ALFAtron ALF SDIW Series User manual

www.alfatronelectronics.com
ALFATRON ELECTRONICS GmbH GERMANY
ALF-30X-SDIW, ALF-20X-SDIW, ALF-20X-SDI
User Manual

Alfatron ALF-XXX-SDIW
1
Attention
This manual introduces functions, installations, and operations for this PTZ camera in detail. Please read this manual
carefully before installation and use.
Cautions
Avoid damage to the product caused by heavy pressure, strong vibration, or immersion during transportation, storage,
and installation.
Housing of this product is made of organic materials. Do not expose it to any liquid, gas, or solids that may corrode the
shell.
Do not expose the product to liquid or moisture.
To prevent the risk of electric shock, do not open the housing. Installation and maintenance should only be carried out
by qualified technicians.
Do not use the product beyond the specified temperature, humidity, or power supply specifications.
Wipe it with a soft, dry cloth when cleaning the camera lens. Wipe it gently with a mild detergent if needed. Do not use
strong or corrosive detergents to avoid scratching the lens and affecting the image.
This product contains no parts which can be maintained by users themselves. Any damage caused by dismantling the
product by the user without permission voids the warranty.
Electrical Safety
Installation and use of this product must strictly comply with local electrical safety standards.
The power supply of the product is ±12V, the max electrical current is 2A.
Installation
Do not rotate the camera head forcefully, it may cause mechanical failure.
This product should be placed on a stable desktop or another horizontal surface. Do not install the product obliquely,
otherwise, it may display an inclined image.
Ensure there are no obstacles within the rotation range of the holder.
Do not power on before completing the installation.
Magnetic Interference
Electromagnetic fields at specific frequencies may affect the video image. This product is Class A. It may cause radio
interference in the household application. The appropriate measure is required.

Alfatron ALF-XXX-SDIW
2
FCC Statement
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
---Reorient or relocate the receiving antenna.
---Increase the separation between the equipment and receiver.
---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
---Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Radiation Exposure
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the device.
Radiation Exposure:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.
Do not dispose of this product with the normal household waste at the end of its life cycle. Return it to a collection point for the
recycling of electrical and electronic devices. This is indicated by the symbol on the product, user manual or packaging. The
materials are reusable according to their markings. By reusing, recycling or other forms of utilisation of old devices you make an
important contribution to the protection of our environment. Please contact your local authorities for details about collection
points.

Alfatron ALF-XXX-SDIW
3
Content
www.alfatronelectronics.com............................................................................................................................................0
ALFATRON ELECTRONICS GmbH GERMANY ..........................................................................................................0
1. Fast Installation .................................................................................................................................................................5
1.1 Camera Interface Explanation.................................................................................................................................5
1.2 Initial power on configuration.................................................................................................................................5
1.3 Video Output...........................................................................................................................................................5
2. Product overview ..............................................................................................................................................................6
2.1 Product Introduction...............................................................................................................................................6
2.1.1 Dimension .............................................................................................................................................6
2.1.2 Accessory .....................................................................................................................................................6
2.2 Main Features .........................................................................................................................................................7
2.2.1 Camera Performance ...................................................................................................................................7
2.2.2 Network performance..................................................................................................................................7
2.3 Technical Specification ............................................................................................................................................8
2.4 Interface Instruction................................................................................................................................................9
2.4.1 External Interface.........................................................................................................................................9
2.4.3 RS-232 Interface ...........................................................................................................................................9
3. Application Instruction.................................................................................................................................................... 11
3.1 Video Output.........................................................................................................................................................11
3.1.1 Power-On Initial Configuration...................................................................................................................11
3.1.2 Video Output..............................................................................................................................................11
3.2 Remote Controller................................................................................................................................................. 11
3.2.1 Keys Instruction..........................................................................................................................................................11
3.2.2 Applications................................................................................................................................................12
3.3 MENU SETTING .....................................................................................................................................................14
3.3.1 Main Menu.................................................................................................................................................14
3.3.2 System Setting............................................................................................................................................14
3.3.3 Camera Setting...........................................................................................................................................15
3.3.4 P/T/Z ...........................................................................................................................................................17
3.3.5 Video Format..............................................................................................................................................18
3.3.6 Version........................................................................................................................................................18
3.3.7 Restore Default...........................................................................................................................................18
4. Network Connection ...............................................................................................................................................19
4.1 Connecting Mode:.........................................................................................................................................19
4.2 IE Log In .................................................................................................................................................................22
4.2.1 Web client ..................................................................................................................................................22
4.2.2 Preview.......................................................................................................................................................22
4.2.3 Configuration..............................................................................................................................................22
4.2.5 Video configuration....................................................................................................................................23
4.2.6 Network configuration ...............................................................................................................................25
4.2.7 System configuration..................................................................................................................................25
4.2.8 Logout ........................................................................................................................................................26
5. Serial Communication Control ........................................................................................................................................27
5.1 VISCA protocol list .................................................................................................................................................27

