A3 LHSM CX-ZL820
O KNOB 8B-MA3-064-010 -- KEY,T-BASS A3 USM CX-ZL720

 9 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O KNOB 8B-MA3-064-010 -- KEY,T-BASS A3 LHSM CX-ZL820
O KNOB 8B-MA3-065-010 -- KEY,ENTER USM CX-ZL720
O KNOB 8B-MA3-065-010 -- KEY,ENTER LHSM CX-ZL820
O KNOB 8B-MA3-066-010 -- KEY,GEQ USM CX-ZL720
O KNOB 8B-MA3-066-010 -- KEY,GEQ LHSM CX-ZL820
X KNOB 8B-MA3-070-010 -- KEY,OPE USM CX-ZL720
X KNOB 8B-MA3-070-010 -- KEY,OPE LHSM CX-ZL820
X KNOB 8B-MA3-071-010 -- KEY,FUNC A3 USM CX-ZL720
X KNOB 8B-MA3-071-010 -- KEY,FUNC A3 LHSM CX-ZL820
X KNOB 8B-MA3-072-010 -- KEY,CD USM CX-ZL720
X KNOB 8B-MA3-072-010 -- KEY,CD LHSM CX-ZL820
X KNOB 8B-MA3-080-010 -- KNOB,RTRY VOL USM CX-ZL720
X KNOB 8B-MA3-080-010 -- KNOB,RTRY VOL LHSM CX-ZL820
O KNOB 8B-MA3-081-010 -- KNOB,RTRY JOG USM CX-ZL720
O KNOB 8B-MA3-081-010 -- KNOB,RTRY JOG LHSM CX-ZL820
X KNOB 8B-MA3-082-010 -- CAP, VOL USM CX-ZL720
X KNOB 8B-MA3-082-010 -- CAP, VOL LHSM CX-ZL820
O KNOB 8B-MA3-083-010 -- KNOB,SL MIC USM CX-ZL720
O KNOB 8B-MA3-083-010 -- KNOB,SL MIC LHSM CX-ZL820
O KNOB 8B-MA3-084-010 -- RING,OPE USM CX-ZL720
O KNOB 8B-MA3-084-010 -- RING,OPE LHSM CX-ZL820
X KNOB 8B-MA3-085-010 -- RING,CD USM CX-ZL720
X KNOB 8B-MA3-085-010 -- RING,CD LHSM CX-ZL820
O KNOB 8B-MA3-086-010 -- RING,VOL USM CX-ZL720
O KNOB 8B-MA3-086-010 -- RING,VOL LHSM CX-ZL820
O KNOB 8B-MA3-088-010 -- RING,IND USM CX-ZL720
O KNOB 8B-MA3-088-010 -- RING,IND LHSM CX-ZL820
X KNOB 8B-MA3-0 0-010 -- REFLECTOR,DIRECT USM CX-ZL720
X KNOB 8B-MA3-0 0-010 -- REFLECTOR,DIRECT LHSM CX-ZL820
X KNOB 8B-MA3-0 1-010 -- REFLECTOR,POWER USM CX-ZL720
X KNOB 8B-MA3-0 1-010 -- REFLECTOR,POWER LHSM CX-ZL820
X KNOB 8B-MA3-0 2-010 -- REFLECTOR,PLAY USM CX-ZL720
X KNOB 8B-MA3-0 2-010 -- REFLECTOR,PLAY LHSM CX-ZL820
X KNOB 8B-MA3-0 3-010 -- REFLECTOR,FF USM CX-ZL720
X KNOB 8B-MA3-0 3-010 -- REFLECTOR,FF LHSM CX-ZL820
X KNOB 8B-MA3-0 4-010 -- REFLECTOR,FUNC USM CX-ZL720
X KNOB 8B-MA3-0 4-010 -- REFLECTOR,FUNC LHSM CX-ZL820
X KNOB 8B-MA3-0 5-010 -- REFLECTOR,CD USM CX-ZL720
X KNOB 8B-MA3-0 5-010 -- REFLECTOR,CD LHSM CX-ZL820
O KNOB 8B-MA3-100-010 -- KEY ASSY,DIRECT USM CX-ZL720
O KNOB 8B-MA3-100-010 -- KEY ASSY,DIRECT LHSM CX-ZL820
O KNOB 8B-MA3-102-010 -- KEY ASSY,OPE USM CX-ZL720
O KNOB 8B-MA3-102-010 -- KEY ASSY,OPE LHSM CX-ZL820
O KNOB 8B-MA3-103-010 -- KEY ASSY,FUNC USM CX-ZL720
O KNOB 8B-MA3-103-010 -- KEY ASSY,FUNC LHSM CX-ZL820
O KNOB 8B-MA3-104-010 -- KEY ASSY,CD USM CX-ZL720
O KNOB 8B-MA3-104-010 -- KEY ASSY,CD LHSM CX-ZL820
O KNOB 8B-MA3-105-010 -- KNOB ASSY,RTRY VOL USM CX-ZL720
O KNOB 8B-MA3-105-010 -- KNOB ASSY,RTRY VOL LHSM CX-ZL820
O KNOB 8B-MA5-087-010 -- RING,JOG R USM CX-ZL720
O KNOB 8B-MA5-087-010 -- RING,JOG R LHSM CX-ZL820
X MECHANICAL 8B-MA3-201-010 -- CHAS,MAIN A3 USM CX-ZL720
X MECHANICAL 8B-MA3-201-010 -- CHAS,MAIN A3 LHSM CX-ZL820
O MIC C 0602 87-A10-706-080 0E C-CAP,U 0.33-16 Z F USM CX-ZL720
O MIC C 0602 87-A10-706-080 0E C-CAP,U 0.33-16 Z F LHSM CX-ZL820
O MIC C 0603 87-012-337-080 0E C-CAP,U 56P-50 J CH GRM USM CX-ZL720
O MIC C 0603 87-012-337-080 0E C-CAP,U 56P-50 J CH GRM LHSM CX-ZL820
O MIC C 0604 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-ZL720
O MIC C 0604 87-012-274-080 0E C-CAP,U 1000P-50 K B LHSM CX-ZL820
O MIC C 0606 87-010-75 -080 0E C-CAP,U 0.1-25 Z F USM CX-ZL720
O MIC C 0606 87-010-75 -080 0E C-CAP,U 0.1-25 Z F LHSM CX-ZL820
O MIC C 0607 87-010-060-040 0E CAP,E 100-16 M 7L SRA USM CX-ZL720
O MIC C 0607 87-010-060-040 0E CAP,E 100-16 M 7L SRA LHSM CX-ZL820
O MIC C 0611 87-012-282-080 0E C-CAP,U 4700P-50 K B USM CX-ZL720
O MIC C 0611 87-012-282-080 0E C-CAP,U 4700P-50 K B LHSM CX-ZL820
O MIC C 0612 87-015-6 -040 0E CAP,E 10-50 M 7L SRA USM CX-ZL720
O MIC C 0612 87-015-6 -040 0E CAP,E 10-50 M 7L SRA LHSM CX-ZL820
O MIC C 0614 87-A10-047-080 0E C-CAP,U 1-10 Z F USM CX-ZL720
O MIC C 0614 87-A10-047-080 0E C-CAP,U 1-10 Z F LHSM CX-ZL820
O MIC C 0621 87-010-75 -080 0E C-CAP,U 0.1-25 Z F USM CX-ZL720

 10 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O MIC C 0621 87-010-75 -080 0E C-CAP,U 0.1-25 Z F LHSM CX-ZL820
O MIC C 0622 87-010-75 -080 0E C-CAP,U 0.1-25 Z F USM CX-ZL720
O MIC C 0622 87-010-75 -080 0E C-CAP,U 0.1-25 Z F LHSM CX-ZL820
O MIC C 0623 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-ZL720
O MIC C 0623 87-012-274-080 0E C-CAP,U 1000P-50 K B LHSM CX-ZL820
O MIC C 0624 87-012-337-080 0E C-CAP,U 56P-50 J CH GRM USM CX-ZL720
O MIC C 0624 87-012-337-080 0E C-CAP,U 56P-50 J CH GRM LHSM CX-ZL820
O MIC CNA0601 8B-MA3-655-010 -- CONN ASSY,3P 80MM USM CX-ZL720
O MIC CNA0601 8B-MA3-655-010 -- CONN ASSY,3P 80MM LHSM CX-ZL820
! O MIC J 0601 87-0 -65 -010 1A JACK,6.3 0 USM CX-ZL720
! O MIC J 0601 87-0 -65 -010 1A JACK,6.3 0 LHSM CX-ZL820
! O MIC J 0602 87-0 -65 -010 1A JACK,6.3 0 USM CX-ZL720
! O MIC J 0602 87-0 -65 -010 1A JACK,6.3 0 LHSM CX-ZL820
S MIC Q 0601 87-A30-076-080 0E C-TR,2SC3052F USM CX-ZL720
S MIC Q 0601 87-A30-076-080 0E C-TR,2SC3052F LHSM CX-ZL820
S MIC Q 0602 87-A30-075-080 0E C-TR,2SA1235F USM CX-ZL720
S MIC Q 0602 87-A30-075-080 0E C-TR,2SA1235F LHSM CX-ZL820
S MIC Q 0611 87-A30-087-080 0E C-FET,2SK2158 USM CX-ZL720
S MIC Q 0611 87-A30-087-080 0E C-FET,2SK2158 LHSM CX-ZL820
S MIC Q 0612 87-A30-076-080 0E C-TR,2SC3052F USM CX-ZL720
S MIC Q 0612 87-A30-076-080 0E C-TR,2SC3052F LHSM CX-ZL820
S MIC Q 0621 87-A30-076-080 0E C-TR,2SC3052F USM CX-ZL720
S MIC Q 0621 87-A30-076-080 0E C-TR,2SC3052F LHSM CX-ZL820
S MIC Q 0622 87-A30-075-080 0E C-TR,2SA1235F USM CX-ZL720
S MIC Q 0622 87-A30-075-080 0E C-TR,2SA1235F LHSM CX-ZL820
X MIC R 0601 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-ZL720
X MIC R 0601 88-108-472-080 0E C-RES,U 4.7K-1/16W J LHSM CX-ZL820
X MIC R 0602 88-108-472-080 0E C-RES,U 4.7K-1/16W J USM CX-ZL720
X MIC R 0602 88-108-472-080 0E C-RES,U 4.7K-1/16W J LHSM CX-ZL820
X MIC R 0603 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-ZL720
X MIC R 0603 88-108-222-080 0E C-RES,U 2.2K-1/16W J LHSM CX-ZL820
X MIC R 0604 88-108-333-080 0E C-RES,U 33K-1/16W J USM CX-ZL720
X MIC R 0604 88-108-333-080 0E C-RES,U 33K-1/16W J LHSM CX-ZL820
X MIC R 0605 88-108-562-080 0E C-RES,U 5.6K-1/16W J USM CX-ZL720
X MIC R 0605 88-108-562-080 0E C-RES,U 5.6K-1/16W J LHSM CX-ZL820
X MIC R 0606 88-108-334-080 0E C-RES,U 330K-1/16W J USM CX-ZL720
X MIC R 0606 88-108-334-080 0E C-RES,U 330K-1/16W J LHSM CX-ZL820
X MIC R 0607 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MIC R 0607 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MIC R 0608 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-ZL720
X MIC R 0608 88-108-101-080 0E C-RES,U 100-1/16W J LHSM CX-ZL820
X MIC R 060 88-121-101-080 0E RES,100-1/8W J USM CX-ZL720
X MIC R 060 88-121-101-080 0E RES,100-1/8W J LHSM CX-ZL820
