Allen-Bradley CENTERLINE 200 A User manual

CENTERLINE 200/400 A
Two-High Cabinet, Standard
and Arc-Resistant Enclosure
Bulletin Numbers 1512B, 1512BT, 1512BP, 1512DM, 1512DO, 1512M,
1562E, 1591B, 1592BF, 1592BP
User Manual Original Instructions

2Rockwell Automation Publication 1500-UM055I-EN-P - December 2021
CENTERLINE 200/400 A Two-High Cabinet, Standard and Arc-Resistant Enclosure User Manual
Important User Information
Read this document and the documents listed in the additional resources section about installation, configuration, and
operation of this equipment before you install, configure, operate, or maintain this product. Users are required to familiarize
themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards.
Activities including installation, adjustments, putting into service, use, assembly, disassembly, and maintenance are required to
be carried out by suitably trained personnel in accordance with applicable code of practice.
If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be
impaired.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use
or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and
requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or liability for
actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or software
described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation, Inc., is
prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
Labels may also be on or inside the equipment to provide specific precautions.
WARNING: Identifies information about practices or circumstances that can cause an explosion in a hazardous environment,
which may lead to personal injury or death, property damage, or economic loss.
ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property
damage, or economic loss. Attentions help you identify a hazard, avoid a hazard, and recognize the consequence.
IMPORTANT Identifies information that is critical for successful application and understanding of the product.
SHOCK HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that dangerous
voltage may be present.
BURN HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that surfaces may
reach dangerous temperatures.
ARC FLASH HAZARD: Labels may be on or inside the equipment, for example, a motor control center, to alert people to
potential Arc Flash. Arc Flash will cause severe injury or death. Wear proper Personal Protective Equipment (PPE). Follow ALL
Regulatory requirements for safe work practices and for Personal Protective Equipment (PPE).

Rockwell Automation Publication 1500-UM055I-EN-P - December 2021 3
Table of Contents
Preface
Summary of Changes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
About This Publication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Download Firmware, AOP, EDS, and Other Files . . . . . . . . . . . . . . . . . . . . 8
Additional Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 1
Installation – Standard
Enclosure
Starter Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Prepared Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Series Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Motor Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Starter Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Recommended Torque Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Environmental Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
High Altitude Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Door Opening Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Opening the Low Voltage Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Opening the Medium Voltage Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Anchoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Joining Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Access to the Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Rear Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Side Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Front Access– Access to Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Front Access – Bottom Exiting Load Cables. . . . . . . . . . . . . . . . . . . . . 23
Load Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Top Exiting Load Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Bottom Exiting Load Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Chapter 2
Installation – Arc-Resistant
Enclosure
Door Opening Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Opening the Low Voltage Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Opening the Medium Voltage Doors. . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Anchoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Joining Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Access to the Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Rear Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Side Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Front Access – Access to Power Bus. . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Front Access – Bottom Exiting Load Cables. . . . . . . . . . . . . . . . . . . . . 39
Load Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Top Exiting Load Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Bottom Exiting Load Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4Rockwell Automation Publication 1500-UM055I-EN-P - December 2021
Chapter 3
Common Installation Bus Splicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Insulated Power Bus Splicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Ground Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Incoming Line Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Installation of Current Transformer Barrier . . . . . . . . . . . . . . . . . . . . . . . 47
Hi-Pot and Insulation Resistance Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Start-up Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Contactor Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Preliminary Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Testing Contactor Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Typical Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Chapter 4
Maintenance Tool Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Recommended Torque Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Door Interlock Circumvention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Power Lock-out Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Fuse Removal and Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Bolt-on Fuse Removal/Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Clip-on Fuse Removal/Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Contactor Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Removing the Contactor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Contactor Interlock Rod Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
To Reduce the Gap Distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
To Increase the Gap Distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Isolation Switch Mechanism Inspection and Maintenance . . . . . . . . . . 63
Isolation Blade Switch Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Isolation Switch Mechanism Grounding Adjustment . . . . . . . . . . . . . . . 67
Auxiliary Contacts Inspection and Replacement . . . . . . . . . . . . . . . . . . . 68
Isolation Switch Auxiliary Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Adjusting the Normally Open (ISa) Contacts . . . . . . . . . . . . . . . . . . . 69
Adjusting the Normally Closed (ISb) Contacts . . . . . . . . . . . . . . . . . . 70
Adjusting the Change-of-State Point . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Emergency Circumvention Procedure for Power Cell Entry . . . . . . . . . 71
Installing Z-clip with Isolation Switch Handle in the
OFF Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Installing Z-clip with Isolation Switch Handle in the
ON Position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Chapter 5
Spare Parts Bulletin 1512 and 1512BT Units Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Rockwell Automation Publication 1500-UM055I-EN-P - December 2021 5
Appendix A
ArcShield Unit Information Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
ArcShield Design. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Exhaust Systems: Chimney or Plenum Option . . . . . . . . . . . . . . . . . . . . . 78
Plenum Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Plenum Exhaust Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Additional Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Chimney Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Chimney Exhaust Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Appendix B
ArcShield Plenum Installation
Instructions
Recommended Torque Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Plenum Bracing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
General Plenum Layout for ArcShield Line-up . . . . . . . . . . . . . . . . . . . . . 84
STEP 1 – Mounting a Single Plenum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
STEP 2 – Alignment of Side-by-Side Plenums . . . . . . . . . . . . . . . . . . . . . . 87
STEP 3 – Sequence of Final Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
STEP 4 – Closing the Front of the Plenum Sections . . . . . . . . . . . . . . . . . 88
STEP 5 – Extension and Elbow Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . 89
STEP 6 – Mounting Extension/Elbow to Plenum Line-up. . . . . . . . . . . . 90
STEP 7 – Additional Mounting Support . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Appendix C
ArcShield Chimney Installation
Instructions
Recommended Torque Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
General Plenum Layout for ArcShield Line-up . . . . . . . . . . . . . . . . . . . . . 94
Cabinet Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Chimney Placement on Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Appendix D
Integrated Protective
Maintenance Grounding Device
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
IPMG Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Operating Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
IPMG Positioning Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Key Interlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Auxiliary Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
IPMG Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Appendix E
History of Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

