SERVICE MANUAL
DATA
NSX-SZ2E HA
SIMPLE
S/M Code No. 09-00A-433-7T3
• Replace this Service manual with “Revision Publishing” when it is issued.
COMPACT DISC STEREO
SYSTEM BASIC TAPE MECHANISM: ZZM-2 APR1NC BASIC CD MECHANISM: 3ZG-3 E8NC

PARTS LIST
-2-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
O AC FC 0101 87-033-213-080 0E FUSE CLAMP,PFC5000 HSC1NC1 CX-NSZ2E
O AC FC 0102 87-033-213-080 0E FUSE CLAMP,PFC5000 HSC1NC1 CX-NSZ2E
! O AC S 0001 87-A90-165-010 1A SW,SL 1-2-3 SWS2301 HSC1NC1 CX-NSZ2E
O AC T 0101 87-A60-317-010 0E TERMINAL, 1P MSC HSC1NC1 CX-NSZ2E
O AC T 0102 87-A60-317-010 0E TERMINAL, 1P MSC HSC1NC1 CX-NSZ2E
O ACCESSORY 87-043-115-010 1A FEEDER-ANT,FM HSC1NC1 CX-NSZ2E
O ACCESSORY 87-A90-030-010 1B ANT,LOOP AM-NC C HSC1NC1 CX-NSZ2E
O ACCESSORY 8A-NEC-701-010 1E RC UNIT,RC-AAS08 HSC1NC1 CX-NSZ2E
! O APPEARANCE 87-B00-002-010 0E BADGE,AIWA 30 ABS SIL HSC1NC1 CX-NSZ2E
O APPEARANCE 8A-NEC-001-010 1E CABI,FR HSC1NC1 CX-NSZ2E
O APPEARANCE 8A-NEC-002-010 1B BOX,CASS 1 HSC1NC1 CX-NSZ2E
O APPEARANCE 8A-NEC-003-010 1A BOX,CASS 2 HSC1NC1 CX-NSZ2E
O APPEARANCE 8A-NEC-004-010 1A PANEL,TRAY CD HSC1NC1 CX-NSZ2E
O APPEARANCE 8A-NEC-013-010 1B PANEL,LEFT HSC1NC1 CX-NSZ2E
O APPEARANCE 8A-NEC-014-010 1B PANEL,RIGHT HSC1NC1 CX-NSZ2E
O APPEARANCE 8A-NEC-015-010 1C PANEL,TOP HSC1NC1 CX-NSZ2E
O APPEARANCE 8A-NEC-030-110 1B CABI,REAR LH W/O SPEC HSC1NC1 CX-NSZ2E
X CD M8-3ZG-38C-070 — 3ZG-3 YE8NC HSC1NC1 CX-NSZ2E
O CD DRIVER C 0371 87-010-221-080 0E CAP,E 470-10 M SME HSC1NC1 CX-NSZ2E
O CD DRIVER C 0372 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DRIVER C 0373 87-010-544-080 0E CAP,E 0.1-50 M 11L SME HSC1NC1 CX-NSZ2E
O CD DRIVER C 0374 87-010-236-080 0E CAP,E 1000-10 M SME HSC1NC1 CX-NSZ2E
O CD DRIVER C 0375 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DRIVER C 0376 87-010-263-080 0E CAP,E 100-10 M 11L SME HSC1NC1 CX-NSZ2E
O CD DRIVER C 0377 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DRIVER C 0378 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DRIVER C 0379 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DRIVER C 0380 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DRIVER C 0381 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DRIVER C 0382 87-016-369-080 0E C-CAP,S 0.033-25 K B GRM HSC1NC1 CX-NSZ2E
O CD DRIVER C 0391 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O CD DRIVER C 0392 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O CD DRIVER C 0393 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O CD DRIVER C 0394 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O CD DRIVER C 0395 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O CD DRIVER C 0396 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
! O CD DRIVER CN 0302 87-099-194-010 0E CONN,6P V BLK 6216 HSC1NC1 CX-NSZ2E
S CD DRIVER IC 0303 87-A21-722-010 1D IC,LA6548D HSC1NC1 CX-NSZ2E
S CD DRIVER Q 0306 87-026-609-080 0E TR,KTA1266GR HSC1NC1 CX-NSZ2E
X CD DRIVER R 0371 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0372 88-128-229-080 0E C-RES, 2.2-1/8W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0373 88-121-561-080 0E RES,560-1/8W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0375 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0376 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0377 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0378 88-118-683-080 0E C-RES,S 68K-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0379 88-118-272-080 0E C-RES,S 2.7K-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0380 88-118-683-080 0E C-RES,S 68K-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0381 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0382 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0383 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X CD DRIVER R 0384 88-118-683-080 0E C-RES,S 68K-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0385 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0386 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0387 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0388 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0389 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0390 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0391 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0392 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0393 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0394 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0395 88-118-222-080 0E C-RES,S 2.2K-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0396 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X CD DRIVER R 0397 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
O CD DSP C 0331 87-A10-504-080 0E C-CAP,U 0.047-16 K B HSC1NC1 CX-NSZ2E
O CD DSP C 0332 87-010-401-080 0E CAP,E 1-50 M 11L SME HSC1NC1 CX-NSZ2E
O CD DSP C 0333 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DSP C 0334 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DSP C 0335 87-010-260-080 0E CAP,E 47-25 M 11L SME HSC1NC1 CX-NSZ2E

PARTS LIST
-3-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
O CD DSP C 0336 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O CD DSP C 0337 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DSP C 0338 87-012-282-080 0E C-CAP,U 4700P-50 K B HSC1NC1 CX-NSZ2E
O CD DSP C 0339 87-A10-504-080 0E C-CAP,U 0.047-16 K B HSC1NC1 CX-NSZ2E
O CD DSP C 0340 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O CD DSP C 0341 87-010-260-080 0E CAP,E 47-25 M 11L SME HSC1NC1 CX-NSZ2E
O CD DSP C 0342 87-012-286-080 0E C-CAP,U 0.01-25 K B HSC1NC1 CX-NSZ2E
O CD DSP C 0344 87-010-260-080 0E CAP,E 47-25 M 11L SME HSC1NC1 CX-NSZ2E
O CD DSP C 0345 87-012-286-080 0E C-CAP,U 0.01-25 K B HSC1NC1 CX-NSZ2E
O CD DSP C 0346 87-010-248-080 0E CAP,E 220-10 M 11L SME HSC1NC1 CX-NSZ2E
O CD DSP C 0347 87-012-286-080 0E C-CAP,U 0.01-25 K B HSC1NC1 CX-NSZ2E
