SMI200
Programmable compact controller
User guide
SMI200_2019.06_ 0275 _EN
© All rights reserved
Subject to technical changes and misprints

akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
1
1
Contents
1Overview..........................................................................................................................................................2
1.1 Functions .................................................................................................................................................2
1.2 Design......................................................................................................................................................2
2Specifications.................................................................................................................................................3
2.1 Environmental conditions.........................................................................................................................3
3Safety...............................................................................................................................................................4
3.1 Safety symbols and key words................................................................................................................4
3.2 Intended use............................................................................................................................................4
4Installation.......................................................................................................................................................5
4.1 Safety precautions...................................................................................................................................5
4.2 Wiring.......................................................................................................................................................5
5Display and function buttons........................................................................................................................7
6System menu ..................................................................................................................................................8
7Operation.......................................................................................................................................................10
7.1 RUN-STOP............................................................................................................................................10
7.2 Down.Mode............................................................................................................................................11
8Maintenance..................................................................................................................................................12
9Transportation and storage.........................................................................................................................13
10 Scope of delivery..........................................................................................................................................14

Overview
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
2
1 Overview
SMI200 is a programmable controller with 2-line 32-character LCD display designed for a wide
variety of applications in industrial and building automation from simple display to complex process
control functions.
The controller can operate as a master or slave in a Modbus network over RS485 interface. In or-
der to be integrated in a Modbus network, the controller has to be configured and programmed with
the akYtec ALP software included on the USB stick.
See ALP Help for further details about device configuration and programming.
The configuration can be carried out with device front buttons over the system menu as well (see
sections 5, 6).
The connection with akYtec ALP running on the PC can be established over the USB interface
(Fig. 1.1). When being connected to PC over USB, the device is powered by USB and does not
need additional power supply.
User application includes the logic program created as a function plan as well as the device config-
uration.
1.1 Functions
The device has the following basic functions:
– 2-line 32-character LCD display
– 6 function buttons on the front panel
– Master or slave in a Modbus RTU/ASCII network over RS485 interface
– Easy mounting in Ø22.5 mm borehole
– Error indication
– Real-time clock
– Free programming with akYtec ALP software
– Micro-USB programming interface
– Quick replacement
1.2 Design
The device is designed in a plastic enclosure for panel mounting (see 4 “Installation”).
Fig. 1.1
1. LCD display
2. Function buttons
3. Micro-USB socket
4. 4-pole plug-in terminal block
For further details about using the display and function buttons see section 5 “Display and function
buttons”.

Specifications
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
3
2 Specifications
Table 2.1
Power supply
Supply voltage
24 (19…30) V DC
Power consumption, max.
2.5 W
Galvanic isolation
none
Galvanic isolation against RS485 circuits
1000 V
Reverse polarity protection
yes
Appliance class
III
Network
Protocol
Modbus RTU/ASCII
Network mode
Master / Slave
Baud rate
9.6…115.2 kbit/s
Programming
Software
akYtec ALP 1.9 or newer
Interface
Micro-USB 2.0
Stack
dynamic
RAM
32 kB
ROM
128 kB
Network variable memory *
1020 Byte
Program cycle, min.
1 ms
Real-time clock
Accuracy
±3 s/day (25°C)
Backup, min.
1.5 years
Backup battery
CR1025
Mechanical
IP code
IP54 front / IP20 rear
Dimensions (with terminal block)
100 x 60 x 60 mm
Weight
approx. 150 g
EMC safety
EMC immunity
conforms to IEC 61326-1 / A1
EMC emission
conforms to EN 55011 / A1
* The limitation applies only to the slave mode, in which all network variables are automatically
declared as retain.
2.1 Environmental conditions
The module is designed for natural convection cooling. It should be taken into account when
choosing the installation site.
The following environment conditions must be observed:
−clean, dry and controlled environment, low dust level
−closed non-hazardous areas, free of corrosive or flammable gases
Table 2.2Environmental conditions
Condition Permissible range
Ambient temperature -20…+55°C
Transportation and storage
-20…+55°C
Relative humidity
up to 80% (at +25°C, non-condensing)
Altitude up to 2000 m above sea level

Safety
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
4
3 Safety
3.1 Safety symbols and key words
Explanation of the symbols and keywords used:
DANGER DANGER indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, could result in
minor or moderate injury.
►
NOTICE NOTICE indicates a potentially harmful situation which, if not avoided, may result in dam-
age of the product itself or of adjacent objects.
3.2 Intended use
The device is provided only for the areas of application described in this user guide when all indi-
cated specifications are observed.
The device can be used only according to the data given in the specification.
Improper use
Any other use is considered improper. Particular attention should be paid to:
– The device may not be used for medical appliances applied to maintain human life or health, its
control or other effect on them.
– The device may not be used in explosive environment.
– The device may not be used in atmosphere in which there are chemically active substances.

