SERVICE MANUAL
Models:
ACR25MP
ACR35MP
ACR45MP
PULL SYNTHESIZED
STEREO RADIO WITH
COMPACT DISC PLAYER
DIGITAL
www.akai.ru

E
BMMODE BMSTAG B MPART BIDESC BDDOCNO BMUNIT
03074 ASM1 1 221-20600-00-00-00 INSULATING SHEET TOP OF THE FRAME 1
03074 ASM1 1 225-20602-00-00-00 REMOTE CONTROL SPONGE BOTTOM OF THE TOP COVER DVD MOTOR 1
03074 ASM1 1 332-20600-00-00-00 FRAME DVD MOTOR BOTTOM OF THE MB 1
03074 ASM1 1 332-20601-00-00-00 FRAME BACK SHEET BACK OF THE FRAME 1
03074 ASM1 1 337-20600-00-00-01 SHORT SHEET OUTSIDE OF THE BODY 1
03074 ASM1 1 435-20040-74-10-00 SCREW BTS2004 FRONT FRAME TO FRAME DVD MOTOR 4
03074 ASM1 1 435-26050-74-10-00 SCREW M2.6X5.0
FRAME BACK TO FRAME DVD(3EA),MB FRAME
DVD(1EA) 4
03074 ASM1 1 435-26060-74-10-00 SCREW M2.6X6.0
BRACKET KOMEC DECK FRONT TO FRAME
DVD(2EA);HEATSINK MAIN TO FRAME DVD
MOTOR(2EA)BRACKET DECK BACK FRAME BACK(2EA) 6
03074 ASM1 1 435-26070-05-10-00 SCREW PTP2607 SOCKET TO FRAME BACK SHEET 2
03074 ASM1 1 435-26100-74-10-00 SCREW M2.6X10.0 HEATSINK MAIN TO FRAME BACK SHEET 2
03074 ASM1 1 435-26140-74-10-00 SCREW BTS2614 HEATSINK MAIN TO BRACKET IC 7386 2
03074 ASM1 1 331-20600-00-00-01 TOP COVER DVD MOTOR TOP OF THE FRAME 1
03074 ASM10 1 333-20600-00-00-00 HEATSINK MAIN TOP OF THE MB 1
03074 ASM10 1 333-20601-00-00-00 HEATSINK IC 7809&BD435 TOP OF THE MB 1
03074 ASM10 1 335-20610-00-00-00 BRACKET IC7386 TOP OF THE MB 1
03074 ASM10 1 435-26050-76-10-00 SCREW BTB2605 IC7809 TO HEATSINK 1
03074 ASM10 1 435-26070-76-10-00 SCREW BTB2607 IC BD435 TO HEATSINK 1
03074 ASM11 1 100-78L05-00-00-04 IC 78L05 REGULATOR ST IC803 1
03074 ASM11 1 100-78L18-00-00-04 IC 78L18 REGULATOR ST IC802 1
03074 ASM11 1 100-AMS10-85-33-22 I.C.AMS1085CT-3V3 TO-220 IC805 1
03074 ASM11 1 100-L7809-00-00-04 IC L7809 REGULATOR ST IC804 1
03074 ASM11 1 100-TA729-1S-00-01 IC TA7291S MOTOR-CTC TOSHIBA IC301 1
03074 ASM11 1 100-TDA73-84-00-04 I.C.TDA7384 IC801 1
03074 ASM11 1 111-CM206-MB-21-01 CM206 MB S/S 191.2*150*1.6MM 1
03074 ASM11 1 122-T7000-CE-00-00 FM/AM TUNER(CET-7000AFL) TUN101 1
03074 ASM11 1 384-CM206-01-05-6E P=2.0MM 5PIN WAFER CON301 1
03074 ASM11 1 384-CM206-01-16-6E 16PIN FPC SOCKET 1.0 CON403 1
1

03074 ASM11 1 384-CM206-01-20-6E 20PIN PWR/SPK SOCKET EST-KNT-20-04 CON801 1
03074 ASM11 1 384-CM206-01-25-6E 25PIN FPC SOCKET 1.25 CON402 1
03074 ASM11 1 410-HIRED-EE-00-02 ∮3MM LED HI-RED 30MM PIN LED401 1
03074 ASM11 1 449-105FM-FG-21-2E CE 1μF/50V ±20% 4X5 105°C C116~7,C522~3,C601~4,C801~4,C815,C818 14
03074 ASM11 1 449-106DM-FG-21-2E CE 10μF/16V ±20% 4X5 105°C C202,C809 2
03074 ASM11 1 449-107DM-JG-21-6E CE 100μF/16V ±20% 6.3X5 105°C
C307,C816,C107,C410,C504,C817,C605,C819,C823,
C530 10
03074 ASM11 1 449-224FM-FG-21-2E CE 0.22μF/50V ±20% 4X5 105°C C104,C508~509 3
03074 ASM11 1 449-225FM-FG-21-2E CE 2.2μF/50V ±20% 4X5 105°C C607~610,C124,C507,C510,C520,C527~528 10
03074 ASM11 1 449-226DM-FG-21-2E CE 22μF/16V ±20% 4X5 105°C C303,C308~309,C503,C814,C305,C351 7
03074 ASM11 1 449-227DM-GP-11-4E CE 220μF/16V ±20% 5X11 85°C C606 1
03074 ASM11 1 449-338DM-R2-21-GE CE 3300μF/16V ±20% 12.5X25 105°C C810 1
03074 ASM11 1 449-476DM-GG-21-4E CE 47μF/16V ±20% 5X5 105°C C301~302,C304,C521,C822,C102,C821,C350,C825 9
