Algoma 4709CDI User manual

Model 4709CDI Large Wood Arc Hammock Stand
Congratulations on purchasing Model 4709C
wood arc hammock stand to be used with
most 13 ft 2-pt hammocks. We hope it helps
provide hours of relaxation. If you have
questions regarding this product, please
contact customer service at [phone]
Weight Limit 450 lbs.
Parts
(A)
(B)
(C)
(D)
(E)
(F)
(G)
(H)
(I)
(J)
(K)
(L)
(A) 9.5” Bolts (x 4)
(B) 5.5” Bolts (x 4)
(C) Washers (x 18)
(D) Lock Nuts (x 8)
(E) Eye bolts (x 2)
(F) Carabiner Clip (x 4)
(G) Chain (x 2)
(H) Wrench (x 2)
(I) Wrench handle (x 2)
(J) Upright supports (x 2)
(K) Base Supports (x 2)
(L) Legs (x 2)
Note: Wrenches for assembly are
provided, however, if using your own
tools, a 17mm metric, or 11/16” SAE
deep socket will be required.
2 piece
wrench

Step 1: Place wood legs (L) on a hard
level surface approximately 48 inches
apart (as in figure 1) with the beveled
cutout facing up, and towards each
other.
Figure 1
Step 2: Place one wood base support (K) onto wood
legs (as in Figure 2). (The ends of the base support
should be arching up and the countersunk holes on
the sides of the base support to the outside). Line up
the hole on the top of the base support with the hole
in the beveled part of the legs. Place a washer (C)
onto one of the 5.5” bolts (B) and insert bolt down
through the wood base support and wood leg. Place
another washer (C) onto end of bolt and a lock nut (D).
Loosely tighten bolt and nut using the 2 piece
wrenches supplied. (Only loosely tighten at this time
to help with aligning holes. Securely tighten when all
pieces are successfully assembled) Repeat the
procedure with the second leg and with the second
base support (K) (as in Figure 3).
(L) (L)
(K)
Figure 2
Figure 3
Figure 4a Figure 4b
Step 3: Locate wood upright support (J) and place end
with the two side holes between the base supports (as
shown in Figure 4a). Place a washer (C) onto one of
the 9.5” bolts (A). Place bolt with washer through the
wood base support, through the upright support, and
through the opposite base support. Place another
washer (C) onto end of the bolt along with a lock nut
(D). Loosely tighten using the 2 piece wrenches.
Align second hole and repeat above
procedure (as shown in Figure 4b.)
Repeat entire step with the second
upright support on the opposite end.

Step 4: Place eye bolt (E) into the hole at the top of the
upright support (as shown in Figure 5) Secure using a
washer (C) and a lock nut (D) tightening with the 2 piece
wrenches supplied.
Step 5: Clip a carabiner clip (F) onto each end of the
chains (G). Attach the hanging chain to the eye bolt on
each end of the stand (as shown in Figure 6.)
TO CONNECT YOUR HAMMOCK: Simply clip the O-ring at
the end of your hammock to the carabiner clip at the end
of the chain lengths (as shown in Figure 7). Adjust the
height of the hammock by moving the clip to an
alternative link in the chain length.
Step 6: Go back and tighten all nuts and bolts.
Caution: Care should always be taken when using your hammock stand but especially when using
the stand the very first time. Please always use extreme caution when getting into and out of your
hammock. Never exceed the weight capacity of the hammock or the hammock stand. Never allow
young children to use the hammock or stand unaccompanied by an adult. Always inspect your
hammock stand before each use to assure all parts are appropriately attached and tightened. Make
sure to read and follow your hammock care instructions.
Care and Storage: The Wooden Arc Stand is finished with a protective outdoor finish. To prolong the
life of the wooden stand try to store in a dry location especially through the winter months.
Please Note: When using your stand for the first time you’ll notice creaking noises as the pieces
settle in place. Once the stand has been used a few times the creaking noise will subside.
Figure 5
Figure 6
Figure 7