Installation
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
5
4 Installation
To mount the device, cut out two holes Ø22.5 mm and Ø4 mm in the panel, as shown in Fig. 4.2.
Carefully position the supplied gasket on the device rear surface. Insert the cylindrical body of the
device into the borehole and tighten the nut from the rear side of the panel (Fig. 4.3).
Fig. 4.1 Dimensions
Fig. 4.2 Panel cutouts (front view) Fig. 4.3 Mounting
The safety precautions from the section 4.1 and the operating conditions from the section 2.1 must
be observed.
4.1 Safety precautions
DANGER
Ensure that the mains voltage matches the voltage marked on the nameplate!
Ensure that the device is provided with its own power supply line and electric fuse!
►
NOTICE
Switch off the power supply before working on the device. Switch on the power
supply only after completing the work.
EMC safety:
−Signal cables should be routed separately or screened from the supply cables.
−Shielded cable should be used for the signal lines.
−Connect the screen in the electrical cabinet in accordance with EMC requirements.
4.2 Wiring
Wire the detachable part of the included 4-pole terminal block according to Fig. 4.4 and connect it
to the built-in part of the block on the rear side of the device.
ALT
100
60
35
60
SELOK
ESC
22,5
51
100
60
31
Switch panel
Gasket
Nut
Enclosure

Installation
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
6
Maximum wire cross-section is 1.0 mm².
Fig. 4.4

Display and function buttons
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
7
5 Display and function buttons
The device and process parameters can be viewed and edited (if available) on the display using
the function buttons. For device parameters, see section 6 “System menu”.
To view or edit the process parameters, display forms have to be programmed with different dis-
play elements. Jump conditions have to be created to let an operator to switch between the display
forms using the function buttons. Jump condition can be a button event of a variable event. For
further details about display elements and jump conditions use Help in akYtec ALP.
There are editable and not editable display elements thus the display can be used in view or edit
mode.
In the view mode (default):
−use and buttons to move between lines
−use button to enter the selected level, and button to exit it
To edit the parameter, press the button . The first editable element on the display starts flash-
ing. Use and buttons to change the value. Use the button combinations to move between
characters:
−+ – one character to the left
−+ – one character to the right
To save the new value and edit the next parameter, use the button .
To reset the parameter to its previous value and exit the edit mode, use the button .
To save the new value staying in the edit mode, use the button . The next editable parameter
will be displayed selected.
The last changed parameter will be shown next time when the edit mode is active.
Note:
When assigning а jump condition to the function button, don't forget that the user function will have
a higher priority than the system function.
Example:
If the and buttons are used as a jump condition for a certain display, it will be impossible to
use them to scroll the lines inside this display.
Table 5.1 Function buttons
Button View Edit
open system menu (>3 s)
one line up increase value
one line down
decrease value
activate edit mode save the new value and edit the next parameter
exit level /
exit system menu (>3 s)
reset the parameter to its previous value and exit
the edit mode
enter selected level save the new value and exit the edit mode
+ one character to the left
+
one character to the right

System menu
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
8
6 System menu
The device parameters can be set in akYtec ALP or using the function buttons on the device. All
parameters are over the system menu available.
Press the button for 3 seconds to access the menu.
Press the button for 3 seconds to exit the menu.
Fig. 6.1 System menu
Fig. 6.2 Protocol - Modbus Slave
Fig. 6.3 Protocol - Modbus Master
* The structure of the system menu depends on the interface configuration in ALP as a master or a
slave.
MENU
Device
3 s
3 s
Password
Interface COM1 Settings
Baud rate
Data bits
Parity
Stop bits
see Fig 6.2-6.3*
Protocol
Version Device and firmware
version
Display Backlight
timeout
Brightness/Contrast
Time/Date
Correction
Cycle time
Clock
Program Run/Stop
ALT
ESC
OK OK OK
OK
OK
OK
OK OK
OK
ESC ESC
ESC
ESC
ESC
OK
ESC
ESC
ESC OKESC
OK
Address
OK
see Fig 6.1*
List of configured devices Address
Polling cycle (ms)
Time-out (ms)
Retries, max
Time between frames
OK OK
ESC
OK
see Fig 6.1*

System menu
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
9
The application running on the device can be interrupted using the menu item Device > Program >
Run/Stop. The device must be restarted for the change to take effect.
The menu can be password protected, although there is no password by default. The password
can be set or changed with ALP or using the system menu. If the password is lost, it can be
changed or deactivated by loading a new application.