03074 ASM11 1 461-1507J-00-01-0A RCF 15Ω1/2W ±5% RTS R813 1
03074 ASM11 1 461-2R27J-00-01-0A RCF 2Ω2 1/2W ±5% RTS R300,R811 2
03074 ASM11 1 481-N4001-EG-10-22 DIODE IN4001 D803 1
03074 ASM11 1 481-N5401-GO-50-22 DIODE IN5401 D801 1
03074 ASM11 1 490-B1243-00-D2-64 TR B1243 POWER SWITCH Q803,Q814 2
03074 ASM11 1 490-BD435-S0-00-04 T.R.BD435S SAMSUNG Q808 1
03074 ASM11 1 501-150L4-GX-00-00 15A DIN FUSE 1
03074 ASM11 1 514-1510K-MU-00-M4 STAND INDUCTOR 150μHL301 1
03074 ASM11 1 560-CM206-21-00-00 ANT SOCKET W/GND L=230MM ANT 1
03074 ASM11 1 520-45000-GP-0E-39 XT 4.5000MHZ(-20°C~+70°C) HC-49/US XT401 1
03074 ASM11 1 520-43320-GP-00-39 CRYSTAL 4.332MHZ DIP XT490 1
03074 ASM12 1 100-2313L-00-00-0G I.C.PT2313L SO-28 IC501 1
03074 ASM12 1 100-70350-00-00-0E I.C.KIA7035AF TO-92 IC402 1
03074 ASM12 1 100-MC455-80-00-0H IC MC4558 SOP DUAL OPERATIONAL AMPLIFIER IC601~2 2
03074 ASM12 1 442-102FK-00-00-0W CC 1000PF/50V ±10% SMT 0603(X7R) C118,C120,C123,C505~6,C805~8,C493 10
03074 ASM12 1 442-103FK-00-00-0W CC 0.01μF/50V ±10% SMT 0603(X7R) C103,C121~122 3
2

03074 ASM12 1 442-104DZ-00-00-0W CC 0.1μF/16V +80% -20% SMT 0603
C110~111,C519,C413,C820,C811,C141,C492,C494,
C529 10
03074 ASM12 1 442-153FM-00-00-0W CC 0.015μF/50V ±20% SMT 0603 C112,C113 2
03074 ASM12 1 442-223FM-00-00-0W CC 0.022μF/50V ±20% SMT 0603 C101,C105,C108~109,C201,C203,C411 7
03074 ASM12 1 442-224DZ-00-00-0W CC 0.22μF/16V +80% -20% SMT 0603 C306,C511~514 5
03074 ASM12 1 442-332FK-00-00-0W CC 3300PF/50V ±10% SMT 0603(X7R) C114,C115 2
03074 ASM12 1 460-0R00J-00-01-0V RMF 0Ω1/10W ±5% SMT 0805 R822,R126 2
03074 ASM12 1 460-101BJ-00-01-0W RMF 100Ω1/16W ±5% SMT 0603 R125,R131,R314~5,R401~5,R465,R614~7 14
03074 ASM12 1 460-1020J-00-01-0V RMF 1KΩ1/10W ±5% SMT 0805 R831,R827 2
03074 ASM12 1 460-102BJ-00-01-0W RMF 1KΩ1/16W ±5% SMT 0603 R101,R121,R202~5,R317,R816,R325~6,R333 11
03074 ASM12 1 460-103BJ-00-01-0W RMF 10KΩ1/16W ±5% SMT 0603
R102/110
,
R201
,
R301/316/319/324
,
R450
,
R518
~
21,
R527/532/534/535,R550~3,R607~8,R802,R832,R81
7~8,R823/824/828,R106 30
03074 ASM12 1 460-104BJ-00-01-0W RMF 100KΩ1/16W ±5% SMT 0603 R320,R819,R355,R462~463 5
03074 ASM12 1 460-151BJ-00-01-0W RMF 150Ω1/16W ±5% SMT 0603 R123 1
03074 ASM12 1 460-152BJ-00-01-0W RMF 1K5Ω1/16W ±5% SMT 0603 R124 1
03074 ASM12 1 460-154BJ-00-01-0W RMF 150KΩ1/16W ±5% SMT 0603 R352 1
03074 ASM12 1 460-184BJ-00-01-0W RMF 180KΩ1/16W ±5% SMT 0603 R313 1
03074 ASM12 1 460-1R0BJ-00-01-0W RMF 1Ω1/16W ±5% SMT 0603 R505 1
03074 ASM12 1 460-222BJ-00-01-0W RMF 2K2Ω1/16W ±5% SMT 0603 R421,R514~517,R620~623,R815,R112 11
03074 ASM12 1 460-223BJ-00-01-0W RMF 22KΩ1/16W ±5% SMT 0603 R103,R302,R310~311,R328,R460,R825~826 8
03074 ASM12 1 460-224BJ-00-01-0W RMF 220KΩ1/16W ±5% SMT 0603 R422,R530,R140,R354 4
03074 ASM12 1 460-331BJ-00-01-0W RMF 330Ω1/16W ±5% SMT 0603 R108,R526 2
03074 ASM12 1 460-332BJ-00-01-0W RMF 3K3Ω1/16W ±5% SMT 0603 R113~114,R541~542,R321 5
03074 ASM12 1 460-471BJ-00-01-0W RMF 470Ω1/16W ±5% SMT 0603 R122 1
03074 ASM12 1 460-472BJ-00-01-0W RMF 4K7Ω1/16W ±5% SMT 0603 R543~544,R801 3
03074 ASM12 1 460-473BJ-00-01-0W RMF 47KΩ1/16W ±5% SMT 0603
R117,R129,R303~8,R322,R329,R331,R418~9,R427,R
