Alink RoadRunner 40/44 User manual

RoadRunner 40/44

1
Copyright
Copyright 2001 by Avaks. All rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in
any form or by any means, electronic, mechanical, magnetic, optical,
chemical, manual or otherwise, without the prior written permission of this
company.
Disclaimer
This company makes no representations or warranties, either expressed
or implied, with respect to the contents hereof and specifically disclaims
any warranties, merchantability or fitness for any particular purpose. Any
software described in this manual is sold or licensed "as is". Should the
programs prove defective following their purchase, the buyer (and not this
company, its distributor, or its dealer) assumes the entire cost of all
necessary servicing, repair, and any incidental or consequential damages
resulting from any defect in the software. Further, this company reserves
the right to revise this publication and to make changes from time to time
in the contents hereof without obligation to notify any person of such
revision or changes.
.
All brand and product names mentioned in this manual are trademarks and/or registered
trademarks of their respective holders.

2
Contents
1. Introduction to ADSL -Ethernet Router……………4
1.1 Product Features…………………………………..4
1.2 Related Documents………………………………..8
2. Package Contents and Hardware Indicators……..10
2.1 Hardware Indicators……………………………..10
3. Hardware Installation………………………………....13
4. USB ADSL Modem Driver Installation……………...14
4.1 Windows 98………………………………………...14
4.2 Windows Me………………………………………..17
4.3 Windows 2000……………………………………...19
4.4 Windows XP………………………………………...23
5. Network Settings………………………………………27
6. Configuring ADSL Router …………………………...33
6.1 Accessing the Web Manager……………………33
6.2 Configuration……………………………………...35
6.3 LAN Setup……………………………………….....37
6.4 NAT Configuration………………………………..39

3
6.5 Virtual Server………………………………………41
6.6 Bridge Filtering……………………………………42
6.7DNS Configuration………………………………..43
6.8Save Settings………………………………………43
7. Admin Privilege……………………………………......43
7.1 WAN Status……………………………………......44
7.2 PPP Status…………………………………………44
7.3 TCP Status…………………………………………44
7.4 Route Table………………………………………...45
7.5 ADSL Configuration………………………………45
7.6 RIP Configuration…………………………………46
7.7 Password Configuration…………………………47
7.8 Miscellaneous Configuration…………………...47
7.9 Reset to Factory Default…………………………48
7.10 Diagnostic Test……………………………………48
7.11 Code Image Update………………………………..51
APPENDIX : PVC
Configuration…………………………52

4
1 Introduction to Ethernet Router
The ADSL Ethernet Router isoptimized toaddress the growing demand
for high-speed Internet access. With both a USB 1.1-complient interface
and an IEEE 802.3-complient Ethernet interface, it provides the widest
array of connectivity options without relaying on host PC drivers.
The ADSL Ethernet Router is an “always-on”high-speed broadband
connection to the internet. Using existing twisted-pair telephone lines,
ADSL technology provides data rates more than 100 times as fast as a
traditional analog modem, without an interruption in telephone service.
The ADSL Ethernet Router is fully compliant with the full-rate
ADSL(T1.413 Issue 2 and G.dmt) and the splitterless G.lite (G.992.2)
standards. With data transfer rates of up to 8 Mbps downstream and
1Mbps upstream.
1. 1 Product Features
ADSL Compliance
-- Compliant with ADSL standards
•Full-rate ANSI T1.413 Issue 2 and ITU G.dmt(G.992.1)
standards
•Splitterless ITU G.lite ( G.992.2 ) specification
-- DMT modulation and demodulation
-- Full-rate adaptive modem

5
•Maximum downstream rate of 8 Mbps
•Maximum upstream rate of 1 Mbps
-- Tone detection for low power mode
-- Support splitterless ADSL implementation
ATM Protocols
-- WAN mode support: PPP over ATM (RFC2364) and PPP over
Ethernet (RFC2516)
-- LAN mode support: bridged/routed Ethernet over ATM (RFC 1483)
-- ATM forum UNI 3.1 / 4.0 PVC
-- Support 1VCs ( Virtual Circuits)
-- ATM SAR ( segmentation and reassembly)
-- ATM AAL5 ( adaption layer type 5 )
-- OAM F5
Bridge Mode
-- Ethernet to ADSL self learning Transparent Bridging
(IEEE 802.1D )
-- Support up to 16 MAC learning address
Router Mode

6
-- IP routing RIPv2
-- Static Routing
-- DHCP ( Dynamic host configuration protocol) server and client
-- NAT ( Network Address Translation)
-- ICMP ( Internet Control Message Protocol )
Security
-- User authentication for PPP
-- PAP ( password authentication protocol )
-- CHAP ( challenge authentication protocol )
-- Password-protected system management
Ethernet Interface
-- IEEE 802.3 compliant
-- 10/100 Mbps
ADSL Ethernet Router (Four-Port Only)
-- Each port can work at 10 Mbps or 100Mbps, full-duplex or half-duplex
mode
-- Automatic MDI/MDIX crossover for 100Base-TX and 10Base-T ports
-- Auto-negotiation and speed-auto-sensing support
-- Back-pressure-based flow control on half-duplex ports
-- Pause-frame-based flow control on full duplex ports

7
-- Store-and-forward switching mode
-- High performance lookup engine with support for up to 4096 MAC
address entries with automatic learning and aging
USB Interface
-- Compliant with USB specification, Revision 1.1
-- USB full speed ( 12Mbps )
-- Vendor specific descriptors
HTTP Web-Based Management
-- Firmware upgrade via FTP
-- Customizable Web pages
-- WAN and LAN side connection statistics
-- Configuration of static routes and routing table
-- Configuration of NAT
-- Password-protected access
-- Selection of bridge or router mode
-- PPP user ID and password
-- Configuration of VCs ( Virtual circuits )

