Alfain aXe 320 double pulse User manual

ALFA IN a.s. © www.alfain.eu aXe 320 double pulse manual EN1
WELDING MACHINES
aXe 320 double pulse
(also HIGHT SPEED)
OPERATING MANUAL

2/35
ALFA IN a.s. © www.alfain.eu
CONTENT:
1. INTRODUCTION .................................................................................... 3
2. SAFETY PRECAUTIONS ....................................................................... 3
3. TECHNICAL DATA ................................................................................ 6
4. MAIN PARTS OF THE MACHINE .......................................................... 7
5. ACCESSORIES ...................................................................................... 8
6. GETTING STARTED .............................................................................. 8
7. CONTROL PANEL ............................................................................... 13
8. STRUCTURE OF MENU ...................................................................... 17
9. JO S MANAGEMENT ......................................................................... 18
10. TORCH TRIGGER MODES .............................................................. 23
11. SET-UP (INITIAL SET-UP OF THE WELDING POWER SOURCE) . 26
12. ALARMS MANAGEMENT ................................................................ 32
13. RESET .............................................................................................. 33
14. ROUTINE MAINTANCE & INSPECTION .......................................... 33
15. SERVICE .......................................................................................... 34
16. DISPOSAL ........................................................................................ 35

3/35
ALFA IN a.s. © www.alfain.eu
1. INTRODUCTION
Dear consumer,
Company ALFA IN a.s. thanks you for buying our product and believe that
you ill be satisfied ith our machine.
Welding machine may be operated only by trained persons and only in the
technical provisions. Company ALFA IN a.s. accept no responsibility for
damage caused by improper use. Before commissioning please read
carefully this manual .
The machine complies ith the appropriate CE mark.
For maintenance and repairs, use only original spare parts. There is of course
a complex of our services.
Welding machine aXe 320 double pulse is designed for MIG / MAG
continuous and pulse, MMA and gouging. By the machine aXe 320 double
pulse you can eld different types of connections (butt, single-sided, double-
sided, fillet, lap, etc.) using ire from diameter 0.8 to 1.2 respectively to 1.6
mm of different metals and alloys (carbon and alloy steels, aluminum alloys,
etc.). They are designed primarily to medium and large industrial facilities
here are high demands on ease of use, reliability and productivity ith
prolonged use.
Welding machines aXe 320 double pulse are available in:
1. aXe 320 double pulse COMPACT (Gas or H2O, HIGHT SPEED
option) compact elding machine and the option of a ater cooled
torch
2. SAFETY PRECAUTIONS
1. Use and maintenance of elding and cutting machines can be
dangerous. Please dra user´s attention to follo the safety precau-
tions to avoid injuries. Welding and cutting machines must be used
appropriate and only by specialist staff. Please inform yourself
constantly about the valid safety precautions and regulations of
accident prevention by orking ith this machine*.
2. Remove all flammable material from the elding area for fire prevention
before elding.
3. Do not eld at containers hich ere filled up before ith flammable
materials (fuel).
4. All inflammable material in the elding area hich could be inflamed by
sparks must be removed.
5. Check after elding the place conforming UVV.
6. Do not expose the unit to rain, steam and do not spray ater in it.

4/35
ALFA IN a.s. © www.alfain.eu
7. Do not eld ithout protection shield. Keep attention to protect other
persons in the elding area against arc-rays.
8. Please use absorbers or other systems to absorb the gases.
9. It is not possible to absorb all the gases correctly please use a
breathing apparatus.
10. Stop operation immediately at a defect or damaging of the mains
cable. Do not touch the cable. Unplug the unit before each service or
repair. Do not use the machine if the mains cable is defect.
11. Place an extinguisher near the elding area.
12. Check the elding area against fire after elding.
13. Never try to repair a defect pressure reducer. Replace the defect
one.
14. Keep attention to connect the ground cable near the elding
location. Welding current through chains, ball-bearing or steel-cables
may destruct or melt it.
15. Secure yourself and the unit at higher or inclinational places.
16. Connect the unit only at mains ith correct connection to
ground/earth and at prolongations and sockets too.
17. Wear correct protective clothing, gloves and leather apron.
18. Protect the elding area ith curtains or mobile alls against
rays.
19. Do not tha frozen aterpipes or conductions ith this unit.
20. In high electrical risk areas (in confined spaces) it is only allo ed
to use machines ith –sign S.
21. S itch off the machine at breaks and close the valve of the gas
cylinder.
22. Secure the gas cylinder ith a chain against falling over.
23. Please take off the gas cylinder from the machine for trans-
portation.
24. Disconnect the plug from the mains before changing the elding
area or repairs at the machine.
*) Please follo the current safety regulations corresponding to your
country.
UNIT PROTECTION
1. This unit is protected electronically against overloading.
2. Close the side lid before elding.
3. Connect the orkpiece ith the groundcable to the unit.
4. Remove elding spatter from the inside of the gas nozzle ith a special
pair of pliers. Spray ith anti spatter spray inside the gas nozzle to
avoid adherence of spatters. Spray sloping to avoid the obstruction of
the gasoutlet.
5. At transportation of the unit only use the purposed transportation
facilities, do not use a fork-lift truck or something similar.

