ALLEN&HEATH 1 XONE:96 XFADER [mini innoFADER] calibration
®
XFADER CALIBRATION
ALLEN&HEATH®

ALLEN&HEATH 2 XONE:96 XFADER [mini innoFADER] calibration
XONE:96 XFADER CALIBRATION
If adjustment of the XONE:96 XFADER cut-in point is required when new, or after replacing the standard Mini innoFADER.
Calibration requires the use of a T8, Torx, and slotted (flat-blade’) screw-driver.
This process only needs to be carried out once
•Place the mixer face-down on a clean surface.
•Remove and retain two (2) Torx screws securing the front panel to the base of the mixer [1].
•Turn the mixer over. Remove and retain six (6) Torx screws securing the front panel to the top and chassis [2].
•Loosen, but do not remove, two (2) Torx screws securing the top panel sides to the mixer chassis [3]
• With care, pull the front panel away from the mixer and place face down in front of the chassis.
• The XFADER calibration potentiometer is located on the right side of the mixer as shown [4]
•Set the top panel XFADER curve switch, right, to FAST CUT
•Route audio to a main stereo mix input channel (CH1 - CH4)
•Set the XFADE ASSIGN switch on the corresponding channel to X
•Move the XFADER to the extreme right (Y) position.
•Turn the corresponding channel fader up and monitor the LR MIX output (via headphones, MST, or BOOTH output)
[1]
[2] [2] [3]
[4]

ALLEN&HEATH 3 XONE:96 XFADER [mini innoFADER] calibration
XONE:96 XFADER CALIBRATION, continued
•Using a flat-headed driver, turn the XFADER calibration pot (clockwise) until the audio signal only just cuts OUT.
•Check that the XFADER travels ≤1mm towards the Xposition before the audio signal cuts back IN.
•Turn the corresponding channel fader down.
•Next, assign the same stereo channel XFADE ASSIGN switch to Y
•Move the XFADER to the extreme left (X) position.
•Turn the corresponding channel fader UP and monitor the LR MIX output
•Using a slotted (’flat-blade’) driver, turn the XFADER calibration pot (clockwise) until the audio signal only just cuts OUT
•Again, check the XFADER travels ≤1mm, toward the Yposition, before audio signal cuts IN
•Turn the corresponding channel fader down.
•Next, route audio to two mix channels, assigning one to Xside of the XFADER and the other to Yand check the XFADER function and
different XFADER curve switch options to confirm adjustment is complete.
•Finally, replace the front panel, re-fit and retighten all screws securing the front panel to the chassis and top panel.
≤1mm
≤1mm
