Alfalaval HEV Series Configuration guide

General information & application
HEV door curtains are equipped with a water coil and gener-
ate a downward flow of warm air for a comfortable working
conditions in draughtfree surroundings with even tempera-
tures, even close to door openings.
HEV door curtains are designed for application in shops, fac-
tory halls and warehouses at entry doors, door openings of
loading areas and for doorways between spaces with differ-
ent temperatures to reduce draught at floor level, energy con-
sumption and eliminate humidity transfer. Thanks to a long air
throw, HEV door curtains are also applicable for local heating
of high room spaces.
Door curtains improve the level of comfort, increase the use-
ful area by reducing draught near to door openings and save
heating costs. The best door curtain effect is reached when
ventilation is balanced and the door opening is protected
from wind.
Characteristics
• Warm, effective door curtain
• Low sound level
• Three fan speed alternatives
• Adjustable air flow direction
• Possible to install either visible
or, if required, above the ceiling
• Minimized need of service
• Easy to install and operate
Construction
The frame construction is made of plastic coated, hot dip gal-
vanized steel plate, standard colour white RR20 (RAL 5820).
The heat transfer section is manufactured of copper tubes
and aluminium fins. Water is used as heat transfer medium.
The maximum working pressure of the finned coil is 10 bar.
The scattered fin spacing of the effective finned coil prevents
dust or dirt from gathering on it, and therefore a filter is not
needed. The heat transfer section is equipped with drainage.
Fans
The fans are centrifugal fans with low sound level.
The 1-phase motors have inbuilt overload protection (auto-
matic reset) and they are pre-wired to the joint junction box.
Protection class is IP23.
The air flow can be regulated by connecting the motor with
the selected fan speed or by using the fan speed regulator.
The maximum fan speed (3) is pre-set at the factory. The fan
speed can also be regulated by external control (see page 3).
Fan speed control is available as an optional extra (incl.
0-position and 3 alternative positions (separate delivery,
dimensions W64xH80xD75 mm).
Selection example
Door opening width is 3 m and maximum required heating
capacity 42 kW. The dimensioning temperature of water is
70/40°C, incoming air temperature is 20°C.
Model HEV-215 is selected, width 1.5 m, so two units are
needed. According to capacity table the capacity of HEV-215
at fan speed 3 is 21 kW, water flow is 0.17 l/s and flow resist-
ance is 4.5 kPa.
HEV
HEV
Door Curtains
Draught,
humidity
Dust,
exhaust
gases
Indoor air

