Akai KS390 User manual

CD+G KARAOKE PLAYER
WITH LIGHT EFFECT
INSTRUCTION MANAUL
KS390
Thank you for purchasing this CD player. Please read this instruction manual carefully
before using this product to ensure proper use. Keep this manual in a safe place for future
reference.

1
WARNINGS
WARNING: TO REDUCE THE RISK OF
FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER OR BACK. NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED PERSONNEL.
The CAUTION marking is located on the rear panel.
This symbol is intended to alert you to the
presence of uninsulated dangerous
voltage within the product’s enclosure that
might be of sufficient magnitude to
constitute a risk of electric shock. Do not
open the product’s case.
This symbol is intended to inform you that
important operating and maintenance
instructions are included in the literature
accompanying this product.
DRIPPING WARNING
The product shall not be exposed to dripping or
splashing and that no objects filled with liquids, such as
vases, shall be placed on the product.
VENTILATION WARNING
The normal ventilation of the product shall not be
impeded for intended use.
Warning: Changes or modification to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment.
SAFETY CERTIFICATION
This device is made and tested to meet safety standards
of the FCC, requirements and compliance with safety
performance of the U.S. Department of Health and
Human Services, and also with FDA Radiation
Performance Standards 21 CFR Subchapter J.
Main plug is used as disconnect device and it should
remain readily operable during intended use. In order to
disconnect the apparatus from the mains completely, the
main plug should be disconnected from the main socket
outlet completely.
Warnings:
•This CD player employs a laser light beam. Only a
qualified service person should remove the cover or
attempt to service this device, due to possible eye
injury.
•The use of controls, adjustments, or procedures other
than those specified herein might result in hazardous
radiation exposure.
•The apparatus shall be used in an open area.
CAUTION
This compact disc player is classified as a CLASS 1
LASER product.
The CLASS 1 LASER PRODUCT label is located on the
rear panel.
CAUTION!
Invisible laser radiation when open and inter locks
defeated. Avoid exposure to beam.
FCC IMPORTANT
Since CD circuitry may cause interference to other radio
tuners nearby, switch this unit off when not in use or
move it away from the affected radio tuner.
This device complies with part 15 of the FCC rules,
operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
This class [B] digital apparatus complies with Canadian
ICES-003.
Class II equipment symbol
This symbol indicates that the unit has a
double insulation system.

2
WARNINGS
NOTE: This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set
out in the Radio Interference Regulations of Industry Canada. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television (which can be determined by turning the equipment off),
the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/ TV technician for help.
IMPORTANT SAFETY INSTRUCTIONS
1. Read Instructions – All the safety and operating instructions should be read before the product is operated.
2. Retain Instructions – The safety and operating instructions should be retained for future reference.
3. Heed Warnings - All warnings on the product and in the operating instruction should be adhered to.
4. Follow Instructions - All operating and use instructions should be followed.
5. Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a dry cloth only for cleaning the exterior only. Do NOT attempt to clean the inside.
6. Attachments – Do not use attachments not recommended by the product manufacturer as they may cause hazards.
7. Water and Moisture – Do not use this product near water – for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement, or near a swimming pool, and the like.
8. Accessories – Do not place this product on an unstable cart, stand tripod, bracket, or table. The product may fall,
causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod,
bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should
follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.
9. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may
cause the appliance and cart combination to overturn.
10. Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the
product and to protect it from overheating, and these openings must not be blocked or covered. The openings should
never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be
placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided.
11. Power Sources – This product should be operated only from the type of power source indicated on the marking
label. If you are not sure of the type of power supply to your home, consult your product dealer or local power
company. For products intended to operate from battery power, or other sources, refer to the operating instruction.
12. Grounding or Polarization – This product may be equipped with a polarized alternating current line plug (a plug
having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If
you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact
your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
Alternate Warnings – This product may be equipped with a three-wire grounding-type plug, a plug having a third
(grounding) pin. This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to
insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the grounding-type plug.
13. Power-Cord Protection – Power supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles,
and the point where they exit from the product.

