SERVICE INSTRUCTIONS
Diaphragm Pump 8301
DESCRIPTION
The Model 8301 Air-Powered Diaphragm Pump is
used to transfer corrosive chemicals. The wetted
parts are polypropylene and the diaphragms are
Santoprene to resist damage from caustics, plating
liquids, brine water and other corrosive chemicals. A
silencer enclosed in the body reduces the noise. The
pump delivers a maximum capacity of fourteen
gallons per minute.
The pump has the following outstanding features:
1. Leak-Free Flange Connections
2. Side-Outlet Port Design
3. Non-Leak Manifold
4. Corrosion-Resistant Air Motor
5. Abrasion-Resistant Housing
6. Air-Valve Reset Button
7. Air Valve Requires No Lubrication
SPECIFICATIONS
Pump Ratio: ..........................................................1:1
Air Connections:
Inlet: .................................................... 1/4" NPT (f)
Outlet: ................................................. 3/8" NPT (f)
Material Connections:
Inlet: .................................................... 1/2" NPT (f)
Outlet: ................................................. 1/2" NPT (f)
Discharge Volume per Cycle ..................... 0.025 Gal.
Maximum Size Solid:..........................................1/32"
Air-Supply Pressure: ................................ 20-100 PSI
Temperature Range: ................................. 32-140° F.
Net Weight: .................................................... 7.7 lbs.
GENERAL SAFETY REQUIREMENTS
IMPORTANT: Read all instruction sheets and any
other explanatory information before beginning any
installation, operation or maintenance.
1. Check all hoses and lines for weak or damaged
condition and make sure that all connections are
secure.
NOTE: Worn or damaged parts threaten person and
property. Replace all such parts.
2. Do not use pump with any liquids not compatible
with the materials of the pump components.
3. Never exceed the maximum pressure rating of any
component in the system.
Figure 1: Model 8301 Diaphragm Pump
AlemiteCorporation
www.alemite.com
167RowelandDrive,JohnsonCity, Tennessee 37601 SER 8301 (6-03)
670557

SER 8301
page 2 page revised 6-03
4. Never point the dispensing device at anyone.
Accidental discharge can cause serious injury.
5. Shut off the air pressure and relieve all material
pressures before attempting to service any part.
6. Check for leaks before starting any pumping
operation. If any leaks or other abnormalities are
found, do not operate the pump.
7. Wear safety glasses at all times when operating
the pump.
8. Wear a face shield and proper body protection
when working with hazardous chemicals.
9. When pumping Class 1 Hazardous (flammable)
liquids, use pump outdoors or in an OSHA approved
location.
10. When pump is used with flammable or Class 1 ma-
terials,thefollowingproceduresmustbestrictlyapplied:
A. A special “static hose” must be used which has
a provision for conducting static electrical charges.
B. Hose must be properly grounded with a
grounding conductor.
C. Pump and entire system must be properly
grounded, in accordance with local and national
codes.
WARNING: Unless proper grounding is followed,
static discharge can cause a fire or an explosion.
INSTALLATION
There are many possible configurations in which the
pump can be connected. Specific installations will
depend on the fluid being pumped and the application.
NOTE: For best results, it is recommended that an
air filter/moisture separator (such as the Alemite
5604-2) and an air-pressure regulator (such as the
Alemite 7604-B) be used in the air line.
WARNING: The pump must be grounded to prevent
anysparkswhenpumpingflammableorvolatileliquids.
NOTE: The inlet and outlet manifolds are reversible
to facilitate connecting the hoses from either
direction.
1. Connect a suction hose from the supply container
to the pump fluid inlet.
2. Connect a discharge hose to the pump fluid outlet. Figure 2: Dimensions & Locations
▼
▼
▲
▲
▼
▼
▼
▼
▼
▼
▼▼
▲
▲
▲
▼
▼
▼
▼
▼
7-5/16
4-29/32
3-29/32—4-15/16
7-3/32
5-29/32
8-7/32
2-3/32
8-7/8
4-7/8
2-17/32
11-29/32
Fluid
Outlet
1/2"NPT
Fluid
Inlet
1/2" NPT
Air
Supply
1/4" NPT
▼
▼
Air
Exhaust
3/8" NPT

SER 8301
page revised 6-03 page 3
NOTE: Use a flexible hose between the pump and
any piping to eliminate any vibration in the piping.
3. Connect a hose from the air supply to the inlet air
port.
NOTE: Make sure that the air-control valve on the
diaphragm pump is closed before connecting to the
air supply.