How to contact Alfa Laval
Up-to-date Alfa Laval contact details for
all countries are always available on our
website at www.alfalaval.com
ECF00348EN 1203 Alfa Laval reserves the right to change specification without prior notification.
Installation and maintenance
HEV door curtains can be installed at the desired height by
using ceiling brackets. Wall brackets (SK) are available as
an optional extra. Electrical connections and service activi-
ties are done through a service hatch. If the door curtain is
installed above the ceiling, sufficient compensation air must
be ensured through adequately sized ceiling openings.
HEV 110 = 0.3 m2
HEV 215 = 0.5 m2
HEV 320 = 0.6 m2
A
A
Ceiling or wall mounting
Mounting on ceiling level Mounting above ceiling
HEV
Air on tem-
perature
[°C]
Fan
speed
Air flow 80/40 70/40 60/40 55/35
[m3/s] Capacity
[kW]
Water
[l/s]
dP
[kPa]
Capacity
[kW]
Water
[l/s
dP
[kPa]
Capacity
[kW]
Water
[l/s
dP
[kPa
Capacity
[kW]
Water
[l/s
dP
[kPa
110
10
1 0,22 9,7 0,06 0,4 11,2 0,09 0,6 10,6 0,13 1,1 9,0 0,11 0,8
2 0,36 14,0 0,09 0,8 12,8 0,10 1,2 11,9 0,14 2,3 10,2 0,13 1,8
3 0,54 18,4 0,11 1,4 16,9 0,13 2,1 16,2 0,19 4,2 13,4 0,16 2,9
15
1 0,22 8,4 0,05 0,3 9,4 0,08 0,4 9,0 0,11 0,8 7,3 0,09 0,5
2 0,36 12,2 0,07 0,6 11,1 0,10 0,9 10,2 0,12 1,7 8,4 0,10 1,2
3 0,54 16,0 0,01 1,1 14,6 0,12 1,6 13,4 0,16 2,9 11,1 0,13 2,1
20
1 0,22 6,1 0,04 0,1 7,4 0,06 0,2 7,3 0,09 0,5 5,0 0,06 0,2
2 0,36 10,3 0,06 0,4 9,3 0,08 0,6 8,5 0,10 1,2 6,6 0,08 0,7
3 0,54 13,6 0,08 0,8 12,2 0,10 1,1 11,1 0,14 2,9 8,7 0,10 1,3
215
10
1 0,32 15,7 0,01 1,5 18,8 0,15 2,3 17,8 0,22 4,9 14,8 0,18 3,1
2 0,53 22,7 0,14 3,0 21,0 0,17 4,5 19,3 0,23 8,2 16,6 0,20 6,3
3 0,78 31,2 0,19 5,4 28,6 0,23 8,0 25,9 0,31 14,3 22,5 0,27 11,1
15
1 0,32 14,0 0,09 1,2 16,3 0,13 1,4 15,2 0,19 3,5 12,4 0,15 1,9
2 0,53 20,1 0,12 2,4 22,5 0,18 3,4 16,7 0,20 6,3 13,8 0,17 4,4
3 0,78 27,3 0,17 4,2 24,9 0,20 6,2 22,5 0,27 11,0 18,9 0,23 6,0
20
1 0,32 12,2 0,07 0,9 13,9 0,11 1,1 12,4 0,15 2,1 10,0 0,12 1,3
2 0,53 17,5 0,11 1,8 15,5 0,13 2,5 13,9 0,17 4,4 11,1 0,14 3,0
3 0,78 22,9 0,14 3,0 21,0 0,17 4,5 19,0 0,23 8,0 14,7 0,18 5,0
320
10
1 0,45 21,5 0,13 1,2 24,1 0,20 0,9 22,5 0,27 1,7 19,2 0,23 1,3
2 0,71 30,5 0,19 2,4 27,7 0,23 3,4 30,9 0,37 3,6 25,4 0,31 2,2
3 1,05 41,6 0,25 4,2 38,3 0,31 6,3 34,9 0,42 10,3 30,2 0,37 8,8
15
1 0,45 19,1 0,12 0,9 20,7 0,17 0,7 19,2 0,23 1,3 15,6 0,19 0,9
2 0,71 27,0 0,17 1,9 24,3 0,20 2,6 25,6 0,31 2,4 21,0 0,26 1,6
3 1,05 35,9 0,22 3,2 33,2 0,27 4,8 30,2 0,37 3,6 25,1 0,30 6,2
20
1 0,45 16,6 0,10 0,7 16,9 0,14 0,4 15,8 0,19 0,9 12,1 0,15 0,5
2 0,71 23,4 0,14 1,4 20,8 0,17 2,0 21,3 0,26 1,6 16,0 0,19 0,9
3 1,05 30,7 0,19 2,4 27,4 0,22 3,3 25,3 0,31 6,2 19,7 0,24 3,9
HEV - 110 - NV - SK
Wall bracket
Fan speed control
Size
Type
Dimensions, electric current values
HEV L
[mm]
E
[mm]
Net weight
[kg]
Int. Vol.
[L]
1/230 V 50Hz
Max. curr.
[A]
Capacity
[W] Speed Lpa *) Lwa **)
110 1000 830 35 3 2 147
1 42 51
2 54 63
3 62 71
215 1500 1330 55 4 3 294
1 45 54
2 58 67
3 64 73
320 2000 1830 70 5 4 294
1 46 55
2 60 69
3 65 74
2
1 m
2 m
3 m
4 m
10 m/s
4 m/s
3 m/s
Speed 3
3 m/s
1
3 m/s
*) Lpa is the A-weighted sound pressure level
dB(A),measured on a hard surface (hall of 50 sqm.,
Sabine), 2 meters under the equipment
**) Lwa is the A-weighted sound power level,
measured according to ISO3741
Max. air velocity at diff.
distances (free space, max.
air safe temp. 20°C)

Factory setting
Air flow can be regulated by a 3-phase fan speed regulator,
or by setting the selected fan speed as standard.
Examples of fan speed control
The contactors are not included in the delivery.
HEV-110 does not need any contactors.
Fan speed selection by central unit
The fan speed can be selected either by time control circuits
of the electric central unit or by DDC system. Connect the
contactors as shown in the figure! Please note that only one
contactor at a time can be switched.
Parallel coupling of HEV units
The fan speed can be selected by fan speed regulator NV,
by time control circuits of the electrical central unit or by DDC
system. The contactors are connected as shown. By NV fan
speed control 20 units can be controlled. Each unit needs 3
contactors.
Fan speed selection by a 3-phase thermostat
Thermostat contacts are shown at low temperature position.
At higher temperature first the left contact changes its posi-
tion, next the contact in the middle and last the right contact.
When the temperature is getting lower, the contacts change
their position in reverse order.
How to contact Alfa Laval
Up-to-date Alfa Laval contact details for
all countries are always available on our
website at www.alfalaval.com
ECF00348EN 1203 Alfa Laval reserves the right to change specification without prior notification.
Fan speed regulator NV
Connect fan speed regulator according
to instructions.
white blue white blue
red gray
blue brown
black black
yellow/green yellow/green
red gray
blue brown
black black
yellow/green yellow/green
Fan speed Fan speed
Fan speed
Fan speed
Fan speed
control voltage
control voltage
Remove connection bar
Remove wire connect
Remove connection bar
Remove wire connect
Remove connection bar
Remove wire connect