3
IMPORTANT SAFETY INSTRUCTIONS
14. Outdoor Antenna Grounding – if an outside antenna is
connected to the receiver, be sure the antenna system is
grounded so as to provide some protection against
voltage surges and built-up static charges. Article 810 of
the National Electrical Code, ANSI/NFPA70, provides
information with regard to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to
an antenna-discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to
grounding electrodes, and requirements for the grounding
Electrode. See figure:
15. Lightning – For added protection for this product during a lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line surges.
16. Power Lines – An outside antenna system should not be located in the vicinity of over head power lines or other
electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with
them might be fatal.
17. Overloading – Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result
in a risk of fire or electric shock.
18. Object and Liquid Entry – Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind
on the product.
19. Serving – Do not attempt to service this product yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
20. Damage Requiring Service – Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) Liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions as an improper adjustment of other controls may
result in damage and will of then require extensive work by a qualified technician to restore the product
to its normal operation.
e) If the product has been dropped or damaged in anyway, and
f) When the product exhibits a distinct change in performance – this indicates a need for service.
21. Replacement Parts – When replacement parts are required, be sure the service technician has used replacement
parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
22. Safety Check – Upon completion of any service or repairs to this product, ask the service technician to perform
safety checks to determine that the products is in proper operating condition.
23. Wall or Ceiling Mounting – The product should be mounted to a wall or ceiling only as recommended by the
manufacturer.
24. Heat – The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
25. Unplug this apparatus during lighting storms or when unused for long periods of time.
26. This appliance is not intended for use by persons (including children) with reduced physical, sensory or metal
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
27. Children should be supervised to ensure that they do not play with the appliance.
28. Ensure children and babies do not play with plastic bags or any packaging materials.

4
CONTROL LOCATION
FRONT VIEW
BACK VIEW
1. LED Display
2. PLAY/PAUSE Indicator
3. CDG Playing Indicator
4. MASTER VOLUME Control
5. SKIP Button
6. REPEAT Button
7. PLAY/PAUSE Button
8. SKIP Button
9. STOP Button
10. PROGRAM Button
11. CD Door Open Area
12. ON/OFF Button
13. A.V.C Button
14. LIGHT ON/OFF Button
15. SCAN Button
16. RESET Button
17. CD Door
18. Right Loudspeaker
19. REPEAT Indicator
20. PROGRAM Indicator
21. CD/RADIO/AUX Selector
22. MIC VOLUME Control
23. ECHO Control
24. BALANCE Control
25. Left Loudspeaker
26. LINE IN Jack
27. VIDEO OUT Jack
28. AUDIO OUT Jack
29. MIC 1 Jack
30. MIC 2 Jack
31. DC Jack
32. Carry Handle
33. Battery Door

5
CONTROL LOCATION
Battery Precautions (Use UM-2 or C-Size x 6 pcs)
The precautions below should be followed when using batteries in this device:
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing the batteries as indicated in the battery
compartment. Reversed batteries may cause damage to the device.
3. Do not mix different type of batteries together (e.g. Alkaline and Carbon Zinc) or old batteries with
fresh ones.
4. If the device is not to be used for a long period of time, remove the batteries to prevent damage or
injury from possible battery leakage.
5. Do not try to recharge batteries not intended to be recharged, they can overheat and rupture (Follow
battery manufacturer’s directions).
6. Rechargeable batteries are to be removed from the product before being charged.
7. Rechargeable batteries are only to be charged under adult supervision.
8. Exhausted batteries are to be removed from the product
9. The supply terminals are not to be short-circuited.
10. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.