Alfatron ALF-XXX-SDIW
4
5.1.1 Camera return command...........................................................................................................................27
5.1.2 Camera control command..........................................................................................................................27
5.1.3,Inquiry command.......................................................................................................................................30
5.2,Pelco-D protocol command list .............................................................................................................................32
5.3 Pelco-P protocol command list..............................................................................................................................33
6. Camera Maintenance and Troubleshooting....................................................................................................................34
6.1 Camera Maintenance............................................................................................................................................34
6.2 Troubleshooting ....................................................................................................................................................34
7. After-Sales Service...........................................................................................................................................................36
8. Warranty .........................................................................................................................................................................37

Alfatron ALF-XXX-SDIW
5
1. Fast Installation
1.1 Camera Interface Explanation
Figure 1.1 Interface
1. Camera Lens
2. Camera Base
3. Remote Controller Receiver Light
4. Bottom Dial Switch
5. Tripod Screw Hole
6. RS232 Control Interface (input)
7. RS232 Control Interface (output)
8. RS485 Input (left +, right-)
9. Audio Input Interface
10. 3G-SDI interface
11. HDMI Interface
12. 10/100M Network Interface
13. DC12V Input Power Supply Socket
1.2 Initial power on configuration
1) Connect DC12V power supply adapter with power supply socket.
2) Initial configuration: Power on with power indicator light on and remote-control receiver light blinking, camera head moves from
bottom left to the bottom, and then goes to the HOME position (intermediate position of both horizontal and vertical), while the
camera module focuses in and out. When remote control receiver light stops blinking, the self-checking is completed.
Note: If you set preset 0, when Power on self-test is completed, the camera automatically moves to the preset 0 position.
1.3 Video Output
This camera has a variety of video outputs: LAN, HDMI and 3G-SDI.
1) Video Output from LAN
a. Network Cable Connection Port: No.12 in Figure1.1.
b. Webpage Login: Open your browser and enter 192.168.5.163 in the address bar (factory default); press Enter to open the login
page. Enter the username admin and password admin (factory default); press Enter to enter the preview page, users can carry
out PTZ control, configuration etc.
2) HDMI Video Output
a. HDMI Video Cable Connection: No.11 in Figure1.1.
b. Connect the camera to the monitor via an HDMI video cable. The video output is available after camera self-test.
3) 3G-SDI Video Output
a. 3G-SDI video cable connection: No.10 in Figure1.1
b. Connect the camera and the monitor via 3G-SDI video cable; video output is available after camera self-test.
1.4 Bracket mount

Alfatron ALF-XXX-SDIW
4
Note: Bracket can only be wall mounted or upside down mounted on template and concrete wall but cannot be installed on
plasterboard.
1) Wall mount step
2. Upside down mount step

Alfatron ALF-XXX-SDIW
5

Alfatron ALF-XXX-SDIW
6
2. Product overview
2.1 Product Introduction
2.1.1 Dimension
Figure 2.2 Camera dimension
2.1.2 Accessory
When you unpack, check that all the supplied accessories are included:
Model NO. Configuration
Accessory
Standard
Power adapter 1piece
RS232 cable 1 piece
User manual 1
Double-side glue shim 4pcs
Warranty card 1 piece
IR Remote controller 1 piece
Wall or Ceiling mounting bracket
Cascade cable

