Alemite 7149-4 Series Operating instructions

SERVICE INSTRUCTIONS 7149-4 Series
Model 7149-4 Series Hand Operated Bucket Pumps
Alemite, LLC
167 Roweland Drive, Johnson City Tennessee 37601
www.alemite.com
Copyright © 2006 by Alemite, LLC
This document contains confidential information that is the property of Alemite, LLC
and is not to be copied, used, or disclosed to others without express written permission.
396534 SER 7149-4
Revision (8/06)
The 7149-4 series of Alemite Bucket Pumps are designed to deliver lubricant to bearings of off-the-road
equipment with various types of grease fittings.
These pumps develop from 2500 to 5000 psi, delivering about 1/3 ounce per stroke with the lever
attached to the pump in the normal center position. The lubricant container has a capacity of 35 pounds.
See the chart below for the various models in the 7149-4 series, which are covered by the instruction
sheet.
Figure 1: Model 7149-A4 Bucket Pump
MODEL CHART
MODEL PAGE COMPONENTS IN ADDITION TO 7149-4 BUCKET PUMP
7149-A4 2-3 322434 Hose Assembly (Figure 4)
7149-C4 4 6617-G Hydraulic Coupler and Hose Assembly (Figure 5)
7149-D4 4 317854-5F Hose (Figure 6)
43706 Angle Body
A-112 Bushing (Figures 3, 6, and 12)
A-336 Pin-Type Fitting
50491 Coupler
171134 Plug Button

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 2 Revision (8/06)
7149-E4 4 6616-G Hose and Coupler Assembly (Figure 7)
A-1188 Button Head Fitting
171134 Plug Button
7149-F4 5 6615-G Hose and Coupler Assembly (Figure 8)
171134 Plug Button
322108 Button Head Fitting
7149-H4 5 322434 Hose Assembly (Figures 4, 9)
322630 Loader Kit
7149-A4P 6 322439 Hose Assembly
7149-4P (Figure10)
Figure 2: Components of Model 7149-A4 Bucket Pump

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 3 Revision (8/06)
ASSEMBLY
To assemble the basic Bucket Pump Model 7149-4, proceed as follows (see Figure 2):
1. Attach link 322092-7 to pump body 322115-6 (see Figure 12) with pin 322109-2 and secure
with cotter pin 172212-14.
2. Attach lever 322418-2 to link with pin and secure with cotter pin.
3. Attach lever to pump plunger with stud 322428 and wing nuts 79882 through one of the three
holes provided (see adjustment instructions on page 7).
4. See further instructions for specific model.
Figure 3: Model 7149-4 Bucket Pump
Figure 4: Model 322434 Hose Assembly (for Models 7149-A4 and 7149-H4)
MODEL 7149-A4 (Figures 3 and 4):
Thread hose assembly 322434 into check valve 317210 and tighten.

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 4 Revision (8/06)
Figure 5: Model 6617-G Hydraulic Coupler and Hose Assembly (for Model 7149-C4)
MODEL 7149-C4 (Figure 5):
Thread hydraulic coupler and hose assembly 6617-G into check valve 317210 and tighten.
Figure 6: Hose and Coupling Assembly (for Model 7149-D4)
MODEL 7149-D4 (Figures 3 and 6):
1. Unthread the 1/8” NPT hydraulic fitting 311199 from bushing A-112 (Figure 3).
Thread angle body 43706 into bushing and pin type fitting A-336 into angle body.
2. Remove hose clip 322576, screw 170343, lock washer 172207-1 and nut 77650 from
container and replace with plug button 171134.
3. Assemble hose 317854-5F, bushing A-112 and coupling assembly 50491 (Figure 6).
Screw hose and coupling assembly into check valve 317210 and tighten.
Figure 7: Model 6616-G Hose and Coupling Assembly (for Model 7149-E4)
MODEL 7149-E4 (Figure 7):
1. Remove hose clip 322576, screw 170343, lockwasher 172207-1 and nut 76650 from
container and replace with plug button 171134.
2. Unthread bushing A-112 with hydraulic fitting 311199 from container and replace with
button head fitting body A-1188.
3. Thread hose and coupler assembly 6616-G into check valve 317210 and tighten.

