Alcad BU-458 User manual

900
ANTENAS TV BANDA UHF
TV ANTENNAS UHF BAND
ANTENNES TV BANDE UHF

Todas las antenas incorporan simetrizador.
All antennas supplied with matching transformer.
Toutes les antennes ont un symétriseur.
Ganancia
Gain
Gain
Relación delante/detrás
Front/back ratio
Rapport avant/arriere
Impedancia
Impedance
Impédance
Polarización
Polarity
Polarisation
Ángulo de apertura
Beam width
Angle d´ouverture
Longitud
Lenght
Longueur
Resistencia al viento
Wind loading
Résistance au vent
mm
N
Pérdidas de retorno
Return loss
Pertes de retour
H
V
Índice de protección
Protection index
Indice de protection
CÓDIGO-CODE-CODE
MODELO-MODEL-MODELE
Rango de frecuencias
Frequency range
Gamme de fréquences
Canales
Channels
Canaux
dB
dBd
° H
°
V
MHz
dB

9000093
BU-458
14
32
21-60
470-790
24
1298
89
93
HOR /VER
75
25
≥10
IP 53

CÓMO MONTAR LA ANTENA BU-458
HOW TO MOUNT THE ANTENNA BU-458
COMMENT MONTER L'ANTENNE BU-458
4
5
3
Cómo montar la caja del simetrizador
How to mount the matching transformer
Comment monter le boîtier du symétriseur
Cómo montar el segundo tramo de antena
How to mount the second antenna section
Comment monter la deuxième section d'antenne
1
2
NO

CÓMO CONECTAR EL CABLE COAXIAL EN LA CAJA DEL SIMETRIZADOR
HOW TO CONNECT THE COAXIAL CABLE TO THE MATCHING TRANSFORMER
COMMENT RELIER LE CÂBLE COAXIAL DANS LE BOÎTIER DU SYMÉTRISEUR
CM-004
9120039
MC-302
9080023
12 mm
8±1mm3±1
Ø 6,5 - 6,8 mm
Ø 6,9 - 7,2 mm
21
5
3
4
6
7

MONTAJE DE LA POLARIDAD HORIZONTAL O VERTICAL
MOUNTING IN EITHER HORIZONTAL OR VERTICAL POLARITY
MONTAGE EN HORIZONTAL OU VERTICAL
BU-458
AJUSTE DEL ÁNGULO DE ELEVACIÓN
ELEVATION ANGLE ADJUSTMENT
RÉGLAGE DE L'ANGLE D'ÉLÉVATION
30°
HORIZONTAL VERTICAL
CURVA DE GANANCIA Y DIAGRAMAS DE RADIACIÓN
GAIN AND RADIATION GRAPHICS
COURBE DU GAIN ET DIAGRAMME DE RAYONNEMENT
17
16
15
14
13
12
11
10
9
8
7
21 25 30 35 40 45 50 55 60 65 69
dBd
0-10-20
VERHOR
0-10-20

Especificaciones sujetas a modificación sin previo aviso
Specifications subject to modifications without prior notice
Les spécifications sont soumises à de possible modifications sans avis préalable
EN 60728-11:2012
Safety:
Company Address:
Company Name:
declares that the product
Pol. Ind. Arreche-Ugalde, 1
Apdo. 455, 20305 IRÚN (Guipúzcoa), SPAIN
ALCAD, S.L.
BU-458, GA-458
Model Number(s):
TV ANTENNAS UHF BAND
Product Description:
INCLUDING ALL OPTIONS
Product Option(s):
is in conformity with:
Cod. 2637800 - Rev. 01
Supplementary Information:
To comply with these directives, do not use the products without covers and operate
the system as specified.
Irún(SPAIN), 05, Jun 2014 Xabier Isasa General Manager
The product herewith complies with the requirements of the Low Voltage Directive 2006/95/EC and the EMC
Directive 2004/108/EC.
DECLARATION OF CONFORMITY
according to EN ISO/IEC 17050-1:2004
ALCAD, S.L.
Tel. [phone]
Fax [phone]
Int. Tel. +34 - 943 63 96 60
[email protected]
Apdo. 455 - Pol. Ind. Arreche-Ugalde,1
20305 IRUN - Spain
www.alcad.net TURKEY - Istambul
Tel. [phone]
CZECH REPUBLIC - Ostrova v cice
Tel. [phone]
UNITED ARAB EMIRATES - Dubai
Tel. [phone]
FRANCE - Hendaye
Tel. 00 34 - 943 63 96 60