Alfatron ALF-XXX-SDIW
7
2.2 Main Features
2.2.1 Camera Performance
This camera offers excellent functionality, superior performance, and superb interfaces. The features include advanced ISP
processing algorithms to provide vivid images with a strong sense of depth, high resolution, and fantastic color rendition. It supports
H.265/H.264 encoding which makes motion video smooth and clear even with less-than-ideal bandwidth conditions.
1.Superb High-definition Image: It employs 1/2.8-inch-high quality CMOS sensor. Resolution is up to 1920x1080 with frame rate up
to 60 fps.
2.Various Optical Zoom Lens: It has a 20X and 30X optical zoom lens options.
3. Leading Auto Focus Technology: Leading auto focus algorithm makes the lens a fast, accurate and stable.
4. Low Noise and High SNR: Low Noise CMOS effectively ensure high SNR of camera video.
Advanced 2D/3D noise reduction technology is also used to further reduce the noise, while ensuring image sharpness.
5.Quiet PTZ: By adopting a high accuracy step driving motor mechanism, the Pan / Tilt / Zoom works quietly and moves smoothly and
quickly to designated positions.
6.Multi-Format Video Outputs: support HDMI,3G-SDI, wired LAN interface. The 3G-SDI is available for 100m transmission at 1080p60
format.
7.Low-power Sleep Function: Support low-power sleep/wake up, the consumption is lower than 500mW under sleep mode.
8.Support Multiple Control Protocol: Support VISCA, PELCO-D, PELCO-P protocols which can also be automatically recognized.
Support VISCA control protocol through IP port.
9.RS-232 Cascade Function: SDI series support RS-232 cascade function which is convenient for installing.
11.255 Presets Positions: Up to 255 presets (10 presets via remote controller).
12.Wide Application: Tele-education, Lecture capture, Webcasting, Videoconferencing, Tel e-training, Tele-medicine, Interrogation
and Emergency command systems.
2.2.2 Network performance
1. Audio Input Interface: Supports 16000, 32000, 44100, 48000 sampling frequency and AAC, MP3, and PCM audio coding.
2. Multiple Audio/Video Compression: Supports H.264/H.265 video compression; AAC, MP3 and PCM audio compression;
Supports compression of resolution up to 1920x1080 with a frame rate up to 60 fps and 2 channel 1920x1080p with 30 fps
compression.
3. Multiple network protocols: Support ONVIF, RTSP, RTMP protocols and RTMP push mode, easy to link to streaming media
servers like YouTube and Facebook)