461,R464,R605~6,R611~2,R814,R451,R118 23
03074 ASM12 1 460-512BJ-00-01-0W RMF 5K1Ω1/16W ±5% SMT 0603 R533 1
03074 ASM12 1 460-562BJ-00-01-0W RMF 5K6Ω1/16W ±5% SMT 0603 R318,R506~507 3
03074 ASM12 1 460-563BJ-00-01-0W RMF 56KΩ1/16W ±5% SMT 0603 R312 1
03074 ASM12 1 460-564BJ-00-01-0W RMF 560KΩ1/16W ±5% SMT 0603 R330 1
3

03074 ASM12 1 460-752BJ-00-01-0W RMF 7K5Ω1/16W ±5% SMT 0603 R601~604,R610,R613,R618~619 8
03074 ASM12 1 460-823BJ-00-01-0W RMF 82KΩ1/16W ±5% SMT 0603 R531 1
03074 ASM12 1 490-39040-00-00-2H TR 3904(SMT SOT-23)NPN
Q101~4,Q109,Q201,Q203,Q301~8,Q310,Q402~3,Q4
60~3,Q501~5,Q802,Q804~5,Q813,Q312~3 33
03074 ASM12 1 490-39060-00-00-2H TR 3906(SMT SOT-23)PNP Q202,Q309,Q801,Q806,Q106 5
03074 ASM12 1 442-330FJ-00-00-0W CC 33PF/50V ±5% SMT 0603 C490,C491C401C402 4
03074 ASM12 1 100-BU192-40-00-00 IC BU1924 RDS DEMOUDULATOR IC490 1
03074 ASM12 1 100-7900R-00-00-0G I.C.DSC-790R(DONGSUNG) IC-7900R 1
03074 ASM12 1 442-105DZ-00-00-0V CC 1μF/16V +80% -20% SMT 0805 C125 1
03074 ASM13 1 215-0055A-05-00-11 JUMP WIRE 5.5MM ∮0.5MM J65,J75 2
03074 ASM13 1 215-0060A-05-00-11 JUMP WIRE 6MM ∮0.5MM J1,J21,J23,J34,J36,J38,J41,J43~44,J50,J74,J89 12
03074 ASM13 1 215-0070A-05-00-11 JUMP WIRE 7MM ∮0.5MM J31~32,J35,J39,J60,J68,J73 7
03074 ASM13 1 215-0075A-05-00-11 JUMP WIRE 7.5MM ∮0.5MM J47 1
03074 ASM13 1 215-0080A-05-00-11 JUMP WIRE 8MM ∮0.5MM J2,J3,J5,J6,J11,J20,J22,J46,J51,J55 10
03074 ASM13 1 215-0085A-05-00-11 JUMP WIRE 8.5MM ∮0.5MM J57 1
03074 ASM13 1 215-0090A-05-00-11 JUMP WIRE 9MM ∮0.5MM J61,J86,J90 3
03074 ASM13 1 215-0095A-05-00-11 JUMP WIRE 9.5MM ∮0.5MM J10,J12,J37 3
03074 ASM13 1 215-0100A-05-00-11 JUMP WIRE 10MM ∮0.5MM J9,J19,J66,J76,J93,J94 6
03074 ASM13 1 215-0105A-05-00-11 JUMP WIRE 10.5MM ∮0.5MM J42,J49,J81 3
03074 ASM13 1 215-0110A-05-00-11 JUMP WIRE 11MM ∮0.5MM J4,J40,J56,J70~72,J78~80,J84~85,J92 12
03074 ASM13 1 215-0120A-05-00-11 JUMP WIRE 12MM ∮0.5MM J24~25,J33,J58,J62~64,J67,J69,J87 10
03074 ASM13 1 215-0130A-05-00-11 JUMP WIRE 13MM ∮0.5MM J82 1
03074 ASM13 1 215-0135A-05-00-11 JUMP WIRE 13.5MM ∮0.5MM J7,J8,J13,J48 4
03074 ASM13 1 215-0140A-05-00-11 JUMP WIRE 14MM ∮0.5MM J77 1
03074 ASM13 1 215-0145A-05-00-11 JUMP WIRE 14.5MM ∮0.5MM J30,J59 2
03074 ASM13 1 215-0155A-05-00-11 JUMP WIRE 15.5MM ∮0.5MM J52~54 3
03074 ASM13 1 215-0160A-05-00-11 JUMP WIRE 16MM ∮0.5MM J18 1
03074 ASM13 1 215-0185A-05-00-11 JUMP WIRE 18.5MM ∮0.5MM J88 1
03074 ASM13 1 215-0190A-05-00-11 JUMP WIRE 19MM ∮0.5MM J27~29 3
03074 ASM13 1 215-0205A-05-00-11 JUMP WIRE 20.5MM ∮0.5MM J14~17 4
4

03074 ASM13 1 215-0250A-05-00-11 JUMP WIRE 25MM ∮0.5MM J45 1
03074 ASM13 1 215-0270A-05-00-11 JUMP WIRE 27MM ∮0.5MM J83 1
03074 ASM13 1 461-1001J-00-01-0A RCF 10Ω1/8W ±5% RTS R406 1
03074 ASM13 1 461-1005J-00-01-0A RCF 10Ω1/4W ±5% RTS R133 1
03074 ASM13 1 461-1011J-00-01-0A RCF 100Ω1/8W ±5% RTS R609,R540 2
03074 ASM13 1 461-1031J-00-01-0A RCF 10KΩ1/8W ±5% RTS R323,R206 2
03074 ASM13 1 461-1041J-00-01-0A RCF 100KΩ1/8W ±5% RTS R522~525 4
03074 ASM13 1 461-1541J-00-01-0A RCF 150KΩ1/8W ±5% RTS R528,R529 2
03074 ASM13 1 461-2221J-00-01-0A RCF 2K2Ω1/8W ±5% RTS R309,R353 2
03074 ASM13 1 461-2231J-00-01-0A RCF 22KΩ1/8W ±5% RTS R132 1
