Alfain SVAROG 320 HD PULSE MODULAR User manual

ALFA IN a.s. © www.alfain.eu SVAROG 320 HD PULSE modular manual EN 01
WELDING MACHINE
SVAROG 320 HD PULSE
MODULAR
OPERATING MANUAL

2/33
ALFA IN a.s. © www.alfain.eu
CONTENT
1 INTRODUCTION ...................................................................................................3
2 SAFETY PRECAUTIONS .........................................................................................4
3 OPERATING CONDITIONS .....................................................................................5
4 TECHNICAL DATA .................................................................................................7
5 MACHINE ACCESSORIES .......................................................................................8
6 MACHINE DESCRIPTION AND FUNCTIONS ............................................................9
7 BASIC SETTINGS ................................................................................................. 16
8 MIG/MAG SYNERGY WELDING .......................................................................... 24
9 PULSE MODE ...................................................................................................... 25
10 WELDING MIG/MAG MANUAL ........................................................................... 25
11 MMA WELDING (ELECTRIC WELDING - ELE) ........................................................ 26
12 CONSUMPTION TABLES ..................................................................................... 27
13 MMA WELDING (ELECTRIC WELDING - ELE) ........................................................ 28
14 MAINTENANCE AND SERVICE TESTS ................................................................... 28
15 ECODESIGN OF WELDING EQUIPMENT ............................................................... 32
16 DISPOSAL OF ELECTRICAL WASTE ....................................................................... 32
17 WARRANTY LETTER ............................................................................................ 33

3/33
ALFA IN a.s. © www.alfain.eu
1 INTRODUCTION
Dear consumer,
Company ALFA IN a.s. thanks you for buying our product and believe that you
will be satisfied with our machine.
Welding machine may be operated only by trained persons and only in the
technical provisions. Company ALFA IN a.s. accept no responsibility for damage
caused by improper use. Before commissioning please read carefully this
manual.
The machine complies with the appropriate CE mark.
For maintenance and repairs, use only original spare parts. There is of course a
complex of our services.
Welding machine SVAROG 320 HD PULSE MODULAR is a modular IGBT
inverter. The machine is designed for welding method MMA, MIG (Metal Inert
Gas) and the MAG (Metal Active Gas) method.
With this machine it is possible to weld various types of joints (blunt, single-sided,
double-sided, corner, overlapped, etc.). Using wires with a diameter of 0.8 to 1.2
and up to 1.6 mm, from various metal materials and alloys (carbon and alloy
steel, aluminium alloys, etc.). They are designed not only for heavy industrial
operations, but also for industries demanding accuracy and speed
S
The machines can be used for welding in areas with increased risk of
electric shock. The machines meet the requirements of the corresponding CE
mark.
We reserve the right to make modifications and changes in case of printing
errors, changes in technical parameters, accessories, etc. without prior notice.
These changes may not be reflected in the user manuals in paper or electronic
form.

4/33
ALFA IN a.s. © www.alfain.eu
2 SAFETY PRECAUTIONS
PERSONAL PROTECTION
1. For safety reasons, protective gloves must be worn during welding. These
gloves protect you from electric shock (circuit voltage at no load). It also
protects you from heat radiation and splashing drops of hot metal.
2. Wear insulated shoes. Open shoes are not suitable as drops of hot metal
can cause burns.
3. Do not look into the welding arc without face and eye protection. Always
use a high-quality welding helmet with an intact protective filter.
4. Notice
Persons with implanted pacemakers must not work with the machine or
move in their immediate vicinity! There is a risk of the stimulator
malfunctioning!
5. Persons in the vicinity of the welding site must also be informed of the
danger and provided with protective equipment.
6. When welding especially in small spaces, it is necessary to ensure a
sufficient supply of fresh air, as welding produces harmful emissions.
7. Do not perform welding work on gas, oil, fuel, etc. Tanks (even empty ones)
as there is a risk of explosion.
8. Special regulations apply in potentially explosive atmospheres.
9. Stop welding immediately if the power cord is damaged. Do not touch this
cable. Unplug it.
10. In areas with an increased risk of electric shock. Only machines marked
with the symbol can be used .
11. Welded joints that are subject to high stress must meet special safety
requirements. These are mainly rails, pressure vessels, etc. These joints
may only be made by qualified trained welders with the necessary
authorization.
SAFETY REGULATIONS
1. Before starting work with the welding machine, it is necessary to get
acquainted with the provisions in ČSN 050601 – Safety provisions for metal
welding and the standard ČSN 050630 – Safety provisions for arc welding
of metals.
2. The CO2 bottle of mixed gases must be handled in accordance with the
regulations for working with pressure vessels contained in ČSN 078305.
3. The welder must use protective equipment.
4. When handling the machine with a lifting device, hook the machine on all
crane eyes. Other mounting is not permitted!
5. Disconnect the device from the mains before carrying out any work on the
electrical system, removing the cover or cleaning it.