X MIC R 0611 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-ZL720
X MIC R 0611 88-108-104-080 0E C-RES,U 100K-1/16W J LHSM CX-ZL820
X MIC R 0612 88-108-224-080 0E C-RES,U 220K-1/16W J USM CX-ZL720
X MIC R 0612 88-108-224-080 0E C-RES,U 220K-1/16W J LHSM CX-ZL820
X MIC R 0613 88-108-334-080 0E C-RES,U 330K-1/16W J USM CX-ZL720
X MIC R 0613 88-108-334-080 0E C-RES,U 330K-1/16W J LHSM CX-ZL820
X MIC R 0614 88-108-224-080 0E C-RES,U 220K-1/16W J USM CX-ZL720
X MIC R 0614 88-108-224-080 0E C-RES,U 220K-1/16W J LHSM CX-ZL820
X MIC R 0621 88-108-273-080 0E C-RES,U 27K-1/16W J USM CX-ZL720
X MIC R 0621 88-108-273-080 0E C-RES,U 27K-1/16W J LHSM CX-ZL820
X MIC R 0622 88-108-333-080 0E C-RES,U 33K-1/16W J USM CX-ZL720
X MIC R 0622 88-108-333-080 0E C-RES,U 33K-1/16W J LHSM CX-ZL820
X MIC R 0623 88-108-564-080 0E C-RES,U 560K-1/16W J USM CX-ZL720
X MIC R 0623 88-108-564-080 0E C-RES,U 560K-1/16W J LHSM CX-ZL820
X MIC R 0624 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MIC R 0624 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MIC R 0625 88-108-562-080 0E C-RES,U 5.6K-1/16W J USM CX-ZL720
X MIC R 0625 88-108-562-080 0E C-RES,U 5.6K-1/16W J LHSM CX-ZL820
O MIC VR 0621 8Z-MA3-603-010 1C VR,SL 10KB RS15111-20 USM CX-ZL720
O MIC VR 0621 8Z-MA3-603-010 1C VR,SL 10KB RS15111-20 LHSM CX-ZL820
O MICON 88-MA1-205-010 0E GUIDE,FL USM CX-ZL720
O MICON 88-MA1-205-010 0E GUIDE,FL LHSM CX-ZL820
X MICON 8B-MA5-601-110 1E PWB,COMBI FR USM CX-ZL720
X MICON 8B-MA5-601-110 1E PWB,COMBI FR LHSM CX-ZL820
X MICON 8B-MA5-602-110 -- PWB,MICON USM CX-ZL720
X MICON 8B-MA5-602-110 -- PWB,MICON LHSM CX-ZL820
X MICON 8B-MA5-603-110 -- PWB,CNTL USM CX-ZL720

 11 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON 8B-MA5-603-110 -- PWB,CNTL LHSM CX-ZL820
X MICON 8B-MA5-604-110 -- PWB,KEY CD USM CX-ZL720
X MICON 8B-MA5-604-110 -- PWB,KEY CD LHSM CX-ZL820
O MICON C 0100 87-A10-047-080 0E C-CAP,U 1-10 Z F USM CX-ZL720
O MICON C 0100 87-A10-047-080 0E C-CAP,U 1-10 Z F LHSM CX-ZL820
O MICON C 0106 87-010-248-040 0E CAP,E 220-10 M 11L SME USM CX-ZL720
O MICON C 0106 87-010-248-040 0E CAP,E 220-10 M 11L SME LHSM CX-ZL820
O MICON C 0107 87-010-75 -080 0E C-CAP,U 0.1-25 Z F USM CX-ZL720
O MICON C 0107 87-010-75 -080 0E C-CAP,U 0.1-25 Z F LHSM CX-ZL820
O MICON C 0108 87-012-278-080 0E C-CAP,U 2200P-50 K B USM CX-ZL720
O MICON C 0108 87-012-278-080 0E C-CAP,U 2200P-50 K B LHSM CX-ZL820
O MICON C 0110 87-010-248-040 0E CAP,E 220-10 M 11L SME USM CX-ZL720
O MICON C 0110 87-010-248-040 0E CAP,E 220-10 M 11L SME LHSM CX-ZL820
O MICON C 0111 87-A10-260-080 0E C-CAP,U 0.1-16 K B USM CX-ZL720
O MICON C 0111 87-A10-260-080 0E C-CAP,U 0.1-16 K B LHSM CX-ZL820
O MICON C 0112 87-010-4 3-040 0E CAP,E 0.47-50 M 5L SRE USM CX-ZL720
O MICON C 0112 87-010-4 3-040 0E CAP,E 0.47-50 M 5L SRE LHSM CX-ZL820
O MICON C 0113 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-ZL720
O MICON C 0113 87-012-274-080 0E C-CAP,U 1000P-50 K B LHSM CX-ZL820
O MICON C 0116 87-010-75 -080 0E C-CAP,U 0.1-25 Z F USM CX-ZL720
O MICON C 0116 87-010-75 -080 0E C-CAP,U 0.1-25 Z F LHSM CX-ZL820
O MICON C 0117 87-010-872-080 0E C-CAP,U 470P-50 SL USM CX-ZL720
O MICON C 0117 87-010-872-080 0E C-CAP,U 470P-50 SL LHSM CX-ZL820
O MICON C 0122 87-012-36 -080 0E C-CAP,S 0.047-50 Z F USM CX-ZL720
O MICON C 0122 87-012-36 -080 0E C-CAP,S 0.047-50 Z F LHSM CX-ZL820
O MICON C 0123 87-010-408-040 0E CAP,E 47-50 M 11L SME USM CX-ZL720
O MICON C 0123 87-010-408-040 0E CAP,E 47-50 M 11L SME LHSM CX-ZL820
O MICON C 0124 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE USM CX-ZL720
O MICON C 0124 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE LHSM CX-ZL820
O MICON C 0125 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE USM CX-ZL720
O MICON C 0125 87-010-421-040 0E CAP,E 4.7-50 M 5L SRE LHSM CX-ZL820
O MICON C 0132 87-012-1 -080 0E C-CAP,U 220P-50 J CH USM CX-ZL720
O MICON C 0132 87-012-1 -080 0E C-CAP,U 220P-50 J CH LHSM CX-ZL820
O MICON C 0133 87-012-184-080 0E C-CAP,U 33P-50 J CH USM CX-ZL720
O MICON C 0133 87-012-184-080 0E C-CAP,U 33P-50 J CH LHSM CX-ZL820
O MICON C 0135 87-018-20 -080 0E CAP,TC U 0.1-50 Z F UP050 USM CX-ZL720
O MICON C 0135 87-018-20 -080 0E CAP,TC U 0.1-50 Z F UP050 LHSM CX-ZL820
O MICON C 0137 87-012-178-080 0E C-CAP,U 18P-50 J CH USM CX-ZL720
O MICON C 0137 87-012-178-080 0E C-CAP,U 18P-50 J CH LHSM CX-ZL820
O MICON C 0138 87-010-75 -080 0E C-CAP,U 0.1-25 Z F USM CX-ZL720
O MICON C 0138 87-010-75 -080 0E C-CAP,U 0.1-25 Z F LHSM CX-ZL820
O MICON C 0251 87-010-75 -080 0E C-CAP,U 0.1-25 Z F USM CX-ZL720
O MICON C 0251 87-010-75 -080 0E C-CAP,U 0.1-25 Z F LHSM CX-ZL820
O MICON C 0252 87-012-1 -080 0E C-CAP,U 220P-50 J CH USM CX-ZL720
O MICON C 0252 87-012-1 -080 0E C-CAP,U 220P-50 J CH LHSM CX-ZL820
O MICON C 0253 87-012-1 5-080 0E C-CAP,U 100P-50 J CH USM CX-ZL720
O MICON C 0253 87-012-1 5-080 0E C-CAP,U 100P-50 J CH LHSM CX-ZL820
O MICON C 0411 87-012-157-080 0E C-CAP,S 330P-50 J CH GRM USM CX-ZL720
O MICON C 0411 87-012-157-080 0E C-CAP,S 330P-50 J CH GRM LHSM CX-ZL820
O MICON C 0412 87-010-405-040 0E CAP,E 10-50 M 11L SME USM CX-ZL720
O MICON C 0412 87-010-405-040 0E CAP,E 10-50 M 11L SME LHSM CX-ZL820
O MICON C 0421 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-ZL720
O MICON C 0421 87-012-274-080 0E C-CAP,U 1000P-50 K B LHSM CX-ZL820
O MICON C 0422 87-012-274-080 0E C-CAP,U 1000P-50 K B USM CX-ZL720
O MICON C 0422 87-012-274-080 0E C-CAP,U 1000P-50 K B LHSM CX-ZL820
O MICON C 0 40 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720
O MICON C 0 40 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
O MICON C 0 41 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720
O MICON C 0 41 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
O MICON C 0 42 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720
O MICON C 0 42 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
O MICON C 0 43 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720
O MICON C 0 43 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
O MICON C 0 44 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720
O MICON C 0 44 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
O MICON C 0 45 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720
O MICON C 0 45 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
O MICON C 0 46 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720
O MICON C 0 46 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
O MICON C 0 47 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720

 12 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O MICON C 0 47 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
O MICON C 0 48 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720