03074 ASM13 1 461-2241J-00-01-0A RCF 220KΩ1/8W ±5% RTS R539,R332 2
03074 ASM13 1 461-4711J-00-01-0A RCF 470Ω1/8W ±5% RTS R120,R452,R423 3
03074 ASM13 1 461-4721J-00-01-0A RCF 4K7Ω1/8W ±5% RTS R512~513,R414~415 4
03074 ASM13 1 461-6811J-00-01-0A RCF 680Ω1/8W ±5% RTS R812 1
03074 ASM13 1 481-N4148-CF-50-12 DIODE IN4148 1/2W
D102~5,D302~12,D401,D404~5,D408,D414,D416,D
425~6,D429~30,D501,D802,D805~6,D301 30
03074 ASM13 1 485-1007J-00-00-02 ZENER DIODE 10V 1/2W ZD802 1
03074 ASM13 1 485-3V37J-00-00-02 ZENER DIODE 3V3 1/2W ZD460 1
03074 ASM13 1 485-6V87J-00-00-02 ZENER DIODE 6.8V 1/2W ZD401~5,ZD803,ZD350,ZD301 8
03074 ASM13 1 510-4R70J-EG-00-02 COIL 4.7μH 3X5MM L201 1
03074 ASM13 1 485-5V17J-00-00-02 ZENER DIODE 5.1V 1/2W ZD501 1
03074 ASM14 1 118-CM206-FB-01-00 CM206 FLEX.FPC 1
03074 ASM14 1 220-20602-00-00-00 WASHER-22-025MM TOP OF THE SHAFT 10
03074 ASM14 1 220-20603-00-00-00 FELT-16-025MM TOP OF THE SHAFT 4
03074 ASM14 1 220-20604-00-00-00 FELT FOR GEAR INSIDE OF THE GEAR B 1
03074 ASM14 1 224-20601-01-00-00 DUST PROOF CABINET 1
03074 ASM14 1 249-20602-00-00-00 LIGHT GUIDE CABINET BACK OF THE CABINET 1
03074 ASM14 1 251-20600-00-00-00 CABINET FRONT OF THE FRAME 1
03074 ASM14 1 253-20601-00-00-00 RIGHT SLIDE GUIDE INSIDE OF THE BOTTOM FRAME 1
03074 ASM14 1 253-20602-00-00-00 LEFT SLIDE GUIDE INSIDE OF THE BOTTOM FRAME 1
03074 ASM14 1 253-20603-00-00-00 RIGHT RACK TOP OF THE BOTTOM FRAME 1
5

03074 ASM14 1 253-20604-00-00-00 LOCK RING INSIDE OF THE GEAR-B 1
03074 ASM14 1 253-20605-00-00-00 WORM GEAR FRONT OF THE MOTOR 1
03074 ASM14 1 253-20606-00-00-00 LOCK DOUBLESIDE OF THE BRACKET PANEL 2
03074 ASM14 1 253-20607-00-00-00 CONNECTOR COVER BACK OF THE CONNECT 15PIN EST 1
03074 ASM14 1 253-20608-00-00-00 GEAR-A-AND-GEAR-B TOP OF THE RIGHT RACK 1
03074 ASM14 1 253-20609-00-00-00 GEAR-A INSIDE OF THE GEAR-B 1
03074 ASM14 1 253-20610-00-00-00 GEAR-B LEFTWARD OF THE FRONT FRAME 1
03074 ASM14 1 290-20601-00-00-00 BUSH1 INSIDE OF THE GEAR-B 1
03074 ASM14 1 290-20602-00-00-00 CAP1 OUTSIDE OF THE GEAR-B 1
03074 ASM14 1 310-20601-00-00-01 SHAFT ∮2.48*12.15MM GEAR TO FRONT FRAME 1
03074 ASM14 1 310-20602-00-00-01 SHAFT ∮5.78*9.95MM GEAR-A-B TO FRONT FRAME 1
03074 ASM14 1 310-20603-00-00-01 SHAFT ∮1.98*4.1MM LEFT SLIDE GUIDE TO FRONT FRAME 2
03074 ASM14 1 310-20605-00-00-01 SHAFT ∮2.48*3.3MM LEFT/RIGHT ARM TO BRACKET PANEL 2
03074 ASM14 1 310-20606-00-00-01 SHAFT ∮4.0*2.9MM BOTTOM FRAME TO BRACKET PANEL 2
03074 ASM14 1 310-20607-00-00-01 SHAFT ∮2.48*1.55MM LEFT/RIGHT ARM TO FRONT FRAME 2
03074 ASM14 1 310-20608-00-00-01 SHAFT ∮1.98*5.3MM RIGHT SLIDE GUIDE TO BRACKET SLIDE 2
03074 ASM14 1 335-20602-00-00-01 FRONT FRAME TOP OF THE FRAME 1
03074 ASM14 1 335-20604-00-00-00 LEFT ARM LEFTWARD OF THE FRONT FRAME 1
03074 ASM14 1 335-20605-00-00-00 RIGHT ARM RIGHTWARD OF THE FRONT FRAME 1
03074 ASM14 1 335-20606-00-00-00 BRACKET SLIDE OUTSIDE OF THE FRONT FRAME 1
03074 ASM14 1 335-20607-00-00-00 BRACKET PANEL FRONT OF THE CABINET 1
03074 ASM14 1 374-20601-00-00-00 SPRING CABINET ON THE LOCK 2
03074 ASM14 1 374-20602-00-00-00 SPRING FOR GEAR INSIDE OF THE GEAR B 1
03074 ASM14 1 380-CM206-01-05-6E 5PIN FLAT CABLE GREY P=2.0 1
