ALAULM 1010Gazebo23-PW-Brown User manual

If you have any questions about the outdoor gazebo, please feel free to contact us.
Customer Service Email: [email protected]
IMPORTANT
PLEASE READ BEFORE YOU COMMENCE ASSEMBLY
Follow the guidelines in this user guide to ensure correct
assembly and care for this product.
10×10 American plastic tile
imitation wood SPA pavilion
(with Sidewall and mosquito net)
1010Gazebo23-PW-Brown

SPECIFICATIONS
01
106.
3 inch
112.2 inch
112.2 inch
124.
8 inch
124.8 inch

Note: The gazebo needs to be installed in cooperation with five people.
The following tools are not included and needed for assembly:
Pistol Drill Tape Measure Rubber Hammer knife
Screw Driver 2 m Adjustable Ladder 2-4 people
NOTICE
Warning
1. This pavilion requires the cooperation of 2-4 people.
2. Please take appropriate actions as heavy rain, wind and snow can damage the
gazebo. If necessary please disassemble and store it for later use.
3. In snowy conditions, please do not allow the thickness of the snow to be more
than 1.82 inches on the roof, this should be cleared as soon as possible for your safety.
4. When the wind speed reaches 38.49 km/h, please take measures to avoid the wind.
02
+

Attention:
1.Please fix all the screws first,do not lock them off,after assembling is
fully completed, lock all at once finally.
2.Please check the manual carefully and make sure you have received all
the parts.
3.If there is any missing,please let us know the letter of the parts you
need.
4.If there is any damage,please send clear photos to us,and we will check
and offer you best solution soon.
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Dear Customer,
Thank you for shopping from us!
When you receive the product, please make sure that all the parts are intact.
Then please browse the entire installation manual before assembling.
If any problem occurs unsatisfactorily as follows：
A.The outer box is damaged
B.The product is damaged / bent / cracked while you open the box
C.The parts / accessories / assembly tools are missing
D.The product is hard to assemble
E. The instructions are not clear and can not be referred
F.The product has functional problems
G.Other aspects that you are not satisfied with
Please feel free to contact us for help. Our after-sales team service
(
[email protected] ) will reply within 24 hours and will do our best to
resolve the problem for you.
03

Part I
Part II
Part III
Part IV
EXPLODED VIEWS
04

PART I
05
P
P
P
Q
Q
R
R
QR O
O
O
P
S1
S2
S2
S1
S2
S2
S1
S2
S2
S1
S2
S2
Q M N
M N
M N
M N
T
RO

PART II
06
J
J
J
J
V
H
H
H
H
I
I
I
I
V
V
X
X
X
X
V

PART III
07
F G
FG
FG
FG

PART IV
08
Z
Z
Y
Y
W
E
B
B
B
B
A
U
U
U
U
A
A
A
C
D

Parts List (Box A)
Parts List (Box B)
B
XWTS1
YZA21
U
A K
S2 L
Sidewall
09
4PCS 4PCS
1PC
4PCS
8PCS
4PCS
1PC
4PCS1PC
1PC 1PC 80 PCS
8PCS 4PCS 4PCS 4PCS
Plastic wood column Column reinforcement profiles
Note:
K is already installed
on the inside of A
Support tripod
Standing plastic
wood pier
Three sides fixed
metal sheet
Diagonal ridge beam
fixed sheet metal Column hook
Roof frame sheet
metal on three sides
Ramp beam
fixed sheet metal Tile top cover
Connecting ridge
tiles (middle hole)
Connecting ridge tiles
(holes on both sides) Column base Mosquito net Hanging hook
A16 A17 A18

10
Parts List (Box C)
Parts List (Box D)
Parts List (Box E)
M
PQR
NO
EC D
4PCS 4PCS 4PCS
4PCS 4PCS 4PCS
4PCS 4PCS 4PCS
Trapezoidal tile left
Reinforced sheet metal crossbeam Short crossbeam - L Short crossbeam - R
Trapezoidal tile right Triangular tile left
Triangular tile right Rectangular tile left Rectangular tile right
A19 A20
4PCS 4PCS
Hanging hook rail left Hanging hook rail right