CAUTION: Maximum air pressure is 100 PSI. Do not
exceed this rating.
NOTE: Due to the plastic construction of the pump, it
is recommended that for all hardware connections,
standard torque values should be used. Pipe-thread
sealant should be used on all plumbing connections.
Over torquing of any component can lead to
distortion of plastic.
OPERATION
WARNING: Wear safety glasses at all times when
operating the pump. Always wear a face shield and
proper body protection when working with hazardous
chemicals.
NOTE: Check for leaks before starting any pumping
operation. If any leaks or other abnormalities are
found, do not operate the pump.
1. The positive-displacement pump is self priming.
To initially prime the pump, using either the control
valve on the pump or the air-regulator valve, bring
the air pressure up slowly.
NOTE: Due to the fact that air and air mixed with
material (which may be a corrosive chemical) can
discharge quite violently during this procedure, direct
the discharge outlet back to the source at this time. If
a reel is used, bring the reel outlet back to the
source. If the reel is too far away for the hose to
reach, bleed the air into a separate container until the
pump and hose are primed.
NOTE: If starting difficulty is encountered, press the
reset button which is located at the air valve.
2. When the pump and hose are fully primed, the
pump is ready for operation.
NOTE: If the pump is operated faster than the
allowable flow rate, it can cause cavitation. This will
reduce the rate flow of the fluid and also reduces the
life of the diaphragm.
3. To obtain the maximum discharge rate, start the
pump by opening the ball valve gradually while
watching the discharging fluid until the flow rate
begins to diminish. Then close the valve slightly to
get the maximum discharge rate.
SERVICE
Trouble-Shooting:
For the most common of problems, a trouble-
shooting chart is provided as a guide to most of the
corrective remedies. (See Table 1.)
MAINTENANCE
INLET CHECK VALVES:
(Figures 3 and 6)
Disassembly:
NOTE: To remove the inlet check valves, the pump
must be turned over.
1. Remove the four nuts (4), lockwashers (3) and
flatwashers (2) that hold the two bases (40) and the
outlet manifold (13) to the two end castings (21).
2. Remove the two bases and the inlet manifold.
NOTE: There are two inlet cavities in the pump. This
procedureiswrittenforonebutisidenticalfortheother.
3. Remove the top “O” ring (16) from the inlet cavity.
4. Remove the valve seat (23) from the inlet cavity.
5. Remove the valve cage (15) with the check-valve
disk from the inlet cavity.
6. Remove the check-valve disk (14) from the valve
cage.
7.Removethebottom“O”ring(16)fromtheinletcavity.
8. Clean and inspect all parts. Replace any parts that
are worn or show any signs of disintegration due to
the corrosive effects of some of the fluids.

Reassembly:
NOTE: The reassembly procedure is written for one
inlet valve but is identical for the other.
1. Reinsert the bottom “O” ring (16) in the inlet cavity.
Make sure that it is properly seated.
2. Insert the check-valve disk (14) into the valve cage
(15).
3. Insert the valve cage with the check-valve disk in
the inlet cavity.
4. Reinsert the valve seat (23) into the inlet cavity.
Make sure that it is pressed down completely.
NOTE: When the valve seat is properly seated, it will
be about flush with the top of the inlet cavity.
5. Replace the top “O” ring (16) in the inlet cavity.
6. Replace the inlet manifold (13) and the two bases
on the studs.
7. Replace the four nuts (4), lockwashers (3) and
flatwashers (2) that hold the outlet manifold and the
bases to the two end castings (21).
8. Tighten the nuts until firm. Do not over tighten.
OUTLET CHECK VALVES:
(Figures 3 and 6)
Disassembly:
1. Remove the four nuts (4), lockwashers (3) and
flatwashers (2) that hold the outlet manifold (13) to
the two end castings (21).
2. Remove the outlet manifold (13).
NOTE: There are two outlet cavities in the pump.
This procedure is written for one but is identical for
the other.
3. Remove the top “O” ring (16) from the outlet cavity.
4. Remove the valve cage (15) from the outlet cavity.
5. Remove the check-valve disk (14) from the valve
cage.
6. Remove the valve seat (23) from the outlet cavity.
7. Remove the bottom “O” ring (16) from the outlet
cavity.
8. Clean and inspect all parts. Replace any parts that
are worn or show any signs of disintegration due to
the corrosive effects of some of the fluids.
Reassembly:
NOTE: The reassembly procedure is written for one
outlet valve but is identical for the other.