Operation
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
10
7 Operation
Once the application has been transferred to the non-volatile memory, the device restarts. On de-
vice startup, a self-test runs. If unsuccessful, the device goes to the error mode. Otherwise the
application runs.
WARNING
Before transferring the application to device, ensure that all network devices are discon-
nected.
Operation mode is cycle oriented:
−Start (readiness test)
−Update of the input process image (input
network variables)
−Running the application
−Update of the output process image (output
network variables)
−Back to Start
For error indication see table 7.1.
For Modbus registers see Table 7.2.
.Fig. 7.1 Operation start
Table 7.1 Error indication
Indication
Cause
Remedy
LOGIC Program INVALID
Invalid application
Repair application in ALP
LOGIC Program STOPPED Application stopped
Start the application using system
menu and restart the device
Table 7.2 Modbus registers
Parameter Data type Address
Read
function
Write
function
Network variables
BOOL
0x2000 – 0x23F0
0x01, 0x02
0x05, 0x0F
INT16 0x0200 – 0x023F 0x03, 0x04 0x06, 0x10
Seconds
INT16
0x0400
0x03, 0x04
0x06, 0x10
Minutes
INT16
0x0401
0x03, 0x04
0x06, 0x10
Hours
INT16
0x0402
0x03, 0x04
0x06, 0x10
Day INT16 0x0403 0x03, 0x04 0x06, 0x10
Month
INT16
0x0404
0x03, 0x04
0x06, 0x10
Year
INT16
0x0405
0x03, 0x04
0x06, 0x10
Weekday INT16 0x0406 0x03, 0x04 -
Week of month
INT16
0x0407
0x03, 0x04
-
Calendar week
INT16
0x0408
0x03, 0x04
-
7.1 RUN-STOP
In this mode, the execution of the user application is stopped. The RUN-STOP mode can be used
to upload a new application to the device. It can be useful if the system menu is unavailable, e.g.
the application is corrupted and / or leads to unstable operation.
To activate the RUN-STOP mode, power on the device with the button pressed.
Power on / Restart / Aplication transfer
Hardware configuration
Self-test
Error
Operation
Successful Failed

Operation
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
11
7.2 Down.Mode
In this mode the firmware update can be forced. This mode is necessary to repair the firmware if
the last firmware update was unsuccessful (power outage, transmission error etc.). See ALP Help
for further details about firmware update.
To activate the Down.Mode, power on the device with the button pressed.

Maintenance
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
12
8 Maintenance
The maintenance includes:
-cleaning of the housing and terminal blocks from dust, dirt and debris
-checking the fastening of the device
-checking the wiring (connecting leads, fastenings, mechanical damage).
The device should be cleaned with a damp cloth only. No abrasives or solvent-containing cleaners
may be used. The safety information in section 3 must be observed when carrying out mainte-
nance.

Transportation and storage
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
13
9 Transportation and storage
Pack the device in such a way as to protect it reliably against impact for storage and transportation.
The original packaging provides optimum protection.
If the device is not taken immediately after delivery into operation, it must be carefully stored at a
protected location. The device should not be stored in an atmosphere with chemically active sub-
stances.
Permitted storage temperature: -20...+55 °C
►
NOTICE
Transport damage, completeness
The device may have been damaged during transportation.
Check the device for transport damage and completeness!
Report the transport damage immediately to the shipper and akYtec GmbH!
►
NOTICE
Before powering on, make sure that the device was stored at the specified ambi-
ent temperature (-20 ... +55 °C) for at least 30 minutes.

Scope of delivery
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover · Germany · Tel.: [phone] · www.akytec.de
14
10 Scope of delivery
– SMI200 1
– Gasket 1
– Mounting nut 1
– Terminal block 1
– Short guide 1