6Rockwell Automation Publication 1500-UM055I-EN-P - December 2021
Notes:

Rockwell Automation Publication 1500-UM055I-EN-P - December 2021 7
Preface
Summary of Changes This publication contains the following new or updated information. This list
includes substantive updates only and is not intended to reflect all changes.
About This Publication This publication pertains to the Rockwell Automation Bulletin 1512B medium
voltage controller. The Bulletin 1512B structure provides one complete medium
voltage controller unit.
The installation section provides instructions for both the standard enclosure
type and the Rockwell Automation arc resistant type (ArcShield™).
The product Bulletin numbers covered by this document are:
• 1512B: 200/400 A, FVNR controller
• 1512BT: 200/400 A, Transformer Feeder
• 1512BP: 200/400 A, Prepared Space
This document may also be used as a reference guide for the following Bulletin
numbers:
• 1512DM: 200/400 A, VFD Input Contactor Units
• 1512DO: 200/400 A, VFD Output Contactor Units
• 1512M: 200/400 A, VFD Output Bypass Starter
• 1562F: 200/400 A, MV SMC-50 Solid-State (up to 4800V), Reduced
Voltage Starter
• 1591B: Incoming Line Unit
• 1592BF: Fused Load Break Switch for Feeders
• 1592BP: Fused Load Break Switch for Feeders, prepared space
Topic Page
Added information around stress cones 24, 39, 46
Added 3000 A Power Splicing configuration graphic 44
Added section on isolation switch maintenance 63
Added attention statement around connecting arc-resistant equipment 77
Added Appendix D, Integrated Protective Maintenance Grounding device 97
IMPORTANT This document is to be used for all Bulletin 1512A unit types, including
arc resistant (ArcShield) units. Important information specifically for
ArcShield units can be found in Appendix A, Appendix B and Appendix C.
ATTENTION: Users must refer to the information in Appendix A, Appendix B
and Appendix C to correctly install and maintain ArcShield arc resistant
units. Failure to do so may negate the arc resistant benefits provided by
ArcShield, exposing personnel to risk of serious injury or death.

8Rockwell Automation Publication 1500-UM055I-EN-P - December 2021
Preface
Download Firmware, AOP,
EDS, and Other Files
Download firmware, associated files (such as AOP, EDS, and DTM), and access
product release notes from the Product Compatibility and Download Center at
rok.auto/pcdc.
Additional Resources These documents contain additional information concerning related products
from Rockwell Automation.
You can view or download publications at rok.auto/literature.
Resource Description
Medium Voltage 450 A Contactor, Series G User Manual,
publication 1502-UM060 Provides information on handling, installing,maintaining, and troubleshooting 450 A medium
voltage contactors.
EtherNet/IP Network Devices User Manual, ENET-UM006 Describes how to configure and use EtherNet/IP devices to communicate on the EtherNet/IP
network.
Ethernet Reference Manual, ENET-RM002 Describes basic Ethernet concepts, infrastructure components, and infrastructure features.
System Security Design Guidelines Reference Manual, SECURE-RM001 Provides guidance on how to conduct security assessments, implement Rockwell
Automation products in a secure system, harden the control system, manage user access,
and dispose of equipment.
Industrial Components Preventive Maintenance, Enclosures, and Contact
Ratings Specifications, publication IC-TD002 Provides a quick reference tool for Allen-Bradley industrial automation controls and
assemblies.
Safety Guidelines for the Application, Installation, and Maintenance of
Solid-state Control, publication SGI-1.1
Designed to harmonize with NEMA Standards Publication No. ICS 1.1-1987 and provides
general guidelines for the application, installation, and maintenance of solid-state control in
the form of individual devices or packaged assemblies incorporating solid-state
components.
Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 Provides general guidelines for installing a Rockwell Automation industrial system.
Product Certifications website, rok.auto/certifications. Provides declarations of conformity, certificates, and other certification details.

