Alcatel OmniStack 8008 User manual

Part No. 060117-10, Rev. B
January 2002
OmniStack®8008
Users Guide

An Alcatel service agreement brings your company the assurance of 7x24 no-excuses
technical support. You’ll also receive regular software updates to maintain and
maximize your Alcatel product’s features and functionality and on-site hardware
replacement through our global network of highly qualified service delivery partners.
Additionally, with 24-hour-a-day access to Alcatel’s Service and Support web page,
you’ll be able to view and update any case (open or closed) that you have reported to
Alcatel’s technical support, open a new case or access helpful release notes, technical
bulletins, and manuals. For more information on Alcatel’s Service Programs, see our
web page at www.ind.alcatel.com, call us at 1-800-995-2696, or email us at
[email protected].
This Manual documents OmniStack®8008 hardware and software.
The functionality described in this Manual is subject to change without notice.
Copyright©2002 by Alcatel Internetworking, Inc. All rights reserved. This document may not be
reproduced in whole or in part without the express written permission of Alcatel Internetworking, Inc.
Alcatel® and the Alcatel logo are registered trademarks of Compagnie Financiére Alcatel, Paris,
France. OmniSwitch®and OmniStack®are registered trademarks of Alcatel Internetworking, Inc.
Omni Switch/Router™, SwitchExpertSM, the Xylan logo are trademarks of Alcatel Internetworking,
Inc. All other brand and product names are trademarks of their respective companies.
26801 West Agoura Road
Calabasas, CA 91301
[phone] FAX [phone]
inf[email protected]lcatel.com
US Customer Support-[phone]
International Customer Support-[phone]
Internet-http://www.ind.alcatel.com

Warning
This equipment has been tested and found to comply with the limits for Class B digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio fre-
quency energy and, if not installed and used in accordance with the instructions in this
guide, may cause interference to radio communications. Operation of this equipment in
a residential area is likely to cause interference, in which case the user will be required
to correct the interference at his own expense.
The user is cautioned that changes and modifications made to the equipment without
approval of the manufacturer could void the user’s authority to operate this equipment.
It is suggested that the user use only shielded and grounded cables to ensure compliance
with FCC Rules.
This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus set out in the radio interference regulations of the Canadian depart-
ment of communications.
Le present appareil numerique níemet pas de bruits radioelectriques depassant les lim-
ites applicables aux appareils numeriques de la Class B prescrites dans le reglement sur
le brouillage radioelectrique edicte par le ministere des communications du Canada.

i
Contents
Chapter 1: Switch Management 1-1
Configuration Options 1-1
Required Connections 1-1
Console Port (Out-of-Band) Connections 1-1
In-Band Connections 1-2
Chapter 2: Console Interface 2-1
Log-in Screen 2-1
Main Menu 2-2
System and Switch Information 2-5
Displaying System Information 2-6
Displaying Switch Version 2-7
Management Setup Menu 2-8
Changing the Network Configuration 2-9
IP Configuration 2-10
IP Connectivity Test (Ping) 2-11
HTTP Configuration 2-12
Configuring the Serial Port 2-13
Assigning SNMP Parameters 2-14
Configuring Community Names 2-15
Configuring IP Trap Managers 2-16
Console Login Configuration 2-17
Downloading System Software 2-18
Using TFTP Protocol to Download Over the Network 2-18
Saving the System Configuration 2-19
Managing the Switch 2-20
Configuring the Banner Message 2-21
Configuring the Switch 2-22
Configuring Port Parameters 2-24
Viewing the Current Port Configuration 2-25
Using the Spanning Tree Algorithm 2-26
Configuring Bridge STA 2-27
Configuring STA for Ports 2-28
Viewing the Current Spanning Tree Information 2-30
Displaying the Spanning Tree Bridge State 2-31
Displaying the Spanning Tree Port State 2-32
Using a Mirror Port for Analysis 2-33
Configuring Port Trunks 2-34
IGMP Multicast Filtering 2-36
Configuring IGMP 2-37