O MICON C 0 48 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
O MICON C 0 4 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720
O MICON C 0 4 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
O MICON C 0 50 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720
O MICON C 0 50 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
O MICON C 0 51 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720
O MICON C 0 51 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
O MICON C 0 52 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM USM CX-ZL720
O MICON C 0 52 87-012-145-080 0E C-CAP,S 270P-50 J CH GRM LHSM CX-ZL820
! O MICON CN 0101 87-0 -720-010 1B CONN,30P BLK TYK-B(P) USM CX-ZL720
! O MICON CN 0101 87-0 -720-010 1B CONN,30P BLK TYK-B(P) LHSM CX-ZL820
! O MICON CN 0104 87-A60-136-010 0E CONN,11P V FE USM CX-ZL720
! O MICON CN 0104 87-A60-136-010 0E CONN,11P V FE LHSM CX-ZL820
! O MICON CN 0301 87-A60-133-010 0E CONN,8P V FE USM CX-ZL720
! O MICON CN 0301 87-A60-133-010 0E CONN,8P V FE LHSM CX-ZL820
! O MICON CN 1000 87-A60-135-010 0E CONN,10P V FE USM CX-ZL720
! O MICON CN 1000 87-A60-135-010 0E CONN,10P V FE LHSM CX-ZL820
S MICON D 0101 87-A40-234-080 0E ZENER,MTZJ5.6A USM CX-ZL720
S MICON D 0101 87-A40-234-080 0E ZENER,MTZJ5.6A LHSM CX-ZL820
S MICON D 0102 87-A40-270-080 0E C-DIODE,MC2838 USM CX-ZL720
S MICON D 0102 87-A40-270-080 0E C-DIODE,MC2838 LHSM CX-ZL820
S MICON D 0103 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0103 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0104 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0104 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0132 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0132 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0134 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0134 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0135 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0135 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0137 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0137 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0138 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0138 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
X MICON D 013 88-100-000-010 0E PLATING-JW, 0.58 SN 5 USM CX-ZL720
X MICON D 013 88-100-000-010 0E PLATING-JW, 0.58 SN 5 LHSM CX-ZL820
X MICON D 0140 88-100-000-010 0E PLATING-JW, 0.58 SN 5 USM CX-ZL720
X MICON D 0140 88-100-000-010 0E PLATING-JW, 0.58 SN 5 LHSM CX-ZL820
S MICON D 0351 87-A40-26 -080 0E C-DIODE,MC2836 USM CX-ZL720
S MICON D 0351 87-A40-26 -080 0E C-DIODE,MC2836 LHSM CX-ZL820
S MICON D 0371 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0371 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0372 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0372 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0375 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0375 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0376 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0376 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0377 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0377 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0378 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0378 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 037 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 037 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0380 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0380 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0381 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0381 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0382 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0382 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0383 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0383 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0384 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0384 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0385 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0385 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0386 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720

 13 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
S MICON D 0386 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0447 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S MICON D 0447 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0450 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S MICON D 0451 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
O MICON FL 0101 8B-MA3-671-010 -- FL,BJ824GNK USM CX-ZL720
O MICON FL 0101 8B-MA3-671-010 -- FL,BJ824GNK LHSM CX-ZL820
S MICON IC 0101 8B-MA3-651-010 -- C-IC,LC876580 USM CX-ZL720
S MICON IC 0101 8B-MA3-651-010 -- C-IC,LC876580 LHSM CX-ZL820
S MICON IC 0412 87-A21-831-010 1B IC,SPS-442-1-F1 USM CX-ZL720
S MICON IC 0412 87-A21-831-010 1B IC,SPS-442-1-F1 LHSM CX-ZL820
S MICON IC 0662 87-070-28 -040 1B C-IC,BU20 2F USM CX-ZL720
S MICON IC 0662 87-070-28 -040 1B C-IC,BU20 2F LHSM CX-ZL820
X MICON JR 0135 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X MICON JR 0135 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X MICON JR 0136 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X MICON JR 0136 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X MICON JR 0137 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X MICON JR 0137 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X MICON JR 1131 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X MICON JR 1131 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
O MICON L 0101 87-A50-333-010 0E COIL,OSC .43MHZ USM CX-ZL720
O MICON L 0101 87-A50-333-010 0E COIL,OSC .43MHZ LHSM CX-ZL820
O MICON LED0131 87-A40-317-080 0E LED,SLR-342VCT31 RED USM CX-ZL720
O MICON LED0131 87-A40-317-080 0E LED,SLR-342VCT31 RED LHSM CX-ZL820
O MICON LED0202 87-A41-056-040 0E LED,HLMF-D405 ORANGE USM CX-ZL720
O MICON LED0202 87-A41-056-040 0E LED,HLMF-D405 ORANGE LHSM CX-ZL820
O MICON LED0205 87-A41-056-040 0E LED,HLMF-D405 ORANGE USM CX-ZL720
O MICON LED0205 87-A41-056-040 0E LED,HLMF-D405 ORANGE LHSM CX-ZL820
O MICON LED0207 87-A41-056-040 0E LED,HLMF-D405 ORANGE USM CX-ZL720
O MICON LED0207 87-A41-056-040 0E LED,HLMF-D405 ORANGE LHSM CX-ZL820
O MICON LED0210 87-A41-056-040 0E LED,HLMF-D405 ORANGE USM CX-ZL720
O MICON LED0210 87-A41-056-040 0E LED,HLMF-D405 ORANGE LHSM CX-ZL820
O MICON LED0212 87-A41-056-040 0E LED,HLMF-D405 ORANGE USM CX-ZL720
O MICON LED0212 87-A41-056-040 0E LED,HLMF-D405 ORANGE LHSM CX-ZL820
S MICON Q 0101 87-026-610-080 0E TR,KTC31 8GR USM CX-ZL720
S MICON Q 0101 87-026-610-080 0E TR,KTC31 8GR LHSM CX-ZL820
S MICON Q 0102 87-A30-447-040 1F C-TR,DTA114EKA USM CX-ZL720
