Alcatel ONETOUCH POP 3 Series Operator's manual

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
1/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
Pixi3-5 3G
ALCATEL ONETOUCH POP 3 (5)
5015D/X/A/E_5016A/J
POP 3 (5) = Pixi3-5 3G
Note: this manual is non-contractual and TCL Communication Ltd. can modify it without prior
notice on the characteristics of described equipments.

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
2/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
1.0
2015-07-15
Draft creation
Xiaolong Yang
Alex Lin
Rev.
Date
Modification description
Prepared By
Checked By
Approved By

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
3/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
Content
1Level 2 repair process ..............................................................................................4
2Warranty Check and Visual Inspection ...................................................................5
2.1 Warranty confirmation of L1.....................................................................................5
2.2 Visual mechanical check..........................................................................................6
2.3 Pretest........................................................................................................................7
3Software download .................................................................................................14
3.1 Equipments requested when download：............................................................14
3.2 Install driver.............................................................................................................14
3.3 SW download process............................................................................................16
5Disassembly and assembly 5015...........................................................................20
5.1 ESD Safety...............................................................................................................20
5.2 Disassembly tool.....................................................................................................20
5.3 Disassembly process .............................................................................................21
5.4 Reassembly Process ..............................................................................................30
5.5 Disassembly process evaluation...........................................................................31
6Disassembly Complete...........................................................................................32
7Level 2 repair...........................................................................................................34
8PCBA exchange.......................................................................................................36
9Other component exchange...................................................................................36
10 Final test ..................................................................................................................37
APPENDIX 1 Packaging Requirements ........................................................................38

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
4/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
1 Level 2 repair process
Reassembly
Record in BIG
End
OK
Retest
OK
OK
Start
Visual Inspection
Warranty Check
Pretest & Failure confirm
SW Upgrade
Disassembly
L2 Repair
Retest
Function test
PCBA Replace
NG
NG
NG
Restore User Information
Back up user data

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
5/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2 Warranty Check and Visual Inspection
2.1 Warranty confirmation of L1
1) IMEI sticker check:
a) Power on the handset, enter *#06#
b) If the IMEI sticker in the back casing is not lost:
We should make sure that the IMEI number must be the same with the one on the IMEI sticker; if
not, it‟s out of warranty policy
2) Humidity sensitive label
If humidity sensitive label is not good, the cell phone will be considered as out of guarantee.
a) Liquid was detection by humidity sensitive label
b) Position of humidity sensitive sticker.
Humidity sensitive sticker is on the bottom of the front casing.

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
6/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
2.2 Visual mechanical check
Mechanical warranties check items:
1) Corrosion
Corrosion on the USB connector, SIM connector, and other metal surfaces。
2) Hole (diameter > 1mm)
Holes on any surface, including the front casing, furnished frame, battery cover, touch Lens,
keypad…
3) Bump
Bumps (diameter > 1mm) on any surface, including front casing, decorate frame, battery
cover, touch Lens, keypad, etc.
Here is the
humidity sensitive
sticker.

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
7/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
4) Scratch
Scratches (length > 3mm) on any surface, including the front casing, decorate frame, battery
cover, touch Lens, keypad, etc.
5) Distortion
Bend, twisted or crushed on the h/s, cover/casing or connectors, etc.
6) Broken
Touch broken, casing/cover broken, etc.
7) Dropped
Keypad tear off, touch lens, connectors dropped, etc.
8) Gap
External physical damage relating to abnormal use, like front case and frame opened
9) Others
Damage caused by disassembly ,wrong part assembly, loss of components
Use in abnormal environment like high temperature causing plastic melts
2.3 Pretest
1) Check that the SIM card is set correctly.
2) Power on the cell phone.
3) If the cell phone asks to input NCK code, this means it is SIM locked and can only be worked
with dedicated SIM card. Use the correct SIM card.

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
8/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
4) Enter the phone code if necessary.
5) After the phone power on, test step by step with the auto test code:
Press *#2886# in dial screen and then you will see the interface displaying the SW version. Select
“Auto” to start the auto test, or select “MANU”to do the MMI test manually.
If one of the tests failed during “Auto”test mode, it will show “Text[X] xxx failed. Restart?”, press
“YES”to retest, press “Next”to go on next test and press ”NO”to finish test.
TRACABILITY
I. You can get some information such as IMEI, CU-REF, PTM, Date Code, etc.
II. Press “Pass” to continue.
TP0
I. It will running the test automatically, don‟t touch TP during test and it will show “Pass”if it
functions well;
II. Press “PASS”to continue.
TP1
I. Please draw on the yellow area and it will show “TEST RESULT OK!”;
II. Press “Pass” to continue.
TP2
I. Please draw on the yellow area and it will show “TEST RESULT OK!”;
II. Press “Pass” to continue;

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
9/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
LCD MIRERGB
I. You will see the LCD display three colors: RED, GREEN and BLUE if it functions well;
II. Press “Pass” to continue;
LCD BLACK
I. You will see the LCD displays black if it functions well;
II. Press “Pass” to continue;
LCD GRAYCHART
I. You will see the LCD displays grey if it functions well;
II. Press “Pass” to continue;
LCD GRAYLEVEL
I. You will see the LCD displays grey level if it functions well;
II. Press “Pass” to continue;
LCD WHITE
I. You will see the LCD displays white if it functions well;
II. Press “Pass”to continue.
KEYPAD
I. Press the key displayed on the screen. The key on the screen will turn grey when you
press it if it functions well;
II. Press “Pass” to continue.