O CD DSP C 0348 87-010-263-080 0E CAP,E 100-10 M 11L SME HSC1NC1 CX-NSZ2E
O CD DSP C 0349 87-012-286-080 0E C-CAP,U 0.01-25 K B HSC1NC1 CX-NSZ2E
O CD DSP C 0350 87-012-176-080 0E C-CAP,U 15P-50 J CH HSC1NC1 CX-NSZ2E
O CD DSP C 0351 87-012-176-080 0E C-CAP,U 15P-50 J CH HSC1NC1 CX-NSZ2E
O CD DSP C 0352 87-010-404-080 0E CAP,E 4.7-50 M 11L SME HSC1NC1 CX-NSZ2E
O CD DSP C 0353 87-012-286-080 0E C-CAP,U 0.01-25 K B HSC1NC1 CX-NSZ2E
O CD DSP C 0354 87-010-401-080 0E CAP,E 1-50 M 11L SME HSC1NC1 CX-NSZ2E
O CD DSP C 0355 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DSP C 0356 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DSP C 0357 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD DSP C 0358 87-010-405-080 0E CAP,E 10-50 M 11L SME HSC1NC1 CX-NSZ2E
O CD DSP C 0359 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O CD DSP C 0360 87-012-349-080 0E C-CAP,S 1000P-50 J CH GRM HSC1NC1 CX-NSZ2E
O CD DSP C 0361 87-010-544-080 0E CAP,E 0.1-50 M 11L SME HSC1NC1 CX-NSZ2E
O CD DSP C 0362 87-010-544-080 0E CAP,E 0.1-50 M 11L SME HSC1NC1 CX-NSZ2E
O CD DSP C 0363 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
S CD DSP D 0302 87-A40-747-080 0E ZENER,UZ5.1BSB HSC1NC1 CX-NSZ2E
S CD DSP D 0303 87-A40-743-080 0E ZENER,UZ4.3BSA HSC1NC1 CX-NSZ2E
S CD DSP IC 0302 87-A21-591-010 2A C-IC,LC78641NE-D HSC1NC1 CX-NSZ2E
S CD DSP Q 0305 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
X CD DSP R 0331 88-118-681-080 0E C-RES,S 680-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0332 88-118-681-080 0E C-RES,S 680-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0333 88-118-395-080 0E C-RES,S 3.9M-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0334 88-118-123-080 0E C-RES,S 12K-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0335 88-118-122-080 0E C-RES,S 1.2K-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0336 88-118-272-080 0E C-RES,S 2.7K-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0337 88-100-000-010 0E PLATING-JW, 0.58 SN95 HSC1NC1 CX-NSZ2E
X CD DSP R 0338 88-118-331-080 0E C-RES,S 330-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0339 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0340 88-100-000-010 0E PLATING-JW, 0.58 SN95 HSC1NC1 CX-NSZ2E
X CD DSP R 0341 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X CD DSP R 0342 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0343 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0344 88-128-104-080 0E C-RES, 100K-1/8W J HSC1NC1 CX-NSZ2E
X CD DSP R 0345 88-118-473-080 0E C-RES,S 47K-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0346 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X CD DSP R 0347 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X CD DSP R 0348 88-118-105-080 0E C-RES,S 1M-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0349 88-100-000-010 0E PLATING-JW, 0.58 SN95 HSC1NC1 CX-NSZ2E
X CD DSP R 0350 88-100-000-010 0E PLATING-JW, 0.58 SN95 HSC1NC1 CX-NSZ2E
X CD DSP R 0351 88-100-000-010 0E PLATING-JW, 0.58 SN95 HSC1NC1 CX-NSZ2E
X CD DSP R 0353 88-128-470-080 0E C-RES, 47-1/8W J HSC1NC1 CX-NSZ2E
X CD DSP R 0354 88-128-152-080 0E C-RES, 1.5K-1/8W J HSC1NC1 CX-NSZ2E
X CD DSP R 0355 88-128-152-080 0E C-RES, 1.5K-1/8W J HSC1NC1 CX-NSZ2E
X CD DSP R 0356 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X CD DSP R 0357 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0358 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0359 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0360 88-128-152-080 0E C-RES, 1.5K-1/8W J HSC1NC1 CX-NSZ2E
X CD DSP R 0361 88-128-152-080 0E C-RES, 1.5K-1/8W J HSC1NC1 CX-NSZ2E
X CD DSP R 0363 88-118-222-080 0E C-RES,S 2.2K-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0364 88-118-222-080 0E C-RES,S 2.2K-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0365 88-118-473-080 0E C-RES,S 47K-1/10W J HSC1NC1 CX-NSZ2E
X CD DSP R 0366 88-118-683-080 0E C-RES,S 68K-1/10W J HSC1NC1 CX-NSZ2E
O CD DSP X 0301 87-A70-046-010 1B VIB,XTAL 16.934MHZ HSC1NC1 CX-NSZ2E
O CD RF AMP C 0301 87-010-374-080 0E CAP,E 47-10 M 11L SME HSC1NC1 CX-NSZ2E
O CD RF AMP C 0302 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O CD RF AMP C 0303 87-010-260-080 0E CAP,E 47-25 M 11L SME HSC1NC1 CX-NSZ2E
O CD RF AMP C 0304 87-010-260-080 0E CAP,E 47-25 M 11L SME HSC1NC1 CX-NSZ2E

PARTS LIST
-4-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
O CD RF AMP C 0305 87-012-286-080 0E C-CAP,U 0.01-25 K B HSC1NC1 CX-NSZ2E
O CD RF AMP C 0306 87-010-405-080 0E CAP,E 10-50 M 11L SME HSC1NC1 CX-NSZ2E
O CD RF AMP C 0307 87-010-263-080 0E CAP,E 100-10 M 11L SME HSC1NC1 CX-NSZ2E
O CD RF AMP C 0308 87-012-349-080 0E C-CAP,S 1000P-50 J CH GRM HSC1NC1 CX-NSZ2E
O CD RF AMP C 0309 87-010-546-080 0E CAP,E 0.33-50 M 11L SME HSC1NC1 CX-NSZ2E
O CD RF AMP C 0310 87-010-401-080 0E CAP,E 1-50 M 11L SME HSC1NC1 CX-NSZ2E
O CD RF AMP C 0311 87-012-193-080 0E C-CAP,U 82P-50 J CH HSC1NC1 CX-NSZ2E
O CD RF AMP C 0312 87-012-286-080 0E C-CAP,U 0.01-25 K B HSC1NC1 CX-NSZ2E
O CD RF AMP C 0313 87-010-260-080 0E CAP,E 47-25 M 11L SME HSC1NC1 CX-NSZ2E
! O CD RF AMP CN 0301 87-A60-424-010 0E CONN,16P V TOC-B HSC1NC1 CX-NSZ2E
S CD RF AMP IC 0301 87-A21-381-040 1E C-IC,LA9235M HSC1NC1 CX-NSZ2E
S CD RF AMP Q 0301 87-026-609-080 0E TR,KTA1266GR HSC1NC1 CX-NSZ2E
S CD RF AMP Q 0302 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
S CD RF AMP Q 0303 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
S CD RF AMP Q 0304 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
