AKEZ R1ZCC User manual

Electric bicycle manual
- 1 -
Electric vehicle manual
GB17761-2018

Electric bicycle manual
- 2 -

Electric bicycle manual
- 3 -
Product information：
Voltage: 48V time to market: 2020
Configuration: standard type check number of people:
2-person style
Maximum speed: below 40km / h, curb weight: 32kg
We are a professional manufacturer of electric bicycles,
"green environmental protection" is the company's
consistent product design and production philosophy,
product design lightweight.
Disney's pursuit is what users need. I hope you can tell us
your feelings and suggestions after riding, constantly
promote our work and make our products more perfect.
The contents of this manual are compiled according to
the latest information. As the company's products are
constantly updated and improved, there are differences
between this manual and the products you actually
purchased. I beg your understanding. After reading this
manual, please keep it for future reference.
Be sure to read this statement carefully before using this
product. In the event of any use of our products, you will
be deemed to have understood and approved all the
contents of this statement.
1. When you use this product, you must abide by the
national laws and regulations and local traffic regulations.
The Company shall not be responsible for any
consequences arising from the violation of the above
laws and regulations.
2. When you purchase this product, please check all the
data on the vouchers and keep all the vouchers after the

Electric bicycle manual
- 4 -
purchase is completed. Because of the inconsistency of
data and material or the inconsistency of vouchers, the
users are responsible for the consequences.
3. Before you use this product, you must read the
instructions carefully. When using this product, you
should strictly follow the instructions. We are not
responsible for any consequences caused by improper
use, speeding, overloading, etc.
4. Without the written permission of the company, the
user shall not disassemble or change the original
assembly device without authorization. If the product
breaks down, we must go to the special repair point of
our company's distribution unit for service. In case of
violation of the aforementioned circumstances, the
consequences shall be borne by the users themselves.
I. User's Guidelines for Use
1. Users must abide by traffic regulations and pay
attention to traffic safety.
1.1 It is strictly forbidden for people under 16 to drive
electric bicycles on the road.
1.2. Electric bicycles should be driven in non-motorized
lanes with a maximum speed of no more than 15 km/h.
On roads without non-motorized lanes, they should be
driven on the right side of the lane.
1.3 Don't lend electric bicycles to people who can't
operate them to avoid injury.
1.4 Electric bicycles shall carry persons or articles in
accordance with laws and regulations;
1.5 It is recommended to wear a helmet when riding.

Electric bicycle manual
- 5 -
1.6 Ride on rainy and snowy days, extend braking
distance, slow down, heavy rain and other bad weather,
try to avoid travel.
2. Users should pay attention to the safety of electric
bicycles.
2.1 Electric bicycles should not be parked in building halls,
evacuation staircases, corridors and safety exits.
2.2 Electric bicycles should not be charged and parked in
residential buildings. They should be far away from
combustibles when charging, and the charging time
should not be too long.
2.3 Correct use and maintenance of batteries. Waste
batteries should not be disassembled without
authorization, and should be recycled by relevant
professional departments.
2.4 The safe use method and warning language of
charger; when replacing charger, it should match the
type of storage battery;
2.5 Notes on Washing According to 5.7.7
2.6 When adjusting handlebars or saddles, care should
be taken not to reveal the safety line marks for the risers
and saddles (when applicable).
3. Check before riding. If there is any abnormality, please
do maintenance or professional maintenance in time.
3.1 Power supply circuit, lighting circuit, etc.
3.2 Whether the front and rear gates can work properly;
3.3 Fastening state of handlebars and front and rear
wheels;
3.4 tire pressure;
3.5 Whether the reflector is damaged or contaminated.

Electric bicycle manual
- 6 -
Warning users
1. It is strictly forbidden to use batteries to connect the
motor directly, otherwise it will cause damage to the
motor.
2. The standard load of the vehicle is 75Kg (including
cyclists). When the vehicle is seriously overloaded, it will
affect the life of the controller and battery.
3. The mileage of one charge is a comprehensive index,
which is related to the following factors:
1) Controller under-voltage protection value, when the
battery under-voltage, the controller will stop power
supply, deep discharge will affect the life of the battery.
2) Ambient temperature, load, wind speed, frequent
braking, ramp (for your battery, pedal support) and
low-speed cycling on crowded roads.
4. When the brushless motor idles, it will emit a kind of
"buzz" sound, which is a normal phenomenon. This is
because the electromagnetic wave vibration sound
produced by the motor through the coil does not affect
the normal use.
5. In the process of starting the brushless motor, the rider
will feel a slight "jitter" phenomenon, which belongs to the
normal state; while driving normally, the "jitter" will be
very slight, which is determined by the structure
characteristics of the brushless motor, so it is better to
start with the help of foot first, and then ride.
6. The front and rear tires should be properly inflated. If
the tires are inflated excessively, they will bump violently
while driving. If the tires are insufficiently inflated, they will
affect the driving speed and increase the power