Contents
ii
Configuring Broadcast Storm Control 2-38
Port Security Configuration 2-39
Configuring Bridge MIB Extensions 2-40
Configuring Traffic Classes 2-41
Port Priority Configuration 2-42
802.1P Port Traffic Class Information 2-43
Configuring Virtual LANs 2-44
802.1Q VLAN Base Information 2-44
802.1Q VLAN Current Table Information 2-45
802.1Q VLAN Static Table Configuration 2-46
802.1Q VLAN Port Configuration 2-48
Monitoring the Switch 2-49
Displaying Port Statistics 2-50
Displaying RMON Statistics 2-51
Displaying the Unicast Address Table 2-53
Displaying the IP Multicast Registration Table 2-54
Configuring Static Unicast Addresses 2-55
Resetting the System 2-56
Logging Off the System 2-56
Chapter 3: Web Interface 3-1
Web-Based Configuration and Monitoring 3-1
Navigating the Web Browser Interface 3-2
Home Page 3-2
Configuration Options 3-3
Panel Display 3-4
Port State Display 3-4
Configuring the Serial Port 3-5
Main Menu 3-6
System Information 3-7
Switch Information 3-8
Main Board 3-8
IP Configuration 3-9
SNMP Configuration 3-10
SNMP Community 3-10
Trap Managers 3-11
Security Configuration 3-11
Change Password 3-11
Firmware Upgrade Options 3-12
Web Upload Management 3-12
TFTP Download Management 3-13
Configuration Save and Restore 3-14
Configuration Upload Management 3-14
Configuration Download Management 3-14
Address Table Configuration 3-15

Contents
iii
STA (Spanning Tree Algorithm) 3-16
Spanning Tree Information 3-16
Spanning Tree 3-16
Ports 3-17
Spanning Tree Configuration 3-18
Switch 3-18
When the Switch Becomes Root 3-19
STA Port Configuration 3-20
Configuring Bridge MIB Extensions 3-21
Bridge Capability 3-21
Bridge Settings 3-22
Priority 3-23
Port Priority Configuration 3-23
Port Traffic Class Information 3-24
Configuring Virtual LANs 3-25
VLAN Basic Information 3-25
VLAN Current Table 3-26
VLAN Static List 3-27
VLAN Static Table 3-27
VLAN Static Membership by Port 3-29
VLAN Port Configuration 3-30
IGMP Multicast Filtering 3-31
Configuring IGMP 3-31
IP Multicast Registration Table 3-32
Port Menus 3-33
Port Information 3-33
Port Configuration 3-34
Port Broadcast Storm Protect Configuration 3-35
Port Security Configuration 3-36
Using a Port Mirror for Analysis 3-37
Port Trunk Configuration 3-37
Port Statistics 3-39
Etherlike Statistics 3-39
RMON Statistics 3-40
Chapter 4: Advanced Topics 4-1
Layer 2 Switching 4-1
Spanning Tree Algorithm 4-1
Virtual LANs 4-2
Assigning Ports to VLANs 4-3
Port Overlapping 4-3
Automatic VLAN Registration (GVRP) 4-3
Forwarding Traffic with Unknown VLAN Tags 4-4
Forwarding Tagged/Untagged Frames 4-4
Connecting VLAN Groups 4-4

Contents
iv
Multicast Filtering 4-5
IGMP Snooping 4-5
IGMP Protocol 4-5
Class-of-Service (CoS) Support 4-6
Port Trunks 4-6
SNMP Management Software 4-6
Remote Monitoring 4-7
Appendix A: Troubleshooting A-1
Troubleshooting Chart A-1
Upgrading Firmware via the Serial Port A-2
Appendix B: Pin Assignments B-1
Console Port Pin Assignments B-1
DB-9 Port Pin Assignments B-1
Console Port to 9-Pin COM Port on PC B-1
Console Port to 25-Pin DTE Port on PC B-2
Glossary
Index

1-1
Chapter 1: Switch Management
Configuration Options
For advanced management capability, the onboard management agent provides a
menu-driven system configuration program. This program can be accessed by a
direct connection to the serial port on the rear panel (out-of-band), or by a Telnet
connection over the network (in-band).
The management agent is based on SNMP (Simple Network Management
Protocol). This SNMP agent permits the switch to be managed from any PC in the
network using in-band management software.
The management agent also includes an embedded HTTP Web agent. This Web
agent can be accessed using a standard Web browser from any computer attached
to the network.
The system configuration program and the SNMP agent support management
functions such as:
• Enable/disable any port
• Set the communication mode for any port
• Configure SNMP parameters
• Add ports to network VLANs
• Display system information or statistics
• Configure the switch to join a Spanning Tree
• Download system firmware
Required Connections
Console Port (Out-of-Band) Connections
Attach a VT100 compatible terminal or a PC running a terminal emulation program
to the serial port on the switch’s rear panel. Use the null-modem cable provided with
this package, or use a null-modem connection that complies with the wiring
assignments shown in Appendix B of this guide.
When attaching to a PC, set terminal emulation type to VT100, specify the port used
by your PC (i.e., COM 1~4), and then set communications to 8 data bits, 1 stop bit,
no parity, and 9600 bps (for initial configuration). Also be sure to set flow control to
“none.” (Refer to “Configuring the Serial Port” on page 2-13 for a complete
description of configuration options.)
Note: If the default settings for the management agent’s serial port have been
modified and you are having difficulty making a console connection, you can
display or modify the current settings using a Web browser as described under
“Configuring the Serial Port” on page 3-5.

