AJAX FireProtect User manual

FireProtect / FireProtect Plus User Manual
Updated December 30, 2021
FireProtect (FireProtect Plus) is a wireless indoor re detector with an in-built
buzzer and a battery, ensuring up to 4 years of autonomous operation. FireProtect
can detect smoke and rapid temperature increase.
Aside from these functions, FireProtect Plus additionally can alert of dangerous
CO level. Both detectors can function independently from the hub.
Connecting to the Ajax security system via a secured radio protocol,
FireProtect (FireProtect Plus) communicates with the at a distance of up to
1,300 m in line of sight.
The detector can be a part of third-party security systems, connecting to them via
the or integration module.
Jeweller
hub
Ajax uartBridge Ajax ocBridge Plus
Buy �re detector with carbon monoxide sensor FireProtect Plus

The detector is set up via the for iOS, Android, macOS, and Windows.
The system noties the user of all events through push notications, SMS, and
calls (if activated).
The Ajax security system can be connected to a central monitoring station of a
security company.
Functional Elements
Operating Principle
Ajax apps
Buy �re detector FireProtect
1. Siren hole
2. Light indicator (acts as the sensor and Test button)
3. Smoke chamber hole with the temperature detector behind the net
4. SmartBracket attachment panel
5. Power button
6. Tamper button
7. QR code

When smoke penetrates the detector chamber, it distorts infrared light between the
emitter and photoelectric receiver. This distortion triggers a smoke alarm. When
the temperature exceeds 60°or rises by 30°during 30 minutes (not necessary to
reach 60°), the detector registers temperature increase, which triggers a re
alarm.
The life span of the FireProtect Plus detector lasts up to 7 years (up to 10 years for the
). In the event of a detector failure, you will receive a corresponding noti�cation —
it will need to be replaced or submitted for .
In case of alarm, the detector activates the built-in buzzer (the siren sound can be
heard from afar) and blinks with the light indicator. When connected to a security
system, both the user and the security company are notied of the alarm.
FireProtect Plus reacts to carbon monoxide long before the rst symptoms of
poisoning appear. It is triggered:
Loss of consciousness is possible at a CO concentration of 0.1% lasting over 2 hours!
The detector stops notifying about the dangerous level of carbon monoxide when
the concentration drops to 40 ppm (0.004%) within one minute.
The siren of the device can be turned off using three ways:
FireProtect
comprehensive diagnostics
• Not earlier than 120 minutes at a carbon monoxide concentration of 0.003%
(30 ppm).
• 60 to 89 minutes at a carbon monoxide concentration of 0.005% (50 ppm).
• 10 to 39 minutes at a concentration of 0.01% (100 ppm).
• Up to 3 minutes at a concentration exceeding 0.03% (300 ppm).
1. By pressing the Ajax logo on the device lid (there is a touch button under the

2. Through the Ajax app. In case of re alarm, you will see a pop-up message in
Ajax app suggesting to turn off the built-in sirens.
3. Using the / (if Interconnected Fire Detectors Alarmfeature
is enabled). To turn off the built-in sirens in case of re alarm, press the “*”
button on the KeyPad/KeyPad Plus.
KeyPad KeyPad Plus

Please note that for this to work you need to priorly select Mute Interconnected
Fire Alarmcommand for this button in the KeyPad/KeyPad Plus settings.
If smoke and/or temperature levels do not restore to normal values, in 10 minutes,
the FireProtect/FireProtect Plus turns on the siren again.
Connecting the Detector to the Ajax Security System
Connecting to the hub
Before starting connection:
Only users with administrator rights can add the device to the hub
Pairing the detector with hub:
1. Following the hub user guide, install the . Create the account, add the
hub, and create at least one room.
Ajax app
2. Switch on the hub and check the internet connection (via Ethernet cable and/or
GSM network).
3. Make sure that the hub is disarmed and does not update by checking its status
in the Ajax app.

To make sure that the detector is on, press the on/off button — the logo will light up
red for a second.
3. Tap Add — the countdown will start.
4. Switch on the device.

the device.
If pairing with the hub fails, the detector operates autonomously; switch off the
detector for 5 seconds and retry.
The detector connected to the hub is displayed in the list of devices in the app. The
update of the detector status in the list depends on the device inquiry time set in
the hub settings (the default value is 36 seconds).
Connecting to Third Party Security Systems
To connect the detector to a third party security central unit using the
or integration module, follow the recommendations
in the manual of the respective device.
The smoke detector always operates in the active mode. When connecting
FireProtect to third party security systems, it is appropriate to place it in a
permanently active protection zone.
States
Parameter State
Temperature Temperature of the device. Measures on the
device processor and changes gradually
Jeweller Signal Strength Signal strength between the hub and the detector
Connection Connection status between the hub and the
device
Ajax
uartBridge Ajax ocBridge Plus
1. Devices
2. FireProtect | FireProtect Plus