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 5 Revision (8/06)
Figure 8: Model 6615-G Hose and Giant Coupler Assembly (for Model 7149-F4)
MODEL 7149-F4 (Figures 3 and 8):
1. Unthread the bushing A-112 and hydraulic fitting 311199 from container and replace with
button head fitting plug 322108.
2. Remove hose clip 322576, screw 170343, lock washer 172207-1 and nut 77650 from
container and replace with plug button 171134.
3. Thread hose and coupler assembly 6615-G into check valve 317210.
Figure 9: Model 7149-H4 Bucket Pump
MODEL 7149-H4 (Figures 4 and 9):
1. Thread loader adapter 322989 into check valve 317210.
2. Thread loader valve 306741 into loader adapter.
3. Thread hose assembly 322434 into loader adapter.

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 6 Revision (8/06)
Figure 10: Model 7149-A4P
PARTS LIST - Model 7149-A4P Bucket Pump (Figure 10):
Part No. Description Quantity
7149-4P Bucket Pump Assembly 1
308730-A Hydraulic Coupler 1
317853-5 Hose 1
322434 Hose Assembly 1
Figure 11: Lever Positions

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 7 Revision (8/06)
OPERATION
TO FILL CONTAINER:
1. Raise lever and wipe off tip of container.
2. Loosen knurled thumb screws and slide cover to one side.
3. Fill container with lubricant, being careful that no air pockets are formed.
TO USE:
1. Check condition of hose and check to see that all connections are secure.
2. ADJUSTMENT INSTRUCTIONS:
Set lever at appropriate position (Figure 11)
a. for lightweight lubricants and warm temperatures.
b. for lubricants of medium thickness.
c. for cold weather and/or thick lubricants.
(To change positions, remove wing nut 79882 and slide pin 322423, with the wing
nut still attached, into alternate hole.)
2. Wipe fitting and coupler and place coupler on fitting.
3. Pump lubricant into bearing. Remove coupler.
4. Wrap hose around bucket and attach coupler to fitting on top of container. On most
models, this fitting serves as a pressure release and allows excess lubricant to run
back into the container.
IF PUMP FAILS TO BUILD UP PRESSURE OR DELIVER LUBRICANT:
1. Check if lubricant level is low or if air pockets have developed, allowing air to enter
pump.
2. Check hose and connection for leaks.
3. If pressure still fails to build up, overhaul pump with Major Repair Kit 398724 or
replace.

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 8 Revision (8/06)
Figure 12: Components of Bucket and Pump Assembly for Series 7149-4 Bucket Pumps

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 9 Revision (8/06)
SERVICE
DISASSEMBLY (Figures 2 and 12):
1. Remove wing nut 79882 from stud 322423 and remove stud from lever 322418-2 and
plunger 337417-1.
2. Remove cotter pins 172212-14 and pins 322109-2 from lever and link 322092-7, allowing
lever and link to be removed.
3. Unscrew knobs 322425 and remove cover 322110-6.
4. If gasket 50784 is to be replaced, pull off gasket and scrape mating surface of container
322100-6 clean. When reassembling, gasket should be cemented to container with suitable
gasket cement.
5. Remove check valve 317210 from pump body 322115-6.
6. Unscrew four hex head cap screws 77786 and remove pump assembly from container.
7. Remove nut 6316, lockwasher 77010 and cup 322098 from Rod 337418.
8. Unscrew pump tube 322105 from pump body and remove aluminum gasket 316277, stop
tube 322113, washer 322112, valve 322103 and sleeve 322102 from rod. Note that the end
of stop tube with four holes goes nearest the pump body.
9. Pull plunger and rod up from pump body and remove rubber quad ring 171008-15 from
groove in bore of pump body. Handle carefully to avoid scratches or nicks on plunger or
bore of pump body.
REASSEMBLY:
To reassemble, reverse the above procedure while being certain that plunger, quad ring, valve
and sleeve are well lubricated with light grease, and that the valve and quad ring are not damaged
during installation.
Figure 13: Model 42030 Standard Button-Head Coupler