Switch Management
1-2
In-Band Connections
Prior to accessing the switch’s onboard agent via a network connection, you must
first configure it with a valid IP address, subnet mask, and default gateway using an
out-of-band connection or the BOOTP protocol.
Note: By default BOOTP is disabled and the IP address is set to 192.168.10.1. See
“IP Configuration” on page 2-10.
After configuring the switch’s IP parameters, you can access the onboard
configuration program from anywhere within the attached network. The onboard
configuration program can be accessed using Telnet from any computer attached to
the network. The switch can also be managed by any computer using a Web
browser (Internet Explorer 4.0 or above, or Netscape Navigator 4.0 or above), or
from a network computer using network management software.
Notes: 1. This switch supports four concurrent Telnet sessions.
2. The onboard program only provides access to basic configuration functions.
To access the full range of SNMP management functions, you must use
SNMP-based network management software.

2-1
Chapter 2: Console Interface
Log-in Screen
Once a direct connection to the serial port or a Telnet connection is established, the
log-in screen for the onboard configuration program appears as shown below.
Note: A banner message may be configured to appear before the Login screen. The
banner message is a login security alert. (See “Configuring the Banner Message”
on page 2-21.)
If this is your first time to log into the configuration program, then the default user
names are “admin” and “guest,” with the password “switch.” The Administrator has
Read/Write access to all configuration parameters and statistics, while the Guest
has Read Only access to the management program.
You should define a new administrator password, record it and put it in a safe place.
Select Console Login Configuration from the Management Setup Menu and enter a
new password for the administrator. Note that passwords can consist of up to 11
alphanumeric characters and are not case sensitive.
Note: You are allowed three attempts to enter the correct password; on the third failed
attempt the current connection is terminated.
Alcatel OmniStack 8008
Alcatel Internetworking
26801 West Agoura Road
Calabasas, CA, 91301
[phone]
Alcatel OmniStack
Copyright (c), 2000 Alcatel and its licensors.
All rights reserved.
OmniStack is a trademark of Alcatel registered in
the United States Patent and Trademark Office.
Username :
Password :

Console Interface
2-2
Main Menu
The Main Menu is the first screen seen after successfully logging into the system.
Alcatel OmniStack 8008
< Main Menu >
About this product
Management Setup Menu
Switch Configuration Menu
Network Monitor Menu
Reset System Menu
Quit Current Session
Display or change Management information.
Use <TAB> or arrow keys to move. <Enter> to select.
Selection Description
About this product
System Information Provides basic system description, including contact information.
Switch Information Shows hardware/firmware version numbers and power status of the
switch.
Management Setup Menu
Network Configuration Includes IP setup, Ping facility, HTTP (Web server) setup, Telnet
configuration, and MAC address.
Serial Port Configuration Sets communication parameters for the serial port, including
management mode, baud rate, console time-out, and screen data
refresh interval.
SNMP Configuration Activates traps; and configures communities and trap managers.
Console Login
Configuration
Sets user names and passwords for system access, as well as the
invalid password threshold and lockout time.
TFTP Download New
Software
Downloads new version of firmware to update your system (in-band).
Configuration Save and
Restore
Saves the switch configuratin to a file on the TFTP server. This file can
be later downloaded to restore the configuration.
Management
Configuration
Allows management access of the switch from all VLANs or only from a
specified VLAN.