Lid The tamper state of the device — reacts to the
detachment
ReX Displays the status of using a
Smoke Shows if smoke is detected
Temperature Threshold Exceeded The state of temperature threshold exceeded
alarm
Rapid Temperature Rise The state of rapid temperature increase alarm
High CO Level (FireProtect Plus only) The state of dangerous CO level alarm
Backup Battery Charge Backup battery level of the device
Smoke sensor The state of the smoke detector
Smoke Sensor Dust Level The dust level in the smoke chamber
Temporary Deactivation
Shows the status of the device: active, completely
disabled by the user, or only noti�cations about
triggering of the device tamper button are
disabled
Firmware Detector �rmware version
Device ID Device identi�er
Settings
How battery charge is displayed in
Ajax apps
radio signal
range extender
1. Devices
2. FireProtect | FireProtect Plus
3. Settings

Dangerous CO Level Alarm (FireProtect Plus only)limits of carbon monoxide concentration
High Temperature Alarm If active, the detector reacts when the
temperature is 60°C and higher
Rapid Temperature Rise Alarm If active, the detector reacts to rapid temperature
increase (30°Сfor 30 minutes or less)
Alert with a siren if smoke is detected If active, added to the systemare
activated in case of smoke alarm
Alert with a siren if temperature threshold
exceeded
If active, added to the systemare
activated in case if temperature threshold
exceeded
Alert with a siren if rapid temperature rise
detected
If active, added to the systemare
activated in case if rapid temperature rise
detected
Alert with a siren if CO detected (FireProtect Plus
only)
If active, added to the systemare
activated in case if CO concentration is
dangerous
Jeweller Signal Strength Test Switches the device to the signal strength test
mode
Smoke Sensor Self Test Starts FireProtect selftest
Temporary Deactivation
Allows the user to disconnect the device without
removing it from the system.
Two options are available:
sirens
sirens
sirens
sirens
• Entirely— the device will not execute system
commands or participate in automation
scenarios, and the system will ignore device
alarms and other noti�cations
• Lid only— the system will ignore only
noti�cations about the triggering of the device
tamper button

Unpair Device Deletes device and its settings
Interconnected Fire Detectors Alarms Setup
The function activates built-in sirens of all re detectors if at least one of them is
triggered. Sirens are activated within the hub–detector ping interval according to
the Jeweller settings.
To enable Interconnected Alarms:
1. Open the Devices tab in the
2. Select a hub
3. Go to its Settings by pressing
4. Select the Service item
5. Go to the Fire detectors settings menu and activate the Interconnected Fire
Detectors Alarmsoption
Interconnected alarms are supported by FireProtect and FireProtect Plus detectors with
�rmware versions 3.42 and later. Please note that when you turn on the interconnected
alarms, you cannot set the hub–detector ping interval (Jeweller settings) of more than 48
seconds.
6. If necessary, set the Delay of Interconnected Alarms from 0 to 5 minutes (in
1-minute increments). The option allows you to postpone the interconnected alarm
for a specied period of time.
When this option is inactive, the interconnected alarm is sent to all �re detectors within a
Ajax app

notications in the Ajax app (if are enabled). At the object,
are activated (if the are enabled).
4. An alarm conrmation event is sent to the monitoring station and security
system users, and the system starts the interconnected alarm for re detectors if:
appropriate noti�cations
Ajax sirens corresponding settings
• The interconnected alarm delay time has passed, and the triggered detector is
still registering an alarm.

temperature threshold after a smoke alarm).
• During the interconnected alarm delay, another re detector in the system
raised an alarm.
00:00 00:13

If a triggered detector does not return to a normal state within 10 minutes after the user
postponed the interconnected alarm, another �re detector reports an alarm, or a triggered
detector reports an alarm of another type (for example, temperature and smoke), the system
will send an alarm con�rmation and activate interconnected alarm for �re detectors.
• By pressing the KeyPad/KeyPad Plus function button (in the interconnected re
alarm muting mode).
• By pressing the Button in the interconnected re alarm muting mode.
• By eliminating the cause of the alarm (re detectors at the facility no longer
detect an alarm).
• By pressing the touch button of the triggered re detector.