X CD RF AMP R 0301 88-118-223-080 0E C-RES,S 22K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0302 88-118-223-080 0E C-RES,S 22K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0303 88-118-223-080 0E C-RES,S 22K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0304 88-118-223-080 0E C-RES,S 22K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0305 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0306 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0307 88-118-820-080 0E C-RES,S 82-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0308 88-121-479-080 0E RES,4.7-1/8W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0309 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X CD RF AMP R 0310 88-118-472-080 0E C-RES,S 4.7K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0311 88-118-472-080 0E C-RES,S 4.7K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0312 88-118-272-080 0E C-RES,S 2.7K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0313 88-118-152-080 0E C-RES,S 1.5K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0314 88-118-822-080 0E C-RES,S 8.2K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0315 88-118-472-080 0E C-RES,S 4.7K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0316 88-118-153-080 0E C-RES,S 15K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0317 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0318 88-118-123-080 0E C-RES,S 12K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0319 88-118-122-080 0E C-RES,S 1.2K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0320 88-118-561-080 0E C-RES,S 560-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0321 88-118-122-080 0E C-RES,S 1.2K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0322 88-118-472-080 0E C-RES,S 4.7K-1/10W J HSC1NC1 CX-NSZ2E
X CD RF AMP R 0323 88-118-472-080 0E C-RES,S 4.7K-1/10W J HSC1NC1 CX-NSZ2E
! X ELECTRICAL 87-069-033-010 0E CABLE,TIE HSC1NC1 CX-NSZ2E
! O ELECTRICAL 87-A80-105-010 1C AC CORD ASSY,AZ HSC1NC1 CX-NSZ2E
O ELECTRICAL 88-905-151-110 0E FF-CABLE,5P 1.25 150MM HSC1NC1 CX-NSZ2E
O ELECTRICAL 88-906-151-110 0E FF-CABLE, 6P 1.25 HSC1NC1 CX-NSZ2E
O ELECTRICAL 8A-NEC-603-010 0E FF-CABLE,16P -1.0 HSC1NC1 CX-NSZ2E
! S ELECTRICAL F 0101 87-035-360-010 1A FUSE,630MA 250V T HSC1NC1 CX-NSZ2E
! O ELECTRICAL PT 0001 8A-NEC-609-010 2M PT,ANE-C LH HSC1NC1 CX-NSZ2E
! O FRCB MECHA * 8A-NFA-208-010 0E GUIDE,FL 100-25 ANFA HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0605 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0606 87-012-275-080 0E C-CAP,U 1200P-50 K B GRM HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0609 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0610 87-010-785-080 0E C-CAP,U 0.015-25 K B GRM HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0611 87-010-545-080 0E CAP,E 0.22-50 M 11L SME HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0612 87-010-545-080 0E CAP,E 0.22-50 M 11L SME HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0613 87-010-545-080 0E CAP,E 0.22-50 M 11L SME HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0614 87-010-545-080 0E CAP,E 0.22-50 M 11L SME HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0615 87-012-172-080 0E C-CAP,U 10P-50 D CH HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0616 87-010-248-080 0E CAP,E 220-10 M 11L SME HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0617 87-010-221-080 0E CAP,E 470-10 M SME HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0618 87-010-405-080 0E CAP,E 10-50 M 11L SME HSC1NC1 CX-NSZ2E
O FUNC/E.VR C 0630 87-A10-248-080 0E C-CAP,U 0.1-16 K BR HSC1NC1 CX-NSZ2E
X FUNC/E.VR C 0678 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
S FUNC/E.VR D 0601 87-A40-739-080 0E ZENER,UZ2.7BSA HSC1NC1 CX-NSZ2E
S FUNC/E.VR D 0602 87-A40-739-080 0E ZENER,UZ2.7BSA HSC1NC1 CX-NSZ2E
S FUNC/E.VR IC 0601 87-A21-443-040 1C C-IC,M62495AFP HSC1NC1 CX-NSZ2E
O FUNC/E.VR J 0602 87-A60-881-010 0E JACK,PIN 2P MSP 242V05 PBSN HSC1NC1 CX-NSZ2E
X FUNC/E.VR JR 0601 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
S FUNC/E.VR Q 0605 87-A30-090-080 0E FET,2SK2541 HSC1NC1 CX-NSZ2E
S FUNC/E.VR Q 0606 87-A30-090-080 0E FET,2SK2541 HSC1NC1 CX-NSZ2E
S FUNC/E.VR Q 0607 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0590 88-121-472-080 0E RES,4.7K-1/8W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0599 88-121-472-080 0E RES,4.7K-1/8W J HSC1NC1 CX-NSZ2E

PARTS LIST
-5-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X FUNC/E.VR R 0601 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0602 88-121-102-080 0E RES,1K-1/8W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0603 88-118-682-080 0E C-RES,S 6.8K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0604 88-118-682-080 0E C-RES,S 6.8K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0605 88-121-153-080 0E RES,15K-1/8W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0606 88-118-153-080 0E C-RES,S 15K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0607 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0608 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0609 88-121-822-080 0E RES,8.2K-1/8W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0610 88-121-822-080 0E RES,8.2K-1/8W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0611 88-118-183-080 0E C-RES,S 18K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0612 88-118-183-080 0E C-RES,S 18K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0613 88-121-822-080 0E RES,8.2K-1/8W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0614 88-121-822-080 0E RES,8.2K-1/8W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0615 88-118-123-080 0E C-RES,S 12K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0616 88-118-123-080 0E C-RES,S 12K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0619 88-118-473-080 0E C-RES,S 47K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0620 88-118-473-080 0E C-RES,S 47K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0621 88-118-334-080 0E C-RES,S 330K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0622 88-121-334-080 0E RES,330K-1/8W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0625 88-121-472-080 0E RES,4.7K-1/8W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0626 