03074 ASM14 1 384-CM206-02-15-6E 15PIN SOCKET MALE ESTF-15-3-Z ON THE CABINET 1
03074 ASM14 1 401-ESE11-HS-10-00 SWITCH REAR ON THE PCB MOTOR 1
03074 ASM14 1 401-ESE11-HS-20-00 SWITCH FRONT ON THE PCB MOTOR 1
03074 ASM14 1 435-16040-00-10-00 SCREW PM1604 RIGHT RACK TO BOTTOM FRAME 3
03074 ASM14 1 435-20015-70-03-00 SCREW BM20015 LEFT ARM&RIGHT ARM TO BRACKET PANEL 2
03074 ASM14 1 435-20030-70-00-00 SCREW BM2003 FRONT FRAME TO CABINET 4
03074 ASM14 1 435-20030-70-20-00 SCREW BM2003 BRACKET SLIDE TO FRONT FRAME 1
6

03074 ASM14 1 435-20030-80-10-00 SCREW PFM2003 MOTOR TO FRONT FRAME 2
03074 ASM14 1 435-20060-75-20-00 SCREW BTP2006 LIGHT GUIDE CABINET TO CABINET 2
03074 ASM14 1 435-20070-70-10-00 SCREW BM2007 PCB MOTOR TO FRONT FRAME 2
03074 ASM14 1 437-20301-80-00-00 M2X4 CM CYLINDER SCREW LOCK TO CABINET 2
03074 ASM14 1 901-20600-00-00-00 DOUBLE SIDE TAPE FOR LENS LENS-PANEL FRONT 0,5
03074 ASM14 1 322-FF050-SK-10-20 MOTOR MABUCHI FF-050SK ON THE FRONT FRAME 1
03074 ASM14 1 335-20603-00-00-01 BOTTOM FRAME INSIDE OF THE FRONT FRAME 1
03074 ASM2 1 250-20600-07-00-00 RIM FRONT OF THE BODY 1
03074 ASM2 1 435-20070-25-00-00 SCREW FTP2007 LENS TO PANEL BACK 4
03074 ASM2 1 901-20600-00-00-00 DOUBLE SIDE TAPE FOR LENS LENS-PANEL FRONT 2
03074 ASM2 1 241-22600-01-00-00 PANEL BACK FOR CM226 BACK OF THE HOUSING 1
03074 ASM2 1 249-22600-00-00-00 LIGHT GUIDE VOL OUT OF THE ENCODER 1
03074 ASM2 1 249-22601-00-00-00 LINING KNOB LOUD&POWER LINING KNOB LOUD&POWER 1
03074 ASM2 1 240-22600-00-07-00 PANEL FRONT FOR CM226 FRONT OF THE HOUSING 1
03074 ASM2 1 245-22601-00-07-00 KNOB AMS&AF FOR CM226 INSIDE OF THE PANEL 1
03074 ASM2 1 245-22603-00-07-00 KNOB SRC FOR CM226 INSIDE OF THE PANEL 1
03074 ASM2 1 245-22602-00-07-00 KNOB EJECT FOR CM226 INSIDE OF THE PANEL 1
03074 ASM2 1 245-22604-00-07-00 KNOB NUM FOR CM226 INSIDE OF THE PANEL 1
03074 ASM2 1 245-22605-00-05-00 KNOB ENCODER FOR CM226 OUT OF THE ENCODER 1
03074 ASM2 1 245-22606-00-07-00 KNOB SLIDE FOR CM226 FRONT OF THE PANEL 1
03074 ASM2 1 245-22607-00-07-00 KNOB BAND&DISP FOR CM226 FRONT OF THE PANEL 1
03074 ASM2 1 245-22609-00-07-00 SHELL KNOB POWER&MUTE FOR CM226 OUT OF THE LINING KNOB LOUD&POWER 1
03074 ASM2 1 245-22610-00-07-00 SHELL KNOB NEXT FOR CM226 OUT OF THE LINING KNOB LOUD&POWER 2
03074 ASM2 1 245-22611-00-07-00 SHELL KNOB TA FOR CM226 OUT OF THE LINING KNOB LOUD&POWER 1
03074 ASM2 1 245-22612-00-07-00 SHELL KNOB PTY FOR CM226 OUT OF THE LINING KNOB LOUD&POWER 1
03074 ASM2 1 247-22601-00-08-00 LENS OF CM226/RDS FRONT OF THE PANEL 1
03074 ASM2 1 253-22600-00-05-00 ORNAMENT RING FOR CM226 FRONT OF THE PANEL 1
03074 ASM2 1 253-22601-00-05-00 ORNAMENT RIB FOR CM226 INSIDE OF THE PANEL 1
03074 ASM20 1 335-20301-00-10-00 LCD-COVER FRONT OF THE LCD 1
03074 ASM20 1 289-CM203-00-00-10 LCD BACKLIGHT BACK OF THE LCD 1
03074 ASM20 1 580-20301-00-00-01 ZEBRA STRIP INSIDE OF THE LCD COVER 1
7

03074 ASM21 1 384-CM206-01-15-6E 15PIN SOCKET FEMALE DSTF-15-3-T CON 1
03074 ASM21 1 468-ECB11-10-06-00 ECB11(7X5)(PV)S14.5 ENVOL 1
03074 ASM21 1 485-3V37J-00-00-02 ZENER DIODE 3V3 1/2W ZD5~D7 3
03074 ASM21 1 105-CM700-02-11-00 CM700 LCD LCD1 1