Rockwell Automation Publication 1500-UM055I-EN-P - December 2021 9
Chapter 1
Installation – Standard Enclosure
Starter Identification A structure nameplate is attached to the right-side flange of the structure (see
Figure 1). Refer to the nameplate for information such as series number,
section number, NEMA enclosure type, unit ratings and bus ratings.
Figure 1 - Typical Structure Nameplate
A unit nameplate is also found in the low voltage compartment with specific
unit motor application information (see Figure 2).
IMPORTANT For information on the installation site preparation, see publication
MV-QS050.
ATTENTION: Use suitable personal protective equipment (PPE) per
local codes or regulations. Failure to do so may result in severe burns,
injury or death.

10 Rockwell Automation Publication 1500-UM055I-EN-P - December 2021
Chapter 1 Installation – Standard Enclosure
Figure 2 - Typical Unit Nameplate
Refer to these nameplates whenever you contact Rockwell Automation for
assistance. Be prepared to provide such information as series number,
structure series, unit series, diagram schematic and catalog number.
Prepared Space When ordering a starter kit to complete a prepared space(a), provide the
following information to ensure the proper components are supplied.
Series Number
Provide the series number from the structure with the prepared space. The
number is stamped on a nameplate on the right-hand flange of the starter (see
Figure 1). The series number is also available from the dimension drawings for
the starter.
Motor Data
Provide the following motor data:
• Locked rotor current
• Full load current
• Maximum locked rotor time
• Acceleration time
• Motor service factor
• Motor horsepower
(a) Not available on arc resistant cabinets.

Rockwell Automation Publication 1500-UM055I-EN-P - December 2021 11
Chapter 1 Installation – Standard Enclosure
Starter Features
Provide information regarding any special features required for the starter kit.
Indicate if these features are different from the motor control features in the
existing, complete power cell.
Recommended Torque
Values
When reinstalling components or when reassembling the cabinet, tighten the
following bolt sizes to the specified torque values:
Environmental Conditions The controller must accept nominal plant power of 2400V, 3300V, 4200V,
4800V, 5500V, 6600V, 6900V (+5/-15%), or 7200 (+0/-15%), 3 phase
50/60 Hz (± 3%).
The standard controller must operate in an ambient temperature range of
0…40 °C (32…104 °F) with a relative humidity of up to 95% (non-condensing).
Higher ambient temperature conditions are supported with factory assistance.
The equipment shall be capable of being stored in an environment with an
ambient temperature range of -40...+85 °C (-40...+185 °F).
If storage temperature fluctuates or if humidity exceeds 85%, space heaters
must be used to prevent condensation. The equipment must be stored in a
heated building having adequate air circulation.
Rockwell Automation products are built using materials that comply with
Class 1: Industrial Clean Air sulfur environments as defined in IEC Standard
60654-4 (Operating Conditions for Industrial-Process Measurement and
Control Equipment), and G1 as defined in ISO-S71.04-1985 (Environmental
Conditions for Process Measurement and Control Systems: Airborne
Contaminants).
High Altitude Application
The equipment shall operate at altitudes from 0…1000 m (0…3300 ft) above sea
level, without derating. For applications above 1000 m (3300 ft), the maximum
current and basic impulse levels (BIL) of the controllers shall be derated, and
vacuum contactors may be compensated for operation at the specified altitude
(see publication 1500-SR020).
Table 1 - Hardware Torque Values
1/4 in. hardware 8 N•m (6 lb•ft)
5/16 in. hardware 15 N•m (12 lb•ft)
3/8 in. hardware 27 N•m (20 lb•ft)
1/2 in. hardware 65 N•m (48 lb•ft)
WARNING: The equipment should never be stored outside.