S MICON Q 0102 87-A30-447-040 1F C-TR,DTA114EKA LHSM CX-ZL820
S MICON Q 0104 87-026-610-080 0E TR,KTC31 8GR USM CX-ZL720
S MICON Q 0104 87-026-610-080 0E TR,KTC31 8GR LHSM CX-ZL820
S MICON Q 0105 87-026-60 -080 0E TR,KTA1266GR USM CX-ZL720
S MICON Q 0105 87-026-60 -080 0E TR,KTA1266GR LHSM CX-ZL820
S MICON Q 0111 87-A30-076-080 0E C-TR,2SC3052F USM CX-ZL720
S MICON Q 0111 87-A30-076-080 0E C-TR,2SC3052F LHSM CX-ZL820
S MICON Q 0130 87-A30-427-040 0E C-TR,DTC114EKA USM CX-ZL720
S MICON Q 0130 87-A30-427-040 0E C-TR,DTC114EKA LHSM CX-ZL820
S MICON Q 0131 87-A30-087-080 0E C-FET,2SK2158 USM CX-ZL720
S MICON Q 0131 87-A30-087-080 0E C-FET,2SK2158 LHSM CX-ZL820
S MICON Q 0132 87-A30-087-080 0E C-FET,2SK2158 USM CX-ZL720
S MICON Q 0132 87-A30-087-080 0E C-FET,2SK2158 LHSM CX-ZL820
S MICON Q 0133 87-A30-427-040 0E C-TR,DTC114EKA USM CX-ZL720
S MICON Q 0133 87-A30-427-040 0E C-TR,DTC114EKA LHSM CX-ZL820
S MICON Q 0134 87-A30-076-080 0E C-TR,2SC3052F USM CX-ZL720
S MICON Q 0134 87-A30-076-080 0E C-TR,2SC3052F LHSM CX-ZL820
S MICON Q 0351 87-A30-582-080 0E TR,CDA1585BC USM CX-ZL720
S MICON Q 0351 87-A30-582-080 0E TR,CDA1585BC LHSM CX-ZL820
S MICON Q 0352 87-A30-4 5-080 0E TR,2SA1 81Y USM CX-ZL720
S MICON Q 0352 87-A30-4 5-080 0E TR,2SA1 81Y LHSM CX-ZL820
S MICON Q 0353 87-A30-4 5-080 0E TR,2SA1 81Y USM CX-ZL720
S MICON Q 0353 87-A30-4 5-080 0E TR,2SA1 81Y LHSM CX-ZL820
S MICON Q 0441 87-A30-142-040 0E C-TR,DTA123EKA USM CX-ZL720
S MICON Q 0441 87-A30-142-040 0E C-TR,DTA123EKA LHSM CX-ZL820
X MICON R 0074 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 0074 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 0075 88-121-102-080 0E RES,1K-1/8W J USM CX-ZL720
X MICON R 0075 88-121-102-080 0E RES,1K-1/8W J LHSM CX-ZL820
X MICON R 0076 88-121-101-080 0E RES,100-1/8W J USM CX-ZL720
X MICON R 0076 88-121-101-080 0E RES,100-1/8W J LHSM CX-ZL820
X MICON R 0077 88-121-102-080 0E RES,1K-1/8W J USM CX-ZL720

 14 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0077 88-121-102-080 0E RES,1K-1/8W J LHSM CX-ZL820
X MICON R 0078 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X MICON R 0078 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X MICON R 007 88-121-101-080 0E RES,100-1/8W J USM CX-ZL720
X MICON R 007 88-121-101-080 0E RES,100-1/8W J LHSM CX-ZL820
X MICON R 0080 88-121-101-080 0E RES,100-1/8W J USM CX-ZL720
X MICON R 0080 88-121-101-080 0E RES,100-1/8W J LHSM CX-ZL820
X MICON R 0081 88-121-102-080 0E RES,1K-1/8W J USM CX-ZL720
X MICON R 0081 88-121-102-080 0E RES,1K-1/8W J LHSM CX-ZL820
X MICON R 0083 88-121-101-080 0E RES,100-1/8W J USM CX-ZL720
X MICON R 0083 88-121-101-080 0E RES,100-1/8W J LHSM CX-ZL820
X MICON R 0084 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-ZL720
X MICON R 0084 88-108-101-080 0E C-RES,U 100-1/16W J LHSM CX-ZL820
X MICON R 0085 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-ZL720
X MICON R 0085 88-108-101-080 0E C-RES,U 100-1/16W J LHSM CX-ZL820
X MICON R 0087 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-ZL720
X MICON R 0087 88-108-222-080 0E C-RES,U 2.2K-1/16W J LHSM CX-ZL820
X MICON R 0088 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-ZL720
X MICON R 0088 88-108-222-080 0E C-RES,U 2.2K-1/16W J LHSM CX-ZL820
X MICON R 00 0 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-ZL720
X MICON R 00 0 88-108-103-080 0E C-RES,U 10K-1/16W J LHSM CX-ZL820
X MICON R 0101 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-ZL720
X MICON R 0101 88-108-104-080 0E C-RES,U 100K-1/16W J LHSM CX-ZL820
X MICON R 0104 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 0104 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 0105 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-ZL720
X MICON R 0105 88-108-222-080 0E C-RES,U 2.2K-1/16W J LHSM CX-ZL820
X MICON R 0106 88-108-471-080 0E C-RES,U 470-1/16W J USM CX-ZL720
X MICON R 0106 88-108-471-080 0E C-RES,U 470-1/16W J LHSM CX-ZL820
X MICON R 0111 88-108-124-080 0E C-RES,U 120K-1/16W J USM CX-ZL720
X MICON R 0111 88-108-124-080 0E C-RES,U 120K-1/16W J LHSM CX-ZL820
X MICON R 0112 88-108-333-080 0E C-RES,U 33K-1/16W J USM CX-ZL720
X MICON R 0112 88-108-333-080 0E C-RES,U 33K-1/16W J LHSM CX-ZL820
X MICON R 0113 88-108-153-080 0E C-RES,U 15K-1/16W J USM CX-ZL720
X MICON R 0113 88-108-153-080 0E C-RES,U 15K-1/16W J LHSM CX-ZL820
X MICON R 0114 88-121-472-080 0E RES,4.7K-1/8W J USM CX-ZL720
X MICON R 0114 88-121-472-080 0E RES,4.7K-1/8W J LHSM CX-ZL820
X MICON R 0115 88-108-224-080 0E C-RES,U 220K-1/16W J USM CX-ZL720
X MICON R 0115 88-108-224-080 0E C-RES,U 220K-1/16W J LHSM CX-ZL820
X MICON R 0116 88-121-224-080 0E RES,220K-1/8W J USM CX-ZL720
X MICON R 0116 88-121-224-080 0E RES,220K-1/8W J LHSM CX-ZL820
X MICON R 0121 88-108-100-080 0E C-RES,U 10-1/16W J USM CX-ZL720
X MICON R 0121 88-108-100-080 0E C-RES,U 10-1/16W J LHSM CX-ZL820
X MICON R 0122 88-108-681-080 0E C-RES,U 680-1/16W J USM CX-ZL720
X MICON R 0122 88-108-681-080 0E C-RES,U 680-1/16W J LHSM CX-ZL820
X MICON R 0123 88-121-472-080 0E RES,4.7K-1/8W J USM CX-ZL720
X MICON R 0123 88-121-472-080 0E RES,4.7K-1/8W J LHSM CX-ZL820
X MICON R 0124 88-108-681-080 0E C-RES,U 680-1/16W J USM CX-ZL720
X MICON R 0124 88-108-681-080 0E C-RES,U 680-1/16W J LHSM CX-ZL820
X MICON R 0125 88-121-472-080 0E RES,4.7K-1/8W J USM CX-ZL720
X MICON R 0125 88-121-472-080 0E RES,4.7K-1/8W J LHSM CX-ZL820
X MICON R 0126 88-108-100-080 0E C-RES,U 10-1/16W J USM CX-ZL720
X MICON R 0126 88-108-100-080 0E C-RES,U 10-1/16W J LHSM CX-ZL820
X MICON R 0131 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 0131 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 0133 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 0133 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 0135 88-121-102-080 0E RES,1K-1/8W J USM CX-ZL720
X MICON R 0135 88-121-102-080 0E RES,1K-1/8W J LHSM CX-ZL820
X MICON R 0136 88-121-102-080 0E RES,1K-1/8W J USM CX-ZL720
X MICON R 0136 88-121-102-080 0E RES,1K-1/8W J LHSM CX-ZL820
X MICON R 0137 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-ZL720
X MICON R 0137 88-108-101-080 0E C-RES,U 100-1/16W J LHSM CX-ZL820
X MICON R 0138 88-108-333-080 0E C-RES,U 33K-1/16W J USM CX-ZL720
X MICON R 0138 88-108-333-080 0E C-RES,U 33K-1/16W J LHSM CX-ZL820
X MICON R 013 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-ZL720
X MICON R 013 88-108-103-080 0E C-RES,U 10K-1/16W J LHSM CX-ZL820
X MICON R 0140 88-108-122-080 0E C-RES,U 1.2K-1/16W J USM CX-ZL720
X MICON R 0140 88-108-122-080 0E C-RES,U 1.2K-1/16W J LHSM CX-ZL820
X MICON R 0141 88-108-224-080 0E C-RES,U 220K-1/16W J USM CX-ZL720

 15 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0141 88-108-224-080 0E C-RES,U 220K-1/16W J LHSM CX-ZL820