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0627 88-118-123-080 0E C-RES,S 12K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0631 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0632 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0637 88-118-152-080 0E C-RES,S 1.5K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0638 88-118-152-080 0E C-RES,S 1.5K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0641 88-118-273-080 0E C-RES,S 27K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0642 88-118-273-080 0E C-RES,S 27K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0649 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0650 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0653 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0654 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0661 88-118-223-080 0E C-RES,S 22K-1/10W J HSC1NC1 CX-NSZ2E
X FUNC/E.VR R 0662 88-118-223-080 0E C-RES,S 22K-1/10W J HSC1NC1 CX-NSZ2E
O KNOB 8A-NEC-008-010 1A KEY,POWER HSC1NC1 CX-NSZ2E
O KNOB 8A-NEC-009-010 1A KEY,OPEN/CLOSE HSC1NC1 CX-NSZ2E
O KNOB 8A-NEC-010-010 1A KEY,CASS 1 HSC1NC1 CX-NSZ2E
O KNOB 8A-NEC-011-110 1A KEY,CASS 2 HSC1NC1 CX-NSZ2E
X LBL,POP 8A-NEC-970-010 — LBL,POP LHL HSC1NC1 CX-NSZ2E
X LBL,POP 8A-NEC-971-010 — LBL,POP LHR HSC1NC1 CX-NSZ2E
X LOCAL PACKING 8A-NEC-872-010 — CUSHION,FRONT AR HSC1NC1 CX-NSZ2E
X LOCAL PACKING 8A-NEC-873-010 — CUSHION,REAR AR HSC1NC1 CX-NSZ2E
X LOCAL PACKING 8A-NEC-874-010 — CTN,PRINTED AR HSC1NC1 CX-NSZ2E
X LOCAL PLATE 8A-NEC-044-010 — LBL,SPEC HASC1NC1 HSC1NC1 CX-NSZ2E
O MACB MECHA 87-067-001-010 0E S-SCREW,BVWWST2+3-12 W/O SLOT HSC1NC1 CX-NSZ2E
O MACB MECHA 87-067-579-010 0E BVT2+3-8 W/0 SL0T HSC1NC1 CX-NSZ2E
O MACB MECHA 87-NF4-224-010 0E S-SCREW,IT3B+3-8 CU HSC1NC1 CX-NSZ2E
X MACB MECHA 8A-NEC-202-110 1A HT-SINK,TR LOW HSC1NC1 CX-NSZ2E
O MECHANICAL 8A-NEC-205-010 1C CABI,BOTTOM HSC1NC1 CX-NSZ2E
O MICON C 0201 87-010-401-040 0E CAP,E 1-50 M 11L SME HSC1NC1 CX-NSZ2E
O MICON C 0202 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O MICON C 0203 87-010-260-040 0E CAP,E 47-25 M 11L SME HSC1NC1 CX-NSZ2E
O MICON C 0204 87-016-251-040 0E CAP,E 220-16 M SMG HSC1NC1 CX-NSZ2E
O MICON C 0500 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O MICON C 0501 87-010-406-040 0E CAP,E 22-50 M 11L SME HSC1NC1 CX-NSZ2E
O MICON C 0505 87-010-829-080 0E C-CAP,U 0.047-16 Z F HSC1NC1 CX-NSZ2E
O MICON C 0506 87-010-263-040 0E CAP,E 100-10 M 11L SME HSC1NC1 CX-NSZ2E
O MICON C 0507 87-010-246-040 0E CAP,E 47-35 M 11L SME HSC1NC1 CX-NSZ2E
O MICON C 0508 87-010-192-080 0E C-CAP,S 0.022-50 Z F C2012 HSC1NC1 CX-NSZ2E
O MICON C 0509 87-010-404-040 0E CAP,E 4.7-50 M 11L SME HSC1NC1 CX-NSZ2E
O MICON C 0510 87-010-404-040 0E CAP,E 4.7-50 M 11L SME HSC1NC1 CX-NSZ2E
O MICON C 0511 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O MICON C 0512 87-010-263-040 0E CAP,E 100-10 M 11L SME HSC1NC1 CX-NSZ2E
O MICON C 0514 87-012-274-080 0E C-CAP,U 1000P-50 K B HSC1NC1 CX-NSZ2E
O MICON C 0515 87-012-274-080 0E C-CAP,U 1000P-50 K B HSC1NC1 CX-NSZ2E
O MICON C 0517 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O MICON C 0518 87-012-268-080 0E C-CAP,U 330P-50 K B GRM HSC1NC1 CX-NSZ2E
O MICON C 0523 87-010-248-040 0E CAP,E 220-10 M 11L SME HSC1NC1 CX-NSZ2E
O MICON C 0524 87-010-192-080 0E C-CAP,S 0.022-50 Z F C2012 HSC1NC1 CX-NSZ2E

PARTS LIST
-6-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
O MICON C 0525 87-010-401-040 0E CAP,E 1-50 M 11L SME HSC1NC1 CX-NSZ2E
O MICON C 0526 87-012-172-080 0E C-CAP,U 10P-50 D CH HSC1NC1 CX-NSZ2E
O MICON C 0527 87-012-274-080 0E C-CAP,U 1000P-50 K B HSC1NC1 CX-NSZ2E
O MICON C 0528 87-010-175-080 0E C-CAP,S 560P-50 J SL HSC1NC1 CX-NSZ2E
O MICON C 0530 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O MICON C 0531 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O MICON C 0532 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O MICON C 0533 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O MICON C 0534 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O MICON C 0535 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O MICON C 0536 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O MICON C 0537 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O MICON C 0538 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O MICON C 0539 87-012-199-080 0E C-CAP,U 220P-50 J CH HSC1NC1 CX-NSZ2E
O MICON C 0540 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O MICON C 0541 87-016-459-040 0E CAP,E 470-10 M SMG HSC1NC1 CX-NSZ2E
O MICON C 0590 87-010-384-040 0E CAP,E 100-25 M 11L SME HSC1NC1 CX-NSZ2E
! O MICON CN 0201 87-A60-062-010 0E CONN,05P V 9604S-05C HSC1NC1 CX-NSZ2E
O MICON CN 0501 87-A60-673-010 0E CONN,9P H 2MM JMT HSC1NC1 CX-NSZ2E
S MICON D 0201 87-A40-758-080 0E ZENER,UZ8.2BSB HSC1NC1 CX-NSZ2E
S MICON D 0202 87-A40-313-080 0E C-DIODE,MC2840 HSC1NC1 CX-NSZ2E
S MICON D 0507 87-020-465-080 0E DIODE,1SS133 HSC1NC1 CX-NSZ2E
S MICON D 0540 87-A40-749-080 0E ZENER,UZ5.6BSB HSC1NC1 CX-NSZ2E
S MICON D 0541 87-020-465-080 0E DIODE,1SS133 HSC1NC1 CX-NSZ2E
S MICON D 0542 87-020-465-080 0E DIODE,1SS133 HSC1NC1 CX-NSZ2E
S MICON D 0543 87-020-465-080 0E DIODE,1SS133 HSC1NC1 CX-NSZ2E
O MICON FL 0501 8A-NEC-601-010 1H FL,HNA-10SS15T HSC1NC1 CX-NSZ2E
S MICON IC 0501 8A-NEC-602-110 1H C-IC,M38B57MCH-E258FP HSC1NC1 CX-NSZ2E
S MICON IC 0502 87-A21-629-010 1B IC,SPS-442-1-N HSC1NC1 CX-NSZ2E
X MICON JR 0201 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X MICON JR 0202 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X MICON JR 0203 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X MICON JR 0204 88-129-000-080 0E C-JUMPER,3216 HSC1NC1 CX-NSZ2E
X MICON JR 0503 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X MICON JR 0504 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X MICON JR 0505 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X MICON JR 0507 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X MICON JR 0510 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X MICON JR 0511 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
