Alemite 8595-C User manual

Service and installation manual
Fluid evacuation system
Model -C
Date of issue January 2024
Form number 671044
Version 2

Safety *. . . . . . . . . . . . . . . . . . . . . . . . . . 5
Description. . . . . . . . . . . . . . . . . . . . . . . 6
Optional kits . . . . . . . . . . . . . . . . . . . . . . 
Installation and maintenance . . . . . . . 7
Installation . . . . . . . . . . . . . . . . . . . . . . . 
Maintenance . . . . . . . . . . . . . . . . . . . . . . 
Service parts . . . . . . . . . . . . . . . . . . . . . 8
Contents
*Indicates change.


WARNING
Do not operate equipment
without reading and fully
understanding safety warn-
ings and instructions.
Failure to follow warnings and
instructions may result in serious injury.
NOTE
Do not operate equipment without
wearing personal protective gear.
Wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing pro-
tection used for appropriate conditions
will reduce personal injuries.
WARNING
Do not allow fluid to leak
onto floor when operating
equipment. If spill occurs,
clean any fluid on floor before continuing
operation.
Failure to comply may result in death
or serious personal injury.
Safety *
Read and carefully observe these installation
instructions before installing/operating/
troubleshooting. Pump must be installed,
maintained and repaired exclusively by
persons familiar with these instructions.
Always disconnect power source (electric,
air or hydraulic) from equipment when not
being used.
This equipment generates high pressure.
Extreme caution should be used when
operating this equipment as material leaks
from loose or ruptured components can
inject fluid through skin and into body. If any
fluid appears to penetrate skin, seek
attention from a doctor immediately. Do not
treat injury as a simple cut. Tell attending
doctor exactly what type of fluid was injected.
Any other use not in accordance with
instructions will result in loss of claim for
warranty or liability.
• Do not misuse, over-pressurize, modify
parts, use incompatible chemicals, fluids,
or use worn and/or damaged parts.
• Do not exceed stated maximum
working pressure of equipment or of
lowest rated component in your system.
• Always read and follow manufacturer’s
recommendations regarding fluid
compatibility, and use of protective
clothing and equipment.
• Failure to comply may result in personal
injury and/or damage to equipment.
Explanation of signal
words for safety
NOTE
Emphasizes useful hints and recom-
mendations as well as information to
prevent property damage and ensure
efficient trouble-free operation.
CAUTION
Indicates a dangerous situation that can
lead to light personal injury if precau-
tionary measures are ignored.
WARNING
Indicates a dangerous situation that
could lead to death or serious injury if
precautionary measures are ignored.
DANGER
Indicates a dangerous situation that will
lead to death or serious injury if precau-
tionary measures are ignored.
*Indicates change.


Model -C fluid evacuation system
provides a clean, safe way to evacuate
waste fluids.
System features a corrosion resistant
aluminum double diaphragm pump that
creates a powerful suction to evacuate waste
fluids and transfer them through an
enclosed system to a remote storage tank.
Model -C includes a pump for
transferring non-flammable fluids such
as used motor oil, coolant or
windshield cleaner.
System can evacuate used fluids from
rolling drain pans, portable oil drain
containers and differentials and transaxles.
Pump is air operated and can be mounted
on any convenient wall surface.
Additional hardware can be used to serve
multiple service stations.
Optional kits
Pump wall bracket kit  facilitates
mounting of diaphragm pump to wall or to
pole. Wall bracket is designed with hooks for
hanging suction hose when not in use.
Pump wall bracket is pre-drilled to facilitate
installation of  filter/regulator on its
side using  FRL wall bracket kit
included with diaphragm pump
evacuation kit. († Fig. IPB 1, page 6).
Description


WARNING
Do not exceed lowest pressure rating of
any component in system.
Failure to comply may result in
serious injury or death.
WARNING
Do not operate pump with broken,
missing or defective parts. Replace
defective parts prior to operation.
Failure to comply may result in
serious injury or death.
WARNING
Do not operate with leakage in system.
Disconnect air to motor.
Failure to comply may results in
serious injury.
Installation
Depending on type of fluid to be evacuated,
fluid evacuation system installation and use
must be in accordance with flammable and
combustible liquids code (NFPA ) and
automotive and marine service station code
(NFPA A) and must comply with all local
state and federal codes.
Also, the United States Government safety
standards have been adopted under the
Occupational Safety and Health Act. These
standards should be consulted, particularly
the General Standards, Part , and the
Construction Standard, Part .
Maintenance
DANGER
Do not operate or service machine prior
to ensuring it has been properly
grounded. System must be grounded to
reduce risk of static electrical parking.
Refer to local, state and federal electrical
codes for detailed grounding
instructions.
Failure to comply will result in death
or serious personal injury.
Installation and maintenance
WARNING
• Make sure pump and equipment used
or located in pumping area are
grounded.
• Do not use system if any static
sparking or electrical shock occurs.
Stop evacuation immediately and do
not use system until problem is
corrected.
• Do not alter or modify any part of this
equipment.
• Do not attempt to repair or
disassemble equipment while system
is operating.
• Make sure all connections are
securely tightened before using
equipment.
• Check all equipment regularly and
repair or replace worn or damaged
parts immediately.
• Never place your hand on or near
pump suction inlet.
Failure to comply may result in
personal injury and/or damage to
equipment.


1
1
2 3
4
4
5
5
6
7
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
Fig. IPB 1
Service parts


Service parts
Item Description Quantity Part
1Air line hose 2 –
2 Full port ball valve, 1/4in NPT 1 –
3 Nipple, 1/4in × 1/4in NPTF 1 327033
4 Filter/regulator, 1/4in 1 7504-1 *
5 Elbow, 1/4in × 1/4in NPTF 2 –
6 Union adapter 1 1000-44
7 Ball valve, 3/4in NPTF 2 338564 1) 2)
8Check valve, 3/4in 1 343274 1)
9Delivery hose 1 –
10 Adapter, 1/2in ID × 3/4in OD 1 –
11 Diaphragm pump, 1/2in 1 8322-A
12 Nipple, 1/2in NPT ×  in 1 –
13 Bushing,  in × 1/2in NPTF 1 320354
14 T-Strainer 1 –
15 Elbow, 3/4ID ×  OD NPTF 1 –
16 Hose, Suction 1 –
17 Elbow, 3/4in OD × 3/4in OD NPTF 1 –
18 Camlock coupler 1 –
19 Camlock connector 1 343261 1)
20 Camlock connector 1 343262 1)
21 Wall bracket kit (pump) 1 343283 1) 3)
22 Wall bracket kit (FRL) 1 – 3)
Not all parts are available separately.
) Designates kit items that are optional and must be purchased separately
) One valve optional
) Available as a individual kits
*Indicates change.


23
24
25
25
26
27
28 29
Fig. IPB 2
Wall bracket kit (pump) (21)
Fig. IPB 3
Wall bracket kit (FRL) (22)
Service parts
Item Description Quantity
23 Wall mount bracket 1
24 Hex head cap screw, 5/16 in - 4
25 Flat washer, 5/16 in 8
 Elastic stop nut, 5/16 in - 
 Bracket 
 Hex nut with exterior lock washer, - 
 Pan head screw, - × 3/8in 
Parts not available separately.


This page left intentionally blank.


alemite.com
® Alemite, LLC is a registered trademark.
The contents of this publication are the copyright of the publisher and may not be reproduced (even
extracts) unless prior written permission is granted. Every care has been taken to ensure the accuracy
of the information contained in this publication but no liability can be accepted for any loss or damage
whether direct, indirect or consequential arising out of the use of the information contained herein.
January  · Form 71044 Version 2
