Alcor Micro AU6337 Product manual

AU6337
USB2.0 SD/MMC/MS
Single/Dual LUN Card Reader controller
Technical Reference Manual
查询AU6337供应商 捷多邦，专业PCB打样工厂，24小时加急出货

AU6337
USB2.0 SD/MMC/MS
Single/Dual LUN Card Reader controller

C
Co op py yr ri ig gh ht t
Copyright © 1997 - 2007. Alcor Micro, Corp. All Rights Reserved. No part of this data
sheet may be reproduced, transmitted, transcribed, stored in a retrieval system or
translated into any language or computer language, in any form or by any means,
electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without prior
written permission from Alcor Micro, Corp.
T
Tr ra ad de em ma ar rk k A Ac ck kn no ow wl le ed dg ge em me en nt ts s
The company and product names mentioned in this document may be the trademarks
or registered trademarks of their manufacturers.
D
Di is sc cl la ai im me er r
Alcor Micro, Corp. reserves the right to change this product without prior notice. Alcor
Micro, Corp. makes no warranty for the use of its products and bears no responsibility
for any error that appear in this document. Specifications are subject to change
without prior notice.
R
Re ev vi is si io on n H Hi is st to or ry y
Date Revision Description
July 2007 1.00W Official Release.
C
Co on nt ta ac ct t I In nf fo or rm ma at ti io on n: :
Web site: http://www.alcormicro.com/
Taiwan China ShenZhenOffice
Alcor Micro, Corp. Rm.2407-08, Industrial Bank Building
4F, No 200 Kang Chien Rd., Nei Hu, No.4013, Shennan Road,
Taipei, Taiwan, R.O.C. ShenZhen,China. 518026
Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone]
Santa Clara Office Los Angeles Office
2901 Tasman Drive, Suite 206 9070 Rancho Park Court
Santa Clara, CA 95054 Rancho Cucamonga, CA 91730
USA USA
Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone]

<Memo>

i
Table of Contents
1. Introduction ............................................................ 1
1.1 Description...................................................................................1
1.2 Features........................................................................................1
2. Application Block Diagram ...................................2
3. Pin Assignment...................................................... 3
4. System Architecture and Reference Design ....... 10
4.1 AU6337 Block Diagram ...............................................................10
5. Electrical Characteristics...................................... 11
5.1 Absolute Maximum Ratings........................................................11
5.2 Recommended Operating Conditions .......................................11
5.3 General DC Characteristics........................................................11
5.4 DC Electrical Characteristics of 3.3V I/O Cells..........................12
5.5 USB Transceiver Characteristics...............................................12
5.6 Power Switch Feature .................................................................16
6. Mechanical Information......................................... 17
7. Abbreviations ......................................................... 19

ii
List of Figures
Figure 2.1 Block Diagram..................................................................2
Figure 3.1 48 LQFP (GBL) Pin Assignment Diagram......................3
Figure 3.2 28SSOP (GBS) Pin Assignment Diagram ......................6
Figure 3.3 28SSOP (GCS) Pin Assignment Diagram ......................8
Figure 4.1 AU6337 Block Diagram ...................................................10
Figure 5.1 Card Detect Power-on Timing.........................................16
Figure 6.1 48 LQFP Mechanical Information Diagram....................17
Figure 6.2 28 SSOP Mechanical Information Diagram ...................18
List of Tables
Table 3.1 48 LQFP (GBL) Pin Descriptions......................................4
Table 3.2 28SSOP (GBS) Pin Descriptions......................................7
Table 3.3 28SSOP (GCS) Pin Descriptions......................................9
Table 5.1 Absolute Maximum Ratings .............................................11
Table 5.2 Recommended Operating Conditions.............................11
Table 5.3 General DC Characteristics..............................................11
Table 5.4 DC Electrical Characteristics of 3.3V I/O Cells ...............12
Table 5.5 Electrical characteristics..................................................12
Table 5.6 Static characteristic：Digital pin .....................................13
Table 5.7 Static characteristic：Analog I/O pins（DP/DM）..........13
Table 5.8 Dynamic characteristic：Analog I/O pins（DP/DM）.....14

AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W 1
1. Introduction
1
1. .1 1 D De es sc cr ri ip pt ti io on n
AU6337 is an USB2.0 high-speed transmission controller, which is designed as a
bridge between USB and SD/MS compatible flash card interface, such as SD, HS-SD,
MMC, HS-MMC, RS-MMC, MMCmicro, MS, MS Pro and MS Duo…etc. AU6337 can
read digital contents stored on memory card designed to cover a wide area of
applications such as digital cameras, PDAs, MP3 players and smart phones…etc.
With the AU6337, users can transfer digital data between flash memory card and PC
or other electronic devices.
AU6337 inherits the high-performance and cost-efficiency character from Alcor’s
products, included power switch integration, dynamic icon utility support, and DMA
engine integration.
1
1. .2 2 F Fe ea at tu ur re es s
 Support USB V2.0 specification and USB Device Class Definition for Mass
Storage, Bulk-Transport V1.0
 Support SD/MMC/MS compatible flash card
 Support the latest flash card specification: SD2.0 (SDHC), MMC4.2 (8-bit),
MSPro parallel mode (4-bit)
 Alcor DMA engine integrated for performance enhancement
 Work with default driver from Windows ME/2000/XP/Vista and Mac OS X;
Windows 98/2000(SP1/SP2) and Mac OS 9 are supported by vendor driver
from Alcor.
 Ping-pong FIFO implementation for concurrent bus operation
 Support multiple sectors transfer optimize performance
 Support slot-to-slot read/write operation (Dual LUN)
 Support Dynamic Icon Utility
 Support LED for bus operating indication
 Power switch integrated to reduce production BOM cost
 53.3 and 3.31.8V regulators built in
 48-pin package for two slots (SD and MS)
 28-pin package for single slot (SD or MS)

AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W
2
2. Application Block Diagram
The following application drawing demonstrates a typical card reader block diagram
using AU6337. By connecting one card reader to a desktop or notebook PC through
USB bus, the AU6337 becomes a bus-powered, high speed USB card reader, which
can be used as a bridge for data transfer between Desktop PC and Notebook PC.
Figure 2.1 Block Diagram
PC with USB Host Controller
USB
Flash Memory Card
Reader Moble Phones
PDA
MP3 Player
Digital Camera
SD/MMC/MS
PC

AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W 3
3. Pin Assignment
There are three different form factor packages available to choose from. The following
figure shows signal names for each pin and the table in the page after describes each
pin in details.
Figure 3.1 48 LQFP (GBL) Pin Assignment Diagram
VDD
1
2
3
5
4
6
7
8
10
9
11
33
32
31
29
30
34
46 45 44 43 42
12
35
36
28
27
26
25
41 40 39 38 374748
13 14 15 16 17 18 19 20 21 22 23 24
ALCOR MICRO
AU6337-GBL
48PIN LQFP
SDDATA5
MSINS
SDDATA0
GPI3
SDCLK
GPI2
RSTN
GPON7
MSBS
GPI0
GND
SDDATA6
SDCDN
VDD33C
MS_V33
SD_V33
SDCMD
SDDATA1
SDWP
SDDATA3
SDDATA4
SDDATA2
GPON6
SDDATA7 MSDATA0 MSDATA1 MSDATA3 MSCLK MSDATA2 ReaderMod
e
VDDHM AVDD5V V18 VSSHM VDD3V
EEPCLK
EPPDATA
REXT
VD33P
DP
DM
VS33P
XI
XO
VS33P
VDDU
AGND5V

AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W
4
Table 3.1 48 LQFP (GBL) Pin Descriptions
Pin # Pin Name I/O Description
1 EEPCLK O EEPROM serial clock.
2 EPPDATA I/O EEPROM for PID,VID customization.
3 REXT I External Resistor 330 to Ground
4 VD33P I Connected to 3.3V
5 DP I/O DP Signal for USB
6 DM I/O DM Signal for USB
7 VS33P I Connected to Ground
8 XI I 12 MHz crystal input.
9 XO O 12 MHz crystal output.
10 VS33P I Connected to Ground
11 VDDU I Connected to 1.8V
12 AGND5V I Ground
13 AVDD5V I 5V input
14 VDD3V O Internal Regulator 3.3V output
15 V18 O Internal Regulator 1.8V output
16 VDDHM I 3.3V input for IO
17 ReaderMode I "0" for Normal, "1" for high-Z
18 VSSHM I Ground
19 MSDATA1 I/O MS Data1. (suspend output mode and databus is
zero)
20 MSDATA0 I/O MS Data0. (suspend output mode and databus is
zero)
21 MSDATA2 I/O MS Data2. (suspend output mode and databus is
zero)
22 MSDATA3 I/O MS Data3. (suspend output mode and databus is
zero)
23 MSCLK O MS serial protocol clock. (suspend IObus is zero)
24 SDDATA7 I/O SD Data 7
25 SDDATA6 I/O SD Data 6
26 SDCDN I SD Card Detect, Low Active
27 VDD33C I Card Power switch
28 MS_V33 O MS card Power

AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W 5
Pin # Pin Name I/O Description
29 SD_V33 O SD card Power
30 SDCMD I/O SD Command
31 SDDATA1 I/O SD Data 1
32 SDWP I SD Write Protect
33 SDDATA2 I/O SD Data 2
34 GPON6 O Card Access LED
35 SDDATA3 I/O SD Data 3
36 SDDATA4 I/O SD Data 4
37 SDDATA5 I/O SD Data 5
38 MSINS I MS stick insertion/extraction detect.
39 SDDATA0 I/O SD Data 0
40 GPI3 I NC
41 SDCLK O SD Clock
42 GPI2 I
Current value.
'0' for 100mA.
'1' for 250mA.
[Default]: '0'
43 RSTN I Reset (low active to reset the whole chip), must be
pull up with RC.
44 GPON7 O Power LED
45 MSBS O MS protocol bus state. (suspend IObus is zero)
46 GPI0 I LUN mode select '1' for share 1LUN
'0' for 2LUN
47 GND I Ground
48 VDD I 1.8V input

AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W
6
The following figure shows signal names of each pin of the 80-pin package and the
table in the page after describes each pin in details.
Figure 3.2 28SSOP (GBS) Pin Assignment Diagram
1
2
3
4
5
6
7
8
9
10
11
12 17
28
27
26
25
24
23
22
21
20
19
18
13
14
16
15
GPI0
GND
VDD
REXT
VD33P
DP
DM
VS33P
XI
XO
VDDU
AGND5V
AVDD5V
VDD3V V18
VDDHM
VSSHM
SDCDN
VDD33C
SD_V33
SDCMD
SDDATA1
SDWP
SDDATA2
CLED
SDDATA3
SDDATA0
SDCLK
Alcor Micro
AU6337-GBS
28-PIN SSOP

AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W 7
Table 3.2 28SSOP (GBS) Pin Descriptions
Pin # Pin Name I/O Description
1 GPI0 I Reserved.
Always connect to 3.3V on PCB
2 GND I Core ground
3 VDD I Core 1.8V power input
4 REXT I External Resistor 330 to Ground
5 VD33P I UTMI 3.3V power input
6 DP I/O USB DP
7 DM I/O USB DM
8 VS33P I UTMI 3.3V ground
9 XI I 12MHz crystal input
10 XO O 12MHz crystal output
11 VDDU I UTMI 1.8V input
12 AGND5V I 5 to 3.3 regulator ground
13 AVDD5V I 5 to 3.3 regulator 5V input
14 VDD3V O 5 to 3.3 regulator 3.3V output
15 V18 O 3.3 to 1.8 regulator 1.8V output
16 VDDHM I IO 3.3V power /
3.3 to 1.8 regulator 3.3V input
17 VSSHM I IO 3.3V ground
18 SDCDN I SD card detect
19 VDD33C I Card power switch 3.3V input
20 SD_V33 O Card power switch output
21 SDCMD I/O SD command
22 SDDATA1 I/O SD data 1
23 SDWP I SD write protect
24 SDDATA2 I/O SD data 2
25 CLED O Card Access LED
26 SDDATA3 I/O SD data 3
27 SDDATA0 I/O SD data 0
28 SDCLK O SD clock

AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W
8
The following figure shows signal names of each pin of the 80-pin package and the
table in the page after describes each pin in details.
Figure 3.3 28SSOP (GCS) Pin Assignment Diagram
1
2
3
4
5
6
7
8
9
10
11
12 17
28
27
26
25
24
23
22
21
20
19
18
13
14
16
15
EEPDATA
REXT
VD33P
DP
DM
VS33P
XI
XO
VDDU
AGND5V
AVDD5V
VDD3V
V18
VDDHM VSSHM
MSDATA1
MSDATA0
MSDATA2
MSDATA3
MSCLK
VDD33C
MS_V33
CLED
MSINS
MSBS
GPI0
VDD
EEPCLK
Alcor Micro
AU6337-GCS
28-PIN SSOP

AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W 9
Table 3.3 28SSOP (GCS) Pin Descriptions
Pin # Pin Name I/O Description
1 EEPDATA I/O EEPROM data
2 REXT I External Resistor 330 to Ground
3 VD33P I UTMI 3.3V power input
4 DP I/O USB DP
5 DM I/O USB DM
6 VS33P I UTMI 3.3V ground
7 XI I 12MHz crystal input
8 XO O 12MHz crystal output
9 VDDU I UTMI 1.8V input
10 AGND5V I 5 to 3.3 regulator ground
11 AVDD5V I 5 to 3.3 regulator 5V input
12 VDD3V O 5 to 3.3 regulator 3.3V output
13 V18 O 3.3 to 1.8 regulator 1.8V output
14 VDDHM I IO 3.3V power /
3.3 to 1.8 regulator 3.3V input
15 VSSHM I IO 3.3V ground
16 MSDATA1 I/O Memory Stick Data1
17 MSDATA0 I/O Memory Stick Data0
18 MSDATA2 I/O Memory Stick Data2
19 MSDATA3 I/O Memory Stick Data3
20 MSCLK O Memory clock
21 VDD33C I Card power switch 3.3V input
22 MS_V33 O Card power switch output
23 CLED O Card Access LED
24 MSINS I
25 MSBS O Memory Stick BS
26 GPI0 I Reserved.
Always connect to 3.3V on PCB
27 VDD I Core 1.8V power input
28 EEPCLK O EEPROM clock

4. System Architecture and Reference
Design
4
4. .1 1 A AU U6 63 33 37 7 B Bl lo oc ck k D Di ia ag gr ra am m
Figure 4.1 AU6337 Block Diagram
5V
1.8 V
3.3V
Voltage
Regulator
12MHz
XTAL
XCVR
USB
SIE RAM
Processor ArbitratorROM
SD/MMC/MS
Control FIFO
SD
MMC
MS
USB
Upstream
Port
AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W
10

5. Electrical Characteristics
5
5. .1 1 A Ab bs so ol lu ut te e M Ma ax xi im mu um m R Ra at ti in ng gs s
Table 5.1 Absolute Maximum Ratings
SYMBOL PARAMETER RATING UNITS
VDDHM
VDD33C Power Supply -0.3 to VDDH +0.3 V
VIN Input Signal Voltage -0.3 to 3.6 V
VOUT Output Signal Voltage -0.3 to VDDH +0.3 V
TSTG Storage Temperature -40 to 150 OC
5.2 Recommended Operating Conditions
Table 5.2 Recommended Operating Conditions
SYMBOL PARAMETER MIN TYP MAX UNITS
AVDD5V 5V Power Supply 4.75 5.0 5.0 V
VDDHM
VDD33C Power Supply 3.0 3.3 3.6 V
VDD
V18 Digital Supply 1.62 1.8 1.98 V
VIN Input Signal Voltage 0 3.3 3.6 V
TOPR Operating Temperature 0 85 OC
5
5. .3 3 G Ge en ne er ra al l D DC C C Ch ha ar ra ac ct te er ri is st ti ic cs s
Table 5.3 General DC Characteristics
SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
IIN Input current No pull-up or
p
ull-down -10 ±1 10 µA
IOZ Tri-state leakage current -10 ±1 10 µA
CIN Input capacitance Pad Limit 2.8 ρF
COUT Output capacitance Pad Limit 2.8 ρF
CBID Bi-directional buffer
ca
p
acitance Pad Limit 2.8 ρF
AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W 11