O MICON L 0501 87-A50-655-010 0E COIL,CLK 4.19MHZ (TOKO)7KLY HSC1NC1 CX-NSZ2E
S MICON Q 0201 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
S MICON Q 0202 87-026-609-080 0E TR,KTA1266GR HSC1NC1 CX-NSZ2E
S MICON Q 0203 87-026-609-080 0E TR,KTA1266GR HSC1NC1 CX-NSZ2E
S MICON Q 0204 87-026-609-080 0E TR,KTA1266GR HSC1NC1 CX-NSZ2E
S MICON Q 0205 87-026-609-080 0E TR,KTA1266GR HSC1NC1 CX-NSZ2E
S MICON Q 0208 87-A30-104-080 0E C-TR,RT1N 441C HSC1NC1 CX-NSZ2E
S MICON Q 0209 87-A30-104-080 0E C-TR,RT1N 441C HSC1NC1 CX-NSZ2E
S MICON Q 0210 87-A30-520-080 0E TR,2SC5342Y HSC1NC1 CX-NSZ2E
S MICON Q 0211 87-A30-520-080 0E TR,2SC5342Y HSC1NC1 CX-NSZ2E
S MICON Q 0212 87-A30-520-080 0E TR,2SC5342Y HSC1NC1 CX-NSZ2E
S MICON Q 0213 87-A30-520-080 0E TR,2SC5342Y HSC1NC1 CX-NSZ2E
S MICON Q 0501 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
S MICON Q 0507 87-A30-234-080 0E TR,CSC4115BC HSC1NC1 CX-NSZ2E
X MICON R 0201 88-121-102-080 0E RES,1K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0202 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0203 88-118-681-080 0E C-RES,S 680-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0204 88-128-392-080 0E C-RES, 3.9K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0205 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0206 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0207 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0208 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0210 88-128-109-080 0E C-RES, 1-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0211 88-128-109-080 0E C-RES, 1-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0212 88-128-109-080 0E C-RES, 1-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0213 88-128-109-080 0E C-RES, 1-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0216 88-121-100-080 0E RES,10-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0217 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0218 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0219 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0220 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E

PARTS LIST
-7-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X MICON R 0221 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0222 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0223 88-118-182-080 0E C-RES,S 1.8K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0224 88-118-182-080 0E C-RES,S 1.8K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0225 88-121-101-080 0E RES,100-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0226 88-118-223-080 0E C-RES,S 22K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0227 88-121-102-080 0E RES,1K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0228 88-118-472-080 0E C-RES,S 4.7K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0229 88-118-472-080 0E C-RES,S 4.7K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0230 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0231 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0232 88-118-821-080 0E C-RES,S 820-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0233 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0234 88-118-122-080 0E C-RES,S 1.2K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0235 88-118-122-080 0E C-RES,S 1.2K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0236 88-118-122-080 0E C-RES,S 1.2K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0237 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0238 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0239 88-118-821-080 0E C-RES,S 820-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0240 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0241 88-118-122-080 0E C-RES,S 1.2K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0250 88-121-102-080 0E RES,1K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0251 88-121-102-080 0E RES,1K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0253 88-118-272-080 0E C-RES,S 2.7K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0254 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0255 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0256 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0257 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0258 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0259 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0260 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0261 88-121-222-080 0E RES,2.2K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0297 88-121-182-080 0E RES,1.8K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0501 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0502 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0503 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0504 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0505 88-121-393-080 0E RES,39K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0506 88-121-101-080 0E RES,100-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0508 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0509 88-121-101-080 0E RES,100-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0510 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0511 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0512 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0513 88-128-109-080 0E C-RES, 1-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0514 88-128-159-080 0E C-RES, 1.5-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0515 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0516 88-100-000-010 0E PLATING-JW, 0.58 SN95 HSC1NC1 CX-NSZ2E