6
MAKING THE CONNECTIONS
CONNECTING POWER
Plug the supplied power adaptor small end into the DC jack
located on the rear panel, plug the adaptor into the standard
AC wall socket.
CAUTION: The unit s designed to operate from a mains
supply of AC 100-240V~50/60Hz. If the adaptor does not fit
properly, turn it over and try again. Do not force it.
NOTES: When the unit is not operated by the AC power or
unused for long periods of time. Please remove the power
adaptor from the wall outlet and unplug from the main unit.
DC OPEARATION
1. Lift battery door to reveal battery compartment. Insert six (6) “C” size alkaline batteries (not provided)
as indicated.
2. Replace cover tightly before operating.
3. When not using batteries for a long period of time, remove batteries to prevent leakage in
compartment. Replace all batteries at the same time. Do not mix old batteries with new ones.
IMPORTANT: The power adaptor MUST be disconnected from the unit, if the unit operates on battery
power. When unused for long periods of time and please remove the batteries from the main unit.
CONNECTING TO YOUR TV OR VCR/ DVD PLAYER
Your CDG machine is designed to connect to your TV the same way you would connect most video
cameras, VCR/ DVD players or video games consoles.
We have provided RCA cables to connect your unit to a TV, VCR/ DVD player, video device or an external
audio/ sound system. The RCA cables have three connection at each end (white and red are for left and
right audio connections and the yellow is for video connections).
Please follow the steps below to display CD+G lyrics on the TV screen:
1. Locate the multi-colored RCA cables
2. Connect video cable (yellow) to the Video Out of the back of the CDG Machine
3. Connect the other end of the video cable (yellow) to the video input on your TV or VCR/ DVD player.

7
MAKING THE CONNECTIONS
SELECTING YOUR CDG MACHINE AS YOUR SOURCE/ INPUT
Selecting your CDG Machine as a source/ input on your TV is very similar to connecting a VCR/ DVD or
Satellite system.
We have listed below the most common ways of selecting the source from your TV or VCR/ DVD player:
1. In the set up menu of the TV or VCR / DVD player there may be an option for “Input Select” where
you can choose between “Cable/ Ant., Video 1, Video 2, etc” as the input source.
2. Look for a TV channel between the highest and lowest on your TV or VCR/ DVD player (i.e. AUX,
EXT, LINE 1 or LINE IN)
3. Your remote control for either your TV or VCR/ DVD player may have source input selections as well
as detailed as the following: “Video, Video 1, Game, AUX, EXT or LINE-IN.” Choosing one of those
sources in most cases should display the lyrics from your CDG Machine as well.
AUDIO CONNECTION
Please follow the steps below to connect the unit to your display CD+G or TV screen or home stereo
system.
1. Locate the multi-colored RCA cables.
2. Connect audio cables (White and Red) to the Audio Out of the back of the CDG Machine.
3. Connect the other end of the audio cables to the Audio/ Auxiliary input on your TV or VCR or home
stereo system.