5/33
ALFA IN a.s. © www.alfain.eu
MACHINE PROTECTION
This machine is electronically protected against overload. Do not turn off the
main power switch while the machine loaded.
ACL-10 coolant is designed for ambient temperatures up to -10˚C.
Notice
Persons with implanted pacemakers must not operate the machines or move in
close proximity to them! There is a risk of impaired pacemaker function!
3 OPERATING CONDITIONS
1. The commissioning of the instrument may only be carried out by trained
personnel and only within the technical provisions. The manufacturer is not
liable for damage caused by improper use and operation. Only use original
ALFA IN spare parts for maintenance and repair.
2. The device complies with EN 61000-3-12 under the following conditions:
The short-circuit power of the Ssc network at the interface between the user
supply and the public power supply (PCC) shall be at least 4106 kW.
The user is obliged to consult with the electricity supplier whether the
impedance of the network at this location corresponds to the required
value of short-circuit power Zmax = 36 mΩ and whether the device can be
connected to the public low-voltage network.
The following symbols appear on the machine's nameplate: .
3. The welding machine can be manipulated using the crane eyes that are
part of the chassis. The machine can only be handled if it is attached by
all crane eyes. It is forbidden to transport the SVAROG using the eyes if
a gas cylinder is placed on the platform.
4. The welding machine is tested according to the standard for protection
class IP 23S, which provides protection against the ingress of solid bodies
with a diameter greater than 12 mm and against the ingress of water falling
in a vertical to oblique direction up to an inclination of 60°.
5. Operating ambient temperature between -10 and +40 °C.
6. Relative humidity below 90% at +20 °C.
7. Up to 3000 m above sea level.
8. The machine must be positioned in such a way that cooling air can enter
and exit through the cooling vents without restriction. Care must be taken
to ensure that no mechanical particles, especially metal particles (e.g.
during grinding), are drawn into the machine.
9. The handling handle is designed for travelling only, it is not designed for
lifting the machine.
10. If the machine overheats, welding is automatically interrupted and this
condition is indicated by a light.
11. All interventions in the el. equipment, as well as repairs (removal of the
mains plug, replacement of fuses) may only be carried out by an authorised
person.

6/33
ALFA IN a.s. © www.alfain.eu
12. The relevant mains voltage and input power must be matched to the mains
plug.
13. Do not use the machine for other purposes, e.g. defrosting pipes, starter
power, etc.
14. The welding machine must be subjected to a periodic inspection once
every 6/12 months by an authorised person in accordance with ČSN 331500
and ČSN 050630 - see paragraph Maintenance and service tests.
15. The welding machine is primarily designed for industrial environments in
terms of suppression. If other areas are used, special precautions may be
necessary (see EN 60974-10).
16. The stability of the machine is guaranteed up to an inclination of 10° if the
following conditions are met:
a. The machine must be secured against spontaneous movement
b. A gas cylinder with a maximum height of 0.9 m may be placed on the
platform and properly anchored.
17. The machine must be protected against:
a. Moisture and rain
b. Mechanical damage
c. Drafts and possible ventilation of neighbouring machines
d. Excessive overloading - exceeding tech. parameters
e. Rough treatment
f. Chemically aggressive environment
ELECTROMAGNETIC COMPATIBILITY
In terms of interference suppression, the welding equipment is designed
primarily for industrial premises. It meets the requirements of ČSN EN 60974-10
class A and is not intended for use in residential areas where electricity is
supplied by a public low-voltage power supply network. There may be possible
problems with ensuring electromagnetic compatibility in these areas, caused by
line propagation interference as well as radiated interference.
The device may be a source of interference during operation.
Notice
Due to the size of the installed capacity, the approval of the distribution plants
must be required to connect the equipment to the public distribution network. We
warn the user that he is responsible for any interference from welding.