X MICON R 0517 88-118-473-080 0E C-RES,S 47K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0519 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0522 88-118-683-080 0E C-RES,S 68K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0523 88-121-102-080 0E RES,1K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0524 88-121-472-080 0E RES,4.7K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0525 88-121-472-080 0E RES,4.7K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0526 88-121-681-080 0E RES,680-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0527 88-121-681-080 0E RES,680-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0529 88-118-563-080 0E C-RES,S 56K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0530 88-121-331-080 0E RES,330-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0531 88-118-100-080 0E C-RES,S 10-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0532 88-121-223-080 0E RES,22K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0533 88-118-823-080 0E C-RES,S 82K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0534 88-118-683-080 0E C-RES,S 68K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0535 88-118-683-080 0E C-RES,S 68K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0536 88-118-683-080 0E C-RES,S 68K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0537 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0538 88-118-683-080 0E C-RES,S 68K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0539 88-121-224-080 0E RES,220K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0540 88-118-683-080 0E C-RES,S 68K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0541 88-118-683-080 0E C-RES,S 68K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0542 88-121-330-080 0E RES,33-1/8W J HSC1NC1 CX-NSZ2E

PARTS LIST
-8-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X MICON R 0543 88-121-330-080 0E RES,33-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0544 88-121-330-080 0E RES,33-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0545 88-121-330-080 0E RES,33-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0546 88-100-000-010 0E PLATING-JW, 0.58 SN95 HSC1NC1 CX-NSZ2E
X MICON R 0547 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0548 88-118-183-080 0E C-RES,S 18K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0549 88-118-822-080 0E C-RES,S 8.2K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0550 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X MICON R 0551 88-118-392-080 0E C-RES,S 3.9K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0552 88-118-224-080 0E C-RES,S 220K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0553 88-118-472-080 0E C-RES,S 4.7K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0555 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0556 88-118-683-080 0E C-RES,S 68K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0581 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0582 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0583 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0584 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0585 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0586 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0587 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0588 88-118-104-080 0E C-RES,S 100K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0589 88-128-102-080 0E C-RES, 1K-1/8W J HSC1NC1 CX-NSZ2E
X MICON R 0591 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0592 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0593 88-118-821-080 0E C-RES,S 820-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0594 88-118-151-080 0E C-RES,S 150-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0595 88-118-122-080 0E C-RES,S 1.2K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0596 88-118-332-080 0E C-RES,S 3.3K-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0597 88-118-331-080 0E C-RES,S 330-1/10W J HSC1NC1 CX-NSZ2E
X MICON R 0598 88-118-123-080 0E C-RES,S 12K-1/10W J HSC1NC1 CX-NSZ2E
O MICON S 0201 87-A90-095-080 0E SW,TACT EVQ11G04M HSC1NC1 CX-NSZ2E
O MICON S 0202 87-A90-095-080 0E SW,TACT EVQ11G04M HSC1NC1 CX-NSZ2E
O MICON S 0203 87-A90-095-080 0E SW,TACT EVQ11G04M HSC1NC1 CX-NSZ2E
O MICON S 0204 87-A90-095-080 0E SW,TACT EVQ11G04M HSC1NC1 CX-NSZ2E
O MICON S 0205 87-A90-095-080 0E SW,TACT EVQ11G04M HSC1NC1 CX-NSZ2E
O MICON S 0206 87-A90-095-080 0E SW,TACT EVQ11G04M HSC1NC1 CX-NSZ2E
O MICON S 0208 87-A90-095-080 0E SW,TACT EVQ11G04M HSC1NC1 CX-NSZ2E
O MICON S 0209 87-A90-095-080 0E SW,TACT EVQ11G04M HSC1NC1 CX-NSZ2E
O MICON S 0210 87-A90-095-080 0E SW,TACT EVQ11G04M HSC1NC1 CX-NSZ2E
O MICON S 0211 87-A90-095-080 0E SW,TACT EVQ11G04M HSC1NC1 CX-NSZ2E
O MICON S 0212 87-A90-095-080 0E SW,TACT EVQ11G04M HSC1NC1 CX-NSZ2E
O MICON S 0213 87-A90-095-080 0E SW,TACT EVQ11G04M HSC1NC1 CX-NSZ2E
O MICON SFR0501 87-024-431-080 0E SFR,3.3K H RH063MC HSC1NC1 CX-NSZ2E
O OTHERS 82-NF7-218-010 0E SPR-T,CASS HSC1NC1 CX-NSZ2E
! O OTHERS 86-NFZ-231-010 1A DMPR,70 HSC1NC1 CX-NSZ2E
O OTHERS 8A-NEC-201-110 0E HLDR,PT HSC1NC1 CX-NSZ2E
O OTHERS 8A-NEC-203-010 0E HLDR,CD L HSC1NC1 CX-NSZ2E
O OTHERS 8A-NEC-204-010 0E HLDR,CD R HSC1NC1 CX-NSZ2E
O OTHERS 8A-NEC-206-010 0E HLDR,DECK HSC1NC1 CX-NSZ2E
X OTHERS 8A-NED-207-010 0E CUSH, 12.5-15.5-2 HSC1NC1 CX-NSZ2E
O P-AMP C 0101 87-012-284-080 0E C-CAP,U 6800P-50 K B GRM HSC1NC1 CX-NSZ2E
O P-AMP C 0102 87-012-284-080 0E C-CAP,U 6800P-50 K B GRM HSC1NC1 CX-NSZ2E
O P-AMP C 0103 87-010-544-080 0E CAP,E 0.1-50 M 11L SME HSC1NC1 CX-NSZ2E
O P-AMP C 0104 87-010-544-080 0E CAP,E 0.1-50 M 11L SME HSC1NC1 CX-NSZ2E
O P-AMP C 0105 87-012-282-080 0E C-CAP,U 4700P-50 K B HSC1NC1 CX-NSZ2E
O P-AMP C 0106 87-012-282-080 0E C-CAP,U 4700P-50 K B HSC1NC1 CX-NSZ2E
O P-AMP C 0107 87-010-403-080 0E CAP,E 3.3-50 M 11L SME HSC1NC1 CX-NSZ2E
O P-AMP C 0108 87-010-403-080 0E CAP,E 3.3-50 M 11L SME HSC1NC1 CX-NSZ2E