5
5. .4 4 D DC C E El le ec ct tr ri ic ca al l C Ch ha ar ra ac ct te er ri is st ti ic cs s o of f 3 3. .3 3V V I I/ /O O C Ce el ll ls
s
Table 5.4 DC Electrical Characteristics of 3.3V I/O Cells
Limits
SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNIT
VDDHM
VDD33C Power supply 3.3V I/O 3.0 3.3 3.6 V
Vil Input low voltage 0.8 V
Vih Input high voltage LVTTL 2.0 V
Vol Output low voltage ∣Iol∣=2~16mA 0.4 V
Voh Output high voltage ∣Ioh∣=2~16mA 2.4 V
Rpu Input pull-up resistance PU=high, PD=low 55 75 110 KΩ
Rpd Input pull-down resistance PU=low, PD=high 40 75 150 KΩ
Iin Input leakage current Vin= VDDHM or 0 -10 ±1 10 μA
Ioz Tri-state output leakage
current -10 ±1 10 μA
5
5. .5 5 U US SB B T Tr ra an ns sc ce ei iv ve er r C Ch ha ar ra ac ct te er ri is st ti ic cs s
Table 5.5 Electrical characteristics
Symbol Parameter Conditions Min. Typ. Max. Unit
VD33P Analog supply Voltage 3.0 3.3 3.6 V
VDD
V18 Digital supply Voltage 1.62 1.8 1.98 V
ICC Operating supply current High speed operating
at 480 MHz 55 mA
ICC (susp) Suspend supply current
In suspend mode,
current with 1.5kΩ
pull-up resistor on pin
RPU disconnected
120 µA
AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W
12

Table 5.6 Static characteristic：Digital pin
Symbol Parameter Conditions Min. Typ. Max. Unit
Input levels
VIL Low-level input voltage 0.8 V
VIH High-level input voltage 2.0 V
Output levels
VOL Low-level output voltage 0.2 V
VOH High-level output voltage VDDHM-0.2 V
Table 5.7 Static characteristic：Analog I/O pins（DP/DM）
Symbol Parameter Conditions Min. Typ. Max. Unit
USB2.0 Transceiver（HS）
Input Levels（differential receiver）
VHSDIFF High speed differential
input sensitivity
∣VI（DP）-VI（DM）∣
measured at the
connection as
application circuit
300 mV
VHSCM
High speed data signaling
common mode voltage
range -50 500 mV
Squelch detected 100 mV
VHSSQ High speed squelch
detection threshold No squelch detected 150 mV
Disconnection
detected 625 mV
VHSDSC High speed disconnection
detection threshold Disconnection not
detected 525 mV
Output Levels
VHSOI High speed idle level
output voltage(differential) -10 10 mV
VHSOL High speed low level
output voltage(differential) -10 10 mV
VHSOH High speed high level
output voltage(differential) -360 400 mV
VCHIRPJ Chirp-J output voltage
（differential）700 1100 mV
VCHIRPK Chirp-K output voltage
（differential）-900 -500 mV
Resistance
RDRV Driver output impedance Equivalent resistance
used as internal chip
only 3 6 9
Ω
AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W 13

Overall resistance
including external
resistor 40.5 45 49.5
Termination
VTERM
Termination voltage for
pull-up resistor on pin
RPU 3.0 3.6 V
USB1.1 Transceiver（FS/LS）
Input Levels（differential receiver）
VDI Differential input
sensitivity ∣VI（DP）-VI（DM）∣0.2 V
VCM Differential common
mode voltage 0.8 2.5 V
Input Levels（single-ended receivers）
VSE Single ended receiver
threshold 0.8 2.0 V
Output levels
VOL Low-level output voltage 0 0.3 V
VOH High-level output voltage 2.8 3.6 V
Table 5.8 Dynamic characteristic：Analog I/O pins（DP/DM）
Symbol Parameter Conditions Min. Typ. Max. Unit
Driver Characteristics
High-Speed Mode
tHSR High-speed differential
rise time 500 ps
tHSF High-speed differential fall
time 500 ps
Full-Speed Mode
tFR Rise time CL=50pF；10 to 90﹪
of∣VOH-VOL∣； 4 20 ns
tFF Fall time CL=50pF；90 to 10﹪
of∣VOH-VOL∣； 4 20 ns
tFRMA Differential rise/fall time
matching（tFR / tFF）Excluding the first
transition from idle
mode 90 110
％
VCRS Output signal crossover
voltage
Excluding the first
transition from idle
mode 1.3 2.0 V
Low-Speed Mode
tLR Rise time CL=200pF-600pF；
10 to 90﹪of
∣VOH-VOL∣； 75 300 ns
AU6337 USB 2.0 SD/MMC/MS Single/Dual LUN Flash Memory Card Reader V1.00W
14
