Reference Manual

1
WARNING
Use of the CD Twin LE is for the legal backup of licensed materials and
editing of personal data. Any copy of licensed materials is the property of
the author of the copyright holder. Any unauthorized copying, editing, or
resale of copyrighted materials is prohibited by US and International laws.
We discourage owners of the CD Twin LE from using this product in any
illegal way.

2
1. INTRODUCTION..............................................4
1.1 PRODUCT OVERVIEW .............................4
1.1.1 Front View..................................................4
1.1.2 Side View....................................................5
1.1.3 Rear View...................................................5
2. OPERATING GUIDE........................................6
2.1 CD TO CD BACKUP.....................................6
2.2 COPY TRACK (MAKE A COMPILATION CD)......6
2.3 CLOSE DISC.................................................8
3. SYSTEM FUNCTIONS.....................................9
3.1 ERASEDISC (CD-RWONLY).....................9
3.2 RAWCOPY DISC.........................................9
3.3 UPGRADE BIOS ........................................10
3.4 SYSTEM INFORMATION........................11
4. SPECIFICATIONS..........................................12
5. TROUBLESHOOTING AND FAQ................13

3
Unpacking
•CD Backup System
•Accessories
9AC Power Supply
9User Manual
Features
•CD to CD copy in one easy step
•Takes only 4 minutes to backup an entire 74 minute CD
•LCD panel allows you to see all functions and copying status
•Stand alone operation, no need to connect to your PC to
perform a CD backup
•Special track editing function allows you to make a compilation
of your personal audio CDs

4
1. INTRODUCTION
The CD Twin LE is a stylish, new concept for CD backup. With it’s
light-weight design, the CD Twin LE provides not only CD backup, but
also doubles as an audio CD track editing console for making a personal
CD. The stylish design makes the elegant CD Twin LE no longer a
boring copy tower. Its portability makes it a great tool for any setting.
1.2 PRODUCT OVERVIEW
1.2.1 Front View

5
1.2.2 Side View 1.2.3 Rear View

6
2. OPERATING GUIDE
2.1 CD to CD BACKUP
I. Power up the CD Twin LE and wait for the system to initialize
II. Insert the source disc into the reader CD-ROM [labeled as Reader],
and insert a blank disc into the writer CD-RW [labeled Writer]
III. Press the START button to begin the CD backup process.
IV. The LCD will display the total disc length and the time elapsed while
the CD Twin is in process.
V. The CD-RW will automatically eject when the CD Twin LE has
successfully completed.
VI. If you would like to make additional copies of the same disc, simply
insert another blank CD-RW into the Writer and press START again.
Pressing the CANCEL button will take you back to the Main Menu.
CD Twin
1. Copy Disc
Write [73:51]
Data CD 00:52
Waiting ...
Blank Disc

7
2.2 COPY TRACK (Make a Compilation CD)
This function allows you to make a compilation audio CD from a single
CD, or multiple source CDs.
I. Insert the source audio CD into the Reader CD-ROM drive and insert
a blank disc into the Writer CD-RW drive.
II. From the main menu, press the << or >> buttons until
[2. Copy Track] is displayed on the LCD and press the START button.
III. Move the cursor under the track that you want to add to the
compilation CD by using the << or >> buttons. After selecting the
track, a letter will be displayed above the track number to denote that this
specific track has been chosen. If you have speakers or headphones
connected to the earphone jack, you will hear the audio of the selected
track. If you would like to cancel a selected track, press the START
button again while the cursor is underneath the track number.
NOTE: If you press the CANCEL button, you will exit [track
selection mode] and return to the main menu.
NOTE: The letters above each selected track represent the order in
which they will be burned onto the compilation CD.
IV. After you are finished selecting all of the tracks for your new
compilation CD, press the >> button until the cursor is under the [OK]
option, all the way to the right. Then simply press the START button and
the CD Twin LE will copy the selected tracks one by one.
CD Twin
2. Co
py
Track
e f a i b
1 2 3 4 5 6 7 8
f a c
13 14 15 16
O
KTrack 11 06:59
[
14.10
]
04:43

8
V. After copying all of the tracks from the first CD, the Reader CD-
ROM drive will automatically eject. Insert the next audio CD, repeating
steps 1 through 4, if you would like to add additional tracks to your
compilation.
NOTE: After you have finished all of the track editing, you must
use the [3. Close Disc] function to make your new CD playable on
any standard CD player.
2.3 CLOSE DISC
I. From the main menu, press the << or >> buttons until
[3. Close Disc] is displayed on the LCD and press the START button.
Make sure that your newly burned disc is still in the Writer CD-RW drive.
II. The LCD will show the total number of tracks and the available free
space remaining on the CD-RW disc. Press the START button to begin
the closing process. Pressing the CANCEL button will abort the close
disc function.
III. The LCD will display the following message during the disc closing
process.
IV. Once the closing disc process has finished, the LCD will return to the
main menu and you may then continue with any other function of the CD
Twin LE. ATTENTION!!
After executing the [Close Disc] function, you CAN NOT add any more
tracks to the disc or change the CD in any way!!!
CD Twin
2. Co
py
Track
CD Twin
3. Close Disc
Track 07 26:15
Free 48:29 Go?
Closing Disc...
00:20

