Alexander Leap Luminous Beta User manual

To enter the global setup menu, rst hold down the PAGE / MENU knob
(lower right,) then hold the left footswitch.
Turn the lower left knob to select the parameter you want to change, then
turn the lower right knob to set its value.
Hold the PAGE / MENU knob (lower right) to save your settings and exit
the menu.
GLOBAL SETUP MENU
M.JACK EXPRESSN MultiJack is expression pedal input
FOOT. SW MultiJack is foot switch input
MIDI MultiJack is MIDI input (requires MIDI to TRS adapter)
PRST.EX Preset selection using ALEXPANDER footswitch
SCRL.EX Preset scroll using ALEXPANDER footswitch
CHANNL Sets MIDI input channel
STEREO MONO IN INPUT jack is mono
INP. SUM INPUT jack sums to mono
STEREO INPUT jack is stereo
RPHASE Sets phase of R output, allows correction for amp or eect phase.
PRESET Sets number of presets available on device. Does not aect MIDI.
DISPLY PRESET Display shows preset except when turning knobs
KNOBS Display shows knobs except when loading preset
BLANK Display is owhen not adjusting knobs
KNOBS JUMP Knobs jump to new value when turned
PICKUP Knobs don’t move until turned to previous value rst
RETURN Pedal will return to the main control page after 5, 10, 30 seconds
MIDOUT OFF Pedal does not send MIDI CC values
JACK Pedal sends MIDI CC from MultiJack
USB Pedal sends MIDI CC from USB MIDI
BOTH Pedal sends MIDI CC from both
TRAILS OFF - hard bypass, ON - trails bypass, AUTO - trails fade out
EXP LO / HI Sets heel and toe calibration for expression pedal
PWR ON Choose BYPASS or ENGAGE to set the power-on state of pedal
RESET Turn to reset CONFIG, PRESETS, or ALL. Hold PAGE knob to reset.
Select MIDIDUMP to export presets over USB MIDI
CONTROL KNOBS
ADJUST PARAMETERS
AS SHOWN ON DISPLAY
PAGE KNOB
TAP TO CHANGE PAGE
HOLD TO ACCESS MENU
TAP / CTRL SWITCH
TAP TWICE TO SET TEMPO
HOLD TO FIRE RAMP
BYPASS SWITCH
TAP TO BYPASS OR ENGAGE
HOLD TO LOAD NEXT PRESET
INPUT
MONO OR TRS
STEREO INPUT
RIGHT
R STEREO OUTPUT
LEFT
MONO OUTPUT
OR TRS STEREO
MULTI
EXPRESSION
PEDAL OR MIDI
We sent a team of sonic scientists deep into the arctic circle on a secret mission: to
capture bits of the Aurora Borealis so we could transmute them into a pedal. What
emerged was Luminous, equal parts phaseshifter and swirly glowing haze machine.
It dances and hovers with the utmost mystery, occasionally imperceptible while
frequently vivid. And it glows in the dark, because of course it does.
Using the pedal is pretty simple: plug your instrument into the INPUT jack and your
amplier or other effect into the L jack, power up the pedal with 9V 250mA or more,
and turn some knobs. As soon as you touch a knob, the display will change to show
what is happening. You can also tell the pedal to stay in the knobs display mode in
the Setup menu.
The lower-right knob has a pushbutton switch, tap that to access extra parameters
on the back pages of the user interface. We’ve put the most common controls up
front, tweaking stuff on page 2, and utility items on page 3. Three small boxes at the
bottom of the display indicate the currently selected page.
This guide covers the basics of the pedal including its
connections, controls, and features. For more detailed
information you can scan the code in this section to be taken
to our website for access to the full manual, MIDI information,
rmware updates, and more.
A NOTE ABOUT POWER:
Leap Series pedals are digital and require a lot of power. They
also don’t like sharing power supply grounds with other pedals,
so please don’t use a “daisy chain” type power supply
Use name-brand isolated supplies for the best possible performance.
BASIC OPERATION
PRESETS
How do you make quick changes on a pedal that has 12+ knobs? PRESETS.