Main Menu
2-3
Banner Message
Configuration
Configures a login security alert message.
Switch Configuration Menu
Port Configuration Enables any port, enables/disables flow control, and sets
communication mode to auto-negotiation, full duplex or half duplex.
Port State Displays operational status, including link state, flow control method,
and duplex mode.
Spanning Tree
Configuration
Enables Spanning Tree Algorithm; also sets parameters for hello time,
maximum message age, switch priority, and forward delay; as well as
port priority and path cost.
Spanning Tree Information Displays full listing of parameters for the Spanning Tree Algorithm.
Mirror Port Configuration Sets the source and target ports for mirroring.
Port Trunking
Configuration
Specifies ports to group into aggregate trunks.
IGMP Configuration Configures IGMP multicast filtering.
BStorm Control
Configuration
Allows you to enable/disable broadcast storm control on a per-port basis
and set the packet-per-second threshold.
Port Security Configuration Allows you to enable and configure port security for the switch.
Extended Bridge
Configuration
Displays/configures extended bridge capabilities provided by this
switch, including support for traffic classes, GMRP* multicast filtering,
and VLAN extensions.
802.1P Configuration Configures default port priorities and queue assignments.
802.1Q VLAN
Base Information
Displays basic VLAN information, such as VLAN version number and
maximum VLANs supported.
802.1Q VLAN Current
Table Information
Displays VLAN groups and port members.
802.1Q VLAN Static Table
Configuration
Configures VLAN groups via static assignments, including setting port
members, or restricting ports from being dynamically added to a port by
the GVRP protocol.
802.1Q VLAN
Port Configuration
Displays/configures port-specific VLAN settings, including PVID,
ingress filtering, and GVRP*.
Network Monitor Menu
Port Statistics Displays statistics on network traffic passing through the selected port.
RMON Statistics Displays detailed statistical information for the selected port such as
packet type and frame size counters.
Unicast Address Table Provides full address listing, as well as search and clear functions.
Selection Description

Console Interface
2-4
IP Multicast Registration
Table
Displays all the multicast groups active on this switch, including
multicast IP addresses and corresponding VLAN IDs.
Static Unicast Address
Table Configuration
Used to manually configure host MAC addresses in the unicast table.
Reset system menu Restarts system with options to use POST, or to retain factory defaults,
IP settings, or user authentication settings.
Quit current session Exits the configuration program.
* Not implemented in the current firmware release.
Selection Description

System and Switch Information
2-5
System and Switch Information
Use the “About this product” menu to display a basic description of the switch,
including contact information, and hardware/firmware versions.
Alcatel OmniStack 8008
< About this product >
System Information
Switch Information
<OK>
Use <TAB> or arrow keys to move. <Enter> to select.
Selection Description
System Information Provides basic system description, including contact information.
Switch Information Shows hardware/firmware version numbers and power status of the switch.

Console Interface
2-6
Displaying System Information
Use the System Information screen to display descriptive information about the
switch, or for quick system identification as shown in the following figure and table.
Alcatel OmniStack 8008
< System Information >
System Description : Alcatel OmniStack 8008
System Object ID : 1.3.6.1.4.1.800.3.1.1.13
System Up Time : 8302069 (0 day 23 hr 3 min 40 sec)
Network Host Name : OmniStack 8008
System Contact :
System Location :
<APPLY> <OK> <CANCEL>
Use <TAB> or arrow keys to move, other keys to make changes.
Parameter Description
System Description System hardware description.
System Object ID MIB II object identifier for switch’s network management subsystem.
System Up Time Length of time the current management agent has been running. (Note that
the first value is 1/100 seconds.)
Network Host Name*Name assigned to the switch system.
System Contact*Contact person for the system.
System Location*Specifies the area or location where the system resides.
*Maximum string length is 255, but the screen only displays 45 characters. You can use the arrow keys to
browse the whole string.

System and Switch Information
2-7
Displaying Switch Version
Use the Switch Information screen to display hardware/firmware version numbers
for the switch, as well as the power status of the system.
Alcatel OmniStack 8008
< Switch Information >
Main Board
Label
P/N : S/N : Revision :
Hardware Version : V3.0 (860 CPU)
Firmware Version : V2.5
POST ROM Version : V1.02
Serial Number : 00-00-11-11-43-21
Port Number : 8
Internal Power Status : Active
Redundant Power Status : Inactive
<OK>
Use <TAB> or arrow keys to move. <Enter> to select.
Parameter Description
Main Board
P/N Part number of the main board.
S/N Serial number of the main board.
Revision Revision number of the main board.
Hardware Version Hardware version of the main board.
Firmware Version System firmware version in Flash ROM.
POST ROM Version Power-On Self-Test version number.
Serial Number MAC address associated with the main board.
Port Number Number of ports on the switch.
Internal Power Status Power status for the switch.
Redundant Power Status Redundant power status for the switch.