7. If necessary, activate the Ignore First Alarm option. This setting is
recommended for premises with potential sources of false alarms. For example, if
the device is installed in a place where dust or steam can get into the detector.
The option functions as follows:
1. The detector reports a smoke alarm.
2. The built-in 30-second timer of the detector starts.
3. If after 30 seconds the detector still detects a threat, an alarm is sent to the hub.
Setting the Residential �re alarm system
Residential �re alarm system is an Ajax system feature that denes user and
device rights to mute the interconnected alarms of re detectors.
If the feature is enabled, users can silence re alarms of triggered detectors only in
the groups to which they have access. And Button, KeyPad, KeyPad Plus — the
alarms only of those re detectors that are in the same group.
The feature is useful for objects consisting of several rooms and protected by a
single hub. For example, for multi-apartment complexes where each apartment is a
group with at least one re detector installed. In this case, users can respond to the
alarms of their groups without silencing the alarms of other groups.

Detector switching on The logo lights up green for 1 second
Detector switching off The logo blinks red three times and the device
switches off
Registration failed The logo blinks green for a minute, then the
device switches to the autonomous mode
Smoke or temperature increase detected The siren switches on, the logo lights red during
the �re/smoke alarm
Battery low
Performance testing
The Ajax security system allows conducting tests for checking the functionality of
connected devices.
The tests do not start straight away but within a period of 36 seconds when using
the standard settings. The test time start depends on the settings of the detector
scanning period (the paragraph on “Jeweller” settings in hub settings).
• One short sound signal per 90 sec — main
batteries low (CR2)
• Two short sound signals per 90 sec — backup
battery low (CR2032)
• Three short sound signals per 90 sec — both
batteries low

Before installing the detector, check the smoke sensor. To test it, switch on the
detector and press the sensor button (the logo center) for a few seconds – the
detector will test the smoke chamber with electronic simulation of smoke
generation and then will switch on the siren for 6 seconds.
You will receive the notication in the Ajax app regarding the test result and
detector status.
Installation
Selecting the Location
The location of the detector depends on its remoteness from the hub, and
obstacles hindering the radio signal transmission: walls, oors, large objects inside
the room.
The device developed only for indoor use.
If the signal level is low (one bar), we cannot guarantee the stable operation of the
detector. Take all possible measures to improve the quality of the signal. At least,
move the detector: even a 20 cm shift can signicantly improve the quality of
signal reception.

ceiling level, install the detector between every two beams.
Installation procedure
Before installing the detector, make sure that you have selected the optimal
location that follows the guidelines of this manual!
How to install FireProtect �re detector correctly
Where and how to install FireProtect Plus
1. Fix the SmartBracket panel on the ceiling using bundled screws. If you use any

If someone detaches the detector from the surface or takes it off the attachment
panel, the security system noties you.
Do not install the detector:
Autonomous Use of the Detector
The detector can be used autonomously, without connecting to a security system.
1. outside the premises (outdoors);
2. nearby any metal objects or mirrors causing attenuation or screening of the
signal;
3. at any places with fast air circulation (air fans, open windows or doors);
4. closer than a meter to the cooking surface;
5. inside premises with the temperature and humidity beyond the range of
permissible limits;
6. closer than 1 m to the hub.
1. Switch on the detector by pressing the on/off button for 3 seconds (the logo
will light up green for 1 second) and conduct the smoke test.

Do not use any substances containing alcohol, acetone, gasoline, and other active
solvents to clean the detector.
To a certain level, the detector ignores the dust in the smoke chamber. When the
chamber becomes too dusty, the detector noties the user of the need to clean it
via the app (and beeps every minute and a half). Such maintenance is compulsory
for the detector to operate correctly.
Pre-installed batteries ensure up to 4 years of autonomous operation. If the
batteries are discharged, the security system sends the respective notications
and the detector signal with a sound every 90 seconds:
Keep new and used batteries away from children. Do not ingest battery, Chemical Burn
Hazard.
How to clean up the smoke chamber
• if the main batteries are low — a single short signal;
• if the backup battery is low — two short signals;
• if both batteries are low — three short signals.

Radio communication protocol
Jeweller
Radio frequency band
866.0 – 866.5 MHz
868.0 – 868.6 MHz
868.7 – 869.2 MHz
905.0 – 926.5 MHz
915.85 – 926.5 MHz
921.0 – 922.0 MHz
Depends on the region of sale.
Compatibility
Operates independently or with all Ajax ,
,
,
Maximum RF output power Up to 20 mW
Radio signal modulation GFSK
Radio signal range
Up to 1,300 m (any obstacles absent)
Learn more
hubs
radio signal range extenders ocBridge
Plus uartBridge
Learn more