Every Leap Series pedal allows you to save up to 32 presets that contain the entire
state of the pedal.
Loading a preset recalls all knob positions and expression pedal mappings.
To load a preset, hold the BYPASS / PRESET footswitch. You can set the number
of available presets in the Setup Menu, from 1 to 8. You can also access the other
preset banks 9-16, 17-24, and 25-32.
To save a preset, rst use the pedal knobs to tweak the sound, then hold the PAGE
knob. Press and hold the BYPASS / PRESET footswitch to enter the save menu.
To save to the current preset, just hold down the BYPASS / PRESET footswitch again.
To rename the preset, turn the lower-left knob to select a character in the name and
then turn the PAGE knob to edit that character. Use the lower-left knob to select the
preset number and edit to change the save location.
9V DC INPUT
250 MA, CENTER NEGATIVE
ISOLATED POWER REQUIRED
USB PORT
USB MIDI AND
FIRMWARE UPDATE
PRESET DISPLAY
PRESET NUMBER & NAME
SOUND MODE NAME
KNOB DISPLAY
KNOB NAMES & VALUES
PAGE INDICATOR BOXES
v1.00
quickstarTguidequickstarTguide

EXPRESSION AND RAMPING
Every Leap Series pedal allows you to get as expressive as you want, any time you
want. Any of the pedal knobs may be controlled with an external expression pedal,
a MIDI controller, or even automatically using the Ramp function.
Connect a TRS expression pedal to the MultiJack input on your pedal, then enter the
setup mode and make sure that M.JACK is set to EXPRESSN. Save and exit setup.
Sweep the expression pedal to its fully heel-back position, then turn any or all of
the pedal knobs. Sweep the pedal to the opposite toe-down position and turn
the knobs again. That’s it! Note: some knobs don’t respond to expression, they’re
indicated by with an * in the Sound Modes section
If you don’t have an expression pedal or would prefer not to use one, you can hold
the TAP / CTRL switch to trigger the automatic expression ramp function. The ramp
controls are on page 3 of the pedal interface.
SOUND MODES
Luminous has ten selectable sound modes, each based on a dierent phaser eect type. You can tweak these modes to your taste, and you can save any sound to any
preset. To change sound modes, turn the lower right knob on page 1. Tap the lower right knob to advance to the next page. Knobs marked * do not respond to expression
or ramp controls.
NOTE: selecting a sound mode with the knob doesn’t change any of the other knob parameters, so you may need to tweak the controls after changing sound modes.
The following controls are common to all modes on page 3:
DIV* - tap division for modulation or delay, not available in DYNAMIC mode FILT* - Low-cut lter, higher settings reduce mud or low-end rumble.
LEVL - overall volume for the pedal (wet + dry) RAMP* - Ramp rate and trigger mode, please see EXPRESSION AND RAMPING below.
RAMP sets how fast the built-in expression ramp function will run, with clockwise
settings ramping more slowly. The range of this knob is divided into three sections
that also select the ramp trigger type.
(T)OGGLE: Ramp will trigger when the Tap / Ctrl switch is held, then remain at the
“toe”position until Tap / Ramp is held again.
(M)OMENTARY: Ramp will trigger while the Tap / Ctrl switch is held, then return
when the switch is released
CLR*: Ramp / EXP reset. Hold the Tap / Ctrl switch to set the“toe” values of each
knob to match the “heel” values.
Ramping and expression use the same “heel” and “toe”values. You can set these
values in ramp mode by ring the ramp in T mode, then turning the knobs while
the ramp is at full / “toe” position. Fire the ramp again to return to minimum / “heel”
position to set the other values.
CLASSIC
Versatile and powerful studio phaser, congurable between 2 and 24 phase
stages. Try a 4-stage phaser with low resonance for stompbox-type phasing, or a
12-stage phaser set to slow sweep for studio style phasing.
RATE - phase speed from 10-0.1s
DEPT - phase LFO intensity
MIX - mix of wet and dry signals
STAG* - phase stages from 2-24
RESO - phase feedback
WAVE* - LFO wave shape
CENT - LFO wave center point
DUAL PHASE
Two independent phase shifters, congurable as SERIES (A into B,) PARALLEL (A
and B summed together,) STEREO (A on left, B on right,) or SPLIT (stereo inputs to
each phaser.) Phaser B may be LOCKED or INVERTED to the LFO for Phase A.