8
CD OR CD+G OPERATION
The unit designed to play CDs and CD+Gs bearing the
identification logo respectively. If the disc does not
confirm to the standard, it may not play properly.
TURNING ON/OFF
•To turn on the CDG Machine, press the ON/OFF button once, the ON/OFF button will light up.
•To turn off the system, press the ON/OFF button again the ON/OFF button will light off.
LOADING A DISC
•Lift up CD Door to open CD/CDG compartment door. Place a CD/CDG disc in the compartment with
the printed side facing toward you.
•Gently close the CD Door and slide the CD/ RADIO/ AUX selector to CD position.
•The CDG Machine begins to read the disc. After that, press the PLAY/ PAUSE button to play the
disc. (If no disc is loaded, it will display “- - or E”. If CDG is loaded, the CDG indicator will light up).
NOTES:
Never place anything except a compact disc in the disc tray. Foreign objects can damage the unit.
Only place one disc on the disc tray at a time.
Refer to the Trouble Shooting Guide “if a disc is loaded but the total tracks do not appear”.
PLAY/ PAUSE
•To start playing, press the PLAY/ PAUSE button. The first track [01] will be displayed on the LED
display.
•To temporarily stop playing, press the PLAY/ PAUSE button.
•To resume play, press this button again.
PLEASE NOTE: Pressing pause repeatedly when a CDG is playing may cause distorted lyrics on the
monitor. Any distortion will remain until the whole screen is refreshed during an instrumental break or you
stop the song and start it from the beginning.
PLAYING CD OR CD+G DISC
•Adjust MASTER VOLUME control on your unit, TV or audio system to a comfortable level.
•Adjust MIC VOLUME/ A.V.C / ECHO/ BALANCE controls as needed to achieve the desired mix of
music and vocals through your sound system.
•Do not press the disc cover of the CD compartment while it’s playing.
•Never place anything except a compact disc on the disc tray. Foreign objects can damage the unit.
•Do not apply excessive force to disc cover.
•Only place one disc on the disc tray at a time.
MASTER VOLUME
Rotate to the MASTER VOLUME control to obtain the desired sound level.
NOTE: The MIC VOLUME must be adjusted simultaneously with the master volume level.
STOP MODE
If the STOP button is pressed during playback, the disc will cease to play. (The total number of tracks will
be shown on the LED display).

9
CD OR CD+G OPERATION
SKIP (FOR BOTH CD & CDG DISCS)
•During STOP mode, you can skip up or down to your desired track by pressing SKIP AAAAA buttons.
•To resume playing the selected song, press PLAY/PAUSE button.
SEARCH (FOR AUDIO CD DISC ONLY)
•When playing any audio CD, press hold the SKIP AAAAA buttons. The CD will search at high speed
in the forward or backward direction. Normal play will continue when you release the SKIP button.
REPEAT
•To repeat the track currently playing, press the REPEAT button once. The REPEAT indicator will
blink.
•To repeat all tracks, press the REPEAT button twice. The REPEAT indicator will light up.
•To clear the REPEAT function, press the REPEAT button again. The REPEAT indicator will turn off.
PROGRAM
Use Program button to program and playback songs in a preselected order.
Step 1: Programming should be done in the stop mode only. Press the PROGRAM button. The Program
indicator will turn on and the LED display will show “00”.
Step 2: Press the double arrow keys (SKIP buttons) to select a desired track.
Step 3: Press Program button to confirm entry. You can repeat same step up to a maximum of 16 tracks.
Step 4: Press PLAY button when you have completed programming and you are ready to start singing.
NOTES: Press the STOP button twice to clear all the programmed entries.
DISCO LIGHT FUNCTION
•To illuminate the Disco Light, press the LIGHT ON/OFF button to switch it ON.
•Press it again to switch it OFF.
KARAOKE FUNCTIONS
Sing along with the music by plugging in the provided microphone into either one of the microphone
sockets on the unit.
ECHO
Adjust the ECHO control to enhance your voice for a concert hall effect.
BALANCE
Adjust the BALANCE control between the pre-recorded singer’s voice and the music when using a
multiplex karaoke or CDG disc.
(Please see Glossary of term to learn more about multiplex on website).
AVC (AUTO VOICE CONTROL)
AUTO VOICE CONTROL can be activated by the AVC control. The vocals on the multiplex recording will
be muted when the singer starts to sing through the microphone. When the singer stops singing, the
vocals will resume to normal.

10
LINE IN & RADIO OPERATION
LINE IN OPERATION
USING LINE IN to connect an audio cable (not included) from the LINE IN socket on rear of the unit to the
external unit’s LINE OUT socket. Slide the CD/ RADIO/ AUX selector to AUX position. This will allow you
to broadcast the external unit’s sound through this unit’s speaker.
RADIO FUNCTION
1. Press the ON/OFF button to turn on the unit, slide the CD/ RADIO/ AUX selector to RADIO position.
2. Rotate the MASTER VOLUME control to desired sound level
3. Press the SCAN button once/ twice to scan through radio frequencies.
4. Press RESET button to reset radio to low end station, press SCAN button the unit will scan station
again.
5. This unit has built-in FM antenna, which provides adequate reception in most areas. If the reception
is weak, turn the unit to improve reception.