1. Reinsert the bottom “O” ring (16) in the outlet
cavity. Make sure that it is properly seated.
2. Reinsert the valve seat (23) in the outlet cavity.
Make sure that it is pressed down completely.
3. Set the check-valve disk (14) into the center of the
valve seat (23).
4. Insert the valve cage (15) in the outlet cavity over
the check-valve disk.
page 4 page revised 6-03
SER 8301
Figure 3: Inlet & Outlet Check Valves
Outlet
Check
Valves
Inlet
Check
Valves
●Repair-Kit Part
16 ●
15
14 ● 23 16 ●
16 ●
15
14 ● 23 16 ●

13. Remove the “O” ring (6) from inside the center
hole in body B.
14. Remove the center rod (24) from body A and
remove the spacer (9) from the center rod.
15. Remove the gasket (26) from body A (25).
16. Remove the bushing (8) from body A (25) and
remove the “O” ring (7) from the bushing.
17. Remove the “O” ring (6) from inside the center
hole in body A (25).
18. Lift out the two springs (10) and the two pilot
guides (11) with the pilot valves (12) attached.
19. Remove the two screens (38) and silencer (39)
from body A (25).
20. Clean and inspect all parts. Replace the silencer
if it cannot be cleaned. If any kits are used, use all
parts in the kit. Replace any other parts that are worn
or show signs of disintegration due to the corrosive
effects of some of the fluids.
NOTE: This procedure does not include the
disassembly of the air-valve as described in the Air-
Valve Section, as these parts do not have to be
removed in order to disassemble the rest of the
pump. If the air-valve needs to be serviced, see that
section of the service sheet.
Reassembly:
1. Install the two screens (38) and the silencer (39)
into body A (25).
2. Reinsert the two springs (10) and the two pilot
guides (11) with the pilot valves (12) attached into the
holes in body A (25).
3. Replace the gasket (26) on body A (25).
NOTE: Be sure to turn the gasket so that the dimples
are facing down and are into the air-valve slots. Align
the gasket on the two metal pins on body A (25).
NOTE: Before reinstalling the two bushings each with
the two “O” rings (6 & 7), apply a little general-
purpose grease to the “O” rings.
4. Insert one “O” ring (6) into the center hole in body
A (25).
5. Insert one “O” ring (7) into one bushing (8) and
attach that bushing to the spacer (9).
NOTE: When the valve cage is properly seated, it will
be about flush with the top of the outlet cavity.
5. Replace the top “O” ring (16) in the outlet cavity.
6. Replace the outlet manifold (13) and replace the
four nuts (4), lockwashers (3) and flatwashers (2) that
hold the outlet manifold to the two end castings (21).
7. Tighten the nuts until firm. Do not over tighten.
COMPLETE PUMP:
(Figure 6)
NOTE: It is not necessary to remove the air-control
valve when completely disassembling the pump.
Disassembly:
1. Remove the outlet manifold and the outlet check-
valve assemblies as described in the disassembly
procedure in the Outlet Check Valve Section.
2. Remove the two bases, the inlet manifold and the
inlet check-valve assemblies as described in the
disassembly procedure in the Inlet Check Valves
Section.
3.Removethesixtierods(1)fromthe pumpassembly.
4. Slide off each end casting (21) from the center
body.
NOTE: Do not let the studs get bent.
5. Hold one diaphragm retaining nut (20) with a
wrench and unscrew the other one.
6. Pull the diaphragm (46) off the center rod (24).
NOTE: The center disk (22) may be stuck to the
diaphragm.
7. Pull the center disk from the diaphragm.
8. Pull the diaphragm cushion (18) from the center
rod (24).
9. Remove the “O“ ring (5) from the body.
10. Repeat steps 6 through 9 for the other side of the
pump.
11. Remove body B (27) from body A (25).
12. Remove the bushing (8) from body B (27) and
remove the “O” ring (7) from the bushing.
SER 8301
page revised 6-03 page 5

page 6 page revised 6-03
Figure 4: Components of Diaphragm Portion of Pump with Manifolds Removed
13. Place the diaphragm cushion (18) on the center
rod (24) next to body B (27).
14. Place the center disk (22) against the diaphragm
(17) and place both on the center rod (24).
15. Replace the diaphragm retaining nut (20) on the
center rod (24).
16. Repeat steps 12 through 15 for body A (25).
17. Hold one diaphragm retaining nut with a wrench
and turn the other one. Do not overtighten.
