Akicon 96566 User manual

Limited 5-year Warranty
Akicon warrants to the original consumer purchaser for as long as the original
consumer purchaser owns their home (the “Warranty Period” for homeowners) that
this faucet will be leak- and drip-free during normal use, and all parts and finishes of
this faucet will be free from defects in material and manufacturing workmanship. All
other purchasers (including purchasers for industrial, commercial and business
use) are warranted for a period of five (3) years from the original date of purchase
(the “Warranty Period” for non-homeowners).
If this faucet should ever develop a leak or drip during the Warranty Period, Akicon will provide FREE OF CHARGE the parts
necessary to put the faucet back in good working condition and will replace FREE OF CHARGE any part or finish that proves
defective in material and manufacturing workmanship, under normal installation, use and service. Replacement parts may
be obtained by calling 1-302-213-4406. Proof of purchase (original sales receipt) from the original consumer purchaser
must accompany all warranty claims. Defects or damage caused by the use of other than genuine Akicon parts is not
covered by this warranty. This warranty is applicable only to faucets purchased after Oct 2018 and shall be effective
from the date of purchase as shown on purchaser’s receipt.
This warranty is extensive in that it covers replacement of all defective parts and finishes. However, damage due to
installation error, product abuse, product misuse, or use of cleaners containing abrasives, alcohol or other organic solvents,
whether performed by a contractor, service company or yourself, are excluded from this warranty. Akicon will not be
responsible for labor charges and/or damage incurred in installation, repair or replacement, nor for any indirect, incidental
or consequential damages, losses, injury or costs of any nature relating to this faucet. Except as provided by law, this
warranty is in lieu of and excludes all other warranties, conditions and guarantees, whether expressed or implied, statutory
or otherwise, including without restriction those of merchantability or of fitness for use.
Some states, provinces and nations do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state, province to province, nation to nation. Akicon will advise you of the procedure
to follow in making warranty claims. Simply write to Akicon Incorporated using the mailbox below. Explain the defect and
include proof of purchase and your name, address, area code and telephone number.
For more warranty
information, please visit
[email protected]
To guarantee warranty on
your products, simply register
your products at
www.akiconshop.com
Warranty Information
Akicon® products have been manufactured under the highest standards of quality
and workmanship. Most Akicon faucets are backed by a Limited 5-year Warranty.
Consult your specific product manual for coverage details.
In the US:
Akicon Inc
Attn: After-sales department
108 EAST 13TH ST
WILMINGTON, DE 19801

７－１／４＂
８－１３／１６＂
２０－７／８＂
２－３／８＂
１－３／８＂
Ｍａｘ１－３／４＂
６＂
９６５１８－Ｄｉｍｅｎｓｉｏｎａｌ ｄｒａｗｉｎｇ

IMPORTANT NOTICES: For easy installation, please read all the instruction completely before beginning.
Before installing this product, make sure that water line trash is cleared to avoid blockage.
YOU MAY NEED
After you open this package, please check to ensure that all of the following items are included.
A- Faucet B- Spray Head C-Flexible Hoses(2) D-Plastic Support
E-Mounting Assembly and Washer F-Allen Wrench
Spring Kitchen Faucet
1
F
D
EX: E001002T Rev: A
4
CAUTION: Maintenance
1. Replacement partsmay be availableat the storewhere you purchasedyour faucet.
2. Alwaysturn off water and relievepressure before workingon your faucet.
Turn off water and relieve pressure! Detach handle button
using a small flathead screwdriver, unscrew set screw
using Allen Wrench and take off handle.
Remove handles. Unscrew dome cap counter clockwise
by hand. Unscrew retaining nut using adjustable wrench,
take out cartridge assembly and inspect. Replace parts
as necessary. Reassemble parts by reversing steps.
Handle Removal Maintenance Valve Cartridge Removal Maintenance
Optional accessories
PACKING LIST
TROUBLE-SHOOTING
If you've followedthe instruction carefullyand your faucetstill does notwork properly, take thesecorrective steps.
Problem Cause Action
Leaks underneath handle. Cartridge has come loose. Tighten thecartridge.
Aerator leaks or has an
inconsisitent water flow
pattern.
Aerator is dirtyor worn
out or misfitted.
Unscrew the aerator to
clean or replace washer,
or replace the aerator.
Water willnot shut off
completely. Dirty or worn out washer
in cartridge.
Remove handle and cartridge
to check if the washer is damaged
permanently or dirty. Re-install
cartridge.
NOTES: Cleaning Instructions
1. To keep thefaucet clean, you should cleanthe faucet frequently and regularly.
2. Clean thefaucet with clearwater or mildliquid, rinse thefaucet with clearwater and then
dry the faucet with soft cotton cloths.
3. Do not use any abrasive cleansers, cloths, or paper towel.
4. Do notuse any acidor abrasive detergent.
B
C
A
B
B
B
E
E
or
Questions, problems, missing parts?
call Akicon Customer Service 8 a.m.-6p.m. EST, Monday-Friday
Phone: [phone], Email: [email protected]
AKICONSHOP.COM
Model: 96566
96518

3
Open the valve, then turn the handle according to the
sign of C and H on the handle to regulate the temperature
of the water. (C=Cold,H=Hot)
Swing Spout
5
6
INSTALLATION PROCEDURES
Removeanydebris from valve outlets.
Turning off the water supply valves.
Install without deck plate. Make sure the O-ring
is placed onto the bottom of base ring. Install
faucet through hole in sink, position faucet on sink
properly and tighten the nut from underside of the
sink.
If necessary, tighten screws using a adjustable
wrench until the faucet is firmly connected to the
sink.
water supply valve, and connect hot and cold water lines
Open the water supply valve and flush for about a minute
of the faucet to the water supply valves.
2
1
2A
3
4
Close
Open
After installation is complete, remove spray head and rotate
fter installation is complete, remove aerator and rotate
handle to the closed position. Turn on the water supply
valves, and check all connections for a leak. Turn on
your faucet and allow both hot and cold water to run at
least one minute each, then put the spray head back.
Faucet Start Up
2B
Install with deck plate. Position deck plate onto sink.
Make sure the O-RING is placed at the bottom of
the faucet base. Install faucet through hole in deck
plate. From underside of sink, attach mounting
assembly. Position faucet on deck plate properly and
tighten Mounting Nut.
to clear the rubbish left in the pipeline, then turn off the