7/33
ALFA IN a.s. © www.alfain.eu
4 TECHNICAL DATA
SVAROG 320 HD PULSE MODULAR
Method MIG/MAG MMA
Mains voltage V/Hz 3x400/50-60
Welding current range A 30/15,5 - 320/30,0 20/20,8 - 300/32,0
Open-circuit voltage U20 V 60,0
Mains protection A 16 @
Max. effective current I 1eff A 15,1 14,1
Welding current (DZ=100%) I2 A 240 200
Welding current (DZ=60%) I2 A 280 240
Welding current (DZ=x%) I2 A 35%=320 30%=300
Protection IP 23S
Standards EN IEC 60974-1, EN 60974-10 cl. A
Dimensions (w x d x h)
generator mm 534 x 1141 x 943
Weight of liquid-cooled
version kg 84
Weight of the air-cooled
version kg 77
Maximum load of the pull-
out
storage box kg 25
Wire speed m/min 1,0 - 20,0 ---
Spool diameter mm 300 ---
Spool weight kg 18 ---
Efficiency % 89
Input power in idle mode P10 W 18
Max.
input
power S
1max
kVA 16,0 15,8
Ambient temperature °C -10 ÷ +40
Insulation class F

8/33
ALFA IN a.s. © www.alfain.eu
5 MACHINE ACCESSORIES
PART OF THE DELIVERY
1. Pulleys for wire diameters 1,0 - 1,2 mm
2. Operating Instructions
3. Torch ARC M6OSW 4m DIGIMIG (M6OSW-DM3-4M)
4. Reducer for wire spool 5 kg and 15 kg
5. 3 m long earthing cable with clamp
6. Hose for gas connection
* Bypass connection of the cooling unit is not included in the standard
delivery.
ACCESSORIES ON REQUEST
See. Catalogue
HOOKAHS TO ORDER
1. M6OSW-DM3-4M Torch ARC M6OSW 4m
2. M22-4M Torch ARC M22 4m 250/220/145A
3. DMB500-4-1 PARKER DIGIMIG 501W 4m aXe UD torch
4. DMB24-4-1 PARKER DIGIMIG 240 4m aXe IN UD Torch
5. DMB36-4-1 Torch PARKER DIGIMIG 360 4m aXe IN UD
6. SGB36-4 PARKER SGB 360 4m Torch
7. DMB24W-4-1 PARKER DIGIMIG 240W 4m aXe IN UD Torch
Notice If you decide to use a torch other than the one above, you must
select according to the current range used and the torch load time. ALFA IN a.s.
is not responsible for damage to welding torches due to overload.

9/33
ALFA IN a.s. © www.alfain.eu
6 MACHINE DESCRIPTION AND FUNCTIONS
MAIN PARTS OF THE MACHINE
Image 1 - Main machine parts
Item. Description
A1 Control panel
A2
Connection cable (re
-
polarity)
A3 Euro torch connector

10/33
ALFA IN a.s. © www.alfain.eu
A4 Coolant reservoir
A5 Quick connector H2O (depends on machine variant)
A6
Quick connector H2O (depends on machine variant)
A7 Quick connector (+)
A8 Quick connector (-)
A9
Gas bottle holder
A10
Coolant filter
A11 Butterfly lock
A12
Main switch
A13
Mains cable
A14 Gas connection connector
A15 Connector for CU and generator connection
A16
Crane eyes
A17
Coolant
drain hole
A18 Wire feeder
A19 Button: wire guide
A20
Wire spool holder
Please note
If the machine is supplied only in the version without chassis, wear-resistant
insulating rails are used as a base.
Separation of the generator from the CU
To separate the generator part from the cooling unit, it is necessary to loosen
the five butterfly nuts A11 and disconnect the connector A15 (electrical
connection between the CU and the generator). The generator can then be
easily manipulated.
WIRE FEED MECHANISM
Figure 2 - Four-fold scroll
Item. Description
E1 Pressure arm nut
E2
Pressure arm
E3
Bovden boot
E4 EURO connector
E5
Pulley

11/33
ALFA IN a.s. © www.alfain.eu
SELECTING A FEED PULLEY
All ALFA IN MIG/MAG machines use double groove pulleys. These grooves are
designed for two different wire diameters (e.g. 0.8 and 1.0 mm).
The wire feed pulleys must be suitable for the diameter and material of the
welding wire. Only in this way can a smooth wire feed be achieved. Irregularities
in wire feed lead to poor welding quality and wire deformation.