8
1.2Related Documents
ITU G.992.1 (G. dmt Full-rate ADSL)
ITU.G.992.2 (G.lite “Splitterless ADSL“ )
RFC 768 User Datagram Protocol (UDP)
RFC 791 Internet Protocol (IP)
RFC 792 Internet Control Message Protocol ( ICMP)
RFC 793 Transmission Control Protocol (TCP)
RFC 826 Ethernet Address Resolution Protocol (ARP)
RFC 1334 Password Authentication Protocol (PAP)
RFC 1483 Multi-protocol Encapsulation over ATM
RFC 1552 Point-to-Point Protocol (PPP)
RFC 1577 Classical IP and ARP over ATM
RFC 1631 Network Address Translation (NAT)
RFC 1638 Bridge Control Protocol (BCP) for the Point-to-Point
Protocol(PPP)
RFC 1661 Link Control Protocol (LCP) for the Point-to-Point
Protocol(PPP)
RFC 1723 Routing Information Protocol Version 2
RFC 1994 Challenged Handshake Authentication Protocol (CHAP)
RFC 2131 Dynamic Host Configuration Protocol

9
RFC 2364 PPP over ATM
RFC 2516 PPP over Ethernet
IEEE 802.3
IEEE 802.3u
IEEE 802.1d

10
2 Package Contents
Make sure that you have the following items:
ADSL Ethernet Router (Single-Port/Four-Port)
12VDC ADAPTER
Telephone cable
Quick start guide
Splitter/ CAT-5 UTP Fast Ethernet cable/ USB cable (Option)
If any of the items is damaged or missing, contact your dealer
immediately.
2.1 Hardware Indicators
Front Panel
Place the Router in a location that permits an easy view of the LED
indicators shown in the front panel diagram below.
-ADSL Ethernet Router (Single-Port)
ADSL Ethernet Router
???SHOW ?LINK
Power Ready TIME
?RxD ?ACT
-ADSL Ethernet Router (Four-Port)
ADSL Ethernet Router
???SHOW ????LINK
Power Ready TIME ????ACT
?RxD 1 2 3 4

11
LED Indicators
The LED Indicators read as follows:
POWER Steady red light indicates the router is powered on.
READY
System status indicators when blinking indicate system
is alive.
SHOWTIME Steady green light indicates a valid ADSL connection.
This will light after the ADSL negotiation process has
been settled.
RXD Blinking green light indicates an active WAN session.
LINK
Steady green light indicates a valid Ethernet connection.
ACT Blinking green indicates an active Ethernet session.
Rear Panel
-ADSL Ethernet Router (Single-Port)
The rear panel of the Router provides access to the DC power adapter,
one USB connection, one LAN connection, one WAN connection and
power on/off switch.
USB LAN WAN
?¤
Power DC
Switch

12
-ADSL Ethernet Router (Four-Port)
The rear panel of the Router provides access to the DC power adapter,
one USB connection, four LAN connections, one WAN connection and
power on/off switch.
USB LAN WAN
?¤
Power DC
Switch 1 2 3 4
Splitter
¿¿¿¿

13
3. Hardware Installation
Power on
Connect the Adapter to power inlet and turn the power switch on, this
product will enter a self-test phase. When it is in the self-test phase, the
indicators READY LED will be lighted ON for about 8 seconds, and the
READY LED will be flashed to indicate that the self-test phase has
finished. Finally,the READY LED will be flashed to indicate that router is
in normal operation.
ADSL connection
Simply plug one end of the cable into the ADSL port (RJ-11 receptacle) on
the rear panel of the Router and insert the other end into splitter .
Connect Router to LAN
Prepare an Ethernet cable to connect Router to Hub or Switch of your
LAN. You can connect Router to your PC directly by crossover Ethernet
cable.
ADSL Ethernet Router (Single-Port)
USB LAN WAN
?¤
Power DC
Switch
HUB Splitter
¿¿¿¿¿

14
4. USB ADSL Modem Driver Installation
4.1 Setting Up Your ADSL Modem For Windows 98
1. After connecting the USB ADSL modem to your PC, power on
your PC .
2. The Wizard box appears detecting a “USB NET CARD”
Insert the provided CD into your CD-ROM drive. Click “Next”.
3. With “Search for the best driver for your device” checkbox selected,
click “Next”

15
4. Select “CD-ROM drive”, and click “Next”. Or click the “Specify a
location“ and pointing the path for the Windows 98 driver in the
CD-ROM.

16
5. Windows will find the driver file. Click “Next”.
6. Click “Finish” to complete installation.

17
4.2 Setting Up Your ADSL Modem for WindowsME
1. After connecting the USB ADSL modem to your PC, power on
your PC .
2. The Wizard box appears detecting a “USB NET CARD”
Insert the provided CD into your CD-ROM drive. Choose Specify
the location of the driver and click “Next”.
3. Insert the driver CD into the CD-ROM drives and click “Browse”to
find the path. Click “Next “

18
4. After Windows ME finishes copying files, it will show "Windows has
finished installing the hardware device". Click “FINISH” to complete the
installation.

19
4.3 Setting Up Your ADSL Modem for Windows 2000
1. As the Windows 2000 operating system boots up with a
connected USB ADSL Modem, it displays a Found New
Hardware Wizard dialog box shown on your screen. Click
NEXT, then a new dialog box will show on the screen.