X MICON R 0156 88-108-124-080 0E C-RES,U 120K-1/16W J USM CX-ZL720
X MICON R 0156 88-108-124-080 0E C-RES,U 120K-1/16W J LHSM CX-ZL820
X MICON R 0157 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-ZL720
X MICON R 0157 88-108-223-080 0E C-RES,U 22K-1/16W J LHSM CX-ZL820
X MICON R 0158 88-108-333-080 0E C-RES,U 33K-1/16W J USM CX-ZL720
X MICON R 0158 88-108-333-080 0E C-RES,U 33K-1/16W J LHSM CX-ZL820
X MICON R 0176 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-ZL720
X MICON R 0176 88-108-103-080 0E C-RES,U 10K-1/16W J LHSM CX-ZL820
X MICON R 01 7 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-ZL720
X MICON R 01 7 88-108-104-080 0E C-RES,U 100K-1/16W J LHSM CX-ZL820
X MICON R 0201 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X MICON R 0201 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X MICON R 0202 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X MICON R 0202 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X MICON R 0205 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X MICON R 0205 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X MICON R 0206 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X MICON R 0206 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X MICON R 020 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X MICON R 020 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X MICON R 0210 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X MICON R 0210 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X MICON R 0213 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X MICON R 0213 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X MICON R 0214 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X MICON R 0214 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X MICON R 0217 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X MICON R 0217 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X MICON R 0218 88-118-122-080 0E C-RES,S 1.2K-1/10W J USM CX-ZL720
X MICON R 0218 88-118-122-080 0E C-RES,S 1.2K-1/10W J LHSM CX-ZL820
X MICON R 0251 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-ZL720
X MICON R 0251 88-108-222-080 0E C-RES,U 2.2K-1/16W J LHSM CX-ZL820
X MICON R 0252 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-ZL720
X MICON R 0252 88-108-222-080 0E C-RES,U 2.2K-1/16W J LHSM CX-ZL820
X MICON R 0253 88-108-222-080 0E C-RES,U 2.2K-1/16W J USM CX-ZL720
X MICON R 0253 88-108-222-080 0E C-RES,U 2.2K-1/16W J LHSM CX-ZL820
X MICON R 0254 88-121-472-080 0E RES,4.7K-1/8W J USM CX-ZL720
X MICON R 0254 88-121-472-080 0E RES,4.7K-1/8W J LHSM CX-ZL820
X MICON R 0255 88-121-103-080 0E RES,10K-1/8W J USM CX-ZL720
X MICON R 0255 88-121-103-080 0E RES,10K-1/8W J LHSM CX-ZL820
X MICON R 0256 88-100-000-010 0E PLATING-JW, 0.58 SN 5 USM CX-ZL720
X MICON R 0256 88-100-000-010 0E PLATING-JW, 0.58 SN 5 LHSM CX-ZL820
X MICON R 0256 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-ZL720
X MICON R 0256 88-108-101-080 0E C-RES,U 100-1/16W J LHSM CX-ZL820
X MICON R 0351 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-ZL720
X MICON R 0351 88-108-103-080 0E C-RES,U 10K-1/16W J LHSM CX-ZL820
X MICON R 0352 88-121-561-080 0E RES,560-1/8W J USM CX-ZL720
X MICON R 0352 88-121-561-080 0E RES,560-1/8W J LHSM CX-ZL820
X MICON R 0353 88-108-10 -080 0E C-RES,U 1-1/16W J USM CX-ZL720
X MICON R 0353 88-108-10 -080 0E C-RES,U 1-1/16W J LHSM CX-ZL820
X MICON R 0354 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-ZL720
X MICON R 0354 88-108-103-080 0E C-RES,U 10K-1/16W J LHSM CX-ZL820
X MICON R 0355 88-121-222-080 0E RES,2.2K-1/8W J USM CX-ZL720
X MICON R 0355 88-121-222-080 0E RES,2.2K-1/8W J LHSM CX-ZL820
X MICON R 0356 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-ZL720
X MICON R 0356 88-108-103-080 0E C-RES,U 10K-1/16W J LHSM CX-ZL820
X MICON R 0357 88-121-222-080 0E RES,2.2K-1/8W J USM CX-ZL720
X MICON R 0357 88-121-222-080 0E RES,2.2K-1/8W J LHSM CX-ZL820
X MICON R 0361 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0361 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0363 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0363 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0366 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0366 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0367 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0367 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0368 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0368 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0371 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720

 16 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0371 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 0373 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 0373 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 0374 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 0374 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 0375 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 0375 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 0376 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 0376 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 0377 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 0377 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 0378 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 0378 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 037 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 037 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 0401 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-ZL720
X MICON R 0401 88-108-103-080 0E C-RES,U 10K-1/16W J LHSM CX-ZL820
X MICON R 0405 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-ZL720
X MICON R 0405 88-108-103-080 0E C-RES,U 10K-1/16W J LHSM CX-ZL820
X MICON R 0411 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-ZL720
X MICON R 0411 88-108-101-080 0E C-RES,U 100-1/16W J LHSM CX-ZL820
X MICON R 0412 88-108-563-080 0E C-RES,U 56K-1/16W J USM CX-ZL720
X MICON R 0412 88-108-563-080 0E C-RES,U 56K-1/16W J LHSM CX-ZL820
X MICON R 0421 88-108-682-080 0E C-RES,U 6.8K-1/16W J USM CX-ZL720
X MICON R 0421 88-108-682-080 0E C-RES,U 6.8K-1/16W J LHSM CX-ZL820
X MICON R 0422 88-108-152-080 0E C-RES,U 1.5K-1/16W J USM CX-ZL720
X MICON R 0422 88-108-152-080 0E C-RES,U 1.5K-1/16W J LHSM CX-ZL820
X MICON R 0423 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0423 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0424 88-108-183-080 0E C-RES,U 18K-1/16W J USM CX-ZL720
X MICON R 0424 88-108-183-080 0E C-RES,U 18K-1/16W J LHSM CX-ZL820
X MICON R 0425 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 0425 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 0441 88-121-223-080 0E RES,22K-1/8W J USM CX-ZL720