 
ABC
Figure 3 - Effect of the pulley on the welding wire
OVERVIEW OF WIRE FEED PULLEYS
ab
4position
a = 19 mm
b =
37
mm
Pulley groove type Wire diameter Order numbers of pulleys
Steel wire
0,6-0,8 4299
0,8
-
1,0
4300
1,0
-
1,2
4301
1,2-1,6 4302
Aluminium wire
1,0
-
1,2
4306
1,2-1,6 4307
1,6-2,0 4308
2,4
-
3,2
4309
Tubular wire
1,0-1,2 4303
1,2
-
1,6
4304
2,4
-
3,2
4305
ADJUSTING THE FEED FOR A DIFFERENT WIRE DIAMETER
All ALFA IN MIG/MAG machines use pulleys with two grooves. These grooves
are designed for two different wire diameters (e.g. 0.8 and 1.0 mm). The groove
A
Correct
B Wrong
C Wrong

12/33
ALFA IN a.s. © www.alfain.eu
can be changed by removing the pulleys and turning them, or by using other
pulleys with grooves of the required dimensions.
1. Unscrew the clamping nuts E1 towards the front of the four-post slide, the
pressure pulleys E2 open upwards.
2. Unscrew the locking part and remove the pulley.
3. If there is a suitable groove on the pulley, turn the pulley over and put it
back on the shaft and secure it by screwing in the piece.
FEED ADJUSTMENT FOR ALUMINIUM WIRE
1. Replace rollers G2 for rollers G2 with U profile of the groove for AL welding.
2. Allow nut G5 on the EURO connector.
3. Replace the Torch used on steel for an aluminium Torch or at least replace
the Torch cable with a teflon one.
4. Remove the capillary from the EURO G1 connector.
5. Trim the end of the teflon bowden cable so that it is close to the G2 feed
pulley. Thread collet G3, o-ring G4, nut G5 on the ned of the teflone cable
brass pipe G7 for stabilization G7. Tighten nut G5.
Place the Torch on the EURO connector G1 and insert the wire into it.
Figure 4 - Feed adjustment for aluminium wire
Item.
Description
G1 EURO connector
G2 Wire feed pulleys
G3
Bovden end cap for 4,0mm, 4,7mm outer diameter
G4 O-ring 3,5x1,5mm
G5 EURO connector nut
G6 Teflon bovden
G7 Bovden support - brass tube
INTRODUCING THE WIRE INTO THE FEED
1. Open the coil cover and release the lock D2 on the coil holder D1. Insert
the wire coil reducer D3 and the wire coil on top of it, secure with lock D2.
Before doing so, ensure that the mandrel is inserted into the appropriate
hole in the wire reducer or coil.
2. If necessary, it is possible to adjust the braking force with screw D4 so that
the wire does not unwind from the spool after the wire feed has stopped.
3. Cut the end of the wire attached to the edge of the coil and feed it into the
bovden E3 through the pulleys E5 and about 5 cm inside the EURO

