Alfa Laval CM Connect
Condition monitoring
BRITISH ENGLISH
2067-0021
Lit. Code 200005871-2-EN-GB Instruction manual

Published by
Alfa Laval Kolding A/S
Albuen 31
DK-6000 Kolding, Denmark
[phone]
The original instructions are in English
© Alfa Laval AB 2024-02
This document and its contents are subject to copyrights and other intellectual property rights owned by Alfa Laval AB (publ) or any of its affiliates (jointly “Alfa Laval”). No part of this
document may be copied, re-produced or transmitted in any form or by any means, or for any purpose, without Alfa Laval’s prior express written permission. Information and services
provided in this document are made as a benefit and service to the user, and no representations or warranties are made about the accuracy or suitability of this information and these
services for any purpose. All rights are reserved.

Contents
1 Declarations of Conformity.................................................................................5
1.1 EU Declaration of Conformity....................................................................................5
1.2 UK Declaration of Conformity....................................................................................6
2 Safety............................................................................................................................... 7
2.1 Purpose of this manual..............................................................................................7
2.2 Warning Signs in Text................................................................................................7
2.3 Safety Instructions and Warnings..............................................................................8
2.3.1 Safety Signs.................................................................................................8
2.3.2 General Safety Precautions......................................................................... 8
2.4 Recycling Information................................................................................................8
3 Introduction...................................................................................................................9
3.1 About CM Connect.................................................................................................. 10
4 Installation................................................................................................................... 11
4.1 Power Supply Connector.........................................................................................12
4.2 Setting Up the CM Connect.....................................................................................13
4.3 Link CM to CM Connect (gateway)..........................................................................15

This page is intentionally left blank.

1 Declarations of Conformity
1.1 EU Declaration of Conformity
The Designated Company
Alfa Laval Kolding A/S, Albuen 31, DK-6000 Kolding, Denmark, [phone]
Company name, address and phone number
Hereby declare that
CM Connect
Designation
Condition Monitor
Type
is in conformity with the following directives with amendments:
• EMC - Directive 2014/30/EU
• RED 2014/53/EU
• RoHS Directive 2011/65/EU and amendments
The person authorised to compile the technical file is the signer of this document.
Global Product Quality Manager Lars Kruse Andersen
Title Name
Kolding, Denmark 2023–06–01
Place Date (YYYY-MM-DD) Signature
This Declaration of Conformity replaces Declaration of Conformity dated 2018–10–01
200005871-2-EN-GB 5
EN

1.2 UK Declaration of Conformity
The Designated Company
Alfa Laval Kolding A/S, Albuen 31, DK-6000 Kolding, Denmark, [phone]
Company name, address and phone number
Hereby declare that
CM Connect
Designation
Condition Monitor
Type
is in conformity with the following directives with amendments:
• The Electromagnetic Compatibility Regulations 2016
• The Radio Equipment Regulations 2017
• The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regu-
lations 2012
Signed on behalf of: Alfa Laval Kolding A/S
Global Product Quality Manager Lars Kruse Andersen
Title Name
Kolding, Denmark 2023–06–01
Place Date (YYYY-MM-DD) Signature
DoC Revison_02_062023
200005871-2-EN-GB6
1 Declarations of ConformityEN

2 Safety
Read this first
WARNING
Failure to observe the instructions contained in this manual could result in personal injury
and property damage, and may void the warranty. Read this manual carefully before instal-
ling and using the product.
2.1 Purpose of this manual
NOTE
Save this manual for future reference and keep it readily available. For detailed use of product guidance,
consult the Alfa Laval CM Connect App. Requesting other information for instructions, situations, or events
that are not considered in this manual or in the sales documents, please contact your local Alfa Laval
representative. Always specify the exact product type and identification code when requesting technical
information or spare parts.
The purpose of this manual is to provide necessary information for:
•Installation
•Safety
•Recycling
•Troubleshooting
•Related documents
2.2 Warning Signs in Text
Pay attention to the safety instructions in this manual.
Below are definitions of the four grades of warning signs used in the text where there is a risk for
injury to personnel or product damage.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate damage
on the product.
NOTE
Indicates important information to simplify or clarify procedures.
200005871-2-EN-GB 7
EN

2.3 Safety Instructions and Warnings
2.3.1 Safety Signs
!
General warning.
Hot surfaces.
2.3.2 General Safety Precautions
!
Installation
This product should only be installed/commissioned by instructed or otherwise competent
personnel.
Hot surfaces
When mounting the CM Connect to external equipment, such as pump gearboxes, be
aware of potential hot surfaces, and always wear appropriate protective equipment.
The CM Connect can be mounted on surfaces up to 80° C (176° F).
!
Temperature
Only expose the CM Connect to ambient temperatures within −30° C to 70° C (22° F to
158° F)].
WARNING
Heating above these temperatures could result in serious injury. Never dispose of the
CM Connect in a fire, this could result in serious injury.
How to contact Alfa Laval
Contact details for all countries are continually updated on our website.
Please visit www.alfalaval.com to access the information directly.
2.4 Recycling Information
NOTE
The CM Connect should be handled according to local rules for WEEE “small IT and communications
equipment”.
200005871-2-EN-GB8
2 SafetyEN