O P-AMP C 0111 87-010-406-080 0E CAP,E 22-50 M 11L SME HSC1NC1 CX-NSZ2E
O P-AMP C 0112 87-010-406-080 0E CAP,E 22-50 M 11L SME HSC1NC1 CX-NSZ2E
O P-AMP C 0113 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O P-AMP C 0114 87-012-195-080 0E C-CAP,U 100P-50 J CH HSC1NC1 CX-NSZ2E
O P-AMP C 0117 87-012-286-080 0E C-CAP,U 0.01-25 K B HSC1NC1 CX-NSZ2E
O P-AMP C 0118 87-012-286-080 0E C-CAP,U 0.01-25 K B HSC1NC1 CX-NSZ2E
O P-AMP C 0119 87-012-286-080 0E C-CAP,U 0.01-25 K B HSC1NC1 CX-NSZ2E
O P-AMP C 0120 87-012-286-080 0E C-CAP,U 0.01-25 K B HSC1NC1 CX-NSZ2E
O P-AMP C 0125 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O P-AMP C 0126 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O P-AMP C 0127 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O P-AMP C 0128 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E

PARTS LIST
-9-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
O P-AMP C 0140 87-010-190-080 0E C-CAP,S 0.01-50 Z F C2012 HSC1NC1 CX-NSZ2E
S P-AMP D 0101 87-A40-269-080 0E C-DIODE,MC2836 HSC1NC1 CX-NSZ2E
S P-AMP D 0103 87-020-465-080 0E DIODE,1SS133 HSC1NC1 CX-NSZ2E
S P-AMP D 0104 87-020-465-080 0E DIODE,1SS133 HSC1NC1 CX-NSZ2E
S P-AMP D 0105 87-A40-269-080 0E C-DIODE,MC2836 HSC1NC1 CX-NSZ2E
S P-AMP D 0106 87-A40-269-080 0E C-DIODE,MC2836 HSC1NC1 CX-NSZ2E
S P-AMP D 0115 87-A40-270-080 0E C-DIODE,MC2838 HSC1NC1 CX-NSZ2E
S P-AMP D 0129 87-A40-270-080 0E C-DIODE,MC2838 HSC1NC1 CX-NSZ2E
O P-AMP J 0101 87-A60-602-010 1A JACK,DIA6.3 BLK ST W/SW TC HSC1NC1 CX-NSZ2E
O P-AMP J 0103 87-A61-452-010 0E TERMINAL,SP 4P(MSC) HSC1NC1 CX-NSZ2E
X P-AMP JR 0101 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
O P-AMP L 0101 87-A50-610-010 0E COIL,1UH K(MDEC) HSC1NC1 CX-NSZ2E
O P-AMP L 0102 87-A50-610-010 0E COIL,1UH K(MDEC) HSC1NC1 CX-NSZ2E
S P-AMP Q 0103 87-A30-075-080 0E C-TR,2SA1235F HSC1NC1 CX-NSZ2E
S P-AMP Q 0104 87-A30-075-080 0E C-TR,2SA1235F HSC1NC1 CX-NSZ2E
S P-AMP Q 0105 87-A30-075-080 0E C-TR,2SA1235F HSC1NC1 CX-NSZ2E
S P-AMP Q 0106 87-A30-075-080 0E C-TR,2SA1235F HSC1NC1 CX-NSZ2E
S P-AMP Q 0107 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
S P-AMP Q 0108 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
S P-AMP Q 0109 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
S P-AMP Q 0110 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
S P-AMP Q 0111 87-026-610-080 0E TR,KTC3198GR HSC1NC1 CX-NSZ2E
S P-AMP Q 0112 87-026-610-080 0E TR,KTC3198GR HSC1NC1 CX-NSZ2E
S P-AMP Q 0113 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
S P-AMP Q 0114 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
S P-AMP Q 0115 87-A30-256-010 1A TR,2SD1933 HSC1NC1 CX-NSZ2E
S P-AMP Q 0116 87-A30-256-010 1A TR,2SD1933 HSC1NC1 CX-NSZ2E
S P-AMP Q 0117 87-A30-255-010 1A TR,2SB1342 HSC1NC1 CX-NSZ2E
S P-AMP Q 0118 87-A30-255-010 1A TR,2SB1342 HSC1NC1 CX-NSZ2E
S P-AMP Q 0123 87-A30-075-080 0E C-TR,2SA1235F HSC1NC1 CX-NSZ2E
S P-AMP Q 0124 87-A30-075-080 0E C-TR,2SA1235F HSC1NC1 CX-NSZ2E
S P-AMP Q 0126 87-A30-075-080 0E C-TR,2SA1235F HSC1NC1 CX-NSZ2E
S P-AMP Q 0130 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
X P-AMP R 0103 88-118-472-080 0E C-RES,S 4.7K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0104 88-118-472-080 0E C-RES,S 4.7K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0105 88-118-223-080 0E C-RES,S 22K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0106 88-118-223-080 0E C-RES,S 22K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0107 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0108 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0109 88-118-222-080 0E C-RES,S 2.2K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0110 88-118-222-080 0E C-RES,S 2.2K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0111 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0112 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0113 88-118-223-080 0E C-RES,S 22K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0114 88-118-223-080 0E C-RES,S 22K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0115 88-128-109-080 0E C-RES, 1-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0116 88-128-109-080 0E C-RES, 1-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0117 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0118 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0119 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0120 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0121 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0122 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0123 88-121-222-080 0E RES,2.2K-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0124 88-121-222-080 0E RES,2.2K-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0125 88-121-222-080 0E RES,2.2K-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0126 88-121-222-080 0E RES,2.2K-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0127 88-118-390-080 0E C-RES,S 39-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0128 88-118-390-080 0E C-RES,S 39-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0131 88-128-109-080 0E C-RES, 1-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0132 88-128-109-080 0E C-RES, 1-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0133 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0134 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0135 88-118-182-080 0E C-RES,S 1.8K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0136 88-118-182-080 0E C-RES,S 1.8K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0137 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0138 88-118-101-080 0E C-RES,S 100-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0139 88-121-562-080 0E RES,5.6K-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0140 88-121-562-080 0E RES,5.6K-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0141 88-118-102-080 0E C-RES,S 1K-1/10W J HSC1NC1 CX-NSZ2E