18. Insert the six tie rods (1) through one of the end
castings (21).
19. Place the body assembly on the end casting.
20. Place the other end casting on the body
assembly.
SER 8301
6. Push bushing and spacer into the center hole in
body A. Press it firmly enough to seat ther “O” rings.
7. Insert the center rod (24) through the spacer (9)
and bushing (8).
8. Insert the other “O” ring (6) into the center hole in
body B (27).
9. Insert the second “O” ring (7) into the second
bushing (8).
10. Insert this bushing into center hole in body B.
11. Place body B (27) over the center rod (24).
NOTE: Be sure to align the air slot and the hole for
the tip of the valve guide.
12. Place “O” ring (5) into the slotted circle on body B.
NOTE: Make sure that the “O” ring is properly seated.
●Repair-Kit Part
21
20 46 ●
2218 5● 25
5●
18 22 46 ●
21
4
3
2
20
27

page revised 6-03 page 7
SER 8301
7. Remove the six “O” rings from the sleeve.
8. Remove the second air-valve cushion (29).
9. Clean and inspect all parts. If any kits are used,
use all parts that are supplied in the kit. Replace any
other parts that are worn.
Reassembly:
1.Placethefirstair-valvecushion(29)intotheaircavity
with the flat side down. Make sure that it is not cocked.
2. Place the six “O” rings (44) on the sleeve (31).
3. Insert the air-valve sleeve wih the six “O” rings
into the air cavity.
NOTE: To ease the process, apply a little general-
purpose grease to the “O” rings on the sleeve.
4. Place the five seal rings (43) on the spool (32).
5. Place the second air-valve cushion (29) and the
detent assembly (33) on the end rod of the spool (32)
and screw nut on the end rod.
6. Insert this assembled unit into the air cavity.
7. Place “O” ring (35)on to the push rod.
8. Insert the push rod (36) with “O” rings (35) into the
air-valve plug (37).
9. Place “O ring (34) on the plug.
10. Replace the air-valve plug (37) into the air cavity.
Tighten with the air-valve plug tool.
Figure 5: Performance Curves for Diaphragm Pump
NOTE: The two end castings each have an arrow on
them. Make sure that the arrow points toward the fluid
outlet. The arrows will point up when the pump is
completely reassembled and sitting on its two bases.
21. Reattach the six flatwashers, the six lockwashers
and the six nuts on the six tie rods. Tighten each tie
rod by holding the nut at one end of the tie rod and
turning the other one.
22. Tighten the nuts on the six tie rods alternately in
a criss-cross pattern so that the pump goes together
properly. Do not overtighten.
NOTE: When the tie rods are tight, there will still be
small gaps between the body assembly and the two
end castings.
23. Reinstall the inlet and outlet check valves and
manifolds as described in the reassembly procedure
in the Inlet and Outlet Check Valves Sections.
AIR-VALVE:
(Figure 6)
NOTE:Toeaseinreassembly,laythebodyofthepump
on its side so that the air-valve plug is facing up.
CAUTION: The ball valve must be removed if the
pump is placed in this manner.
NOTE: Two special tools are furnished with the
pump. They are used when removing the air valve.
These are the air-valve plug tool for removal of the
air valve plug and the air-valve sleeve extraction tool
for the removal of the air-valve sleeve.
Disassembly:
1. Remove the air-valve plug (37) from the body of
the pump.
NOTE: Use the air-valve plug tool to ease the
removal of this plug.
2. Remove “O” ring (34) from this plug.
3. Remove the push rod (36) from the air-valve plug.
4. Remove “O” ring (35) from the push rod.
5. Pull out the spool assembly, consisting of the
spool (32) with the five seal rings (43), one air-valve
cushion (29) and the detent assembly (33). Remove
the five seal rings from the spool.
6. Remove the sleeve (31) with the six “O” rings (44)
by using the air-valve sleeve extraction tool.
NOTE: Curves based on fresh water at 70°F and one-
foot flooded suction.
Feet
200 100PSI
80PSI
60PSI
40PSI
20PSI
150
100
50
0
3CFM
6CFM
9CFM
02.5 5 7.5 10 12.5 15 17.5
Gallon / Min.

