Confidential Alesis Service Manual
Alesis
Elevate 4
[LAUH]
Service Manual
v1.0
2017-12-06
The information in this document contains privileged and confidential information. It is intended
only for the use of those authorized by Alesis. If you are not the authorized, intended recipient,
you are hereby notified that any review, dissemination, distribution or duplication of this
document is strictly prohibited. If you are not authorized, please contact Alesis and destroy all
copies of this document. You may contact Alesis at [email protected].
© Copyright Alesis
ATTENTION!
This document contains sensitive proprietary information.
All recipients must have a current non-disclosure agreement on
file with Alesis.
Do not make illegal copies of this document.

Confidential Alesis Service Manual
Preface
This document is intended to assist the service technician in the operation, maintenance and
repair of the Alesis device. Together with the User Reference Manual, this document provides a
complete description of the functionality and serviceability of the Device. Any comments or
suggestions you may have pertaining to the document are welcome and encouraged.
Read This!
In addition to any purchase price that Alesis may charge as consideration for Alesis selling or
otherwise transferring this service manual (“Manual”) to you, if you are not a service and repair
facility (“Service Center”) authorized by Alesis in writing to be an authorized Service Center,
Alesis sells or transfers the Manual to you on the following terms and conditions:
Only Service Centers authorized by Alesis in writing are authorized to perform service and
repairs covered by an Alesis warranty (if any), and transfer of the Manual to you does not
authorize you to be an authorized Service Center. Therefore, if you perform, or if the Manual
is used to perform, any service or repairs on any Alesis product or part thereof, any and all
warranties of Alesis as to that product and any service contract with Alesis for that
product shall be voided and shall no longer apply for such product, even if your services or
repairs were done in accordance with the Manual.
All service or repairs done by you or with reference to the Manual shall be solely your
responsibility, and Alesis shall have no liability for any such repairs or service work. All such
service or repairs are performed at the sole risk of the person performing the service or
repairs. You agree that all such work will be performed in a competent, professional and safe
manner at all times and to indemnify and fully hold Alesis and its successors and assigns
harmless in the event of any failure to so perform.
Your purchase of the Manual shall be for your own ultimate use and shall not be for purposes of
resale or other transfer.
As the owner of the copyright to the Manual, Alesis does not give you the right to copy the
Manual, and you agree not to copy the Manual without the written authorization of Alesis. Alesis
has no obligation to provide to you any correction of, or supplement to, the Manual, or any new
or superseding version thereof.
Alesis shall have the right to refuse to sell or otherwise transfer repair parts or materials to you in
its sole discretion. You shall not use, sell or otherwise transfer spare or replacement parts
supplied by Alesis to you (i) to repair or be used in products manufactured for or by third parties
or (ii) to any third parties for any purpose.
You shall not make any warranties or guarantees with respect to the products of Alesis or the
use thereof on behalf of Alesis or in your own name.
The foregoing describes the entire understanding related to sale or transfer of the Manual to you,
and no other terms shall apply unless in a writing signed by an authorized representative of Alesis.
All Trademarks are property of their respective companies.

Confidential Alesis Service Manual
Warnings
TO REDUCE THE RISK OF ELECTRIC SHOCK OR FIRE, DO NOT EXPOSE THIS
PRODUCT TO WATER OR MOISTURE.
The arrowhead symbol on a lightning flash inside a triangle is intended to
alert the user to the presence of uninsulated “dangerous voltage” within the
enclosed product which may be of sufficient magnitude to constitute a risk
of electric shock to persons.
The exclamation point inside a triangle is intended to alert the user to the
presence of important operating, maintenance and servicing instructions in
the literature which accompanies the product.
REPAIR BY ANY PERSON OR ENTITY OTHER THAN AN AUTHORIZED ALESIS
SERVICE CENTER WILL VOID THE ALESIS WARRANTY.
PROVISION OF THIS MANUAL DOES NOT AUTHORIZE THE RECIPIENT TO
COMPETE WITH ANY ALESIS DISTRIBUTOR OR AUTHORIZED REPAIR SERVICE
CENTER IN THE PROVISION OF REPAIR SERVICES OR TO BE OR MAKE REPAIRS
AS AN AUTHORIZED SERVICE CENTER.
ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED ALESIS
SERVICE CENTER SHALL BE SOLELY THE RESPONSIBILITY OF THAT ENTITY,
AND ALESIS SHALL HAVE NO LIABILITY TO THAT ENTITY OR TO ANY OTHER
PARTY FOR ANY REPAIRS BY THAT ENTITY.
Regarding the Power Supply Fuse
Caution: The product under service may employ the use of a replaceable
fuse. Danger of fire or electrocution if fuse is incorrectly replaced. Replace
with only the same type or equivalent type recommended by the equipment
manufacturer.
Regarding the Internal Battery
Caution: The product under service may employ the use of a internal
battery. Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instruction.