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
10/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
BACKLIGHT
I. The screen backlight and key backlight will be flashing if it functions well;
II. Press “Pass” to continue.
CAMERA
Press “Pass”to continue if the main camera functions well.
CAMERA IMG FRONT
Press “Pass”to continue if the front camera functions well.
CAMERA LED
I. Camera LED will turn on if it functions well;
II. Press “Pass”to continue.
CHARGER LED
I. The charger LED will turn on if it functions well;
II. Press “Pass”to continue.
AUDIO
I. You will hear a voice prompt which introduces some emergency call numbers from the
receiver if it functions well;
II. Press “PASS”to continue;
III. You will hear a voice prompt which introduces some emergency call numbers from the
speaker if it functions well;

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
11/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
IV. Press “Pass”to continue;
V. Make a noise near the main MIC, you will hear it from the receiver if it functions well;
VI. Press “Pass”to continue;
VII. Make a noise near the sub MIC, you will hear it from the receiver if it functions well;
VIII. Press “Pass”to continue.
VIBRATOR
I. You can feel the phone‟s vibrating if it functions well;
II. Press “Pass”to continue.
ACCESSORY
I. Insert headset according to the instruction and you will hear a voice prompt which
introduces some emergency call numbers through the headset left if it functions well;
II. Press “Pass”to continue;
III. You will hear a voice prompt which introduces some emergency call numbers through the
headset right if it functions well;
IV.Press “Pass”to continue;
V. Make a noise near the headset mic, you will hear it from headset if it functions well;
VI.Press “Pass”to continue;
VII. You will hear FM playing and FM frequency will be displayed on the screen if it functions
well;

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
12/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
VIII.Press “Pass”to continue;
IX.Remove headset according to the instruction;
X. Press “Pass”to continue.
CHARGER
I. Insert charger cable according to instruction, it will detect it and say “Battery Voltage”,
“Charger Current”, “Charger: OK”if it functions well;
II. Please remove charger cable and press “Pass”to continue.
USB
I. Insert USB cable according to instruction and it will say “USB: OK”if it functions well;
II. Remove USB cable according to instruction and press “Pass”to continue.
GSENSOR
I. Put the handset towards up according to instruction;
II. Press “Pass”to continue;
III. Put the handset “face down”, “down”, “left”, “right”and “face up”according to instruction,
and then the instruction will disappear and it will say “All positions checked”if it functions
well;
IV. Press “Pass”to continue.
LIGHT SENSOR
I. It will show the value of ambient light and the value will change according to the phone‟s
environment (Bright or Dark), then it will say “dark: OK”, “bright: OK”if it functions well;

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
13/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
II. Press “Pass”to continue.
PROXIMITY
I. Please shawdow the senor according to instruction and it will say “near: OK”, “far: OK”if it
functions well;
II. Press “Pass”to continue.
SIM CARD
I. Insert SIM card and the phone will detect it if it functions well;
II. Press “Pass”to continue.
SD CARD
I. Insert SD card and the phone will detect it if functions well;
II. Press “Pass”to continue.
BATTERY TEMP
I. It will display the value of battery temperature, battery content, battery voltage and battery
ID if it functions well;
II. Press “Pass”to continue.
BT
I. Bluetooth will search automatically and it will display device address if it functions well;
II. Press “Pass”to continue.
WIFI

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
14/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
I. It will search for WIFI hotspot and it will display searched result on the screen if it functions
well;
II. Press “Pass”to continue.
GPS
I. It will run GPS and search for satellite, and then it will display info such as “PRN”, “SNR”,
etc. on the screen if it functions well;
II. Press “Pass”to continue.
3 Software download
It is authorized to download software for the handset which needs to be updated. This downloading tool
is called “Sugar MTK_SP”. Thus internet access is necessary. TS Website: https://css.tclmobile.cn/.
3.1Equipments requested when download：
1) A handset with full power;
2) PC with windows system;
3) A USB cable.
3.2Install driver
Double click to install the Sugar MTK_SP, then select the “Install driver”check box for the driver
installation.

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
15/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
16/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
3.3SW download process
Ⅰ. Login the Sugar MTK_SP, then select the 5015 model:

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
17/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
Ⅱ. Click the button ”Get Version”to check the SW version of the headset.

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
18/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
III. Click the “Upgrade”button, disconnect the USB cable, then insert USB cable again.
Online upgrade process starting:

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
19/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
IV. Upgrade finished:

L2 Repair Document TCLCommunication Ltd.
Rev.
5015D/X/A/E_5016A/J Level 2 Repair Document
Page
1.0
20/42
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
5 Disassembly and assembly 5015
5.1ESD Safety
Please wear static loop or static glove
5.2Disassembly tool
You may use the following tools during the disassembly and reassembly procedure:
Plastic Flake
Tweezers
Screwdriver
(TORX6
)
Soldering iron
Pry bar
Hot wind gun