03074 ASM21 1 485-6V87J-00-00-02 ZENER DIODE 6.8V 1/2W ZD1~ZD4 4
03074 ASM21 1 481-N4148-CF-50-12 DIODE IN4148 1/2W D1 1
03074 ASM22 1 100-LC758-23-E0-0G IC LC75823E LCD DRIVE IC1 1
03074 ASM22 1 401-1101E-11-L0-12 KEY SWITCH 4.3MM SW101~114 14
03074 ASM22 1 410-22100-00-10-R4 LED 2.2V RED SMT 0603 LED1~20 20
03074 ASM22 1 442-102FK-00-00-0W CC 1000PF/50V ±10% SMT 0603(X7R) C1 1
03074 ASM22 1 442-105DZ-00-00-0V CC 1μF/16V +80% -20% SMT 0805 C2,C3,C104 3
03074 ASM22 1 460-102BJ-00-01-0W RMF 1KΩ1/16W ±5% SMT 0603 R8,R15 2
03074 ASM22 1 460-103BJ-00-01-0W RMF 10KΩ1/16W ±5% SMT 0603 R16,R2,R44 3
03074 ASM22 1 460-152BJ-00-01-0W RMF 1K5Ω1/16W ±5% SMT 0603 R9,R35 2
03074 ASM22 1 460-181BJ-00-01-0W RMF 180Ω1/16W ±5% SMT 0603 R3 1
03074 ASM22 1 460-220BJ-00-01-0W RMF 22Ω1/16W ±5% SMT 0603 R18~21 4
03074 ASM22 1 460-221BJ-00-01-0W RMF 220Ω1/16W ±5% SMT 0603 R4 1
03074 ASM22 1 460-222BJ-00-01-0W RMF 2K2Ω1/16W ±5% SMT 0603 R10 1
03074 ASM22 1 460-331BJ-00-01-0W RMF 330Ω1/16W ±5% SMT 0603 R5,R36 2
03074 ASM22 1 460-332BJ-00-01-0W RMF 3K3Ω1/16W ±5% SMT 0603 R11 1
03074 ASM22 1 460-4710J-00-01-0V RMF 470Ω1/10W ±5% SMT 0805 R25~34 10
03074 ASM22 1 460-471BJ-00-01-0W RMF 470Ω1/16W ±5% SMT 0603 R6,R14 2
03074 ASM22 1 460-473BJ-00-01-0W RMF 47KΩ1/16W ±5% SMT 0603 R1,R12~13,R22,R23,R41 6
03074 ASM22 1 460-681BJ-00-01-0W RMF 680Ω1/16W ±5% SMT 0603 R7,R46 2
03074 ASM22 1 460-822BJ-00-01-0W RMF 8K2Ω1/16W ±5% SMT 0603 R17 1
03074 ASM22 1 490-39040-00-00-2H TR 3904(SMT SOT-23)NPN Q1 1
03074 ASM22 1 490-343TK-00-00-2H TR DTC343TK(SMT SOT-23) Q2~4 3
03074 ASM22 1 460-1510J-00-01-0V RMF 150Ω1/10W ±5% SMT 0805 R24 1
03074 ASM22 1 460-391BJ-00-01-0W RMF 390Ω1/16W ±5% SMT 0603 R37 1
03074 ASM22 1 460-0R0BJ-00-01-0W RMF 0Ω1/16W ±5% SMT 0603 R48,R39,R50 3
03074 ASM22 1 401-11076-11-L0-00 KEY SWITCH 2.5MM TS1107GS-2 SW115-~119 5
8

03074 ASM22 1 112-CM226-KB-2G-00 CM226KB D/S 166X41X1.2MM 1
03074 ASM22 1 460-512BJ-00-01-0W RMF 5K1Ω1/16W ±5% SMT 0603 R40 1
03074 ASM22 1 460-684BJ-00-01-0W RMF 680KΩ1/16W ±5% SMT 0603 R42 1
03074 ASM22 1 460-334BJ-00-01-0W RMF 330KΩ1/16W ±5% SMT 0603 R43 1
03074 ASM22 1 460-272BJ-00-01-0W RMF 2K7Ω1/16W ±5% SMT 0603 R45 1
03074 ASM22 1 444-226BM-00-11-0Q CT 22μF/6.3V ±20% SMT 1206 C105 1
03074 CHASS1 1 180-10008-00-10-01 LASER WARNING LABEL 1
03074 CHASS1 1 225-20603-00-00-00 SPONGE FOR FPC TO SERVO BOARD 1
03074 CHASS1 1 335-20608-00-00-00 BRACKET KOMEC DECK BACK BACK OF DECK 1
03074 CHASS1 1 335-20609-00-00-01 BRACKET KOMEC DECK FRONT FRONT OF DECK 1
03074 CHASS1 1 360-01000-00-00-00 CD DECK CDX100(KOMEC) 1
03074 CHASS1 1 435-20040-54-21-00 SCREW M2.0X4.0 PW SB TO DECK 4
03074 CHASS1 1 435-26050-04-10-00 SCREW PTS2605 BRACKET TO DECK 5
03074 CHASS11 1 112-CM206-SB-2G-00 CM206 MP3 SERVO PCB D/S 112*93.5*1.2MM 1
03074 CHASS11 1 214-AWG30-3P-10-CM CM 3P*100MM CONNECTION WIRE 1
03074 CHASS11 1 218-01000-00-25-00 25PIN FFC 1.25MM L=100MM 1
03074 CHASS11 1 384-CM206-01-04-6E PH-4AW PH=2.0MM CONNECTOR CON903 1
03074 CHASS11 1 401-CM206-00-00-01 CD DETECTOR CDX100 SW901 1
03074 CHASS11 1 410-IR928-6C-00-00 PHOTOTRANSISTOR IR928-6C LED901,LED902 2
03074 CHASS11 1 449-106DM-FG-21-2E CE 10μF/16V ±20% 4X5 105°C CE903,CE905~906,CE908~909 5
