Aktakom ACM-2348 User manual

OPERATING INSTRUCTION
ACM-2348
DC+AC TRMS WATT CLAMP METER
www.tmatlantic.com

Safety
International Safety Symbols
This symbol, adjacent to another symbol or
terminal, indicates the user must refer to the
manual for further information.
This symbol, adjacent to a terminal, indicates that,
under normal use, hazardous voltages may be
present
Double insulation
SAFETY NOTES
xDo not exceed the maximum allowable input range of
any function
xDo not apply voltage to meter when resistance function
is selected.
xSet the function switch OFF when the meter is not in
use.
WARNINGS
xSet function switch to the appropriate position before
measuring.
xWhen measuring volts do not switch to
current/resistance modes.
xWhen changing ranges using the selector switch always
disconnect the test leads from the circuit under test.
xDo not exceed the maximum rated input limits.
CAUTIONS
Improper use of this meter can cause damage, shock, injury
1

or death. Read and understand this user manual before
operating the meter.
Always remove the test leads before replacing the battery.
Inspect the condition of the test leads and the meter itself for
any damage before operating the meter. Repair or replace
any damage before use.
Use great care when making measurements if the voltages
are greater than 25VAC rms or 35VDC. These voltages are
considered a shock hazard.
Remove the battery if the meter is to be stored for long
periods.
Always discharge capacitors and remove power from the
device under test before performing Diode, Resistance or
Continuity tests.
xVoltage checks on electrical outlets can be difficult and
misleading because of the uncertainty of connection to the
recessed electrical contacts. Other means should be used
to ensure that the terminals are not "live".
xIf the equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment may
be impaired.
Input Limits
Function Maximum Input
DC+AC Watt 240KW
A AC,A DC 1000A
V DC, V AC 600V DC/AC
Resistance, Diode, Continuity,
Frequency, Duty Cycle, Test
250V DC/AC
2

Meter Description
1. Current clamp
2. Clamp trigger
3. Data Hold and Backlight button
4. Mode select button
5. Hz/% button
6. LCD display
7. COM input jack
8. Rotary Function swith
9. ZERO button
10. Range select button
11. V ˖+]jack
12. Battery compartment on rear
1. AC DC AC (alternating current)
and DC (direct currrent)
2. Minus sign
3. 8.8.8.8 4000 count (0 to 3999)
measurement reading
4. AUTO AutoRange mode
5. Diode test mode
6. •))) Audible Continuity
7
8
5
6
3
4
Hz%
9
2
1
A
A
A
AC
KW
DC
+
KW
DC
AC A
3

7. HOLD Data Hold mode
9.KW, P,m,V,A,K,M,
˖
,Units of measure list
Specifications
Function Range &
R
esolution
Accuracy (% of
r
eading)
DC Current 1000 ADC ± (1.8% + 5 digits)
AC Current 1000 AAC ± (2.0% + 5 digits)
400.0 mVDC ± (0.8% + 3 digits)
4.000 VDC
40.00 VDC
400.0 VDC ± (1.5% + 3 digits)
DC Voltage
600 VDC ± (2.0% + 3 digits)
400.0 mVAC ± (0.8% + 20 digits)
4.000 VAC
40.00 VAC
400.0 VAC ± (1.8% + 5 digits)
AC Voltage
600 VAC ± (2.5% + 5 digits)
400.0 ˖± (1.0% + 4 digits)
4.000K˖
40.00K˖
400.0K˖± (1.5% + 2 digits)
4.000M˖± (2.5% + 3 digits)
Resistance
40.00M˖± (3.5% + 5 digits)
5.000Hz r(1.5% reading + 5
digits)
50.00Hz
500.0Hz
5.000kHz
50.00kHz
Frequency
100.0kHz
r(1.2% reading + 2
digits)
Sensitivity: 10Vrms
min.
4

0.5 to 99.0% r(1.2% reading + 2
digits)
Duty Cycle
Pulse width: 100μs - 100ms, Frequency:
5.000Hz ~ 100.0kHz
AC WATT
(0-250 V,0-
400A,
50/60Hz
TRMS)
40KW ± (2.5% + 5 digits)
AC WATT
(0-600V,0-
400A,
50/60Hz
TRMS)
240KW ± (2.5% + 5 digits)
DC WATT
(0-250 V,0-
400A)
40KW ± (2.0% + 5 digits)
DC WATT
(0-250 V,0-
400A)
240KW ± (2.0% + 5 digits)
Note: No Autoranging & 400mV AC Voltage Range
Clamp size Opening 1.2" (30mm) approx
Diode Test Test current of 0.3mA typical;
Open circuit voltage 1.5V DC typical.
Continuity Check Threshold <100:; Test current
< 1mA
Low Battery Indication “ BAT ” is displayed
5