12 Rockwell Automation Publication 1500-UM055I-EN-P - December 2021
Chapter 1 Installation – Standard Enclosure
Door Opening Procedure Opening the Low Voltage Doors
Low voltage doors are identified as LV in Figure 3.
1. To access the compartments for standard cabinets – use a flat-head
screwdriver and turn both of the 1/4-turn fasteners at least 90° in a
counterclockwise direction.
2. The door is now released and will swing open.
3. Reverse the procedure to secure the doors.
Figure 3 - Access to Low Voltage Compartments
Opening the Medium Voltage Doors
Medium voltage doors are identified as MV in Figure 4.
.
.
.
.
.
.
.
.
LV MV
LV MV
.
.
.
.
.
.
.
.
LV MV
LV MV
1/4-turn fasteners for
Upper Low Voltage Door
1/4-turn fasteners for
Lower Low Voltage Door
ATTENTION: Medium voltage components are located behind the
swing-out low voltage panel (standard cabinets only). Complete the
Power Lock-out procedure (see Power Lock-out Procedure on page 53)
before attempting to open the swing-out low voltage panel. Failure to
do so may result in severe burns, injury or death.
ATTENTION: Complete the Power Lock-out procedure (see Power Lock-
out Procedure on page 53) before beginning any service procedures to
the unit. Failure to do so may result in severe burns, injury or death.

Rockwell Automation Publication 1500-UM055I-EN-P - December 2021 13
Chapter 1 Installation – Standard Enclosure
Figure 4 - Access to Medium Voltage Compartments
Refer to Access to the Power Bus on page 16 for the procedure to open the
swing-out low voltage panel behind the low voltage door (for standard cabinet
only).
1. Electrically open the contactor by pressing the STOP button on the
starter or at the remote control location.
2. Move the isolation switch handle to the OFF position.
3. Unscrew the locking 3/8-1.75 bolts for both MV doors.
The doors are now released and will swing open to the left.
4. Reverse the procedure to close the door.
.
.
.
.
.
.
.
.
LV MV
LV MV
.
.
.
.
.
.
.
.
LV MV
LV MV
Door Locking Bolts for Upper
Medium Voltage Door
Door Locking Bolts for Upper
Medium Voltage Door
Isolation
Switch
Handles
IMPORTANT Each medium voltage door has its own isolation switch handle and
interlocking safeguards. Upper and lower power cells are separated
by an isolation barrier.
IMPORTANT Ensure that the swing-out low voltage panel is in its original
position before attempting to close the MV door. When closing the
medium voltage door, ensure all door locking bolts on the right side
of the MV door are in place and tightened until the door is flush with
the flange. Do not overtighten the bolts. If the door is not securely
fastened, it will not be possible to move the isolation switch handle
to the ON position.
ATTENTION: Complete the Power Lock-out procedure (see Power Lock-
out Procedure on page 53) before beginning any service procedures to
the unit. Failure to do so may result in severe burns, injury or death.

14 Rockwell Automation Publication 1500-UM055I-EN-P - December 2021
Chapter 1 Installation – Standard Enclosure
Anchoring Place the controller in the desired installation location. Use M12 (1/2 in.) floor
mounting bolts to securely fasten the controller to the mounting surface. See
Figure 5 as an example of the location of the mounting holes in the cabinet.
Figure 5 - Cabinet Floor Plan
Seismic Applications
•For installations on concrete – the minimum depth and radius of
concrete supporting the cabinet anchors is dependent on seismic loads.
Refer to important information above.
•For installations on a metal structure – the metal plate depth and cabinet
anchoring method is dependent on seismic loads.
Refer to Dimension Drawing provided with order documentation for
additional details related to cabinet floor plan.
IMPORTANT Pre-determined cabinets have been designed for Uniform Building
Code (UBC) seismic zone 1, 2A, 2B, 3 and 4, and IBC (International
Building Code) seismic activity without overturning or lateral
movement, provided they are securely mounted according to UBC,
IBC and local building codes. This can include concrete pad design,
steel floor design and the sizing of cabinet anchors. Concrete floor
cutouts must not be adjacent to floor anchor bolts and must be
sized to seismic load. Consult factory if floor mounting must be
reviewed by an accredited engineer. Many jurisdictions require an
engineer from the local area to review the design. Seismic
qualification does not indicate that the equipment will function
properly after a seismic event.
Line cable conduit opening.
Load cable conduit opening for bottom compartment.
Load cable conduit opening for top compartment.
Control wire conduit opening. Each opening provides
access to top and bottom compartments.
Mounting holes for 1/2 in. (M12) anchor bolts.
Mounting holes for 1/2 in. (M12) anchor bolts (required for
seismic applications only).
Minimum distance to concrete floor cut-out required for
seismic applications.
1.00 (25) x 3.00 (76) non removable sill channels.
All dimensions in. (mm)Front

