MODEL DL 2700WP
LEVER SETS
PARTS LIST
Standard Cylinder and Interchangeable Core Models
KeyPart No. Description
1a HW592-US3 Battery Cover
1b HW592-US5 Battery Cover
1c HW592-26D Battery Cover
1d HW592-26 Battery Cover
2a HW615-US3 Inside Lever
2b HW615-US5 Inside Lever
2c HW615-26D Inside Lever
2d HW615-26 Inside Lever
Thru Bolt/10-32x2-1/2”, (2)
3a SC458-US3 Flat Hd.,PH,MS
3b SC458-US5 Flat Hd.,PH,MS
3c SC458-26D Flat Hd.,PH,MS
3d SC458-26 Flat Hd.,PH,MS
4a S6044-US3 Inside Housing Ass’y
4b S6044-US5 Inside Housing Ass’y
4c S6044-26D Inside Housing Ass’y
4d S6044-26 Inside Housing Ass’y
Inside Mounting Screws (2)
5a P1526-US3 #6-32x3/8”, Oval Hd
5b P1526-US5 #6-32x3/8”, Oval Hd
5c P1526-26D #6-32x3/8”, Oval Hd
5d P1526-26 #6-32x3/8”, Oval Hd
6 HW594 Inside Mounting Plate
Inside Mounting Plate Screws (2)
7 SC459 #8-32 x 1”, Flat Hd., PH, MS
8a P5851-26D #4-40x1/4”, Flat Hd., PH, MS
8b P5851-US3 #4-40x1/4”, Flat Hd., PH, MS
Inside Rose Screws (2)
9 SC457 #10-32 x 1”, w/#8 Pan Hd, PH, MS
10 HW564 Inside Rose
11 S6045 Lock Body Assembly
11A S6046 IC Lock Body Assembly
12a S6054-US3 Outside Housing Ass’y
12b S6054-US5 Outside Housing Ass’y
12c S6054-26D Outside Housing Ass’y
12d S6054-26 Outside Housing Ass’y
13a HW596-US3 Std. Cylinder Ass’y
13b HW596-26D Std. Cylinder Ass’y
14 HW578 Cylinder Retainer
15a HW614-US3 Outside Lever
15b HW614-US5 Outside Lever
15c HW614-26D Outside Lever
15d HW614-26 Outside Lever
16a HW616-US3 Outside Lever-IC Core
16b HW616-US5 Outside Lever-IC Core
16c HW616-26D Outside Lever-IC Core
16d HW616-26 Outside Lever-IC Core
17 HW618 Lever Release Pin
18a S6034-US3 Latch - 2-3/4” Backset
18b S6034-US5 Latch - 2-3/4” Backset
18c S6034-26D Latch - 2-3/4” Backset
18d S6034-26 Latch - 2-3/4” Backset
18e S6035-US3 Latch - 2-3/8” Backset
18f S6035-US5 Latch - 2-3/8” Backset
18g S6035-26D Latch - 2-3/8” Backset
18h S6035-26 Latch - 2-3/8” Backset
19a SC460-US3 #8x3/4” Combination screw
19b SC460-US5 #8x3/4” Combination screw
19c SC460-26D #8x3/4” Combination screw
19d SC460-26 #8x3/4” Combination screw
20a HW577-US3 Strike 2-3/4” x 1-1/8”
20b HW577-US5 Strike 2-3/4” x 1-1/8”
20c HW577-26D Strike 2-3/4” x 1-1/8”
20d HW577-26 Strike 2-3/4” x 1-1/8”
21 P5847 Dust Box
22 HW598 IC Tailpiece for Best, Arrow, Falcon
Key Part No. Description Key Part No. Description Key Part No. Description Key Part No. Description
1
2
3
28
8
9
10
18
19
21
20
12
17 13
14 15
22
23 24
25 26
16
11
4
7
6
5
IC INTERCHANGEABLE CORE
TAILPIECES
FINISH LEGEND
US3 Polished Brass
US5 Antique Brass
26D Satin Chrome
26 Polished Chrome
27
23 HW597 Std. Tailpiece
24 HW580 Replacement tailpiece for Schlage
25 HW620 Replacement tailpiece for Lori
26 WA160 Tailpiece washer for all tailpieces
27a HW470-US3 Strike 4-7/8” x 1-1/4”
27b HW470-US5 Strike 4-7/8” x 1-1/4”
27c HW470-26D Strike 4-7/8” x 1-1/4”
27d HW470-26 Strike 4-7/8” x 1-1/4”
28 S6040 Battery Pack Assembly
19
W I989 6/99
28