Alfatron ALF-XXX-SDIW
8
2.3 Technical Specification
Model
20X
30X
Camera Parameter
Sensor
1/2.8 inch high quality HD CMOS sensor
Effective Pixels
16: 9, 2.07 megapixel
Video Format
HDMI/SDI video format
1080P60/50/30/25/59.94/29.97;1080I60/50/59.94;720P60/50/30/25/59.94/29.97
Optical Zoom
20X
f
＝
5.2
～
98mm
30X
f
＝
4.3
～
129mm
View Angle
3.2°
（
tele
）
55.8°
（
wide
）
2.34°(tele)--65.1°(wide)
AV
F1.5 – F3.0
F1.6
～
F4.7
Digital Zoom
10X
Minimum Illumination
0.5Lux (F1.8, AGC ON)
DNR
2D & 3D DNR
White Balance
Auto / Manual/ One Push/ 3000K/ 4000K/5000K/6500K
Focus
Auto/Manual
Aperture
Auto/Manual
Electronic Shutter
Auto/Manual
BLC
ON/OFF
WDR
OFF/ Dynamic level adjustment
Video adjustment
Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
SNR
>55dB
Input/Output Interface
Video Interfaces
HDMI, 3G-SDI, LAN, Audio-in
Image code stream
Double streams outputs simultaneously
Video Compression
format
H.264, H.265
Control Signal Interface
RS-232 Ring through RS232 output, RS-485
Control Protocol
VISCA/Pelco-D/Pelco-P; Baud Rate: 115200/9600/4800/2400bps
Audio input Interface
Double track 3.5mm linear input;
Audio Compression
Format
AAC/MP3/PMC Audio compression
HD IP Interface
100M IP port (100BASE-TX); support IP Visca control protocol
Network Protocol
RTSP/ R T MP, ONVIF
Power Interface
HEC3800 outlet (DC12V)
PTZ Parameter
Pan Rotation
±170°
Tilt Rotation
-30°
～
+90°
Pan Control Speed
0.1 -180°/sec
Tilt Control Speed
0.1-80°/sec
Preset Speed
Pan: 60°/sec, Tilt: 30°/sec
Preset Number
255 presets (10 presets by remote controller)
Other Parameter
Supply Adapter
AC110V-AC220V to DC12V/2A
Input Voltage
DC12V±10%
Input Current
1A(Max)
Consumption
12W (Max)
Store Temperature
-10℃to +60℃
Store Humidity
20% - 95%
Working Tem perature
-10℃to +50℃
Working Humidity
20%--80%
Dimension
150mmX150mmX167.5mm
Weight
1.4KG
Working Environment
Indoor
Remote Operation (IP)
Remote Upgrade, Reboot and Reset

Alfatron ALF-XXX-SDIW
9
Accessory
Power Supply, RS232 Control Cable, Remoter, Manual, Warranty card
Optional Accessory
Bracket
2.4 Interface Instruction
2.4.1 External Interface
1) External interface: RS232 Input /Output, RS485 Input, Audio Input,3G-SDI Output, HDMI Output, LAN, DC12V Power
Interface.
Figure 2.3 External interface diagram
2.4.3 RS-232 Interface
1) RS-232C interface specification as shown below:
Computer or keyboard and camera connection method
Camera
WindowsDB-9
1.DTR 1.DCD
2.DSR 2.RXD
3.TXD
3.TXD
4.GND
4.DTR
5.RXD
5.GND
6.GND
6.DSR
7.IR OUT
7.RTS
8.NC
8.CTS
9.RI

Alfatron ALF-XXX-SDIW
10
2) RS-232 Mini-DIN 8-pin Port Definition
3) RS232 (DB9) Port Definition
2) VISCA networking as shown below:
Camera cascade connection method
Camera 1
Camera 2
1.DTR
1.DTR
2.DSR
2.DSR
3.TXD
3.TXD
4.GND
4.GND
5.RXD
5.RXD
6.GND
6.GND
7.IR OUT
7.OPEN
8. NC
8.OPEN
Note: SDI model has RS232 input and output interface, so you can cascade as the above way;
NO.
Port Definition
1
DTR Data Terminal Ready
2
DSR Data Set Ready
3
TXD Transmit Data
4
GND
System Ground
5
RXD Receive Data
6 GND
System Ground
7
IR OUT
IR Commander Signal
8
NC
No Connection
NO.
Port
Definition
1
DCD
Data Carrier Detect
2
RXD
Receive Data
3
TXD
Transmit Data
4
DTR
Data Terminal Ready
5
GND
System Ground
6
DSR
Data Set Ready
7
RTS
Request to Send
8
CTS
Clear to Send
9
RI
Ring Indicator