Electric bicycle manual
- 7 -
consumption.
7. In order to ensure your safety, it is forbidden to contact
battery contacts and charging sockets with wet hands or
metal objects.
5.1 riding instructions
5.1.1 Before riding, please read this instruction carefully.
After fully understanding the performance, use and
maintenance methods of the bike, you can ride.
5.1.2 Check whether the speed control handle is flexible
and effective, the reliability and flexibility of front and rear
brake, and adjust it in time if operation brake failure is
found.
5.1.3 Check whether the battery box is fastened.
5.1.4 Slow down, whistle and walk sideways at turning.
5.1.5 In rainy, snowy and slippery areas, braking is very
difficult. Emergency braking should be avoided to
prevent slippage. When parking, braking should be used
slowly.
5.1.6 Do not overload, otherwise it will affect the life of
the vehicle and your riding safety.
5.1.7 Don't lend to people who can't ride an electric
bicycle. They must strictly abide by traffic regulations.
Please ride on the corresponding lane. No pedestrians
are allowed to ride.
5.2 Installation of Batteries
5.2.1 Connect the fully charged battery box and place it in
the battery box seat.
5.2.2 Lock the battery box.
Note: New cars or batteries should be fully charged

Electric bicycle manual
- 8 -
before they are used.
5.3 Start-up Vehicle
5.3.1 Connect the power supply: insert the key of the
door into the switch lock of the power supply, turn on
(turn on), the power indicator light is on, and the meter
indicates that the power supply has been connected.
5.3.2 Vehicle start-up.
5.3.3 Driving Vehicles:
Steady rotation should accelerate the vehicle slowly after
starting, and do not immediately increase to the highest
speed to avoid danger. In the course of driving, we
should maintain uniform speed and balance, and drive
safely. Don't speed up and overload.
When braking, we should develop the habit of braking
and restoring the speed control handle to its original
position, so as to avoid damaging the control system or
increasing the burden of batteries.
When going up the hill, pedals should be used as much
as possible to assist cycling. In order to avoid excessive
consumption of electricity, while conducive to motor,
battery maintenance.
After use, the lock of the door must be closed, the key of
the door must be removed and charged in time
according to the situation.
5.4. Promotion and parking
5.4.1 When you get out of the car to promote or stop, you
must turn off the power supply, in order to avoid
accidental rotation of speed control handles.
5.4.2 Vehicles should be avoided frequently starting with
speed control handles at rest to ensure the service life of

Electric bicycle manual
- 9 -
batteries, motors and electrical switches.
5.4.3 When parking and leaving, you must take down the
key and lock the anti-theft lock.
5.5 Charging Method and Notices
5.5.1 Electric vehicles use special batteries for electric
vehicles. Normally, they do not need maintenance. If they
need to be replaced, please send the used batteries to
the recycling station designated by our company.
5.5.2 A new car purchased from the factory,
transportation and storage needs a certain time, which
may result in insufficient battery power. Therefore, before
the first use, the battery must be fully charged before
riding.
5.5.3 The batteries of this electric vehicle must be
charged with the special charger equipped by our
company, otherwise the batteries will be damaged and
even cause fire hazards.
5.5.4 Check whether the input voltage of the charger is
consistent with the grid voltage.
When the 5.5.5 power switch is turned off, the battery
can be charged directly in the car, or it can be unloaded
and taken to a suitable place for charging indoors.
Charging method
5.5.6 First insert the outlet plug of the charger into the
charging socket of the battery, and then insert the plug of
the charger into the AC power socket to start charging. It
takes about 6-10 hours to charge once. When the full
indicator light (green) is on, it means that the electricity is
full. It is better to recharge for another 1-2 hours. (See
Charger Instructions for details)

Electric bicycle manual
- 10 -
5.5.7 This charger has overcharge protection device.
Long time charging will not affect the battery life, but the
continuous charging time is better not to exceed 18 hours.
5.5.8 After charging, the plug on the AC power supply
should be removed first, and then the plug connected
with the battery should be removed.
5.5.9 It is prohibited to connect charger to AC power for
a long time. This will not only damage the life of the
charger, but also cause other dangers.
5.6 Cautions for Charging
5.6.1 When charging, please put it in a safe place that
children can't touch.
5.6.2 It is better not to start using without full charge,
otherwise it will affect the battery life.
5.6.3 Do not use other brand chargers for charging, other
types of batteries should not use this charger.
5.6.4 Charger contains high voltage circuit, away from
inflammable and explosive articles.
5.6.5 When charging, don't cover anything.
5.6.6 This charger is suitable for indoor use. Please use it
in a dry and ventilated environment.
5.6.7 When charging, if you smell odor or the
temperature is too high, please stop charging
immediately and send it to the distribution room for repair.
5.6.8 Charging time exceeds 12 hours. If the red light on
the charger is not converted to green light, please stop
charging immediately to avoid battery failure.
5.7 Maintenance Notes
5.7.1 Please check whether the fixed rear wheel nut is
loose and tighten in time.