11
TROUBLE SHOOTING GUIDE
If you have followed the instructions and are having difficulty operating the unit, locate the PROBLEM in
the left column below. Check the corresponding POSSIBLE CAUSE column to locate and remedy the
problem.
PROBLEM POSSIBLE CAUSE SOLUTION
No power when ON/OFF button
is on. No power plugs connection at the AC outlet. Insert the adaptor plug into the AC outlet.
No power when adaptor
plugged in.
The AC outlet may not have
power.
Check the outlet with a working
lamp or other electrical
appliance.
The DC small plug is not secure
on the back of the unit. Secure the DC small plug into the back of the unit.
No Sound
Volume control is set to
minimum. Turn up the volume on the TV or PA system.
Volume control on TV set or PA
system is set to minimum. Turn up the volume on the TV or PA system.
TV or PA system is powered off. Turn on the power at the TV/PA
system.
AUX OUT jack not connected. Follow directions “Audio
Connection” page.
Wrong function selected Select the correct function by
CD/ Radio/ Aux selector
CD player does not work
normally or the LED displays
“no”, “E” or “- -”.
Disc is inserted upside down. Insert the disc correctly.
Disc is dirty. Wipe clean with a soft cloth.
Disc is scratched. Use a new disc.
Disc is warped. Use a new disc.
A non standard disc is inserted Only use discs bearing the
standard logo.
Lens is dirty Use a CD lens cleaner
Moisture has formed inside the
CD deck. Wait about 20 – 30 minute to let it dry out.
CDG machine needs to be
reset. Disconnect the machine from the power source for 2-5 minute.
No sound – if audio is going
through TV, VCR, or home
stereo
Source selection on TV or VCR
or home stereo is not set
properly.
Select AUX IN as the source for
your TV, VCR or home stereo.
Improper connection to stereo
system or PA
Follow direction on “Audio
Connection” page for
connecting to a home stereo
system.

12
TROUBLE SHOOTING GUIDE
PROBLEM POSSIBLE CAUSE SOLUTION
No song lyrics appear on the TV
screen
Video cable is not connected
properly to the TV.
Connect the video cable to the
CDG machine’s VIDEO OUT
and to the TV VIDEO IN.
Source selector on TV is not set
to VIDEO. Using your TV remote to select VIDEO input.
TV does not have video line
input.
Connect from VIDEO OUT of
the system to the VIDEO IN on
your VCR or connect to an RF
Modulator and then to the TV
cable input. Check the disc to
be sure it is a CDG.
A CDG is loaded but the CDG
indicator is not lit. Check the disc to be sure it is clean.
No sound from microphone Microphone is off. Turn on microphone with the ON/OFF switch located on the
microphone.
Radio reception is weak Station signal is weak. Turn or move the unit to
improve reception.
SPECIFICATION
Audio Section
Output power
Output impedance
1 watt + 1 watt RMS
8 Ohm
CD Player
Frequency response
Signal – to – noise ratio
Number of programs
Sampling system
100 Hz – 20 KHz
50 dB
16 steps random access programming
8 times over sampling
Microphone -73 dB 600 ohms impedance with Ø 6.3mm
dynamic microphone
AC Power Section AC Power Adaptor
Input: AC 100-240V~50/60Hz, 0.25A
Output: DC 9V, 0.8A
Battery Section UM2 or C size battery x 6pcs
Dimensions (W x D x H) 12” x 6” x 12” / 30.5 x 15.3 x 30.5 cm
Weight 3.54 lb / 1.61kg
Specifications are typical, individual units might vary. They are subject to continuous improvement without
notice and without incurring any obligation.
1406-01