5/35
ALFA IN a.s. © www.alfain.eu
EMISSION OF SOUND
The sound level of the unit is smaller as 70 dB (A) measured at standard load
conforming EN 60 974 at the max. orkpoint.
ELEKTROMAGNETIC COMPATIBILITY (EMC)
1. This product is manufactured conform to the current EMV standard.
Please notice follo ing items:
2. The unit is for elding under commercial or industrial conditions. The
use in other surroundings (for example in residential areas) may disturb
other electric devices.
3. During elding electromagnetic problems can be caused at:
a) Mains cables, control cables, connections for telecommunication
b) TV/Radio
c) Computer and other similar devices
d) Protection devises as for example alarm systems
e) Pacemakers and hearing aids
f) Devices for measure and calibrate
g) Devices ith less protection against disturbances
4. If other devices are disturbed it may be necessary to protect
additionally.
5. The affected area can be bigger than your premises/ property depends
of the building etc.
6. Please use the unit conform to the instructions of the manufacturer. The
user is responsible for installation and use of the machine. Furthermore
the user is responsible to eliminate the disturbances caused by
electromagnetic fields.

/35
ALFA IN a.s. © www.alfain.eu
3. TECHNICAL DATA
Technical data aXe 320 double pulse
Method MIG/MAG
Mains voltage V/Hz 3x400/50- 0
Welding current
range A 20 - 320
Open-circuit
voltage U20 V 71,0
Mains protection A 20 @
Max. effective
current I1eff A 14,2
Welding current
(DC=100%) I2 A 230
Welding current
(DC= 0%) I2 A 280
Welding current
(DC=x%) I2 A 45%=320
Protection IP 23S
Standards EN 0974-1
Dimensions (w x l
x h) generator mm 572 x 1035 x 880
Weight -
generator
/compact
kg 9 ,8
Wire speed m/min
1 - 20
Spool diameter mm 300
Spool weight kg 18
Cooling power
(Q=1l/min) kW 0,74
Total liquid content
l 3,0
Max. pressure Bar 3,5
Max. flow l/min 8
 Attention 
Given the size of the installed capacity, the connection of the device to
the po er supply must be approved by distribution companies.
 Attention 
Users are reminded that they are responsible for any interference from
elding.

7/35
ALFA IN a.s. © www.alfain.eu
4. MAIN PARTS OF THE MACHINE
Picture 1 - The main part
A1 ON/OFF s itch
A5 Quick connector (-)
A6 PCB control panel
A7 EURO connector
A8 Wire Feeder
A9 Spool Holder
A10 Solenoid Valve
A11 Mains Cable
A25 Fuse 500mA 6x32
A26 Adaptor W (red)
A27 Adaptor W (blue)
A29 Connector remote control

8/35
ALFA IN a.s. © www.alfain.eu
A30 CU aXe Cooling unit
A31 Cup
5. ACCESSORIES
INCLUDED IN DELIVERY
1. po er generator
2. feed unit
3. connecting cable
4. 3 m long earthing cable ith clamp
5. rolls for ire ith diametres from 1,0 to 1,2 mm
6. reducting for the spool ire 5 kg and 18 kg
7. hose for gas connection
ACCESSORIES ON REQUEST
1. pressure regulator
2. set of four crane heels (code 3.0199)
3. gas bottle
4. spare parts for the torch
5. 4 – 5 m long earthing cable
6. rolls 0,6 – 0,8, 1,0 – 1,2, 1,4 – 1,6, 1,6 – 2,4
7. remote control UP-DOWN
TORCHES ON REQUEST
1. torches 3, 4, 5 m UP-DOWN
2. torch PUSH-PULL up to 25 m
6. GETTING STARTED
TORCH INSTALATION
1. Never connect the torch in the machine if it’s still running!
2. Connect the EURO connector male 2 to EURO connector 1. Then,
connect Quick connector torch W (red) 6 to the Quick connector W
(red) 4 and the Quick connector torch W (blue) 7 to the Quick
connector W (blue) 5
3. When connecting a gas-cooled torch, it is necessary to interconnect the
quick connectors ith ater hose of the hydraulic circuit. If this
condition is not met, it may result in damage to the pump.