Alfatron ALF-XXX-SDIW
11
3. Application Instruction
3.1 Video Output
3.1.1 Power-On Initial Configuration
When powered, the camera will run its initial configuration, IR indicator light will be flashing. When the camera returns to the HOME
position (middle position for P/T), and lens completes zooming in/out, the auto-testing is completed, and the IR led will stop flashing.
If the preset 0 is set, camera will rotate to the 0-preset position after initial configuration.
3.1.2 Video Output
Connect the video output cable. HDMI, SDI or Network
Network output: connect this product and your computer via a network cable, then open the browser, enter the camera IP address
(factory default 192.168.5.163) in the address bar, then to the login page and input a username and password (factory default
username and passwords are “admin”).Finally enter the preview page, and the image is displayed in preview menu.
(Note: If you forget your username, password, or IP address, you can manually restore the default by the remote controller
key combination * #)
2)3G-SDI output or HDMI output: Connect the monitor with the corresponding video output interface, then the monitor output
image.
3.2 Remote Controller
3.2.1 Keys Instruction
1. Standby Key
After 3-second-long press, the camera will step into standby mode. Long press for 3 seconds again,
the camera will self-test again and move back to the HOME position. (Note: If power-on mode is
turned on and Preset 0 is set, and there is no operation within 12s, it will automatically point to the
specified preset position.
2. Camera Address Selection
Select the camera addresswhich requires control.
3. Number Key
Set or run 0-9 presets.
4. *, # Key
Key combination use
5. Focus Control Key
Auto Focus: Enter auto focus mode.
Manual Focus: The camera focus mode is manual.
Switch the camera focus mode to manual focus by pressing [focus +] or [focus -] to adjust.
6. Zoom Control Key
Zoom＋: Lens near
Zoom－: Lens far
7. Set or Clear Preset key:
Set Preset: Set preset key + 0-9 number key:
Clear Preset key: Clear preset key + 0-9 number key
8. Pan/Tilt Control Key
Press Key :Up
Press Key :Down
Press Key :Left
Press Key: Right

Alfatron ALF-XXX-SDIW
12
“HOME” Key: Return to the middle position or enter into the next level menu
9. BLC Control Key
Back Light ON / OFF: Turn on or off the back light
10. Menu Setting
Open or close the OSD menu
Enter / exit the OSD menu or return to the previous menu.
11. Camera IR Remote Control Address Setting
【*】+【＃】+【F1】:Camera Address No.1
【*】+【＃】+【F2】:Camera Address No. 2
【*】+【＃】+【F3】:Camera Address No. 3
【*】+【＃】+【F4】:Camera Address No. 4
12. Key Combination Functions
1)
【
#
】
+
【
#
】
+
【
#
】
:Clear all presets
2)
【
*
】
+
【
#
】
+
【
6
】
:Restore factory defaults
3)
【
*
】
+
【
#
】
+
【
9
】
:Flip switch
4)
【
*
】
+
【
#
】
+Auto: Enter into the aging mode
5)
【
*
】
+
【
#
】
+
【
3
】
:Menu set to Chinese
6)
【
*
】
+
【
#
】
+
【
4
】
:Menu set to English
7)
【
*
】
+
【
#
】
+Manual: Restore the default user name, password,
and IP address
8)
【
#
】
+
【
#
】
+
【
0
】
:Switch the video format to 1080P60
9)
【
#
】
+
【
#
】
+
【
1
】
: Switch the video format to 1080P50
10)
【
#
】
+
【
#
】
+
【
2
】
:Switch the video format to 1080I60
11)
【
#
】
+
【
#
】
+
【
3
】
:Switch the video format to 1080I50
12)
【
#
】
+
【
#
】
+
【
4
】
:Switch the video format to 720P60
13)
【
#
】
+
【
#
】
+
【
5
】
:Switch the video format to 720P50
14)
【
#
】
+
【
#
】
+
【
6
】
:Switch the video format to 1080P30
15)
【
#
】
+
【
#
】
+
【
7
】
:Switch the video format to 1080P25
16)
【
#
】
+
【
#
】
+
【
8
】
:Switch the video format to 720P30
17)
【
#
】
+
【
#
】
+
【
9
】
:Switch the video format to 720P25
3.2.2 Applications
Once finalizing initialization, the camera can receive and execute the IR commands. Press the remote controller button, the
indicator light is flashing; release the button, the indicator light stops flashing. Users can control the pan/tilt/zoom, setting and
running preset positions via the IR remote controller.
Key Instruction:
1. In this instruction, “press the key” means a click rather than a long-press, and a special note will be given if a long-press for
more than one second is required.
2. When a key-combination is required, do it in sequence. For example “【*】+【#】+【F1】”means press“【*】”first and then
press“【#】” and last press“【F1】”.
1) Camera Selection
Select the camera address to control.
2) Pan/Tilt Control
Up: press Down: press
Left: press Right: press
Back to middle position: press “【HOME】”
Press and hold the up/down/left/right key, the pan/tilt will keep
running, from slow to fast, until it runs to the endpoint; the
pan/tilt running stops as soon as the key is released.
3) Zoom Control