Confidential Alesis Service Manual
Safety Instructions
Carefully read the applicable items of the operating instructions and these safety suggestions
before using this product. Use extra care to follow the warnings written on the product itself and
in the operating instructions. Keep the operating instructions and safety suggestions for
reference in the future.
1. Power Source. The product should only be connected to a power supply which is
described either in the operating instructions or in markings on the product.
2. Power Cord Protection. AC power supply cords should be placed such that no one is likely
to step on the cords and such that nothing will be placed on or against them.
3. Periods of Non-use. If the product is not used for any significant period of time, the
product’s AC power supply cord should be unplugged from the AC outlet.
4. Foreign Objects and Liquids. Take care not to allow liquids to spill or objects to fall into
any openings of the product.
5. Water or Moisture. The product should not be used near any water or in moisture.
6. Heat. Do not place the product near heat sources such as stoves, heat registers, radiators
or other heat producing equipment.
7. Ventilation. When installing the product, make sure that the product has adequate
ventilation. Improperly ventilating the product may cause overheating, which may damage
the product.
8. Mounting. The product should only be used with a rack which the manufacturer
recommends. The combination of the product and rack should be moved carefully. Quick
movements, excessive force or uneven surfaces may overturn the combination which may
damage the product and rack combination.
9. Cleaning. The product should only be cleaned as the manufacturer recommends.
10. Service. The user should only attempt the limited service or upkeep specifically described in
the operating instructions for the user. For any other service required, the product should be
taken to an authorized service center as described in the operating instructions.
11. Damage to the Product. Qualified service personnel should service the unit in certain
situations including without limitation when:
a. Liquid has spilled or objects have fallen into the product,
b. The product is exposed to water or excessive moisture,
c. The AC power supply plug or cord is damaged,
d. The product shows an inappropriate change in performance or does not operate
normally, or
e. The enclosure of the product has been damaged.

Bill of Materials (BOM)
Part No Item Description Usage
13110028 switching power AN-T90028,AC90-240,VDC24V,2A 1
16040810 wire AN-W4370,2P,18#,UL1007,110mm,red black,3.96 female
terminal
1
16041033 wire AN-W4594,3P,18#,UL1617,100mm,red white VH-T
terminal,tinning 7mm
1
20080052 rear cover DN-PC8045,main speaker,ABS,80%,UL94-V0,painted
matte black,V1.0
1
20080053 rear cover DN-PC8046,auxiliary speaker,ABS,80%,UL94-V2,painted
matte black,V1.0
1
20210086 knob DN-PN2060,ABS,black,surface of rubber paint 1
20290072 bracket DN-PB0069,ABS,80%,UL94-V0,black,ROHS,V1.0 1
30010019 heat-shrinkable tubing Φ5*15*0.28mm,UL,black 2
30060464 foam LAUH,EVA,black,(1),50*39*1mm,V1.0 1
30060466 foam LAUH,EVA black,(3),20.9*17.9mm*2mm,V1.0 1
40010039 power socket AN-J0139,ST-A03-002BS 1
54080010 rear cover DN-PC8045,main speaker,ABS,80%,UL94-V2,silkscreen
white,V1.0
1
54080011 rear cover DN-PC8046,auxiliary speaker,ABS,80%,UL94-V2,silkscreen
white,V1.0
1
70010006 screw Φ2.6*5mm,cross round hea,screw headD6mm,black
zinc,harden
3
70010127 screw AN-C10127,M3*12mm,cross round hea,screw
headD5.5mm,black zinc,harden
2
70010337 screw Φ2.6*8mm,cross round hea,screw headD4.5mm,black
zinc,harden
5
70070014 hex nut Φ6*M3*2.5mm,black zinc 2
CR011005 RoHS semi-electronic
part:LAUH PRE&AMP
LAUH PRE&AMP ASSY 1
CR011007 RoHS semi-electronic
part:LAUH VR+HP JACK
LAUH VR+HP JACK ASSY 1
CR011008 RoHS semi-electronic
part:LAUH CK JACK
LAUH CK JACK ASSY 1
16041034 wire AN-W4595,20#,UL1007,250mm,XHS2.5female
terminal,wicking 5mm
2
16140408 wire 26#,UL1007,5+100+5mm,black 2
16140438 wire 26#,UL1007,5+80+5mm,blue 2
16150074 wire AN-W1559,18#,UL2468,2000mm,DC3.5mono plug 1
16150075 wire AN-W1560,2000mm,3.5mm stereo straight plug 1
17050103 capacitance 2.2uF/50V,±20%,-40/+85℃,Φ6*17mm,purple 2
20300120 washer LAUH,rubber,black,T=2mm,V1.0 8
20640028 front cover DN-EC026,main speaker,ABS,UL94-V2,silver
gray,ROSH,V1.0
1
20640029 front cover DN-EC027,auxiliary speaker,ABS,UL94-V2,silver
gray,ROHS,V1.0
1