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 10 Revision (8/06)
Figure 14: Model 51219 Hose Swivel
Figure 15: Model 304300 Giant Button-Head Coupler
Major Repair Kit
398724 For 7149-4 Series Bucket Pumps
Part No. Description Quantity
171008-15............................................................Quad Ring, 3/4” I.D. x O.D...............................................................2
172212-14............................................................Cotter pin, 3/32” x 5/8” long............................................................3
316227.................................................................Aluminum Gasket, 1-1/16” O.D........................................................1
322102.................................................................Sleeve................................................................................................1
322103.................................................................Valve..................................................................................................1
6316......................................................................Nut, Hex, 5/16” - 24..........................................................................1
Minor Repair Kits
398726 For 304300 Giant Button-Head Coupler (Figures 8, 15)
Part No. Description Quantity
48928....................................................................Rubber Seal, 11/16” O.D..............................................................10
48929....................................................................Flat Washer, 11/16” O.D...............................................................10
48930....................................................................Cone Washer,, 11/16” O.D...........................................................10

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 11 Revision (8/06)
398727 For 42030 Standard Button-Head Coupler (Figure 7, 13)
Part No. Description Quantity
301080....................................................................Rubber Seal, 9/16” O.D..............................................................10
301081....................................................................Flat Washer, 9/16” O.D...............................................................10
PARTS LIST - Model 7149-A4 Bucket Pump (Figure 4)
Part No. Description Quantity
7149-4*......................................................................Bucket Pump Assembly............................................................1
308730-A#................................................................Hydraulic Coupler.......................................................................1
317853-5#.................................................................Hose.............................................................................................1
322434......................................................................Hose Assembly (Figure 4)..........................................................1
*See separate parts list
#Included in Hose Assembly 322434
PARTS LIST - Model 7149-C4 Bucket Pump (Figure 5)
Part No. Description Quantity
6304-C#......................................................................Hydraulic Coupler......................................................................1
6617-G........................................................................Hose and Coupler Assembly (Figure 5)..................................1
7149-4*.......................................................................Bucket Pump Assembly............................................................1
52940#.......................................................................Adapter........................................................................................1
317854-5F#................................................................Hose............................................................................................1
*See separate parts list
#Included in Hose Assembly 6617-G
PARTS LIST - Model 7149-D4 Bucket Pump (Figure 6)
Part No. Description Quantity
A-112..........................................................................Bushing (Figure 3).....................................................................1
A-336..........................................................................Pin-Type Fitting..........................................................................1
7149-4*.......................................................................Bucket Pump Assembly............................................................1
43706.........................................................................Angle Body..................................................................................1
50491.........................................................................Coupler........................................................................................1
171134....................................................................... Plug Button................................................................................1
317854-5F..................................................................Hose............................................................................................1
*See separate parts list
PARTS LIST - Model 7149-E4 Bucket Pump (Figure 7)
Part No. Description Quantity
A-1188.........................................................................Button-Head Fitting..................................................................1
6616-G.........................................................................Hose and Coupler Assembly (Figure 7).................................1
7149-4*........................................................................Bucket Pump Assembly...........................................................1
42030+.........................................................................Button-Head Coupler (Figure 13)............................................1
46405+.........................................................................Check Valve..............................................................................1
51219*+....................................................................... Hose Swivel (Figure 14)...........................................................1
171134............................................................ ............Plug Button...............................................................................1
301080#^................................................................... Rubber Seal, 9/16” O.D............................................................1
301081#^............................................................. ..... .Flat Washer, 9/16” O.D.............................................................1
317854-5F+.......................................................... .......Hose..........................................................................................1
#Repair Kit Part
*See separate parts list
+Included in Hose and Coupler Assembly 6616-G
^Included in Button-Head Coupler 42030