5 ●
18
Figure 6a: Spool and Detent Assembly
● 43 (5)
32
▼
▼▼
46 ●
20
21
●Repair Kit Part ❋Shipped Loose
25
▼▼▼▼
29 ●33 ●
▼
45 ●
22
20
27
● 16
● 14
14 ●
23
16 ●
23
15
13 4
3
2
15
16 ●
● 16
X
26
▼
37
32
●43 (5)
31
36
29 ●
38 38
39
40
41
15
● 14
23
● 16
13
● 16
23
4
42
30 ❋
4
2
34
2
3
Y
2
40
3
41
42
15
14 ●
23
16 ●
16 ●
4
X
Y
34 ●
35 ●
29 ●
33 ●
●44 (6)
432
10
12 11
10 6 ●
11
12 7 ●
8 ●
98 ●
7 ●6 ●
24 ●
46 ●
18 22
5 ●
4
3
2
1
21
page 8 page revised 6-03
SER 8301

SER 8301
page revised 6-03 page 9
SYMPTOM
Little or no flow
Pulsating flow
Unbalanced pumping
Air exhaust from discharge
Liquid returns from inlet
Pump does not stop when
discharge is closed
Abnormal sound in exhaust
POSSIBLE CAUSE(S)
1. Insufficient air supply.
2. Closed valve or clogged line.
3. Piping too small.
4. Spool valve stopped in neutral
position.
5. Damaged spool valve.
6. Clogged diaphragm chamber.
7. Relief valve not adjusted
properly.
8. Damaged diaphragm.
9. Incorrectly positioned and
plumbed.
10. Clogged muffler.
1. Some pulsating flow is normal.
2. Clogged check valve.
3. Damaged check valve disk.
4. Damaged check valve seat.
5. Air leak in suction line.
6. Clogged discharge line.
7. Clogged diaphragm chamber.
1. Damaged diaphragm.
2. Damaged check valve disk.
3. Damaged check valve seat.
4. Damaged spool and detent.
1. Damaged diaphragm.
2. Air leak in suction line.
1. Damaged check valve disk.
2. Damaged check valve seat.
3. Viscosity of liquid too high.
4. Pump speed too fast.
1. Clogged check valve.
2. Damaged check valve disk.
3. Damaged check valve seat.
4. Air leak in suction line.
Clogged diaphragm chamber.
CORRECTIVE ACTION
1. Check air supply.
2. Open valve or remove
restriction.
3. Increase piping size; should
be at least one size larger
than pump port.
4. Push Reset Button for
manual start.
5. Repair or replace valve.
6. Clean diaphragm chamber.
7. Adjust or clean.
8. Replace diaphragm.
9. Position pump with discharge
at top and suction at bottom.
Pump must be mounted
horizontally.
10. Clean or replace muffler.
1. None required.
2. Clean or replace.
3. Replace disk.
4. Replace seat.
5. Repair or replace.
6. Clean line.
7. Clean diaphragm chamber.
1. Replace diaphragm.
2. Replace disk.
3. Replace seat.
4. Replace spool and detent.
1. Replace diaphragm.
2. Repair or replace.
1. Replace disk.
2. Replace seat.
3. Reduce pump speed.
4. Reduce pump speed.
1. Clean or replace valve.
2. Replace disk.
3. Replace seat.
4. Repair or replace.
Clean diaphragm chamber.
Table 1: Trouble-Shooting Chart

SER 8301
page10 page revised 6-03
Minor Repair Kits
393630-75 Check Valves and Diaphragm Kit
Item No. Part No. Description Qty.
5 ............ 393630-5.............. “O” Ring ...............................................................................2
14 .......... 393630-14............ Check Valve Disk .................................................................4
16 .......... 393630-16............ “O” Ring ...............................................................................8
46 .......... 393630-46............ Diaphragm (Santoprene)) ....................................................2
393630-76 Center Rod Replacement Kit
Item No. Part No. Description Qty.
5 ............ 393630-5.............. “O” Ring ...............................................................................2
6 ............ 393630-6.............. “O” Ring ...............................................................................2
7 ............ 393630-7.............. “O” Ring ...............................................................................2
8 ............ 393630-8 .............. Bushing ................................................................................2
24 .......... 393630-24............ Center Rod...........................................................................1
393590 ................. Teflon Grease ......................................................................1
393630-77 Air-Valve Seal Kit
Item No. Part No. Description Qty.
29 .......... 393630-29............ Air-Valve Cushion ................................................................2
34 .......... 393630-34............ “O“ Ring (Buna N) ................................................................1
35 .......... 393630-35............ “O” Ring (Buna N) ................................................................1
43 .......... 393630-43............ Seal Ring .............................................................................5
44 .......... 393630-44............ “O” Ring ...............................................................................6
45 .......... 393630-45............ Nut .......................................................................................1
393630-78 Detent Assembly Kit
Item No. Part No. Description Qty.