03074 CHASS11 1 449-107DM-JG-21-6E CE 100μF/16V ±20% 6.3X5 105°C CE907,CE910~912 4
03074 CHASS11 1 449-475FM-FG-21-2E CE 4.7μF/50V ±20% 4X5 105°C CE901 1
03074 CHASS11 1 449-476DM-GG-21-4E CE 47μF/16V ±20% 5X5 105°C CE902,CE904 2
03074 CHASS11 1 520-16934-GP-0E-09 XT 16.9344MHZ(-10°C~+60°C) XT901 1
03074 CHASS12 1 100-04X04-00-00-0G IC DRAM 4MX4 TSOP 3.3V IC905 1
03074 CHASS12 1 100-09226-00-00-0G IC.S1L9226 IC901 1
03074 CHASS12 1 100-09259-00-00-0G IC.KA9259D IC904 1
03074 CHASS12 1 100-09276-00-00-0G IC S5L9276 IC903 1
03074 CHASS12 1 100-09290-00-00-0G IC.S5L9290 IC902 1
03074 CHASS12 1 384-CM206-01-17-6E 17PIN FPC SOCKET 1.0MM CON901 1
03074 CHASS12 1 442-102FK-00-00-0W CC 1000PF/50V ±10% SMT 0603(X7R) C904,C943 2
9

03074 CHASS12 1 442-103FK-00-00-0W CC 0.01μF/50V ±10% SMT 0603(X7R) C905,C913~914,C924,C926~927,C948,C993 8
03074 CHASS12 1 442-104DZ-00-00-0W CC 0.1μF/16V +80% -20% SMT 0603
C906~8,C910~911,C920~3,C925,C929,C934~5,C941
,C944~7,C949~950,C991 21
03074 CHASS12 1 442-152FK-00-00-0W CC 1500PF/50V ±10% SMT 0603 C936~937 2
03074 CHASS12 1 442-153FM-00-00-0W CC 0.015μF/50V ±20% SMT 0603 C928 1
03074 CHASS12 1 442-222FK-00-00-0W CC 2200PF/50V ±10% SMT 0603(X7R) C909,C918,C930~931 4
03074 CHASS12 1 442-224DZ-00-00-0W CC 0.22μF/16V +80% -20% SMT 0603 C916 1
03074 CHASS12 1 442-330FJ-00-00-0W CC 33PF/50V ±5% SMT 0603 C938~939 2
03074 CHASS12 1 442-333FM-00-00-0W CC 0.033μF/50V ±20% SMT 0603 C932 1
03074 CHASS12 1 442-391FK-00-00-0W CC 390PF/50V ±10% SMT 0603 C917,C919 2
03074 CHASS12 1 442-472FK-00-00-0W CC 4700PF/50V ±10% SMT 0603 C903 1
03074 CHASS12 1 442-474DZ-00-00-0W CC 0.47μF/16V +80% -20% SMT 0603 C912,C933 2
03074 CHASS12 1 442-4P7FD-00-00-0W CC 4.7PF/50V ±0.5P SMT 0603 C901 1
03074 CHASS12 1 442-683FM-00-00-0W CC 0.068μF/50V ±20% SMT 0603 C915 1
03074 CHASS12 1 442-821FK-00-00-0W CC 820PF/50V ±10% SMT 0603 C940 1
03074 CHASS12 1 442-8P2FD-00-00-0W CC 8.2PF/50V ±0.5P SMT 0603 C902 1
03074 CHASS12 1 460-0R0BJ-00-01-0W RMF 0Ω1/16W ±5% SMT 0603 R914 1
03074 CHASS12 1 460-100BJ-00-01-0W RMF 10Ω1/16W ±5% SMT 0603 R917 1
03074 CHASS12 1 460-102BJ-00-01-0W RMF 1KΩ1/16W ±5% SMT 0603 R925,R933,R936,R991 4
03074 CHASS12 1 460-103BJ-00-01-0W RMF 10KΩ1/16W ±5% SMT 0603 R905,R943,R993~994 4
03074 CHASS12 1 460-104BJ-00-01-0W RMF 100KΩ1/16W ±5% SMT 0603 R934,R937 2
03074 CHASS12 1 460-105BJ-00-01-0W RMF 1MΩ1/16W ±5% SMT 0603 R932,R938,R996~998 5
03074 CHASS12 1 460-124BJ-00-01-0W RMF 120KΩ1/16W ±5% SMT 0603 R995 1
03074 CHASS12 1 460-151BJ-00-01-0W RMF 150Ω1/16W ±5% SMT 0603 R941 1
03074 CHASS12 1 460-153BJ-00-01-0W RMF 15KΩ1/16W ±5% SMT 0603 R908,R929 2
03074 CHASS12 1 460-154BJ-00-01-0W RMF 150KΩ1/16W ±5% SMT 0603 R907,R922~923 3
03074 CHASS12 1 460-184BJ-00-01-0W RMF 180KΩ1/16W ±5% SMT 0603 R912 1
03074 CHASS12 1 460-203BJ-00-01-0W RMF 20KΩ1/16W ±5% SMT 0603 R928 1
03074 CHASS12 1 460-204BJ-00-01-0W RMF 200KΩ1/16W ±5% SMT 0603 R926 1
03074 CHASS12 1 460-223BJ-00-01-0W RMF 22KΩ1/16W ±5% SMT 0603 R909,R945~950 7
03074 CHASS12 1 460-224BJ-00-01-0W RMF 220KΩ1/16W ±5% SMT 0603 R902,R910 2
10

03074 CHASS12 1 460-274BJ-00-01-0W RMF 270KΩ1/16W ±5% SMT 0603 R906 1
03074 CHASS12 1 460-2R2BJ-00-01-0W RMF 2Ω2 1/16W ±5% SMT 0603 R989 1