Alfatron ALF-XXX-SDIW
13
ZOOM IN: press “ZOOM “ key
ZOOM OUT: press “ZOOM ” key
Press and hold the key, the camera will keep zooming in or
zooming out and stops as soon as the key is released.
4) Focus Control
Focus (near): Press “【focus+】” key (Valid only in manual focus
mode)
Focus (far): Press “【focus-】”key (Valid only in manual focus
mode)
Auto Focus: Support
Manual Focus: Support
Press and hold the key, the action of focus will keep continuing
and stops as soon as the key is released.
5) BLC Setting
BLC ON / OFF: support
6) Presets Setting, Running, Clearing
1. Preset setting: to set a preset position, the users should press
the “【SET PRESET】” key first and then press the number key 0-9
to set a relative preset,
Note: 10 preset posi
tions in total are available by remote
controller.
2. Preset Running: Press a number key 0-9 directly to run the
relative preset.
Note: Action in vain if a relative preset position is not existed.
3. Preset clearing: to clear a preset position, the user can press
the “【CLEAR PRESET】” key first and then press the number key
0-9 to clear the relative preset:
Note: press the “
【
#
】
” key three times continually to cancel all
the presets.
7) Camera Remote Controller Address Setting
【*】+【＃】+【F1】:Camera Address No.1
【*】+【＃】+【F2】:Camera Address No. 2
【*】+【＃】+【F3】:Camera Address No. 3
【*】+【＃】+【F4】:Camera Address No. 4

Alfatron ALF-XXX-SDIW
14
3.3 MENU SETTING
3.3.1 Main Menu
In normal working mode, press 【MENU】key to display the menu, using scroll arrow to point at or highlight the selected items.
LANGUAGE: Language setting, Chinese / English
SETUP:System setting
CAMERA OPTION:Camera setting
PTZ OPTION:Pan tilt setting
VERSON:camera version setting
Restore Default:Reset setting
[↑↓] Select:for selecting menu.
[← →] Change Value:for modify parameters.
[MENU] Back:Press [MENU] to return.
[Home] OK:Press [Home] to confirm.
3.3.2 System Setting
Move the pointer to the (Setup) in the Main Menu, click the【HOME】key and enter the (System Setting) as shown below:
PROTOCOL: VISCA/Pelco-P/Pelco-D/Auto
Visca ADDR: VISCA=1~7 Pelco-P=1~255 Pelco-D = 1~255
Baud rate: 2400/4800/9600/115200
Visca Address Fix: On/Off
SETUP
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
Protocol
Auto
Visca Address 1
Visca Address Fix OFF
PELCO-P Address
1
PELCO-D Address 0
Baudrate
9600
[↑↓]Select [←→]Change
MENU
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
Language English
(Setup)
(Camera)
(P/T/Z)
(Video Format)
(Version)
(Restore Default)
[
↑↓
]Select [
←
→
]Change
Value