Console Interface
2-8
Management Setup Menu
After initially logging onto the system, adjust the communication parameters for your
console to ensure a reliable connection (Serial Port Configuration). Specify the IP
addresses for the switch (Network Configuration / IP Configuration), and then set the
Administrator and User passwords (Console Login Configuration). Remember to
record them in a safe place. Also set the community string which controls SNMP
access to the switch via in-band management software (SNMP Configuration). The
items provided by the Management Setup Menu are described in the following
sections.
Alcatel OmniStack 8008
< Management Setup Menu >
Network Configuration
Serial Port Configuration
SNMP Configuration
Console Login Configuration
TFTP Download New Software
Configuration Save & Restore
Management Configuration
Banner Message Configuration
<OK>
Use <TAB> or arrow keys to move. <Enter> to select.
Selection Description
Network Configuration Includes IP setup, Ping facility, HTTP (Web server) setup, Telnet
configuration, and MAC address.
Serial Port Configuration Sets communication parameters for the serial port, including management
mode, baud rate, console time-out, and screen data refresh interval.
SNMP Configuration Activates traps; and configures communities and trap managers.
Console Login
Configuration
Sets user names and passwords for system access, as well as the invalid
password threshold and lockout time.
TFTP Download New
Software
Downloads new version of firmware to update your system (in-band).
Configuration Save &
Restore
Saves the switch configuration to a file on a TFTP server. This file can be later
downloaded to restore the configuration.
Management
Configuration
Allows management access of the switch from all VLANs or only from a
specified VLAN.
Banner Message
Configuration
Configures a banner message. The banner message is a login security alert
message.

Management Setup Menu
2-9
Changing the Network Configuration
Use the Network Configuration menu to set the bootup option, configure the switch’s
Internet Protocol (IP) parameters, enable the on-board Web server, or to set the
number of concurrent Telnet sessions allowed. The screen shown below is
described in the following table.
Alcatel OmniStack 8008
< Network Configuration >
IP Configuration
IP Connectivity Test(Ping)
HTTP Configuration
MAX Number of allowed Telnet sessions (1-4) : 4
Physical Address : 00-00-11-11-43-21
<APPLY> <OK> <CANCEL>
Use <TAB> or arrow keys to move. <Enter> to select.
Parameter Description
IP Configuration Screen used to set the bootup option, or configure the switch’s IP parameters.
IP Connectivity Test Screen used to test IP connectivity to a (Ping) specified device.
HTTP Configuration Screen used to enable the Web server.
MAX Number of Allowed
Telnet Sessions
The maximum number of Telnet sessions allowed to simultaneously access
the switch.
Physical Address MAC address of the switch.

Console Interface
2-10
IP Configuration
Use the IP Configuration screen to set the bootup option, or configure the switch’s IP
parameters. The screen shown below is described in the following table.
Alcatel OmniStack 8008
< IP Configuration >
Interface Type : Ethernet
IP Address : 192.168.10.1
Netmask : 255.255.255.0
Default Gateway :
IP State : USER-CONFIG
<APPLY> <OK> <CANCEL>
Use <TAB> or arrow keys to move, other keys to make changes.
Parameter Default Description
Interface Type Ethernet Indicates IP over Ethernet.
IP Address 192.168.10.1 IP address of the switch you are managing when accessing it over
the network. The switch supports SNMP over UDP/IP transport
protocol. In this environment, all systems on the Internet, such as
network interconnection devices and any PC accessing the switch
must have an IP address.
Valid IP addresses consist of four decimal numbers, of 0 to 255,
separated by periods. Anything outside of this format will not be
accepted by the configuration program.
Subnet Mask 255.255.255.0 Subnet mask of the switch. This mask identifies the host address
bits used for routing to specific subnets.
Default
Gateway
The gateway that the switch’s agent uses to pass data to the
management station. Note that the gateway must be defined if the
management station is located in a different IP segment.
IP State USER-CONFIG Specifies whether IP functionality is enabled via manual
configuration, or set by Boot Protocol (BootP). Options include:
USER-CONFIG -IP functionality is enabled based on the default or
user specified IP configuration.
BOOTP-GET-IP - IP is enabled but will not function until a BootP
reply has been received. BootP requests will be broadcast 10
times, once every second, in an effort to learn its IP address. If no
response is received, the switch will use the default IP setting in
NVRAM. (BootP values can include the IP address, default
gateway, and subnet mask.)
