Alarm Lock CYLINDER ADAPTER KIT Addendum Guide

CYLINDER ADAPTER KIT
ADDENDUM
WI 1177 1/03
CAUTION
PROPER ALIGNMENT OF GEARS IS CRITICAL!
FAILURE TO ALIGN GEARS PROPERLY WILL CAUSE LOCK TO MALFUNCTION.
345 Bayview Avenue
Amityville, New York 11701
For Sales and Repairs 1-800-ALA-LOCK
For Technical Service 1-800-645-9440
© ALARM LOCK 2003
Note: See the illustrated instructions, WI 1163,
"How to Replace Cylinder" for detailed replace-
ment procedures. After inserting the new cylin-
der and Slide Plate, and before replacing the
Cover Plate (step 16), align the gears as follows:
The rollpin hole located on the Spindle Bush-
ing (HW970) must be aligned with the
stamped arrow on the Gear Driver (HW968).
Using a straight edge (or for convenience you
can use the Cover Plate HW1016 instead of a
straight edge) align the gears as shown in the il-
lustration at right:
Place one end of the straight edge directly over
the center retaining screw of the Gear Driver.
Align the other end of the straight edge with the
rollpin hole. The stamped arrow (!) on the Gear
Driver must be directly underneath the straight
edge when aligned with the rollpin hole.
If the arrow is not aligned, loosen the Gear
Driver retaining screw, lift the Gear Driver. The
Slide Plate springs will cause the Spindle Bush-
ing to self-align (if the Slide Plate is installed
properly). Re-position the Gear Driver until the
arrow is aligned with the rollpin hole. Tighten the
Gear Driver Retaining screw, and Replace the
Cover Plate and Frame Spacer as per the direc-
tions in WI 1163.
Rollpin hole
on Spindle
Bushing
(HW970)
Idle Gear
(HW967)
Stamped
Arrow on
Gear Driver
(HW968)
Gear Driver
retaining
screw