X MICON R 0441 88-121-223-080 0E RES,22K-1/8W J LHSM CX-ZL820
X MICON R 0442 88-121-101-080 0E RES,100-1/8W J USM CX-ZL720
X MICON R 0442 88-121-101-080 0E RES,100-1/8W J LHSM CX-ZL820
X MICON R 0 01 88-108-223-080 0E C-RES,U 22K-1/16W J USM CX-ZL720
X MICON R 0 01 88-108-223-080 0E C-RES,U 22K-1/16W J LHSM CX-ZL820
X MICON R 0 02 88-108-103-080 0E C-RES,U 10K-1/16W J USM CX-ZL720
X MICON R 0 02 88-108-103-080 0E C-RES,U 10K-1/16W J LHSM CX-ZL820
X MICON R 0 03 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 03 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 04 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 04 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 05 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 05 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 06 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 06 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 07 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 07 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 08 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 08 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 0 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 0 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 10 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 10 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 11 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 11 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 12 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 12 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 13 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-ZL720
X MICON R 0 13 88-108-683-080 0E C-RES,U 68K-1/16W J LHSM CX-ZL820
X MICON R 0 14 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-ZL720
X MICON R 0 14 88-108-683-080 0E C-RES,U 68K-1/16W J LHSM CX-ZL820
X MICON R 0 15 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-ZL720
X MICON R 0 15 88-108-683-080 0E C-RES,U 68K-1/16W J LHSM CX-ZL820
X MICON R 0 16 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-ZL720
X MICON R 0 16 88-108-683-080 0E C-RES,U 68K-1/16W J LHSM CX-ZL820
X MICON R 0 17 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-ZL720

 17 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0 17 88-108-683-080 0E C-RES,U 68K-1/16W J LHSM CX-ZL820
X MICON R 0 18 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-ZL720
X MICON R 0 18 88-108-683-080 0E C-RES,U 68K-1/16W J LHSM CX-ZL820
X MICON R 0 1 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-ZL720
X MICON R 0 1 88-108-683-080 0E C-RES,U 68K-1/16W J LHSM CX-ZL820
X MICON R 0 20 88-108-683-080 0E C-RES,U 68K-1/16W J USM CX-ZL720
X MICON R 0 20 88-108-683-080 0E C-RES,U 68K-1/16W J LHSM CX-ZL820
X MICON R 0 21 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 21 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 22 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 22 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 23 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 23 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 24 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 24 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 25 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 25 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 26 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 26 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 27 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 27 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 28 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 28 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 2 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 2 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 30 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 30 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 31 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 31 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 32 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 32 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 33 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 33 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 34 88-121-473-080 0E RES,47K-1/8W J USM CX-ZL720
X MICON R 0 34 88-121-473-080 0E RES,47K-1/8W J LHSM CX-ZL820
X MICON R 0 35 88-121-473-080 0E RES,47K-1/8W J USM CX-ZL720
X MICON R 0 35 88-121-473-080 0E RES,47K-1/8W J LHSM CX-ZL820
X MICON R 0 36 88-121-473-080 0E RES,47K-1/8W J USM CX-ZL720
X MICON R 0 36 88-121-473-080 0E RES,47K-1/8W J LHSM CX-ZL820
X MICON R 0 37 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 37 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 38 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 38 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 3 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 3 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 40 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 40 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 41 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 41 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 42 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 42 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 43 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 43 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 44 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 44 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 45 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 45 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 46 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 46 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 47 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 47 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 48 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 48 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 4 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 4 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 50 88-108-123-080 0E C-RES,U 12K-1/16W J USM CX-ZL720
X MICON R 0 50 88-108-123-080 0E C-RES,U 12K-1/16W J LHSM CX-ZL820
X MICON R 0 51 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720
X MICON R 0 51 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 52 88-108-473-080 0E C-RES,U 47K-1/16W J USM CX-ZL720

 18 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X MICON R 0 52 88-108-473-080 0E C-RES,U 47K-1/16W J LHSM CX-ZL820
X MICON R 0 53 88-108-104-080 0E C-RES,U 100K-1/16W J USM CX-ZL720
X MICON R 0 53 88-108-104-080 0E C-RES,U 100K-1/16W J LHSM CX-ZL820