9/35
ALFA IN a.s. © www.alfain.eu
Picture 2 – Torch installation
B1 EURO connector
B2 EURO connector male
B3 Torch
B4 Quick connector W (red)
B5 Quick connector W (blue)
EARTHING CABLE CONNECTION
1. Connect the quick connector of the earthing cable C1 to the quick
connector located on the machine C3 (-), secure it thoroughly by turning
it clock ise. Attach the earthing clamp to eldment C2.
EARTHING CLAMP CONNECTION
1. Attach the earthing clamp near the eld. It is important to ensure that
the connection ith orkpiece is as strong as possible.
Picture 3 – Earthing clamp connection
C1 Quick Connector male
C2 Earthing Clamp
C3 Quick Connector (-)

10/35
ALFA IN a.s. © www.alfain.eu
Picture 4 - Earthing clamp connection
 Do not place the earthing clamp on the elding machine or a gas bottle!
 Firmly connect the earthing clamp to eldment or elding table.
CONNECTING TO POWER SUPPLY
1. Plug the po er plug into the all socket. Circuit breakers must conform
to the technical dates of the machine.
INSERTING THE WIRE
1. Open the side cover of the ire feeder space
2. Put the ire spool on the ire spool holder D1 using the adapter D3
and fix it ith the fixing nut D2
3. Cut off the curved or damaged end of elding ire and lead it through
the inlet liner E3, and the roll into the liner inside the EURO torch
connector (about 5 cm). Make sure, that you use the suitable groove.
4. Put the pressure arm E2 do n in that ay, that the teeth or the gear fit
and fix it by setting the lever E1 into vertical position.
5. Adjust the pressure nut that ay that it provides constant movement of
ire but it does not deform ire.
Picture 5 - Spool ire holder

11/35
ALFA IN a.s. © www.alfain.eu
D1 Spool Holder
D2 Nut Spool Holder
D3 Adapter
Picture 6 – Wire feed 4-roller
E1 Fixing shaft
E2 Pressure arm
E3 Liner- Feeder
E4 EURO connector
E5 Roll
Picture 7 – Roller impact on the elding ire
GAS FLOW
1. Place the gas cylinder on the platform and fix it properly by the fixing
chain. We recommend using bolts and nuts to fix it more safely.
2. Connect the pressure reduction valve on the gas cylinder.
3. Connect the gas hose to gas outlet F8 on the valve and the gas inlet F9
on the machine
4. Open the F2 cylinder valve
5. Press the button Gas test T23 for more then 4 s
6. Adjust the amount of gas on the reduction gas valve (it is not a part of
the elding machine) by the F7 adjusting scre

12/35
ALFA IN a.s. © www.alfain.eu
Picture 8 - Adjusting the gas flo
F1 Gas Cylinder
F2 Cylidner Valve
F4 Pressure Reducer
F5 High Pressure Manometer
F6 Lo Pressure Manometer
F7 Adjusting Scre
F8 Gas outlet
F9 Solenoid Valve
F10 Chain
AD USTING THE MACHINE FOR WELDING OF ALUMINIUM
1. Replace the rollers G2 for rollers G2 ith U-profile of the groove (for AL
elding)
2. Loosen the nut G5 on EURO connector
3. Replace the torch used on steel for aluminum torch or at least replace
the liner for Liner tefl. G6.
4. Replace the capillary from the EURO connector G1.
5. Cut end of the teflon liner G6 so that it is near the rollers.
6. Thread the end of the teflon liner ith sustainpipe for teflon and plastic
liner G7 for stabilization.
7. Put the torch on the EURO connector G1 and insert the ire.
Picture 9 – Customization of the feed for the aluminum ire

13/35
ALFA IN a.s. © www.alfain.eu
G1 EURO connector
G2 Rolls
G3 Liner terminal
G4 O - ring
G5 Nut
G6 Liner tefl.
G7 Sustainpipe for teflon and plastic liner
7. CONTROL PANEL
Picture 10 - Panel of the machine
P1 The button scrolls the selection made on the menus
do n ards or to the left.
P2 The button scrolls the selection made on the menus
up ards or to the right.
P3 The button restores the main menu of display P25, starting
from any other page.