Overrange Indication “OL” is displayed
Measurements Rate 2 per second, nominal
Input Impedance 7.8M:(VDC and VAC)
Display 4000 counts LCD
AC Current 50/60Hz True RMS (AAC)
AC Voltage bandwidth 50/60Hz True RMS (VAC)
Operating Temperature 14 to 122oF (-10 to 50oC)
Storage Temperature -14 to 140oF (-30 to 60oC)
Relative Humidity 90%(0oC to 30oC); 75%(30oC
to 40oC); 45%(40oC to 50oC)
Altitude Operating: 3000m; Storage
10,000m
Over voltage Category III 600V
Battery One “9V” Battery
Auto OFF approx. 35 minutes
Dimensions/Weight 229x80x49mm/303g
Safety For indoor use and in
accordance with Overvoltage
Category II, Pollution Degree
2. Category II includes local
level, appliance, portable
equipment, etc., with transient
overvoltages less than
Overvoltage Cat. III
6

Operation
NOTICES: Read and understand all warning and
precaution statements listed in the safety
section of this operation manual prior to using
this meter. Set the function select switch to the
OFF position when the meter is not in use.
DC+AC Power/Watt Measurements
Hz%
A
A
KW
current
Voltage
1. Connect the test leads to the voltage source in parallel
with the load.
2. Clamp on one of the wire to the load.
3. Select the range to Voltage AC or DC, and check the
voltage reading.
7

4. Select the range to Current AC or DC, and check the
current reading.
5. Select appropriate Watt range 40KW(0-250V,0-400A)
or 240KW (0-600V,0-400A).
6. Read the value shown on LCD in KW (AC+DC).
DC/AC Current
Measurements
WARNING: Ensure that
the test leads are
disconnected from the
meter before making
current
clamp measurements.
Select AC or DC with
the MODE button.
DC/AC Voltage
Measurements
1. Insert the black test lead into the negative COM terminal
and the
red test lead into the positive Vterminal.
2. Set the function switch to the V position.
3. Select AC or DC with the MODE button.
4. Connect the test leads in parallel to the circuit under test.
5. Read the voltage measurement on the LCD display.
No Yes
˖˖
CAP CAP
᧝᧝
DC DC
AC
A
C
..
..
n
n
n
n
A
A
+ +
8

Resistance and Continuity Measurements
1. Insert the black test lead into the negative COM terminal
and the
red test lead into the positive terminal.
2. Set the function switch to the •))) :position.
3. Use the multifunction MODE button to select resistance.
4. Touch the test probe tips across the circuit or component
under
test. It is best to disconnect one side of the device under
test so
the rest of the circuit will not interfere with the resistance
reading.
5. For Resistance tests, read the resistance on the LCD
display.
6. For Continuity tests, if the resistance is < 100:, a tone
will sound.
Diode Measurements
1. Insert the black test lead banana plug into the negative
COM jack and the red test lead banana plug into the
positive diode jack.
2. Turn the rotary switch to the •))) position.
3. Press the MODE button until “ “ appears in the
display.
4. Touch the test probes to the diode under test. Forward
voltage will indicate 0.4V to 0.7V. Reverse voltage will
indicate “OL”. Shorted devices will indicate near 0mV
and an open device will indicate “OL” in both polarities.
Red Black Black Red
Probe Probe Probe Probe
Forward test Reverse test
9

Capacitance Measurements
WARNING: To avoid electric shock, disconnect power to
the unit under test and discharge all capacitors before
taking any capacitance measurements. Remove the
batteries and unplug the line cords.
1. Set the rotary function switch to the cap position.
2. Insert the black test lead banana plug into the negative
(COM) jack.
Insert the red test lead banana plug into the positive (V)
jack.
3. Touch the test leads to the capacitor to be tested.
4. Read the capacitance value in the display
Frequency or % duty cycle measurements
1. Set the function switch to the V position.
2. Insert the black lead banana plug into the negative
COM jack and the red test lead banana plug into
the positive V jack.
3. Select Hz or % duty with the Hz/% button.
4. Touch the test probe tips to the circuit under test.
5. Read the frequency on the display.
Data Hold and Backlight
To freeze the LCD meter reading, press the data hold
button. The data hold button is located on the left side of the
meter (top button). While data hold is active, the HOLD
display icon appears on the LCD. Press the data hold button
again to return to normal operation.
Note: The HOLD feature will activate when the Backlight is
turned on. Press the HOLD key again to exit Hold.
10

11
The backlight function illuminates the display and is used
when the ambient light to too low to permit viewing of the
displayed readings. Press the (HOLD) button for one
second to turn the backlight on and press the button a
second time to turn the backlight off.
Manual Ranging
The meter turns on in the autoranging mode. Press the
Range button to go to manual ranging. Each press of the
range button will step to the next range as indicated by the
units and decimal point location. Press and hold the Range
button for two seconds to return to autoranging. Manual
ranging does not function in the AC/DC Current ,Watt, Diode
and Continuity check functions
Battery Replacement
1. Remove the one rear Phillips head screw
2. Open the battery compartment
3. Replace the Requires one “9V” battery (NEDA1604,
6F22 006P)
4. Re-assemble the meter