I
A2 A3A1
A4 A5 A6
J V
11
U
3PCS
Standing plastic wood pier
Parts List (Box E)
4PCS
76PCS
12PCS 56PCS 40PCS
20PCS 40PCS
4PCS
3PCS
4PCS
4PCS4PCS4PCS
F G H
Plastic wood
reinforcement strip-R
Plastic wood
reinforcement strip-L Diagonal ridge profiles
Roof frame inclined beam Roof frame crossbeam Roof frame sheet metal
Bolt M6×16
Bolt M6×65 Self-tapping screws M4×60 Drilling screws M5×50
Bolt M8×16 Bolt M6×40
List (Box B)
H
a a
r
d
w
e
L
Column base

List (Box B)
Nuts M6
H
a a r d w e
1. Please ensure that all accessories are complete before starting the
installation.
2. Due to the variety of accessories, many accessories may be glued
together, please check carefully
3. If any accessories are missing or damaged, please contact the
seller immediately.
E-Mail:
[email protected]
12
4PCS 8PCS 40PCS 20PCS 20PCS
2PCS
1PC 2PCS 1PC
1PC
8PCS
8PCS 24PCS
A7 A8 A9 A10 A11
A12 A13 A14
A15
Self-tapping
screws M4×20 Decorative buckles
M6 Hexagonal wrench
1PC 16PCS 16PCS
AA
M8 Hexagonal wrench
Drill Bit
Gasket Φ6
A25
A22
A23 A24
Rubber ring Φ5
Caulk Gun
Caulk Gloves
Gasket Φ8
Expansion bolts M6*80
Round-headed ground nails Φ8*180
A26
Cross bolt M5×16
A27
Square nuts M5

13
A1
A4 A5 A6
(Box B)
2PCS 2PCS
2PCS
2PCS
6PCS
4PCS 8PCS
2PCS
4PCS
2PCS
2PCS6PCS
Bolt M6×16
Bolt M6×65 Self-tapping screws M4×60 Drilling screws M5×50
A3
Bolt M6×40
A2
Bolt M8×16
Nuts M6
A11
1PC
A7
Self-tapping screws M4×20
A9
A16
Gasket Φ6
Rubber ring Φ5
A10
Gasket Φ8
Hanging hook
A18
Extra
A21
Column hook

STEP 1
14
Bolt M6×40
A× 4
K× 4
U× 4
A3 × 8
L× 4
Note: Part (K) is pre-installed in part (A).
Please align the hole, insert the part (L) into (K), insert the bolt (A3) into the hole,put
the spacer (A9) on the bolt (A3) on the inside of the part (U), and then fix the nut (A11)
tightly on the bolt (A3) and put it into the part (U) from above the part (A).
A
U
L
A3
K
L
A

STEP 2
15
Bolt M6×40Bolt M6×15
E× 4
C× 4
D× 4
B× 8
A3 × 16 A1 × 16
Place the crossbeam (E) with the hole position facing upward, and install the short crossbeam
(C) and (D) on the left and right sides of (E) respectively with (A1) bolts as shown in the
illustration. Install the triangle support (B) as shown in the figure using (A3) bolts under the
cross member already installed.
E
D
A1
A1
B
A3
C
NOTE:Please tighten the bolts.

STEP 3
A+K+U+L
A+K+U+L × 4
E+C+D+B × 2
E+C+D+B
A3
NOTE:Please tighten the bolts.
Combine the installed legs (A+K+U+L) and the installed cross members (E+C+D+B) as
shown in the illustration using (A3) bolts，as shown in the figure first combine the 4 legs
with the two beams.
16
Bolt M6×40
A3 × 8

STEP 4
A+K+U+L × 4
E+C+D+B × 2
NOTE:Please tighten the bolts.
The step3 installed components are placed flat on the ground, and then the step2 installed
beams are placed vertically as shown on the leg pipe hole position, and the bolts (A3) are
installed in the hole position.
17
Bolt M6×40
A3 × 4