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 12 Revision (8/06)
PARTS LIST - Model 7149-F4 Bucket Pump (Figure 8)
Part No. Description Quantity
6615-G......................................................................Hose and Coupler Assembly (Figure 8)....................................1
7149-4*.....................................................................Bucket Pump Assembly..............................................................1
46405+.....................................................................Check Valve..................................................................................1
48928#^...................................................................Rubber Seal, 11/16” O.D..............................................................1
48929#^...................................................................Flat Washer, 11/16” O.D...............................................................1
48930#^...................................................................Cone Washer, 11/16” O.D............................................................1
51219*+................................................................... Hose Swivel (Figure 14)..…………………………………………...1
171134......................................................................Plug Button..................................................................................1
304300+...................................................................Giant Button-Head Coupler (Figure 15).…………..……………..1
317854-5F+..............................................................Hose..............................................................................................1
322108......................................................................Button-Head Fitting Plug............................................................1
.
#Repair Kit Part
*See separate parts list
+Included in Hose and Coupler Assembly 6615-G
^Included in Giant Button-Head Coupler 304300 (Figure 15)
PARTS LIST - Model 7149-H4 Bucket Pump (Figure 9)
Part No. Description Quantity
7149-4*.....................................................................Bucket Pump Assembly..............................................................1
306741+...................................................................Loader Valve.................................................................................1
308730-A#...............................................................Rubber Seal, 11/16” O.D...............................................................1
317853-5#................................................................Hose...............................................................................................1
322434.....................................................................Hose Assembly (Figure 4)...........................................................1
322630.....................................................................Loader Kit......................................................................................1
322989+^.................................................................Loader Adapter.............................................................................1
*See separate parts list
#Included in Hose and Coupler Assembly 322434
+Included in Loader Kit 322630
^Not available as a separately purchased part
PARTS LIST - Model 7149-4 Bucket Pump Assembly (Figure 12)
Part No. Description Quantity
A-112.......................................................................Bushing.........................................................................................1
50784.......................................................................Large Oval Cork Gasket..............................................................1
77650.......................................................................Hex Nut, 1/4-20.............................................................................1
170343^...................................................................Screw,1/4-20 x 7/16” long...........................................................1
170705......................................................................Retaining Ring.............................................................................2
172207-1^................................................................Lock Washer, 1/4” I.D..................................................................1
311199^...................................................................Hydraulic Fitting...........................................................................1
322100-6..................................................................Shell Assembly.............................................................................1
322110-6..................................................................Cover Assembly...........................................................................1
322425..................................................................... Knob.............................................................................................2
322576..................................................................... Spring Clip...................................................................................1
377340-A1*.............................................................. Pump-Tube Assembly.................................................................1
#^..............................................................................Lever and Link Assembly (Figure 2)…......................................1
*See separate parts list
^Not available as a separately purchased part

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 13 Revision (8/06)
PARTS LIST - Model 337340-A1 Pump-Tube Assembly (Figure 12)
Part No. Description Quantity
6316^........................................................................Hex Nut, 5/16-24...........................................................................1
77010^......................................................................Internal-Tooth Lock Washer, 5/16”............................................1
77786.......................................................................Hex-Head Cap Screw, 1/4-20 x 1/2” long....................................4
171008-15~..............................................................Quad Ring, 3/4” I.D. x 1” O.D......................................................1
316277~...................................................................Aluminum Gasket, 1-1/16” O.D...................................................1
317210......................................................................Check Valve.................................................................................1
322098.....................................................................Cup.................................................................................................1
322102~...................................................................Sleeve............................................................................................1
322103~...................................................................Valve..............................................................................................1
322105.....................................................................Tube Assembly.............................................................................1
322112.....................................................................Three-Point Star Washer, 11/32” I.D...........................................1
322113.....................................................................Tube...............................................................................................1
322115-6................................................................. Pump Body...................................................................................1
337507.....................................................................Rod Assembly..............................................................................1
~Repair Kit Part
^Not available as a separately purchased part
PARTS LIST - Lever and Link Assembly (Figures 2 and 11)
Part No. Description Quantity
79882........................................................................Wing Nut, 5/16-18........................................................................2
172212-14~..............................................................Cotter Pin, 3/32” x 5/8” long.......................................................2
322092-7...................................................................Link...............................................................................................1
322109-2~.................................................................Pin, 1-9/16” long..........................................................................2
322418-2...................................................................Lever.............................................................................................1
322423......................................................................Stud, 1-19/32” long......................................................................1
~Repair Kit Part
PARTS LIST - Model 51219 Hose Swivel (Figure 14)
Part No. Description Quantity
40901^......................................................................Spring...........................................................................................1
40902^......................................................................Retaining Washer........................................................................1
40903^......................................................................Leather Cup..................................................................................1
40904^......................................................................Swivel Nut....................................................................................1
40905^......................................................................Swivel Stud..................................................................................1
51218^......................................................................Adapter.........................................................................................1
^Not available as a separately purchased part
NOTE: The parts listed in this instruction sheet are for reference identification in the
instructions and illustrations. Some of them are not available as separate parts, and these are
noted in the parts list. Standard items such as nuts, bolts, etc. should be purchased at a hardware
store. Refer to the current parts price list and bulletins before ordering parts, and always give the
part number, quantity, description, and model where used when ordering parts. Parts availability
and prices are subject to change without notice.

SER 7149-4 Hand Operated Bucket Pump
Alemite, LLC 14 Revision (8/06)