13/33
ALFA IN a.s. © www.alfain.eu
connector tube E4. Check that the wire runs through the correct groove of
the pulley.
4. Fold down the pressure arms E2 and return the clamping nuts E1 to the
vertical position.
5. Adjust the pressure of the clamping nut to ensure smooth movement of the
wire without deforming the wire. Press button A13, located in the feed area
of the machine, to start the feed motor. The adjustment screw is located
under the plastic screws E1.
6. The coil brake is set by the manufacturer. If necessary, it can be adjusted
with screw D4 so that when the feed stops, the coil stops in time and the
wire does not become too loose. However, an over-tightened brake puts
unnecessary stress on the feeding mechanism and can cause the wire to
slip in the pulleys.
Figure 5 - Wire spool holder
ADJUSTING THE CLAMPING FORCE OF THE FEED PULLEYS
The amount of clamping force of the feed pulleys is important for the reliable
operation of the feeding mechanism.
The amount of force depends on the type of welding wire, for aluminium or
tubular wire we choose a smaller clamping force.
If the clamping force is insufficient, the pulleys slip and the feed rate becomes
irregular.
If the pressure force is too high, the mechanical wear of the bearings increases,
the pressure mechanism does not fulfil its protective function and in case of
increased resistance of the wire feed (damaged or contaminated bovden, baked
wire in the grommet, etc.), the wire does not slip and there is a risk of the wire
being displaced to the side. In the extreme case, the motor may be completely
blocked and the gearbox will be unduly mechanically stressed, the electric motor
and the power output of the controller will be overloaded and may be damaged.
Clean the pulleys of canned oil before starting.
Item.
Description
D1
Coil holder
D2 Fuse
D3
Wire spool reducer
D4 Screw - brake force
adjustment

14/33
ALFA IN a.s. © www.alfain.eu
INTRODUCTION OF THE WELDING WIRE INTO THE TORCH AND
CONNECTION OF THE EARTHING CABLE
1. Connect the grounding pliers to the welding machine or welding table.
2. Caution Do not point the torch against the eyes when inserting the
wire!
3. Screw the central torch tip to the A3 connector on the machine with the
machine switched off.
4. Remove the gas nozzle from the Torch.
5. Unscrew the current feedthrough.
6. Connect the machine to the network.
7. Turn the main switch to position I.
8. Press button A13 located in the feed area of the machine to start the feed
motor. The welding wire is fed into the torch. After the wire has been run
out of the torch tube, screw on the current pass and the gas nozzle.
9. Before welding, spray the area in the gas nozzle and the jet line with a
separating spray to prevent spatter from sticking.
GAS FLOW ADJUSTMENT
The electric arc and the melt bath must be perfectly protected by gas. Too little
gas cannot create the necessary protective atmosphere; on the contrary, too
much gas entrains air into the electric arc.
Warning The gas cylinder must be well secured against falling. This
manual does not address the safe securing of the gas cylinder. Information can
be obtained from the supplier of industrial gases.
1. Attach the gas hose to the gland on the rear panel of the machine.
2. Press button V1 (fig. 7) on the main panel to switch on the gas valve. If the
button is pressed for less than 3 s, the gas valve will be switched off when
the button is released. If the button press time is longer than 3 s, the gas
valve will be switched off after approx. 20 s or after pressing any button.
3. Turn the adjusting screw F7 on the bottom of the pressure reducing valve
until the flow meter F6 shows the desired flow, then release the button.
The optimum flow rate is 10-15l/min.
4. After a prolonged machine shutdown or torch change, it is advisable to
purge the pipe with shielding gas before welding.
Figure 6 - Gas flow settings
Item. Description
F1
Bottle
F2 Bottle valve
F4 Reducing valve
F5 High pressure manometer
F6 Low pressure manometer
F7 Adjusting screw
F8 Gas valve

15/33
ALFA IN a.s. © www.alfain.eu
WATER TORCH COOLING SYSTEM
1. The cooling unit is located at the bottom of the machine.
2. The pump seal in this ALFA IN welder is specially designed for ACL-10
fluid (pink, order no. 4600, 5 l canister.
Operating range - ambient temperature -10 °C to +40 °C).
3. Leakage of the cooling circuit may occur if other fluids are used.
A failure of the cooling circuit using a fluid other than ACL-10 cannot be
covered under the manufacturer's warranty.
4. We recommend a complete fluid change every one to three years. The
fluid must not be mixed with any other type of fluid. The procedure for
changing the fluid can be found at
https://www.alfain.eu/static/_dokumenty/1/2/9/7/1/1/Vymena-chladici-
kapaliny1-navod-CZ.pdf
5. Keep the coolant level in the coolant reservoir
within the permitted range (see picture). The
fluid level is visually visible on the front of the
reservoir. Use the fluid prescribed by the
manufacturer.
If the error message "Err 2" - Low fluid
pressure lights up during operation, turn off
the main switch and check the coolant level.
After switching on the machine, test the cooling unit. If the error recurs, the
cause of the fault must be determined.
6. ACL-10 liquid is not poisonous. However, due to its operation in the pump,
treat the replaced fluid as hazardous waste. Do not pollute the
environment. In the worst case, take it to a salvage yard in its original
canister. The safety data sheet can be found at
https://www.alfain.eu/static/_dokumenty/1/2/8/8/0/4/Bezpecnostni-list-
ACL-10.pdf
7. Note: When connecting a gas-cooled torch, it is necessary to connect the
water quick couplings with the liquid circuit connection hose! Failure to do
so may result in damage to the pump.

