Aladdin Hardlock Instruction Manual

Installing Instruction
Hardlock Internal PCI
Hardlock Server Internal PCI
© Aladdin Knowledge Systems 2001
Aladdin Document : Hardlock Internal PCI Guide
Hl-mn (10/2001) 1.2-04520
Revision: 1.2
Date: 01.10.2001

S
lot cover
Parallel port for
protection modules
Plug-
i
n contact for the
PCI slot

1
Hardlock Internal PCI
Hardlock Server Internal PCI
You have purchased software which is licensed with hardware. The
software will not run with its full range of functions unless you have the
appropriate hardware, a Hardlock module.
Note Please note that the conditions for use are largely
dependent on how your software vendor has protected the
software. As a result, the procedures explained here may
differ from the actual situation. If in doubt, follow the
instructions given by the software vendor.
Hardlock modules for the PCI slot also serve as a special parallel card
which gives you the following options:
• You can connect additional Hardlock modules to the parallel slot on
the card.
• You can connect the installed Hardlock modules to the external
interface using the supplied cable. This gives you an extra parallel
port, which you can use for additional protection keys, a printer, or
other peripherals.
Necessary steps
• Install the drivers for the hardware, unless the installation is already
integrated in the installation routine of the protected program.
• Prepare the hardware.
• Install the hardware.
• Install the drivers for the extra parallel port, also if you don't want to
use it.

Installing the Hardlock Drivers
2
Installing the Hardlock Drivers
The appropriate drivers must be installed in order to use the Hardlock
modules. To do this, run HLDRV32.EXE.
To use Hardlock Internal PCI and Hardlock Server Internal PCI you need
to install at least HARDLOCK.VXD 2.50 and HARDLOCK.SYS 2.50. The
version numbers display when you run HLDRV32.EXE. Contact your
software vendor if you have any doubts or meet any problems.
Note Driver installation may already have been integrated in the
installation routine for the protected software. This means
there is no need to perform the installation again. Contact
your software vendor if you have any doubts.
Preparing the Hardware
1. Use a wrist grounder to ground yourself or briefly touch a metal part of
the computer housing.
2. Carefully unpack the card. Avoid touching any components or
connection contacts when doing this. If you do, there is a risk of
irreparable damage to components due to static discharges.
3. If required connect additional protection modules to the parallel port
on the card and tighten the screws.
Note: We cannot guarantee that it will be possible to daisy-chain
protection modules made by other manufacturers.
4. Use the supplied cable to connect the last protection module to the
slot cover on the card. This step is only necessary if you wish to use
the card externally as an extra parallel port.

Installing the Card
3
Installing the Card
1. Switch off the computer and disconnect the main plug. Disconnect any
other cables if required and open the housing.
2. Use a wrist grounder to ground yourself or briefly touch a metal part of
the computer housing.
3. Select an unused PCI slot and remove the corresponding slot cover
from the computer housing.
4. Install the card in the appropriate slot. Make sure the slot cover is
pointing towards the housing. First, carefully press the side facing
away from the computer housing into the interface, then the side
facing the housing.
5. Tighten the slot cover onto the computer housing.
6. Put back the housing cover, reconnect the computer to the power
supply and connect the cables which were removed previously.
Installing the Drivers for the Parallel Port
After installing the hardware you need to install the drivers for the parallel
port. This step is always required, also if you don't want to use the
parallel port. The procedure depends on the operating system.
Windows NT4
To install drivers under Windows NT you need to be logged on as an
administrator.
1. Start the computer.
2. Start the supplied installation wizard for installing the drivers,
ACPCI_INSTALL.EXE. The PCIAKS.INF and PCIAKS.SYS files must
be in the same folder.
3. Follow the instructions of the installation wizard.
4. Restart the computer.
The card will now be detected automatically. The new parallel port is
generally assigned to LPT2.

Installing the Drivers for the Parallel Port
4
Windows 95/98/ME and Windows 2000/XP
To install drivers under Windows 2000/XP you need to be logged on as
an administrator.
1. Start the computer.
A message is displayed informing you that new hardware has been
located. The device driver installation wizard opens.
2. Follow the instructions in the wizard. Search for the file automatically
or enter the name of the folder in which the AKSPCI.INF and
AKSPCI2.INF driver files are located. The file is located on the
supplied Aladdin CD or in a folder on the CD provided by your
software supplier. The AKSPPVI.DLL and AKSPP.VXD files must be
in the same folder (not with Windows 2000/XP).
3. Repeat the procedure if required.
4. Restart the computer following driver installation. This step is not
required with Windows 2000/XP.
The card will now be detected automatically. The new parallel port is
generally assigned to LPT2.
A random address is assigned to the parallel port under Windows
NT4/2000/XP. Address 0x378, if available, is assigned with Windows
95/98/ME. Otherwise, address 0x278 is assigned.
Note on driver installation under Windows XP
Under Windows XP drivers for Plug&Play devices (USB, PCI, PCMCIA)
are installed with a signature. The signature ensures that the driver fullfills
the quality criteria for Windows XP.
In spite of this it is still possible to install drivers without a signature. This
requires that Windows XP is configured not to block drivers without
signature. You can change this setting under Driver Signing on the
Hardware tab in System Settings.
