CyberPro PCI 1S
Quick Installation Guide
04-0340B
Introducing the CyberPro PCI 1S I/O
The CyberProPCI1Shigh-speedserialI/Ocard provides
one additional 9-pin serial port. Depending on the
model purchased, this board will fit into either a Full or
Low Profile chassis.
FeaturesandBenefits
•Conforms to PCI v2.2 Plug and Play
•Full support for Windows-based software
•Reduces CPU load and improves system
performance dramatically
•IRQ sharing feature reduces IRQ conflicts
•High-speed serial port (9-pin) works with 56K V.90
external modems, ISDN terminal adapters, PDAs,
digital cameras, label printers and other serial port
devices
•Built-in FIFO buffers dramatically increase data
transmit/receivespeed,especiallyunderWindows'
multitasking environment
•Each serial port can be configured for either 5V or
12V output, for serial devices that require power
SystemRequirements
•Pentium or equivalent computer with an available
PCI slot
•Windows 95/98/98SE/ME/NT 4.0/2000/XP/
Server 2003

2
PackageContents
•CyberPro PCI 1S board
• DriverCD
• Low profile bracket (Dual Profile board only)
• Quick installation guide
Layout
JP1
Serial Port
(9-pin)
Full profile
bracket
Figure 1. Layout
Note: Depending on the model purchased, the
bracket size will be either Full or Low-profile.
JumperSettings(JP1)
Open = 0 volts (default)
Short 1-2 = 5V
Short 2-3 = 12V
Note: Mostserialdevices donotrequireadditional
power through the serial port. Refer to your serial
device's manual for more information.

3
Hardware Installation
General instructions for installing the card are provided
below, since the design of computer cases and
motherboards vary. Refer to your computer’s reference
manual for further information, if needed.
Static Electricity Discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer’s case for a few
seconds. Avoid any contact with internal parts and
handle cards only by their external edges.
1. Turn OFF the power to your computer and any
other connected peripheral devices.
2. Unplug the power cord from the back of the
computer.
3. Remove your computer’s cover.
4. Remove the slot bracket from an available PCI slot.
5. Change JP1 jumper settings to the desired voltage
only if your serial device needs additional power
from the serial port. However, most serial devices
do not require additional power. For more
information go to Figure 1 on page 2. Skip this step
if power is not required.
6. To install the card, carefully align the card's bus
connector with the selected PCI slot on the
motherboard. Push the board down firmly, but
gently, until it is well seated.
7. Replace the slot bracket's holding screw to secure
the card.
8. Replacethecomputercoverandreconnectthepower
cord.

4
Driver Installation
This section provides information on how to install the
CyberPro PCI 1S drivers.
Windows95
1. At the Update Device Driver Wizard, click Next.
2. Insert the driver CD, and click Other Locations.
TypeinD:\9x,clickOK,thenFinish. (Change D:to
match your CD-ROM drive letter)
3. From the Insert Disk window, click OK. When the
Copying Files dialog box appears, type in
D:\9x, then click OK.
4. Restart Windows to complete the installation.
Windows98/98SE
1. At the Add New Hardware Wizard window, click
Next.
2. Select Search for the best driver for your device
(Recommend), then click Next.
3. Select Specify a location, uncheck the other boxes,
insert the driver CD, type in D:\9x,then click Next.
(Change D: to match your CD-ROM drive letter)
4. Click Next, then Finish.
5. Repeat steps 1-4.
6. Restart Windows to complete the installation.
WindowsME
1. AttheAddNewHardwareWizard,chooseSpecify
the location of the driver (Advanced), then click
Next.

5
2. Check Specify a location, uncheck the other box,
insert the driver CD, type in D:\Me, then click
Next. (Change D: to match your CD-ROM drive
letter)
3. Click Next and Finish.
4. Repeat steps 1 and 2.
5. Click Next, Next, then Finish
6. Restart Windows to complete the installation.
ToVerifyWindows95/98/98SE/MEInstallation
1. Fromthemaindesktop,doubleclickMyComputer,
ControlPanel,System,thenclickDeviceManager.
2. DoubleclickPorts(COM&LPT),CyberSerialPCI
16Cxxx... should be displayed.
3. Double click Multi-function adapters, SIIG
CyberPro 1S PCI board and PCI Function should
be displayed.
WindowsNT4.0
1. From the desktop click Start, then Run.
2. Insert the driver CD, type in
D:\NT4\install_serial.exe, then click OK.
(Change D: to match your CD-ROM drive letter)
3. Click Next when the Welcome window appears.
4. Choose Install, then click Next.
5. Click Yes, then click Exit.
6. Restart Windows to complete the installation.