16/33
ALFA IN a.s. © www.alfain.eu
VENTING OF THE TORCH COOLING SYSTEM
1. After filling an empty torch cooling system or after refilling the fluid after a
large leak and aeration, a complete venting of the circuit is required.
2. Remove the coolant reservoir cap and connect the water quick couplers
with the fluid circuit connecting hose.
3. Run the cooling test for about 30 seconds.
4. Connect the torch and run the cooling test for about 30 seconds.
5. If the error message "Err 2" - Low fluid pressure lights up after pressing
the torch button, the procedure must be repeated.
COOLING UNIT CONVERSION KIT
The machine with a pull-out storage box can be converted to a water-cooled
version. A conversion KIT E.466 is required. The conversion KIT has to be built
into the existing pull-out storage box. We will send you the conversion
instructions together with the conversion kit E.466.
7 BASIC SETTINGS
DESCRIPTION OF THE CONTROL PANEL
Figure 7 - Control Panel
Item. Description
V1
Button
:
gas
test
V2
Button
:
Pulse
mode
V3 LED - shines when PULSE mode is selected.
V4 Quick JOB selection

17/33
ALFA IN a.s. © www.alfain.eu
V5
Encoder
2 + confirmation button
V6 LED -
lights up when the material thickness is displayed on the left
display.
V7 LED -
lights up when the wire feed speed is displayed on the left
display
.
V8 Button: Select synergy display
V9 LED - lights up when the left display shows the current -
the expected
value the welder wants.
V10
The display shows:
1. Welding current size
2. The size of the welding current in the electrode
3. Feed rate
4. Material thickness
5.
Secondary parameter name
V11
The display shows:
1. Welding voltage size
2. Correction
3. The value of the choke
V12
LED
-
shine
when voltage data is displayed on the right display
V13 Button: Correction selection
V14 LED - lights up when wire feed speed correction is set
V15 LED - shines when the right display shows data about the choke
V16
Encoder
1
V17 LED - shines when 2T mode is selected
V18 LED - shines when 4T mode is selected
V19
LED
-
shine
when stair mode is selected
V20
Button:
2T/4T/stairs
SELECTION OF THE WELDING METHOD
1. Long press encoder V5 to enter the method selection menu.
2. Rotate encoder V5 to select ELE (coated electrode MMA), MAN
(MIG/MAG manual), SYN (MIG/MAG synergic). Confirm the selected
method by pressing encoder V5.
3. For the SYN method, use the V16 encoder to set the synergy program
number.
SYN METHOD
The synergy curves are welded in the PB position (fillet weld, horizontal, inclined
from above). For welding in other positions, parameter correction is necessary.
AXE 250-320 PULSE SMART (AL) ø 0.8 ø 1.0 ø 1.2
SG/Fe With 82% CO2 18% 0 * 1 * 2 *
SG/Fe With 92% CO2 8% 3 * 4 * 5 *