X MICON R 1000 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 1000 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 1001 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 1001 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 1002 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-ZL720
X MICON R 1002 88-108-101-080 0E C-RES,U 100-1/16W J LHSM CX-ZL820
X MICON R 1003 88-108-272-080 0E C-RES,U 2.7K-1/16W J USM CX-ZL720
X MICON R 1003 88-108-272-080 0E C-RES,U 2.7K-1/16W J LHSM CX-ZL820
X MICON R 1004 88-108-101-080 0E C-RES,U 100-1/16W J USM CX-ZL720
X MICON R 1004 88-108-101-080 0E C-RES,U 100-1/16W J LHSM CX-ZL820
X MICON R 1005 88-108-272-080 0E C-RES,U 2.7K-1/16W J USM CX-ZL720
X MICON R 1005 88-108-272-080 0E C-RES,U 2.7K-1/16W J LHSM CX-ZL820
X MICON R 1006 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 1006 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 1007 88-108-102-080 0E C-RES,U 1K-1/16W J USM CX-ZL720
X MICON R 1007 88-108-102-080 0E C-RES,U 1K-1/16W J LHSM CX-ZL820
X MICON R 1008 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X MICON R 1008 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X MICON R 100 88-108-000-080 0E C-JUMPER,U USM CX-ZL720
X MICON R 100 88-108-000-080 0E C-JUMPER,U LHSM CX-ZL820
X MICON R 1010 88-108-563-080 0E C-RES,U 56K-1/16W J USM CX-ZL720
X MICON R 1010 88-108-563-080 0E C-RES,U 56K-1/16W J LHSM CX-ZL820
O MICON S 0421 87-A 2-071-010 -- SW,RTRY EC12E24508-30MM USM CX-ZL720
O MICON S 0421 87-A 2-071-010 -- SW,RTRY EC12E24508-30MM LHSM CX-ZL820
! O OTHERS 82-NF5-22 -010 0E PLATE,LOCK(*) USM CX-ZL720
! O OTHERS 82-NF5-22 -010 0E PLATE,LOCK(*) LHSM CX-ZL820
O OTHERS 86-NF -224-010 0E SPR-C,LOCK USM CX-ZL720
O OTHERS 86-NF -224-010 0E SPR-C,LOCK LHSM CX-ZL820
X OTHERS 87-063-173-010 0E CLOTH, N 2 5B BLK 30-10-0.35 USM CX-ZL720
X OTHERS 87-063-173-010 0E CLOTH, N 2 5B BLK 30-10-0.35 LHSM CX-ZL820
O OTHERS 87-064-185-010 0E HLDR,WIRE PVC 0.5 USM CX-ZL720
O OTHERS 87-064-185-010 0E HLDR,WIRE PVC 0.5 LHSM CX-ZL820
X OTHERS 87-B40-142-010 0E SH, 12-8.5-2 W/ADH FOOT EEA USM CX-ZL720
X OTHERS 87-B40-142-010 0E SH, 12-8.5-2 W/ADH FOOT EEA LHSM CX-ZL820
O OTHERS 87-MA3-062-010 0E FOOT, H17 USM CX-ZL720
O OTHERS 87-MA3-062-010 0E FOOT, H17 LHSM CX-ZL820
! O OTHERS 87-NF4-216-010 0E HLDR,LOCK 1 USM CX-ZL720
! O OTHERS 87-NF4-216-010 0E HLDR,LOCK 1 LHSM CX-ZL820
! O OTHERS 87-NF4-217-110 0E HLDR,LOCK 2 USM CX-ZL720
! O OTHERS 87-NF4-217-110 0E HLDR,LOCK 2 LHSM CX-ZL820
! O OTHERS 87-NF4-221-010 0E HLDR,CABLE USM CX-ZL720
! O OTHERS 87-NF4-221-010 0E HLDR,CABLE LHSM CX-ZL820
! O OTHERS 87-NF8-220-010 0E DMPR,150 USM CX-ZL720
! O OTHERS 87-NF8-220-010 0E DMPR,150 LHSM CX-ZL820
O OTHERS 88-MA1-208-210 1A JOINT,CABI USM CX-ZL720
O OTHERS 88-MA1-208-210 1A JOINT,CABI LHSM CX-ZL820
X OTHERS 8A-MA3-208-110 1B PLATE,PT USM CX-ZL720
X OTHERS 8A-MA3-208-110 1B PLATE,PT LHSM CX-ZL820
O OTHERS 8A-MA5-207-010 0E SPR-T,EJECT 1 USM CX-ZL720
O OTHERS 8A-MA5-207-010 0E SPR-T,EJECT 1 LHSM CX-ZL820
O OTHERS 8A-MA5-208-010 0E SPR-T,EJECT 2 USM CX-ZL720
O OTHERS 8A-MA5-208-010 0E SPR-T,EJECT 2 LHSM CX-ZL820
O OTHERS 8B-MA3-202-010 -- HLDR,HT-SINK USM CX-ZL720
O OTHERS 8B-MA3-202-010 -- HLDR,HT-SINK LHSM CX-ZL820
! O OTHERS * 8A-DB8-20 -010 0E HLDR,PWB PT USM CX-ZL720
! O OTHERS * 8A-DB8-20 -010 0E HLDR,PWB PT LHSM CX-ZL820
X OTHERS * 8B-MA3-203-010 -- HT-SINK,MAIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-203-010 -- HT-SINK,MAIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720

 19 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 USM CX-ZL720
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-204-010 -- HT-SINK,FIN A3 LHSM CX-ZL820
O OTHERS * 8B-MA3-205-010 -- GUIDE,LED DIRECT USM CX-ZL720
O OTHERS * 8B-MA3-205-010 -- GUIDE,LED DIRECT LHSM CX-ZL820
O OTHERS * 8B-MA3-206-010 -- GUIDE,LED OPE USM CX-ZL720
O OTHERS * 8B-MA3-206-010 -- GUIDE,LED OPE LHSM CX-ZL820
O OTHERS * 8B-MA3-207-010 -- HLDR,TR A3 USM CX-ZL720
O OTHERS * 8B-MA3-207-010 -- HLDR,TR A3 LHSM CX-ZL820
X OTHERS * 8B-MA3-208-010 -- HT-SINK ASSY,A USM CX-ZL720
X OTHERS * 8B-MA3-208-010 -- HT-SINK ASSY,A LHSM CX-ZL820
X OTHERS * 8B-MA3-210-010 -- SH,TR VM USM CX-ZL720
X OTHERS * 8B-MA3-210-010 -- SH,TR VM LHSM CX-ZL820
! X P-AMP(FRONT/LF) 87-A 0-267-010 0E HLDR,WIRE(U)2.5 -4P USM CX-ZL720
O P-AMP(FRONT/LF) C 0101 87-012-27 -080 0E C-CAP,U 2700P-50 K B GRM USM CX-ZL720
O P-AMP(FRONT/LF) C 0101 87-012-27 -080 0E C-CAP,U 2700P-50 K B GRM LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0102 87-012-27 -080 0E C-CAP,U 2700P-50 K B GRM USM CX-ZL720
O P-AMP(FRONT/LF) C 0102 87-012-27 -080 0E C-CAP,U 2700P-50 K B GRM LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0103 87-A12-0 0-080 0E CAP,E 4.7-50 SMG USM CX-ZL720
O P-AMP(FRONT/LF) C 0103 87-A12-0 0-080 0E CAP,E 4.7-50 SMG LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0104 87-A12-0 0-080 0E CAP,E 4.7-50 SMG USM CX-ZL720
O P-AMP(FRONT/LF) C 0104 87-A12-0 0-080 0E CAP,E 4.7-50 SMG LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0107 87-A12-0 1-080 0E CAP,E 10-50 SMG USM CX-ZL720
O P-AMP(FRONT/LF) C 0107 87-A12-0 1-080 0E CAP,E 10-50 SMG LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0108 87-A12-0 1-080 0E CAP,E 10-50 SMG USM CX-ZL720
O P-AMP(FRONT/LF) C 0108 87-A12-0 1-080 0E CAP,E 10-50 SMG LHSM CX-ZL820
O P-AMP(FRONT/LF) C 010 87-012-1 -080 0E C-CAP,U 220P-50 J CH USM CX-ZL720
O P-AMP(FRONT/LF) C 010 87-012-1 -080 0E C-CAP,U 220P-50 J CH LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0110 87-012-1 -080 0E C-CAP,U 220P-50 J CH USM CX-ZL720
O P-AMP(FRONT/LF) C 0110 87-012-1 -080 0E C-CAP,U 220P-50 J CH LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0111 87-010-3 2-080 0E CAP,E 33-35 M 11L SME USM CX-ZL720
O P-AMP(FRONT/LF) C 0111 87-010-3 2-080 0E CAP,E 33-35 M 11L SME LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0112 87-010-3 2-080 0E CAP,E 33-35 M 11L SME USM CX-ZL720
O P-AMP(FRONT/LF) C 0112 87-010-3 2-080 0E CAP,E 33-35 M 11L SME LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0113 87-A10-5 6-080 0E C-CAP,S 100P-100 J CH USM CX-ZL720
O P-AMP(FRONT/LF) C 0113 87-A10-5 6-080 0E C-CAP,S 100P-100 J CH LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0114 87-A10-5 6-080 0E C-CAP,S 100P-100 J CH USM CX-ZL720
O P-AMP(FRONT/LF) C 0114 87-A10-5 6-080 0E C-CAP,S 100P-100 J CH LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0115 87-012-167-080 0E C-CAP,U 5P-50 C CH USM CX-ZL720
O P-AMP(FRONT/LF) C 0115 87-012-167-080 0E C-CAP,U 5P-50 C CH LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0116 87-012-167-080 0E C-CAP,U 5P-50 C CH USM CX-ZL720
O P-AMP(FRONT/LF) C 0116 87-012-167-080 0E C-CAP,U 5P-50 C CH LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0117 87-A12-317-080 0E C-CAP,U 0.1-50 Z F USM CX-ZL720