03074 CHASS12 1 460-303BJ-00-01-0W RMF 30KΩ1/16W ±5% SMT 0603 R911 1
03074 CHASS12 1 460-332BJ-00-01-0W RMF 3K3Ω1/16W ±5% SMT 0603 R931 1
03074 CHASS12 1 460-333BJ-00-01-0W RMF 33KΩ1/16W ±5% SMT 0603 R956~957,R963~966 6
03074 CHASS12 1 460-392BJ-00-01-0W RMF 3K9Ω1/16W ±5% SMT 0603 R903 1
03074 CHASS12 1 460-472BJ-00-01-0W RMF 4K7Ω1/16W ±5% SMT 0603 R951~955,R990 6
03074 CHASS12 1 460-473BJ-00-01-0W RMF 47KΩ1/16W ±5% SMT 0603 R904,R916,R940,R942,R944,R958~962 10
03074 CHASS12 1 460-682BJ-00-01-0W RMF 6K8Ω1/16W ±5% SMT 0603 R901,R992 2
03074 CHASS12 1 460-683BJ-00-01-0W RMF 68KΩ1/16W ±5% SMT 0603 R915,R918~921,R913 6
03074 CHASS12 1 460-820BJ-00-01-0W RMF 82Ω1/16W ±5% SMT 0603 R924 1
03074 CHASS12 1 460-822BJ-00-01-0W RMF 8K2Ω1/16W ±5% SMT 0603 R930 1
03074 CHASS12 1 490-39060-00-00-2H TR 3906(SMT SOT-23)PNP Q901 1
03074 CHASS3 1 163-10000-04-07-00 REMOTE CELL POLY BAG UNIT 1
03074 CHASS3 1 590-8605S-GK-40-61 REMOTE-CRM HEADER(IRM2038F4) REM1 1
03074 CHASS3 1 225-20602-00-00-00 REMOTE CONTROL SPONGE 1
03074 CHASS3 1 225-20601-00-00-00 SHADE SPONGE 1
03074 CHASS3 1 567-20300-00-31-00 REMOTE CONTROL FORYOU 1
03074 CHASS4 1 111-CM206-CB-11-00 FILTER PCB S/S 36*30*1.6MM 1
03074 CHASS4 1 251-20601-00-00-00 FILTER BOX 1
03074 CHASS4 1 384-CM206-02-20-6E 20PIN PWR/SPK WIRE EST-KNT-20-05 1
03074 CHASS4 1 512-CM206-00-00-01 CHOKE 470μH(CM206) L801 1
03074 PACKING 1 130-20600-00-11-00 CARTON 0,17
03074 PACKING 1 134-10101-00-00-00 BROWN BOX 1
03074 PACKING 1 161-10101-00-00-01 PE FOAM L 1
03074 PACKING 1 161-10102-00-00-01 PE FOAM R 1
03074 PACKING 1 163-10000-05-08-10 POLY BAG SCREW 1
03074 PACKING 1 163-10000-08-15-10 POLY BAG SIDE LOCK 1
03074 PACKING 1 163-10000-10-26-10 POLY BAG RIM 3
03074 PACKING 1 163-10000-16-25-10 POLY BAG MANUAL 1
03074 PACKING 1 163-10000-28-35-10 POLY BAG UNIT 1
11

03074 PACKING 1 180-10002-00-10-00 SERIAL NO.LABEL FRAME,WARRANTY CARD OF MANUAL;GIFT BOX 3
03074 PACKING 1 180-10003-00-10-01 QC PASS LABEL BOTTOM OF FRAME 1
03074 PACKING 1 180-10009-00-10-00 WHITE LABEL 1
03074 PACKING 1 180-10011-00-10-00 WARRANTY LABEL (ENGLISH) JOINT OF TOP COVER & FRAME 1
03074 PACKING 1 180-20600-00-02-00 E1 LABEL 1
03074 PACKING 1 180-30102-00-10-00 SCREW WARNNING LABEL(ENGLISH) DECK 2
03074 PACKING 1 225-10001-01-0A-00 RUBBER 1
03074 PACKING 1 229-10001-00-00-00 SPONGE FOR PANEL BOX 2
03074 PACKING 1 251-10000-04-00-00 PANEL BOX 1
03074 PACKING 1 310-10001-00-0A-00 POLE 1
03074 PACKING 1 335-10005-00-0A-00 SIDE LOCK 2
03074 PACKING 1 435-50060-70-10-00 SCREW M5.0X6.0 FRAME T/N 4
03074 PACKING 1 131-22600-00-10-00 GIFT BOX FOR CM226 1
03074 PACKING 1 170-22600-00-10-00 MANUAL FOR CM226 1
03074 PACKING 1 180-22600-00-10-00 MODEL LABEL OF CM226 TOP COVER 1
03074 SUNDRY 1 220-20605-00-00-00 WASHER ∮3.0*0.6MM 4
03074 SUNDRY 1 910-20000-00-00-00 PP TAPE(PVC)2" 1
03074 SUNDRY 1 936-10003-00-00-00 TRANSPARENT GLUE 1
03074 SUNDRY 1 940-10001-00-00-00 MOISTUREPROOF PELLET 1
03074 SUNDRY 1 950-10200-00-00-00 SOLDER WIRED 1.02MM 1
03074 SUNDRY 1 951-20600-00-00-00 STANNUM SLURRY 1
03074 SUNDRY 1 955-10001-00-00-00 HEATSINK OIL 1
03074 SUNDRY 1 960-10001-00-00-00 GREASE 1
12
