AKCP SP+ Instruction manual

www.AKCP.com
SP+ External Modem
QuickStart Manual
Copyright © 2022, AKCP

Introduction
In this manual we will talk about the general features of the External Modem. We will not
go into details of modem configuration or notification setup, as these are the same for
other modems available for the sensorProbe+ family. Please refer to the manual of the
SP+ Internal Modem for more information.
What is the External Modem?
This modem is available only for SPXN and SP2+ RevG units, which have a dedicated
port for connecting an external modem. It is ideal for customers who require cellular
communications as either primary or backup connection.
It supports SMS, e-mail alerts and voice calls* as well as access to the webUI or
communications via VPN to AKCPro Server.
An optional GPS antenna (as seen on the picture above) can be added for mobile asset
tracking and monitoring or automatic geo locating static sites on maps in AKCPro
Server.
*voice calls are via third party e-mail to voice call gateway

What’s the difference between the External Modem and the Internal Modem?
The Internal Modem can be selected as an option for any SP2+ or SPX+ units, and
supports all modem functionality without restrictions.
The External Modem is available only for SPXN and SP2+ units, which have a
dedicated port for connecting an external modem. It only supports voice calls via third
party e-mail to voice call gateway.
How to identify SP2+ RevG model?
Only Revision G and newer SP2+ models support the External Modem.
You can identify the revision on the underside of the SP2+ case.

LED information for External Modem
LED behavior of SP2+ revG Port #1 and External Modem:
- If Port #1 is configured as a sensor port : Port #1 LED : OFF, EXT MODEM LED : OFF
- If Port #1 is configured as a modem port : Port #1 LED : blinking fast (When modem is
not detected yet), EXT MODEM LED: steady ON
- If Port #1 is configured as a modem port : Port #1 LED : steady ON (When modem is
detected), EXT MODEM LED: blinking
- If no SIM card is inserted or not detected: Port #1 LED : steady ON (When modem is
detected), EXT MODEM LED: steady ON
LED behavior of SPXN+ with the dedicated modem port and External Modem:
- If the modem is not yet detected : EXT Modem LED : OFF
- If the modem is not yet detected : EXT Modem LED : Blinking
- Note: there is no LED for the EXT modem port on the SPXN+

Setting up the modem - physical connection
First you would need to insert the SIM card to the modem.
Note: Please make sure that the SIM does not require a PIN code.
To insert the SIM, you need to follow these steps:
#1 Take off the plastic cover.
It is held on by a single screw at the bottom of the cover.

#2 Operate the SIM holder as follows:
Note: if you do not close and lock the SIM holder, the modem will not be able to use the
SIM card.

#3 Place the SIM card in the holder:
#4 Close the SIM retainer to lock it in place:
Note: if you do not close and lock the SIM holder, the modem will not be able to use the
SIM card.

Re-assemble the modem case and connect the GSM antenna to the modem, as shown
on the picture below.
Connect the modem’s power cable to the microUSB port.

Then finally connect the modem to the sensor port #1 of SP2+ RevG via RJ45 cable.
If your base unit is SPXN, locate the dedicated Modem Port and connect the modem
here:
Important note: the maximum allowed length of the cable is 12 inches (305 mm).
