Alienware A9090 User manual

is a trademark of SRS Labs, Inc. SRS WOW technology is incorporated
under license from SRS Labs, Inc.
2

Dear Valued Alienware Customer,
Alienware would like to take this opportunity to thank you for purchasing a cutting-edge HUB Docking
Sound System and welcome you to the growing family of dedicated users who have been enjoying
Alienware's award-winning products since 1996. Alienware products incorporate state-of-the-art
components, innovative engineering and design, and unprecedented customer service. All of this
combines to make Alienware the leading manufacturer of high-performance desktop, notebook, media
center, and professional computer systems.
The technicians responsible for creating your HUB dedicated themselves to ensuring it is properly
optimized and performs to its fullest potential. Your HUB has been extensively tested in order to
ensure the highest levels of reliability and performance.
Please do not hesitate to e-mail or call Alienware with any questions or concerns you may have.
Alienware would like to hear from you. The entire staff sincerely hopes that you enjoy your new HUB
for years to come.
Sincerely,
The Alienware Staff
INTRODUCTION / INTRODUCCIÓN / INTRODUCTION
3

4

INDEX / ÍNDICE / INDEX
LOCATIONOFFEATURES...............................7
OPERATION
ACADAPTOR...............................8
DCADAPTOR...............................8
REPLACINGBATTERIES.............................8
CONNECTION
INSERTING ALIENWARE FLASH PLAYER . . . . . . . . . . . . . . . . . . . . . . . . . 9
OPTIONAL DOCKING FOR OTHER DEVICES . . . . . . . . . . . . . . . . . . . . . . . . 9
EXTERNALDEVICES..............................10
A/VOUTPUT................................10
OPERATION
POWER.................................11
AUXILIARY................................11
VOLUME.................................11
SRSSOUNDADJUSTMENT ............................11
TROUBLESHOOTINGGUIDE..............................12
WARNING..................................13
WARRANTY
ENGLISH.................................14
SPANISH/FRENCH..............................15
5

6

LOCATION OF FEATURES / UBICACION DE LOS BOTONES / EMPLACEMENT DES BOUTONS
FLASH PLAYER DOCKING
ACOPLAMIENTO DEL TOCADOR FLASH
AMARRAGE INSTANTANÉ DE DÉBITEUR
INPUT SELECTOR
SELECTOR DE ENTRADA
SÉLECTEUR D'ENTRÉE
VOLUME +
VOLUMEN +
VOLUME +
HEADPHONE JACK
HEADPHONE JACK
HEADPHONE JACK
VOLUME -
VOLUMEN -
VOLUME -
SRS 3D
SRS 3D
SRS 3D
FOCUS
FOCUS
FOCUS
TruBass
TruBass
TruBass
POWER
BOTÓN DE ENERGÍA
PUISSANCE
LINE IN JACK
TOMA DE LINEA DE ENTRADA
LIGNE EN JACK
AV OUT JACK
TOMA DE LA SALIDA AV
POIDS DU COMMERCE HORS DE JACK
12V INPUT
ENTRADA 12V
ENTREÉ 12V WOW
WOW
WOW
MUTE
SILENCIADOR
MUET
VOLUME UP
SUBIR VOLUMEN
VOLUME VERS LE HAUT
VOLUME DN
BAJAR VOLUMEN
VOLUME VERS LE BAS
MUTE
VOLUME
USE ONE SIZE CR2305
LITHIUM BATTERY
BATTERY INSTALLATION
REMOTE CONTROL
CONTROL REMOTO
CONTRÔLE ÉLOIGNÉ
++
LithiumCell
Cr2025
3V
sc2
• The button cell battery contains mercury.
Don't put in the trash. Recycle or dispose as
hazardous waste.
• La pila célula tipo botón contiene mercurio. No la tire
en la basura. Recíclela ó deséchela como residuo
peligroso.
•La pile cellule type bouton contient du mercure. Ne la jetez
pas à la poubelle. Veuillez la recyclé ou jeté comme déchet
dangereux.
7

SETUP / SISTEMA / ORGANISATION
BOTTOM VIEW / VISTA BAJA / VUE INFÉRIEURE
8 "D" Batteries
(Not Included)
REPLACING BATTERY COVER /REEMPLAZANDO LA TAPA DE LAS PILAS /
REMPLACEMENT DE LA COUVERTURE DE BATTERIE
Turn to "OPEN"
OPEN
CLOSE
Push switches
toward HUB center.
Take the battery cover
off and place 8 "D" batteries
into battery compartment.
Turn to "CLOSE"
OPEN
CLOSE
Push switches
away from HUB center.
Place battery cover
on unit.
A
C
B
USING DC ADAPTOR /
UTILIZANDO EL ADAPTADOR DC
UTILISATION DE L'ADAPTEUR DE C.C
AC ADAPTOR / ADAPTADOR AC /
ADAPTEUR À C.A.
DC IN 12V
DC IN 12V
TO DC IN 12V JACK
110 - 240V
50/60Hz
To Cigarette Lighter
8

CONNECTION / CONECTANDO / CONNECXION
ALIENWARE FLASH PLAYER /
TOCADOR DE FLASH DE ALIENWARE /
JOUEUR INSTANTANÉ D'ALIENWARE
OPTIONAL DOCKING FOR OTHER DEVICES /ACOPLAMIENTO OPCIONAL PARA OTROS APARATOS /
AMARRAGE FACULTATIF POUR D'AUTRES DISPOSITIFS
A
B
Alienware CE-IV digital audio players
are sold separately.
Lay the unit down
inside the HUB.
Input connection plug.
Place the unit
inside the HUB.
NOTE: Make sure both units are off. Power
on flash player first then turn on the HUB.
OTHER DEVICE
SOLD SEPARATELY
Output Jack on cradle.
¬

1. Plug other device into
"Input connection plug."
2. Place inside HUB.
3. Close Docker.
1. Conecte el otro aparato en el
"Input connection plug."
2. Ponga dentro del HUB
3. Sierre el acoplamiento
1. Branchez l'autre dispositif à
"Input connection plug."
Placez à l'intérieur du HUB
3. Docker Étroit
2.
Press "PUSH
OPEN" to open
Flash Player Docking
Presione "PUSH OPEN" para
abrir el acoplamiento del
tocador de Flash
Pression "PUSH OPEN"
d'amarrage instantané
ouvert de joueur
BOTTOM OF UNIT
9
1. Lift the cradle.
2. Pull away from base
to remove.
1. Soulevez le berceau
1. Levante la horquilla
2. Tirez loin de la base pour enlever
2. Para remover, hale en via contraria de la base

OPTIONAL DOCKING FOR OTHER DEVICES /ACOPLAMIENTO OPCIONAL PARAOTROS APARATOS
/ AMARRAGE FACULTATIF POUR D´AUTRES DISPOSITIFS
AV OUT JACK
LINE IN
A/V OUT
Digital Player
EXTERNAL DEVICES / APARATOS EXTERNOS / DISPOSITIFS EXTERNES
A/V OUTPUT / SALIDA DE A/V / RENDEMENT D'A/V
CD Player Computer
LINE IN JACK
LINE OUT JACK
OPTIONAL
(NOT INCLUDED)
OPTIONAL
(NOT INCLUDED)
LINE IN