9
3. SYSTEM FUNCTIONS
3.1 ERASE DISC (CD-RW ONLY)
The [Erase Disc] function may only be used to erase a CD-RW disc that is
installed in the Writer drive location.
I. Select [4. System] from the main menu and press START.
II. Insert the CD-RW disc that you would like to erase into the Writer
CD-RW drive.
III. Select [4.1 Erase Disc] and press START.
IV. The LCD will show the following during the [Erase Disc] procedure.
V. Once the [Erase Disc] function has completed, either insert
another disc to be erased or press the CANCEL button to return
to the main menu.
3.2 RAWCOPY DISC
Select this function if you want to copy an entire disc in one easy
step. The [RAWCOPY DISC] function will make a mirror
image of the source disc.
When the RAW reading mode is enabled, all tracks will be read
with a block length of 2352. If this option is not selected, then
all Mode1 and Mode2 data tracks will be read with a block
length of 2048 and 2336 respectively.
NOTE: This option has no effect on audio or CD+G tracks.
Just insert the source disc into the Reader drive and insert a
blank disc into the Writer drive, select [RAWCOPY DISC] and
press START.
4. System
4.1 Erase Disc
Erasing ...
00:06

10
3.3 UPGRADE BIOS
From time to time, Alesis will upgrade the CD Twin LE’s BIOS.
You can obtain the latest version from the Alesis website at
www.alesis.com.
I. Select [4. System] and press START.
II. Select the function [4.3 Upgrade BIOS] and press START.
III. Select the drive that you would like to upgrade the BIOS for
and press START.
IV. Insert the BIOS source disc into the selected drive when requested by
the LCD.
NOTE: The LCD will show an error message if the incorrect disc
is inserted into the drive.
V. The CD Twin LE will auto-detect the latest BIOS version
and then perform the upgrade.
!!! WARNING !!!
Do NOT turn the CD Twin LE off when the BIOS Upgrade is in
process!! You will not be able to get the unit to boot-up again if
the power is interrupted during this process.
4.3 Upgrade BIOS
4.3.1 S
y
stemBIOS
4.3 Upgrade BIOS
4.3.2 ReaderBIOS
4.3 Upgrade BIOS
4.3.2 WriterBIOS
*Wrong Disc*Put
in BIOS Disc

11
3.4 SYSTEM INFORMATION
This function will provide you with all of the related information
about your CD Twin LE. [Product serial number, Model name,
Firmware version, CD-R and CD-RW drive manufacturers and
their respective firmware versions.
Select function [4.4 Machine Info] and press START. You can
scroll through the pages with the << and >> buttons.
Please have this information handy if contacting Alesis customer
service.
4. System
4.4 Machine Info
5006120021
CD Twin v1.12
[Reader]
EPO CD-ROM 3.31G
[Writer]
EPO CD-RW TB6D

12
4. SPECIFICATIONS
Supported Disc Formats All audio CDs, Data CD, VCD,
CD-1, Photo-CD
Blank Disc Type CD-R, CD-RW
CD Twin Burning Speed (CD-R/CD-RW)
Copy Disc 24x (fixed)
Copy Track 16x (fixed)
Rawcopy Disc 4x (fixed)
Copy Function CD to CD, Personal audio CD
editing
Power Supply 100V~240V, 50/60Hz, AC input
Front Control Panel 2x16 LCD display, 4 control keys
(START, CANCEL, <<, >>)
Weight 3.88 lbs, 1760 g
Dimensions 11.26” x 8.90” x 2.44”
286mm x 226mm x 62mm

13
5. Troubleshooting and FAQ
Q: How long does it take to copy a CD?
A: it takes around 4 minutes to copy a 74 minute source disc
Q: Why does the LCD show an error message when you put a CD-R disc
into the CD-RW and execute [Erase Disc] function?
A: CD-R disc is not erasable. Please change it to a CD-RW disc.
Q: When executing [Copy track], the LCD shows error message of:
A: This means you have selected too many tracks (more than
the available space on the blank disc). You will need to remove
some tracks from your edited list or put in a new CD-R or CD-
RW disc.
Q: How can I get a BIOS update?
A: See chapter 3.3 UPGRADE BIOS
Q: Can I change the CD-ROM or CD-RW?
A: No. There are no user serviceable parts inside.
Q: Why won’t my unit turn on?
A: Make sure you are using the power supply that came with
your unit. Other power supplies will likely not work.
Waiting ...
[36:57]>[31:18]

14
Alesis Contact Information
Alesis, LLC
E-mail: [e-mail]
Website: http://www.alesis.com
Alesis CD Twin LE Reference Manual
Copyright 2006, Alesis, LLC. All rights reserved
Reproduction in whole or in part is prohibited. CD Twin LE is a trademark of
Alesis, LLC. Specifications subject to change without notice.
8/4/2006 Rev B