18/33
ALFA IN a.s. © www.alfain.eu
SG/Fe CO2 100% 6n 7n 8n
Cr/Ni 308 With 97.5% CO2 2.5% 9 * 10 * 11 *
Cr/Ni 316 With 97.5% CO2 2.5% 12 * 13 * 14 *
CuSi 3 With 100 % 15 * x x
AlMg With 100 % x 16 ** 17 **
AlSi With 100 % x 18 ** 19 **
Table of synergy programmes
* - Use the V2 button to switch the pulse mode on/off.
** - Can only be welded in pulse mode and is only available for AL machines.
n - Cannot weld in pulse mode.
1. The SYN is displayed on the left display V10 and the synergy curve
number is displayed on the right display V11.
2. Use encoder V16 to select the synergy curve (program number). Confirm
the selected program number by pressing encoder V5.
WELDING CIRCUIT CALIBRATION
The welding characteristics of the synergistic curve depend on many factors,
such as the length of the welding torch, the length of the grounding cable, the
quality of the grounding, the distance of the weldment from the grounding point,
etc. It is therefore advisable to calibrate the welding circuit for the actual welding
conditions.
1. Press button V20 and encoder V5 simultaneously to enter the secondary
parameters menu.
2. Select the CAL parameter with the V5 encoder, press to confirm
3. Set CrE with encoder V5, press to confirm.
4. Unscrew the gas nozzle of the welding torch.
5. Cut the welding wire close to the welding nozzle.
6. Pull a piece of welding wire (approx. 50 mm) into the wire feed. There must
now be no welding wire in the jet nozzle.
7. Apply slight pressure to the welding torch with the jet nozzle on a clean
and cleaned area of the workpiece, press the torch button and hold it down
for approx. 2 seconds. A short-circuit current flows for a while, by means
of which the new circuit resistance is determined and displayed. (The value
can be 0 mΩ to 60 mΩ - these values are not important for the user, factory
setting CrE = 10 mΩ, the value can be set badly with the V16 encoder).
8. If an error occurs, Err is displayed on the right display of V11, the
measurement must be repeated.

19/33
ALFA IN a.s. © www.alfain.eu
9. Confirm the measured value by pressing encoder V5, exit the menu by
pressing any button twice.
10. Screw on the gas nozzle of the welding torch.
11. Insert the welding wire.
QUICK JOB SELECTION - MEMORY
Works for all welding methods.
1. Long press (4s) of one of the V4 buttons (1,2,3,4,5,6) will save the set
parameters to the memory.
2. JOBs are stored as active (they can be switched by remote control on the
torch).
3. A short press of one of the V4 buttons (1,2,3,4,5,6) will retrieve the stored
parameters from memory.
4. If no JOB is stored for the desired position, the display will show No Job.
WELDING MODE 2T - TWO-STROKE
Works for both MIG/MAG welding methods.
Use the V20 button to switch between the 2T , 4T and modes.
If the V17 light is on, the machine is set to two-stroke mode. The first stroke is
to press the torch button and keep it pressed, the machine will start the welding
process. The second stroke means to release the torch button, the machine
stops the welding process.
WELDING MODE 4T - FOUR STROKE
Works for both MIG/MAG welding methods.
Use the V20 button to switch between 2T , 4T and modes. If
the V18 light is on, the machine is set to 4-stroke mode. The first stroke is to
press the torch button and keep it pressed, the machine will start the welding
process. The second stroke means to release the torch button, the machine
continues the welding process. The third stroke means to press the torch button,
the welding process continues. The fourth stroke means to release the torch
button, the machine stops the welding process.
WELDING MODE 2T - DOUBLE STAIRS
Works for both MIG/MAG welding methods (only in SYN mode).
Press the V20 button to switch between the 2T , 4T and
modes. If the V17 and V19 lights are on, the machine is set to two-stroke stair
mode. The first stroke means to press the torch button and keep it pressed, the
machine will start welding with the starting current SCu for the starting current t

20/33
ALFA IN a.s. © www.alfain.eu
S. Then the machine will start welding with the main welding current (100%) after
the start-up time tuP. The second stroke means to release the torch button, the
machine will start welding with the end current ECu for the end current t E after
the start-up time tdo.
WELDING MODE 4T - FOUR STAIRS
Works for both MIG/MAG welding methods.
Press the V20 button to switch between the 2T , 4T and
modes. If the V18 and V19 lights are on, the machine is set to the 4-stroke stair
mode. The first stroke is to press the torch button and keep the button pressed,
the machine will start welding with the starting current SCu. The second stroke
means to release the torch button, the machine will start welding with the main
welding current (100%) after the ramp-up time tuP. The third stroke means to
press the torch button, the machine will start welding with the end current ECu
after the ramp-down time tdo. The fourth stroke means to release the torch
button, the machine stops the welding process.
BILEVEL bCu ≠ 100 %
The difference of the BILEVELU compared to the classical steps is in the second
stroke, when by quickly pressing and releasing the torch button the machine
switches between the two set main welding currents.
Figure 8 - Mode curves