RAT1 - phaser A rate
DEP1 - phaser A intensity
MIX - mix of wet and dry signals
RAT2 - phaser B rate or LOCK / INV
DEP2 - phaser B intensity
WAVE* - sine or square for A/B
ROUT* - phaser A and B routing
PHASE DELAY
Clean digital delay (up to 800ms) with an 8-stage phaser on the delay trails. The
delay is controlled by the tap tempo in this mode instead of the phaser.
TIME - delay time from 0-800ms
REPT - delay repeat level
MIX - mix of wet and dry signals
RATE - phaser rate
DEPT - phaser intensity
WAVE* - LFO wave shape
CENT - LFO center point
K-TREM
Inspired by vintage tuck-and-roll amps, this is phase vibrato combined with
tremolo. Try 2 stages with low Image settings for amp-type eects, or 3 stages for
more of a vibro thang. Sync sets tremolo to mute during high or low phase sweep.
RATE - modulation speed
VIB - phase / vibrato intensity
TREM - tremolo intensity
STAG* - phaser stages from 2-5
IMAG - phaser resonance
WAVE* - LFO wave shape
SYNC* - trem mutes high or low phase
INFINITE
This one will spin you right round! Combines a Bode-inspired frequency shifter
with phaser bank to produce innitely rising or falling phase using the DIR control
on page 2. The Rate and Depth controls aect the phaser bank to add motion.
RATE - phase speed from 10-0.1s
DEPT - phase LFO intensity
MIX - mix of wet and dry signals
DIR - innite direction and speed
RESO - feedback
WAVE* - phase LFO wave shape
CENT - phase LFO center point
FLYING PAN
Classic ‘70s style panned phaser. Warning - this one only works to its full potential
in stereo, but it’s still a cool tremolo phaser in mono. The phase signal may be
placed anywhere in the stereo spectrum before it hits the panning engine.
RATE - phase speed from 10-0.1s
DEPT - phase LFO intensity
MIX - mix of wet and dry signals
PRAT - panning rate
PDEP - panning intensity
PWAV* - panning LFO wave shape
PAN - phaser panning location
PATTERN
Rhythmic step-sequenced phaser with 8 selectable patterns.
RATE - pattern step speed
STEP - number of pattern steps
MIX - mix of wet and dry signals
STAG* - phase stages from 2-24
RESO - phase feedback
PATT* - pattern selection
DIR* - DOWN, UP, or UP&DOWN
UNIQUE
Special mode inspired by an incandescent-powered Japanese eect from the
1960s. The second page has controls to go way beyond the original eect, set
these at their minimum position to start at the vintage sound. Set the Mix control
to 50% for“chorus” or 100% for “vibrato.”
RATE - phase speed from 10-0.1s
DEPT - phase LFO intensity
MIX - mix of wet and dry signals
STAG* - normal (4) or double (8)
RESO - phase feedback
BEAT - amount of “throb”
SYNC* - sets“throb” polarity
DYNAMIC
8-stage phaser controlled by your playing dynamics. Dynamic engine may control
phaser RATE, DEPTH, or set to MANUAL mode to control the phaser directly like an
auto-lter.
RATE - phaser speed
DEPT - phaser depth
MIX - mix of wet and dry signals
SENS - gain for volume sensing
RISE - time for volume sensing
SOFT - control value at low volume
LOUD - control value at high vol
MODE* (pg3) RATE, DEPTH, MANUAL
PHLANGER
Takes inspiration from a classic DIY kit. While the original was just a funny spelling
of “anger,” our version combines phaser and anger in a single mode. Use the
Time control to mix and swirl between the two eects.
RATE - LFO speed from 10-0.1s
DEPT - LFO intensity
MIX - mix of wet and dry signals
TIME - phase at min, ange at max
RESO - feedback
WAVE* - LFO wave shape
CENT - LFO wave center point