6
ToVerify WindowsNT 4.0Installation
1. Go to Start / Setting / Control Panel,double click
Ports device icon.
2. AnewCOMportwillbeassignedwhensuccessfully
installed.
Windows2000
1. At the Found New Hardware Wizard, click Next.
2. Select Search for a suitable driver for my device
(recommended) and click Next.
3. SelectSpecifyalocation,uncheckthe otheroptions
and click Next.
4. InsertthedriverCD,typeinD:\2000,thenclickOK.
(Change D: to match your CD-ROM drive letter)
5. Click Next and Finish.
6. Repeat steps 1-5 two more times
7. Restart Windows to complete the installation.
WindowsXP
1. AttheFoundNewHardwareWizard,chooseInstall
from a list or specific location (Advanced),then
click Next.
2. Insert the driver CD, check Include this location in
the search,uncheck the other check box, type in
D:\XP,and click Next. (Change D: to match your
CD-ROM drive letter)
3. IftheHardwareInstallationwindowpopsup,click
Continue Anyway, then Finish. Our driver has been
testedforstabilityandcompatibility.
4. Repeat steps 1-3 two more times
5. Restart Windows to complete the installation.

7
WindowsServer2003
1. AttheFoundNewHardwareWizard,chooseInstall
from a list or specific location (Advanced),then
click Next.
2. Insert the driver CD, check Include this location in
the search,uncheck the other check box, type in
D:\2003,and click Next. (Change D: to match your
CD-ROM drive letter)
3. IftheHardwareInstallationwindowpopsup,click
Continue Anyway, then Finish. Our driver has been
testedforstabilityandcompatibility.
4. Repeat steps 1-3 two more times.
5. Restart Windows to complete the installation.
ToVerifyWindows2000/XP/2003Installation
1. RightclickMyComputer,clickManage,thenselect
Device Manager.
2. Click on the + (plus sign) in front of Ports (Com &
LPT), CyberSerial PCI 16Cxxx... should be
displayed.
3. Double click Multifunction adapters, SIIG
CyberPro 1S PCI board should be displayed.

8
Changing COM Port Address
Some serial devices need a specific COM port in order to
work. If your serial device works properly, do not
change this setting.
Windows95/98/98SE/ME
1. From the Device Manager window double click
Ports(COM & LPT), then double click the
CyberSerial PCI serial port you want to change.
2. Click Settings tab, click the down arrow that is next
tothePortNameboxandselectaCOMaddressthat
is not currently in use.
3. Click OK, then close Device Manager to save the
changes.
Windows2000/XP/Server2003
1. From the Device Manager window double click
Ports(COM & LPT), then double click the
CyberSerial PCI serial port you want to change.
2. Click Settings tab and click Advanced.
3. Click the down arrow that is next to the COM Port
numberboxandselectaCOMportthatisnotinuse.
Click OK.
4. Click OK, then close Device Manager to save the
changes.

9
Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers!
Simply visit our website at www.siig.com and click on Support.
Our online support database is updated daily with new drivers
and solutions. Answers to your questions could be just a few clicks
away. Youcanalsosubmitquestionsonlineandoneofourtechnical
supportanalysts will promptlyrespond.
A lifetime manufacturer warranty supplied with this product is
offered by SIIG, Inc. Please see SIIG website for more warranty
details. If you should happen to encounter any problems with this
product,pleasefollowtheproceduresbelow.
If it is within the store's return policy period, please return the
producttothestorewhereyoupurchasedfrom.
If your purchase has passed the store's return policy period, please
followthese steps to havetheproductrepaired or replaced.
Step1: SubmityourRMArequest.
Go to www.siig.com, click Support, then RMA to submit a
request to SIIG RMA. If the product is determined to be
defective,anRMAnumberwillbeissued. SIIGRMAdepartment
can also be reached at [phone].
Step2: After obtaining anRMAnumber, ship theproduct.
•Properlypacktheproductforshipping. Allsoftware,cable(s)
andanyotheraccessoriesthatcame with the originalpackage
mustbeincluded.
•Clearly write your RMA number on the top of the returned
package. SIIGwillrefusetoacceptanyshippingpackage,and
will not be responsible for a product returned without an
RMA number posted on the outside of the shipping carton.
•YouareresponsibleforthecostofshippingtheproducttoSIIG
at the following address:
SIIG,Inc.
6078 Stewart Avenue
Fremont, CA 94538
RMA#:
•SIIG will ship the repaired or replaced product via Ground
in the U.S and International Economy outside of the U.S at
nocosttothecustomer.