14/35
ALFA IN a.s. © www.alfain.eu
The button serves to exit any menu ithout saving any
changes.
P4 This button selects the torch trigger procedure.
10 TORCH TRIGGER MODES
P5 This button selects the elding mode.
P6 Data setting: The encoder adjusts the main elding (and
synergy) parameter, sho n on the follo ing display: P12
P7 This LED illuminates to sho that the follo ing elding
mode is selected: DOUBLE PULSED SYNERGIC MIG/MAG
P8 This LED illuminates to sho that the follo ing elding
mode is selected: PULSED SYNERGIC MIG/MAG
P9 This LED illuminates to sho that the follo ing elding
mode is selected: SYNERGIC MIG/MAG
P10 This LED illuminates to sho that the follo ing elding
mode is selected: MANUAL MIG/MAG
P11
Manual MIG/MAG mode: The button is not active.
Synergic MIG/MAG mode: The button cycles through the
follo ing LEDs in sequence, selecting only one: / /
P12
During illumination of the follo ing LEDs: / /
The display sho s the value of the selected parameter.
Welding: The display sho s the effective amperes value
during elding.
HOLD function (at welding end): The display sho s the
latest measured current value.
P13
When this LED illuminates the follo ing parameter can be
set: WIRE FEED RATE
The value appears on the follo ing display: P12.
P14
Short-Spray, pulsed and synergic MIG/MAG elding:
When this LED illuminates the follo ing parameter can be
set: WELDING CURRENT
HOLD function (at elding end):
Illuminates to sho a value in the follo ing unit of
measurement: AMPERES
The value appears on the follo ing display: P12
P15
This LED illuminates to sho an anomaly in the operating
conditions.
An alarm message appears on the follo ing display: P19
12 ALARMS MANAGEMENT
P16
When this LED illuminates the follo ing parameter can be
set: WELDING THICKNESS
(Reference is made to "T" fillet elds on identical
thicknesses. The relative value is purely guideline).
The value appears on the follo ing display: P12

15/35
ALFA IN a.s. © www.alfain.eu
P17
Illuminates to sho the last voltage and current values
measured during elding.
The LED s itches off hen a ne elding procedure is
started, or hen any of the elding settings is modified.
The value appears on the follo ing displays: P12 - P19
P18 This LED illuminates to confirm the presence of po er on
the output sockets.
P19
Data setting: The display sho s the value, in Volts, of the
selected elding voltage.
Welding: The display sho s the effective voltage value
during elding.
HOLD function (at welding end): The display sho s the
latest measured voltage value.
P20
Manual MIG/MAG welding: The display is not active. The
display sho s “- - - “.
Synergic MIG/MAG welding: The display sho s the arc
correction value imposed by the operator ith respect to the
default value of the synergic curve.
P21
Illumination sho s that the follo ing function has been
activated: 2 times procedure
2T MIG/MAG WELDING
A flashing signal means the follo ing function is activated: 2
times procedure
2T SPOT MIG/MAG WELDING
P22
Illumination sho s that the follo ing function has been
activated: 4 times procedure
4T MIG/MAG WELDING / 4T B-LEVEL MIG/MAG WELDING
P23
Illumination sho s that the follo ing function has been
activated: 3 levels procedure
3 LEVEL - 2T B-LEVEL MIG/MAG WELDING / 3 LEVEL - 2T
SPOT MIG/MAG WELDING
3 LEVEL - 4T B-LEVEL MIG/MAG WELDING / 3 LEVEL - 4T
B-LEVEL MIG/MAG WELDING
P24
Manual MIG/MAG mode: The encoder adjusts the elding
voltage, and the relative value is sho n, in volts, on the
follo ing display: P19
Synergic MIG/MAG mode: The encoder is used to correct
the factory-set value of the selected synergic curve, the
value of hich is sho n on the follo ing display: P20
P25
Data setting: The display sho s the various elding menus
relative to the selected processes.
The display sho s the selected parameter.
P26 This button activates ire feed to insert it through the

1 /35
ALFA IN a.s. © www.alfain.eu
MIG/MAG torch.
The insertion speed is 2 m/min for 3 seconds, subsequently
increasing to 10 m/min.
This function produces a slo er feed rate and hence greater
precision hen inserting the ire hen it enters the torch
nozzle.
P27
This button opens the gas solenoid valve to fill the circuit
and calibrate the pressure ith the regulator on the gas
cylinder.
TORCH LOADING
P28
The encoder changes the setting of the selected parameter
sho n on the follo ing display: P25
The selected parameter is sho n by the follo ing symbol:

P29
The button enables management of the personalised
programs that can be sho n on the follo ing display: P25
9 Jobs management
P30 The button selects the various submenus visible in the
follo ing display: P25