O P-AMP(FRONT/LF) C 0117 87-A12-317-080 0E C-CAP,U 0.1-50 Z F LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0118 87-A12-317-080 0E C-CAP,U 0.1-50 Z F USM CX-ZL720
O P-AMP(FRONT/LF) C 0118 87-A12-317-080 0E C-CAP,U 0.1-50 Z F LHSM CX-ZL820
O P-AMP(FRONT/LF) C 011 87-A12-317-080 0E C-CAP,U 0.1-50 Z F USM CX-ZL720
O P-AMP(FRONT/LF) C 011 87-A12-317-080 0E C-CAP,U 0.1-50 Z F LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0120 87-A12-317-080 0E C-CAP,U 0.1-50 Z F USM CX-ZL720
O P-AMP(FRONT/LF) C 0120 87-A12-317-080 0E C-CAP,U 0.1-50 Z F LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0121 87-A12-0 0-080 0E CAP,E 4.7-50 SMG USM CX-ZL720
O P-AMP(FRONT/LF) C 0121 87-A12-0 0-080 0E CAP,E 4.7-50 SMG LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0122 87-A12-0 0-080 0E CAP,E 4.7-50 SMG USM CX-ZL720
O P-AMP(FRONT/LF) C 0122 87-A12-0 0-080 0E CAP,E 4.7-50 SMG LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0123 87-010- 86-080 0E C-CAP,S 820P-50 J CH USM CX-ZL720
O P-AMP(FRONT/LF) C 0123 87-010- 86-080 0E C-CAP,S 820P-50 J CH LHSM CX-ZL820

 20 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O P-AMP(FRONT/LF) C 0124 87-010- 86-080 0E C-CAP,S 820P-50 J CH USM CX-ZL720
O P-AMP(FRONT/LF) C 0124 87-010- 86-080 0E C-CAP,S 820P-50 J CH LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0133 87-012-282-080 0E C-CAP,U 4700P-50 K B USM CX-ZL720
O P-AMP(FRONT/LF) C 0133 87-012-282-080 0E C-CAP,U 4700P-50 K B LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0140 87-012-278-080 0E C-CAP,U 2200P-50 K B USM CX-ZL720
O P-AMP(FRONT/LF) C 0140 87-012-278-080 0E C-CAP,U 2200P-50 K B LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0186 87-010-75 -080 0E C-CAP,U 0.1-25 Z F USM CX-ZL720
O P-AMP(FRONT/LF) C 0186 87-010-75 -080 0E C-CAP,U 0.1-25 Z F LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0187 87-A10-11 -080 0E CAP,E 10-100 REA USM CX-ZL720
O P-AMP(FRONT/LF) C 0187 87-A10-11 -080 0E CAP,E 10-100 REA LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0188 87-A10-11 -080 0E CAP,E 10-100 REA USM CX-ZL720
O P-AMP(FRONT/LF) C 0188 87-A10-11 -080 0E CAP,E 10-100 REA LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0225 87-A12-317-080 0E C-CAP,U 0.1-50 Z F USM CX-ZL720
O P-AMP(FRONT/LF) C 0225 87-A12-317-080 0E C-CAP,U 0.1-50 Z F LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0226 87-A12-317-080 0E C-CAP,U 0.1-50 Z F USM CX-ZL720
O P-AMP(FRONT/LF) C 0226 87-A12-317-080 0E C-CAP,U 0.1-50 Z F LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0227 87-A12-317-080 0E C-CAP,U 0.1-50 Z F USM CX-ZL720
O P-AMP(FRONT/LF) C 0227 87-A12-317-080 0E C-CAP,U 0.1-50 Z F LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0228 87-A12-317-080 0E C-CAP,U 0.1-50 Z F USM CX-ZL720
O P-AMP(FRONT/LF) C 0228 87-A12-317-080 0E C-CAP,U 0.1-50 Z F LHSM CX-ZL820
O P-AMP(FRONT/LF) C 022 87-012-287-080 0E C-CAP,U 0.015-25 Z F USM CX-ZL720
O P-AMP(FRONT/LF) C 022 87-012-287-080 0E C-CAP,U 0.015-25 Z F LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0230 87-012-287-080 0E C-CAP,U 0.015-25 Z F USM CX-ZL720
O P-AMP(FRONT/LF) C 0230 87-012-287-080 0E C-CAP,U 0.015-25 Z F LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0231 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-ZL720
O P-AMP(FRONT/LF) C 0231 87-012-286-080 0E C-CAP,U 0.01-25 K B LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0232 87-012-286-080 0E C-CAP,U 0.01-25 K B USM CX-ZL720
O P-AMP(FRONT/LF) C 0232 87-012-286-080 0E C-CAP,U 0.01-25 K B LHSM CX-ZL820
O P-AMP(FRONT/LF) C 0241 87-010-75 -080 0E C-CAP,U 0.1-25 Z F USM CX-ZL720
O P-AMP(FRONT/LF) C 0241 87-010-75 -080 0E C-CAP,U 0.1-25 Z F LHSM CX-ZL820
! O P-AMP(FRONT/LF) CN 0201 87-A61-108-010 0E CONN,5P V TID-A USM CX-ZL720
! O P-AMP(FRONT/LF) CN 0202 87-0 -043-010 0E CONN,2P V WHT EH USM CX-ZL720
O P-AMP(FRONT/LF) CNA0201 8B-MA3-656-010 -- CONN ASSY,5P TID-A(400)BMA3 USM CX-ZL720
O P-AMP(FRONT/LF) CNA0202 8A-NHP-643-010 0E CONN ASSY,2P (FAN)ANHP-3 0 USM CX-ZL720
S P-AMP(FRONT/LF) D 0101 87-A40-26 -080 0E C-DIODE,MC2836 USM CX-ZL720
S P-AMP(FRONT/LF) D 0101 87-A40-26 -080 0E C-DIODE,MC2836 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0103 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S P-AMP(FRONT/LF) D 0103 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0104 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S P-AMP(FRONT/LF) D 0104 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0105 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S P-AMP(FRONT/LF) D 0105 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0106 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S P-AMP(FRONT/LF) D 0106 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0107 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S P-AMP(FRONT/LF) D 0107 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0108 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S P-AMP(FRONT/LF) D 0108 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0115 87-A40-270-080 0E C-DIODE,MC2838 USM CX-ZL720
S P-AMP(FRONT/LF) D 0115 87-A40-270-080 0E C-DIODE,MC2838 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0117 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S P-AMP(FRONT/LF) D 0117 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0118 87-020-465-080 0E DIODE,1SS133 USM CX-ZL720
S P-AMP(FRONT/LF) D 0118 87-020-465-080 0E DIODE,1SS133 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0150 87-A40-270-080 0E C-DIODE,MC2838 USM CX-ZL720
S P-AMP(FRONT/LF) D 0150 87-A40-270-080 0E C-DIODE,MC2838 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0160 87-A40-270-080 0E C-DIODE,MC2838 USM CX-ZL720
S P-AMP(FRONT/LF) D 0160 87-A40-270-080 0E C-DIODE,MC2838 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0185 87-A40-646-010 1B DIODE,FMB-G16L USM CX-ZL720
S P-AMP(FRONT/LF) D 0185 87-A40-646-010 1B DIODE,FMB-G16L LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0186 87-A40-646-010 1B DIODE,FMB-G16L USM CX-ZL720
S P-AMP(FRONT/LF) D 0186 87-A40-646-010 1B DIODE,FMB-G16L LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0187 87-A40-002-080 0E ZENER,MTZJ5.1C USM CX-ZL720
S P-AMP(FRONT/LF) D 0187 87-A40-002-080 0E ZENER,MTZJ5.1C LHSM CX-ZL820
S P-AMP(FRONT/LF) D 0188 87-A40-74 -080 0E ZENER,UZ5.6BSB USM CX-ZL720
S P-AMP(FRONT/LF) D 0188 87-A40-74 -080 0E ZENER,UZ5.6BSB LHSM CX-ZL820
S P-AMP(FRONT/LF) D 018 87-A40-270-080 0E C-DIODE,MC2838 USM CX-ZL720
S P-AMP(FRONT/LF) D 018 87-A40-270-080 0E C-DIODE,MC2838 LHSM CX-ZL820
S P-AMP(FRONT/LF) D 01 0 87-A40-26 -080 0E C-DIODE,MC2836 USM CX-ZL720
S P-AMP(FRONT/LF) D 01 0 87-A40-26 -080 0E C-DIODE,MC2836 LHSM CX-ZL820