Alfatron ALF-XXX-SDIW
15
3.3.3 Camera Setting
Move the pointer to the (CAMERA) in the Main Menu, click the【HOME】key and enter the (CAMERA) as follows:
EXPOSURE: Enter Exposure setting.
COLOR: Enter color setting.
Image: Enter image setting.
Focus: Enter into focus setting.
Noise Reduction: Enter into noise reduction.
1) EXPOSURE SETTING
Move the pointer to the (EXPOSURE) in the Main Menu, click the【HOME】and enter the (EXPOSURE SET) as follows:
Mode:Auto, Manual, Shutter priority, Iris priority and Brightness priority.
EV: On/Off (only available in auto mode)
Compensation Level: -7~7 (only available in auto mode when EV is ON)
BLC: ON/OFF for options (only available in auto mode)
Anti-Flicker:OFF/50Hz/60Hz for options (only available in Auto/Iris priority/Brightness priority modes)
Gain Limit: 0~15(only available in Auto/ Iris priority /Brightness priority mode)
WDR: Off,1~8
Shutter
Priority:1/25,1/30,1/50,1/60,1/90,1/100,1/120,1/180,1/250,1/350,1/500,1/1000,1/2000,1/3000,1/4000,1/6000,1/10000(only
available in Manual and Shutter priority mode)
EXPOSURE
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
Mode
Auto
EV
OFF
BLC
OFF
Anti-Flicker 50Hz
Gain Limit 3
WDR 5
[
↑↓
]Select [
←
→
]Change
Value
CAMERA
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
(Exposure)
(Color)
(Image)
(Focus)
(Noise Reduction)
[
↑↓
] Select [
←
→
]Change
Value

Alfatron ALF-XXX-SDIW
16
IRIS Priority: O FF, F11.0, F9.6, F8.0, F6.8, F5.6, F4.8, F4.0, F3.4, F2.8, F2.4, F2.0, F1.8 (only available in Manual and Iris priority mode)
Brightness: 0~23 (only available in Brightness priority mode)
2) COLOR SETTING
Move the pointer to the (COLOR) in the Main Menu, click the【HOME】and enter the (COLOR SET) as follow,
WB Mode: Auto, 3000K、3500K、4000K、4500K、5000K、5500K、6000K、6500K、7000K, Manual, One Push
Red Gain: 0~255(only available in Manual mode)
Blue Gain: 0~255(only available in Manual mode)
Saturation: 60%,70%,80%,90%,100%,110%,120%,130%
Hue: 0~14
AWB Sensitivity: high/middle/low
Color Style: Default, style1~4.
Color Temp: high/middle/low
3) IMAGE
Move the pointer to the (IMAGE) in the Menu, click the【HOME】and enter the (IMAGE) as follow,
Brightness: 0~14
Contrast: 0~14
Sharpness: 0~15
Flip-H: On/Off
Flip-V: On/Off
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
Brightness
6
Contrast 8
Sharpness 7
Flip-H OFF
Flip-V
OFF
B&W-Mode Color
Gamma Default
DZoom OFF
DCI Close
[
↑↓
]Select [
←
→
]Change
Value
COLOR
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
WB Mode
Auto
Saturation 80%
Hue 7
AWB Sensitivity
High
Color style Default
Color temp Low
[
↑↓
]Select [
←
→
]Change
Value

Alfatron ALF-XXX-SDIW
17
B&W Mode: color, black/white
Gamma: default, 0.47, 0.50, 0.52, 0.55
DZoom: digital zoom options: On/Off
DCI: Dynamic Contrast: Off,1～8
4) FOCUS
Move the pointer to the (FOCUS) in the Menu, click the【HOME】and enter the (FOCUS) as follow,
Focus Mode: Auto, manual
AF-Zone: Up, middle, down
AF-Sensitivity: High, middle, low
5) NOISE REDUCTION
Move the pointer to the (NOISE REDUCTION) in the Menu, click the【HOME】and enter the (NOISE REDUCTION) as follows:
2D Noise Reduction: Auto, close, 1~7
3D Noise Reduction: Close, 1~8
Dynamic Hot Pixel: Close, 1~5
3.3.4 P/T/Z
Move the pointer to the (P/T/Z) in the Main Menu, click the【HOME】and enter the (P/T/Z) as follow,
P/T/Z
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
Depth of field ON
Zoom speed
8
Image Freezing OFF
Acc Curve Slow
[
↑↓
]Select [
←
→
]Change
Value
NOISE REDUCTION
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
NR-2D Auto
NR-3D 3
Dynamic Hot Pixel OFF
[
↑↓
]Select [
←
→
]Change
Value
FOCUS
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
Focus Mode Auto
AF-Zone Center
AF-Sensitivity Low
[
↑↓
]Select [
←
→
]Change
Value