17/35
ALFA IN a.s. © www.alfain.eu
8. STRUCTURE OF MENU
Menu is divided into three levels.
1ST LEVEL
The menu sho s the setting of the most important elding parameters
(or synergic settings) relative to the selected elding process.
P
U
L
S
E
S
Y
N
M
A
T
→
S
G
2
/
S
G
3
Ø
:
1
.
2
G
A
S
:
8
0
%
A
r
/
2
0
%
C
O
2
J
O
B
:
F
E
5
5
F
A
N
T
A
2ND LEVEL
For each process selection the menu sho s the "secondary" elding
parameters that can be modified ith respect to their synergic values.
If the type of ire, gas, or diameter is changed ithin a elding process,
the second level parameters return to their default values.
The changed parameters remain saved for the relative process selection
(manual, synergic, pulsed synergic, double pulsed synergic MIG/MAG ).
To save and retrieve the changes made, utilise the JOBs storage procedure.
Acronym of the selected welding
process.
MAT: This parameter sets the
material of the welding wire
utilised.
GAS: This parameter sets the
type of gas utilised for welding.
Name of loaded JOB. When the indicator is “→” the parameter value can e modified.
The value is saved automatically.
After pressing the torch trigger or after 10 seconds without any
commands, the indicator switches to “:“.
To reactivate the parameter value editing function press one of the
following uttons:
SYN: This code indicates that parameters control is synergic.
MAN:
This code indicates that parameters control is manual.
Ø: This parameter sets the
diameter of the wire utilised for
welding procedures.

18/35
ALFA IN a.s. © www.alfain.eu
3RD LEVEL
The menu contains the settings and values that are changed infrequently and
are to be set up the first time the unit is po ered up.
The changed parameters remain saved until the next modification or reset of
the unit.
11 SET-UP (INITIAL SET-UP OF THE WELDING POWER SOURCE)
9. JO S MANAGEMENT
Personalised elding settings, or JOBs, can be saved in memory locations
and subsequently uploaded.
Up to 99 jobs can be saved (j01-j99).
The settings of the SETUP menu are not saved.
SAVING A OB
This function is available hen elding mode is not active.
P29
Press the button.
The job menu appears in the follo ing displays: P25
P2 P1 Use these buttons to select the follo ing parameter: OPT
The selected parameter is sho n by the follo ing symbol: 
P28
Use the encoder to select the follo ing setting: SAVE
P2 P1 Use these buttons to select the follo ing parameter: JOB

19/35
ALFA IN a.s. © www.alfain.eu
The first free memory location is displayed.
If all the memory locations are occupied, the ord JOB
flashes and the first JOB is displayed.
If the memory location is already occupied by another job,
hen a ne JOB is ritten to the location it ill
over rite the existing JOB.
The names of unassigned jobs are “-“ by default after a space
follo ing the number corresponding to the
memory location.
Naming jobs
Save and keep original
P28
Using the encoder, select one of the unoccupied jobs.
Exit ithout confirmation
P3 Press the button.
This action ill automatically close the menu.
Exit ith confirmation
P29
Press the button.
This action ill automatically close the menu.
Save and replace original
P28
Using the encoder, select one of the occupied jobs.
P29
Press the button.
CONFIRM JOB
CHANGE
The message appears on the
follo ing displays: P25
Exit ithout confirmation
P28
Use the encoder to select the follo ing setting: NO
P29
Press the button.
This action ill automatically close the menu.
Exit ith confirmation
P28
Use the encoder to select the follo ing setting: YES
P29
Press the button.

20/35
ALFA IN a.s. © www.alfain.eu
This action ill automatically close the menu.
NAMING OBS
JOBS can be named and renamed (maximum 9 characters) in the JOB
menu, LOAD, or SAVE.
This function is available hen elding mode is not active.
P29
Press the button.
The job menu appears in the follo ing displays: P25
P2
P1 Use these buttons to select the follo ing parameter: OPT
The selected parameter is sho n by the follo ing symbol: 
P28
Use the encoder to select the follo ing setting:
LOAD / SAVE
P2
P1 Use these buttons to select the follo ing parameter: JOB
P28
Use the encoder to select the position of the job to be
renamed.
P29
Hold do n the button for 3 seconds.
The first letter of the name blinks.
P28
Use the encoder to change the letter.
P29
Press the button to confirm.
P2
P1 Use these buttons to select the character to be modified.
Exit ithout confirmation
P3 Press the button.
Return to the job menu.
P3 Press the button.
Exit ith confirmation
P29
Hold do n the button for 3 seconds.
Return to the job menu.
P29
Press the button.