PARTS LIST
-10-
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX
X P-AMP R 0142 88-121-102-080 0E RES,1K-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0143 88-130-221-080 0E RES,220-1/4W J HSC1NC1 CX-NSZ2E
X P-AMP R 0144 88-130-221-080 0E RES,220-1/4W J HSC1NC1 CX-NSZ2E
X P-AMP R 0145 88-130-221-080 0E RES,220-1/4W J HSC1NC1 CX-NSZ2E
X P-AMP R 0146 88-130-221-080 0E RES,220-1/4W J HSC1NC1 CX-NSZ2E
X P-AMP R 0147 88-130-100-080 0E RES,10-1/4W J HSC1NC1 CX-NSZ2E
X P-AMP R 0148 88-130-100-080 0E RES,10-1/4W J HSC1NC1 CX-NSZ2E
X P-AMP R 0149 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0150 88-128-100-080 0E C-RES, 10-1/8W J HSC1NC1 CX-NSZ2E
X P-AMP R 0151 88-130-102-080 0E RES,1K-1/4W J HSC1NC1 CX-NSZ2E
X P-AMP R 0152 88-140-471-080 0E RES,470-1/2W J HSC1NC1 CX-NSZ2E
X P-AMP R 0157 88-118-472-080 0E C-RES,S 4.7K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0159 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0160 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0165 88-118-272-080 0E C-RES,S 2.7K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0166 88-118-272-080 0E C-RES,S 2.7K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0167 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0168 88-118-473-080 0E C-RES,S 47K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0169 88-118-222-080 0E C-RES,S 2.2K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0170 88-118-222-080 0E C-RES,S 2.2K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0171 88-118-122-080 0E C-RES,S 1.2K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0172 88-118-122-080 0E C-RES,S 1.2K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0175 88-118-331-080 0E C-RES,S 330-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0176 88-118-331-080 0E C-RES,S 330-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0178 88-118-103-080 0E C-RES,S 10K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0179 88-118-473-080 0E C-RES,S 47K-1/10W J HSC1NC1 CX-NSZ2E
X P-AMP R 0180 88-118-473-080 0E C-RES,S 47K-1/10W J HSC1NC1 CX-NSZ2E
! O P-AMP RY 0101 87-045-389-010 1C RELAY,12V OSA-SS-212DM5 HSC1NC1 CX-NSZ2E
X P-SUPPLY/PWB/FUN 8A-NEC-640-210 1F PWB,COMB MAIN HSC1NC1 CX-NSZ2E
X P-SUPPLY/PWB/FUN 8A-NEC-641-210 — PWB,MAIN HSC1NC1 CX-NSZ2E
X P-SUPPLY/PWB/FUN 8A-NEC-642-210 — PWB,HLDR WIRE HSC1NC1 CX-NSZ2E
X P-SUPPLY/PWB/FUN 8A-NEC-643-210 — PWB,HLDR FFC HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0009 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0010 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0011 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0012 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0021 87-A12-442-000 1H CAP,E 3300-25 M 85 IV LELON HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0022 87-A10-831-080 1A CAP,E 1000-25 M SMG HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0023 87-010-387-080 1A CAP,E 470-25 M SME HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0025 87-010-408-080 0E CAP,E 47-50 M 11L SME HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0026 87-010-408-080 0E CAP,E 47-50 M 11L SME HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0031 87-010-759-080 0E C-CAP,U 0.1-25 Z F HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0032 87-012-286-080 0E C-CAP,U 0.01-25 K B HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0034 87-010-260-080 0E CAP,E 47-25 M 11L SME HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0035 87-010-406-080 0E CAP,E 22-50 M 11L SME HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0036 87-010-112-080 0E CAP,E 100-16 M 11L SME HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0050 87-010-247-080 0E CAP,E 100-50 M SME HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0051 87-010-247-080 0E CAP,E 100-50 M SME HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0060 87-010-403-080 0E CAP,E 3.3-50 M 11L SME HSC1NC1 CX-NSZ2E
O P-SUPPLY/PWB/FUN C 0061 87-010-260-080 0E CAP,E 47-25 M 11L SME HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0005 87-A40-455-090 0E DIODE,RL203 GW HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0006 87-A40-455-090 0E DIODE,RL203 GW HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0007 87-A40-455-090 0E DIODE,RL203 GW HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0008 87-A40-455-090 0E DIODE,RL203 GW HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0026 87-A40-553-080 0E DIODE,1N4003 LES HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0027 87-A40-553-080 0E DIODE,1N4003 LES HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0029 87-A40-777-080 0E ZENER,UZ30BSB HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0030 87-020-465-080 0E DIODE,1SS133 HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0031 87-A40-764-080 0E ZENER,UZ10BSC HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0032 87-A40-764-080 0E ZENER,UZ10BSC HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0034 87-020-465-080 0E DIODE,1SS133 HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0035 87-020-465-080 0E DIODE,1SS133 HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0063 87-A40-313-080 0E C-DIODE,MC2840 HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN D 0064 87-A40-313-080 0E C-DIODE,MC2840 HSC1NC1 CX-NSZ2E
X P-SUPPLY/PWB/FUN JR 0002 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
X P-SUPPLY/PWB/FUN JR 0004 88-118-000-080 0E C-JUMPER,S HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN Q 0002 87-026-609-080 0E TR,KTA1266GR HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN Q 0003 89-213-702-010 1A TR,2SB1370E HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN Q 0005 87-026-610-080 0E TR,KTC3198GR HSC1NC1 CX-NSZ2E
S P-SUPPLY/PWB/FUN Q 0006 87-A30-076-080 0E C-TR,2SC3052F HSC1NC1 CX-NSZ2E