33 .......... 393630-33............ Detent Assembly..................................................................1
45 .......... 393630-45............ Nut .......................................................................................1

SER 8301
PARTS LIST – Model 8301 Diaphragm Pump (Figure 6)
Item No. Part No. Description Qty.
1✚11 ................393630-1....... Tie Rod (Stainless Steel) ...........................................................6
1✚12 ................393630-2....... Washer (Stainless Steel) ......................................................... 24
1✚13 ................393630-3....... Spring Washer (Stainless Steel).............................................. 24
1✚14 ................393630-4....... Nut (Stainless Steel) ................................................................ 24
1●15 ................393630-5....... “O” Ring, 3-23/32" I.D. x 1/8" Thick (Buna N) ...........................2
1✚ ● 16 ................393630-6....... “O” Ring, 27/32" I.D. x 9/64" Thick (Buna N).............................2
1✚ ● 17 ................393630-7....... “O” Ring, 17/32" I.D. x 3/32" Thick (Buna N).............................2
1✚ ● 18 ................393630-8....... Bushing ......................................................................................2
19 ................393630-9....... Spacer........................................................................................ 1
10 ................393630-10..... Spring.........................................................................................2
✚11 ................393630-11..... Pilot Guide ................................................................................. 2
12 ................393630-12..... Pilot Valve (Buna N) ..................................................................2
13 ................393630-13..... Manifold (Polypropylene) ...........................................................2
✚ ● 14 ................393630-14 ..... Check Valve Disk ......................................................................4
15 ................393630-15..... Valve Cage (Polypropylene) ...................................................... 4
●16 ................393630-16 ..... “O” Ring, 1-5/32" I.D. x 9/64" Thick (Buna-N) ...........................8
✚18 ................393630-18..... Diaphragm Cushion ...................................................................2
✚20 ................393630-20..... Outer Disk.................................................................................. 2
21 ................393630-21..... End Casting ...............................................................................2
✚22 ................393630-22..... Inner Disk ..................................................................................2
23 ................393630-23..... Valve Seat (Polypropylene) .......................................................4
✚ ● 24 ................393630-24 ..... Center Rod (Stainless Steel) .....................................................1
✚25 ................393630-25..... Body A .......................................................................................1
26 ................393630-26..... Gasket (TPFE)...........................................................................1
✚27 ................393630-27..... Body B .......................................................................................1
✚ ● 29 ................393630-29 ..... Air-Valve Cushion ......................................................................2
30 ................393630-30..... Ball Valve ...................................................................................1
✚31 ................393630-31..... Air-Valve Sleeve ........................................................................1
✚32 ................393630-32..... Spool ..........................................................................................1
✚ ● 33 ................393630-33 ..... Detent Assembly........................................................................1
✚ ● 34 ................393630-34 ..... “O” Ring, 31/32" I.D. x 9/64" Thick (Buna N).............................1
✚ ● 35 ................393630-35 ..... “O” Ring, 3/16" I.D. x 1/16" Thick (Buna N)............................... 1
✚36 ................393630-36..... Reset Button ..............................................................................1
✚37 ................393630-37..... Air-Valve Plug ............................................................................1
38 ................393630-38..... Screen........................................................................................2
✚39 ................393630-39..... Silencer ......................................................................................1
40 ................393630-40..... Base (Polypropylene) ................................................................2
41 ................393630-41..... Rubber Foot ...............................................................................4
✚42 ................393630-42..... Bolt.............................................................................................4
●43 ................393630-43 ..... Seal Ring....................................................................................5
✚ ● 44 ................393630-44 ..... “O” Ring, 25/32" I.D. x 1/16" Thick (Buna N).............................6
✚ ● 45 ................393630-45 ..... Nut .............................................................................................1
✚ ● 46 ................393630-46 ..... Diaphragm (Santoprene)............................................................2
●Repair-Kit Part
✚Not available as a separate purchased part
NOTE: The parts listed in this instruction sheet are for reference identification in the instructions and
illustrations. Some of them are not available as separate parts and these are noted in the parts list.
Refer to the current parts price list and bulletins before ordering parts, and always give the part
number, quantity, description and model where used when ordering parts. Parts availability and prices
are subject to change without notice.
PARTS CHANGES SINCE LAST PRINTING
Deleted Air Coupler
page revised 6-03 page11