21010545 wooden box DN-X10230,main speaker,MDF,T=9mm,silver surface
PCV,V1.0
1
21010546 wooden box DN-X10231,auxiliary speaker,MDF,T=9mm,silver surface
PCV,V1.0
1
22011047 user manual LAUH,English user manual,V1.0 1
22050008 desiccant 20g,silica gel,nonwovens,DMT,SGS 1
23010565 packing bag PE,120*280*0.08mm,with hole,red printing,V1.0 3
23010601 packing bag PE,240*350*0.025mm,red silkscreen,with 4 hole,V1.0 1
23010602 packing bag PE,(250+230)*540*0.08,red silkscreen,with 4 holes,V1.0 2
23020278 polyfoam LAUH,polyfoam,white,454*284*80mm,ROHS,V1.0 2
23031417 master carton LAUH,A=A,T=6mm,,485*315*350mm,V1.0 1
23090639 giftbox LAUH,350g gray+B3+A3,T=6mm,468*298*330mm,color
printing,V1.0
1
30060465 foam LAUH,EVA,black,(2),45*25*2mm,V1.0 2
54280008 front cover DN-EC026,main speaker,ABS,UL94-V2,gray,black
silkscreen,V1.0
1
54280009 front cover DN-EC027,auxiliary speaker,ABS,UL94-V2,gray,black
silkscreen,V1.0
1
70010656 screw Φ3.5*15mm,cross round hea头,screw headD6mm,black
zinc,harden
28
70010874 screw Φ3*7mm,cross round head,screw headD6mm,black
zinc,harden
10
70010875 screw Φ3*8mm,cross round hea,screw headD10mm,black
zinc,harden
16
80010022 3/4" tweeter AN-L114,8ohm,10W,99-08-Y200UH-00 2
80250006 4" woofer AN-LM006,8ohm,20W,99-08-00LAUH-01 2
90021423 S/N sticker LAUH,white grounding with black printing,64*13mm,V1.0 4
90041534 barcode sticker LAUH,white grounding with black printing,38*26mm,V1.0 2
90080001 destination stickers GA0/GA1/GA2,coated paper,yellow bottom 3
90200056 labeling sticker coated paper,,BLACK&361C printing,Φ30mm,V1.0 1
90220078 Special stickers ALESIS,30*30mm,coated paper,PANTONE 361C,V1.0 1
90250043 CARB label coated paper,black grounding with white
printing,75*27mm,V1.0
1
90270013 date sticker LGAC-2,coated paper,black grounding with white
printing,20*5mm,V1.0
1
16070187 power line AN-W1081,2C,0.75mm2,H03VVH2-F,2000mm,black,for EU 1
16070191 power line AN-W1085,2C,0.824mm2,NISPT-2
18AWG,2000mm,black,for ul
1
16070192 power line AN-W1086,2C,0.75mm2,H03VVH2-F,2000mm,black,for UK 1
16070198 power line AN-W1092,2C,0.75mm2,H03VVH2-F,BK,2000mm,for AU 1
22011056 user manual ALESIS,safety manual,V2.0 1
90041535 barcode sticker LAUH,white grounding with black printing,76*50mm,for
UL,V1.0
1