3 Introduction
The ability to determine the current running condition of equipment and
whether service or maintenance is necessary is paramount to keeping plant
and processes running efficiently and cost effective. Having this overview
whilst at your desk or on your mobile device without needing to collect data
from the process floor increases plant safety.
The Alfa Laval CM Connect is a compact, easy to use, cloud-based gateway
which allows the user to connect and remotely monitor the condition and
changes in running behaviour of rotating equipment. Providing users via built-
in wireless cellular technology with easy, safe data, accessed remotely from a
PC or handheld mobile device to enable them to optimise their process
uptime, assist in maintenance scheduling and efficiency and reduce operating
costs.
The Alfa Laval CM Connect is used as a gateway for up to 10 Alfa Laval CMs
connected within Bluetooth range.
All data and alerts are stored in the cloud and can be accessed for easy
record keeping and troubleshooting.
In addition, unique identification can provide the user with service data of the
equipment and contacts of service partners to ease the maintenance process,
ensuring asset value, total cost of ownership and process continuity.
200005871-2-EN-GB 9
EN

3.1 About CM Connect
The CM Connect is a compact, easy to use, cloud-based gateway which allows the user to connect
and remotely monitor the condition of pumps. The CM Connect communication is performed
wirelessly. Via the built-in cellular solution, pumps from critical equipment and application information
can be accessed anytime and anywhere from a PC or handheld device.
The CM Connect can be connected to up to 10 Alfa Laval Condition Monitors (CM) via Bluetooth
which measures equipment vibration and temperature.
All data and alerts are stored in the cloud and can be accessed for easy record keeping and
troubleshooting.
b
c
a
a) Connected devices and services
b) Cellular 4G data-connection
c) BLE connection up to 10 CMs per gateway
NOTE
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
200005871-2-EN-GB
10
3 IntroductionEN

4 Installation
How to mount the CM Connect:
Wall mounted acting as a gateway only.
The CM Connect should be mounted on the wall utilizing two flat or conehead screws (not included).
86 mm / 3.38”
x2: 5.25 mm / 0.21”
86 mm / 3.38”
102 mm / 4.02”
AB
2067-0022
116 mm / 4.56”
40 mm / 1.57”
200005871-2-EN-GB 11
EN

4.1 Power Supply Connector
Power supply specifications 24VDC, 7 – 15W
2067-0023
1
2
3
4
Wiring diagram - power supply connector
PIN1 Power supply 24VDC (brown)
PIN2 Future option
PIN3 Power supply GND (blue)
PIN4 Future option
Power connector cables can be ordered through Alfa Laval using following article numbers:
Cable M12 4 wire female
straight connector 10m [30Ft] length For wall mount 8010000289
200005871-2-EN-GB12
4 InstallationEN

4.2 Setting Up the CM Connect
NOTE
Ensure there is 4G mobile coverage at the installation location.
1Mount the CM Connect (see section
Installation on page 11).
2Connect M12 cable to power (order
separately) as illustrated in section
Installation on page 11.
3Register device for activation of first 12
months of connected services. Scan the QR
code.
2067-0026
Manufacturer: Alfa Laval Kolding A/S
Albuen 31, 6000 Kolding, Denmark
Type: CM Connect
Device ID XXXXX
Service enquiries: www.alfalaval.com
Device ID XXXXX
4The CM Connect is accessed through web
browser access. Go to www.cm-connect.com.
2067-0024
For PC:
For mobile device:
1.
2. and open the
3.
CM Connect product
page on
5For new and existing users: Follow instruction
from the registration form.
200005871-2-EN-GB 13
Installation 4 EN

6When registration is completed – wait
minimum 2 minutes until the device LED
enters heartbeat mode (connected to CM
Connect server).
a) Searching for cellular network.
(Single blinking led).
b) Connected to cellular network.
(Double blinking led).
c) Connected to CM-Connect server.
(Pulsating heartbeat led).
ON
OFF
2067-0027
ON
OFF
ON
OFF
a
b
c
7If there are any issues during the registration
process please contact Alfa Laval Customer
Support.
200005871-2-EN-GB14
4 InstallationEN

4.3 Link CM to CM Connect (gateway)
Install and commission the CM on the equipment as described in the CM manual.
1Now enter the setup screen and scan for
CMs (the CMs must be within Bluetooth
range from the CM Connect.
2067-0028
2A list of available CMs will appear in the
devices in range list.
2067-0029
3Use the function "Add to gateway" to link the
wanted CMs to this gateway. Remember to
save the selection.