Rockwell Automation Publication 1500-UM055I-EN-P - December 2021 15
Chapter 1 Installation – Standard Enclosure
Joining Sections
1. Position the left side of the section on a level surface and secure the
section in place with 12 mm (1/2 in. [M12]) floor mounting bolts (refer
to Anchoring on page 14).
2. When joining NEMA Type 12, apply a continuous 3 mm (1/8 in.) wide
bead of silicone sealer around the perimeter of one section.
3. Remove the side bus access covers if applicable.
4. Position the right section against the left section. Ensure that the surface
is level.
5. Secure the sections together using the 1/4-20 self-tapping screws (12 lb•ft
[15 N•m]). Thread the screw through the 7 mm (0.281 in.) clearance hole
to the corresponding 6 mm (0.219 in.) pilot hole. To access the front
clearance holes of the left-side cabinet, open the medium voltage doors.
To access the rear clearance holes remove the rear covers of the starter. If
rear access is not available, refer to Front Access– Access to Power Bus on
page 18.
6. Secure the right section to the floor using M12 (1/2 in.) floor mounting
bolts (refer to Anchoring on page 14).
Figure 6 - Joining Sections
Joining hardware can be found in a package mounted on the front
of the shipping skid. Refer to publication MV-QS050 for level floor
surface requirements.
Front
Front
Side Bus
Access Cover
0.219 Pilot
Holes (5x)
0.281 Pilot
Holes (5x)
0.281 Pilot
Holes (5x)
0.219 Pilot
Holes (3x)

16 Rockwell Automation Publication 1500-UM055I-EN-P - December 2021
Chapter 1 Installation – Standard Enclosure
Access to the Power Bus
Rear Access
1. Remove the hardware securing the center rear bus access cover (see
Figure 7).
2. Remove the center rear bus access cover.
3. Once the rear bus cover is removed, you will see the three power bus bars
and the ground bus bar (see Figure 8).
Figure 7 - Access to Power Bus from Side and Rear of Cabinet
ATTENTION: This procedure requires contact with medium voltage
components. To avoid shock hazards, lock out incoming power before
working on the equipment (see Power Lock-out Procedure on page 53).
Verify with a hot stick or appropriate voltage measuring device that all
circuits are voltage free. Failure to do so may result in severe burns,
injury or death.
Side Bus
Access Cover
Center Rear Bus
Access Cover

Rockwell Automation Publication 1500-UM055I-EN-P - December 2021 17
Chapter 1 Installation – Standard Enclosure
Figure 8 - Bus Bars from Back Access
Side Access
A side bus access cover is located on each side of the controller.
1. Remove the hardware from the appropriate side bus access cover (see
Figure 7).
2. Remove the side bus access cover.
3. Once the side bus access cover is removed, you will see the three power
bus bars and the ground bus (see Figure 9).

18 Rockwell Automation Publication 1500-UM055I-EN-P - December 2021
Chapter 1 Installation – Standard Enclosure
Figure 9 - Side Bus Access Cover Removed
Front Access– Access to Power Bus
1. Open the doors and remove the hinge pins.
2. Open the low voltage cell doors (refer to Opening the Low Voltage Doors
on page 12).
3. Disconnect the control wiring harness from the wire plug at the lower
left side of the contactor.
4. Remove the two 1/4-20 self-tapping screws from the center vertical
channel (see Figure 10).
5. Pull on the center vertical channel to swing out the low voltage panel.
ATTENTION: To avoid shock hazards, lock out incoming power (see
Power Lock-out Procedure on page 53) before working on the
equipment. Verify with a hot stick or appropriate voltage measuring
device that all circuits are voltage free. Failure to do so may result in
severe burns, injury or death.

Rockwell Automation Publication 1500-UM055I-EN-P - December 2021 19
Chapter 1 Installation – Standard Enclosure
Figure 10 - Center Vertical Channel
6. Remove each glass-polyester barrier located in front of the current
transformers (see Figure 11).
Remove self-tapping screws
from center vertical channel
Control Wiring Harness

20 Rockwell Automation Publication 1500-UM055I-EN-P - December 2021
Chapter 1 Installation – Standard Enclosure
Figure 11 - Removing Glass-polyester Barrier
7. Remove the 1/4-20 retaining screw from the cable duct barrier and
remove the barrier (see Figure 12).
8. Remove the two 1/4-20 retaining screws from the cable duct boot and
remove the boot (see Figure 12).
Current Transformers
Remove self-tapping screws
from barrier assembly
Glass-polyester barrier
